Genuine OEM GE Range Hood Part
WB26X30785 Range Hood Genuine OEM Blower Motor Assembly
A complete manufacturer-approved blower assembly designed to circulate air and help remove cooking grease, smoke, steam, and odors from the kitchen.
Product Overview
The GE WB26X30785 Range Hood Blower Motor Assembly is the main air-moving component inside compatible range hoods. When the hood fan is switched on, the motor turns the blower wheel to pull air through the filters and move smoke, steam, grease, and cooking odors through the venting system or recirculation path.
This is a new Genuine OEM GE replacement part manufactured to the original equipment specifications. The assembly includes the blower motor and blower wheel, helping provide a more complete repair than replacing an individual motor component alone.
Quick Answer
WB26X30785 is a Genuine OEM GE range hood blower motor assembly that includes the motor and blower wheel. It replaces previous GE part number WB26X27202 and is used in select GE range hood models. Always verify your complete appliance model number before ordering.
Common Problems This Part May Fix
Range hood fan does not run
Blower starts intermittently or stops during use
Weak or reduced airflow
Smoke and cooking odors are not being removed properly
Grinding, rattling, humming, or scraping noise from the blower area
Blower wheel is damaged, loose, or difficult to turn
Replaces Part Numbers
WB26X30785, WB26X27202, AGE22285, AP6880846, EAP12716502, PD00066165, PS12716502.
WB26X30785 is the current manufacturer part number. Cross-reference numbers are included only to help identify the same component; order by your appliance model whenever possible.
Compatibility
Designed for select GE range hood models that specify part number WB26X30785 or the superseded number WB26X27202. Confirmed model examples include:
JVX5300EJ1ES
JVX5300SJ2SS
JVX5360DJ2WW
JVX5360EJ2ES
JVX5360SJ2SS
Important: This is a partial compatibility list. Range hood parts can look alike while using different mounting points, wiring connectors, motor ratings, or blower-wheel designs. Verify the complete model number from the hood identification label before purchasing.
Key Features
Genuine OEM GE replacement part
Complete blower motor and blower wheel assembly
Moves air through the range hood ventilation system
Helps remove grease, smoke, steam, and cooking odors
Manufactured for original fit and performance
Direct replacement when WB26X30785 is specified
Supersedes GE part number WB26X27202
Product Specifications
Manufacturer Part Number
WB26X30785
Brand
GE Appliances
Part Type
Range Hood Blower Motor Assembly
Condition
New
Quality
Genuine OEM
Application
Range Hood / Vent Hood
Assembly Includes
Blower Motor and Blower Wheel
Primary Function
Circulates air through the hood ventilation system
Package Quantity
1 Blower Motor Assembly
Installation Notes
Disconnect the range hood from electrical power or switch off the correct house circuit breaker before beginning service.
Remove the grease filters and any covers needed to access the blower compartment.
Photograph or label the wire connections before disconnecting the original motor assembly.
Inspect the wiring harness, connector, capacitor, mounting hardware, and vent path for additional damage or blockage.
Remove the old blower assembly and install WB26X30785 in the same position, using the original hardware when required.
Confirm that the blower wheel turns freely and does not contact the housing before reassembling the hood.
Restore power only after all covers, filters, and safety components are correctly reinstalled.
Safety: Electrical diagnosis and installation should be performed by a qualified technician when you are not experienced with appliance repair. Do not work on the hood while power is connected.
Frequently Asked Questions
Is WB26X30785 a genuine GE part?
Yes. WB26X30785 is a Genuine OEM GE Appliances replacement blower motor assembly.
What is included with the assembly?
The assembly includes the blower motor and blower wheel used to move air through the range hood.
Which part number does WB26X30785 replace?
WB26X30785 replaces the previous GE manufacturer part number WB26X27202.
Will this part fit every GE range hood?
No. It fits only select models. Compare your complete range hood model number and required manufacturer part number before ordering.
Can this assembly fix a noisy range hood?
It may correct noise caused by a worn motor, damaged blower wheel, loose shaft, or internal blower failure. First check the filters, ductwork, mounting hardware, and blower housing for obstructions or loose components.
Shop With Confidence
Purchase the correct Genuine OEM replacement part for dependable fit and performance. Verify your complete range hood model number before ordering, and contact our parts team when compatibility assistance is needed.
