Choice 6602-001655 Dryer Drum Belt

Description

Choice Manufactured Parts

Choice 6602-001655 Dryer Drum Belt for Samsung

Aftermarket 92-inch, 5-rib / 4-groove dryer drum drive belt for select Samsung and Kenmore dryers.

Product Overview

The Choice 6602-001655 dryer drum belt transfers power from the dryer motor pulley to the drum so the drum can rotate during the drying cycle.

This Choice Manufactured Parts aftermarket belt is designed as a replacement for Samsung belt 6602-001655 on compatible dryers.

Quick Answer

6602-001655CM is a 92-inch, 5-rib / 4-groove aftermarket dryer drum belt for select Samsung and Kenmore dryers. It replaces Samsung 6602-001655 and 6602-001314. Verify the complete dryer model number before ordering.

Common Problems This Part May Fix

  • Dryer motor runs but drum does not turn
  • Broken or snapped drum belt
  • Belt is frayed, glazed, cracked, or stretched
  • Thumping or slapping noise from a damaged belt
  • Drum turns intermittently or slips under load

Replaces and Cross-References

6602-001655, 6602-001314, 5PH2337, LB1655, ASM874658, PD00002012, EAP2407938, AP4373659, PS4133825, 6602-001655CM, ER6602-001655.

Cross-reference numbers are provided for identification. This is a Choice Manufactured Parts aftermarket replacement and is not manufactured by Samsung.

Compatibility

Fits select Samsung and Kenmore dryers using the 6602-001655 / 5-rib belt configuration. Compatible model examples include:

DV203AEW/XAA
DV209AEW/XAA
DV218AEW/XAA
DV42H5200EP/A3
DV42H5600EW/A3
DV45H7000EW/A2
DV45K6500EV/A3
DV50K7500GW/A3
DVE45R6100C/A3
DVE45R6300W/A3
DVG45T6000W/A3
Kenmore 592 Series

Important: This is a partial compatibility list. Match the complete dryer model number and original belt number before purchasing.

Key Features

  • Choice Manufactured Parts aftermarket replacement
  • 92-inch drum drive belt
  • 5 ribs / 4 grooves
  • Approx. 5/16-inch belt width
  • Ribbed drive surface with smooth outer/back surface
  • For select Samsung and Kenmore dryers

Specifications

Choice Part Number 6602-001655CM
Brand Choice Manufactured Parts
Part Type Dryer Drum Drive Belt
Condition New
Part Quality Aftermarket Replacement
Length Approx. 92 in.
Width Approx. 5/16 in.
Ribs / Grooves 5 Ribs / 4 Grooves
Primary Replacement For Samsung 6602-001655
Application Dryer Drum Drive System

Installation Notes

  1. Disconnect dryer power before service.
  2. Access the drum and note the original belt routing before removal.
  3. Route the replacement belt around the drum, idler pulley, and motor pulley exactly as the original.
  4. Install the ribbed side toward the drum/pulley contact surface as required by the dryer design.
  5. Confirm the idler pulley applies proper tension and spins freely.
  6. Rotate the drum by hand before reassembly to verify smooth belt tracking.

Diagnostic tip: Before installing a new belt, inspect the idler pulley, drum support rollers, motor pulley, and felt seals. A seized or damaged support component can quickly damage a replacement belt.

FAQ

Is this a Genuine Samsung OEM belt?

No. This is a Choice Manufactured Parts aftermarket replacement for Samsung 6602-001655.

How long is the belt?

Choice specifies this belt at approximately 92 inches long.

How many ribs does it have?

It has 5 ribs and 4 grooves.

Does it replace 6602-001314?

Yes. 6602-001314 is a commonly listed earlier/cross-reference number for the 6602-001655 belt family.

Does this include the idler pulley?

No. This listing is for the drum belt only unless the product package explicitly states otherwise.

Shop With Confidence

Match your complete dryer model number and original belt number before ordering. Compatibility assistance is available if you are unsure which belt your dryer uses.

Choice Replacement92-Inch Belt5 Rib / 4 GrooveCompatibility Support
Product form

Choice 6602-001655 Dryer Drum Belt

Free Pickup in In Stock Parts-O-Matic - WB Store 1820 Featherstone Road Woodbridge, VA 22191 Usually ready in 1 hour
Online Shipped Price $22.00 List Price $14.25You Save: $7.75Delivered to your address
Store Walk-In
Discounted Price $11.30Walk-In Savings: $2.95In-store purchase only — not valid for online checkout
✓ IN STOCK
Ships Today if ordered within --:--:--
Free Pickup in our Store • Usually ready in 1 hour
Pickup Store: Parts-O-Matic — Woodbridge, VA
