Genuine GE OEM Dryer Part
GE WE12X10014 Dryer Genuine OEM Drum Belt
87-inch, 4-rib drum drive belt for select GE, Hotpoint, RCA and Kenmore dryers.
Product Overview
The GE WE12X10014 Dryer Genuine OEM Drum Belt connects the dryer motor pulley to the drum so the drum can rotate during the drying cycle.
This genuine GE replacement belt is designed for compatible GE, Hotpoint, RCA, and select Kenmore dryers that use the common 87-inch, 4-rib drive belt.
Quick Answer
WE12X10014 is an approximately 87 inch long × 1/4 inch wide dryer belt with 4 ribs/ridges. It replaces several earlier GE belt numbers including WE12X42 and WE12X82.
Common Problems This Part May Fix
Dryer drum does not turn
Motor runs but drum stays still
Belt is broken, stretched, glazed, or frayed
Squealing or slapping noise from a damaged belt
Dryer will not tumble properly
Replaces and Cross-References
WE12X10014, 103C7487, 1472898, WE12X0042, WE12X0082, WE12X42, WE12X42-, WE12X42P, WE12X42R, WE12X82, WE12X82E, WE12X82P, WE12X82R, 132C7487P004, AH2350043, EA2350043, PD00000990, EAP2350043, AGE25021, AP4379804, PS2350043
Cross-reference numbers are provided for identification. This listing is for Genuine GE OEM part WE12X10014.
Compatibility
Fits select GE, Hotpoint, RCA and Kenmore dryers. Compatible model examples include:
DCLR333ET0WW
DBLR333ET0WW
DBLR333GT0WW
NVLR333ET0WB
NVLR333GT0WB
DVLR223ET0WW
DDE7200SBLWW
DDE7500GAL
DLB3400SBLWH
DWLR473ET0WW
NLLR113ET1WO
DDG7688MCL
Important: This is only a partial compatibility list. Verify the complete dryer model number and original belt part number before ordering.
Key Features
Genuine GE OEM replacement part
Approx. 87 inches long
Approx. 1/4 inch wide
4-rib / 4-ridge drive surface
Transfers motor power to dryer drum
Fits many GE-built dryer platforms
Product Specifications
Manufacturer Part Number
WE12X10014
Brand
GE Genuine OEM
Part Type
Dryer Drum Drive Belt
Length
Approx. 87 in.
Width
Approx. 1/4 in.
Ribs / Ridges
4
Condition
New
Part Quality
Genuine OEM
Package Quantity
1 Belt
Installation Notes
Unplug the dryer before service.
Access the drum and release belt tension from the idler pulley.
Remove the old belt and inspect the idler pulley and motor pulley for wear or debris.
Install the new belt with the ribbed side against the drum where specified by the dryer design.
Route the belt around the motor pulley and idler exactly as shown in the appliance service diagram.
Rotate the drum by hand to confirm smooth tracking before reassembly.
Diagnostic tip: A broken belt can result from a seized idler pulley, worn drum bearing/glides, or an obstructed drum. Inspect related components before installing the new belt.
Frequently Asked Questions
How long is WE12X10014?
It is approximately 87 inches long and 1/4 inch wide.
How many ribs does this belt have?
It has 4 ribs/ridges on the drive surface.
Does it replace WE12X42 and WE12X82?
Yes. WE12X10014 is commonly listed as the replacement for those earlier belt numbers.
Is this a Genuine GE OEM belt?
Yes. This listing is for Genuine GE OEM part WE12X10014.
Shop With Confidence
Verify the complete dryer model number before ordering. Our compatibility team can help confirm whether Genuine GE OEM WE12X10014 is correct for your dryer.
Genuine GE OEM87 Inch Belt4-Rib DesignCompatibility Support
349241T Genuine OEM Dryer Drum Roller Kit - Compatible with Whirlpool, Kenmore, Maytag
Restore smooth and quiet operation to your dryer with the 349241T Genuine OEM Dryer Drum Roller Kit. This Whirlpool-manufactured kit includes two drum rollers, four tri-rings, and one retaining washer, designed to support the drum in select Whirlpool, Kenmore, Maytag, and other compatible dryers. It addresses issues like excessive noise, vibration, or drum not tumbling, ensuring efficient drying performance. Recommended to replace both rollers at once for optimal results.
This set includes 2 drum rollers, 4 tri-ring retaining clips, and 2 retaining washers — everything needed for a complete rear roller replacement. Each roller measures 3-1/4"L x 1"W x 3-1/4"H and is constructed from rubber over a metal bearing hub with a plastic axle support. Both rollers must always be replaced at the same time. The set directly replaces 349241, 349241TVP, 8170, 8205, 337089, 340352, 661562, 3389901, 3397588, 3397590, AP3098345, PS347627, and several additional cross-reference numbers. Often replaced together with the drum belt (341241) and idler pulley (691366 or 279640) for a complete drum drive repair. Installs in 30–60 minutes with basic hand tools.
Quick Answer
349241T Genuine OEM Dryer Drum Roller Kit. This Whirlpool-manufactured kit includes two drum rollers, four tri-rings, and one retaining washer, designed to support the drum in select Whirlpool, Kenmore, Maytag, and other compatible dryers. It addresses issues like excessive noise, vibration, or drum not tumbling, ensuring efficient drying performance. Recommended to replace both rollers at once for optimal results. Replaces 349241, 8170, 8205, 337089, 3389901, AP3098345, PS347627.
Common Problems This Part Fixes
Loud thumping, rumbling, or squealing noise during the drying cycle
Grinding or scraping sound when the drum is turning
Drum turning unevenly or wobbling during operation
Drum not spinning — rollers so worn they can no longer support the drum
Squealing or squeaking that gets worse over time as roller bearings degrade
Marks or scuff lines on clothes — drum dragging against the dryer cabinet
Excessive vibration during the drying cycle
Replaces Part Numbers
This drum roller set directly replaces the following OEM and cross-reference part numbers:
349241T, 26000349241, 337089, 3389901, 3397588, 3397590, 340352, 3436, 349241, 349241TVP, 661562, 8170, 8205, 99989678, 99989679, AH347627, EA347627, K34-895, AWP39168, PD00002257, EAP347627, AP3098345, PS347627.
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This drum roller set is compatible with select 29-inch gas and electric dryers from the following brands:
Whirlpool dryers (gas and electric — 29" models)
Kenmore / Sears dryers (Whirlpool-built models)
Maytag dryers
KitchenAid dryers
Amana dryers
Roper dryers
Crosley dryers
Estate dryers
Inglis dryers
Admiral dryers
Magic Chef dryers
Note: The 349241T rollers are for 29-inch Whirlpool-family dryers. Newer Whirlpool Duet front-load dryers and larger-capacity models use different roller part numbers (such as WPW10314173 / 8536974). Always verify your model number before ordering.
Key Features
Set of 2 rear drum support rollers — supports and cradles the drum as it rotates for smooth, quiet operation
Includes all hardware: 2 rollers, 4 tri-ring retaining clips, 2 retaining washers — everything needed for a complete installation
Dimensions: 3-1/4"L x 1"W x 3-1/4"H per roller
Rubber wheel over metal bearing hub with plastic axle support — designed to resist wear and heat under continuous drum load
Both rollers must be replaced at the same time — replacing only one results in uneven drum support and accelerated wear on the new roller
Often replaced together with the drum belt (341241) and idler pulley (691366 or 279640) for a complete drum drive repair
Compatible with 11 major appliance brands on the Whirlpool 29-inch platform
Dryer Genuine OEM Part.
DIY repair — installs in 30–60 minutes with basic hand tools
Product Specifications
Part Number
349241T
Part Type
Dryer Rear Drum Support Roller Set
Condition
Genuine Whirlpool OEM
Application
29-inch Gas and Electric Dryers
Quantity
Set of 2 rollers (replace both at the same time)
Roller Dimensions
3-1/4"L x 1"W x 3-1/4"H (per roller)
Material
Rubber wheel / Metal bearing hub / Plastic axle support
Color
Black / White
Kit Includes
2 drum rollers, 4 tri-ring retaining clips, 2 retaining washers
Often Replaced With
341241 Drum Belt, 691366 or 279640 Idler Pulley
Compatible Brands
Whirlpool, Kenmore, Maytag, KitchenAid, Amana, Roper, Crosley, Estate, Inglis, Admiral, Magic Chef
Installation Notes
⚠️ Unplug Dryer Before Starting Disconnect power (and shut off gas for gas dryers) before beginning. Remove the lint screen and unscrew the screws inside the lint screen housing. Use a putty knife to release the top panel spring clips and lift the top panel. Remove the front panel to access the drum. Release the drive belt from the idler pulley, lift the drum forward, and set it aside. The rear drum support rollers are mounted on shafts on the rear bulkhead — each roller is secured with a tri-ring clip and a retaining washer. Use needle-nose pliers to remove the old tri-ring clips, then slide the old rollers off the shafts. Install the new rollers, new retaining washers, and new tri-ring clips on the shafts. Reinstall the drum, re-route the belt around the motor and idler pulley, and reassemble the front and top panels. Restore power and run a test cycle to verify quiet, smooth drum operation. Tip: while the dryer is open, inspect and replace the drum belt (341241) and idler pulley (691366 or 279640) if worn. Tools needed: Phillips screwdriver, 1/4" or 5/16" nut driver, putty knife, needle-nose pliers.
Frequently Asked Questions
What do the drum support rollers do?
