XPARTCO DC97-16350U Washer Suspension Rod Kit (Set of 4)
The XPARTCO DC97-16350U is an aftermarket replacement washer suspension rod kit (set of 4) compatible with a wide range of Samsung top-load washers in the WA40, WA41, WA42, WA44, WA45, WA49, and WA50 series. The suspension rods are spring-loaded shock-absorbing rods that connect the outer washer tub to the top corners of the cabinet frame, suspending the tub and dampening the vibrations generated during agitation and high-speed spin cycles. When one or more rods lose tension, break, or degrade, the tub swings off-center and strikes the cabinet walls — causing violent shaking, loud banging, error code dc (out of balance), UE imbalance errors, and progressive damage to the machine.
Each rod measures 26.4–26.5 inches in overall length and 1-1/4 inches in diameter, constructed from spring steel with plastic end caps. The kit includes all 4 suspension rods — always replace all four at the same time since they wear at the same rate. It directly replaces DC97-16350S, DC97-16350T, DC97-16350E, DC97-16350C, DC97-16350D, DC97-16350K, DC97-05280W, 4962798, AP6884450, EAP12720841, PS12720841, and PD00065434. Wear gloves during installation — the rods are coated with grease. Installs in 20–30 minutes — no special tools required.
Quick Answer
The XPARTCO DC97-16350U Washer Suspension Rod Kit fixes Samsung top-load washers that vibrate violently, bang loudly, walk across the floor, or display dc or UE imbalance error codes during spin. Set of 4 rods, 26.4–26.5" long, 1-1/4" diameter, spring steel with plastic end caps. Replace all 4 at the same time. Wear gloves — rods are greased. Compatible with Samsung WA40–WA50 series. Replaces DC97-16350S, DC97-16350T, DC97-16350E, DC97-16350C, DC97-16350D, AP6884450, PS12720841.
Common Problems This Kit Fixes
Washer vibrating violently or shaking excessively during the spin cycle
Loud banging or thumping — tub striking the cabinet walls during spin
Washer "walking" or moving across the floor during high-speed spin
Error code dc displayed — Samsung out-of-balance error during spin
Error code UE displayed — unbalanced load error the washer cannot self-correct
Washer repeatedly stopping and rebalancing the load without completing the spin cycle
Visible broken, detached, or sagging suspension rod inside the washer cabinet
Rattling or clunking during agitation — tub no longer centered
Replaces Part Numbers
This suspension rod kit directly replaces the following OEM and cross-reference part numbers:
DC97-16350U, DC97-16350S, DC97-16350T, DC97-16350E, DC97-16350C, DC97-16350D, DC97-16350J, DC97-16350K, DC97-16350U, DC97-16350E, DC97-16350S, DC97-16350C, DC97-16350D, DC97-16350T, AP6884450, ASM34747, EAP12720841, PD00065434, PS12720841.
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This suspension rod kit is compatible with select top-load washers from the following Samsung series:
Samsung WA40 series — WA400PJHDWR, WA40J3000AW, WA40A3005AW, WA44A3205AW and related models
Samsung WA41 series — WA41A3000AW and related models
Samsung WA42 series — WA422PRHDWR and related models
Samsung WA45 series — WA45H7000AW, WA45H7200AW, WA45K7600AW, WA45M7050AW, WA45N3050AW, WA45T3200AW, WA45T3400AW, WA45T3400AP, WA456DRHDSU, WA456DRHDWR and related models
Samsung WA49 series — WA49B5105AW, WA49B5205AW and related models
Samsung WA50 series — WA50R5200AW, WA50R5400AV, WA50R5400AW, WA50T5300AC and related models
Kenmore / Sears top-load washers (select Samsung-built models)
Important: The DC97-16350U rod is 26.4–26.5 inches long and is for Samsung WA40–WA50 series washers. Larger-capacity WA48–WA54 series models use the longer DC97-16350V rod (27.5 inches). Always measure your existing rods or verify your model number before ordering — using the wrong length rod can cause the tub to sit at the incorrect height inside the cabinet.
Key Features
Set of 4 suspension rods — complete replacement covering all four tub mounting points
Suspends and centers the outer tub within the cabinet — dampens agitation and spin vibration to prevent tub-to-cabinet contact
Resolves Samsung error codes dc (out of balance) and UE (unbalanced load)
Rod length: 26.4–26.5 inches overall; diameter: 1-1/4 inches
Spring steel construction with plastic end caps — durable and corrosion resistant
Rods are pre-coated with grease — wear work gloves during installation
Replace all 4 rods at the same time — rods wear together and partial replacement results in uneven tub support
No special tools required — installs in 20–30 minutes
Replaces DC97-16350S, DC97-16350T, DC97-16350E, DC97-16350C, DC97-16350D, and over 15 additional cross-references
Aftermarket replacement built to OEM-equivalent quality standards
Product Specifications
Part Number
DC97-16350U
Part Type
Washer Suspension Rod and Spring Assembly
Condition
Aftermarket Replacement
Application
Samsung Top-Load Washers — WA40, WA41, WA42, WA44, WA45, WA49, WA50 series
Quantity
Set of 4 (replace all four rods at the same time)
Rod Length
26.4–26.5 inches overall
Rod Diameter
1-1/4 inches
Material
Spring steel / Plastic end caps
Color
Brass / Black / White / Pink
Lubrication
Pre-coated with grease — wear gloves during installation
Error Codes Resolved
dc (out of balance), UE (unbalanced load)
Compatible Brands
Samsung, Kenmore (Samsung-built)
Installation Notes
⚠️ Unplug Washer and Shut Off Water Before Starting — Wear Gloves Disconnect power and turn off the water supply before beginning. Wear work gloves throughout — the suspension rods are coated with grease. Remove the lid and the top panel (typically secured by screws under the lid hinge covers and at the rear corners). With the top panel removed, the four suspension rods are visible at the corners, each running from a mounting point on the tub rim up to a hook or bracket at the top corners of the cabinet frame. Note the orientation and attachment method of each rod before removing. Unhook the top of each rod from the cabinet bracket and lift the bottom cup off the tub mounting pin. Install each new DC97-16350U rod by seating the bottom cup onto the tub mounting pin and hooking the top over the cabinet bracket. Replace all four rods before reassembling. Reinstall the top panel and lid, restore power and water, and run a spin cycle to verify smooth, quiet, centered operation. Tools needed: Phillips screwdriver; no special tools required for the rods themselves.