Genuine OEM GE Fast U.S. Shipping Compatibility Support Secure Checkout
XPARTCO WB25X10019 Microwave Light Bulb - Compatible with GE, LG, and Other Microwaves
Product Description
Illuminate your microwave’s interior with the replacement WB25X10019 Microwave Light Bulb. This part is designed for select GE, LG, and other compatible microwave models, providing bright, reliable lighting for safe and convenient operation. This Halogen Light Bulb is a replacement part for specific microwave models and ovens. It provides interior lighting, allowing you to clearly see the contents inside the appliance during operation. This illumination is essential for monitoring cooking progress and ensuring safety. You should replace the halogen light bulb if it burns out or becomes damaged. Causes of a bad halogen light bulb can include regular use over time, electrical surges, or physical impact that can cause the bulb to break.
Note: Disconnect power before installation. Verify model compatibility for proper fit.
Replaces part numbers: WB25X10019, WB36X10344, WB08X10050, WB36X10246, AH2351821, EA2351821, AP4380308, PS2351821, WB36X10213, 947124, AP3203814, PS651484, 26QBP0213, 6912A40002E, 383EW1A077A, 383EW1A077B, 6912A40002A, 1462319, 383EW1A077D, AH3530398, EA3530398, AP4457323, PS3530398.
Compatibility:
Compatible with models including but not limited to:
GE: JVM3160DFBB, JVM6175SKSS, JVM7195EKES, JNM3161MFSA, PVM9005SJSS
LG: LMV2031ST, LMV1762ST, MV1501BQ, LMV1683SW
Other: Select Kenmore, Frigidaire, and Whirlpool microwaves
Verify your model number or contact our support team for assistance.
Key Features:
✅ Brand Compatibility: Fits select GE, LG, Kenmore, Frigidaire, and Whirlpool microwaves.
🔥 Specifications: 20W, 120V, T4 halogen bulb with G8 bi-pin base.
💰 Cost-Effective Alternative: Matches OEM performance at a lower price.
🛠️ Easy Installation: Requires screwdriver; typically installed in 5–10 minutes.
🛡️ Effective Fixes: Resolves no light, dim light, or flickering in the microwave.
Product Specification
Part Number: WB25X10019
Component Type: Microwave light bulb
Material: Glass bulb, metal G8 bi-pin base
Mounting: Inserts into socket within microwave compartment
Operating Conditions: Suitable for high-heat microwave environments
Compliance: Prop 65 warning for California
Installation Notes:
Safety First: Disconnect the microwave from power before installation. Follow the owner’s manual for guidance. Avoid touching the bulb with bare hands to prevent oil residue damage.
Shop for high-quality replacement appliance parts with a 30-day return policy. Keep your dryer running safely today!
Add to cart now for a budget-friendly fix!
ERP WD12X10277 Dishwasher Lower Dish rack Roller Axle
Single Pack
Gray Color
Replaces Part Number: WD12X10277, WD12X10075, WD12X10101, WD12X10126, WD12X10261
This is an aftermarket part that can be used as a replacement for the OEM part.
California Residents only
WARNING: Cancer and/or Reproductive Harm - www.p65warnings.ca.gov
XPARTCO WE03X37318 Dryer Drum Slide - Compatible with GE, Hotpoint.
Product Description
Restore your dryer’s smooth operation with the WE03X37318 Dryer Drum Slide. This replacement slide supports the front of the dryer drum, ensuring smooth rotation. Designed for select GE, Hotpoint dryers, it fixes issues like squeaking, grinding, or improper drum rotation.
Note: Includes two drum slide. Replace all slides (typically 2–4) and inspect drum bearing for a complete repair.
Replaces part numbers: WE03X37318, WE1M504, WE01M0333, WE1M333, TJDE504, TJWE1M333, DE504, DE775, TJDE775, AH755842, EA755842, ERWE1M333, AP7217724, PS17137205.
Compatibility:
Compatible with models including but not limited to:
GE: GTD42EASJWW, GTD65EBSJWS, GTD33EASKWW, GTX33EASKWW, GTD72EBPNDG
Hotpoint: HTX24EASKWS, HTX21PASKWW
Kenmore: 363.61542410
Verify your model number or contact our support team for assistance.