The rear drum support rollers are cylindrical wheels mounted on fixed shafts at the back of the dryer cabinet. As the drum rotates, its rear outer rim rests on these rollers, which carry the drum's weight and allow it to spin smoothly and quietly. When the rubber wheels wear down or the bearing hubs corrode, the drum no longer rides smoothly on the rollers — causing thumping, rumbling, or squealing noises that get progressively worse. In severe cases, worn rollers allow the drum to sag and drag against the cabinet rear panel.
Why must I replace both rollers at the same time?
Both rear drum support rollers carry the same load and experience the same wear through every drying cycle. When one roller fails, the other has been under the same stress for the same number of cycles and is almost certainly near the end of its useful life. Replacing only the failed roller leaves one worn roller supporting the drum unevenly, which puts extra stress on the new roller and causes it to wear out much faster. Replace both rollers at the same time to ensure even drum support and get the full service life from the new parts.
Should I also replace the belt and idler pulley at the same time?
Yes — this is the ideal time. Since the dryer must be fully disassembled to access the rear drum rollers, replacing the drum belt (341241) and idler pulley (691366 or 279640) at the same time is strongly recommended. All three parts wear at similar rates, and a worn belt or idler pulley is often what caused the rollers to wear prematurely. Doing all three in one repair eliminates the most common drum drive failure points and saves you from repeating the teardown in the near future. The 4392065 maintenance kit includes all three parts together.
What causes dryer drum rollers to wear out?
Drum rollers wear naturally over time from the continuous load of supporting the rotating drum. The most common accelerating factors are operating the dryer with a worn or broken belt (which allows the drum to sag and puts extra weight on the rollers), running very large or heavy loads frequently, and allowing lint to accumulate around the roller shafts, which causes the bearings to run dry and wear faster. Regular dryer maintenance — including cleaning lint from around the drum and periodically checking the belt — helps extend roller life.
Is this an OEM or aftermarket part?
It is a genuine Whirlpool OEM part.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Genuine OEM Parts ✓ Compatibility Support ✓ Secure Checkout
XPARTCO 6602-001655 Dryer Drum Belt
The XPARTCO 6602-001655 is an aftermarket replacement dryer drum belt compatible with select Samsung and Kenmore dryers. The drum belt wraps around the outside of the dryer drum, loops around the motor pulley and idler pulley, and drives the drum to rotate during every drying cycle. Without a functioning belt, the drum cannot spin and clothes will not tumble or dry.
Made from premium neoprene rubber reinforced with polyester cords, this 5-rib belt measures 92 inches long x 5/16 inch wide and is built to resist cracking, stretching, and wear under the high heat and repeated tension cycles of daily dryer use. It is a direct drop-in replacement for OEM part numbers 6602-001655 and 6602-001314, and installs in 30–45 minutes with basic hand tools.
Quick Answer
The XPARTCO 6602-001655 Dryer Drum Belt fixes dryers where the drum is not spinning, clothes are not tumbling, or a thumping/squealing noise is coming from the dryer during operation. It drives the drum via the motor and idler pulleys. Compatible with select Samsung and Kenmore dryers. Measures 92" L x 5/16" W with 5 ribs and 4 grooves.
Common Problems This Part Fixes
Dryer drum not spinning — motor runs but drum stays still
Clothes not tumbling during the drying cycle
Thumping, squealing, or slapping noise during operation
Dryer runs but produces no heat because drum is stationary
Visible broken or frayed belt pieces found inside the dryer cabinet
Dryer shuts off shortly after starting due to drum not rotating
Replaces Part Numbers
This drum belt directly replaces the following OEM and cross-reference part numbers:
6602-001655, 6602-001314, 5PH2337, LB1655, ASM874658, PD00002012, EAP2407938, AP4373659, PS4133825.
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This drum belt is compatible with select dryers from the following brands:
Samsung dryers (gas and electric)
Kenmore / Sears dryers (select models)
Always verify your appliance model number before ordering. Contact our support team if you're unsure.
Key Features
Drives the dryer drum via the motor pulley and idler pulley for smooth, consistent tumbling every cycle
92" length x 5/16" width — 5-rib, 4-groove design for a secure, slip-free grip on the pulleys
Made from premium neoprene rubber with polyester cord reinforcement — resists cracking, stretching, and heat damage
Direct replacement for OEM part numbers 6602-001655 and 6602-001314 — no modification required
Aftermarket replacement built to OEM-equivalent quality standards
DIY-friendly repair — installs in 30–45 minutes with basic hand tools
Often replaced together with the idler pulley (DC93-00634A) and drum rollers (DC97-16782A) for a complete drum drive repair
Product Specifications
Part Number
6602-001655
Part Type
Dryer Drum Drive Belt
Condition
Aftermarket Replacement
Application
Gas and Electric Dryers
Length
92 inches
Width
5/16 inch
Height
1/8 inch
Ribs
5 ribs, 4 grooves
Material
Neoprene rubber with polyester cord reinforcement
Color
Black
Compatible Brands
Samsung, Kenmore
Often Replaced With
DC93-00634A Idler Pulley, DC97-16782A Drum Rollers
Installation Notes
⚠️ Safety First — Unplug Dryer Before Starting Unplug the dryer from the power source (and shut off the gas supply for gas dryers) before beginning any repair. To access the drum belt, remove the top panel and front panel of the dryer. Lift the drum out of the cabinet, remove the old belt, and loop the new 6602-001655 belt around the drum with the ribbed side facing inward. Route the belt slack around the idler pulley and motor pulley — consult your dryer's service manual or a model-specific video for the correct belt path around the pulleys. Reassemble the front panel, top panel, and restore power before running a test cycle. Tip: While the drum is out, this is an ideal time to also inspect and replace the idler pulley and drum support rollers if worn. Tools needed: Phillips screwdriver, putty knife or flat pry tool.
Frequently Asked Questions
Will the 6602-001655 fit my Samsung or Kenmore dryer?
This belt is compatible with select Samsung and Kenmore dryers. Use the model search above to verify your model number, or contact our support team before ordering.
What does the dryer drum belt do?
The drum belt wraps around the outside of the dryer drum and connects to the motor pulley and idler pulley. As the motor spins, it drives the belt which causes the drum to rotate, tumbling your clothes through the heated air to dry them. A broken or worn belt means the drum cannot spin.
How do I know if my drum belt is broken?
The most obvious sign is that the dryer motor runs and you can hear it humming, but the drum does not spin. You may also hear a thumping or slapping sound if the belt is slipping or partially broken. Opening the dryer cabinet and visually inspecting the belt will confirm if it is broken, frayed, or stretched.
Should I replace the idler pulley and drum rollers at the same time?
Yes — since you need to disassemble the dryer to replace the belt anyway, it is highly recommended to also inspect and replace the idler pulley (DC93-00634A) and drum support rollers (DC97-16782A) at the same time. These parts wear at a similar rate and replacing all three together prevents having to disassemble the dryer again in the near future.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Samsung OEM part, but is made from premium neoprene rubber with polyester cord reinforcement to match the dimensions and performance of the original belt.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout
XPARTCO WE03X32037 Dryer Drum Belt Replaces WE12M24
The XPARTCO WE03X32037 is an aftermarket replacement drum drive belt for GE, Hotpoint, and RCA portable, compact, and unitized stack dryers. The belt is a long, slender loop that wraps all the way around the outside of the drum, passes around the idler tension pulley, and finishes around the small drive motor pulley. That belt is the only mechanical link between the motor and the drum — there are no gears and no direct coupling — so when it breaks, the dryer behaves in a very specific way: the console lights up, the motor runs, the blower moves air, and the drum simply sits there. Open the door and spin the drum by hand and it coasts freely with no resistance at all.
This belt measures approximately 79 inches long and about 1/4 inch wide, with a 4-rib multi-groove profile molded into the inner face. The 79" length is the defining specification here — GE uses several visually similar 4-rib dryer belts across its lineup, and the difference between them is length. Belts fail from heat and age: the rubber hardens, the ribs glaze and begin slipping under a heavy wet load, and eventually the belt cracks through or snaps. Fraying edges, a squeal at startup, a rhythmic thump timed to drum rotation, or black rubber dust in the bottom of the cabinet all point to a belt nearing the end of its life. It directly replaces WE12M24, WE12M9, WE12X79, WE12X0079, AP3418890, AP7186820, PS755943, and related numbers. Installs in 45–90 minutes with basic hand tools.
Quick Answer
The XPARTCO WE03X32037 Dryer Drum Belt fixes GE, Hotpoint, and RCA portable, compact, and stack dryers where the motor runs but the drum won't turn, the drum spins freely by hand, or the dryer squeals, thumps, or rumbles during a cycle. Approximately 79" long, 1/4" wide, 4 ribs, black rubber. Fits DDP1370/DDP1375/DDP1380 portable and DSKP333/DSKS333/DSKS433 stack models. Replaces WE12M24, WE12M9, WE12X79, WE12X0079, AP3418890, AP7186820, PS755943. Not the same belt as the 89-1/2" full-size GE WE12M29 — length is what separates them.
Common Problems This Part Fixes
Dryer runs and hums but the drum does not turn — the classic broken belt symptom
Drum spins freely by hand with no resistance when the door is open
Loud squealing or screeching that begins as soon as the cycle starts
Rhythmic thumping or slapping noise timed to drum rotation — cracked or split belt
Grinding or rumbling from inside the cabinet as a frayed belt drags
Drum turns slowly, intermittently, or stalls under a heavy wet load — glazed belt slipping
Clothes not drying because the drum isn't tumbling to expose them to airflow
Black rubber dust or belt fragments in the bottom of the cabinet
Visible cracking, fraying, glazing, or stretching on the old belt
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This dryer drum belt directly replaces the following OEM and cross-reference part numbers:
WE03X32037, WE12M24, WE12M9, WE12X79, WE12X0079, AP3418890, AP7186820, PS755943, PS16729246, EAP16729246, AH755943, EA755943, 943874, AGE25647, PD00074729
WE03X32037 is the current GE part number; WE12M24 is the long-running legacy number that most service diagrams and older belts still carry. If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This drum belt is compatible with select portable, compact, and unitized stack dryers from the following brands:
GE portable and compact electric dryers — DDP1370, DDP1375, and DDP1380 series
GE unitized stack and Spacemaker laundry centers — DSKP333, DSKS333, and DSKS433 series
Hotpoint compact and stack dryers (select GE-built models)
RCA compact and stack dryers (select GE-built models)
Select Kenmore compact dryers built on the GE platform
Verified model numbers include: DDP1370GAM, DDP1370SAM, DDP1370SBM, DDP1375GAM, DDP1375GBM, DDP1375GCM, DDP1375GDM, DDP1375GEM, DDP1375SAM, DDP1375SBM, DDP1380GAM, DDP1380GBM, DDP1380GCM, DDP1380GDM, DDP1380GFM, DDP1380SAM, DDP1380SBM, DDP1380SCM, DDP1380SDM, DDP1380TAM, DSKP333EC0WH, DSKP333EC0WW, DSKP333EC2WW, DSKP333EC3WW, DSKP333EC4WW, DSKP333EC5WW, DSKP333EC6WW, DSKS333EC0WH, DSKS333EC0WW, DSKS333EC2WW, DSKS333EC3WW, DSKS333EC4WW, DSKS333EC5WW, DSKS333EC6WW, DSKS433EA0AA, DSKS433EB3WW, DSKS433EB5WW, DSKS433EB6WW, and DSKS433EB7WW.
Note — 79" portable/compact belt only: GE uses several visually identical 4-rib dryer belts that differ only in length, and they are NOT interchangeable. This belt is approximately 79 inches, for portable, compact, and stack units. It is NOT the WE12M29 / WE03X29897 belt (89-1/2") used on full-size GE dryers, NOT the WE12X10009 belt (87"), and NOT the WE12X10014 / WE12X42 belt (87-13/16"). Fitting a longer belt leaves slack the idler cannot take up, and the belt will slip or walk off the pulley within minutes. Measure your old belt end to end, or verify your full model number, before ordering. Contact our support team with your model number if you're unsure.
Key Features
Aftermarket replacement drum drive belt — transfers motor rotation to the dryer drum
Approximately 79" long, the correct length for GE portable, compact, and unitized stack dryers
4-rib multi-groove profile molded into the inner face for positive grip on the motor pulley
1/4" width matched to the original belt track and idler pulley
Durable black rubber construction that resists heat hardening and cracking
Resolves "motor runs but drum won't turn," "squealing," "thumping," and "drum spins freely by hand" symptoms
Multi-rib design prevents slipping under heavy wet loads where a worn belt would stall
Direct drop-in replacement — no cutting, splicing, or modification required
Replaces WE12M24, WE12M9, WE12X79, WE12X0079, AP3418890, AP7186820, PS755943, AH755943, EA755943, and 943874
Compatible with GE, Hotpoint, RCA, and select Kenmore compact and stack dryers
Aftermarket replacement built to OEM-equivalent quality standards
Straightforward DIY repair — installs in 45–90 minutes with basic hand tools
Product Specifications
Part Number
XPWE03X32037
OEM Part Number
WE03X32037 (formerly WE12M24)
Part Type
Dryer Drum Drive Belt
Condition
Aftermarket Replacement
Application
GE Portable, Compact, and Unitized Stack Dryers
Length
Approx. 79 in.
Width
1/4 in.
Ribs
4 ribs / 3 grooves
Material
Rubber
Color
Black
Rib Orientation
Ribbed side faces the drum
Routing
Around drum → idler tension pulley → drive motor pulley
Fuel Type
Electric and gas dryers
Quantity
1 belt
Compatible Brands
GE, Hotpoint, RCA, select Kenmore
Installation Notes
⚠️ Unplug Dryer Before Starting — Photograph Belt Routing First Disconnect power at the outlet or shut off the circuit breaker before beginning. On a gas model, also close the gas shutoff valve before moving the cabinet. Wear work gloves — the sheet metal edges inside the cabinet are sharp. Before removing anything, photograph how the old belt routes around the drum, around the idler tension pulley, and around the motor pulley. If the belt is already broken and the routing isn't visible, note that the ribbed side of the belt faces toward the drum, with the smooth back riding against the idler pulley. Access on these compact and stack units is generally from the front: remove the top panel, then the control panel and front panel, which frees the drum enough to lift or tilt it forward. Vacuum out accumulated lint while the cabinet is open — restricted airflow and lint packed around the motor are what cook belts prematurely. Slip the new belt around the drum roughly one-third of the way back from the front lip, ribbed side against the drum, and seat it in the polished wear track the old belt left behind. Reach underneath, route the belt around the idler pulley, then loop it around the small motor pulley. Useful trick: tape the belt loosely to the drum with a strip of masking tape before you reach underneath, so it can't slide off while you work the idler into position. Many GE idler arms have a locked or pre-loaded position — if yours does, remember to release it after the belt is seated, or the belt will have no tension and the drum will stall under load. Once routed, rotate the drum several full turns by hand and confirm the belt tracks straight and stays centered without walking toward an edge. While you're in there, spin the idler pulley and each drum roller by hand; if any is noisy, gritty, or has side-to-side play, replace it now, because a seized idler or flat-spotted roller will destroy the new belt quickly. Reassemble, restore power, and run a short empty cycle listening for squeal or thump before loading it. Tools needed: Phillips screwdriver, nut driver or socket set, putty knife, masking tape, flashlight, work gloves.
Frequently Asked Questions
How do I confirm the belt is broken and not the motor?
With the dryer unplugged, open the door and try to spin the drum by hand. An intact belt gives firm resistance, because you're turning the motor and idler through the belt. If the drum coasts freely like a bicycle wheel, the belt is broken or has jumped off its pulleys. Sound is the other tell: with a broken belt the motor hums and the blower whooshes normally, so the dryer sounds like it's running perfectly while the drum sits still. A failed motor usually buzzes and does nothing, or trips the breaker outright.
What's the difference between WE03X32037 and WE12M24?
They are the same belt across production revisions. WE12M24 was the long-running legacy GE number and WE03X32037 is the current number that supersedes it. If your dryer's parts diagram or the old belt itself shows WE12M24, WE12M9, WE12X79, or WE12X0079, this listing is the correct replacement. The remaining cross-references (AP3418890, AP7186820, PS755943, AH755943, EA755943, 943874) are catalog identifiers used by various parts distributors for the same belt.
Can I use a longer GE belt if this one is out of stock?
No. GE's 4-rib dryer belts look nearly identical and differ mainly in length, which is precisely why they get substituted by mistake. This belt is about 79"; the full-size GE belt WE12M29 is 89-1/2", and WE12X10009 and WE12X10014 are around 87". On a compact or portable drum, that extra 8 to 10 inches is far more slack than the idler arm can absorb, so the belt runs loose, slips on the motor pulley, and typically walks off within minutes. If you're unsure, lay your old belt flat in a loop and measure its circumference before ordering.
Which way do the ribs face?
On this GE platform the ribbed side faces toward the drum, so the ribs grip the drum surface while the smooth back of the belt rides against the idler pulley. This is worth stating plainly because rib orientation is not universal across manufacturers — some other platforms run the grooves against the motor pulley instead. Whenever possible, photograph the old belt before removing it. The polished wear track on the drum will also show you exactly where the belt is meant to sit.
The dryer squeals but the drum still turns. Belt or something else?
Could be either, and it's worth diagnosing before you order. A glazed or hardening belt squeals as it slips on the motor pulley, usually loudest at startup and under a heavy wet load. But a dry idler pulley bearing makes a very similar squeal, and worn drum rollers add a low rumble underneath. With the cabinet open, spin the idler and each roller by hand — they should turn smoothly and silently. If they're gritty, noisy, or have play, replace them along with the belt, since they share the same teardown and you'd otherwise be opening the dryer twice.
Why did my belt fail in the first place?
Usually heat and age — rubber hardens over years of thermal cycling until it cracks. Two things accelerate it sharply. Restricted airflow from a lint-clogged vent makes the whole cabinet run far hotter than designed, which cooks the belt. And a seized idler pulley or a flat-spotted drum roller forces the belt to drag against a stationary surface, shredding it in short order. If your belt failed unusually early, clean the vent ducting end to end and inspect the idler and rollers rather than assuming the new belt will simply last longer.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine GE OEM part, but is manufactured to match the dimensions (approximately 79" length, 1/4" width), 4-rib profile, rubber construction, and drum-drive function of the original WE03X32037 / WE12M24 belt used in compatible GE, Hotpoint, RCA, and related portable, compact, and unitized stack dryers.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Quality Aftermarket Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
XPARTCO 661570 Dryer Drum Belt Replaces 661570V
The XPARTCO 661570 is an aftermarket replacement dryer drum belt compatible with select Whirlpool, Maytag, Kenmore, Amana, KitchenAid, Crosley, Admiral, and Speed Queen dryers. The drum belt wraps around the outside of the dryer drum, loops around the idler pulley and motor pulley, and drives the drum to rotate during every drying cycle. Without a functioning belt, the drum cannot spin and clothes will not tumble or dry.
Made from high-strength rubber, this 4-rib belt measures 93-1/2 inches long x 1/4 inch wide x 1/8 inch high with 4 ribs and 3 grooves. It is a direct drop-in replacement for OEM part numbers 661570V and 661570, and is part of the 4392067 dryer repair kit. It pairs with the W10837240 idler pulley and WPW10314173 drum rollers for a complete drum drive overhaul. Installs in 30–45 minutes with basic hand tools.
Quick Answer
The XPARTCO 661570 Dryer Drum Belt fixes dryers where the drum is not spinning, clothes are not tumbling, or a thumping/squealing noise is present during operation. Compatible with select Whirlpool, Maytag, Kenmore, Amana, KitchenAid, Crosley, Admiral, and Speed Queen dryers. Measures 93-1/2" L x 1/4" W x 1/8" H with 4 ribs and 3 grooves.
Common Problems This Part Fixes
Dryer drum not spinning — motor runs but drum stays still
Clothes not tumbling during the drying cycle
Thumping, squealing, or slapping noise during operation
Dryer runs but produces no heat because drum is stationary
Burning rubber smell coming from the dryer
Visible broken or frayed belt pieces found inside the dryer cabinet
Dryer shuts off shortly after starting due to drum not rotating
Replaces Part Numbers
This drum belt directly replaces the following OEM and cross-reference part numbers:
661570V, 661570, 3387610, 3389728, 3393999, 339728, 4248258, 661570VP, AWP761693, OEM17951196, PD00023608, FIX382430, AP5983729, PS11722115.
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This drum belt is compatible with select dryers from the following brands:
Whirlpool dryers (gas and electric)
Maytag dryers (gas and electric)
Kenmore / Sears dryers (select Whirlpool-built models)
Amana dryers
KitchenAid dryers
Crosley dryers
Admiral dryers
Speed Queen dryers
Always verify your appliance model number before ordering. Contact our support team if you're unsure.
Key Features
Drives the dryer drum via the idler pulley and motor pulley for smooth, consistent tumbling every cycle
93-1/2" length x 1/4" width x 1/8" height — 4-rib, 3-groove design for a secure, slip-free grip on the pulleys
Made from high-strength rubber — resists cracking, stretching, heat damage, and oil
Direct replacement for OEM part numbers 661570V and 661570 — no modification required
Part of the 4392067 dryer repair kit — pairs with W10837240 idler pulley and WPW10314173 drum rollers
Aftermarket replacement built to OEM-equivalent quality standards
DIY-friendly repair — installs in 30–45 minutes with basic hand tools
Product Specifications
Part Number
661570
OEM Part Number
661570V
Part Type
Dryer Drum Drive Belt
Condition
Aftermarket Replacement
Application
Gas and Electric Dryers
Length
93-1/2 inches
Width
1/4 inch
Height
1/8 inch
Ribs
4 ribs, 3 grooves
Material
High-strength rubber
Color
Black
Compatible Brands
Whirlpool, Maytag, Kenmore, Amana, KitchenAid, Crosley, Admiral, Speed Queen
Part of Kit
4392067 Dryer Repair Kit
Often Replaced With
W10837240 Idler Pulley, WPW10314173 Drum Rollers
Installation Notes
⚠️ Safety First — Unplug Dryer Before Starting Unplug the dryer from the power source (and shut off the gas supply for gas dryers) before beginning any repair. Remove the lint screen and unscrew the Phillips screws inside the lint screen housing. Use a putty knife to release the top panel clips and lift the top panel. Remove the front panel to access the drum. Release the belt from the idler pulley, lift the drum slightly, and slide the old belt off. Loop the new 661570 belt around the drum with the ribbed side facing inward toward the drum. Route the belt around the idler pulley and motor pulley — consult your dryer's service manual or a model-specific repair video for the correct belt path. Reassemble and run a test cycle. Tip: While the drum is out, inspect and replace the idler pulley (W10837240) and drum rollers (WPW10314173) if worn. Tools needed: Phillips screwdriver, putty knife or flat pry tool.
Frequently Asked Questions
What is the difference between 661570 and 661570V?
These are the same belt. 661570V is the updated OEM part number (the "V" denotes the current version) that superseded the original 661570. Both numbers refer to the identical drum belt — this aftermarket replacement is compatible with both.
How does the 661570 differ from the 341241 and W10205415 belts?
All three are Whirlpool-family dryer drum belts, but they differ in length, width, and rib count. The 661570 is 93-1/2" long x 1/4" wide with 4 ribs and 3 grooves. The 341241 is 92-1/4" long x 1/4" wide with 4 ribs and 3 grooves. The W10205415 is 92" long x 3/8" wide with 5 ribs and 4 grooves. They are not interchangeable — always use the part number specific to your dryer model.
How do I know if my drum belt is broken?
The most obvious sign is that the dryer motor hums but the drum does not spin. You may also notice a thumping or slapping sound, a burning rubber smell, or damp clothes after a full drying cycle. Open the dryer cabinet to visually confirm if the belt is broken, frayed, or stretched out of shape.
Should I also replace the idler pulley and drum rollers?
Yes — since the dryer is already disassembled, it is highly recommended to inspect and replace the idler pulley (W10837240) and drum support rollers (WPW10314173) at the same time. All three parts wear together and are sold together in the 4392067 dryer repair kit. Replacing all three prevents having to disassemble the dryer again in the near future.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is made from high-strength rubber to match the dimensions and performance of the original 661570V belt.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout
EXP653 Dryer Idler Pulley and Belt Set Replaces 6602-001655, DC93-00634A
The EXP653 is an aftermarket replacement drum belt and idler pulley set for Samsung electric dryers, and also fits select Kenmore, Amana, and Maytag models built on the Samsung platform. These two components work together: the drum belt wraps around the drum and motor pulley to transmit rotation and keep the drum tumbling, while the idler pulley rides against the belt to maintain proper tension so it doesn't slip or sag during operation.
Over time, the belt wears, cracks, or glazes over, and the idler pulley's bearing wears out, causing it to spin roughly or seize. Because these two parts work together in the same drive path and tend to wear on a similar timeline, they're commonly sold and replaced as a set. Symptoms of failure include the dryer not starting, the drum not tumbling or spinning, and noise issues such as squealing or grinding during operation. It directly replaces 6602-001655, 6602-001314, 5PH2337, EXP645, PD00002012, EAP2407938, AP4373659, PS4133825 (drum belt), and DC93-00634A, DC97-07509B, DC61-01230B, DC96-00882B, DC96-00882C, 4455850, PD00032419, EAP11771601, AP6038887, and PS11771601 (idler pulley).
Quick Answer
The EXP653 Dryer Idler Pulley and Belt Set fixes Samsung, Kenmore, Amana, and Maytag electric dryers that won't start, won't tumble or spin, or make squealing/grinding noise during operation. Includes drum belt and idler pulley. Replaces 6602-001655, 6602-001314, 5PH2337, EXP645, PD00002012, EAP2407938, AP4373659, PS4133825, DC93-00634A, DC97-07509B, DC61-01230B, DC96-00882B, DC96-00882C, 4455850, PD00032419, EAP11771601, AP6038887, PS11771601. These two parts wear together — replacing both at once, rather than just the one that failed, helps avoid reopening the dryer again soon after.
What's In The Set
Component
Replaces
Function
Drum Belt
6602-001655
Wraps around the drum and motor pulley to transmit rotation and keep the drum tumbling.
Idler Pulley
DC93-00634A
Rides against the belt to maintain proper tension so it doesn't slip or sag.
Common Problems This Set Fixes
Dryer won't start
Drum won't tumble or spin
Squealing or grinding noise during operation
Belt slipping or sagging, causing inconsistent tumbling
Vibration or rattling from the belt/pulley area
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This dryer idler pulley and belt set directly replaces the following OEM and cross-reference part numbers:
6602-001655, 6602-001314, 5PH2337, PD00002012, EXP645, EAP2407938, AP4373659, ASM874658, PS4133825, DC93-00634A, DC97-07509B, DC61-01230B, DC96-00882B, DC96-00882C, EXP645, 4455850, PD00032419, EAP11771601, AP6038887, ASM34631, PS11771601.
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This set is compatible with select Samsung electric dryers, and also fits select Kenmore, Amana, and Maytag dryers built on the Samsung platform, including model numbers such as:
DV42H5000EW/A3, DV42H5000GW/A3, DV42H5200EF/A3, DV42H5200EP/A3, DV42H5200EW/A3, DV42H5200GF/A3, DV42H5200GP/A3, DV42H5200GW/A3
DV42H5400EF/A3, DV42H5400EW/A3, DV42H5400GF/A3, DV42H5400GW/A3, DV42H5600EP/A3, DV42H5600EW/A3, DV42H5600GP/A3, DV42H5600GW/A3
DV45H6300EG/A3, DV45H6300EW/A3, DV45H6300GG/A3, DV45H7000EW/A2, DV48H7400EW/A2, DV48J7700EW
DV45K6200EW/A3, DV45K7600EW/A3, DV40J3000EW/A2, DV48J7770EP, DV50F9A6EVW/A2, DV52J8700EP/A2, DV52J8700EW
DV330AEB/XAA, DV331AER/XAA, DV350AEP/XAA, DV350AER/XAA, DV350AEW/XAA
DV455EVGSGR/AA, DV455EVGSWR/AA, DV455GVGSGR/AA, DV455GVGSWR/AA
DV456ETHDSU/AA, DV456EWHDSU/AA, DV456EWHDWR/AA, DV456GWHDSU/AA, DV456GWHDWR/AA
DV457EVGSGR/AA, DV457EVGSWR/AA, DV457GVGSGR/AA, DV457GVGSWR/AA
Note: Always verify your full model number before ordering, since Samsung uses different belt lengths and pulley designs across its dryer lineup. Contact our support team with your model number if you're unsure.
Key Features
Aftermarket replacement set — drum belt and idler pulley in one purchase
Resolves "won't start," "won't tumble or spin," and "squealing/grinding noise" symptoms
Restores smooth drum rotation with proper belt tracking and tension
Reduces noise and vibration from a worn belt or seized pulley
Direct drop-in replacement matching the original belt length and pulley mounting
Replaces 6602-001655, 6602-001314, 5PH2337, EXP645, PD00002012, EAP2407938, AP4373659, PS4133825, DC93-00634A, DC97-07509B, DC61-01230B, DC96-00882B, DC96-00882C, 4455850, PD00032419, EAP11771601, AP6038887, and PS11771601
Compatible with Samsung, Kenmore, Amana, and Maytag electric dryers
Built to OEM-equivalent quality standards
Product Specifications
Part Number
EXP653
Set Contents
1x Drum Belt (replaces 6602-001655), 1x Idler Pulley (replaces DC93-00634A)
Condition
Aftermarket Replacement
Application
Samsung Electric Dryers
Belt Material
Black rubber
Pulley Material
Metal alloy
Repair Difficulty
Moderate — front/top panel removal required
Compatible Brands
Samsung, Kenmore, Amana, Maytag
Installation Notes
⚠️ Unplug Dryer Before Starting Disconnect power at the outlet or shut off the circuit breaker before beginning. Wear work gloves. Remove the top and front panels of the dryer to access the drum, belt, and idler pulley. Remove the old drum belt from around the drum and motor pulley. Remove the old idler pulley from its mounting bracket. Install the new EXP653 idler pulley in the same position, making sure it spins freely by hand before continuing. Route and install the new drum belt correctly around the drum and motor pulley, matching the original path exactly, and re-tension it through the idler pulley. Reinstall the drum if it was removed, then reassemble the front and top panels. Restore power and run a test cycle to confirm quiet, smooth operation with the drum tumbling normally and no squealing or grinding noise. Tools needed: 1/4" nut driver, Phillips screwdriver, work gloves.
Frequently Asked Questions
My dryer won't start. Could that really be the belt or pulley?
Yes, on some models a broken belt or seized idler pulley can prevent the dryer from starting a cycle at all, since certain safety switches rely on normal drum movement or belt tension to allow the cycle to proceed. If your dryer hums or clicks but won't fully start, or starts and immediately stops, this set is worth checking alongside more obvious suspects like the door switch.
Do I need to replace both the belt and the pulley, or just the one that failed?
You can replace just the failed component if you've confirmed which one is actually bad, but these two parts share the same drive path and tend to wear out around the same time — a seized pulley can accelerate belt wear, and a worn belt puts extra strain on the pulley. Replacing both together, since you'll already have the dryer open, helps avoid a second teardown soon after.
My dryer squeals during operation. Is that this set?
Yes, squealing or grinding noise is one of the most common symptoms addressed by this belt and pulley set, typically caused by a worn idler pulley bearing or a belt that's slipping due to lost tension.
Is this an OEM or aftermarket part?
This is an aftermarket replacement set built to OEM-equivalent quality standards. It is not a genuine Samsung OEM part, but is manufactured to match the belt length, rib pattern, and pulley design of the original 6602-001655 belt and DC93-00634A idler pulley used in compatible Samsung, Kenmore, Amana, and Maytag electric dryers.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Quality Aftermarket Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
5304511380 Replacement Dryer Drum Belt - Compatible with Frigidaire, Electrolux
Product Description
Ensure your dryer’s drum rotates smoothly with the 5304511380 Replacement Dryer Drum Belt. This replacement part is designed for select Frigidaire, Electrolux, and compatible dryers, connecting the motor to the drum to enable proper tumbling during drying cycles. It addresses issues like the drum not spinning, unusual noises, or failure to start, offering a cost-effective alternative to OEM parts with equivalent performance.
Note: Includes one dryer drum belt. Disconnect power before installation. Inspect the idler pulley and motor pulley for wear to prevent repeat failures. This is a replacement part designed to match OEM specifications.
Replaces part numbers: 5304511380, 4584320, PD00063076, EAP12176502, AP6261662, PS12176502.
Compatibility:
Compatible with models including but not limited to:
Frigidaire: FASE7073LW0, FFQE5000QW0, FARE4044MW0, FAQE7077KR0, FARE1011MW0, FFSE5115PA0
Electrolux: EIED50LIW0, EIMED60JIW0, EIMED55IIW0
Kenmore: 417.81122310, 417.91122310
Verify your model number or contact our support team for assistance.
Key Features:
✅ Brand and Models Compatibility: Fits select Frigidaire, Electrolux, and compatible Kenmore dryers.
💰 Cost-Effective Alternative: Offers OEM-equivalent performance at a lower price.
🛠️ Easy Installation: Requires screwdriver, wrench, work gloves; typically installed in 20–40 minutes with YouTube video guidance.
🛡️ Effective Fixes: Resolves drum not spinning, noisy operation, or failure to start.
Product Specification
Part Number: XP5304511380
Component Type: Dryer drum belt
Material: Durable rubber
Mounting: Loops around drum, motor pulley, and idler pulley
Operating Conditions: Suitable for high-tension dryer drum systems
Compliance: Prop 65 warning for California
Installation Notes:
Safety First: Disconnect the dryer from the power source before installation.
Tip: Access the drum by removing the dryer’s top or front panel; thread the belt through the idler pulley and around the motor pulley, ensuring proper tension. Watch YouTube videos for step-by-step guidance. Check idler pulley and motor pulley for wear to avoid premature belt failure.
Shop for high-quality replacement appliance parts with a 30-day return policy. Keep your dryer running smoothly today!
Add to cart now for a budget-friendly fix!
XPARTCO W10198086 Dryer Drum Belt Replaces WPW10198086
The XPARTCO W10198086 is an aftermarket replacement dryer drum belt for Whirlpool, Maytag, and Amana electric dryers. This belt wraps around the drum and the motor pulley, and it's what actually makes the drum turn — the motor drives the belt, and the belt tumbles the drum. When this belt breaks or wears out, the motor can still run, but nothing inside the dryer actually moves.
This is a 5-rib belt measuring approximately 92-1/2"L x 5/16"W x 1/8"H, with grooves on one side and a flat surface on the other. A broken or badly worn belt produces an unmistakable symptom: the dryer runs — you'll hear the motor and often the blower — but the drum doesn't turn at all, or turns only briefly before stopping. A simple way to confirm this diagnosis before opening the dryer is to try turning the drum by hand; if it spins freely with no resistance, the belt is almost certainly broken. Overloading the dryer with oversized loads is a common cause of belt failure over time. It directly replaces WPW10198086, W11575709, W11667279, LB8086, 1481904, AP6016842, AH2348726, EA2348726, PS2348726, EAP11750135, PS11750135, AWP49253, and PD00007598.
Quick Answer
The XPARTCO W10198086 Dryer Drum Belt fixes Whirlpool, Maytag, and Amana electric dryers where the motor runs but the drum doesn't turn, or turns only briefly. 5-rib belt, approximately 92-1/2"L x 5/16"W x 1/8"H. Replaces WPW10198086, W11575709, W11667279, LB8086, 1481904, AP6016842, AH2348726, EA2348726, PS2348726, EAP11750135, PS11750135, AWP49253, PD00007598. Try turning the drum by hand first — if it spins freely with no resistance, the belt has broken.
Common Problems This Part Fixes
Dryer runs — motor and blower audible — but the drum doesn't turn
Drum turns briefly then stops
Drum spins freely by hand with no resistance (indicating a broken belt)
Loud squeaking noise during operation from a worn but not yet broken belt
Burning rubber smell from a slipping or overheating belt
Dryer that stopped tumbling suddenly during a cycle
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This dryer drum belt directly replaces the following OEM and cross-reference part numbers:
WPW10198086, W10198086, 1481904, W11575709, W11667279, LB8086, PD00007598, EAP11750135, AP6016842, AWP49253, PS11750135
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This drum belt is compatible with select Whirlpool electric dryers, and also fits select Maytag and Amana dryers built on the same platform, including model numbers such as:
MEDC465HW0, MEDC215EW0, MEDC215EW1, MEDC200XW0, MEDC200XW1, MEDC200XW3
MEDX655DW0, MEDX655DW1, MEDX500BW0, MEDX500BW1
MEDC300BW0, MEDC300XW0, MEDC300XW1, MEDC400VW0, MEDC400BW1, MEDC415EW0
MGDC400VW0, MGDC215EW0, MGDC215EW2, MGDC465HW0, MGDC300XW3, MGDC400BW1, MGDC400BW2, MGDC500VW0, MGDC555DW1
MEDC555DW1, MEDC555DW2, MEDC100YQ0, MEDB766FW0
7MMGDC400DW0, 7MMGDC400DW1, 7MMGDC400DW2, 7MMEDC300DW1, 7MMEDC300BW0
Note: Always verify your full model number before ordering, since Whirlpool uses several different drum belts across its dryer lineup with different lengths and rib counts. Contact our support team with your model number if you're unsure.
Key Features
Aftermarket replacement drum belt — connects the motor pulley to the drum so it can turn
Resolves "motor runs but drum won't turn," "drum stops mid-cycle," and "squeaking" symptoms caused by a worn or broken belt
5-rib design with grooves on one side, flat on the other
Approximately 92-1/2"L x 5/16"W x 1/8"H
Direct drop-in replacement matching the original belt routing
Replaces WPW10198086, W11575709, W11667279, LB8086, 1481904, AP6016842, AH2348726, EA2348726, PS2348726, EAP11750135, PS11750135, AWP49253, and PD00007598
Compatible with Whirlpool, Maytag, and Amana electric dryers
Aftermarket replacement built to OEM-equivalent quality standards
Product Specifications
Part Number
W10198086
OEM Part Number
WPW10198086
Part Type
Dryer Drum Belt
Condition
Aftermarket Replacement
Length
Approx. 92-1/2 in.
Width
5/16 in.
Thickness
1/8 in.
Ribs
5
Color
Black
Material
Rubber
Repair Difficulty
Easy — 15 to 30 minutes
Quantity
1 drum belt
Compatible Brands
Whirlpool, Maytag, Amana
Installation Notes
⚠️ Unplug Dryer Before Starting — Check The Idler Pulley While You're In There Disconnect power at the outlet or shut off the circuit breaker before beginning. Wear work gloves. Lift the lint screen cover and remove the two screws underneath it — if your model has a lint screen with a built-in cover, simply pull it out and remove the screws. Run a putty knife around the top edge of the dryer to find the release clips, then press them in to release and swing the top open. Remove the front panel to access the drum and belt area; on many models, all the work for this repair is performed from the front rather than the rear. Route the new W10198086 belt around the drum with the grooved side against the drum, then loop it around the motor pulley and the idler pulley, following the routing diagram on the inside of the cabinet or your old belt's path if it's still intact when you remove it. If the belt broke rather than just wearing out, check that the idler pulley is still properly seated — a belt snapping can sometimes cause the pulley to pop out of position, and reseating it is a quick fix while you already have the panel open. Reinstall the front panel, close the top and secure the release clips, and reinstall the lint screen area and its screws. Restore power and run a test cycle to confirm the drum turns smoothly with no slipping or noise. Tools needed: Phillips screwdriver, 5/16" nut driver, putty knife, work gloves.
Frequently Asked Questions
My dryer runs but the drum won't turn. How do I confirm it's the belt before ordering?
Try turning the drum by hand with the dryer unplugged. If it spins freely with little to no resistance, that's a strong sign the belt has broken, since an intact belt normally provides some resistance from the motor and idler pulley connected to it. If the drum feels stuck or hard to turn instead, the problem may be elsewhere, such as a seized idler pulley or motor issue.
What caused my belt to break in the first place?
Belts wear out from age and normal use, but overloading the dryer with oversized or overly heavy loads is a common accelerating factor, since it puts extra strain on the belt with every rotation. Avoiding overloaded loads going forward can help the new belt last as long as it should.
While replacing the belt, I noticed the idler pulley looks out of place. Is that related?
Yes, this can happen when a belt breaks suddenly — the pulley can pop out of its normal seated position as tension is lost. Since you'll already have the panel open for the belt replacement, take a moment to check that the idler pulley is properly seated before closing everything back up, as this is a common and easy thing to overlook.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is manufactured to match the length, width, rib count, and routing configuration of the original WPW10198086 drum belt used in compatible Whirlpool, Maytag, and Amana electric dryers.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Quality Aftermarket Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
EXP445 Dryer Repair Kit – Compatible with LG and Kenmore Dryers
Product Description
Eliminate dryer noise and restore smooth drum rotation with the EXP445 Dryer Repair Kit, designed for select LG and Kenmore dryers. This high-quality aftermarket replacement kit includes all the essential components — drum rollers, idler pulley, and drive belt — to replace worn or noisy parts. A failing roller or belt can cause squealing, thumping, or the drum not turning properly. Installing this all-in-one kit brings quiet, efficient operation back to your dryer at an affordable price.
Replaces Part Numbers
Drum Rollers Replaces 4581EL2002L, AGM75510755, 4581EL2002H, 4581EL2002C, 4581EL2002A, 4581EL2002D, 4581EL2002E, 4581EL3001A, 4581EL3001C, 4581EL3001F, AP7220429, PS17269866.
Drum Belt Replaces: 4400EL2001F, 4400EL2001A, 4115028, 4400EL2001C, 4400EL2001E, AP5972814, PS11705916.
Idler Pulley Assembly Replaces: 4561EL3002A, 4561EL3002B, AH3523033, EA3523033, AP4438243, PS3523033.
Compatibility
This replacement repair kit fits select LG and Kenmore dryers.
Example compatible models include (but are not limited to): LG DLE7177WM, LG DLE5955W, LG DLEX3470V, and Kenmore 796.81022900.
Always verify your dryer’s model number before ordering. Contact our support team if you’re unsure.
✅ Key Features
🔄 Aftermarket Replacement Kit – Designed specifically for LG dryers
🔇 Restores Quiet Operation – Replaces worn rollers, belt, and pulley to reduce noise
💰 Complete Solution – All major moving parts included in one repair bundle
🛠️ DIY Friendly – Easy installation using standard hand tools
🛡️ Fixes Common Issues – Solves loud squealing, drum not spinning, or uneven drying
📐 Product Specification
Part Number: EXP445
Component Type: Dryer Maintenance Kit
Included Components:
(4) Drum Support Rollers
(1) Idler Pulley
(1) Drive Belt
Material: Reinforced rubber belt, metal rollers, and high-strength bearings
Mounting: Direct-fit replacement for LG dryer assemblies
Compliance: Built to OEM-equivalent quality standards (not OEM)
🛠️ Installation Notes
Tools Needed: Phillips screwdriver, nut driver, needle-nose pliers
⚠️ Safety First: Always unplug the dryer before beginning repairs to prevent electrical shock.
Steps:
Unplug dryer and remove top and front panels.
Release belt tension and lift drum out of cabinet.
Replace rollers, pulley, and belt with new kit components.
Reassemble dryer and reconnect power.
Test dryer for smooth, quiet rotation.
⏱️ Time Required: 30–45 minutes
📦 Shop With Confidence
🚚 Free Shipping on All Orders
🛠️ Trusted Appliance Parts Supplier
🔄 30-Day Return Policy
Get your LG dryer running like new — Add to Cart Now for a complete, cost-effective repair kit!
XPARTCO W10849499 Dryer Drum Belt
The XPARTCO W10849499 is an aftermarket replacement drum belt for Whirlpool's large-capacity dryer platform. The belt wraps all the way around the outside of the drum, passes around the idler tension pulley, and loops around the drive motor pulley — that belt is the only mechanical connection between the motor and the drum, so when it breaks, the console still lights up, the motor still hums, and the blower still moves air, but the drum sits completely still. Open the door and spin the drum by hand and it will turn freely with no resistance.
This belt measures approximately 97.75 inches long. Belts fail from age and heat: the rubber hardens over years of thermal cycling, the ribs glaze over and begin slipping under a heavy wet load, and eventually the belt cracks through or snaps outright. A worn or seized idler pulley is also a common root cause of premature belt failure, since a pulley that won't turn freely forces the belt to drag continuously against a stationary surface until it shreds. Squealing or chirping at startup, a rhythmic thump timed to drum rotation, fraying at the edges, or black rubber dust in the cabinet are all signs a belt is near the end of its life. As an aftermarket replacement, the W10849499 is built to OEM-equivalent quality standards. It directly replaces AP5989682, 4383705, PS11731121, and W10610882.
Quick Answer
The XPARTCO W10849499 Dryer Drum Belt fixes Whirlpool large-capacity dryers where the motor runs but the drum won't turn, the drum spins freely by hand, or the dryer squeals, chirps, or thumps during operation. Approximately 97.75" long. Replaces AP5989682, 4383705, PS11731121, W10610882. If your belt broke due to a worn idler pulley rather than simple age, replace the pulley (PS334244) at the same time or the new belt will wear out quickly too.
Common Problems This Part Fixes
Dryer runs and hums but the drum does not turn — the classic broken belt symptom
Drum spins freely by hand with no resistance when the door is open
Loud squealing, chirping, or scraping noise from inside the dryer
Rhythmic thumping or slapping noise timed to drum rotation — cracked or split belt
Drum turns slowly, intermittently, or stalls under a heavy wet load — glazed belt slipping
Clothes not drying completely, or drying taking longer than it used to
Broken belt pieces or fragments found inside the drum
Visible cracking, fraying, glazing, or stretching on the old belt
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This dryer drum belt directly replaces the following OEM and cross-reference part numbers:
W10849499, W10610882, AP5989682, 4383705, AWP42591, EAP11731121, OEM17969055, PD00046442, PS11731121
W10610882 was the immediately preceding number for this same belt. If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This drum belt is compatible with select large-capacity Whirlpool-built dryers across the Whirlpool family of brands, including:
Whirlpool large-capacity electric and gas dryers
Maytag dryers (select Whirlpool-built models)
KitchenAid, Jenn-Air, and Amana dryers (select models)
Magic Chef, Admiral, Norge, Roper, and Inglis dryers (select models)
Select Kenmore and Ikea dryers built on the Whirlpool platform
Verified model numbers include: YWED8500DC, YWED8000DW, YWED8500DW, 7MWGD8000E, and 7MWGD8500E.
Note: Whirlpool uses several different drum belt lengths across its dryer lineup, and this one is approximately 97.75" long — different from the shorter belts used on other Whirlpool-built platforms. Belts of a similar rib profile but a different length are not interchangeable; a belt that's too long or short for your drum will slip, walk off the pulley, or fail to seat properly. Verify your model number, or measure your old belt end to end, before ordering. Contact our support team with your model number if you're unsure.
Key Features
Aftermarket replacement drum belt for Whirlpool's large-capacity dryer platform
Approximately 97.75" in length
Wraps around the drum, idler tension pulley, and drive motor pulley to transfer motor rotation to the drum
Resolves "motor runs but drum won't turn," "squealing or chirping," and "drum spins freely by hand" symptoms
Direct drop-in replacement — no cutting, splicing, or modification required
Replaces W10610882, AP5989682, 4383705, and PS11731121
Compatible with Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Inglis, and Kenmore large-capacity dryers
Aftermarket replacement built to OEM-equivalent quality standards
Product Specifications
Part Number
W10849499
OEM Part Number
W10849499 (formerly W10610882)
Part Type
Dryer Drum Drive Belt
Condition
Aftermarket Replacement
Application
Whirlpool Large-Capacity Dryers
Length
Approx. 97.75 in.
Routing
Around drum → idler tension pulley → drive motor pulley
Fuel Type
Electric and gas dryers
Companion Part
Idler pulley PS334244 (check/replace if belt failed prematurely)
Quantity
1 belt
Compatible Brands
Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Inglis, Kenmore
Installation Notes
⚠️ Unplug Dryer Before Starting — A Second Person Helps Support The Drum Disconnect power at the outlet or shut off the circuit breaker before beginning. On a gas model, also close the gas shutoff valve before moving the cabinet. Wear work gloves — sheet metal edges inside the cabinet are sharp. On many large-capacity models, both the front and rear panels need to come off to fully access the belt and drum, so budget extra time compared to a simpler platform. Photograph how the old belt routes around the drum, the idler pulley, and the motor pulley before removing anything. Loosen and remove the motor mount or bracket as needed to slip the old belt free, and check the idler pulley by spinning it with your fingers — if it's stiff, gritty, or doesn't spin freely, replace it at the same time, since a worn pulley is a common cause of premature belt failure and will shorten the life of the new belt. With the front panel off, the drum may need to be supported by hand as it comes free — having a second person hold the drum steady makes this significantly easier and reduces the risk of scratching the drum or dropping it. Vacuum out accumulated lint while the cabinet is open. Place the new belt around the drum, seat it in the polished wear track left by the old belt, then route it around the idler pulley and around the motor pulley. Reinstall the motor mount, rotate the drum by hand to confirm the belt tracks straight and stays centered, then reassemble the front and rear panels. Restore power and run a short empty cycle listening for squeal or thump before loading it. Tools needed: nut driver or bit driver, open-end wrench, Phillips screwdriver, work gloves, and ideally a second person to support the drum.
Frequently Asked Questions
How do I confirm the belt is broken and not the motor?
With the dryer unplugged, open the door and try to spin the drum by hand. An intact belt gives firm resistance, because you're turning the motor and idler through the belt. If the drum coasts freely like a bicycle wheel, the belt is broken or has jumped off its pulleys. Sound is the other tell: with a broken belt the motor hums and the blower whooshes normally, so the dryer sounds like it's running perfectly while the drum sits still.
My belt broke and I noticed the idler pulley felt stiff. Do I need to replace that too?
Yes, strongly consider it. A worn or seized idler pulley is a well-documented cause of belt failure — if the pulley can't spin freely, it drags against the belt continuously instead of rolling with it, which wears through even a brand-new belt quickly. If your old belt broke and the pulley feels stiff, gritty, or doesn't spin smoothly when you turn it by hand, replace the idler pulley (part PS334244) along with the belt to avoid repeating this repair soon.
Is this the same length as your other Whirlpool dryer belt listings?
Not necessarily — Whirlpool uses different belt lengths across different dryer platforms even when the rib profile looks similar. This belt is approximately 97.75" long, which is specific to the large-capacity platform it's designed for. Always check your model number or measure your old belt's total length before ordering, since a belt of the wrong length will not seat and tension correctly.
Why does replacing this belt need two people?
On this large-capacity platform, accessing the belt often means removing the front panel and freeing the drum, which is heavy and can be awkward to support single-handedly while also working with your other hand. A second person holding the drum steady while you route the new belt reduces the risk of the drum shifting, scratching the finish, or being dropped. It's not strictly required, but it makes the job considerably easier.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is manufactured to match the approximately 97.75" length and rib profile of the original W10849499 / W10610882 belt used in compatible Whirlpool, Maytag, KitchenAid, Jenn-Air, and related large-capacity dryers.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Quality Aftermarket Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
341241 Dryer Genuine OEM Drum Belt
The 341241 is a Genuine OEM dryer drum belt compatible with a wide range of Whirlpool-family dryers including Whirlpool, Kenmore, Maytag, KitchenAid, Amana, Roper, Admiral, Jenn-Air, Estate, Magic Chef, Crosley, Inglis, Norge, Modern Maid, Hardwick, Caloric, and Ikea. The drum belt wraps around the outside of the dryer drum, loops around the motor pulley and idler pulley, and drives the drum to rotate during every drying cycle. Without a functioning belt, the drum cannot spin and clothes will not tumble or dry.
Made from high-strength rubber with reinforced ribs, this belt measures 92-1/4 inches long x 1/4 inch wide and features 4 ribs and 3 grooves. It is flat on one side and ribbed on the other, and is built to resist cracking, stretching, and wear under the high heat and repeated tension cycles of daily dryer use. It also replaces some 5-rib, 4-groove belts. Installs in 30–45 minutes with basic hand tools.
Quick Answer
The 341241 Dryer Genuine OEM Drum Belt fixes dryers where the drum is not spinning, clothes are not tumbling, or a thumping/squealing noise is coming from the dryer. Compatible with Whirlpool, Kenmore, Maytag, KitchenAid, Amana, Roper, Admiral, Jenn-Air, Estate, Magic Chef, Crosley, Inglis, and more. Measures 92-1/4" L x 1/4" W with 4 ribs and 3 grooves.
Common Problems This Part Fixes
Dryer drum not spinning — motor runs but drum stays still
Clothes not tumbling during the drying cycle
Thumping, squealing, or slapping noise during operation
Dryer runs but produces no heat because drum is stationary
Burning rubber smell coming from the dryer
Visible broken or frayed belt pieces found inside the dryer cabinet
Clothes taking too long to dry due to drum not rotating at correct speed
Replaces Part Numbers
This drum belt directly replaces the following OEM and cross-reference part numbers:
341241, 14210003, 2008, 26000341241, 26000349533, 31001026, 31531589, 3389628, 3392665, 3394651, 3399844, 341241VP, 345473, 349533, 529597, 53-0186, 53-1080, 53-1086, 53-1528, 53-1589, 53-2671, 53-2910, 660996, 660997, 661561, 693306, 694088, 694416, 694868, 695055, 697388, 8066065, 8206, 8210, 920H4, 920H5, 99906951, 99989673, 99989674, FSP341241, LB276, LB279, P46-037, P46-149, W10127457, W10131364, AH346995, AP32, EA346995, ER341241, AWP39161, PD00002263, EAP346995, AP2946843, PS346995, TJ341241.
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This drum belt is compatible with select dryers from the following brands:
Whirlpool dryers (gas and electric)
Kenmore / Sears dryers (select models)
Maytag dryers
KitchenAid dryers
Amana dryers
Roper dryers
Admiral dryers
Jenn-Air dryers
Estate dryers
Magic Chef dryers
Crosley dryers
Inglis dryers
Norge, Modern Maid, Hardwick, Caloric, and Ikea dryers
Always verify your appliance model number before ordering. Contact our support team if you're unsure.
Key Features
Drives the dryer drum via the motor pulley and idler pulley for smooth, consistent tumbling every cycle
92-1/4" length x 1/4" width — 4-rib, 3-groove design; flat on one side, ribbed on the other
Also replaces some 5-rib, 4-groove belts — wide cross-compatibility across Whirlpool-family models
Made from high-strength rubber with reinforced ribs — resists cracking, stretching, and heat damage
Direct replacement for OEM part numbers 341241 and 8066065 — no modification required
Compatible with over a dozen major appliance brands built on the Whirlpool platform
Genuine OEM part — factory-exact fit, materials, and dimensions
DIY-friendly repair — installs in 30–45 minutes with basic hand tools
Often replaced together with the idler pulley (691366) and drum rollers (349241T) for a complete drum drive repair
Product Specifications
Part Number
341241
Part Type
Dryer Drum Drive Belt
Condition
Genuine OEM
Application
Gas and Electric Dryers
Length
92-1/4 inches
Width
1/4 inch
Ribs
4 ribs, 3 grooves
Profile
Flat on one side, ribbed on the other
Material
High-strength rubber with reinforced ribs
Color
Black
Compatible Brands
Whirlpool, Kenmore, Maytag, KitchenAid, Amana, Roper, Admiral, Jenn-Air, Estate, Magic Chef, Crosley, Inglis, Norge, Modern Maid, Hardwick, Caloric, Ikea
Often Replaced With
691366 Idler Pulley, 349241T Drum Rollers
Installation Notes
⚠️ Safety First — Unplug Dryer Before Starting Unplug the dryer from the power source (and shut off the gas supply for gas dryers) before beginning any repair. Remove the lint screen, then unscrew the two Phillips screws inside the lint filter housing. Use a putty knife 2 inches from each front corner to release the top panel clips and lift the top panel. Remove the front panel to access the drum. Release belt tension at the idler pulley, lift the drum slightly, and slide the old belt off. Loop the new 341241 belt around the drum with the ribbed side facing down (toward the drum). Route the belt around the idler pulley and motor pulley — consult your model's service manual or a model-specific video for the correct belt path. Reassemble and run a test cycle. Tip: While the drum is out, inspect and replace the idler pulley (691366) and drum rollers (349241T) if worn. Tools needed: Phillips screwdriver, putty knife or flat pry tool.