Frequently Asked Questions
What is the difference between DC97-16350U and DC97-16350V?
Both are Samsung top-load washer suspension rods, but they are different lengths for different washer capacity generations. The DC97-16350U is approximately 26.4–26.5 inches long and is used on mid-capacity Samsung WA40 through WA50 series washers. The DC97-16350V is approximately 27.5 inches long and is used on larger-capacity WA48 through WA54 series washers. Using the wrong length rod causes the tub to sit at the wrong height inside the cabinet, which can cause new imbalance issues. Always measure your existing rods or verify your model number before ordering.
Why must I replace all 4 rods instead of just the broken one?
All four suspension rods experience the same amount of wear over the same number of wash cycles. When one rod fails, the remaining three have experienced the same stress and fatigue and are likely to fail soon after. Replacing only the broken rod leaves three worn rods supporting the tub unevenly — this can cause continued vibration, accelerate wear on the new rod, and require a second repair shortly after. Replacing all four at the same time ensures even tub support, fully resolves the imbalance, and prevents a repeat repair.
Do DC97-16350S, DC97-16350T, and DC97-16350E all cross to the DC97-16350U?
Yes — DC97-16350S, DC97-16350T, DC97-16350E, DC97-16350C, and DC97-16350D are all cross-reference part numbers for the same Samsung suspension rod assembly used across different production runs of the same washer series. Samsung updates part number suffixes during production revisions. All of these numbers have the same 26.4–26.5" length and are interchangeable with the DC97-16350U.
What do error codes dc and UE mean on Samsung washers?
Error code dc on Samsung top-load washers indicates the machine has detected an out-of-balance condition and stopped spinning to prevent damage. Error code UE indicates an unbalanced load that the washer cannot self-correct by redistributing. Both codes can be caused by an overloaded or unevenly distributed laundry load — but if the errors occur consistently even with normal, balanced loads, worn or broken suspension rods are the most common mechanical cause. Replacing the rod kit resolves these errors in most cases.
Is this an OEM or aftermarket part?
This is an aftermarket replacement kit built to OEM-equivalent quality standards. It is not a genuine Samsung OEM part, but is manufactured from spring steel with plastic end caps to match the length and spring tension of the original DC97-16350U suspension rods.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout
DC97-19289F Genuine OEM Samsung Washer Drain Pump Assembly
The DC97-19289F is a Genuine OEM Samsung replacement washer drain pump assembly compatible with a wide range of Samsung top-load washers in the WA40, WA41, WA42, WA44, WA45, WA48, WA50, WA52, and WA54 series, as well as select Kenmore models built on the Samsung platform. The drain pump removes water from the washer tub during the drain portion of each wash cycle. When the pump fails, the washer will display error codes 5C, SE, nd, 5E, FO2, or E5, leave standing water in the tub, stop mid-cycle, or produce unusual noise during draining.
This complete drain pump assembly is rated 120V, 60Hz, 80W, 1.1A with a 30-minute on / 30-minute off duty cycle. It directly replaces DC97-19289A, DC97-19289B, DC97-17349B, DC97-17366A, DC97-17366J, and PX3516-01. Note: the wire plug on the new pump may differ slightly from the original — if the connector does not match your washer's harness, transfer the wiring harness from the old pump to the new one. Installs in 20–30 minutes with basic hand tools.
Quick Answer
The DC97-19289F Genuine OEM Samsung Washer Drain Pump Assembly fixes Samsung top-load washers displaying error codes 5C, SE, nd, 5E, FO2, or E5, not draining, leaving standing water, or making loud noise during the drain cycle. 120V/60Hz/80W/1.1A, 30 min on/30 min off duty cycle. Compatible with Samsung WA40 through WA54 series and Kenmore (Samsung-built). Replaces DC97-19289A, DC97-19289B, DC97-17349B, DC97-17366A, DC97-17366J, PX3516-01. Note: if wire plug differs, transfer harness from old pump.
Common Problems This Part Fixes
Error codes 5C, SE, nd, 5E, FO2, or E5 — washer cannot drain within the allotted time
Washer not draining — standing water remaining in the tub after a cycle
Washer stopping mid-cycle due to a drain fault
Loud humming, grinding, or rattling noise during the drain cycle
Water draining very slowly — worn pump motor below rated performance
Water leaking from the drain pump area at the bottom of the washer
Pump running continuously but water not being expelled from the tub
Replaces Part Numbers
This drain pump directly replaces the following OEM and cross-reference part numbers:
DC97-19289F, DC97-17349B, DC97-19289B,DC97-17366A, DC97-17366J, DC97-19289A,ASM772133, AP6806651, EAP12592631, PD00049911, PX3516-01, PS12592631.
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This drain pump is compatible with select top-load washers from the following brands and series:
Samsung top-load washers — WA40 series (WA400PJHDWR and related models)
Samsung top-load washers — WA41 series (WA41A3000AW and related models)
Samsung top-load washers — WA42 series
Samsung top-load washers — WA44 series (WA44A3205AW and related models)
Samsung top-load washers — WA45 series (WA45H7000AW, WA45M7050AW, WA45N3050AW, WA45T3200AW and related models)
Samsung top-load washers — WA48 series (WA48H7400AW and related models)
Samsung top-load washers — WA50 series (WA50F9A7DSP, WA50M7450AW and related models)
Samsung top-load washers — WA52 series (WA52M7750AW, WA52M8650AW and related models)
Samsung top-load washers — WA54 series (WA54M8750AV and related models)
Samsung top-load washers — WA456DRHDSU series
Kenmore / Sears top-load washers (select Samsung-built models)
Always verify your appliance model number before ordering. Contact our support team if you're unsure.