Key Features:
✅ Brand Compatibility: Fits select GE, Hotpoint, and Kenmore dryer models.
🔄 Specifications: Replacement plastic drum slide, ~2–3" long, clips onto drum support for reliable rotation. 2 11/16" x 5/8" Polyethylene
💰 Cost-Effective: OEM performance at a competitive price.
🛠️ Easy Installation: Requires a screwdriver, putty knife, work gloves; typically installed in 20–40 minutes.
🛡️ Reliable Fixes: Resolves squeaking, grinding, or improper drum rotation.
Installation Notes:
Safety First: Unplug the dryer or shut off the circuit breaker before installation to avoid electrical shock.
Remove top and front panels, access drum support, remove old slides, install new slides, and reassemble. Replace all slides and inspect drum bearing and felt seal. Run a test cycle.
Shop Parts-O-Matic for high-quality replacement appliance parts with a 30-day return policy. Keep your dryer running smoothly today!
Add to cart now for a budget-friendly fix!
ERP 306508 Drum Slide, Glide, or Pad
Replaces Part Numbers: 306508, 1309, 3-12941, 3-6508, 306508VP, 312941, AH1804752, DE747, EA1804752, K35-603, AP4037304, PS1804752.
Description: This Tumbler Bearing Kit is a replacement part for specific Maytag, Amana, Whirlpool dryer models. It includes multiple replacement glides that support the movement of the tub. As it rotates during the cycle, the tub experiences friction that the bearings help manage.
This is an aftermarket part that can be used as a replacement for the OEM part.
XPFH065A Microwave 5kV 0.65A High Voltage Fuse - Compatible with LG, Samsung, Whirlpool, Sharp, Panasonic, Bosch and many other Microwaves
Product Description
Protect your microwave with the replacement XPFH065A Microwave 5kV 0.65A High Voltage Fuse. This replacement fuse safeguards the electrical system in LG, Samsung, Whirlpool, Sharp, Panasonic, Bosch, Siemens, and many other microwaves by breaking the circuit during power surges or faults (0.65A, 5.0kV). Featuring a fast-blow glass fuse (6x40mm), it resolves issues like no power, blown fuses, or intermittent failures.
Note: Includes one fuse. Disconnect power before installation. Handle glass fuse carefully. Excess cable may need to be tied back.
Replaces part numbers: XPFH065A, XPFH-065-5KV, XPFH065A, XPFH-065-5KV, F650mA L5KV, EAF36358301, AP5249671, AH3620511, EA3620511, PS3620511.
Compatibility:
Compatible with models including but not limited to:
LG, Samsung, Whirlpool, Sharp, Panasonic, Bosch, Siemens, Daewoo, Fagor, Brandt, Candy, Hitachi, De Dietrich, Proline, Scholtes, Midea, Galanz: Select models requiring 0.65A, 5.0kV fuse
Verify your model number or contact our support team for assistance.
Key Features:
✅ Brand and Models Compatibility: Fits select LG, Samsung, Whirlpool, Sharp, Panasonic, Bosch, Siemens, Daewoo, Fagor, Brandt, Candy, Hitachi, De Dietrich, Proline, Scholtes, Midea, and Galanz microwaves.
🔥 Specifications: replacement high voltage fuse with holder, 0.65A, 5.0kV, fast-blow, glass fuse.
💰 Cost-Effective Alternative: Offers OEM-equivalent performance at a lower price.
🛠️ Easy Installation: Requires needle-nose pliers, Phillips screwdriver, work gloves; typically installed in 15–25 minutes.
🛡️ Reliable Fixes: Addresses microwave not powering on, blown fuses, or intermittent power issues.
Product Specification
Part Number: XPFH065A
Fuse Type: Fast-blow, high voltage
Current Rating: 0.65A (650mA)
Voltage Rating: 5.0kV (5000V)
Fuse Material: Glass tube
Fuse Dimensions: 6mm diameter x 40mm length (1/4" x 1-5/8")
Compliance: UL-listed components, Prop 65 warning for California
Installation Notes:
Safety First: Disconnect the microwave from the power source before installation.
Shop for high-quality replacement appliance parts with a 30-day return policy. Get your microwave running today!
