XPARTCO 694089 Dryer Blower Wheel Replaces WP694089
The XPARTCO 694089 is an aftermarket replacement dryer blower wheel compatible with a wide range of Whirlpool, Kenmore, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Roper, Estate, Crosley, Inglis, Caloric, Hardwick, and Glenwood 29-inch dryers with a lint filter on top. The blower wheel works together with the drive motor to create the airflow that makes drying possible — it draws heated air through the heating element, pushes it into and through the drum to evaporate moisture from your clothes, and exhausts it out through the vent system. Without a properly functioning blower wheel, airflow drops, drying times increase dramatically, and the dryer may overheat.
Measures 8-5/8" in diameter. Mounts on the motor's blower shaft with left-hand threads — to remove the old blower wheel, turn it clockwise (the reverse of standard threading). This blower wheel fits dryers where the motor is mounted in the rear of the cabinet, not the front. Common causes of failure: the internal sleeve wears out over time, allowing the wheel to wobble on the motor shaft; lint, socks, or small clothing articles escape past the lint filter and jam the wheel; or the plastic fins crack and break from age or debris impact. It directly replaces WP694089, WP694089VP, AP6010602, 279500, 279711, 299678, 338840, 343939, 343941, 686172, 695499, DE601, PS11743785, AH383953, EA383953, and PS383953. Installs in 30–60 minutes with basic hand tools.
Quick Answer
The XPARTCO 694089 Dryer Blower Wheel fixes Whirlpool, Kenmore, Maytag, KitchenAid, Amana, Roper, Estate, and Admiral 29" dryers that take too long to dry, make loud thumping/rattling/scraping noises, have weak airflow, or won't tumble. 8-5/8" diameter. Left-hand threads (turn clockwise to remove). Fits rear-mounted motor dryers with lint filter on top. Replaces WP694089, WP694089VP, AP6010602, 279500, 279711, 299678, 338840, 343939, 343941, 686172, 695499, DE601, PS11743785. Check for trapped lint, socks, or debris before replacing — a jammed wheel may not be broken.
Common Problems This Part Fixes
- Dryer takes too long to dry clothes — reduced airflow from a worn or damaged blower wheel
- Loud thumping, rattling, or scraping noise during operation — debris caught in the wheel or broken fins
- Weak or no airflow from the exhaust vent — wheel wobbling or not spinning properly
- Clothes still damp at the end of the cycle — inadequate air circulation
- Dryer overheating — restricted airflow causing heat buildup
- Blower wheel wobbling on the motor shaft — worn internal sleeve
- Sock, small garment, or lint clump jammed in the blower wheel
- Blower wheel fins cracked or broken from debris impact or age
- Dryer running but drum not turning — severely damaged wheel preventing motor from spinning
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This dryer blower wheel directly replaces the following OEM and cross-reference part numbers:
WP694089, 694089, 279500, 279711, 299678, 338840, 343939, 343941, 695499, DE601, PD00002470, EAP11743785, AP6010602, AWP48132, OEM18031815, PS11743785
If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Note: some Whirlpool dryers use a different blower wheel (such as the 697772) — verify your original part number or model number before ordering.
Compatibility
This blower wheel is compatible with select 29-inch dryers with a lint filter on top from the following brands:
- Whirlpool dryers — 29" models with lint filter on top and rear-mounted motor (WED, LER, LEQ, LE series and related)
- Kenmore / Sears dryers — select Whirlpool-built models (110-series)
- Maytag dryers (select Whirlpool-built models)
- KitchenAid dryers (select models)
- Jenn-Air dryers (select models)
- Amana dryers (select models)
- Magic Chef dryers (select models)
- Admiral dryers (select models)
- Roper dryers (select models)
- Estate dryers (select models)
- Crosley, Inglis, Caloric, Hardwick, Glenwood dryers (select Whirlpool-built models)
Note: This blower wheel fits dryers where the motor is mounted in the rear of the cabinet (not the front). If your dryer has the motor in the front, this is not the correct blower wheel. Confirm your dryer model number before ordering. Also: before replacing the blower wheel due to noise, check for trapped lint, socks, or small garments caught in the wheel — clearing the debris may resolve the noise without needing a new part.