Key Features
Removes water from the tub during the drain and spin cycles for proper washer operation
Resolves Samsung error codes 5C, SE, nd, 5E, FO2, and E5 caused by drain pump failure
Rated 120V, 60Hz, 80W, 1.1A — correct electrical specifications for compatible Samsung top-load models
30-minute on / 30-minute off duty cycle — matches the operational requirements of compatible models
Replaces DC97-19289A, DC97-19289B, DC97-17349B, DC97-17366A, DC97-17366J, and PX3516-01
Wire plug may differ from original — transfer harness from old pump if connector does not match
Compatible with Samsung WA40 through WA54 series and Kenmore Samsung-built top-load washers
Genuine OEM part manufactured by Samsung to factory specifications — guaranteed fit and performance
DIY repair — installs in 20–30 minutes with basic hand tools
Product Specifications
Part Number
DC97-19289F
Also Replaces
DC97-19289A, DC97-19289B (prior versions)
Part Type
Washer Drain Pump Assembly
Condition
Genuine OEM
Application
Samsung Top-Load Washers
Voltage
120V AC
Frequency
60 Hz
Wattage
80W
Amperage
1.1A
Duty Cycle
30 minutes on / 30 minutes off
Error Codes Resolved
5C, SE, nd, 5E, FO2, E5
Connector Note
Wire plug may differ — transfer harness from old pump if needed
Compatible Brands
Samsung, Kenmore (Samsung-built)
Installation Notes
⚠️ Unplug Washer and Shut Off Water Before Starting Disconnect power and turn off the water supply before beginning. Tilt the washer back or lay it on its side to access the drain pump at the bottom of the machine. Place towels and a shallow pan to catch residual water when the pump is disconnected. Note the wiring connector orientation before disconnecting — take a photo if needed. If the new pump's connector does not match the washer's harness, carefully transfer the wiring harness from the old pump to the new pump. Disconnect the drain hoses from the pump using pliers to loosen the clamps. Unscrew the pump mounting screws and remove the old pump. Install the new DC97-19289F pump in the same position, reconnect drain hoses and secure with clamps, and reconnect the wiring harness. Restore water supply and power, then run a drain cycle to verify proper drainage and check for leaks. Tools needed: Phillips screwdriver, pliers, shallow pan, towels.
Frequently Asked Questions
What error codes indicate a drain pump failure on Samsung washers?
Error codes 5C, SE, nd, 5E, FO2, and E5 on Samsung top-load washers all indicate a drain fault — the washer was unable to drain within the expected time. These codes can also be caused by a clogged drain filter, blocked hose, or kinked drain line, so check those first. If the filter and hose are clear and the error persists after clearing them, the drain pump is the most likely cause.
What is the difference between DC97-19289F, DC97-19289A, and DC97-19289B?
These are successive revisions of the same Samsung drain pump assembly. DC97-19289A was the original version, DC97-19289B was an update, and DC97-19289F is the current version. Samsung issues revised part numbers when minor production changes are made — all three perform the same function and the DC97-19289F is the correct current replacement for any of the earlier versions. The DC97-17349B, DC97-17366A, and DC97-17366J are additional older cross-references for this pump used on earlier Samsung top-load models.
Why might the wire plug on the new pump differ from the original?
Samsung revised the wiring connector on this drain pump across different production runs. If the DC97-19289F pump you receive has a different connector than your washer's harness, do not force the connection. Instead, carefully remove the wiring harness from the old pump and transfer it to the new pump — both versions use the same internal terminals and the harness swap is straightforward. This is a known and documented step for this part and does not affect performance or safety.
Should I check the drain filter before replacing the pump?
Yes — always check and clean the drain filter and inspect the drain hose for kinks or blockages before replacing the pump. A clogged filter or blocked hose can cause the same error codes as a failed pump and clearing the blockage may resolve the problem without needing a new part. On Samsung top-load washers the drain filter is typically located at the bottom front of the machine. If the filter and hose are clear and the error persists, the pump needs replacement.
Is this an OEM or aftermarket part?
This is a Genuine OEM part manufactured by Samsung to factory specifications. It is the exact same drain pump assembly installed in compatible Samsung and Kenmore top-load washers from the factory — guaranteed fit, materials, and performance.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Genuine OEM Parts ✓ Compatibility Support ✓ Secure Checkout
WPW10409079 Washer Genuine OEM Drain Pump
Replaces Part Number: WPW10409079, W10409079, 2118648, AP6021043, PS11754363, LP09079.
Description: This Drain Pump is a replacement part for specific Whirlpool top-loading washing machine models. Located near the bottom center of the machine, it actively pumps water out of the washer tub at the end of each cycle. The pump motor spins an impeller chamber to push water through the drain hose and out of the home. Causes of failure include clogging from mineral buildup or fabric fibers within the pumping components. Over time, motor windings experience excess heat and may burn out from consistent drainage cycles. WPW10409079 is the part number for a Whirlpool washer drain pump that removes water from the washer during the drain cycle. It is compatible with many Whirlpool, KitchenAid, Maytag, Jenn-Air, Amana, Inglis, and Magic Chef models.
W11399437 Genuine OEM Washer Drain Pump
Replaces Part Numbers: AP6974144, PS12731241
Description: This Drain Pump is a Genuine OEM part for select Maytag, Kenmore, Whirlpool washer models. It is responsible for circulating water through the washing machine during all cycles. The pump draws water from the tub and dispenses it through the water supply hoses to soak, scrub, and rinse clothes.
AHA72973309 Genuine OEM LG Washer Drain & Circulation Pump Assembly
The AHA72973309 is a genuine LG OEM drain and circulation pump assembly for LG and select Kenmore front-load washers. This is a dual-purpose pump — an Askoll M120-2 unit — that handles two separate jobs from one motor and housing. During the drain portion of the cycle, it pumps wastewater out of the tub and out through the drain hose. During the wash and rinse portions, it switches roles and recirculates water from the bottom of the tub back up through the dispenser and spray nozzle, showering it back over the load. That recirculation spray is what lets LG's front-load washers clean effectively with less water than an older top-load design would need.
Because this single assembly performs both functions, a failure here can show up in more than one way: standing water left in the tub after a cycle, a washer that won't complete its drain step, unusual grinding or humming noise, or reduced wash performance if the recirculation spray isn't working even though draining still seems fine. Common causes include debris such as coins, buttons, or lint lodged in the impeller, general wear and tear on the motor bearings, or an electrical failure in the pump motor itself. It directly replaces AP5676608, 2659237, AHA72973304, and PS7788830. As a genuine OEM part, the AHA72973309 is manufactured by LG to factory specifications — guaranteed fit, materials, and performance.
Quick Answer
The AHA72973309 Genuine OEM LG Washer Drain & Circulation Pump Assembly fixes LG and select Kenmore front-load washers with standing water left in the tub after a cycle, a washer that won't drain, unusual grinding or humming noise, or reduced wash performance from a weak recirculation spray. Askoll M120-2 dual-purpose pump — handles both draining and mid-cycle water recirculation. Replaces AP5676608, 2659237, AHA72973304, PS7788830. Installation is average difficulty, 30 to 60 minutes — and on many models it's accessible through the front panel without needing to tip the washer over.