Add to cart now for a budget-friendly fix!
ERP 5304506516 Dishwasher Upper Spray Arm
Dishwasher Upper Spray Arm
Replaces Part Numbers: 5304506516, 154754502, 154478201, 154478202, 154607802, 154698901, 154698902, AP6036336, PS11770483.
This is an aftermarket part that can be used as a replacement for the OEM part.
California Residents only
WARNING: Cancer and/or Reproductive Harm - www.p65warnings.ca.gov
XPARTCO W10516085 Dryer lint Screen
Replaces Part Numbers: WPW10516085, W10370972, W10516085, AP6022545, PS11755878, W10211906
This is an aftermarket part that can be used as a replacement for the OEM part.
California Residents only
WARNING: Cancer and/or Reproductive Harm - www.p65warnings.ca.gov
WB06X10943CM Microwave Door Handle End Cap (White)
End Cap (White)
Black end cap used on over-the-range Microwaves.
Fits Specific GE Microwave
Made in USA
Replaces part Numbers: WB06X10943, 261301814001, 3025054, AP5790057, PS8753758.
This is an aftermarket part that can be used as a replacement for the OEM part.
California Residents only
WARNING: California’s Proposition 65
XPARTCO WB13K10003 Surface Burner Spark Electrode
The XPARTCO WB13K10003 is an aftermarket replacement spark electrode for the surface burners on GE, Hotpoint, and Kenmore gas ranges. The electrode is the small ceramic-tipped component mounted at the burner head that actually creates the spark: when you turn the burner knob, the range's spark module sends a rapid series of high-voltage electrical pulses to the electrode, which arcs across a small gap to the metal burner cap. That spark ignites the gas flowing from the burner, and the clicking sound you hear while the knob is turned is literally the sound of that spark firing over and over until the burner catches.
Because the electrode's ceramic insulator is what keeps that high-voltage pulse contained to a precise spark path, even small damage matters: a hairline crack in the ceramic can let voltage leak to ground instead of arcing at the tip, carbon and grease buildup on the tip can insulate it just enough to weaken the spark, and the metal tip itself can corrode or erode after years of sparking. A failing electrode typically shows up as a burner that clicks normally but is slow to catch, catches with a small "whoof" as gas builds up before ignition, or doesn't spark at all while the other burners on the same range work fine. It directly replaces AP2020574, 244911, AH231266, EA231266, and PS231266. GE's internal part number for this electrode is WG02F05048.
Quick Answer
The XPARTCO WB13K10003 Surface Burner Spark Electrode fixes GE, Hotpoint, and Kenmore gas ranges where a specific burner clicks but won't light, sparks weakly or intermittently, or ignites with a delayed "whoof" instead of catching right away. Ceramic-tipped spark electrode for the surface burner. Replaces AP2020574, 244911, AH231266, EA231266, PS231266. If a burner doesn't click at all, the problem is more likely the spark module or igniter switch — not this electrode.
Common Problems This Part Fixes
A specific surface burner clicks but won't ignite, while other burners work fine
Burner sparks weakly, intermittently, or only from certain knob positions
Delayed ignition — a noticeable pause with gas smell before the burner catches with a "whoof"
Clicking sound that continues well after the burner has already lit
Visible carbon buildup, grease, or discoloration on the electrode tip
Cracked, chipped, or damaged ceramic insulator visible at the base of the electrode
Electrode tip that looks corroded, pitted, or eroded compared to a new one
No spark at all from one specific burner position
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This surface burner spark electrode directly replaces the following OEM and cross-reference part numbers:
WB13K10003, WG02F05048, AP2020574, 244911, AH231266, AGE261531, PD00035924, EA231266, PS231266
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This spark electrode is compatible with select gas surface burners on ranges from the following brands:
GE gas ranges — EGR2000, EGR3000, and EGR3001 series
GE gas ranges — J2B900 and JGB910 series
GE gas ranges — JGBP27 series
Hotpoint gas ranges (select GE-built models)
Kenmore gas ranges (select GE-built models)
Westinghouse, Monogram, Café, Moffat, and Profile gas ranges (select GE-built models)
Verified model numbers include: EGR2000EC0BB, EGR2000EC0CC, EGR2000EC0WW, EGR2000EC1BB, EGR2000EC1CC, EGR2000EC1WW, EGR3000ED0BB, EGR3000ED0CC, EGR3000ED0WW, EGR3000ED1BB, EGR3000ED2BB, EGR3000ED3BB, EGR3000EH1BB, EGR3001ED1SS, EGR3001ED2SS, EGR3001ED3SS, EGR3001EF1SS, EGR3001EH1SS, J2B900BEF1BB, J2B900CEF1CC, J2B900SEF1SS, J2B900SEF2SS, J2B900WEF1WW, JGB910BEC1BB through JGB910BEC4BB, JGB910CEC1CC through JGB910CEC4CC, JGB910SEC1SS through JGB910SEC3SS, JGB910WEC1WW through JGB910WEC4WW, and the JGBP27BEA1AD through JGBP27BEA5AD range.