Key Features
- Dryer blower wheel — draws heated air through the heating element, circulates it through the drum, and exhausts it through the vent system
- Resolves "takes too long to dry," "loud noise," "weak airflow," "overheating," and "clothes still damp" symptoms when caused by a worn or damaged blower wheel
- 8-5/8" diameter — matches the original OEM dimensions
- Left-hand threads — mounts on the motor's blower shaft (turn clockwise to remove, counterclockwise to install)
- Designed for 29" Whirlpool-built dryers with lint filter on top and rear-mounted motor
- Replaces WP694089, WP694089VP, AP6010602, 279500, 279711, 299678, 338840, 343939, 343941, 686172, 695499, DE601, PS11743785, AH383953, EA383953, and PS383953
- Compatible with Whirlpool, Kenmore, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Roper, Estate, Crosley, Inglis, and more
- Aftermarket replacement built to OEM-equivalent quality standards
- DIY repair — installs in 30–60 minutes with basic hand tools
Product Specifications
| Part Number |
694089 |
| OEM Part Number |
WP694089 |
| Part Type |
Dryer Blower Wheel |
| Condition |
Aftermarket Replacement |
| Application |
29" Dryers with Lint Filter on Top (Whirlpool platform) |
| Diameter |
8-5/8" |
| Threading |
Left-hand threads (clockwise to remove) |
| Motor Position |
Rear-mounted motor (not front-mounted) |
| Function |
Circulates heated air through the drum and out the exhaust vent |
| Location |
Attached to the motor's blower shaft inside the blower housing |
| Compatible Brands |
Whirlpool, Kenmore, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Roper, Estate, Crosley, Inglis, Caloric, Hardwick, Glenwood |
Installation Notes
⚠️ Disconnect Power Before Starting — 240V Circuit (Electric) or Gas Line (Gas) — Wear Work Gloves Disconnect power at the breaker before beginning — electric dryers operate on a 240V circuit. For gas dryers, also shut off the gas supply. Wear work gloves and safety glasses. Pull the dryer away from the wall. Access the blower wheel by removing the dryer's back panel — remove the screws securing the rear panel and set it aside. Locate the blower housing at the bottom rear of the dryer, connected to the motor. The blower wheel is inside this housing, mounted on the motor's blower shaft. Remove the blower housing cover or clamp to expose the wheel. Important: the blower wheel has left-hand threads. To remove the old blower wheel, turn it clockwise (the opposite of standard threading). If the wheel is stuck on the shaft, hold the motor pulley on the other end of the shaft to prevent it from turning while you unscrew the wheel. If the old wheel's plastic hub has seized on the shaft from age, you may need to use a flat-blade screwdriver to gently pry it — some customers report the old wheel breaks apart during removal, which is fine since you're replacing it. Before installing the new wheel, clean out any lint, debris, socks, or clothing articles from the blower housing. Thread the new 694089 blower wheel onto the motor shaft counterclockwise (remember: left-hand threads — counterclockwise tightens). Tighten firmly by hand. Reassemble the blower housing, reinstall the rear panel, push the dryer back into place, and restore power. Run a test cycle and check airflow at the exhaust vent. Tools needed: Nut driver, Phillips screwdriver, flat-blade screwdriver, work gloves, safety glasses.
Frequently Asked Questions
My dryer is making a loud thumping or rattling noise — is the blower wheel the cause?
It's one of the most common causes of dryer noise, yes. There are two main ways the blower wheel causes noise: first, lint, socks, or small clothing articles can escape past the lint filter and get caught in the wheel, where they hit the housing with each rotation — producing a rhythmic thumping or scraping sound. Second, the wheel's internal sleeve can wear out over time, allowing the wheel to wobble loosely on the motor shaft, which creates a rattling or vibrating noise. Before ordering a new wheel, check for trapped debris first — pull the back panel and inspect the blower housing. Clearing a stuck sock may solve the problem immediately. If the wheel wobbles freely on the shaft or has cracked/broken fins, it needs replacement.
Why does the blower wheel have left-hand threads?
The left-hand (reverse) threading is by design. The motor shaft spins in a direction that would naturally loosen a standard right-hand threaded wheel over time. By using left-hand threads, the motor's rotation actually tightens the wheel onto the shaft during operation, preventing it from working loose while the dryer runs. This means: turn clockwise to remove the old wheel (opposite of what you'd expect), and turn counterclockwise to tighten the new wheel onto the shaft. Many customers get stuck at this step because they instinctively turn counterclockwise to loosen — so if the wheel seems stuck, try turning it the other way first.
My dryer takes forever to dry — is the blower wheel the issue?
It can be, but check the easier things first. Long drying times are usually caused by restricted airflow, and the most common culprit is a clogged or kinked exhaust vent hose — clean the entire vent path from the dryer to the outside wall first. Also clean the lint filter and check the lint trap housing for buildup. If the vent system is clear and drying times are still long, the blower wheel is a strong candidate: a worn sleeve that lets the wheel wobble reduces its ability to move air efficiently, and cracked fins reduce airflow even if the wheel still spins. You can test by running the dryer and checking the airflow at the outside exhaust vent — weak or no airflow with a clear vent path points to the blower wheel.
Does this fit dryers with the motor in the front?
No — the 694089 blower wheel is designed for 29" Whirlpool-platform dryers where the motor is mounted in the rear of the cabinet. If your dryer has the motor in the front, it uses a different blower wheel. The easiest way to confirm: look at the back of the dryer — if you can see the motor and blower housing when the rear panel is removed, the motor is in the rear and this wheel fits (verify your model number too). If the motor is accessible from the front, this is not the correct part. Contact our support team with your model number and we'll confirm.
The old blower wheel is stuck on the shaft — how do I get it off?
First, make sure you're turning it the right direction — this has left-hand threads, so turn clockwise to loosen (the opposite of normal). If it's truly stuck from age or corrosion: hold the motor pulley on the other end of the shaft with one hand (or use pliers wrapped in a cloth) to keep the shaft from spinning, then turn the blower wheel clockwise with the other hand. If the plastic hub has seized, a flat-blade screwdriver can help gently pry it. In many cases, an old seized blower wheel will crack and break apart during removal — that's perfectly fine since you're replacing it anyway. Just make sure all the old pieces are cleared from the blower housing before installing the new wheel.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is manufactured to match the 8-5/8" diameter, left-hand threading, sleeve, fin design, and airflow function of the original WP694089 blower wheel used in compatible Whirlpool, Kenmore, Maytag, KitchenAid, Amana, and related 29" dryers.