Common Problems This Part Fixes
Standing water left in the tub after a cycle finishes
Washer won't drain, or drains very slowly
Drainage-related error code displayed on the control panel
Unusual grinding, humming, or rattling noise during the drain or wash portion of the cycle
Reduced wash performance — clothes not getting as clean, possibly from a weak recirculation spray
Washer stalling mid-cycle at the drain step
Water leaking from underneath the washer near the pump housing
Pump that hums but doesn't seem to move water — possible clog or seized impeller
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This washer drain and circulation pump assembly directly replaces the following OEM and cross-reference part numbers:
AHA72973309, AHA72973304, AP5676608, 2659237, ALG53336, PD00024680, PS7788830
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This drain and circulation pump assembly is compatible with select LG front-load washers, and also fits select Kenmore and Kenmore Elite front-load washers built on the LG platform.
Note: This is a dual-function drain-and-circulation assembly specific to LG's front-load platform, built around the Askoll M120-2 pump. It is not a drain-only pump, and it is not intended for top-load washers, which use a different pump design. Always verify your full model number before ordering. Contact our support team with your model number if you're unsure.
Key Features
Genuine LG OEM part — factory-specified motor, impeller, and housing design
Dual-purpose Askoll M120-2 pump — drains the tub and recirculates wash water through the dispenser spray nozzle
Resolves "standing water in the tub," "won't drain," "grinding or humming noise," and "reduced wash performance" symptoms caused by pump failure
Includes all necessary wiring and mounting hardware for a complete replacement
Direct drop-in replacement — no modification required
Replaces AP5676608, 2659237, AHA72973304, and PS7788830
Compatible with LG and select Kenmore/Kenmore Elite front-load washers
Genuine OEM replacement — guaranteed fit, materials, and performance
Average installation difficulty — typically 30 to 60 minutes
Product Specifications
Part Number
AHA72973309
Part Type
Washer Drain & Circulation Pump Assembly
Condition
Genuine OEM
Brand
LG
Pump Model
Askoll M120-2
Function
Drains tub water and recirculates wash water through the dispenser spray
Kit Contents
Pump assembly with wiring and mounting hardware
Application
Front-Load Washers (LG-Built)
Repair Difficulty
Average — 30 to 60 minutes
Quantity
1 pump assembly
Compatible Brands
LG, select Kenmore, Kenmore Elite
Installation Notes
⚠️ Unplug Washer And Shut Off Water Before Starting — Drain Residual Water First Disconnect power at the outlet or shut off the circuit breaker, and close the water supply valves before beginning. Wear work gloves. Place towels down and have a shallow pan ready, since the pump housing will hold residual water even after a completed cycle — draining this into a pan before disconnecting hoses will save you a mess. On many models, this pump is fully accessible by removing the front lower access panel or kick plate, without needing to tip the washer onto its back — check this first, since it can save significant time and effort compared to some online guides that recommend tipping the unit. Photograph the hose routing and wiring connections before disconnecting anything. Disconnect the two hose clamps connecting the pump to the tub and drain hose, and unplug the electrical connector from the pump motor. Remove the mounting screws or clips securing the pump assembly and lift it free, checking the impeller area for coins, buttons, or debris while it's out — clearing a clog here may have been the actual cause of the original symptom. Install the new AHA72973309 in the same orientation, reconnect both hoses with their clamps, and reconnect the electrical connector fully. Reinstall the front access panel, restore water and power, and run a short cycle to confirm normal draining, recirculation spray, and no leaks around the pump housing. Tools needed: Phillips screwdriver, hose clamp pliers, shallow pan or towels, work gloves.
Frequently Asked Questions
Do I really need to tip the washer over to replace this pump?
Not necessarily — check your model first. While a lot of general online guidance recommends tipping the washer onto its back to access the pump from underneath, many LG and Kenmore Elite front-load models make this pump fully accessible through the front lower access panel or kick plate instead, without any tipping required. It's worth removing that panel first and seeing what you find before committing to the more involved tip-over approach.
Why does this one pump handle both draining and something during the wash cycle?
LG's front-load washers use this same Askoll pump for two different jobs at different points in the cycle: pumping wastewater out during the drain step, and recirculating water from the bottom of the tub back up through the dispenser and spray nozzle during wash and rinse to shower it over the load. That recirculation spray is part of how these washers clean effectively while using less water than an older top-load design. Because one pump does both jobs, a failure can affect draining, wash performance, or both, depending on what's actually gone wrong inside it.
There's water left in the tub after every cycle. Is this definitely the pump?
It's one of the most common causes, but check the easy things first. A clogged drain filter or a kinked drain hose can produce the same "won't drain" symptom and cost nothing to fix. If the filter and hose are clear and water is still standing in the tub, or if the pump hums but doesn't seem to move any water, the pump assembly itself has likely failed.
My washer drains fine but clothes aren't coming out as clean. Could this pump be the cause?
Possibly. Since this same assembly also handles the recirculation spray during wash, a partial failure can leave draining intact while weakening or eliminating that spray function, which reduces how effectively detergent and water reach the load. If drainage is normal but wash performance has noticeably declined, it's worth having this pump checked as one possible cause alongside things like detergent dosing and water hardness.
Is this an OEM or aftermarket part?
This is a genuine OEM part, manufactured by LG to factory specifications — guaranteed fit, materials, and performance. It includes the same Askoll M120-2 dual-function pump design, wiring, and mounting configuration as the drain and circulation pump assembly originally installed in your front-load washer.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Genuine OEM Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
XPARTCO WH03X30517 Washer Shift Actuator
The XPARTCO WH03X30517 is an aftermarket replacement shift actuator (mode shifter) for GE top-load washers, and also fits select Hotpoint and Kenmore models. Mounted at the bottom of the washer, this actuator changes the function of the washer's motor between agitation and spin cycles, effectively managing the conversion from agitation to high-speed rotation that removes moisture from clothing at the end of the wash.
Made mostly of plastic, with two mounting holes and a single wire harness connection. Over time, the actuator's internal motor can burn out or fail electrically. Symptoms of a failing shift actuator include the washer failing to switch between agitation and spin modes, the washer not spinning or agitating at all, abnormal noise or grinding during the cycle, or clothes coming out still soggy after a completed wash. It directly replaces WH03X30517, WH05X24435, WH05X25036, 290D1056G001, 4588015, 4961069, AP7014559, AGE25894, PD00068062, EAP16554752, PS16554752.
Quick Answer
The XPARTCO WH03X30517 Washer Shift Actuator fixes GE, Hotpoint, and Kenmore top-load washers that won't switch between agitation and spin, won't spin or agitate at all, or leave clothes still soggy after a wash. Sold individually. Replaces WH03X30517, WH05X24435, WH05X25036, 290D1056G001, 4588015, 4961069, AP7014559, AGE25894, PD00068062, EAP16554752, PS16554752. If your washer agitates and spins fine individually but still won't switch between the two modes after replacing this actuator, the underlying cause may lie elsewhere — one customer found this exact residual symptom after installing this part.
Common Problems This Part Fixes
Washer won't switch between agitation and spin modes
Washer not spinning or agitating at all
Abnormal noise or grinding during the wash cycle
Clothes still soggy after a completed wash cycle
No clicking sound heard when the washer attempts to change modes
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This washer shift actuator directly replaces the following OEM and cross-reference part numbers:
WH03X30517, WH05X24435, WH05X25036, 290D1056G001, 4588015, 4961069, AP7014559, AGE25894, PD00068062, EAP16554752, PS16554752
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This shift actuator is compatible with select GE top-load washers, and also fits select Hotpoint and Kenmore washers built on the GE platform, including model numbers such as:
GTW680BSJ0WS, GTW680BSJ1WS, GTW680BSJ2WS, GTW680BSJ3WS, GTW680BSJ4WS, GTW680BSJ5WS, GTW680BSJ6WS, GTW680BSJ7WS
GTW220ACK1WW, GTW220ACK2WW, GTW220ACK3WW, GTW220ACK7WW
GTW540ASP0WS, GTW540ASP1WS, GTW465ASN2WW, GTW500ASN1WS, GTW685BSL2WS
YTW4514SN0WS, YTW4514SN1WS, YTW4514PN0DG, YTW4514PN1DG
GTW335ASN0WW, GTW335ASN2WW, GTW460AMJ2WW, GTW750CPL0DG
GTW490ACJ1WW, GTW490ACJ1WS, GTW490ACJ6WW, GTW490ACJ6WS
HTW200ASK0WW, HTW200ASK1WW, HTW200ASK2WW, HTW200ASK3WW, HTW200ASK4WW
HTW240ASK0WS, HTW240ASK1WS, HTW240ASK2WS, HTW240ASK3WS, HTW240ASK4WS, HTW240ASK5WS, HTW240ASK6WS
Note: This is the standalone shift actuator only, sold individually. A related but separate combined kit exists that also includes a shift clutch (WH05X24185); if you also need the clutch, order it separately. Always verify your full model number before ordering. Contact our support team with your model number if you're unsure.
Key Features
Aftermarket replacement shift actuator (mode shifter) — switches the motor between agitation and spin
Resolves "won't switch modes," "won't spin or agitate," and "clothes still soggy" symptoms caused by actuator failure
Mostly plastic construction, two mounting holes, single wire harness
Direct drop-in replacement matching the original mounting
Replaces WH03X30517, WH05X24435, WH05X25036, 290D1056G001, 4588015, 4961069, AP7014559, AGE25894, PD00068062, EAP16554752, PS16554752
Compatible with GE, Hotpoint, and Kenmore top-load washers
Aftermarket replacement built to OEM-equivalent quality standards
Sold individually
Typical repair takes 15 to 30 minutes
Product Specifications
Part Number
XPWH03X30517
OEM Part Number
WH03X30517
Part Type
Washer Shift Actuator (Mode Shifter)
Condition
Aftermarket Replacement
Material
Plastic
Mounting
Two screw holes
Wiring
Single wire harness
Related Part
WH05X24185 shift clutch (sold separately)
Repair Difficulty
Easy to Moderate — 15 to 30 minutes
Quantity
1 shift actuator (sold individually)
Compatible Brands
GE, Hotpoint, Kenmore
Installation Notes
⚠️ Unplug Washer Before Starting — Laying The Washer On Its Side Makes Access Easier Disconnect power at the outlet before beginning. Wear work gloves. This repair typically requires tipping or laying the washer on its side to access the bottom of the machine, where the shift actuator is mounted. Lay the washer down carefully, protecting the floor and the washer's exterior. Locate the shifter connector and unplug it, then remove the two screws holding the actuator in place. Take out the old actuator. Install the new WH03X30517 in the same position, securing it with the two mounting screws, and reconnect the wire harness connector fully. Stand the washer back upright. Restore power and run a test cycle to confirm the washer switches correctly between agitation and spin, listening for a clicking sound as it changes modes. Tools needed: Phillips screwdriver, work gloves.
Frequently Asked Questions
My washer won't switch from wash to spin, but it will spin if I catch it there. Is this the part I need?
Yes, this is a well-documented symptom of a failing shift actuator. One customer described their machine not going to wash mode with no clicking sound heard when the mode should change, which is a classic sign this part has failed. They accessed the actuator by laying the machine on its side, then unplugged the shifter connector and removed two screws to complete the swap.
I replaced this part but my washer still won't switch from wash to spin. What's going on?
This is a fair question, and it's worth knowing that replacing this actuator doesn't always resolve every mode-switching problem on its own. One customer replaced the mode shifter, cleared all codes, and confirmed the washer agitated and spun fine individually, but it still wouldn't switch between the two modes — suggesting a different or additional component may have been involved in their specific case. If you're still having trouble after installing this part, further diagnosis of the transmission or related components may be needed.
Does this come with the clutch too?
No, this listing is for the shift actuator only, sold individually. A related shift clutch, WH05X24185, is a separate part — if your repair requires replacing both, you'll need to order the clutch separately.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine GE OEM part, but is manufactured to match the mounting, wiring, and switching function of the original WH03X30517 shift actuator used in compatible GE, Hotpoint, and Kenmore top-load washers.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Quality Aftermarket Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
Genuine OEM WH23X10040 Washer Drain Pump
The WH23X10040 is a genuine OEM drain pump from GE for GE and Kenmore laundry centers, the stacked washer and dryer units. The drain pump removes water from the washer tub during the drain and spin portions of the cycle. When it clogs, wears out, or fails, the washer may leave water in the tub, stop mid-cycle, drain slowly, or make unusual noise while draining.
This is a genuine OEM part, not an aftermarket equivalent, so the fit and operation match the original pump. Retailers rate it as a moderate DIY repair, and reviewers report roughly 15 to 30 minutes, using pliers, screwdrivers, and a socket set.
Quick Answer
The Genuine OEM WH23X10040 Drain Pump fixes a GE or Kenmore laundry center whose washer won't drain, leaves standing water in the tub, or stops mid-cycle because the pump has failed. Genuine OEM from GE Appliances. Classic symptom: the cycle stalls with water still in the tub, or you hear the pump hum or grind but the water doesn't leave.
Common Problems This Part Fixes
Washer won't drain
Standing water left in the tub after the cycle
Washer stops mid-cycle with water in the tub
Unusual noise while the washer drains
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This drain pump is listed under the following part number:
WH23X10040, 2216538, 228C89P001, AGE26071, AH3501453, AP5306354, EA3501453, EAP3501453, PD00030410, PS3501453
We have not found any superseded or alternate manufacturer numbers for this pump. If your old pump or parts diagram shows a different number, contact our support team and we'll check whether it matches.
Compatibility
This drain pump is listed for GE and Kenmore laundry centers, including these examples:
GE GUV27ESSM1WW, GUV27ESSM0WW, GUD27ESPM1DG, GUD27GSSM2WW
GE GTUP270GM0WW, GTUP270EM1WW, GTUP240EM4WW, GTUN275GM0WW
Kenmore 2661532210, 2661532110
Note: The models above are a small sample, not a full list. This pump is for laundry centers, and GE uses different drain pumps in its other washers, so check your model number against your parts diagram, or contact our support team to verify fit before ordering.
Key Features
Genuine OEM GE drain pump, not an aftermarket equivalent
Removes water from the tub during the drain and spin portions of the cycle
Resolves no-drain, standing-water, and mid-cycle stall problems caused by a failed pump
Listed for GE and Kenmore laundry centers
Reviewers report a 15 to 30 minute repair
Product Specifications
Part Number
WH23X10040
OEM Part Number
WH23X10040
Part Type
Washer Drain Pump
Condition
Genuine OEM
Manufacturer
GE Appliances
Application
GE & Kenmore Laundry Centers
Installation Notes
⚠️ Unplug Power and Expect Water Unplug the laundry center and turn off the water supply before starting, and shut off the gas supply first on gas models. Wear work gloves. Put towels and a shallow pan under the work area, since some water will remain in the pump and hoses. Following your model's service guide, remove the panel needed to reach the pump, note how the wiring connector and hoses are attached, and disconnect them. Remove the old pump, fit the new one in the same position, and reattach the hoses and wiring. Replace the panel, restore power and water, and run a drain cycle while checking for leaks. Inspect the hoses and clamps while you are there and replace any that are worn.
Frequently Asked Questions
My washer won't drain. Is this the part I need?
A failed or clogged drain pump is a common cause. Before replacing it, check the drain hose and the pump for a clog from a sock, coin, or lint. If the path is clear but the pump hums, grinds, or doesn't run, replacing it should fix the problem.
Is this pump for any GE washer?
No. Retailers list it for GE and Kenmore laundry centers, and GE uses other drain pump numbers for its other washers. Check your model number against your parts diagram, or contact our support team, before ordering.
Is this an OEM or aftermarket part?
This is a genuine OEM part from GE Appliances, not an aftermarket equivalent.
Will this fit my laundry center?
It is listed for many GE and Kenmore laundry centers, but the model list above is only a sample. Match the number on your old pump or parts diagram, or contact our support team with your model number and we'll confirm fit before you order.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Genuine OEM Parts ✓ Compatibility Support ✓ Secure Checkout
WH23X10026 Washer Genuine OEM Drain Pump
Description: The GE drain pump assembly is an OEM replacement part responsible for removing wastewater, including dirty water and detergent residue, from the washer's tub during the drain cycle. This pump assembly consists of a motor and an impeller, which removes dirty water through the drain hose and out of the appliance. This part ensures that the washing machine efficiently drains water, allowing for the completion of the laundry cycle.
Replaces Part Numbers: WH23X10028, WH23X10026, WH23X10037, AP4324598, AH1766031, EA1766031, PS1766031.
California Residents only
WARNING: California’s Proposition 65
XPARTCO 6501KW2001B Washer Rotor Positioning Sensor
The XPARTCO 6501KW2001B is an aftermarket replacement rotor position sensor (RPS) compatible with a wide range of LG and Kenmore direct-drive front-load washers. This 5-pin Hall effect sensor mounts to the motor stator and monitors the speed and rotational direction of the motor rotor, feeding that data back to the control board so it can properly manage spin speed, direction changes during wash/rinse agitation, and load balancing.
When this sensor fails or reads inaccurately, the control board loses the feedback it needs to run the motor correctly, and the washer commonly throws an "LE" (motor/rotor position) error code, fails to spin or agitate, or runs unusually long cycles as it struggles to detect motor movement. Built with PBT-GF30 housing and black epoxy potting for durability in the motor compartment. It directly replaces 6501KW2001A, 6501KW2001D, AP5973402, PS11706506, EAP11706506, and 3282954. Installs in 30–60 minutes with basic hand tools.
Quick Answer
The XPARTCO 6501KW2001B Washer Rotor Positioning Sensor fixes LG and Kenmore (LG-built) direct-drive front-load washers throwing an "LE" error code, failing to spin or agitate, or running abnormally long cycles. 5-pin Hall effect sensor, PBT-GF30 housing, black epoxy potting. Replaces 6501KW2001A, 6501KW2001D, AP5973402, PS11706506, EAP11706506, 3282954. Classic symptom: washer displays "LE" and stops mid-cycle, or won't spin at all.
Common Problems This Part Fixes
Washer displays an "LE" (motor/rotor position) error code
Tub fails to spin or agitate during the wash cycle
Washer struggles to detect load movement, resulting in abnormally long cycle times
Motor runs erratically or stalls mid-cycle
Washer stops partway through a cycle without completing
Inconsistent or failed direction changes during agitation
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This rotor position sensor directly replaces the following OEM and cross-reference part numbers:
6501KW2001B, 6501KW2001A, 6501KW2001D, PD00001726, EAP2497738, 6501KW2001C, EBR37560301, ALG52243, AP4457567, AP5973402, EAP11706506, 3282954, PD00059513, PS3529185, PS11706506
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This rotor position sensor is compatible with select LG-built direct-drive front-load washers, including:
LG front-load washers (including WM1814CW, WM2010CW, WM2016CW, WM3455HW)
Kenmore front-load washers (select LG-built models, including WD-3243RHD, WD-3245RHD, WD-3274RHD)
Important: Do not confuse this with 6501KW2002B, which is a different, non-interchangeable rotor position sensor used on other LG washer platforms. Some newer LG models also integrate the Hall sensor directly into the motor stator assembly (such as AJB73816004) rather than using a standalone sensor like this one. Always verify your appliance model number before ordering, and check your parts diagram to confirm whether your model uses a standalone sensor. Contact our support team with your model number if you're unsure.
Key Features
Direct-fit replacement LG/Kenmore washer rotor position sensor (Hall effect, 5-pin)
Resolves "LE error code," "won't spin," "won't agitate," and "long cycle time" symptoms
Monitors motor rotor speed and rotational direction for accurate control board feedback
PBT-GF30 housing with black epoxy potting for durability in the motor compartment
Replaces 6501KW2001A, 6501KW2001D, AP5973402, PS11706506, EAP11706506, and 3282954
Compatible with select LG and Kenmore (LG-built) direct-drive front-load washers
Aftermarket replacement built to OEM-equivalent quality standards
Product Specifications
Part Number
XP6501KW2001B
OEM Part Number
6501KW2001B
Part Type
Washer Motor Rotor Position Sensor
Condition
Aftermarket Replacement
Sensor Type
Hall Effect, 5-Pin
Housing Material
PBT-GF30 with black epoxy potting
Application
LG-Built Direct-Drive Front-Load Washer Motor Assembly
Compatible Brands
LG, Kenmore
Installation Notes
⚠️ Unplug Washer Before Starting Disconnect power before beginning. Access the motor compartment, typically by removing the rear panel of the washer. Locate the rotor position sensor mounted to the motor stator near the rotor. Photograph the wiring before disconnecting, then unplug the sensor's connector from the wiring harness. Remove the mounting screw(s) or clip holding the sensor to the stator and remove the old sensor. Install the new 6501KW2001B sensor in the same position, taking care to seat it at the correct distance/orientation from the rotor magnets, and secure it. Reconnect the wiring harness connector, matching your photos. Reinstall the rear panel, restore power, and run a test cycle to confirm the washer spins and agitates normally without triggering an LE error code. Tools needed: nut driver or screwdriver, needle-nose pliers (for wiring connectors).
Frequently Asked Questions
My washer shows an "LE" error code — is this the part I need?
This is one of the most common causes of an LE (motor/rotor position) error on LG and LG-built Kenmore washers. If your washer displays LE and stops mid-cycle or won't spin, this sensor is a likely culprit. That said, LE errors can also stem from the control board or a damaged wiring harness between the sensor and the board, so if replacing the sensor doesn't resolve the error, those components are the next things to inspect.
Is this the same as the 6501KW2002B sensor?
No — 6501KW2001B and 6501KW2002B are different, non-interchangeable rotor position sensors used on different LG washer platforms. Confirm your exact part number from your appliance's parts diagram before ordering, since these two are easy to mix up by their similar naming.
My LG washer's parts diagram doesn't show a separate rotor position sensor — why?
Some newer LG models integrate the Hall sensor directly into the motor stator assembly (such as part AJB73816004) rather than using a standalone sensor like this one. If your model doesn't list a standalone sensor, check whether your repair requires the full stator assembly instead. Contact our support team with your model number if you're unsure which one applies to your washer.
Do I need any special tools to install this?
No special tools — a nut driver or screwdriver to access the rear panel and remove the sensor's mounting screw(s), plus needle-nose pliers to help with the wiring connector. The main thing to get right is reinstalling the new sensor at the same position and orientation relative to the rotor as the original.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout
W11458345 Genuine OEM Washer Drain Pump - Compatible with Whirlpool, Maytag, Amana
Product Description
Restore your washer’s performance with the W11458345 Genuine OEM Washer Drain Pump. This Whirlpool-manufactured pump is designed as a replacement for select Whirlpool, Maytag, Amana, Inglis, and Kenmore washing machines. It efficiently drains wastewater during wash cycles and includes a large filter that can be cleaned monthly with Washing Machine Cleaner Tablets. This part addresses issues like water not draining, loud buzzing or grinding noises, or failure to enter agitation cycles, often caused by blockages, wear, or pump motor failure.
Note: Includes (1) drain pump assembly. Disconnect power before installation. Verify compatibility with your washer model.
Replaces part numbers: W11458345, W11316609, W10918608, W11319789, PD00062450, EAP16218041, AP6989186, PS16218041.
Compatibility:
Compatible with select washer models, including but not limited to:
Whirlpool: WFW862CHC3, WFW6620HW1, WFW6620HW2, WFW9620HC2, 8TWFW8620HW1
Maytag: MHW5630HW1, MHW5630HW3, 7MWFW5622HW2
Amana: NFW5800HW0
Kenmore: 110.42932200
Inglis: IFW5900HW0
Verify your model number or contact our support team for assistance.
Key Features:
✅ Brand and Models Compatibility: Fits select Whirlpool, Maytag, Amana, Inglis, and Kenmore washers.
🔧 Specifications: Genuine OEM Whirlpool drain pump, 120V, stainless steel construction.
💪 Reliable Performance: Efficiently drains wastewater for optimal washer operation.
🛠️ Easy Installation: Requires screwdriver, pliers, and nut driver; typically installed in 30–60 minutes.
🛡️ Effective Fixes: Resolves water not draining, buzzing/grinding noises, or agitation cycle issues.
Product Specification
Part Number: W11458345
Component Type: Washer drain pump assembly
Material: Stainless steel and plastic (Based on web:0, web:1, web:2, web:3, web:4, web:5, web:6, web:7, web:8, web:9, web:10, web:11, web:12, web:13, web:14, web:15)
Dimensions: Approximately 9.75" L x 9.5" W x 5.25" H (Based on web:0)
Weight: 3.32 lbs (Based on web:0)
Electrical Specs: 120V, submersible design (Based on web:0, web:2)
Compliance: UL-listed, Prop 65 warning for California (Based on web:0, web:1, web:2, web:3, web:4, web:5, web:6, web:7, web:8, web:9, web:10, web:11, web:12, web:13, web:14, web:15)
Installation Notes:
Safety First: Disconnect the washer from the power source before installation.
Shop for high-quality appliance parts with a 30-day return policy. Keep your washer running smoothly today!
Add to cart now for a reliable fix!
WP3363394 Genuine OEM Washer Drain Pump
The WP3363394 is a genuine Whirlpool OEM drain pump for direct-drive (no-belt) Whirlpool, Kenmore, Maytag, KitchenAid, Estate, Roper, Crosley, and Inglis top-load washers. This pump mounts directly to the washing machine's motor using two clips, and removes water from the tub during the drain portion of the wash cycle. It has one large port and one small port for its hose connections.
Over time, the pump can become locked up internally, or a small object can get lodged inside and clog it, preventing normal drainage. Symptoms of a failing pump include the washer not draining at all, or a small leak appearing near the front of the washer from a defective pump. A DIY replacement typically takes about 10 to 15 minutes. It directly replaces 3363394, WP3363394VP, AP6008107, 21024, 3296, 3348014, 3348015, 3348215, 3352492, 3352493, 3352292, 3352293, 62516, 63347, 64076, 8235, PS11741239, EAP11741239, and 1195967.
Quick Answer
The WP3363394 Genuine OEM Washer Drain Pump fixes direct-drive Whirlpool, Kenmore, Maytag, KitchenAid, Estate, Roper, Crosley, and Inglis top-load washers that aren't draining, or are leaking near the front of the unit. Mounts to the motor with two clips; one large port, one small port. Replaces 3363394, WP3363394VP, AP6008107, 21024, 3296, 3348014, 3348015, 3348215, 3352492, 3352493, 3352292, 3352293, 62516, 63347, 64076, 8235, PS11741239, EAP11741239, 1195967. This pump is specifically for direct-drive (no-belt) washers — confirm your washer's drive type before ordering.
Common Problems This Part Fixes
Washer not draining — standing water left in the tub after a cycle
Small leak near the front of the washer
Pump that has locked up or become clogged with a small object
Cycle stalling at the drain step and never advancing
Unusual noise coming from the pump during the drain phase
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This washer drain pump directly replaces the following OEM and cross-reference part numbers:
WP3363394, 3363394, 21024, 3296, 3348014, 3348015, 3348215, 3352492, 62516, 63347, 64076, 8235, AP6008107, AWP47721, EAP11741239, PD00002328, PS11741239
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This drain pump is compatible with select direct-drive Whirlpool top-load washers, and also fits select Kenmore, Maytag, KitchenAid, Estate, Roper, Crosley, and Inglis washers built on the Whirlpool platform, including model numbers such as WET4024EW, LTE5243DQ, LTE5243DQA, LTG5243DQ, CAM2742TQ, MAT14PDAWW, LSW9750PQ3, TAWS850PQ2, LSR7233EQ, and Kenmore 110.26812690 and 110.28522701.
Note: This pump is designed specifically for direct-drive (no-belt) washers. Belt-drive models use a different pump design. Always verify your full model number before ordering. Contact our support team with your model number if you're unsure which pump your washer needs.
Key Features
Genuine Whirlpool OEM part — factory-specified pump design for direct-drive washers
Mounts directly to the motor with two clips
Resolves "not draining" and "leaking near the front of the washer" symptoms caused by pump failure
One large port, one small port for hose connections
Factory Certified Part built to Whirlpool's engineering specifications
Direct drop-in replacement — matches the original mounting and hose connections
Replaces 3363394, WP3363394VP, AP6008107, 21024, 3296, 3348014, 3348015, 3348215, 3352492, 3352493, 3352292, 3352293, 62516, 63347, 64076, 8235, PS11741239, EAP11741239, and 1195967
Compatible with Whirlpool, Kenmore, Maytag, KitchenAid, Estate, Roper, Crosley, and Inglis top-load washers
Genuine OEM replacement — guaranteed fit, materials, and performance
DIY-friendly repair, typically 10 to 15 minutes
Product Specifications
Part Number
WP3363394
Part Type
Washer Drain Pump
Condition
Genuine OEM
Brand
Whirlpool
Application
Direct-Drive (No-Belt) Top-Load Washers
Mounting
Direct to motor, secured with two clips
Ports
1 large port, 1 small port
Companion Clip
WP8546127 (recommended addition)
Repair Difficulty
Easy — 10 to 15 minutes
Quantity
1 drain pump
Compatible Brands
Whirlpool, Kenmore, Maytag, KitchenAid, Estate, Roper, Crosley, Inglis
Installation Notes
⚠️ Unplug Washer Before Starting Disconnect power at the outlet or shut off the circuit breaker before beginning. Wear work gloves. Remove the two screws securing the top panel of the washer, then carefully lift off the panel and set it aside. Disconnect the hoses connected to the drain pump by squeezing the clamps and pulling them off, then disconnect the wires from the terminals. Using a Phillips-head screwdriver, unscrew the four screws around the old pump and carefully lift it out. Take the new WP3363394 and place it into the same position as the old one, securing it with the screws. Attach the hoses back onto their ports and plug the wires back into the terminals. Reinstall the top panel and secure its screws. Restore power and run a test cycle to confirm the washer drains completely with no leaks. Tools needed: multi-screwdriver, standard pliers, work gloves.
Frequently Asked Questions
My washer isn't draining. Is this the right pump?
Yes, this is the most direct symptom of a failed drain pump. If the pump has locked up internally or become clogged by a small object, water won't be removed from the tub during the drain phase, leaving standing water behind after the cycle finishes.
How do I know if my washer is direct-drive or belt-drive?
This pump is specifically designed for direct-drive washers, which don't use a belt to connect the motor to the transmission. If you're not sure which type your washer uses, check your model number against the compatibility list, or contact our support team for confirmation before ordering, since belt-drive washers require a different pump design.
Should I replace the mounting clips at the same time?
It's worth considering, especially if your original clips show wear or damage. The companion clip, WP8546127, is commonly recommended alongside this pump since it secures the pump to the motor, and replacing a worn clip at the same time can help ensure a secure fit for the new pump.
Is this an OEM or aftermarket part?
This is a genuine OEM part, manufactured by Whirlpool to factory specifications — guaranteed fit, materials, and performance. It matches the original pump design, port configuration, and motor mounting of the drain pump originally installed in your washer.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Genuine OEM Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