Note: GE uses several visually similar spark electrodes across its gas range lineup that differ in overall length and mounting angle — for example, a related electrode sold under WB13K10014 is used on other burner positions and model platforms. Some customers have reported this electrode arriving slightly longer than the original but still fitting with room to spare; if your range has very tight clearance underneath, verify your exact model number and burner position before ordering. Contact our support team with your model number if you're unsure.
Key Features
Aftermarket replacement ceramic-tipped spark electrode for gas surface burner ignition
Directs high-voltage pulses from the spark module into a precise spark path at the burner cap
Resolves "clicks but won't light," "weak or intermittent spark," and "delayed ignition" symptoms caused by a worn or damaged electrode
Ceramic insulator construction resists heat and contains the spark path
Direct drop-in replacement — mounts to the same burner head bracket and wire connector
Replaces AP2020574, 244911, AH231266, EA231266, and PS231266
Compatible with GE, Hotpoint, Kenmore, Westinghouse, Monogram, Café, Moffat, and Profile gas ranges
Aftermarket replacement built to OEM-equivalent quality standards
Product Specifications
Part Number
WB13K10003
OEM Part Number
WB13K10003 (WG02F05048)
Part Type
Gas Range Surface Burner Spark Electrode
Condition
Aftermarket Replacement
Application
Gas Range Surface Burner Ignition
Tip Material
Ceramic-insulated electrode tip
Function
Directs spark module pulses to ignite burner gas
Mounting
Burner head bracket with wire lead connector
Quantity
1 electrode
Compatible Brands
GE, Hotpoint, Kenmore, Westinghouse, Monogram, Café, Moffat, Profile
Installation Notes
⚠️ Danger — Gas Appliance Turn off the gas supply to the range at the shutoff valve and unplug the range (or shut off its circuit breaker) before beginning any work near the burners or gas line. After reassembly, check every disturbed connection for leaks using a soapy water solution — bubbling indicates a leak. If you ever smell gas at any point during this repair, do not attempt to light the range or operate any switches; leave the area immediately and contact your gas utility or a qualified technician.
⚠️ Handle The Ceramic Insulator Carefully Wear work gloves. Remove the burner grate and burner cap from the affected position to access the electrode underneath. Photograph the electrode's mounting position and wire connection before removing anything. Most electrodes are held in place with a single screw and connect to the spark module via a simple push-on wire terminal — disconnect the wire first, then remove the mounting screw and lift the old electrode free. The ceramic insulator is more fragile than it looks; avoid gripping or prying on it directly, and handle it by the mounting bracket instead. Install the new WB13K10003 in the same position and orientation, making sure the tip sits at the correct gap and angle relative to the burner cap — too far and the spark won't reach the gas port, too close and it can short against the burner base. Reconnect the wire terminal, secure the mounting screw, and reinstall the burner cap and grate. Restore the gas supply and power, then test ignition at that burner position and check for leaks at any connection you touched before considering the job complete. Tools needed: Phillips or flat-blade screwdriver (model-dependent), soapy water for leak testing, work gloves.
Frequently Asked Questions
My burner doesn't click at all when I turn the knob. Is this the right part?
Probably not, at least not by itself. If a burner produces no clicking sound whatsoever, the issue is more likely the spark module (the component that generates the high-voltage pulses) or the igniter switch behind the knob, rather than the electrode itself — an electrode can't spark if it's never receiving a pulse in the first place. This electrode is the right fix when you hear clicking at that burner position but it fails to ignite, sparks weakly, or ignites with a delay.