Frequently Asked Questions
How does the 341241 differ from the W10205415 and 6602-001655 belts?
All three are 92-inch dryer drum belts, but they differ in width and rib count. The 341241 is 1/4" wide with 4 ribs and 3 grooves. The W10205415 is 3/8" wide with 5 ribs and 4 grooves. The 6602-001655 is 5/16" wide with 5 ribs and 4 grooves designed for Samsung dryers. Always match the part number to your specific model — do not substitute based on appearance alone.
Will this belt fit my Kenmore dryer?
Many Kenmore dryers — especially the popular 110-series — are manufactured by Whirlpool and use the 341241 belt. Check your model number against the compatibility list and contact our support team if you need help confirming the fit before ordering.
How do I know if my drum belt needs to be replaced?
The most obvious sign is that the dryer motor hums but the drum does not spin. You may also notice a thumping or slapping sound during operation, a burning rubber smell, or clothes that are damp after a full cycle. Open the dryer cabinet to visually confirm if the belt is broken, frayed, or stretched.
Should I also replace the idler pulley and drum rollers?
Yes — since the dryer is already disassembled, it is highly recommended to inspect and replace the idler pulley (691366) and drum support rollers (349241T) at the same time. These parts wear at a similar rate and replacing all three together — often sold as a repair kit — prevents having to disassemble the dryer again in the near future.
Is this an OEM or aftermarket part?
This is a Genuine OEM part manufactured by Whirlpool to factory specifications. It is the exact same belt that came installed in your dryer from the factory — same materials, dimensions, and performance.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Genuine OEM Parts ✓ Compatibility Support ✓ Secure Checkout
XPARTCO WR51X10055 Refrigerator Defrost Heater Assembly
The XPARTCO WR51X10055 is an aftermarket replacement refrigerator defrost heater and bracket assembly compatible with a wide range of GE, Hotpoint, Kenmore, Haier, Americana, Monogram, and Café refrigerators. The defrost heater is a glass quartz tube heater mounted on a bracket below the evaporator coils in the freezer compartment. During each automatic defrost cycle, the heater energizes and melts any frost that has accumulated on the evaporator coils — maintaining unobstructed airflow through the coils so the refrigerator can cool efficiently. When the heater fails, frost accumulates on the coils unchecked, blocking airflow and causing both the freezer and fresh food sections to gradually warm up.
Rated at 120V, 725W, this single quartz tube heater assembly measures 12-1/8" L x 3-3/8" W x 2-1/8" H and includes the heater element and mounting bracket. It directly replaces WR51X10030, AP3183311, 914088, AH303781, EA303781, PS303781, SH323, and EAP303781. Often replaced together with the defrost thermostat (WR50X10068) and temperature sensor (WR55X10025) for a complete defrost system repair. Installs in 20–30 minutes with basic hand tools.
Quick Answer
The XPARTCO WR51X10055 Refrigerator Defrost Heater Assembly fixes GE and Hotpoint refrigerators where frost is building up on the evaporator coils, the freezer is too warm, the fresh food section is warming up, or the refrigerator is running continuously without cooling properly. Single quartz tube heater, 120V / 725W. Assembly measures 12-1/8" L x 3-3/8" W x 2-1/8" H. Includes heater and bracket. Replaces WR51X10030, AP3183311, 914088, SH323, and more. Compatible with GE, Hotpoint, Kenmore, Haier, Americana, Monogram, and Café.
Common Problems This Part Fixes
Frost or ice buildup covering the evaporator coils in the freezer compartment
Freezer section warming up or not maintaining set temperature
Fresh food section warming up even though the freezer is running
Refrigerator running continuously but not cooling properly
Visible frost accumulation on the freezer back wall behind the panel
Defrost heater element visibly burned out, broken, or dark/charred at the ends
Both compartments gradually warming up after working normally for years
Replaces Part Numbers
This defrost heater assembly directly replaces the following OEM and cross-reference part numbers:
WR51X10055, WR51X10030, 914088, AGE29323, AH303781, AP3183311, EA303781, EAP303781, PD00001004, PS303781.
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This defrost heater is compatible with select refrigerators from the following brands:
GE refrigerators (side-by-side, French door, top-freezer, and bottom-freezer)
Hotpoint refrigerators
Kenmore / Sears refrigerators (select GE-built models)
Haier refrigerators (select GE-platform models)
Americana refrigerators
Monogram refrigerators
Café refrigerators
Tip: When replacing the defrost heater, it is highly recommended to also replace the defrost thermostat (WR50X10068) and temperature sensor (WR55X10025) at the same time. These three parts form the defrost system and are commonly replaced together — replacing all three prevents a second disassembly if another component fails soon after.
Key Features
Single quartz tube glass heater — melts frost from the evaporator coils during each automatic defrost cycle, maintaining airflow and cooling efficiency
Rated 120V / 725W — correct electrical specifications for compatible GE refrigerators
Assembly dimensions: 12-1/8" L x 3-3/8" W x 2-1/8" H — direct fit into the evaporator coil bracket
Includes heater element and mounting bracket — complete assembly ready to install
Replaces WR51X10030 and WR51X10055 — both older and current part numbers covered
Compatible with GE, Hotpoint, Kenmore, Haier, Americana, Monogram, and Café refrigerators
Often replaced together with WR50X10068 defrost thermostat and WR55X10025 temperature sensor
Aftermarket replacement built to OEM-equivalent quality standards
DIY repair — installs in 20–30 minutes with basic hand tools
Product Specifications
Part Number
WR51X10055
Also Replaces
WR51X10030
Part Type
Refrigerator Defrost Heater and Bracket Assembly
Condition
Aftermarket Replacement
Heater Type
Single quartz tube glass heater
Voltage
120V AC
Wattage
725W
Dimensions
12-1/8" L x 3-3/8" W x 2-1/8" H
Includes
Heater element and mounting bracket
Often Replaced With
WR50X10068 Defrost Thermostat, WR55X10025 Temperature Sensor
Compatible Brands
GE, Hotpoint, Kenmore, Haier, Americana, Monogram, Café
Installation Notes
⚠️ Unplug Refrigerator Before Starting — Wear Work Gloves Unplug the refrigerator before beginning. Remove all food and shelving from the freezer compartment. Remove the freezer bottom drawer and the back panel screws (typically 2 hex-head screws). Slide out the back panel to expose the evaporator coils and defrost heater assembly. If the coils are covered in frost or ice, use a hair dryer to melt the ice before removing the heater — do not chip or force the heater free while iced over, as the glass element is fragile and will break. Disconnect the heater wires from the wiring harness — note the orientation before disconnecting. Remove the 2 Phillips screws securing the heater bracket and lift the heater assembly out. Install the new WR51X10055 heater assembly in the same position, reconnect the wires, and reinstall the bracket screws. Reinstall the back panel, shelving, and food. Restore power and verify the defrost cycle operates normally. Wear work gloves throughout — the evaporator area has sharp edges. Tools needed: Phillips screwdriver, 1/4" nut driver, hair dryer (if coils are iced over), work gloves.
Frequently Asked Questions
What does the refrigerator defrost heater do?
Modern refrigerators use an automatic defrost system that periodically runs a defrost cycle — typically once or twice a day — to melt frost that accumulates on the evaporator coils during normal operation. The defrost heater is a glass quartz heating element that energizes during this cycle and melts the frost off the coils. This keeps the coils clear so air can flow freely through them to cool the refrigerator. When the heater fails, frost builds up unchecked on the coils over days or weeks — eventually blocking airflow completely and causing both compartments to warm up, even though the compressor is still running.
How do I know if my defrost heater has failed?
Remove the freezer back panel to expose the evaporator coils. If the coils are heavily coated in frost or solid ice — especially if both the freezer and refrigerator sections have been warming up — a failed defrost heater is the most likely cause. You can confirm with a multimeter: disconnect the heater and probe both wire ends. A working heater shows continuity (resistance between approximately 10–200 ohms at room temperature depending on wattage). No continuity confirms the heater element has burned out. Also visually inspect the glass tube — a burned, blackened, or broken tube is a clear sign of failure.
Should I also replace the defrost thermostat and temperature sensor?
Yes — since the freezer must be fully emptied and the back panel removed to replace the heater, it is highly recommended to also replace the defrost thermostat (WR50X10068) and temperature sensor (WR55X10025) at the same time. All three components form the defrost system and wear at similar rates. A failed thermostat or sensor can cause the heater to run too long or not at all — replacing all three in a single repair eliminates that risk and saves you from another complete freezer teardown in the near future.
My freezer is warming up but the compressor is running — is it the defrost heater?
It often is — but not always. A compressor that is running but not cooling can be caused by a failed defrost heater (frost blocking airflow), a faulty evaporator fan motor (air not circulating), a defrost thermostat or timer failure, or a sealed system problem (refrigerant leak or compressor issue). The easiest way to distinguish a defrost system failure from other causes is to open the freezer and check whether frost has built up on the back panel or coils. If yes, the defrost heater is the most likely culprit. If the coils are clear and the compressor is running, look at the evaporator fan or sealed system next.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine GE OEM part, but is manufactured as a single quartz tube glass heater rated at 120V/725W to match the dimensions and performance of the original WR51X10055 defrost heater assembly.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout
