Search results for "Idler Pulley"

12238200001084 Genuine OEM Midea Dryer Bearing House Assembly (Drum Rear Bearing) The 12238200001084 is a Genuine OEM Midea replacement bearing house assembly compatible with select Midea, Criterion, and Insignia electric and gas dryers, including the CDE41N1AW series. The bearing house assembly is mounted at the rear of the drum and houses the bearing that the rear drum shaft rotates within, supporting the back of the drum and allowing it to spin smoothly. Unlike front-mounted slide rollers used on some dryer platforms, this Midea design uses a rear bearing housing assembly to carry the load at the back of the drum. When the bearing house assembly wears out — typically from age, lack of lubrication, or accumulated lint and debris — the drum no longer spins smoothly on its rear support, resulting in grinding, rumbling, or squealing noise, increased drum drag, and in advanced cases, visible wobble or binding of the drum during rotation. As a Genuine OEM part manufactured by Midea to factory specifications, the 12238200001084 is a complete bearing house assembly designed as a direct replacement for the original equipment component. Installs in 45–60 minutes with basic hand tools, as drum removal is required. Quick Answer The 12238200001084 Genuine OEM Midea Dryer Bearing House Assembly fixes Midea, Criterion, and Insignia dryers with grinding, rumbling, or squealing noise from the rear of the drum, increased drum drag, or visible drum wobble. Mounted at the rear of the drum — houses the bearing the rear drum shaft rotates within. Genuine OEM. Compatible with Midea CDE41N1AW and related Midea electric dryer platform models. Requires drum removal to access — a more involved repair than a front roller swap. Common Problems This Part Fixes Loud grinding or rumbling noise from the rear of the drum during the drying cycle Squealing or squeaking noise as the drum rotates — worn or dry bearing surface Increased drag or resistance felt when manually rotating the drum by hand Drum wobbling or binding during rotation — worn bearing no longer providing stable support Excessive vibration during the drying cycle Visible wear, cracking, or lint/debris buildup in the bearing house area Drum scraping against the rear bulkhead due to lost bearing support Replaces Part Numbers This bearing house assembly directly replaces the following part number: 12238200001084, AP7154967, PS18167713 This is the Midea manufacturer part number used across the compatible Midea, Criterion, and Insignia dryer platform. Contact our support team with your model number if you need confirmation before ordering. Compatibility This bearing house assembly is compatible with select Midea, Criterion, and Insignia dryers, including: Midea CDE41N1AW electric dryer Midea MLE series electric dryers (select models — same drum/bearing platform) Criterion electric dryers built on the Midea platform (select models) Insignia electric dryers built on the Midea platform (select models) Always verify your appliance model number before ordering. Contact our support team if you're unsure. Key Features Genuine OEM part manufactured by Midea to factory specifications — guaranteed fit and performance Complete bearing house assembly — supports the rear of the drum and allows smooth, quiet rotation Houses the bearing that the rear drum shaft rotates within — a sealed-style design intended to resist lint intrusion Direct replacement for the original equipment bearing house assembly Compatible with Midea CDE41N1AW and related Midea, Criterion, and Insignia electric dryer platform models Installs in 45–60 minutes with basic hand tools (drum removal required) Product Specifications Part Number 12238200001084 Part Type Dryer Bearing House Assembly (Drum Rear Bearing) Condition Genuine OEM Application Electric Dryers (Midea platform) Location Rear of drum — houses rear drum shaft bearing Compatible Brands Midea, Criterion, Insignia Installation Notes ⚠️ Unplug Dryer Before Starting — Wear Work Gloves Disconnect power before beginning. Wear work gloves — there are sharp sheet metal edges inside the dryer cabinet. Remove the lint filter housing screws, release the top panel locking clips with a putty knife, and lift the top panel. Remove the front panel to access the drum. Take a photo of the belt routing before disconnecting the drive belt from the idler pulley. Carefully lift the drum out of the cabinet and set it aside on a padded surface. Locate the bearing house assembly mounted at the rear bulkhead where the drum's rear shaft was seated. Remove the mounting screws or clips securing the old bearing house assembly and pull it free. Clean any accumulated lint or debris from the mounting area before installing the new part. Install the new 12238200001084 bearing house assembly in the same position and secure the mounting hardware. Reinstall the drum, re-route and reconnect the drive belt, and reassemble the front and top panels. Restore power and run a test cycle to confirm the drum rotates smoothly and quietly. Tools needed: Phillips screwdriver, putty knife, work gloves. Frequently Asked Questions What does the bearing house assembly do? The bearing house assembly is mounted at the rear bulkhead of the dryer and houses the bearing that the rear drum shaft rotates within. It supports the back of the drum as it spins, allowing smooth, low-friction rotation throughout the drying cycle. Unlike dryer platforms that use front-mounted slide rollers or felt seals for drum support, this Midea design relies on a dedicated rear bearing housing to carry the structural load at the back of the drum. As the bearing wears, friction increases, leading to noise, drag, and eventually wobble or binding if left unaddressed. How do I know if the bearing house assembly has failed versus another component? A grinding, rumbling, or squealing noise specifically tied to drum rotation — rather than the blower motor or idler pulley — and noise that changes pitch as the drum speeds up or slows down often points to the rear bearing. With the dryer unplugged and the drum exposed (front panel removed), try rotating the drum by hand: if you feel noticeable resistance, grinding, or grittiness compared to a smooth, free rotation, the bearing house assembly has likely worn out and needs replacement. Why does this repair require removing the drum? The bearing house assembly is mounted at the rear bulkhead behind the drum, supporting the drum's rear shaft from the inside. There is no way to access this component without first removing the front panel and lifting the drum out of the cabinet. This makes it a more involved repair than swapping a front-accessible part like a belt or idler pulley, but it follows the same general dryer disassembly procedure used for accessing other internal drum components. Should I inspect other components while the drum is out? Yes — since the drum must already be removed to access the bearing house assembly, this is an excellent opportunity to inspect the drive belt, idler pulley, and any felt seals or gaskets around the drum opening for wear. Components in this drum drive system tend to wear together, and addressing multiple worn parts in a single repair session helps avoid a near-term repeat teardown. Is this a Genuine OEM or aftermarket part? This is a Genuine OEM part manufactured by Midea to factory specifications. It is the exact same bearing house assembly installed in compatible Midea, Criterion, and Insignia electric dryers from the factory — guaranteed fit, materials, and performance. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Genuine OEM Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout

Read more less

XPARTCO W10198086 Dryer Drum Belt Replaces WPW10198086 The XPARTCO W10198086 is an aftermarket replacement dryer drum belt for Whirlpool, Maytag, and Amana electric dryers. This belt wraps around the drum and the motor pulley, and it's what actually makes the drum turn — the motor drives the belt, and the belt tumbles the drum. When this belt breaks or wears out, the motor can still run, but nothing inside the dryer actually moves. This is a 5-rib belt measuring approximately 92-1/2"L x 5/16"W x 1/8"H, with grooves on one side and a flat surface on the other. A broken or badly worn belt produces an unmistakable symptom: the dryer runs — you'll hear the motor and often the blower — but the drum doesn't turn at all, or turns only briefly before stopping. A simple way to confirm this diagnosis before opening the dryer is to try turning the drum by hand; if it spins freely with no resistance, the belt is almost certainly broken. Overloading the dryer with oversized loads is a common cause of belt failure over time. It directly replaces WPW10198086, W11575709, W11667279, LB8086, 1481904, AP6016842, AH2348726, EA2348726, PS2348726, EAP11750135, PS11750135, AWP49253, and PD00007598. Quick Answer The XPARTCO W10198086 Dryer Drum Belt fixes Whirlpool, Maytag, and Amana electric dryers where the motor runs but the drum doesn't turn, or turns only briefly. 5-rib belt, approximately 92-1/2"L x 5/16"W x 1/8"H. Replaces WPW10198086, W11575709, W11667279, LB8086, 1481904, AP6016842, AH2348726, EA2348726, PS2348726, EAP11750135, PS11750135, AWP49253, PD00007598. Try turning the drum by hand first — if it spins freely with no resistance, the belt has broken. Common Problems This Part Fixes Dryer runs — motor and blower audible — but the drum doesn't turn Drum turns briefly then stops Drum spins freely by hand with no resistance (indicating a broken belt) Loud squeaking noise during operation from a worn but not yet broken belt Burning rubber smell from a slipping or overheating belt Dryer that stopped tumbling suddenly during a cycle Cross Reference Information Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item. Replaces Part Numbers This dryer drum belt directly replaces the following OEM and cross-reference part numbers: WPW10198086, W10198086, 1481904, W11575709, W11667279, LB8086, PD00007598, EAP11750135, AP6016842, AWP49253, PS11750135 If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This drum belt is compatible with select Whirlpool electric dryers, and also fits select Maytag and Amana dryers built on the same platform, including model numbers such as: MEDC465HW0, MEDC215EW0, MEDC215EW1, MEDC200XW0, MEDC200XW1, MEDC200XW3 MEDX655DW0, MEDX655DW1, MEDX500BW0, MEDX500BW1 MEDC300BW0, MEDC300XW0, MEDC300XW1, MEDC400VW0, MEDC400BW1, MEDC415EW0 MGDC400VW0, MGDC215EW0, MGDC215EW2, MGDC465HW0, MGDC300XW3, MGDC400BW1, MGDC400BW2, MGDC500VW0, MGDC555DW1 MEDC555DW1, MEDC555DW2, MEDC100YQ0, MEDB766FW0 7MMGDC400DW0, 7MMGDC400DW1, 7MMGDC400DW2, 7MMEDC300DW1, 7MMEDC300BW0 Note: Always verify your full model number before ordering, since Whirlpool uses several different drum belts across its dryer lineup with different lengths and rib counts. Contact our support team with your model number if you're unsure. Key Features Aftermarket replacement drum belt — connects the motor pulley to the drum so it can turn Resolves "motor runs but drum won't turn," "drum stops mid-cycle," and "squeaking" symptoms caused by a worn or broken belt 5-rib design with grooves on one side, flat on the other Approximately 92-1/2"L x 5/16"W x 1/8"H Direct drop-in replacement matching the original belt routing Replaces WPW10198086, W11575709, W11667279, LB8086, 1481904, AP6016842, AH2348726, EA2348726, PS2348726, EAP11750135, PS11750135, AWP49253, and PD00007598 Compatible with Whirlpool, Maytag, and Amana electric dryers Aftermarket replacement built to OEM-equivalent quality standards Product Specifications Part Number W10198086 OEM Part Number WPW10198086 Part Type Dryer Drum Belt Condition Aftermarket Replacement Length Approx. 92-1/2 in. Width 5/16 in. Thickness 1/8 in. Ribs 5 Color Black Material Rubber Repair Difficulty Easy — 15 to 30 minutes Quantity 1 drum belt Compatible Brands Whirlpool, Maytag, Amana Installation Notes ⚠️ Unplug Dryer Before Starting — Check The Idler Pulley While You're In There Disconnect power at the outlet or shut off the circuit breaker before beginning. Wear work gloves. Lift the lint screen cover and remove the two screws underneath it — if your model has a lint screen with a built-in cover, simply pull it out and remove the screws. Run a putty knife around the top edge of the dryer to find the release clips, then press them in to release and swing the top open. Remove the front panel to access the drum and belt area; on many models, all the work for this repair is performed from the front rather than the rear. Route the new W10198086 belt around the drum with the grooved side against the drum, then loop it around the motor pulley and the idler pulley, following the routing diagram on the inside of the cabinet or your old belt's path if it's still intact when you remove it. If the belt broke rather than just wearing out, check that the idler pulley is still properly seated — a belt snapping can sometimes cause the pulley to pop out of position, and reseating it is a quick fix while you already have the panel open. Reinstall the front panel, close the top and secure the release clips, and reinstall the lint screen area and its screws. Restore power and run a test cycle to confirm the drum turns smoothly with no slipping or noise. Tools needed: Phillips screwdriver, 5/16" nut driver, putty knife, work gloves. Frequently Asked Questions My dryer runs but the drum won't turn. How do I confirm it's the belt before ordering? Try turning the drum by hand with the dryer unplugged. If it spins freely with little to no resistance, that's a strong sign the belt has broken, since an intact belt normally provides some resistance from the motor and idler pulley connected to it. If the drum feels stuck or hard to turn instead, the problem may be elsewhere, such as a seized idler pulley or motor issue. What caused my belt to break in the first place? Belts wear out from age and normal use, but overloading the dryer with oversized or overly heavy loads is a common accelerating factor, since it puts extra strain on the belt with every rotation. Avoiding overloaded loads going forward can help the new belt last as long as it should. While replacing the belt, I noticed the idler pulley looks out of place. Is that related? Yes, this can happen when a belt breaks suddenly — the pulley can pop out of its normal seated position as tension is lost. Since you'll already have the panel open for the belt replacement, take a moment to check that the idler pulley is properly seated before closing everything back up, as this is a common and easy thing to overlook. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is manufactured to match the length, width, rib count, and routing configuration of the original WPW10198086 drum belt used in compatible Whirlpool, Maytag, and Amana electric dryers. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Quality Aftermarket Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout

Read more less

341241 Dryer Genuine OEM Drum Belt The 341241 is a Genuine OEM dryer drum belt compatible with a wide range of Whirlpool-family dryers including Whirlpool, Kenmore, Maytag, KitchenAid, Amana, Roper, Admiral, Jenn-Air, Estate, Magic Chef, Crosley, Inglis, Norge, Modern Maid, Hardwick, Caloric, and Ikea. The drum belt wraps around the outside of the dryer drum, loops around the motor pulley and idler pulley, and drives the drum to rotate during every drying cycle. Without a functioning belt, the drum cannot spin and clothes will not tumble or dry. Made from high-strength rubber with reinforced ribs, this belt measures 92-1/4 inches long x 1/4 inch wide and features 4 ribs and 3 grooves. It is flat on one side and ribbed on the other, and is built to resist cracking, stretching, and wear under the high heat and repeated tension cycles of daily dryer use. It also replaces some 5-rib, 4-groove belts. Installs in 30–45 minutes with basic hand tools. Quick Answer The 341241 Dryer Genuine OEM Drum Belt fixes dryers where the drum is not spinning, clothes are not tumbling, or a thumping/squealing noise is coming from the dryer. Compatible with Whirlpool, Kenmore, Maytag, KitchenAid, Amana, Roper, Admiral, Jenn-Air, Estate, Magic Chef, Crosley, Inglis, and more. Measures 92-1/4" L x 1/4" W with 4 ribs and 3 grooves. Common Problems This Part Fixes Dryer drum not spinning — motor runs but drum stays still Clothes not tumbling during the drying cycle Thumping, squealing, or slapping noise during operation Dryer runs but produces no heat because drum is stationary Burning rubber smell coming from the dryer Visible broken or frayed belt pieces found inside the dryer cabinet Clothes taking too long to dry due to drum not rotating at correct speed Replaces Part Numbers This drum belt directly replaces the following OEM and cross-reference part numbers: 341241, 14210003, 2008, 26000341241, 26000349533, 31001026, 31531589, 3389628, 3392665, 3394651, 3399844, 341241VP, 345473, 349533, 529597, 53-0186, 53-1080, 53-1086, 53-1528, 53-1589, 53-2671, 53-2910, 660996, 660997, 661561, 693306, 694088, 694416, 694868, 695055, 697388, 8066065, 8206, 8210, 920H4, 920H5, 99906951, 99989673, 99989674, FSP341241, LB276, LB279, P46-037, P46-149, W10127457, W10131364, AH346995, AP32, EA346995, ER341241, AWP39161, PD00002263, EAP346995, AP2946843, PS346995, TJ341241. If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This drum belt is compatible with select dryers from the following brands: Whirlpool dryers (gas and electric) Kenmore / Sears dryers (select models) Maytag dryers KitchenAid dryers Amana dryers Roper dryers Admiral dryers Jenn-Air dryers Estate dryers Magic Chef dryers Crosley dryers Inglis dryers Norge, Modern Maid, Hardwick, Caloric, and Ikea dryers Always verify your appliance model number before ordering. Contact our support team if you're unsure. Key Features Drives the dryer drum via the motor pulley and idler pulley for smooth, consistent tumbling every cycle 92-1/4" length x 1/4" width — 4-rib, 3-groove design; flat on one side, ribbed on the other Also replaces some 5-rib, 4-groove belts — wide cross-compatibility across Whirlpool-family models Made from high-strength rubber with reinforced ribs — resists cracking, stretching, and heat damage Direct replacement for OEM part numbers 341241 and 8066065 — no modification required Compatible with over a dozen major appliance brands built on the Whirlpool platform Genuine OEM part — factory-exact fit, materials, and dimensions DIY-friendly repair — installs in 30–45 minutes with basic hand tools Often replaced together with the idler pulley (691366) and drum rollers (349241T) for a complete drum drive repair Product Specifications Part Number 341241 Part Type Dryer Drum Drive Belt Condition Genuine OEM Application Gas and Electric Dryers Length 92-1/4 inches Width 1/4 inch Ribs 4 ribs, 3 grooves Profile Flat on one side, ribbed on the other Material High-strength rubber with reinforced ribs Color Black Compatible Brands Whirlpool, Kenmore, Maytag, KitchenAid, Amana, Roper, Admiral, Jenn-Air, Estate, Magic Chef, Crosley, Inglis, Norge, Modern Maid, Hardwick, Caloric, Ikea Often Replaced With 691366 Idler Pulley, 349241T Drum Rollers Installation Notes ⚠️ Safety First — Unplug Dryer Before Starting Unplug the dryer from the power source (and shut off the gas supply for gas dryers) before beginning any repair. Remove the lint screen, then unscrew the two Phillips screws inside the lint filter housing. Use a putty knife 2 inches from each front corner to release the top panel clips and lift the top panel. Remove the front panel to access the drum. Release belt tension at the idler pulley, lift the drum slightly, and slide the old belt off. Loop the new 341241 belt around the drum with the ribbed side facing down (toward the drum). Route the belt around the idler pulley and motor pulley — consult your model's service manual or a model-specific video for the correct belt path. Reassemble and run a test cycle. Tip: While the drum is out, inspect and replace the idler pulley (691366) and drum rollers (349241T) if worn. Tools needed: Phillips screwdriver, putty knife or flat pry tool. Frequently Asked Questions How does the 341241 differ from the W10205415 and 6602-001655 belts? All three are 92-inch dryer drum belts, but they differ in width and rib count. The 341241 is 1/4" wide with 4 ribs and 3 grooves. The W10205415 is 3/8" wide with 5 ribs and 4 grooves. The 6602-001655 is 5/16" wide with 5 ribs and 4 grooves designed for Samsung dryers. Always match the part number to your specific model — do not substitute based on appearance alone. Will this belt fit my Kenmore dryer? Many Kenmore dryers — especially the popular 110-series — are manufactured by Whirlpool and use the 341241 belt. Check your model number against the compatibility list and contact our support team if you need help confirming the fit before ordering. How do I know if my drum belt needs to be replaced? The most obvious sign is that the dryer motor hums but the drum does not spin. You may also notice a thumping or slapping sound during operation, a burning rubber smell, or clothes that are damp after a full cycle. Open the dryer cabinet to visually confirm if the belt is broken, frayed, or stretched. Should I also replace the idler pulley and drum rollers? Yes — since the dryer is already disassembled, it is highly recommended to inspect and replace the idler pulley (691366) and drum support rollers (349241T) at the same time. These parts wear at a similar rate and replacing all three together — often sold as a repair kit — prevents having to disassemble the dryer again in the near future. Is this an OEM or aftermarket part? This is a Genuine OEM part manufactured by Whirlpool to factory specifications. It is the exact same belt that came installed in your dryer from the factory — same materials, dimensions, and performance. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Fast US Shipping ✓ Genuine OEM Parts ✓ Compatibility Support ✓ Secure Checkout

Read more less

XPARTCO 33002535 Dryer Drum Belt Replaces WP33002535 The XPARTCO 33002535 is an aftermarket replacement dryer drum belt compatible with a wide range of Maytag, Amana, Crosley, and Kenmore dryers. The drum belt is a long, ribbed rubber belt that wraps around the outside of the dryer drum and connects to the motor pulley and idler pulley, transferring the motor's rotation to spin the drum during every drying cycle. When the belt breaks or wears out, the motor continues to run but the drum stops spinning — clothes tumble only under gravity or not at all, and the dryer produces heat with no airflow through the load. This belt measures 91-5/8" in length and 5/16" in width, with 5 ribs and 4 grooves — the correct profile to grip the drum, motor pulley, and idler pulley on compatible Maytag-platform dryers. Made from high-strength rubber designed to resist stretching, cracking, and heat degradation over years of use. It directly replaces WP33002535, 33001777, 63700300, 791135, WP33002535VP, and several additional cross-reference numbers. Installs in 30–45 minutes with basic hand tools. Quick Answer The XPARTCO 33002535 Dryer Drum Belt fixes Maytag-platform dryers where the drum is not spinning, the motor runs but the drum is still, or the belt is visibly broken or worn. 91-5/8" long x 5/16" wide, 5 ribs, 4 grooves. Compatible with Maytag, Amana, Crosley, and Kenmore dryers. Replaces WP33002535, 33001777, 63700300, 791135, and more. Installs in 30–45 minutes. Common Problems This Part Fixes Dryer drum not spinning — motor runs but drum is completely still Drum spinning only when manually pushed — belt is slipping or broken Dryer running but not drying — drum not tumbling clothes through the airflow Squealing or thumping noise just before the belt broke and the drum stopped Belt visibly broken, frayed, or in pieces inside the dryer cabinet Dryer tumbling unevenly or intermittently due to a stretched or slipping belt Replaces Part Numbers This dryer drum belt directly replaces the following OEM and cross-reference part numbers: WP33002535, 33002535, 33001777, 63700300, 6 3713880, 791135,AWP47236, EAP11741110, ER33002535, AP6007983, PD00002428, PS11741110. If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This drum belt is compatible with select gas and electric dryers from the following brands: Maytag dryers (gas and electric — MDE and MDG series) Amana dryers (gas and electric) Crosley dryers (gas and electric) Kenmore / Sears dryers (select Maytag-built models) Always verify your appliance model number before ordering. Contact our support team if you're unsure. Key Features Wraps around the drum and connects to the motor pulley and idler pulley to transfer motor rotation to the drum Length: 91-5/8 inches (91.5" / 2327 mm) — correct circumference for Maytag-platform dryers Width: 5/16 inch — correct profile for the drum groove on compatible models 5 ribs, 4 grooves — ribbed profile grips the motor pulley and idler pulley without slipping High-strength rubber construction — resists heat, stretching, cracking, and wear over years of daily use Replaces WP33002535, 33001777, 63700300, 791135, and over 15 additional cross-reference numbers Often replaced together with drum support rollers (12001541) and idler pulley (WP6-3700340) Aftermarket replacement built to OEM-equivalent quality standards DIY repair — installs in 30–45 minutes with basic hand tools Product Specifications Part Number 33002535 OEM Part Number WP33002535 Part Type Dryer Drum Drive Belt Condition Aftermarket Replacement Application Gas and Electric Dryers Length 91-5/8 inches (91.5" / 2327 mm) Width 5/16 inch Ribs / Grooves 5 ribs, 4 grooves Material High-strength rubber Color Black Often Replaced With 12001541 Drum Rollers, WP6-3700340 Idler Pulley Compatible Brands Maytag, Amana, Crosley, Kenmore Installation Notes ⚠️ Unplug Dryer Before Starting Disconnect power (and shut off gas for gas dryers) before beginning. Remove the top panel by unscrewing the screws inside the lint screen housing and releasing the front clips with a putty knife. Remove the front panel to access the drum. Release tension from the old belt at the idler pulley, then slide the belt off the drum, idler pulley, and motor pulley. Note how the belt is routed before removing it — take a photo if needed. Loop the new 33002535 belt around the drum with the ribbed side facing inward (toward the drum). Route the belt under the idler pulley and around the motor pulley, then pull the idler pulley toward you to create tension. Reassemble the front and top panels, restore power, and run a test cycle to confirm the drum spins. Tip: while the dryer is open, inspect the drum support rollers (12001541) and idler pulley (WP6-3700340) for wear and replace if needed. Tools needed: Phillips screwdriver, 1/4" nut driver, putty knife. Frequently Asked Questions What is the difference between 33002535 and WP33002535? These are the same dryer drum belt. WP33002535 is the updated Whirlpool/Maytag OEM part number that superseded the original 33002535. The 33001777 is also a cross-reference for this same belt. This aftermarket replacement is compatible with all three numbers. How do I know if my dryer belt has broken? The clearest sign of a broken belt is a motor that runs — you can hear it humming — but the drum does not spin when you start the dryer. On most Maytag-platform dryers, you can open the dryer door and try to spin the drum by hand — if it spins very freely with almost no resistance, the belt has likely broken. You can also open the top or front panel to visually inspect the belt; a broken belt will be lying loose inside the cabinet or wrapped around components rather than stretched around the drum. Should I replace the drum rollers and idler pulley at the same time? Yes — since the dryer is already disassembled, this is the ideal time to inspect and replace the drum support rollers (12001541) and idler pulley (WP6-3700340). These components wear at similar rates to the belt, and a worn roller or pulley bearing is often what caused the belt to wear and break prematurely. Replacing all three together eliminates the most common sources of drum noise and prevents a second teardown in the near future. Which side of the belt faces the drum? The ribbed side of the 33002535 belt faces inward — toward the drum surface. The smooth side faces outward, away from the drum. When installing, wrap the belt around the drum with the ribs against the drum, then route the smooth side under the idler pulley and around the motor pulley. If the belt is installed inside-out, it will slip and the drum will not spin correctly. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Maytag or Whirlpool OEM part, but is manufactured from high-strength rubber to match the length, width, and rib profile of the original WP33002535 drum belt. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout

Read more less

12638200000241 Genuine OEM Midea Dryer Drum Belt The 12638200000241 is a Genuine OEM Midea replacement dryer drum belt compatible with a wide range of Midea, Criterion, and Insignia electric and gas dryers, including the MLE41/45/47/52, MLG45/52, MLTE37, CDE41, CDG41/45, CLADE67, and MDD160 series. The drum belt wraps around the dryer drum and the motor pulley, transferring the motor's rotation to spin the drum during the drying cycle. When the belt breaks, stretches, or wears out, the motor continues to run but the drum no longer spins — clothes sit still in the drum while the motor hums, and the dryer cannot complete a normal cycle. As a Genuine OEM part manufactured by Midea to factory specifications, the 12638200000241 is constructed from durable black rubber. Packaged dimensions are approximately 11" L x 3" W x 2" H. Note: if the drum belt has failed, this is also a good opportunity to inspect the drum support rollers (Midea 12638000004021) and the idler/tensioner pulley assembly while the dryer cabinet is open — these components wear together and a failing roller or pulley can accelerate belt wear. Installs in 45–60 minutes with basic hand tools. Quick Answer The 12638200000241 Genuine OEM Midea Dryer Drum Belt fixes Midea, Criterion, and Insignia dryers where the motor runs but the drum doesn't spin, the belt has snapped or is visibly stretched, or where there's a burning rubber smell during operation. Black rubber drum belt. Packaged dimensions approximately 11" L x 3" W x 2" H. Genuine OEM. Compatible with Midea MLE41/45/47/52, MLG45/52, MLTE37, CDE41, CDG41/45, CLADE67, MDD160 series, plus Criterion CDE41N1AW/CDG41N1AW/CDG45N1AW and Insignia Midea-built models. Common Problems This Part Fixes Drum not spinning — belt has broken or slipped off Motor runs and hums but the drum stays still Drum spins intermittently — belt slipping under load Burning rubber smell during operation — belt slipping on the motor pulley Squealing or chirping noise during the drying cycle — belt frayed or stretched Belt visibly cracked, frayed, broken, or missing inside the dryer cabinet Extended drying times — drum not rotating at correct speed due to a worn belt Replaces Part Numbers This drum belt directly replaces the following part number: 12638200000241, AP7158561, PS18170626 This is the Midea manufacturer part number used across the compatible Midea, Criterion, and Insignia dryer platform. Contact our support team with your model number if you need confirmation before ordering. Compatibility This drum belt is compatible with select Midea, Criterion, and Insignia electric and gas dryers, including: Midea electric dryers — MLE41N1AWW, MLE45N1AWW, MLE45N1BWW, MLE45N3BMG, MLE45N3BWW, MLE47A3AGG, MLE47C3AWW, MLE47C4AWW, MLE47R5BWW, MLE52N3AWW, MLE52S7AGS, MLE52S7AWW Midea gas dryers — MLG45N1AWW, MLG45N1BWW, MLG45N3BMG, MLG45N3BWW, MLG52S7AGS, MLG52S7AWW Midea — MLTE37N1BWW, CLADE67W, MDD160A2301E1305 and related models Criterion — CDE41N1AW (electric), CDG41N1AW (gas), CDG45N1AW (gas) Insignia electric dryers — NSDRE67WH8A, NSFDRE67WH8A, NSFDRE67WH8AC, NSFDRE77WH8B, NSTDRE67W1, NSTDRE75W1 Insignia gas dryers — NSFDRG67WH8A, NSTDRG67W1, NSTDRG75W1 Always verify your appliance model number before ordering. Contact our support team if you're unsure. Key Features Genuine OEM part manufactured by Midea to factory specifications — guaranteed fit and performance Wraps around the dryer drum and motor pulley to transfer the motor's rotation to spin the drum Durable black rubber construction designed for continuous flex and motor load Packaged dimensions: approximately 11" L x 3" W x 2" H Compatible with the full Midea, Criterion, and Insignia electric and gas dryer platform Often replaced along with the drum support rollers (Midea 12638000004021) and idler pulley assembly Installs in 45–60 minutes with basic hand tools Product Specifications Part Number 12638200000241 Part Type Dryer Drum Belt Condition Genuine OEM Application Electric and Gas Dryers (Midea platform) Material Rubber Color Black Packaged Dimensions Approximately 11" L x 3" W x 2" H Often Replaced With Drum Support Roller (Midea 12638000004021) Compatible Brands Midea, Criterion, Insignia Installation Notes ⚠️ Unplug Dryer Before Starting (Shut Off Gas First on Gas Models) — Wear Work Gloves Disconnect power before beginning (and shut off the gas supply first if you have a gas dryer model). Wear work gloves — there are sharp sheet metal edges inside the dryer cabinet. Remove the lint filter housing screws, release the top panel locking clips with a putty knife, and lift the top panel. Disconnect the door switch harness and remove the front panel to access the drum, drive belt, and motor/idler pulley assembly. Take a photo of the existing belt routing before removing anything — this is essential for correct reassembly. Release the old belt from the idler pulley and slide it off the drum and motor pulley. Carefully lift the drum out and inspect the drum support rollers and idler pulley for wear — replace them now if needed while the dryer is open. Wrap the new 12638200000241 belt around the drum (ribbed side against the drum). Reinstall the drum, then route the belt around the motor pulley and under the idler pulley, allowing the idler to tension the belt. Reassemble the front panel and top panel in reverse order. Restore power (and gas, for gas models) and run a test cycle to confirm smooth, quiet drum rotation. Tools needed: Phillips screwdriver, putty knife, work gloves. Frequently Asked Questions How do I know if the drum belt has failed? The clearest sign of a broken drum belt is a dryer where the motor starts and runs normally, but the drum does not spin — you'll hear the motor humming with no drum movement. If you open the door mid-cycle and the drum spins freely with no resistance (as if disconnected from the motor), the belt has either broken or slipped off completely. A stretched or worn belt that still drives the drum may also produce squealing or burning rubber smells from slippage on the motor pulley. Visually inspecting the belt after removing the dryer's front panel confirms the condition. Should I replace the drum rollers and idler pulley at the same time? Yes — since the dryer cabinet must already be opened and the drum removed to replace the belt, this is the ideal time to also inspect and replace the drum support rollers (Midea 12638000004021) and the idler/tensioner pulley. All three components form the drum drive system and tend to wear together. A worn roller or pulley is often what caused the belt to fail prematurely in the first place. Addressing them together in a single repair eliminates the most common drum drive failure points and prevents a near-term repeat teardown. Does this belt fit Insignia and Criterion dryers as well as Midea? Yes — Insignia (Best Buy) and Criterion (Sears/Kmart) are house brands whose dryers in this size class are manufactured by Midea and use the same internal components, including this drum belt. Confirmed compatible models include Insignia NSDRE67WH8A, NSFDRE67WH8A, NSFDRE77WH8B, NSTDRE67W1, NSTDRE75W1 (electric) and NSFDRG67WH8A, NSTDRG67W1, NSTDRG75W1 (gas), plus Criterion CDE41N1AW (electric) and CDG41N1AW/CDG45N1AW (gas). Always verify your specific model number before ordering. Which way does the belt go around the drum — ribbed side in or out? On the drum belt, the ribbed (grooved) side should face inward, against the drum surface, while the smooth side faces outward. The ribs grip the smooth drum surface to drive it as the motor pulley turns. On the motor pulley side, the belt seats in the grooves of the small motor pulley. Take a photo of how the original belt was routed before removing it — this is the most reliable way to confirm correct orientation during reinstallation. Is this a Genuine OEM or aftermarket part? This is a Genuine OEM part manufactured by Midea to factory specifications. It is the exact same drum belt installed in compatible Midea, Criterion, and Insignia electric and gas dryers from the factory — guaranteed fit, materials, and performance. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Genuine OEM Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout

Read more less

XPARTCO Y312959 Dryer Drum Belt Replaces WPY312959 The XPARTCO Y312959 is an aftermarket replacement dryer drum drive belt compatible with a wide range of Maytag, Jenn-Air, Whirlpool, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore dryers — including the long-running vintage Maytag DE and DG halo-of-heat series. The drum belt is a critical component that connects the drive motor to the drum. It wraps all the way around the drum's circumference, passes around a spring-loaded idler (tension) pulley, and connects to the drive motor pulley. When the motor runs, it drives the belt, which rotates the drum to tumble clothes for even drying. Over time, drive belts fail from normal wear, cracking or fraying from age and repeated flexing, exposure to heat and lint buildup, stretching that causes slipping, or sudden breakage. Constructed from durable black rubber. Dimensions: 100" long x 3/8" (5/16") wide, with 5 ribs and 4 grooves. Includes instructions. It directly replaces Y312959, WPY312959, WPY312959VP, 312959, 3-12959, 3-14774, 314774, 1000H5, 8195-959, LB234, P46-150, P46-151, 1246110, 6-3129590, AP6024192, EAP11757542, PD00028571, and PS11757542. Important: install the belt with the grooved side against the motor pulley and the smooth side against the drum. Because the belt is symmetrical, it can be installed with either end facing out. Often replaced together with the idler pulley (WP6-3037050) and drum support roller kit (12001541 / 303373K), sold separately. Installs in 30–60 minutes with basic hand tools. Quick Answer The XPARTCO Y312959 Dryer Drum Belt fixes Maytag, Jenn-Air, Whirlpool, Amana, and Kenmore dryers where the drum won't turn (motor runs but drum stays still), the drum spins slowly, or the dryer makes loud squealing/thumping noises. 100"L x 3/8"W. 5 ribs, 4 grooves. Black rubber. Replaces WPY312959, WPY312959VP, 312959, 3-12959, 3-14774, 314774, 1000H5, 8195-959, LB234, P46-150, P46-151, 1246110, 6-3129590, AP6024192, EAP11757542, PS11757542. Install grooved side against the motor pulley, smooth side against the drum. Often paired with idler pulley WP6-3037050 and drum roller kit 12001541. Common Problems This Part Fixes Dryer drum doesn't turn — motor runs but drum stays still (belt snapped) Dryer drum rotates slowly or intermittently — belt worn or slipping Loud squealing, squeaking, or thumping noises during operation — belt cracked, glazed, or misaligned Clothes taking much longer than normal to dry — drum not tumbling clothes effectively Visible cracks, fraying, or glazing on the belt surface Belt broken completely — often heard as a loud snap during operation Drum spins freely by hand with no resistance — a clear sign the belt has snapped Belt worn thin or stretched after decades of use on a vintage Maytag dryer Cross Reference Information Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item. Replaces Part Numbers This dryer drum belt directly replaces the following OEM and cross-reference part numbers: Y312959, WPY312959, 1000H5, 1246110, 3-12959, 3-14774, 312959, 314774, 8195-959, P46-150, P46-151, 6 3129590, AP6024192, AWP51437, EAP11757542, PD00028571, PS11757542 If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This dryer drum belt is compatible with select dryers from the following brands: Maytag electric dryers — DE106, DE107, DE110, DE180, DE18CA/CM/CS/CT, DE19CA/CD/CS/CT, DE210, DE212, DE21CA/CM/CS/CT, DE22CA/CS/CT, DE23CD, DE24CA/CM/CS/CT, DE25CS, DE26CA/CD/CS/CT, DE27CA/CS/CT, DE303, DE308, DE309, DE312, DE313, DE382, DE4000, DE408-DE9900 series and many more Maytag gas dryers — DG106, DG107, DG110, DG18CA/CM/CS/CT, DG19CA/CD/CS/CT, DG210, DG212, DG21CA/CM/CS/CT, DG22CA/CS and related DG-series models Maytag dryers — LDE and LDG series (LDE7304ACE, LDE8406ACE/ACM/ADE, LDE8410, LDG8424AAE, LDG9304AAM and related) Jenn-Air dryers (select models) Whirlpool dryers (select Whirlpool-built models) Amana, Magic Chef, Admiral, Norge, Roper dryers (select Whirlpool/Maytag-built models) Kenmore / Sears dryers (select Whirlpool/Maytag-built models) Note: When you replace the drum belt, this is also the ideal time to inspect the idler (tension) pulley (WP6-3037050) and the drum support rollers (kit 12001541 / 303373K) — they wear from the same friction cycles as the belt, and if they're rough, seized, or noisy, the new belt will wear out prematurely. Before replacing the belt due to noise, check the drum support rollers and idler pulley and replace if you see signs of wear. Always verify your dryer model number before ordering. Key Features Dryer drum drive belt — connects the motor pulley to the drum to enable tumbling during drying cycles Resolves "drum won't turn," "loud squealing noise," and "long dry times" symptoms when caused by belt failure Durable black rubber construction — engineered to withstand thousands of hours of high-temperature, high-friction operation Dimensions: 100" long x 3/8" (5/16") wide with 5 ribs and 4 grooves Install with the grooved side against the motor pulley and the smooth side against the drum Symmetrical design — can be installed with either end facing out Includes instructions Replaces WPY312959, WPY312959VP, 312959, 3-12959, 3-14774, 314774, 1000H5, 8195-959, LB234, P46-150, P46-151, 1246110, 6-3129590, AP6024192, EAP11757542, and PS11757542 Compatible with vintage Maytag DE/DG series, LDE/LDG series, plus Jenn-Air, Whirlpool, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore dryers Often replaced together with the idler pulley (WP6-3037050) and drum support roller kit (12001541 / 303373K), sold separately Aftermarket replacement built to OEM-equivalent quality standards DIY repair — installs in 30–60 minutes with basic hand tools Product Specifications Part Number Y312959 OEM Part Number WPY312959 Part Type Dryer Drum Drive Belt Condition Aftermarket Replacement Application Dryers (Maytag / Whirlpool platform) Length 100" Width 3/8" (5/16") Ribs / Grooves 5 ribs / 4 grooves Color Black Material Rubber Installation Orientation Grooved side against motor pulley, smooth side against drum Often Paired With Idler Pulley (WP6-3037050), Drum Roller Kit (12001541 / 303373K) Compatible Brands Maytag, Jenn-Air, Whirlpool, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore Installation Notes ⚠️ Unplug Dryer Before Starting — Wear Work Gloves — Grooved Side Against Motor Pulley Disconnect power at the breaker or outlet before beginning. Wear work gloves to protect your hands from sharp sheet metal edges inside the dryer cabinet. Access the drum by removing the appropriate panels — the specific procedure varies by model, but on many vintage Maytag dryers this involves removing the front or top panel. Photograph the belt routing before disassembly if any belt fragments remain. Remove any pieces of the old broken belt from around the drum, motor pulley, and idler pulley, and vacuum out accumulated lint and belt dust. Clean any belt dust off the drum. Route the new Y312959 belt around the drum. Install with the grooved (ribbed) side against the motor pulley and the smooth side against the drum — this is the correct orientation for proper drive engagement. Because the belt is symmetrical, either end can face outward. A helpful tip from experienced installers: use two small pieces of tape to hold the belt against the drum while you lace it onto the idler and motor pulleys. From under or behind the drum, route the belt around the idler (tension) pulley and the drive motor pulley following the belt diagram for your model. Rotate the drum by hand a few full turns to confirm the belt seats correctly and rides smoothly without binding. While you have the machine apart, check that the idler pulley and drum support rollers spin freely — if they're rough or noisy, replace them now to protect the new belt. Reassemble the panels, restore power, and run a test cycle. Tools needed: Phillips screwdriver, nut driver, socket/ratchet, vacuum, work gloves, tape (helpful for holding the belt). Frequently Asked Questions My dryer runs but the drum won't turn — is the belt the problem? Almost certainly, yes. When the motor runs (you hear the humming) but the drum stays still, the belt has almost always snapped. To confirm without opening the dryer: reach in and try turning the drum by hand. If it spins freely with no resistance whatsoever, the belt is broken. If it turns but feels notchy or resistant, the belt may still be intact but the drum rollers or bearings could be the issue. Opening the dryer to inspect is the definitive check — a snapped belt will be lying in the bottom of the cabinet. On decades-old Maytag dryers, a belt that finally snapped from age is one of the most common repairs. Which way does the belt go — grooves in or out? Install the belt with the grooved (ribbed) side facing the motor pulley and the smooth side against the drum. The ribs engage the grooved motor pulley for positive drive without slipping, while the smooth side rides against the large drum surface. Note that this is the opposite orientation from some other dryer belts (like certain Frigidaire belts where grooves face the drum) — so don't assume; follow the grooves-against-motor-pulley rule for this Maytag/Whirlpool-platform belt. The belt is symmetrical end-to-end, so either end can face outward; only the grooved-vs-smooth orientation matters. Should I replace the idler pulley and drum rollers at the same time? It's strongly recommended, especially on older dryers. The idler (tension) pulley (WP6-3037050) keeps the belt under proper tension, and the drum support rollers (kit 12001541 / 303373K) carry the drum's weight as it turns. All wear from the same friction and heat cycles as the belt. In fact, a common piece of repair advice is: before you replace the belt due to noise, check the drum support rollers and idler pulley first — worn rollers or a seized idler are frequent noise sources, and if you replace only the belt, the new belt may wear out prematurely against a bad pulley. Since the dryer is already apart, replacing all three together is efficient and saves a repeat repair. What's the difference between Y312959 and WPY312959? These are the same drum belt across production revisions. Y312959 was the earlier Maytag part number and WPY312959 is the Whirlpool-era part number (after Whirlpool acquired Maytag) for the same belt. WPY312959VP is a variant packaging code. All are physically and functionally identical — if your dryer's parts diagram shows any of these numbers, this listing is the correct replacement. The many other cross-references (3-12959, 314774, LB234, P46-150, etc.) reflect the belt's long production history across decades of Maytag dryers. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Maytag/Whirlpool OEM part, but is manufactured from durable rubber to match the dimensions (100"L x 3/8"W), rib and groove pattern (5 ribs, 4 grooves), and drive function of the original Y312959/WPY312959 drum belt used in compatible Maytag, Jenn-Air, Whirlpool, Amana, and Kenmore dryers. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout

Read more less

XPARTCO W10677723PL Washer Motor Pulley - Compatible with Whirlpool, Maytag, Kenmore, Crosley Washer Motor W10677723 Product Description Restore smooth operation to your washer with the replacement XPARTCO W10677723PL Washer Motor Pulley. This replacement motor pulley is designed for select Whirlpool, Maytag, Kenmore, and Crosley top-load washers, connecting the motor to the transmission for efficient power transfer. It addresses issues like excessive noise, belt slippage, or failure to spin, offering a cost-effective alternative to OEM parts. Note: Includes one motor pulley (2-5/16" diameter, 4 ribs, 5 grooves). Sold individually. Disconnect power before installation. Verify compatibility with your washer model. Replaces Pulley for Motor part numbers: W10677723, 4461547, AP6038394, PS11770267, EAP11770267 Compatibility: Compatible with models including but not limited to: Whirlpool: MVWC565FW0, MVW4505MW0, WTW5010LW0, WTW5015LW0, WTW5057LW0, WTW5100HC0, WTW5100HC1, WTW5100HC2, WTW5100HC3, WTW5100HW0, WTW5100HW2, WTW5100HW3, WTW5105HC0, WTW5105HC1, WTW5105HC2, WTW5105HW0, WTW5105HW1, WTW5105HW2, WTW6120HC0, WTW6120HC1, WTW6120HC2, WTW6120HC3, WTW6120HW0, WTW6120HW1, WTW6120HW2, WTW6120HW3, 8TWTW5010PW0, 8TWTW5057PW0 Maytag: MVWC565FW0, 7MMVWC565FW0, MVW4505MW0, MVW4505MW1, MVW4505MW2, MVW5035MW0, MVW5035MW1, MVW5035MW2, MVW5430MW0, MVW5430MW2, MVW5430PBK0, MVW5435PBK0, MVW5435PW0, MVW6200KW0, MVW6200KW1, MVW6200KW2, MVW6200KW3, MVW6230HC0, MVW6230HC1, MVW6230HC2, MVW6230HC3, MVW6230HW0, MVW6230HW1, MVW6230HW2, MVW6230RHW0, MVW6230RHW1, MVW6230RHW2, MVW6230RHW3, MVW6500MBK0, MVW6500MW0, MVWC565FW1, MVWX655DW1 Kenmore: 11022352510, 11022352511, 11021112020, 11021112021, 11031312021, 11031312022 Crosley: CAW42114GW0, CAW42114GW1, CAW45125LW0 Verify your model number or contact our support team for assistance. Key Features: ✅ Brand and Models Compatibility: Fits select Whirlpool, Maytag, Kenmore, and Crosley top-load washers requiring W10677723PL. 🔥 Specifications: Precision-engineered motor pulley, 2-5/16" diameter, 4 ribs, 5 grooves, designed for secure belt engagement and efficient power transfer. 💰 Cost-Effective Alternative: Offers OEM-equivalent performance at a lower price. 🛠️ Easy Installation: Requires Phillips screwdriver, work gloves, optional pry tool; typically installed in 15–30 minutes. 🛡️ Effective Fixes: Resolves issues like excessive noise, belt slippage, or failure to spin. Product Specification Part Number: XPW10677723PL Component Type: Washer motor pulley Material: Durable plastic with reinforced ribs Terminal Type: Fits motor shaft with locking tabs Operating Conditions: Suitable for high-torque washer environments Compliance: Prop 65 warning for California

Read more less

XPARTCO 341241 Dryer Drum Belt The XPARTCO 341241 is an aftermarket replacement dryer drum belt compatible with a wide range of Whirlpool-family dryers including Whirlpool, Kenmore, Maytag, KitchenAid, Amana, Roper, Admiral, Jenn-Air, Estate, Magic Chef, Crosley, Inglis, Norge, Modern Maid, Hardwick, Caloric, and Ikea. The drum belt wraps around the outside of the dryer drum, loops around the motor pulley and idler pulley, and drives the drum to rotate during every drying cycle. Without a functioning belt, the drum cannot spin and clothes will not tumble or dry. Made from high-strength rubber with reinforced ribs, this belt measures 92-1/4 inches long x 1/4 inch wide and features 4 ribs and 3 grooves. It is flat on one side and ribbed on the other, and is built to resist cracking, stretching, and wear under the high heat and repeated tension cycles of daily dryer use. It also replaces some 5-rib, 4-groove belts. Installs in 30–45 minutes with basic hand tools. Quick Answer The XPARTCO 341241 Dryer Drum Belt fixes dryers where the drum is not spinning, clothes are not tumbling, or a thumping/squealing noise is coming from the dryer. Compatible with Whirlpool, Kenmore, Maytag, KitchenAid, Amana, Roper, Admiral, Jenn-Air, Estate, Magic Chef, Crosley, Inglis, and more. Measures 92-1/4" L x 1/4" W with 4 ribs and 3 grooves. Common Problems This Part Fixes Dryer drum not spinning — motor runs but drum stays still Clothes not tumbling during the drying cycle Thumping, squealing, or slapping noise during operation Dryer runs but produces no heat because drum is stationary Burning rubber smell coming from the dryer Visible broken or frayed belt pieces found inside the dryer cabinet Clothes taking too long to dry due to drum not rotating at correct speed Replaces Part Numbers This drum belt directly replaces the following OEM and cross-reference part numbers: 341241, 14210003, 2008, 26000341241, 26000349533, 31001026, 31531589, 3389628, 3392665, 3394651, 3399844, 341241VP, 345473, 349533, 529597, 53-0186, 53-1080, 53-1086, 53-1528, 53-1589, 53-2671, 53-2910, 660996, 660997, 661561, 693306, 694088, 694416, 694868, 695055, 697388, 8066065, 8206, 8210, 920H4, 920H5, 99906951, 99989673, 99989674, FSP341241, LB276, LB279, P46-037, P46-149, W10127457, W10131364, AH346995, AP32, EA346995, ER341241, AWP39161, PD00002263, EAP346995, 694088-NC, AP2946843, PS346995, TJ341241. If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This drum belt is compatible with select dryers from the following brands: Whirlpool dryers (gas and electric) Kenmore / Sears dryers (select models) Maytag dryers KitchenAid dryers Amana dryers Roper dryers Admiral dryers Jenn-Air dryers Estate dryers Magic Chef dryers Crosley dryers Inglis dryers Norge, Modern Maid, Hardwick, Caloric, and Ikea dryers Always verify your appliance model number before ordering. Contact our support team if you're unsure. Key Features Drives the dryer drum via the motor pulley and idler pulley for smooth, consistent tumbling every cycle 92-1/4" length x 1/4" width — 4-rib, 3-groove design; flat on one side, ribbed on the other Also replaces some 5-rib, 4-groove belts — wide cross-compatibility across Whirlpool-family models Made from high-strength rubber with reinforced ribs — resists cracking, stretching, and heat damage Direct replacement for OEM part numbers 341241 and 8066065 — no modification required Compatible with over a dozen major appliance brands built on the Whirlpool platform Aftermarket replacement built to OEM-equivalent quality standards DIY-friendly repair — installs in 30–45 minutes with basic hand tools Often replaced together with the idler pulley (691366) and drum rollers (349241T) for a complete drum drive repair Product Specifications Part Number 341241 Part Type Dryer Drum Drive Belt Condition Aftermarket Replacement Application Gas and Electric Dryers Length 92-1/4 inches Width 1/4 inch Ribs 4 ribs, 3 grooves Profile Flat on one side, ribbed on the other Material High-strength rubber with reinforced ribs Color Black Compatible Brands Whirlpool, Kenmore, Maytag, KitchenAid, Amana, Roper, Admiral, Jenn-Air, Estate, Magic Chef, Crosley, Inglis, Norge, Modern Maid, Hardwick, Caloric, Ikea Often Replaced With 691366 Idler Pulley, 349241T Drum Rollers Installation Notes ⚠️ Safety First — Unplug Dryer Before Starting Unplug the dryer from the power source (and shut off the gas supply for gas dryers) before beginning any repair. Remove the lint screen, then unscrew the two Phillips screws inside the lint filter housing. Use a putty knife 2 inches from each front corner to release the top panel clips and lift the top panel. Remove the front panel to access the drum. Release belt tension at the idler pulley, lift the drum slightly, and slide the old belt off. Loop the new 341241 belt around the drum with the ribbed side facing down (toward the drum). Route the belt around the idler pulley and motor pulley — consult your model's service manual or a model-specific video for the correct belt path. Reassemble and run a test cycle. Tip: While the drum is out, inspect and replace the idler pulley (691366) and drum rollers (349241T) if worn. Tools needed: Phillips screwdriver, putty knife or flat pry tool. Frequently Asked Questions How does the 341241 differ from the W10205415 and 6602-001655 belts? All three are 92-inch dryer drum belts, but they differ in width and rib count. The 341241 is 1/4" wide with 4 ribs and 3 grooves. The W10205415 is 3/8" wide with 5 ribs and 4 grooves. The 6602-001655 is 5/16" wide with 5 ribs and 4 grooves designed for Samsung dryers. Always match the part number to your specific model — do not substitute based on appearance alone. Will this belt fit my Kenmore dryer? Many Kenmore dryers — especially the popular 110-series — are manufactured by Whirlpool and use the 341241 belt. Check your model number against the compatibility list and contact our support team if you need help confirming the fit before ordering. How do I know if my drum belt needs to be replaced? The most obvious sign is that the dryer motor hums but the drum does not spin. You may also notice a thumping or slapping sound during operation, a burning rubber smell, or clothes that are damp after a full cycle. Open the dryer cabinet to visually confirm if the belt is broken, frayed, or stretched. Should I also replace the idler pulley and drum rollers? Yes — since the dryer is already disassembled, it is highly recommended to inspect and replace the idler pulley (691366) and drum support rollers (349241T) at the same time. These parts wear at a similar rate and replacing all three together — often sold as a repair kit — prevents having to disassemble the dryer again in the near future. Is this an OEM or aftermarket part? This is an aftermarket replacement built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is made from high-strength rubber to match the dimensions and performance of the original 341241 belt. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout

Read more less

XPARTCO WE03X32037 Dryer Drum Belt Replaces WE12M24 The XPARTCO WE03X32037 is an aftermarket replacement drum drive belt for GE, Hotpoint, and RCA portable, compact, and unitized stack dryers. The belt is a long, slender loop that wraps all the way around the outside of the drum, passes around the idler tension pulley, and finishes around the small drive motor pulley. That belt is the only mechanical link between the motor and the drum — there are no gears and no direct coupling — so when it breaks, the dryer behaves in a very specific way: the console lights up, the motor runs, the blower moves air, and the drum simply sits there. Open the door and spin the drum by hand and it coasts freely with no resistance at all. This belt measures approximately 79 inches long and about 1/4 inch wide, with a 4-rib multi-groove profile molded into the inner face. The 79" length is the defining specification here — GE uses several visually similar 4-rib dryer belts across its lineup, and the difference between them is length. Belts fail from heat and age: the rubber hardens, the ribs glaze and begin slipping under a heavy wet load, and eventually the belt cracks through or snaps. Fraying edges, a squeal at startup, a rhythmic thump timed to drum rotation, or black rubber dust in the bottom of the cabinet all point to a belt nearing the end of its life. It directly replaces WE12M24, WE12M9, WE12X79, WE12X0079, AP3418890, AP7186820, PS755943, and related numbers. Installs in 45–90 minutes with basic hand tools. Quick Answer The XPARTCO WE03X32037 Dryer Drum Belt fixes GE, Hotpoint, and RCA portable, compact, and stack dryers where the motor runs but the drum won't turn, the drum spins freely by hand, or the dryer squeals, thumps, or rumbles during a cycle. Approximately 79" long, 1/4" wide, 4 ribs, black rubber. Fits DDP1370/DDP1375/DDP1380 portable and DSKP333/DSKS333/DSKS433 stack models. Replaces WE12M24, WE12M9, WE12X79, WE12X0079, AP3418890, AP7186820, PS755943. Not the same belt as the 89-1/2" full-size GE WE12M29 — length is what separates them. Common Problems This Part Fixes Dryer runs and hums but the drum does not turn — the classic broken belt symptom Drum spins freely by hand with no resistance when the door is open Loud squealing or screeching that begins as soon as the cycle starts Rhythmic thumping or slapping noise timed to drum rotation — cracked or split belt Grinding or rumbling from inside the cabinet as a frayed belt drags Drum turns slowly, intermittently, or stalls under a heavy wet load — glazed belt slipping Clothes not drying because the drum isn't tumbling to expose them to airflow Black rubber dust or belt fragments in the bottom of the cabinet Visible cracking, fraying, glazing, or stretching on the old belt Cross Reference Information Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item. Replaces Part Numbers This dryer drum belt directly replaces the following OEM and cross-reference part numbers: WE03X32037, WE12M24, WE12M9, WE12X79, WE12X0079, AP3418890, AP7186820, PS755943, PS16729246, EAP16729246, AH755943, EA755943, 943874, AGE25647, PD00074729 WE03X32037 is the current GE part number; WE12M24 is the long-running legacy number that most service diagrams and older belts still carry. If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This drum belt is compatible with select portable, compact, and unitized stack dryers from the following brands: GE portable and compact electric dryers — DDP1370, DDP1375, and DDP1380 series GE unitized stack and Spacemaker laundry centers — DSKP333, DSKS333, and DSKS433 series Hotpoint compact and stack dryers (select GE-built models) RCA compact and stack dryers (select GE-built models) Select Kenmore compact dryers built on the GE platform Verified model numbers include: DDP1370GAM, DDP1370SAM, DDP1370SBM, DDP1375GAM, DDP1375GBM, DDP1375GCM, DDP1375GDM, DDP1375GEM, DDP1375SAM, DDP1375SBM, DDP1380GAM, DDP1380GBM, DDP1380GCM, DDP1380GDM, DDP1380GFM, DDP1380SAM, DDP1380SBM, DDP1380SCM, DDP1380SDM, DDP1380TAM, DSKP333EC0WH, DSKP333EC0WW, DSKP333EC2WW, DSKP333EC3WW, DSKP333EC4WW, DSKP333EC5WW, DSKP333EC6WW, DSKS333EC0WH, DSKS333EC0WW, DSKS333EC2WW, DSKS333EC3WW, DSKS333EC4WW, DSKS333EC5WW, DSKS333EC6WW, DSKS433EA0AA, DSKS433EB3WW, DSKS433EB5WW, DSKS433EB6WW, and DSKS433EB7WW. Note — 79" portable/compact belt only: GE uses several visually identical 4-rib dryer belts that differ only in length, and they are NOT interchangeable. This belt is approximately 79 inches, for portable, compact, and stack units. It is NOT the WE12M29 / WE03X29897 belt (89-1/2") used on full-size GE dryers, NOT the WE12X10009 belt (87"), and NOT the WE12X10014 / WE12X42 belt (87-13/16"). Fitting a longer belt leaves slack the idler cannot take up, and the belt will slip or walk off the pulley within minutes. Measure your old belt end to end, or verify your full model number, before ordering. Contact our support team with your model number if you're unsure. Key Features Aftermarket replacement drum drive belt — transfers motor rotation to the dryer drum Approximately 79" long, the correct length for GE portable, compact, and unitized stack dryers 4-rib multi-groove profile molded into the inner face for positive grip on the motor pulley 1/4" width matched to the original belt track and idler pulley Durable black rubber construction that resists heat hardening and cracking Resolves "motor runs but drum won't turn," "squealing," "thumping," and "drum spins freely by hand" symptoms Multi-rib design prevents slipping under heavy wet loads where a worn belt would stall Direct drop-in replacement — no cutting, splicing, or modification required Replaces WE12M24, WE12M9, WE12X79, WE12X0079, AP3418890, AP7186820, PS755943, AH755943, EA755943, and 943874 Compatible with GE, Hotpoint, RCA, and select Kenmore compact and stack dryers Aftermarket replacement built to OEM-equivalent quality standards Straightforward DIY repair — installs in 45–90 minutes with basic hand tools Product Specifications Part Number XPWE03X32037 OEM Part Number WE03X32037 (formerly WE12M24) Part Type Dryer Drum Drive Belt Condition Aftermarket Replacement Application GE Portable, Compact, and Unitized Stack Dryers Length Approx. 79 in. Width 1/4 in. Ribs 4 ribs / 3 grooves Material Rubber Color Black Rib Orientation Ribbed side faces the drum Routing Around drum → idler tension pulley → drive motor pulley Fuel Type Electric and gas dryers Quantity 1 belt Compatible Brands GE, Hotpoint, RCA, select Kenmore Installation Notes ⚠️ Unplug Dryer Before Starting — Photograph Belt Routing First Disconnect power at the outlet or shut off the circuit breaker before beginning. On a gas model, also close the gas shutoff valve before moving the cabinet. Wear work gloves — the sheet metal edges inside the cabinet are sharp. Before removing anything, photograph how the old belt routes around the drum, around the idler tension pulley, and around the motor pulley. If the belt is already broken and the routing isn't visible, note that the ribbed side of the belt faces toward the drum, with the smooth back riding against the idler pulley. Access on these compact and stack units is generally from the front: remove the top panel, then the control panel and front panel, which frees the drum enough to lift or tilt it forward. Vacuum out accumulated lint while the cabinet is open — restricted airflow and lint packed around the motor are what cook belts prematurely. Slip the new belt around the drum roughly one-third of the way back from the front lip, ribbed side against the drum, and seat it in the polished wear track the old belt left behind. Reach underneath, route the belt around the idler pulley, then loop it around the small motor pulley. Useful trick: tape the belt loosely to the drum with a strip of masking tape before you reach underneath, so it can't slide off while you work the idler into position. Many GE idler arms have a locked or pre-loaded position — if yours does, remember to release it after the belt is seated, or the belt will have no tension and the drum will stall under load. Once routed, rotate the drum several full turns by hand and confirm the belt tracks straight and stays centered without walking toward an edge. While you're in there, spin the idler pulley and each drum roller by hand; if any is noisy, gritty, or has side-to-side play, replace it now, because a seized idler or flat-spotted roller will destroy the new belt quickly. Reassemble, restore power, and run a short empty cycle listening for squeal or thump before loading it. Tools needed: Phillips screwdriver, nut driver or socket set, putty knife, masking tape, flashlight, work gloves. Frequently Asked Questions How do I confirm the belt is broken and not the motor? With the dryer unplugged, open the door and try to spin the drum by hand. An intact belt gives firm resistance, because you're turning the motor and idler through the belt. If the drum coasts freely like a bicycle wheel, the belt is broken or has jumped off its pulleys. Sound is the other tell: with a broken belt the motor hums and the blower whooshes normally, so the dryer sounds like it's running perfectly while the drum sits still. A failed motor usually buzzes and does nothing, or trips the breaker outright. What's the difference between WE03X32037 and WE12M24? They are the same belt across production revisions. WE12M24 was the long-running legacy GE number and WE03X32037 is the current number that supersedes it. If your dryer's parts diagram or the old belt itself shows WE12M24, WE12M9, WE12X79, or WE12X0079, this listing is the correct replacement. The remaining cross-references (AP3418890, AP7186820, PS755943, AH755943, EA755943, 943874) are catalog identifiers used by various parts distributors for the same belt. Can I use a longer GE belt if this one is out of stock? No. GE's 4-rib dryer belts look nearly identical and differ mainly in length, which is precisely why they get substituted by mistake. This belt is about 79"; the full-size GE belt WE12M29 is 89-1/2", and WE12X10009 and WE12X10014 are around 87". On a compact or portable drum, that extra 8 to 10 inches is far more slack than the idler arm can absorb, so the belt runs loose, slips on the motor pulley, and typically walks off within minutes. If you're unsure, lay your old belt flat in a loop and measure its circumference before ordering. Which way do the ribs face? On this GE platform the ribbed side faces toward the drum, so the ribs grip the drum surface while the smooth back of the belt rides against the idler pulley. This is worth stating plainly because rib orientation is not universal across manufacturers — some other platforms run the grooves against the motor pulley instead. Whenever possible, photograph the old belt before removing it. The polished wear track on the drum will also show you exactly where the belt is meant to sit. The dryer squeals but the drum still turns. Belt or something else? Could be either, and it's worth diagnosing before you order. A glazed or hardening belt squeals as it slips on the motor pulley, usually loudest at startup and under a heavy wet load. But a dry idler pulley bearing makes a very similar squeal, and worn drum rollers add a low rumble underneath. With the cabinet open, spin the idler and each roller by hand — they should turn smoothly and silently. If they're gritty, noisy, or have play, replace them along with the belt, since they share the same teardown and you'd otherwise be opening the dryer twice. Why did my belt fail in the first place? Usually heat and age — rubber hardens over years of thermal cycling until it cracks. Two things accelerate it sharply. Restricted airflow from a lint-clogged vent makes the whole cabinet run far hotter than designed, which cooks the belt. And a seized idler pulley or a flat-spotted drum roller forces the belt to drag against a stationary surface, shredding it in short order. If your belt failed unusually early, clean the vent ducting end to end and inspect the idler and rollers rather than assuming the new belt will simply last longer. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine GE OEM part, but is manufactured to match the dimensions (approximately 79" length, 1/4" width), 4-rib profile, rubber construction, and drum-drive function of the original WE03X32037 / WE12M24 belt used in compatible GE, Hotpoint, RCA, and related portable, compact, and unitized stack dryers. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Quality Aftermarket Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout

Read more less

XPARTCO 6602-001717 Dryer Drum Belt The XPARTCO 6602-001717 is an aftermarket replacement drum belt for Samsung 24-inch compact dryers. The belt wraps all the way around the outside of the drum, passes under the idler pulley, and loops around the motor pulley — as the motor turns, the belt drags the drum around with it. There is no other mechanical connection between the motor and the drum, which is why a broken belt produces the classic symptom set: the dryer powers on, the console lights up, the motor hums and the blower runs, but the drum sits completely still. Reach in and spin the drum by hand and it will turn freely with no resistance at all. Samsung specifies this belt as "BELT-TIMING GEAR; 5PH2010, RUBBER, T2.7" — a 5-rib PH-profile belt, 2010 mm long (approximately 79-1/8 inches), 2.7 mm thick, in reinforced rubber. This is a compact-platform belt used on 24" Samsung dryers, and it is physically shorter than the 6602-001655 (5PH2337) belt used on Samsung's full-size 27" dryers. Belts fail from age and heat: the rubber hardens, the ribs glaze over and start slipping, and eventually the belt cracks through or snaps outright. Frayed edges, a squealing or thumping noise that tracks drum rotation, or black rubber dust in the cabinet are all signs the belt is on its way out. Installs in 45–90 minutes with basic hand tools. Quick Answer The XPARTCO 6602-001717 Dryer Drum Belt fixes Samsung 24" compact dryers where the motor runs but the drum won't turn, the drum spins freely by hand, or the dryer squeals, thumps, or rumbles during operation. 5 ribs, PH profile, 2010 mm (~79-1/8") long, 2.7 mm thick, reinforced rubber. Also marked 5PH2010. Fits DV22K6800EW and DVE22N6850 compact platforms. Not the same belt as the full-size 6602-001655 / 5PH2337 — that one is over a foot longer. Common Problems This Part Fixes Dryer runs and hums but the drum does not turn — the classic broken belt symptom Drum spins freely by hand with no resistance when the door is open Loud squealing or screeching that starts as soon as the cycle begins Rhythmic thumping or slapping noise timed to drum rotation — cracked or split belt Grinding or rumbling from inside the cabinet as a frayed belt drags Drum turns slowly, intermittently, or stalls under a heavy wet load — glazed belt slipping Clothes not drying because the drum isn't tumbling to expose them to airflow Black rubber dust or belt fragments found in the bottom of the cabinet Visible cracking, fraying, glazing, or stretching on the old belt Cross Reference Information Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item. Replaces Part Numbers This dryer drum belt directly replaces the following OEM and cross-reference part numbers: 6602-001717, 6602001717, 5PH2010, SAM6602-001717, AP5623743, EAP4133826, ASM30222, PD00060820, PS4133826. Samsung has not superseded this belt with a newer number, so the cross-reference list is intentionally short. 5PH2010 is the belt's size designation rather than a separate part number, and it is often stamped on the belt itself — if your old belt is marked 5PH2010, this is the correct replacement. If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Heads up on bad cross-reference data: A number of online listings for 6602-001717 have incorrect cross-references copied onto them from a completely unrelated Frigidaire belt — numbers such as 134163400, AP3865318, 148270, PS1148434, and 5303283471, along with a long list of Frigidaire GLER, FDE, FER, and GLGQ model numbers. Those numbers do not apply to this Samsung belt and those Frigidaire dryers do not use it. If you arrived here from a listing showing those numbers, verify against your Samsung model number before ordering. Compatibility This drum belt is compatible with select Samsung 24-inch compact dryers, including: Samsung DV22K6800EW/A1 and DV22K6800EW/AC compact electric dryers Samsung DV22K6800EW series (all sub-variants) Samsung DVE22N6850X and DVE22N6850 series compact electric dryers Samsung DV22N6800 series compact dryers Select Samsung-built compact dryers sold under other retail labels These are Samsung's 24" ventless and compact-footprint dryers, commonly installed in apartments, condos, closets, and stacked laundry towers where a full-size 27" dryer will not fit. Note — compact platform only: The 6602-001717 is a 2010 mm belt for 24" compact Samsung dryers. It is NOT interchangeable with the 6602-001655 (5PH2337) belt used on Samsung's full-size 27" dryers such as the DV42H, DV45H, DV40J, DV48H, DV48J, and DV50K series — that belt is 2337 mm, roughly 13 inches longer. A full-size belt will hang loose on a compact drum and slip immediately; a compact belt will not stretch far enough to reach around a full-size drum. Measure your old belt or check your model number before ordering. Contact our support team with your model number if you're unsure. Key Features Aftermarket replacement drum belt for Samsung 24" compact dryers — transfers motor rotation to the drum 5-rib PH-profile design matched to the compact-platform motor pulley and idler 2010 mm circumference (approximately 79-1/8 inches) — the correct compact-dryer length 2.7 mm thickness in reinforced rubber for heat resistance and long service life Also identified by its size marking 5PH2010, often stamped on the original belt Resolves "motor runs but drum won't turn," "squealing," "thumping," and "drum spins freely by hand" symptoms Multi-rib construction grips the motor pulley without slipping under heavy wet loads Direct drop-in replacement — no cutting, splicing, or modification required Aftermarket replacement built to OEM-equivalent quality standards Straightforward DIY repair — installs in 45–90 minutes with basic hand tools Product Specifications Part Number 6602-001717 OEM Part Number 6602-001717 Size Designation 5PH2010 Part Type Dryer Drum Drive Belt Condition Aftermarket Replacement Application Samsung 24" Compact Dryers Length 2010 mm (approx. 79-1/8 in.) Ribs 5 Profile PH (multi-rib) Thickness 2.7 mm Material Reinforced rubber Color Black Rib Orientation Ribbed side faces the drum Quantity 1 belt Compatible Brand Samsung Installation Notes ⚠️ Unplug Dryer Before Starting — Note Belt Orientation And Idler Routing Disconnect power at the outlet or shut off the circuit breaker before beginning. Wear work gloves — the sheet metal edges inside the cabinet are sharp. Before you start, take a photograph of how the old belt routes around the drum, under the idler pulley, and around the motor pulley. If the belt is already broken and you cannot see the original routing, note that the ribbed side of the belt faces toward the drum on this platform, with the smooth back side riding against the idler pulley. Access on Samsung compact dryers is typically through the front: remove the top panel, then the control panel and front panel, which lets you lift the drum out or tilt it forward far enough to work. Vacuum out accumulated lint while the cabinet is open — lint buildup around the motor and idler is what cooks belts prematurely. With the drum accessible, slip the new belt around the drum roughly one-third of the way back from the front lip, ribbed side against the drum surface, and seat it in the wear track left by the old belt. Reach underneath, route the belt under the idler pulley, then loop it around the small motor pulley. A useful trick: tape the belt loosely in position on the drum with a strip of masking tape before you reach underneath, so it doesn't slide off while you're working the idler. Once seated, rotate the drum several full turns by hand and confirm the belt tracks straight and stays centered in its groove without walking toward the edge. While you are in there, spin the idler pulley and the drum rollers by hand — if either is noisy, gritty, or wobbly, replace them now, because a seized idler or worn roller will destroy the new belt in short order. Reassemble, restore power, and run a short empty cycle listening for squeal or thump before putting a load in. Tools needed: Phillips screwdriver, nut driver or socket set, putty knife, masking tape, flashlight, work gloves. Frequently Asked Questions How do I know for sure the belt is broken and not the motor? Open the door with the dryer unplugged and try to spin the drum by hand. With an intact belt you will feel firm resistance — you're turning the motor and idler through the belt. If the drum spins freely and easily, coasting like a bicycle wheel, the belt is broken or has come off its pulleys. The other tell is sound: with a broken belt the motor hums and the blower whooshes normally, so you hear a dryer that sounds like it's running perfectly while the drum sits still. A failed motor, by contrast, usually buzzes and does nothing, or trips the breaker. Which way do the ribs face on this belt? On this Samsung compact platform the ribbed side faces toward the drum, so the ribs grip the drum surface and the smooth back of the belt rides against the idler pulley. This is worth stating plainly because belt orientation is not universal across brands — some Whirlpool-platform dryers run the grooves against the motor pulley instead. Photograph your old belt before removing it whenever possible; the wear track polished into the drum will also show you exactly where the belt is meant to sit. Will the full-size Samsung belt work if I can't find this one? No. The full-size Samsung belt is 6602-001655, marked 5PH2337 — it is 2337 mm long against this belt's 2010 mm, a difference of about 13 inches. On a compact drum that extra length leaves the belt slack, so the idler cannot take up the tension and the belt slips or walks straight off the pulley. Going the other direction, a compact belt simply will not reach around a 27" drum. The rib count and profile are the same, which is exactly why these two get mixed up — always confirm the length. My dryer squeals but the drum still turns. Is it the belt or something else? It could be either, and it's worth diagnosing before you order. A glazed or hardening belt squeals as it slips on the motor pulley, usually loudest at startup and under a heavy wet load. But a dry or failing idler pulley bearing produces a very similar squeal, and worn drum rollers add a low rumble. With the dryer open, spin the idler and each roller by hand: they should turn smoothly and silently. If they're gritty, noisy, or have side-to-side play, replace them along with the belt — the parts share the same teardown, so doing them together saves you from opening the cabinet twice. Why did my belt break in the first place? Most often heat and age — rubber hardens over years of thermal cycling until it cracks. But two things dramatically accelerate it. Restricted airflow from a lint-clogged vent makes the cabinet run far hotter than designed, cooking the belt. And a seized idler pulley or a flat-spotted drum roller forces the belt to drag against a stationary surface, which shreds it quickly. If your belt failed early, clean the vent ducting end to end and inspect the idler and rollers before assuming the new belt will simply last. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Samsung OEM part, but is manufactured to match the dimensions (2010 mm length, 2.7 mm thickness), 5-rib PH profile, reinforced rubber construction, and drum-drive function of the original 6602-001717 belt used in compatible Samsung 24" compact dryers. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Quality Aftermarket Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout

Read more less

XPARTCO 8573713 Gas Dryer Thermal Cut-Off Fuse Replaces WP8573713 The XPARTCO 8573713 is an aftermarket replacement thermal cut-off fuse for Whirlpool, Maytag, Kenmore, Crosley, Amana, and Inglis gas dryers. This fuse is mounted on top of the burner funnel, directly under the drum, and it's a one-time safety device: as long as the dryer stays within its normal operating temperature, it does nothing at all, but the instant temperatures near the burner climb high enough — almost always from restricted airflow — the fuse permanently opens the circuit and cuts power. That's why a blown fuse produces such a specific symptom: the dryer won't heat, even though the drum may still tumble and the rest of the dryer seems to run normally. Because this fuse sits on the burner funnel underneath the drum rather than on the more accessible blower housing, replacing it is a more involved repair than a typical thermal fuse swap — the drum has to come out of the cabinet to reach it. Unlike a resettable thermostat, this fuse cannot be reset once it blows; it must be replaced. A blown thermal fuse is almost always a symptom rather than a random failure: restricted exhaust venting is the leading cause, since trapped heat near the burner is exactly what this fuse is designed to react to. It directly replaces WP8573713, AP6013467, and PS11746693. Quick Answer The XPARTCO 8573713 Gas Dryer Thermal Cut-Off Fuse fixes Whirlpool, Maytag, Kenmore, Crosley, Amana, and Inglis gas dryers that won't heat, even if the drum still tumbles normally. Mounted on the burner funnel under the drum. Replaces WP8573713, AP6013467, PS11746693. Always inspect and clean the dryer venting when replacing this fuse — a blown fuse is a symptom of restricted airflow, and installing a new fuse without fixing the vent will likely blow it again. Common Problems This Part Fixes Dryer runs and tumbles but produces no heat Dryer that stopped heating suddenly, especially after running unusually hot Drying times that have gotten noticeably longer or clothes coming out damp Repeated blown fuses on a dryer with a known venting or airflow restriction Dryer that recently smelled like burning or overheating before losing heat Continuity test shows an open circuit across the old fuse Cross Reference Information Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item. Replaces Part Numbers This gas dryer thermal cut-off fuse directly replaces the following OEM and cross-reference part numbers: WP8573713, 1180872, 8573713, AP3866211, EAP990558, PS990558, AWP49233, PD00006618 If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This thermal cut-off fuse is compatible with select Whirlpool gas dryers, and also fits select Maytag, Kenmore, Kenmore Elite, Crosley, Amana, Inglis, and Sears Canada gas dryers built on the Whirlpool platform, including model numbers such as WGD8500SR0, and Kenmore 11070372710 and 11071112020. Note: This fuse is specific to gas dryers, mounted on the burner funnel. It is not the same fuse used on electric dryer platforms. Always verify your full model number before ordering. Contact our support team with your model number if you're unsure. Key Features Aftermarket replacement thermal cut-off fuse — one-time safety device that cuts power if the dryer overheats Mounted on top of the burner funnel, directly under the drum Resolves "runs but won't heat," "drying takes too long," and "clothes coming out damp" symptoms caused by a blown fuse Replaces WP8573713, AP6013467, and PS11746693 Compatible with Whirlpool, Maytag, Kenmore, Kenmore Elite, Crosley, Amana, Inglis, and Sears Canada gas dryers Aftermarket replacement built to OEM-equivalent quality standards Product Specifications Part Number 8573713 OEM Part Number WP8573713 Part Type Gas Dryer Thermal Cut-Off Fuse Condition Aftermarket Replacement Application Gas Dryers Location Top of the burner funnel, under the drum Resettable No — one-time use, must be replaced once blown Material Plastic housing Dimensions Approx. 1"H x 1"W Repair Difficulty Moderate to Hard — drum removal required for access Quantity 1 thermal cut-off fuse Compatible Brands Whirlpool, Maytag, Kenmore, Kenmore Elite, Crosley, Amana, Inglis, Sears Canada Installation Notes ⚠️ Gas Safety — Shut Off The Gas Supply Before Starting This fuse sits directly on the burner funnel, close to the gas burner assembly. Before beginning, close the gas shutoff valve behind the dryer in addition to unplugging the dryer or shutting off its circuit breaker. If at any point you smell gas, stop immediately, leave the area, and do not operate any switches — contact your gas utility or a qualified technician. Do not attempt this repair if you are not comfortable working safely around a gas appliance's burner assembly; a qualified technician can complete it instead. ⚠️ Drum Removal Required — Inspect And Clean The Venting Before Reassembling Wear work gloves. This repair requires removing the drum from the dryer cabinet to access the burner funnel, so budget more time and disassembly than a typical thermal fuse swap. Remove the top and front panels according to your model's service diagram, disconnect the drive belt from the idler pulley, and lift the drum out of the cabinet to expose the burner funnel underneath. Photograph the wiring before disconnecting the old fuse's connectors. Test the old fuse for continuity with a multimeter to confirm it's actually blown (no continuity) rather than assuming, and test the new fuse to confirm it's good out of the box. This is the most important step: fully inspect and clean the dryer's exhaust vent, from the lint trap housing all the way to the exterior vent hood, checking for lint buildup, crushed sections, or excessive length. A blown thermal fuse is a symptom of restricted airflow, and skipping this step means the new fuse is likely to blow again. Install the new 8573713 fuse on the burner funnel in the same mounting position, reconnect the wiring, and reassemble the drum, belt, and panels in reverse order. Restore the gas supply and power, and run a test cycle to confirm normal heating and shutoff behavior. Tools needed: Phillips or nut driver (model-dependent), multimeter, vent brush or vacuum attachment for cleaning ductwork, work gloves. Frequently Asked Questions My dryer tumbles fine but there's no heat. Is this the right part? Yes, this is the classic symptom of a blown gas dryer thermal cut-off fuse. Because this fuse only interrupts the heating circuit and not the drive motor, the drum can continue tumbling completely normally while the dryer produces no heat at all. If you've confirmed the burner isn't igniting and the fuse tests as an open circuit, this is very likely the fix. Why does this repair require removing the drum? My other dryer's fuse didn't need that. This particular fuse is mounted on the burner funnel underneath the drum rather than on the blower housing at the back of the cabinet, which is where many thermal fuses on other platforms are located. Reaching the burner funnel requires taking the drum out of the cabinet, which is why this repair involves more disassembly than some other thermal fuse replacements. I replaced the fuse and it blew again. What's going on? This is a strong sign that the underlying cause — almost always restricted airflow — was never addressed. Thermal fuses don't fail from age; they blow because the dryer overheated. If a new fuse keeps blowing, thoroughly inspect and clean the entire exhaust path from the lint trap housing to the outside vent hood, checking for lint buildup, crushed or kinked ductwork, or a vent run that's too long. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is manufactured to match the electrical specifications and mounting configuration of the original WP8573713 thermal cut-off fuse used in compatible Whirlpool, Maytag, Kenmore, Crosley, Amana, and Inglis gas dryers. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Quality Aftermarket Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout

Read more less

XPARTCO W10112954 Dryer Drum Belt Replaces WPW10112954 The XPARTCO W10112954 is an aftermarket replacement dryer drum belt compatible with select Whirlpool, Maytag, Amana, Kenmore, and Crosley dryers. The drum belt wraps around the outside of the dryer drum, loops around the motor pulley and idler pulley, and drives the drum to rotate during every drying cycle. Without a functioning belt, the drum cannot spin and clothes will not tumble or dry. Made from durable rubber, this 5-rib Multi-V belt measures 93-1/4 inches long x 5/16 inch wide x 1/8 inch high and is built to resist cracking, stretching, and wear under the high heat and repeated tension cycles of daily dryer use. It is a direct drop-in replacement for OEM part numbers WPW10112954 and W10112954, and also replaces W10131172 on compatible models. Installs in 30–45 minutes with basic hand tools. Quick Answer The XPARTCO W10112954 Dryer Drum Belt fixes dryers where the drum is not spinning, clothes are not tumbling, or a thumping/squealing noise is coming from the dryer during operation. Compatible with select Whirlpool, Maytag, Amana, Kenmore, Crosley, and Admiral dryers. Measures 93.38" with 5 ribs and 4 grooves. Common Problems This Part Fixes Dryer drum not spinning — motor runs but drum stays still Clothes not tumbling during the drying cycle Thumping, squealing, or slapping noise during operation Dryer runs but produces no heat because drum is stationary Burning rubber smell coming from the dryer Visible broken or frayed belt pieces found inside the dryer cabinet Dryer shuts off shortly after starting due to drum not rotating Replaces Part Numbers This drum belt directly replaces the following OEM and cross-reference part numbers: WPW10112954, W10112954, 1447719, AWP48873, PD00003553, EAP11748388, AP6015116, PS11748388. If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This drum belt is compatible with select dryers from the following brands: Whirlpool dryers (gas and electric) Maytag dryers (gas and electric) Amana dryers Kenmore / Sears dryers (select Whirlpool-built models) Crosley dryers Admiral dryers Always verify your appliance model number before ordering. Contact our support team if you're unsure. Key Features Drives the dryer drum via the motor pulley and idler pulley for smooth, consistent tumbling every cycle 93-1/4" length x 5/16" width x 1/8" height — 5-rib Multi-V design for a secure, slip-free grip on the pulleys Made from durable rubber — resists cracking, stretching, and heat damage Direct replacement for OEM part numbers WPW10112954 and W10112954 — no modification required Also replaces W10131172 on compatible models Compatible with Whirlpool, Maytag, Amana, Kenmore, Crosley, and Admiral dryers Aftermarket replacement built to OEM-equivalent quality standards DIY-friendly repair — installs in 30–45 minutes with basic hand tools Product Specifications Part Number W10112954 OEM Part Number WPW10112954 Part Type Dryer Drum Drive Belt (5-Rib Multi-V) Condition Aftermarket Replacement Application Gas and Electric Dryers Length 93-1/4 inches Width 5/16 inch Height 1/8 inch Ribs 5 ribs, 4 grooves Material Rubber Color Black Compatible Brands Whirlpool, Maytag, Amana, Kenmore, Crosley, Admiral Installation Notes ⚠️ Safety First — Unplug Dryer Before Starting Unplug the dryer from the power source (and shut off the gas supply for gas dryers) before beginning any repair. To access the drum belt, remove the top panel and front panel of the dryer. Lift the drum out of the cabinet, remove the old belt, and loop the new W10112954 belt around the drum with the ribbed side facing inward toward the drum. Route the belt around the idler pulley and motor pulley — consult your dryer's service manual or a model-specific repair video for the correct belt path around the pulleys. Reassemble the front panel, top panel, and restore power before running a test cycle. Tip: While the drum is out, inspect and replace the idler pulley and drum support rollers if worn. Tools needed: Phillips screwdriver, putty knife or flat pry tool. Frequently Asked Questions What is the difference between W10112954 and WPW10112954? These are the same belt. WPW10112954 is the updated Whirlpool OEM part number that superseded the original W10112954 number. Both refer to the identical drum belt — this aftermarket replacement is compatible with both. How does the W10112954 differ from the W10205415 belt? Both are 5-rib Whirlpool-family belts, but they differ slightly in length and width. The W10112954 is 93-1/4" long x 5/16" wide. The W10205415 is 92" long x 3/8" wide. They are not interchangeable — always use the part number specific to your dryer model. How do I know if my drum belt is broken? The most obvious sign is that the dryer motor runs and you can hear it humming, but the drum does not spin. You may also hear a thumping or slapping sound if the belt is partially broken or slipping. Open the dryer cabinet to visually inspect the belt and confirm if it is broken, frayed, or stretched out of shape. Does the W10112954 also replace W10131172? Yes — the W10112954 belt replaces W10131172 on compatible models. Both are 5-rib Whirlpool-family drum belts used across similar model ranges. Always verify your specific model number to confirm the correct belt before ordering. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is made from durable rubber to match the dimensions and performance of the original WPW10112954 belt. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout

Read more less