The burner lights but with a small "whoof" and a delay. Is that dangerous?
A delayed ignition means gas is flowing and accumulating for a moment before the spark finally catches it, which is exactly the kind of small buildup that produces that "whoof" sound and flare. It's not something to ignore — a weak or intermittent electrode is the common cause, and replacing it restores immediate, reliable ignition. If delayed ignition continues after replacing the electrode, have the burner and gas supply checked by a qualified technician rather than continuing to use it.
Can I clean the electrode instead of replacing it?
Light cleaning can sometimes help if the tip is coated in grease or food residue — gently wiping the ceramic and metal tip with a dry cloth or a small amount of rubbing alcohol may restore a weak spark caused purely by surface buildup. But if you see a cracked or chipped ceramic insulator, a visibly eroded or pitted tip, or the spark still fails after cleaning, the electrode itself has degraded and cleaning won't fix that — replacement is the correct next step.
One burner sparks weakly but the others are fine. Does that rule out the spark module?
Yes, generally. The spark module typically drives all the surface burner electrodes from the same unit, so if only one position is affected while the rest spark normally, the shared module is very unlikely to be the cause — the problem is isolated to that one electrode (or its individual wire connection). If every burner is weak or unreliable at the same time, that points toward the spark module instead.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine GE OEM part, but is manufactured to match the ceramic insulator design, tip geometry, mounting bracket, and wire connector of the original WB13K10003 electrode used in compatible GE, Hotpoint, and Kenmore gas ranges.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Quality Aftermarket Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
5 Pack - XPFH065A Microwave 5kV 0.65A High Voltage Fuse - Compatible with LG, Samsung, Whirlpool, Sharp, Panasonic, Bosch and many other Microwaves
Product Description
Protect your microwave with the replacement XPFH065A Microwave 5kV 0.65A High Voltage Fuse. This replacement fuse safeguards the electrical system in LG, Samsung, Whirlpool, Sharp, Panasonic, Bosch, Siemens, and many other microwaves by breaking the circuit during power surges or faults (0.65A, 5.0kV). Featuring a fast-blow glass fuse (6x40mm), it resolves issues like no power, blown fuses, or intermittent failures.
Note: Includes one fuse. Disconnect power before installation. Handle glass fuse carefully. Excess cable may need to be tied back.
Replaces part numbers: XPFH065A, XPFH065A, XPFH-065-5KV, F650mA L5KV, EAF36358301, AP5249671, AH3620511, EA3620511, PS3620511.
Compatibility:
Compatible with models including but not limited to:
LG, Samsung, Whirlpool, Sharp, Panasonic, Bosch, Siemens, Daewoo, Fagor, Brandt, Candy, Hitachi, De Dietrich, Proline, Scholtes, Midea, Galanz: Select models requiring 0.65A, 5.0kV fuse
Verify your model number or contact our support team for assistance.
Key Features:
✅ Brand and Models Compatibility: Fits select LG, Samsung, Whirlpool, Sharp, Panasonic, Bosch, Siemens, Daewoo, Fagor, Brandt, Candy, Hitachi, De Dietrich, Proline, Scholtes, Midea, and Galanz microwaves.
🔥 Specifications: replacement high voltage fuse with holder, 0.65A, 5.0kV, fast-blow, glass fuse.
💰 Cost-Effective Alternative: Offers OEM-equivalent performance at a lower price.
🛠️ Easy Installation: Requires needle-nose pliers, Phillips screwdriver, work gloves; typically installed in 15–25 minutes.
🛡️ Reliable Fixes: Addresses microwave not powering on, blown fuses, or intermittent power issues.
Product Specification
Part Number: XPFH065A
Fuse Type: Fast-blow, high voltage
Current Rating: 0.65A (650mA)
Voltage Rating: 5.0kV (5000V)
Fuse Material: Glass tube
Fuse Dimensions: 6mm diameter x 40mm length (1/4" x 1-5/8")
Compliance: UL-listed components, Prop 65 warning for California
Installation Notes:
Safety First: Disconnect the microwave from the power source before installation.
Shop for high-quality replacement appliance parts with a 30-day return policy. Get your microwave running today!
Add to cart now for a budget-friendly fix!
XPARTCO DE60-20066A Microwave Mounting Flat Bolt
The XPARTCO DE60-20066A is an aftermarket replacement mounting flat bolt for over-the-range microwaves, including Samsung and Maytag microwave and hood combinations. The flat bolt is the long mounting bolt that holds the microwave in place. If the original is stripped, damaged, or missing, the microwave may no longer stay securely mounted.
This bolt also replaces the GE WB01X10180 flat cab mounting bolt. Because it holds a heavy appliance in place, match it to the bolt you are replacing and make sure the microwave is properly supported while you work.
Quick Answer
The XPARTCO DE60-20066A Mounting Flat Bolt replaces a stripped, damaged, or missing mounting bolt on an over-the-range microwave. Replaces Samsung DE60-20066A and GE WB01X10180. Classic symptom: the microwave is loose on its mounting bracket, or one of the mounting bolts is stripped or missing.
Common Problems This Part Fixes
Stripped mounting bolt
Missing mounting bolt after the microwave was removed or moved
Microwave loose or not held securely against its mounting bracket
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This mounting flat bolt directly replaces the following part numbers:
DE60-20066A, ASM36399, AP4219712, OEM12659145, EAP4226718, PD00024313, PS4226718, WB01X10180, WB1X10180, AP3205964, AGE20652, AH651196, EA651196, OEM9617901, 942461, PD00035893, PS651196
DE60-20066A is the Samsung number and WB01X10180 is the GE number. Confirm against your microwave's parts diagram, or contact our support team, if your model calls out a different number.
Compatibility
This bolt is listed for Samsung and Maytag over-the-range microwaves under DE60-20066A, and for GE, Hotpoint, and Kenmore microwaves under WB01X10180, including these examples:
Samsung ME18H704SFS/AA-00, ME17R7021ES/AA-00, SMH1816S/XAA-00, SMH9151ST/XAA-00
Maytag MMV1153BAS, MMV5165BAS, UMV1152CAS
GE CVM2072SM1SS, DVM1850DM2WW, DVM1850DM4BB
Kenmore 36362702200, 36362709200
Note: The models above are a small sample of longer lists, not full lists. Compare your old bolt's length and head style to this bolt, and contact our support team with your model number to verify fit before ordering.
Key Features
Aftermarket replacement mounting flat bolt for over-the-range microwaves
Replaces Samsung DE60-20066A and GE WB01X10180
Approximately 4 inches long
Restores a secure mount when the original bolt is stripped or missing
Product Specifications
Part Number
XPDE60-20066A
OEM Part Number
DE60-20066A, WB01X10180
Part Type
Microwave Mounting Flat Bolt
Condition
Aftermarket Replacement
Length
Approx. 4 Inches
Application
Over-the-Range Microwaves (Samsung, Maytag, GE, Hotpoint, Kenmore)
Installation Notes
⚠️ Unplug Power And Support The Microwave Unplug the microwave before beginning, and wear work gloves. An over-the-range microwave is heavy, so have a helper support it, or support it from below, while you remove or loosen any fasteners. Follow your model's installation guide. In general, you remove the screws covering the mounting bolts, loosen the mounting bracket screws, replace the old bolt with the new one, then reattach the bracket and cover screws. Return the microwave to position, make sure it is firmly seated and secure, and reconnect power.
Frequently Asked Questions
My microwave is loose on its mount. Is this the part I need?
If a mounting bolt is stripped, damaged, or missing, replacing it is the usual fix. Check the bracket and the other fasteners too, and do not rely on a microwave that is not securely mounted.
Is DE60-20066A the same as WB01X10180?
DE60-20066A is the Samsung number and WB01X10180 is the GE number. This bolt is listed as a replacement for both. Compare it to your old bolt, or contact our support team with your model number, before ordering.
How many bolts come in this order?
Retailers list the equivalent GE bolt as sold individually, but do not state a pack count for every listing. Contact our support team if you need to confirm the quantity.
Will this fit my microwave?
It is listed for many over-the-range microwaves, but the model lists above are only samples. Check your model number against your parts diagram, or contact our support team and we'll verify it before you order.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout
