WB24X25013 Genuine OEM GE Range Surface Burner Infinite Switch Replaces WB24X47186.
The WB24X25013 is a genuine GE OEM infinite control switch for a dual (bridge) surface element on GE, Hotpoint, and select Kenmore electric ranges — the kind of burner with an inner coil and an outer coil that can be run together for a large pot or as the inner coil alone for a small pan. Because it's governing two coil zones instead of one, this switch uses six terminal connections rather than the three or four found on a standard single-element infinite switch, and it mounts to the control panel with a distinctive figure-8 style shaft and two female mounting holes.
Like any infinite switch, it doesn't have fixed heat positions — instead it rapidly cycles power to the element(s) on and off at a ratio set by the knob, giving continuous heat adjustment from warm to high rather than a handful of steps. Rated for 240VAC at 15 amps. Over years of cycling, the internal contacts on a switch like this wear, pit, or weld together, and boilovers or spills can corrode the switch body and cause it to fail. A worn switch on a dual-element burner can produce an unusually wide symptom set: the whole burner may fail, or just the outer ring may stop responding while the inner coil still works, or the burner may stay on continuously regardless of the knob position. It directly replaces WB24X47186, 191D4774P005, AP5999509, PS11729102, EAP11729102, and 4464832. As a genuine OEM part, the WB24X25013 is manufactured by GE to factory specifications — guaranteed fit, materials, and performance.
Quick Answer
The WB24X25013 Genuine OEM GE Range Surface Burner Infinite Switch fixes GE, Hotpoint, and Kenmore electric ranges with a dual (bridge) element burner where the burner won't turn on or off, only the outer ring fails to work while the inner coil still heats, the burner stays on continuously, or heat can't be adjusted. Six-terminal switch, figure-8 shaft, 240VAC / 15A. Replaces WB24X47186, 191D4774P005, AP5999509, PS11729102, EAP11729102, 4464832. Not the same switch as a standard single-element infinite switch — this one is specific to dual/bridge burners with an inner and outer coil.
Common Problems This Part Fixes
Dual-element burner won't turn on at all when the knob is turned
Outer ring of a dual/bridge element won't activate while the inner coil still works
Burner won't turn off — stays hot even with the knob at the off position
Burner stuck at one heat level regardless of where the knob is set
No ability to adjust temperature — always full blast or always low
Intermittent burner operation — works sometimes, not others
Knob feels loose, gritty, or doesn't turn smoothly through its range
Burner failure that followed a boilover or liquid spill on the control panel
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This range surface burner infinite switch directly replaces the following OEM and cross-reference part numbers:
WB24X25013, WB24X47186, 191D4774P005, AGE1543754, AP7216136, PS11729102, PS17872685, EAP11729102, 4464832, 191D4774P005, MDSA-W767-GEM
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This dual-element infinite switch is compatible with select GE, Hotpoint, and Kenmore electric ranges equipped with a dual (bridge) surface element, including model families such as:
GE JB6, JB7, and JB8 series electric ranges (including JB630, JB640, JB645, and JB655)
GE JBS series electric ranges
GE JS6 and JS7 series electric ranges (including the JS760 series)
GE GRS and GRF series electric ranges
Hotpoint electric ranges (select GE-built models)
Select Kenmore electric ranges built on the GE platform
Verified model numbers include: JB645RK6SS, JS760EP6ES, JS760DP6WW, JS760SP7SS, JS760DP7WW, JS760SP6SS, JS760FP7DS, JS760FP6DS, JS760EP7ES, JB860EJAES, JB860FJADS, and GRS500PV1SS.
Note: This is a six-terminal switch built specifically for a dual (bridge) element with a figure-8 style shaft and two female mounting holes — it is NOT interchangeable with a standard single-element infinite switch such as the WB24T10029 or WB24T10025, which use fewer terminals and a different shaft profile. Fitting a standard single-element switch to a dual-element burner circuit will not correctly control both coil zones. Always verify your full model number and confirm the affected burner is a dual/bridge element before ordering. Contact our support team with your model number if you're unsure.
Key Features
Genuine GE OEM part — factory-specified contact design for dual-element switching
Six-terminal design controls both the inner coil and outer ring of a dual (bridge) surface element
Figure-8 style shaft with two female mounting holes matched to the original control panel bracket
Infinite switch design allows continuous heat adjustment rather than a handful of fixed positions
Rated 240VAC at 15 amps
Resolves "burner won't turn on," "outer ring not working," "won't turn off," and "stuck at one heat level" symptoms caused by worn or corroded switch contacts
Direct drop-in replacement — mounts to the same control panel bracket and wiring harness
Replaces 191D4774P005, AP5999509, PS11729102, EAP11729102, and 4464832
Genuine OEM replacement — guaranteed fit, materials, and performance
Product Specifications
Part Number
WB24X25013
Part Type
Range Surface Burner Infinite Switch (Dual/Bridge Element)
Condition
Genuine OEM
Brand
GE
Element Type Controlled
Dual (bridge) surface element — inner coil + outer ring
Terminal Connections
6
Shaft Style
Figure-8
Mounting
Two female mounting holes
Voltage
240VAC
Amperage
15A
Function
Cycles element power to allow continuous (infinite) heat adjustment across both coil zones
Quantity
1 switch
Compatible Brands
GE, Hotpoint, select Kenmore
Installation Notes
⚠️ 240V Circuit — Unplug Range Or Shut Off Breaker Before Starting Disconnect power at the outlet or shut off the circuit breaker before beginning — this switch operates on a 240V circuit, and working on it while powered presents a serious shock hazard. Wear work gloves. Remove the burner knob (it typically pulls straight off, though some models use a small retaining clip) then remove the screws securing the control panel or backsplash to reach the switch from behind. Photograph the wiring before disconnecting anything — this is a six-terminal switch, and getting even one wire out of place can miswire the inner coil, the outer ring, or both. Label each wire as you remove it. Disconnect all six terminal connections from the old switch, then remove the mounting screws from the two mounting holes and pull the switch free from its figure-8 shaft opening. Install the new WB24X25013 in the same orientation, reconnect each of the six wires exactly as labeled, and secure the mounting hardware. Reinstall the control panel or backsplash, press the knob back onto the shaft, restore power, and test the burner at every knob position — confirm the inner coil and outer ring both activate correctly (together and, if your model supports it, with the outer ring switched off independently) before considering the repair complete. Tools needed: Phillips screwdriver, nut driver, wire terminal pliers (helpful but optional), work gloves.
Frequently Asked Questions
How do I know if my burner uses a dual-element switch like this one?
Look at the burner element itself: a dual (bridge) element has two distinct coil rings — a smaller inner coil and a larger outer ring — usually with a separate control or a knob position that lets you activate just the inner coil for a small pan or both rings together for a large pot. A standard single-ring element has only one coil and uses a simpler switch with fewer terminals. If your range has this two-ring burner design, the WB24X25013 (or the exact switch behind it) is the correct type — but always confirm your model number, since dual-element switches vary by range generation.
Only the outer ring of my dual burner doesn't work. Is it the switch or the element?
It could be either, and it's worth narrowing down before ordering. If the inner coil heats normally but the outer ring never activates at any knob position, check the outer ring element itself first — a broken element coil is a common and cheaper fix than a switch. If the outer ring element tests fine but the switch's six-terminal wiring specific to the outer coil circuit has failed or corroded, the infinite switch is the correct replacement.
Can I use a standard single-element infinite switch instead if this one is out of stock?
No. A standard single-element switch has fewer terminals and cannot correctly control the two separate coil zones of a dual (bridge) burner. Wiring a single-element switch into a dual-element circuit will leave one coil zone permanently uncontrolled or non-functional. Always order the six-terminal dual-element switch specified for your model.
What does "infinite switch" mean?
An infinite switch lets you dial in a continuous range of heat rather than a few fixed positions, by rapidly cycling the element's power on and off at a ratio set by the knob — low settings get short power pulses, high settings get long ones. When the internal contacts wear or weld together from years of cycling, the switch can get stuck feeding constant power (burner always hot) or stop switching at all (burner always off), regardless of where the knob is turned.
A spill got into the control panel and now the burner won't turn off. Is that the switch?
Very likely, yes. Liquid boilovers and spills are one of the most common causes of infinite switch failure — moisture gets into the switch body, corrodes or bridges the internal contacts, and the switch can end up stuck feeding power continuously even with the knob turned to off. If you suspect this, shut off power to the range immediately at the breaker rather than relying on the knob, since a shorted switch may not respond to it at all.
Is this an OEM or aftermarket part?
This is a genuine OEM part, manufactured by GE to factory specifications — guaranteed fit, materials, and performance. It matches the original six-terminal wiring, figure-8 shaft, 240VAC/15A electrical rating, and dual-coil switching behavior of the infinite switch originally installed for the dual (bridge) element in your GE, Hotpoint, or Kenmore range.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Genuine OEM Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
WB24T10029 Genuine OEM GE Range Surface Burner Control Switch
The WB24T10029 is a genuine GE OEM surface burner control switch — also called an infinite switch — for the 6-inch surface element on GE, Hotpoint, and select Kenmore electric ranges and cooktops. This switch is what the burner knob actually turns: it doesn't have fixed positions like a light switch, but instead cycles the element's power on and off at varying ratios as you rotate the knob, which is why it's called an "infinite" switch — it lets you dial in a continuous range of heat levels rather than a handful of fixed steps. Turn the knob to a low setting and the switch feeds the element power only briefly out of every few seconds; turn it toward high and the element stays powered for most of that same window.
This switch is rated for 1,500 watts and controls a 6-inch surface element, drawing 4.4–7.4A at 240V. Over years of use the internal contacts wear, pit, or weld from repeated on/off cycling, and moisture from boilovers or spills can corrode the switch body and cause it to short internally. A worn switch produces predictable symptoms: the burner won't turn on or off at all, it sticks at one heat level no matter where the knob is turned, or it works only intermittently. It directly replaces 769696, AP2024076, AH236754, EA236754, and PS236754. As a genuine OEM part, the WB24T10029 is manufactured by GE to factory specifications — guaranteed fit, materials, and performance.
Quick Answer
The WB24T10029 Genuine OEM GE Range Surface Burner Control Switch fixes GE, Hotpoint, and Kenmore electric ranges where a surface burner won't turn on or off, stays at one heat level regardless of the knob setting, or works intermittently. This is the 6-inch element switch — 1,500W, 4.4–7.4A at 240V. Replaces 769696, AP2024076, AH236754, EA236754, PS236754. Not the same switch as the WB24T10025 used on the 8-inch element — check which burner is affected before ordering.
Common Problems This Part Fixes
Surface burner won't turn on at all when the knob is turned
Burner won't turn off — stays hot even with the knob at the off position
Burner stuck at one heat level regardless of where the knob is set
No ability to adjust temperature — always full blast or always low
Intermittent burner operation — works sometimes, not others
Burner cycles unpredictably, on and off faster or slower than the knob setting suggests
Knob feels loose, gritty, or doesn't click through its normal range of motion
Burner failure that followed a boilover or liquid spill on the control panel
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This range surface burner control switch directly replaces the following OEM and cross-reference part numbers:
WB24T10029, 769696, AP2024076, AH236754, EA236754, EAP236754, AGE22522, PD00008555, PS236754
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This surface burner control switch is compatible with select GE, Hotpoint, and Kenmore electric ranges and cooktops using a 6-inch surface element, across a very wide range of model families, including:
GE JB, JBP, JCBP, and JBS series electric ranges
GE RB and RA series electric ranges
Hotpoint RB series electric ranges (select GE-built models)
Select Kenmore electric ranges built on the GE platform
This switch fits several thousand model variants across GE's electric range lineup, including common families such as JB250, JB350, JB500, JB600 through JB870, JBP10 through JBP99, JCBP35 through JCBP85, JBS07, JBS27, JBS55, JBS60, JBS86, RA724, RB536, RB540, RB560, RB585, RB720, RB740, RB757, RB758, RB787, RB790, RB798, and RB800 — each spanning many color and revision suffixes. Because the model list is extremely long, always verify your full model number against your range's data label, located inside the storage drawer or along the back panel, before ordering.
Note — 6-inch element switch only: GE ranges typically pair a smaller 6-inch element with a larger 8-inch element, and each uses its own dedicated infinite switch. The WB24T10029 is the switch for the 6-inch element. The larger 8-inch element on the same range uses the separate WB24T10025 switch (replaces 769692, AP2024072, AH236750, EA236750, PS236750) instead. The two switches look nearly identical and are easy to mix up when ordering — before you buy, confirm which specific burner has failed and measure or check the element size. Contact our support team with your model number if you're unsure which switch you need.
Key Features
Genuine GE OEM part — factory-specified contact design and heat-cycling calibration
Infinite switch design allows continuous heat adjustment rather than a handful of fixed positions
Rated for the 6-inch surface element — 1,500 watts, 4.4–7.4A at 240V
Resolves "burner won't turn on," "burner won't turn off," "stuck at one heat level," and "intermittent operation" symptoms caused by worn or corroded switch contacts
Direct drop-in replacement — mounts to the same control panel bracket and wiring harness
Replaces 769696, AP2024076, AH236754, EA236754, and PS236754
Compatible with a wide range of GE, Hotpoint, and Kenmore electric range models
Genuine OEM replacement — guaranteed fit, materials, and performance
Product Specifications
Part Number
WB24T10029
Part Type
Range Surface Burner Control Switch (Infinite Switch)
Condition
Genuine OEM
Brand
GE
Element Size Controlled
6 in.
Wattage Rating
1,500 W
Amperage
4.4–7.4 A
Voltage
240V
Function
Cycles element power to allow continuous (infinite) heat adjustment
Mounting
Control panel bracket, knob shaft, and wiring harness terminals
Quantity
1 switch
Compatible Brands
GE, Hotpoint, select Kenmore
Installation Notes
⚠️ 240V Circuit — Unplug Range Or Shut Off Breaker Before Starting Disconnect power at the outlet or shut off the circuit breaker before beginning — this switch operates on a 240V circuit, and working on it while powered presents a serious shock hazard. Wear work gloves. Access is from the front of the control panel: remove the burner knob (it typically pulls straight off, though some models use a small retaining clip or screw), then remove the screws securing the control panel or backsplash to reach the switch from behind. Photograph the wiring before disconnecting anything — this switch has multiple terminals and getting one out of order will affect either the wrong burner or its heat-cycling behavior. Disconnect the wire terminals from the old switch, noting or labeling each one, then remove the mounting screws or clips holding the switch to the panel and pull it free. Install the new WB24T10029 in the same orientation, reconnect each wire terminal exactly as labeled, and secure the mounting hardware. Reinstall the control panel or backsplash, press the knob back onto the shaft, restore power, and test the burner through its full range from low to high to confirm smooth, continuous heat adjustment. Tools needed: Phillips screwdriver, nut driver, wire terminal pliers (helpful but optional), work gloves.
Frequently Asked Questions
How do I know if I need the WB24T10029 or the WB24T10025?
It depends entirely on which burner has failed. Most GE ranges pair a smaller 6-inch element with a larger 8-inch element, and each has its own dedicated infinite switch. The WB24T10029 is for the 6-inch element; the WB24T10025 is for the 8-inch element. Look at your range and identify which specific burner is misbehaving, then measure that element's diameter if you're not sure — the two switches are not interchangeable even though they look nearly identical side by side.
What does "infinite switch" mean, and why does mine only work at one setting?
An infinite switch lets you dial in a continuous range of heat rather than a few fixed positions, by rapidly cycling the element's power on and off at a ratio set by the knob — low settings get short power pulses, high settings get long ones. When the internal contacts wear or weld together from years of cycling, the switch can get stuck feeding constant power (burner always hot) or stop switching at all (burner always off), regardless of where the knob is turned. That "stuck at one heat level" complaint is the classic symptom of a failing infinite switch.
A spill got into the control panel and now the burner won't turn off. Is that the switch?
Very likely, yes. Liquid boilovers and spills are one of the most common causes of infinite switch failure — moisture gets into the switch body, corrodes or bridges the internal contacts, and the switch can end up stuck feeding power continuously even with the knob turned to off. If you suspect this, shut off power to the range immediately at the breaker rather than relying on the knob, since a shorted switch may not respond to it at all.
My burner works but only at high heat no matter where I turn the knob. Could it be something else?
The infinite switch is the most common cause, but it's worth a quick visual check first. Make sure the knob itself is properly seated on its shaft — a knob that's been pushed on at the wrong angle, or whose shaft has worn round, can make it feel like the switch isn't responding even though it is. If the knob is properly seated and turns smoothly through its full range but the heat output doesn't change, the switch's internal contacts have failed and replacement is the correct fix.
Is this an OEM or aftermarket part?
This is a genuine OEM part, manufactured by GE to factory specifications — guaranteed fit, materials, and performance. It matches the original 1,500W, 4.4–7.4A, 240V electrical rating and the heat-cycling behavior of the infinite switch originally installed for the 6-inch element in your GE, Hotpoint, or Kenmore range.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Genuine OEM Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
XPARTCO 8273103 Gas Range Burner Knob (Black) – Replaces WP8273103 – Compatible with Whirlpool, Maytag & KitchenAid Ranges
Product Description
Restore smooth and precise burner control with the XPARTCO 8273103 Gas Range Burner Knob (Black). This high-quality aftermarket replacement knob fits securely onto the burner control shaft, allowing accurate flame adjustment from low to high heat settings.
A cracked, loose, or broken knob can make it difficult to regulate temperature or safely turn the burner off. Replacing it with this durable XPARTCO knob restores proper control and enhances everyday cooking convenience.
XPARTCO provides cost-effective aftermarket appliance parts engineered to match original fit and function.
Replaces Part Numbers
WP8273103, 8273103, 8273107, 8273111, 831219, WP8273103VP, ER8273103, PD00005537, EAP393678, AP6012363, PS11745570.
Compatibility
This replacement gas range burner knob fits select Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, and Kenmore (Whirlpool-manufactured) gas ranges.
Common compatible models include (but are not limited to):
Whirlpool WFG320M0BS
Maytag MGR6600FZ
KitchenAid KFGG500ESS
Always verify your range’s model number before ordering.Contact our support team if you’re unsure.
✅ Key Features
🔄 Aftermarket Replacement – Matches OEM fit and appearance
🔥 Precise Flame Control – Smooth adjustment from simmer to high heat
🧩 Direct Push-On Fit – Secure installation onto control shaft
💪 Durable Plastic Construction – Built for daily kitchen use
🎨 Black Finish – Matches original style
💰 Cost-Effective Repair – Affordable alternative to OEM knobs
📐 Product Specification
Part Number: 8273103
Component Type: Gas Range Burner Control Knob
Material: High-strength molded plastic
Color: Black
Mounting: Push-on / shaft-fit
Application: Gas range surface burner control
Quality Level: Aftermarket replacement (not OEM)
🛠️ Installation Notes
Tools Needed: None
⚠️ Safety First: Ensure all burners are turned off and cool before installing the knob.
Basic Steps:
Confirm burner control is in the OFF position.
Align the new XPARTCO 8273103 knob with the control shaft.
Press firmly until fully seated.
Rotate to verify smooth operation and proper engagement.
⏱️ Time Required: Under 2 minutes
📦 Shop With Confidence
🚚 Free Shipping on All Orders
⚙️ Trusted Aftermarket Appliance Parts
🔄 30-Day Return Policy
Restore safe, precise burner control in seconds — Add to Cart Now for a quick, budget-friendly fix!
8053720 Range Genuine Surface Burner Igniter
Replaces: W11032529, 8053720, W10850843, W10896683, 3186479, 3186480, 3186482, 3186486, 4455849, AP6038814, PS11770331.
8053720 Range Surface Burner Igniter – Genuine OEM Replacement
Ensure reliable burner ignition on your gas range with the 8053720 Surface Burner Igniter. This Genuine OEM part provides the spark needed to ignite the burner quickly and safely.
Key Features:
✅ Replaces: W11032529, 8053720, W10850843, W10896683, 3186479, 3186480, 3186482, 3186486, 4455849, AP6038814, PS11770331.
✅ Compatible with Whirlpool, KitchenAid, Maytag, and more
⚡ Supplies consistent spark to surface burner
🛠️ Durable ceramic construction for long-lasting use
🧰 Easy to install – OEM fit and function
⚠️ Disconnect power and gas before installation. Need help confirming compatibility? Contact us!
📦 Part Number: 8053720
XPARTCO 7733P410-60 Surface Burner Knob (Replaces WP7733P410-60)
Product Overview
The XPARTCO 7733P410-60 Surface Burner Knob (Replaces WP7733P410-60) is designed to control the heat level of your range’s surface burners. This durable replacement knob restores precise control and a clean, finished look to your cooktop.
Quick Answer
If your stove knob is cracked, loose, missing, or difficult to turn, the 7733P410-60 burner knob is likely worn. Replacing it restores proper control of burner heat settings.
Replaces Part Numbers
Replaces OEM part number: WP7733P410-60, 7733P410-60, 74007733, WP7733P410-60VP, EAP11744702, AWP48511, PD00004326, AP6011505, PS11744702.
Compatibility
This surface burner knob is compatible with select Whirlpool, Maytag, Amana, and other compatible ranges.
Whirlpool Ranges
Maytag Ranges
Amana Ranges
Always verify your appliance model number before ordering.
Common Problems This Part Fixes
Broken or cracked knob
Knob slipping or not turning properly
Missing control knob
Difficulty adjusting burner heat
Key Features
Restores precise burner control
Easy push-on installation
High-quality aftermarket replacement
Durable construction for daily use
Product Specifications
Part Number: 7733P410-60
Part Type: Surface Burner Knob
Brand: XPARTCO
Condition: New
OEM / Aftermarket: Aftermarket
Application: Range Cooktop Control
Troubleshooting Guide
Knob spins freely → Worn internal insert
Cannot adjust flame → Damaged knob
Knob falls off → Cracked or loose fit
When Should You Replace This Knob?
Replace this knob if it is cracked, loose, missing, or no longer controls burner settings accurately.
Installation Notes
⚠️ Ensure the appliance is off. Pull the old knob straight off the control shaft and push the new knob firmly into place.
Related Parts
Surface Burner Valve
Igniter Switch
Control Panel Overlay
Frequently Asked Questions
Will this knob fit my range?This knob fits many Whirlpool and compatible models. Always verify your model number.
Is installation difficult?No, most knobs are push-on and can be replaced without tools.
What are signs of a bad knob?Cracks, slipping, or inability to control heat settings.
Is this OEM or aftermarket?This is a high-quality aftermarket replacement part.
Shop With Confidence
Parts-O-Matic is a U.S.-based appliance parts retailer specializing in OEM and high-quality replacement parts. We offer fast shipping, reliable products, and expert support.
Fast Shipping Quality Tested Parts Compatibility Support
WPW10411934 Range Genuine OEM Surface Element Switch – Compatible with Whirlpool, Maytag & KitchenAid Ranges
Product Description
Restore precise burner temperature control with the WPW10411934 Range Genuine OEM Surface Element Switch. This Genuine OEM switch is engineered by the original manufacturer to control the heat output of electric surface elements. A faulty surface element switch can cause burners to stay on high, not heat at all, or cycle inconsistently. Replacing it with this authentic OEM part ensures proper electrical performance, safe operation, and factory-level reliability.
This part is a Genuine OEM component, manufactured to exact specifications for fit, durability, and long-term performance.
Replaces Part Numbers
WPW10411934, W10411934, 4446483, PD00033778, EAP11754410, AP6021089, PS11754410.
Compatibility
This Genuine OEM surface element switch fits select Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, and Kenmore (Whirlpool-manufactured) electric ranges.
Common compatible models include (but are not limited to):
Whirlpool WFE515S0ES
Maytag MER8800FZ
KitchenAid KERA205PB
Always verify your range’s model number before ordering.Contact our support team if you’re unsure.
✅ Key Features
🏭 Genuine OEM Part – Manufactured to original factory specifications
🔥 Accurate Heat Regulation – Restores proper burner temperature control
⚡ Safe Electrical Operation – Designed for correct voltage and load handling
🎛️ Smooth Adjustment – Ensures responsive burner control
🔧 Exact Fit & Direct Replacement – No modifications required
📐 Product Specification
Part Number: WPW10411934
Component Type: Surface Element Control Switch
Voltage: 240V
Application: Electric range surface burner control
Mounting: Shaft-mounted behind control panel
OEM Status: Genuine OEM
🛠️ Installation Notes
Tools Needed: Phillips screwdriver, nut driver
⚠️ Safety First: Disconnect power at the breaker before servicing the range to avoid electrical shock.
Basic Steps:
Turn off power to the range at the breaker.
Remove the control knob and access the control panel.
Label and disconnect wires from the old switch.
Remove mounting screws and remove the old switch.
Install the new WPW10411934 Genuine OEM switch.
Reconnect wiring, reassemble the control panel, and restore power.
Test burner operation.
⏱️ Time Required: 20–30 minutes
📦 Shop With Confidence
🏭 Genuine OEM Appliance Part
🚚 Free Shipping on All Orders
🔄 30-Day Return Policy
Restore factory-level burner control and safe cooking performance — Add to Cart Now with confidence!
XPARTCO WB13K10003 Surface Burner Spark Electrode
The XPARTCO WB13K10003 is an aftermarket replacement spark electrode for the surface burners on GE, Hotpoint, and Kenmore gas ranges. The electrode is the small ceramic-tipped component mounted at the burner head that actually creates the spark: when you turn the burner knob, the range's spark module sends a rapid series of high-voltage electrical pulses to the electrode, which arcs across a small gap to the metal burner cap. That spark ignites the gas flowing from the burner, and the clicking sound you hear while the knob is turned is literally the sound of that spark firing over and over until the burner catches.
Because the electrode's ceramic insulator is what keeps that high-voltage pulse contained to a precise spark path, even small damage matters: a hairline crack in the ceramic can let voltage leak to ground instead of arcing at the tip, carbon and grease buildup on the tip can insulate it just enough to weaken the spark, and the metal tip itself can corrode or erode after years of sparking. A failing electrode typically shows up as a burner that clicks normally but is slow to catch, catches with a small "whoof" as gas builds up before ignition, or doesn't spark at all while the other burners on the same range work fine. It directly replaces AP2020574, 244911, AH231266, EA231266, and PS231266. GE's internal part number for this electrode is WG02F05048.
Quick Answer
The XPARTCO WB13K10003 Surface Burner Spark Electrode fixes GE, Hotpoint, and Kenmore gas ranges where a specific burner clicks but won't light, sparks weakly or intermittently, or ignites with a delayed "whoof" instead of catching right away. Ceramic-tipped spark electrode for the surface burner. Replaces AP2020574, 244911, AH231266, EA231266, PS231266. If a burner doesn't click at all, the problem is more likely the spark module or igniter switch — not this electrode.
Common Problems This Part Fixes
A specific surface burner clicks but won't ignite, while other burners work fine
Burner sparks weakly, intermittently, or only from certain knob positions
Delayed ignition — a noticeable pause with gas smell before the burner catches with a "whoof"
Clicking sound that continues well after the burner has already lit
Visible carbon buildup, grease, or discoloration on the electrode tip
Cracked, chipped, or damaged ceramic insulator visible at the base of the electrode
Electrode tip that looks corroded, pitted, or eroded compared to a new one
No spark at all from one specific burner position
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This surface burner spark electrode directly replaces the following OEM and cross-reference part numbers:
WB13K10003, WG02F05048, AP2020574, 244911, AH231266, AGE261531, PD00035924, EA231266, PS231266
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This spark electrode is compatible with select gas surface burners on ranges from the following brands:
GE gas ranges — EGR2000, EGR3000, and EGR3001 series
GE gas ranges — J2B900 and JGB910 series
GE gas ranges — JGBP27 series
Hotpoint gas ranges (select GE-built models)
Kenmore gas ranges (select GE-built models)
Westinghouse, Monogram, Café, Moffat, and Profile gas ranges (select GE-built models)
Verified model numbers include: EGR2000EC0BB, EGR2000EC0CC, EGR2000EC0WW, EGR2000EC1BB, EGR2000EC1CC, EGR2000EC1WW, EGR3000ED0BB, EGR3000ED0CC, EGR3000ED0WW, EGR3000ED1BB, EGR3000ED2BB, EGR3000ED3BB, EGR3000EH1BB, EGR3001ED1SS, EGR3001ED2SS, EGR3001ED3SS, EGR3001EF1SS, EGR3001EH1SS, J2B900BEF1BB, J2B900CEF1CC, J2B900SEF1SS, J2B900SEF2SS, J2B900WEF1WW, JGB910BEC1BB through JGB910BEC4BB, JGB910CEC1CC through JGB910CEC4CC, JGB910SEC1SS through JGB910SEC3SS, JGB910WEC1WW through JGB910WEC4WW, and the JGBP27BEA1AD through JGBP27BEA5AD range.
Note: GE uses several visually similar spark electrodes across its gas range lineup that differ in overall length and mounting angle — for example, a related electrode sold under WB13K10014 is used on other burner positions and model platforms. Some customers have reported this electrode arriving slightly longer than the original but still fitting with room to spare; if your range has very tight clearance underneath, verify your exact model number and burner position before ordering. Contact our support team with your model number if you're unsure.
Key Features
Aftermarket replacement ceramic-tipped spark electrode for gas surface burner ignition
Directs high-voltage pulses from the spark module into a precise spark path at the burner cap
Resolves "clicks but won't light," "weak or intermittent spark," and "delayed ignition" symptoms caused by a worn or damaged electrode
Ceramic insulator construction resists heat and contains the spark path
Direct drop-in replacement — mounts to the same burner head bracket and wire connector
Replaces AP2020574, 244911, AH231266, EA231266, and PS231266
Compatible with GE, Hotpoint, Kenmore, Westinghouse, Monogram, Café, Moffat, and Profile gas ranges
Aftermarket replacement built to OEM-equivalent quality standards
Product Specifications
Part Number
WB13K10003
OEM Part Number
WB13K10003 (WG02F05048)
Part Type
Gas Range Surface Burner Spark Electrode
Condition
Aftermarket Replacement
Application
Gas Range Surface Burner Ignition
Tip Material
Ceramic-insulated electrode tip
Function
Directs spark module pulses to ignite burner gas
Mounting
Burner head bracket with wire lead connector
Quantity
1 electrode
Compatible Brands
GE, Hotpoint, Kenmore, Westinghouse, Monogram, Café, Moffat, Profile
Installation Notes
⚠️ Danger — Gas Appliance Turn off the gas supply to the range at the shutoff valve and unplug the range (or shut off its circuit breaker) before beginning any work near the burners or gas line. After reassembly, check every disturbed connection for leaks using a soapy water solution — bubbling indicates a leak. If you ever smell gas at any point during this repair, do not attempt to light the range or operate any switches; leave the area immediately and contact your gas utility or a qualified technician.
⚠️ Handle The Ceramic Insulator Carefully Wear work gloves. Remove the burner grate and burner cap from the affected position to access the electrode underneath. Photograph the electrode's mounting position and wire connection before removing anything. Most electrodes are held in place with a single screw and connect to the spark module via a simple push-on wire terminal — disconnect the wire first, then remove the mounting screw and lift the old electrode free. The ceramic insulator is more fragile than it looks; avoid gripping or prying on it directly, and handle it by the mounting bracket instead. Install the new WB13K10003 in the same position and orientation, making sure the tip sits at the correct gap and angle relative to the burner cap — too far and the spark won't reach the gas port, too close and it can short against the burner base. Reconnect the wire terminal, secure the mounting screw, and reinstall the burner cap and grate. Restore the gas supply and power, then test ignition at that burner position and check for leaks at any connection you touched before considering the job complete. Tools needed: Phillips or flat-blade screwdriver (model-dependent), soapy water for leak testing, work gloves.
Frequently Asked Questions
My burner doesn't click at all when I turn the knob. Is this the right part?
Probably not, at least not by itself. If a burner produces no clicking sound whatsoever, the issue is more likely the spark module (the component that generates the high-voltage pulses) or the igniter switch behind the knob, rather than the electrode itself — an electrode can't spark if it's never receiving a pulse in the first place. This electrode is the right fix when you hear clicking at that burner position but it fails to ignite, sparks weakly, or ignites with a delay.
The burner lights but with a small "whoof" and a delay. Is that dangerous?
A delayed ignition means gas is flowing and accumulating for a moment before the spark finally catches it, which is exactly the kind of small buildup that produces that "whoof" sound and flare. It's not something to ignore — a weak or intermittent electrode is the common cause, and replacing it restores immediate, reliable ignition. If delayed ignition continues after replacing the electrode, have the burner and gas supply checked by a qualified technician rather than continuing to use it.
Can I clean the electrode instead of replacing it?
Light cleaning can sometimes help if the tip is coated in grease or food residue — gently wiping the ceramic and metal tip with a dry cloth or a small amount of rubbing alcohol may restore a weak spark caused purely by surface buildup. But if you see a cracked or chipped ceramic insulator, a visibly eroded or pitted tip, or the spark still fails after cleaning, the electrode itself has degraded and cleaning won't fix that — replacement is the correct next step.
One burner sparks weakly but the others are fine. Does that rule out the spark module?
Yes, generally. The spark module typically drives all the surface burner electrodes from the same unit, so if only one position is affected while the rest spark normally, the shared module is very unlikely to be the cause — the problem is isolated to that one electrode (or its individual wire connection). If every burner is weak or unreliable at the same time, that points toward the spark module instead.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine GE OEM part, but is manufactured to match the ceramic insulator design, tip geometry, mounting bracket, and wire connector of the original WB13K10003 electrode used in compatible GE, Hotpoint, and Kenmore gas ranges.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Quality Aftermarket Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
3148953CM Surface Burner Infinite Switch
240V, 7.5-9.3A
switch for 8" elements.
Fits specific Whirlpool electric ranges.
Replaces Part Numbers: WP3148953, 3148953, 492439, AP6007658, PS11740775, WP3148953VP.
Description The Infinite Control Switch is a replacement part for specific Whirlpool ranges and cooktop models. This part allows for precise adjustment of the heat level, enabling users to achieve the perfect temperature for various cooking techniques, from simmering to boiling. Causes of a bad Infinite Control Switch can range from electrical issues, such as short circuits or worn contacts, to mechanical failures within the switch itself.
This is an aftermarket part that can be used as a replacement for the OEM part.
California Residents only
WARNING: Cancer and/or Reproductive Harm - www.p65warnings.ca.gov
74009592CM Burner Control Knob
Black plastic burner knob
Fits Specific Maytag, Jenn Air, Whirlpool ranges
Replaces Part Numbers: WP74009592, 74009592, 1032643, 71003477, AP6011140, PS11744334.
Description: This Top Burner Control Knob is a replacement part for specific Whirlpool ranges and cooktop models. This part allows for precise control over the heat level of the stove's burners, enabling users to adjust the flame size for various cooking needs. Constructed from durable materials, the knob is designed to withstand the rigors of daily use, providing a reliable interface for setting and maintaining the desired cooking temperature.
This is an aftermarket part that can be used as a replacement for the OEM part.
XPARTCO WB03T10325 Range Surface Burner Control Knob
Replaces Part Numbers: WB03T10325, 2691864, AP5690210, PS3510510.
Description: This Range Knob is a replacement part for specific GE ranges and oven models. It is used to control the temperature and settings of the stove's burners or oven functions, providing an interface for selecting heat levels and cooking modes.
This is an aftermarket part that can be used as a replacement for the OEM part.
XPARTCO 00631633 Range Surface Burner Igniter Electrode
The XPARTCO 00631633 is an aftermarket replacement gas range surface burner igniter electrode (also called a spark electrode) compatible with select Bosch, Thermador, and Gaggenau gas ranges and cooktops in the HDI, HGI, NGM, NGMP, HDIP, and HGIP series. The surface burner igniter electrode is the ceramic-tipped spark generator located at each gas burner position on the cooktop. When the burner is turned on, the ignition system sends a high-voltage pulse to the electrode, which generates a spark across the ceramic tip to ignite the gas flowing from the burner. When the electrode cracks, chips, or becomes contaminated with grease or food residue, the burner may fail to light, click continuously without igniting, or spark intermittently.
This replacement electrode is constructed from high-quality ceramic and metal — the ceramic insulator body withstands the thermal cycling of repeated ignition, while the metal spark tip maintains reliable spark gap geometry over time. Sold individually — one electrode per order. It directly replaces AP5950372, 4162041, and PS10057850. Because a gas range typically has four or more burners with individual electrodes, compare your existing electrode's dimensions and mounting configuration before ordering to ensure a correct fit. Installs in minutes — no tools required in most cases.
Quick Answer
The XPARTCO 00631633 Range Surface Burner Igniter Electrode fixes Bosch, Thermador, and Gaggenau gas ranges where a surface burner won't light, clicks repeatedly without igniting, or sparks intermittently. Ceramic and metal construction. Sold individually — one electrode per order. Compatible with Bosch HDI, HGI, NGM, NGMP, HDIP, HGIP series. Replaces AP5950372, 4162041, PS10057850. Compare dimensions to your original before ordering — each burner position uses the same electrode style on compatible models.
Common Problems This Part Fixes
Gas burner will not light when the knob is turned
Burner clicks repeatedly without igniting the gas
Burner sparks intermittently — fires once or twice but does not sustain ignition
Igniter clicks continuously even when the burner knob is in the off position
One burner not lighting while other burners on the same range work normally
Electrode tip visibly cracked, chipped, or heavily contaminated with baked-on grease
Weak or inconsistent spark — arc not reaching the burner port reliably
Replaces Part Numbers
This igniter electrode directly replaces the following OEM and cross-reference part numbers:
00631633, 631633, ABS11789, AP5950372, EAP10057850, PD00044775, PS10057850
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This igniter electrode is compatible with select gas ranges and cooktops from the following brands and series:
Bosch gas ranges — HDI8054U, HDI8056U, HGI8046UC, HGI8054UC, HGI8056UC series
Bosch gas ranges — HDIP054U, HDIP056U, HGIP054UC, HGIP056UC series
Bosch gas cooktops — NGM5055UC, NGM5455UC, NGM5655UC, NGM8055UC, NGM8065UC, NGM8655UC, NGM8665UC, NGMP055UC, NGMP655UC series
Thermador gas ranges and cooktops (select models using the same electrode style)
Gaggenau gas ranges and cooktops (select models using the same electrode style)
Note: Before ordering, compare your existing igniter electrode's physical dimensions and mounting configuration to confirm this electrode is the correct fit for your burner position. Always verify your exact model number. If you are unsure, contact our support team with your model number for confirmation.
Key Features
Ceramic and metal spark electrode — generates the high-voltage spark that ignites the gas burner when the knob is turned
High-quality ceramic insulator body — withstands repeated thermal cycling without cracking under normal use
Durable metal spark tip — maintains reliable spark gap geometry for consistent ignition
Replaces AP5950372, 4162041, and PS10057850
Compatible with Bosch HDI, HGI, NGM, NGMP, HDIP, and HGIP series gas ranges and cooktops
Also compatible with select Thermador and Gaggenau gas ranges and cooktops
Sold individually — one electrode per order; order as many as needed for your burner positions
Aftermarket replacement built to OEM-equivalent quality standards
Quick DIY repair — installs in minutes, no special tools required in most cases
Product Specifications
Part Number
00631633
Also Known As
631633
Part Type
Gas Range Surface Burner Igniter Electrode (Spark Electrode)
Condition
Aftermarket Replacement
Application
Gas Ranges and Cooktops
Material
Ceramic / Metal
Color
White
Sold As
Single electrode — order quantity as needed
Compatible Brands
Bosch, Thermador, Gaggenau
Installation Notes
⚠️ Gas Appliance Safety Warning This part is used in gas ranges. Always turn off the gas supply at the shutoff valve and unplug the range from the electrical outlet before beginning any repair. If you smell gas at any point during or after installation, leave the area immediately and contact your gas utility provider. If you are not confident working on gas appliances, have this part installed by a qualified appliance technician.
⚠️ Unplug Range and Turn Off Gas Before Starting With the range unplugged and gas supply off, remove the cooktop grates and burner caps to access the burner heads. The igniter electrode is the small ceramic component positioned beside each burner head, held in place by a mounting bracket and screw or a snap-in clip depending on the model. Disconnect the single wire connector from the old electrode. Remove the mounting screw and lift the old electrode out. Install the new 00631633 electrode in the same position, secure the mounting screw, and reconnect the wire connector. Replace the burner caps and grates. Restore power and gas supply, then test each burner for reliable ignition. If the burner still does not light after replacing the electrode, inspect the igniter wire and the electronic ignition module. Tools needed: Phillips or Torx screwdriver (for mounting bracket on some models); no tools needed on models with snap-in electrodes.
Frequently Asked Questions
What does the surface burner igniter electrode do?
The igniter electrode is the component that creates the spark to light each gas burner. When you turn a burner knob past the "lite" position, the range's electronic ignition module sends a series of high-voltage pulses through the igniter wiring to the electrode at that burner. The electrode generates a visible spark across its ceramic tip to the grounded burner cap or burner head, and that spark ignites the gas flowing from the burner ports. Each burner position has its own dedicated electrode — failure of one electrode affects only that burner, while other burners on the same range continue to work normally.
My burner clicks constantly even when turned off — is it the electrode?
Constant clicking when a burner is in the off position is almost always caused by moisture or food residue in the igniter system rather than a failed electrode. When liquid boilover or steam gets into the burner cap area or electrode housing, it can cause the ignition module to fire continuously. Remove the burner cap and grate from the affected burner and allow everything to dry thoroughly — an hour in a warm oven (electric only, turned off) can help. Wipe the electrode tip clean with a dry cloth. If clicking persists after the components are completely dry and clean, the electrode or the ignition module may have been damaged by the moisture and needs replacement.
How many electrodes do I need for my Bosch range?
Most Bosch gas ranges have four surface burners, each with its own dedicated igniter electrode — so a full cooktop replacement typically requires four electrodes. This listing is for one electrode. If only one burner is not lighting, you likely only need one replacement. If multiple burners are failing, order one electrode for each affected burner. Because the electrodes on compatible Bosch models use the same part number across all burner positions, one order of multiple quantities covers all positions.
Can I clean the electrode instead of replacing it?
Yes — a contaminated or greasy electrode can often be cleaned successfully rather than replaced. Remove the electrode from the burner area and gently clean the ceramic tip and metal contact with a dry cloth or a soft toothbrush. Do not use water or liquid cleaners directly on the electrode — moisture in the ceramic can cause persistent clicking. If the ceramic body is cracked or the metal tip is corroded or missing, replacement is required. If the ceramic is intact and clean but the spark is still weak or absent, the electrode's spark gap geometry may have changed from thermal expansion and a replacement is the better fix.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Bosch OEM part, but is manufactured from high-quality ceramic and metal to match the dimensions and spark performance of the original 00631633 igniter electrode.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout
