XPARTCO 3977394 Dryer Thermal Cut-Off Kit – Compatible with Whirlpool, Kenmore, Maytag, and KitchenAid Dryers
Product Description
Protect your dryer from overheating with the XPARTCO 3977394 Dryer Thermal Cut-Off Kit. This high-quality aftermarket replacement shuts off the heating element if the dryer temperature rises above safe operating limits. A failed cut-off can cause no-heat issues or overheating during drying cycles. Installing this reliable XPARTCO 3977394 kit restores safe temperature control and helps prevent damage to internal components.
Replaces Part Numbers
XPTC352, 3977394, 352F, EXPTC352
Compatibility
This replacement thermal cut-off kit fits select Whirlpool, Kenmore, Maytag, Roper, Estate, Crosley, and KitchenAid dryers.
Example compatible models include (but are not limited to): Whirlpool WED4815EW1, Kenmore 110.86573110, and Maytag MEDC215EW1.
Always verify your dryer’s model number before ordering. Contact our support team if you’re unsure.
✅ Key Features
🔄 Aftermarket Replacement – Matches OEM safety and temperature performance
🔥 Overheat Protection – Automatically shuts off power to the heating element if the dryer overheats
💰 Cost-Effective Fix – Affordable alternative to OEM thermal cut-off kits
🛠️ Easy Installation – Direct-fit design with included thermostats and connectors
🛡️ Fixes Common Issues – Solves dryer not heating, overheating, or shutting off prematurely
📐 Product Specification
Part Number: 3977394
Component Type: Dryer Thermal Cut-Off Kit
Includes: Thermal cut-off, high-limit thermostat, mounting hardware, and wire connectors
Temperature Rating: Cut-off opens at ~352°F.
Material: Metal thermostat housing and heat-resistant components
Compliance: Built to OEM-equivalent quality standards (not OEM)
🛠️ Installation Notes
Tools Needed: Nut driver, Phillips screwdriver
⚠️ Safety First: Always unplug the dryer before performing any repairs to prevent electrical shock.
Steps:
Disconnect power and remove the rear dryer panel.
Locate the heating element housing and identify the cut-off and thermostat.
Disconnect wires and remove the old components.
Install the new 3977394 cut-off and thermostat in the same locations.
Reconnect wires, reassemble the back panel, and restore power.
Run a short test cycle to verify proper heating.
⏱️ Time Required: 15–25 minutes
📦 Shop With Confidence
🚚 Free Shipping on All Orders
⚙️ Trusted Appliance Parts Supplier
🔄 30-Day Return Policy
Keep your dryer safe and efficient — Add to Cart Now for a reliable, budget-friendly repair!
XPARTCO 280148 Dryer Thermostat Set
The XPARTCO 280148 is an aftermarket replacement thermal fuse and high-limit thermostat set for Whirlpool electric dryers, and also fits select Kenmore, Maytag, Amana, Roper, Estate, Crosley, Admiral, KitchenAid, and Norge models. This set bundles the 8557403 high-limit thermostat, which monitors temperature and automatically cuts power to the heating element if it overheats, then resets itself once the dryer cools, together with the 8318314 thermal fuse, a one-time backup safety device that permanently opens the circuit if temperatures climb high enough that the thermostat alone doesn't prevent an overheat.
These two parts are sold together and commonly fail around the same time, since they protect the same circuit and respond to the same underlying overheating conditions — most often restricted exhaust venting. Symptoms include the dryer not heating at all, taking longer than normal to dry a load, or overheating before shutting down. It directly replaces 280148VP, 1175772, AP3874047, PS991443, EAP991443, and 314634.
Quick Answer
The XPARTCO 280148 Dryer Thermostat Set fixes Whirlpool, Kenmore, Maytag, Amana, Roper, Estate, Crosley, Admiral, KitchenAid, and Norge electric dryers with no heat, drying that takes too long, or a dryer that overheats before shutting down. Includes the 8557403 high-limit thermostat (auto-resetting) and 8318314 thermal fuse (one-time). Replaces 280148VP, 1175772, AP3874047, PS991443, EAP991443, 314634. Always inspect and clean the exhaust venting when replacing this set — a blown thermal fuse is a symptom of restricted airflow, and skipping the vent check leads to repeat failures.
What's In The Set
Component
Type
Function
8557403 High-Limit Thermostat
Auto-resetting
Cuts power to the heating element if temperature exceeds safe limits, resets automatically once the dryer cools.
8318314 Thermal Fuse
One-time, non-resettable
Backup safety device — permanently opens the circuit if temperature exceeds safe limits. Must be replaced once blown.
Common Problems This Set Fixes
Dryer runs but produces no heat at all
Dryer won't start at all — no lights, no tumble, no response
Drying takes noticeably longer than it used to
Dryer overheating before shutting down
Dryer that stopped working suddenly after running unusually hot
Repeated thermal fuse failures on a dryer with a known venting issue
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This dryer thermostat set directly replaces the following OEM and cross-reference part numbers:
280148, 1175772, 280148VP, PD00002627, FIX991443, EAP991443, AH991443, AP3874047, AWP39427, EA991443, PS991443, 8318314, WP8557403, 8557403, 1180102, AP6013164, AWP48681, PD00003588, PS11746386
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This thermostat set is compatible with select Whirlpool electric dryers, and also fits select Kenmore, Maytag, Amana, Roper, Estate, Crosley, Admiral, KitchenAid, and Norge dryers built on the Whirlpool platform, including model numbers such as:
7MWED5620HW0, 7MWED5620HW1, 7MWED6613HC0, 7MWED6613HC1, 7MWED6613HW0, 7MWED6613HW1
MED5500FC1, MED5500FC2, MED5500FW1, MED5500FW2
MED5630HC0, MED5630HC1, MED5630HC2, MED5630HW0, MED5630HW1, MED5630HW2
MED6000XG0, MED6000XG1, MED6000XG2, MED6000XR0, MED6000XR1, MED6000XW0, MED6000XW1, MED6000XW2
MED6630HC0, MED6630HC1, MED6630HC2, MED6630HW0, MED6630HW1, MED6630HW2
MED7000XG0, MED7000XG1, MED7000XR0, MED7000XR1, MED7000XW0, MED7000XW1, MED7000XW2
MED7230HC0, MED7230HC1, MED7230HC2, MED7230HC3, MED7230HW0, MED7230HW1, MED7230HW2, MED7230HW3
MED8200FC1, MED8200FC2, MED8200FW1, MED8200FW2
Note: Always verify your full model number before ordering, since Whirlpool uses several different thermostat and fuse designs across its dryer lineup. This set is commonly purchased alongside heating element WP8544771. Contact our support team with your model number if you're unsure.
Key Features
2-piece set: 8557403 auto-resetting high-limit thermostat and 8318314 one-time thermal fuse
Resolves "no heat," "won't start at all," "takes too long to dry," and "overheating" symptoms
Addresses two overheat-protection thresholds in the same circuit at once
Commonly purchased alongside heating element WP8544771
No special tools required for installation
Replaces 280148VP, 1175772, AP3874047, PS991443, EAP991443, and 314634
Compatible with Whirlpool, Kenmore, Maytag, Amana, Roper, Estate, Crosley, Admiral, KitchenAid, and Norge electric dryers
Aftermarket replacement built to OEM-equivalent quality standards
Product Specifications
Set Part Number
280148
OEM Part Number
280148
Set Contents
1x High-Limit Thermostat (8557403), 1x Thermal Fuse (8318314)
Condition
Aftermarket Replacement
Application
Whirlpool Electric Dryers
High-Limit Thermostat Type
Automatically resetting
Thermal Fuse Type
One-time use, non-resettable
Companion Heating Element
WP8544771 (commonly used together)
Repair Difficulty
Easy to Moderate — no special tools required
Compatible Brands
Whirlpool, Kenmore, Maytag, Amana, Roper, Estate, Crosley, Admiral, KitchenAid, Norge
Installation Notes
⚠️ Unplug Dryer Before Starting — Inspect And Clean The Venting Before Reassembling Disconnect power at the outlet or shut off the circuit breaker before beginning. Wear work gloves. Access is typically through the rear panel, near the heating element and blower housing where both components are mounted. Photograph the wiring connections before disconnecting anything, since the thermostat and fuse can be easy to swap positions by mistake. Remove each old component from its mounting position, noting orientation, and disconnect its wiring. Before reassembling, fully inspect and clean the dryer's exhaust vent, from the lint trap housing all the way to the exterior vent hood, checking for lint buildup, crushed sections, or excessive length. Restricted airflow is the leading cause of failure for both of these components, and skipping the vent check often leads to repeat failures even with new parts installed. Install the new 8557403 thermostat and 8318314 thermal fuse from this set in the same positions as the parts they replace, reconnecting wiring exactly as photographed. Reassemble the panel, restore power, and run a full test cycle to confirm normal, consistent heating with no premature shutoffs. Tools needed: Phillips or nut driver (model-dependent), work gloves.
Frequently Asked Questions
Why replace both the thermostat and the fuse together instead of just the one that failed?
These two parts protect the same circuit at different thresholds and tend to fail from the same underlying cause. If the high-limit thermostat isn't regulating temperature correctly, the thermal fuse often ends up blowing as the backup safety measure. Replacing only one risks the other failing again shortly after, so they're sold and serviced together as a set.
I replaced this set and the dryer failed again. What should I check?
This is a strong sign the underlying cause — almost always restricted airflow — was never addressed. Thoroughly inspect and clean the entire exhaust path from the lint trap housing to the outside vent hood, checking for lint buildup, crushed or kinked ductwork, or a vent run that's too long. Failing to correct a venting issue will cause repetitive failures of this set even when it's brand new.
Should I replace the heating element at the same time?
It's worth considering if your dryer's heating element (commonly WP8544771 on compatible models) is original and has been running alongside a failing thermostat, since sustained overheating can stress the element as well. It's not required, but since you'll already have the panel open for this repair, it's a reasonable time to inspect the element for visible damage.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is manufactured to match the temperature thresholds and mounting configuration of the original 280148 high-limit thermostat and thermal fuse set used in compatible Whirlpool, Kenmore, Maytag, Amana, Roper, and related electric dryers.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Quality Aftermarket Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
XPARTCO WR60X10074 Refrigerator Evaporator Fan Motor
The XPARTCO WR60X10074 is an aftermarket replacement evaporator fan motor with thermistor for GE and Hotpoint refrigerators. This motor is located at the back of the freezer and circulates air across the evaporator coils, which convert refrigerant into cooling capacity — the fan is what carries that cooled air into both the freezer and fresh food compartments. Bundled with this motor is a separate thermistor that snaps onto the top portion of the evaporator and sends temperature signals back to the main control board, letting it regulate cooling accurately.
Rated 9.75V DC, 3.25W — the same base motor used in our WR60X10185 listing, but this version ships with the thermistor included. GE's own guidance is direct on this point: the thermistor should be replaced at the same time as the evaporator fan, since the two are serviced together under this part number rather than sold and swapped independently. Common failure causes include worn motor bearings and general electrical wear. Symptoms include unusual noise from the freezer, a refrigerator or freezer section running too warm, or inconsistent temperatures overall. It directly replaces AP3191003, 914169, 197D4492G001, and 197D2039P013.
Quick Answer
The XPARTCO WR60X10074 Refrigerator Evaporator Fan Motor fixes GE and Hotpoint refrigerators with unusual noise from the freezer, a refrigerator or freezer section running too warm, or inconsistent cooling overall. 9.75V DC, 3.25W, includes thermistor. Replaces AP3191003, 914169, 197D4492G001, 197D2039P013. This is the motor-plus-thermistor version — if your old connector has no thermistor wire, you need our WR60X10185 listing instead; this is also a different assembly from our WR60X10318 side-by-side listing, which has the thermistor integrated into the motor's own harness rather than as a separate snap-on piece.
Common Problems This Part Fixes
Unusual noise — humming, buzzing, or grinding — coming from the freezer
Fresh food compartment or freezer running too warm
Inconsistent or fluctuating refrigerator temperatures
Refrigerator running constantly as it struggles to maintain temperature
Fan motor that has gone silent after previously running normally
Fan blade that doesn't spin freely, or doesn't spin at all, when checked by hand
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This refrigerator evaporator fan motor directly replaces the following OEM and cross-reference part numbers:
WR60X10074, 197D4492G001, 914169, AH304658, AP3191003, AGE29122, PD00001062, EA304658, PS304658
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This evaporator fan motor is compatible with select GE and Hotpoint refrigerators, including model numbers such as DSS25PFMCCC.
Note — check your connector before ordering: This motor includes the thermistor. If your old motor's connector has no thermistor wire — a plain 4-wire harness with 2 empty pin slots on a 6-pin connector — you need our WR60X10185 listing instead (no thermistor). If your connector has a dedicated light connector, you need WR23X10467. This part is also a separate assembly from our WR60X10318 listing, a side-by-side platform motor with the thermistor built directly into its own 6-pin harness rather than snapping onto the evaporator as a separate piece. Even between similar GE thermistor-equipped motors, always verify your full model number, since GE support has confirmed these are not automatically interchangeable without checking your specific model. Contact our support team with your model number if you're unsure which motor your refrigerator needs.
Key Features
Aftermarket replacement evaporator fan motor — circulates air across the evaporator coils to cool the freezer and fresh food compartments
Includes a separate thermistor that snaps onto the top of the evaporator and reports temperature to the main control board
Resolves "unusual noise," "running too warm," and "inconsistent cooling" symptoms caused by fan motor or thermistor failure
Rated 9.75V DC, 3.25W
Direct drop-in replacement matching the original mounting and blade fitment
Replaces AP3191003, 914169, 197D4492G001, and 197D2039P013
Compatible with GE and Hotpoint refrigerators
Aftermarket replacement built to OEM-equivalent quality standards
Product Specifications
Part Number
WR60X10074
OEM Part Number
WR60X10074
Part Type
Refrigerator Evaporator Fan Motor with Thermistor
Condition
Aftermarket Replacement
Brand
GE
Location
Back of the freezer, over the evaporator coils
Voltage
9.75V DC
Wattage
3.25 W
Includes Thermistor
Yes — snaps onto the top of the evaporator, sold together
Weight
Approx. 0.6 lb.
Quantity
1 fan motor + 1 thermistor
Compatible Brands
GE, Hotpoint
Installation Notes
⚠️ Unplug Refrigerator Before Starting — Replace The Thermistor Along With The Motor Disconnect power at the outlet before beginning, and move perishable food to a cooler for the duration of the repair. Wear work gloves. Access is through the freezer's rear interior panel: remove shelving and bins as needed, then remove the screws securing the back panel to expose the evaporator coil, fan, and thermistor. If there's significant frost or ice around the fan or coil, let the unit sit unplugged with the door open for a few hours, or run a manual defrost, before continuing. Photograph the wiring harness connector, the fan blade's orientation, and the thermistor's snap-on position before disconnecting anything. Unplug the motor's wiring harness connector, remove the mounting screws or clips holding the motor bracket in place, and pull the motor and fan blade assembly free. Unsnap the old thermistor from the top of the evaporator and disconnect its wiring as well. Install both the new motor and the new thermistor together, even if only one of them tested as failed — GE's own guidance is to replace the thermistor whenever the evaporator fan is replaced, since they're serviced as a pair under this part number. Mount the new motor in the same position, reconnect the wiring harness connector, and snap the new thermistor onto the same spot on the evaporator, reconnecting its wiring. Confirm the fan blade spins freely by hand without contacting the housing before reassembling the back panel. Restore power and monitor both compartments over the next 24 hours to confirm even, consistent cooling has returned. Tools needed: Phillips screwdriver, nut driver, work gloves.
Frequently Asked Questions
Do I really need to replace the thermistor if only the fan motor stopped working?
GE's official guidance is yes — the thermistor should be replaced along with the evaporator fan whenever this part number is used, since they're sold and serviced together as a pair rather than as fully independent components. That said, some technicians have successfully replaced just the fan motor alone in certain situations; if you want to attempt a fan-only swap, test your existing thermistor first and keep in mind this isn't the manufacturer-recommended approach.
How do I know if I need this motor or the WR60X10185 (no thermistor) version?
Look at your old motor's electrical connector before ordering. This WR60X10074 motor comes with a thermistor — if your connector has a thermistor wire running to it, this is the correct part. If your connector is a plain 4-wire harness with no thermistor wire and two empty pin positions on a 6-pin plug, you need our WR60X10185 listing instead, which does not include a thermistor.
My fridge isn't cooling but the fan seems to spin fine. Could it still be this part?
Yes — if the fan is spinning but the fridge still isn't cooling properly, the thermistor half of this assembly is worth suspecting, since a faulty thermistor can send incorrect temperature readings to the control board even while the fan motor itself works fine. One customer confirmed their control board and thermistor initially "checked good" before eventually tracing a similar symptom to fan circulation — so it's worth testing both components rather than assuming the fan alone is the issue.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine GE OEM part, but is manufactured to match the 9.75V, 3.25W motor design, blade fitment, and thermistor function of the original WR60X10074 evaporator fan motor and thermistor used in compatible GE and Hotpoint refrigerators.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Quality Aftermarket Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
WR60X10062 Refrigerator Air Damper Assembly
Replaces Part Numbers:WR60X10062, 914163, AH304650, EA304650, AP3184950, PS304650.
California Residents only
WARNING: Cancer and/or Reproductive Harm - www.p65warnings.ca.gov
3405-001117 Genuine OEM Refrigerator Dispenser Control Switch - Compatible with Samsung
Product Description
Restore your refrigerator’s dispenser functionality with the 3405-001117 Genuine OEM Refrigerator Dispenser Control Switch. This Samsung-manufactured microswitch is designed for select Samsung refrigerators, controlling the activation of the water and ice dispenser mechanism. It ensures reliable dispensing, addressing issues like unresponsive or intermittent water/ice dispensing for a seamless user experience.
Note: Includes (1) dispenser control microswitch. Disconnect power before installation. Verify compatibility with your refrigerator model.
Replaces part numbers: 3405-001117, DA34-00011A, 110634, 3727507, PD00033242, EAP11712663, AP5962465, PS11712663.
Compatibility:
Compatible with select Samsung refrigerator models, including but not limited to:
Samsung: RS2530BBP, RS2530BSH, RS2530BWP, RS2555BB, RS2555SL, RS2555SW, RS2577BB, RS2577SL, RS2577SW, RS2630SH, RS2630WW, RS265LABP, RS265LAWP, RS277ACBP, RS277ACPN, RS277ACWP
Common models: Samsung RS253BABB, RS253BAVQ, RS255BABB, RS255BASB, RS257BARB
Verify your model number or contact our support team for assistance.
Key Features:
✅ Brand and Models Compatibility: Fits select Samsung refrigerators with water and ice dispensers.
🔧 Specifications: Genuine OEM Samsung microswitch, single-pole, double-throw (SPDT), 0.1A, 125/250V.
💪 Reliable Performance: Ensures precise activation of the water and ice dispenser mechanism.
🛠️ Easy Installation: Requires a screwdriver and pliers; typically installed in 15–20 minutes.
🛡️ Effective Fixes: Resolves unresponsive or intermittent water/ice dispensing issues.
Product Specification
Part Number: 3405-001117
Component Type: Refrigerator dispenser control switch
Material: Durable plastic housing with metal contacts
Operating Conditions: 0.1A, 125/250V, suitable for refrigerator dispenser environments
Compliance: UL-listed, Prop 65 warning for California
Installation Notes:
Safety First: Disconnect the refrigerator from the power source before installation.
Shop for high-quality appliance parts with a 30-day return policy. Keep your refrigerator’s dispenser working smoothly today!
Add to cart now for a reliable fix!
Genuine OEM WR60X27396 Refrigerator Air Damper Assembly
The WR60X27396 is a genuine OEM air damper assembly for GE refrigerators, including side-by-side and bottom-mount models. The damper is a motorized flap that opens and closes to direct cold air from the freezer into the fresh food compartment, which is how the refrigerator keeps the fresh food section at the right temperature. When it sticks open or closed, or its motor stops working, the compartments fall out of balance: the fresh food section can run too warm or too cold, frost can build up, and the damper may make noise as it moves.
This is a genuine OEM part from GE Appliances, not an aftermarket equivalent, so the fit and operation match the original. It supersedes the earlier WR31X20918 damper assembly.
Quick Answer
The Genuine OEM WR60X27396 Air Damper Assembly fixes a GE refrigerator whose fresh food section is too warm or too cold, or has uneven temperatures, frost buildup, or damper noise because the damper is stuck or has failed. Genuine OEM from GE Appliances. Classic symptom: the freezer is cold but the fresh food section is warm, or the fresh food section freezes items, even with normal settings.
Common Problems This Part Fixes
Fresh food section too warm while the freezer stays cold
Fresh food section too cold, freezing food
Damper stuck open or closed, causing a temperature imbalance
Unusual clicking or buzzing noises when the damper moves
Frost or ice buildup that interferes with the damper
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This air damper assembly replaces the following part numbers:
WR60X27396, 4590355, WR09X10065, WR31X20918, WR9X10065, AGE29713, AP6280910, EAP12172988, PD00047584, PS12172988.
WR60X27396 is GE's current number for this damper, superseding WR31X20918. If your old damper or parts diagram shows WR31X20918, this is the matching replacement.
Compatibility
This damper assembly is listed for GE refrigerators, including:
Side-by-side models such as ZISS360DNKSS, ZIS420NNEII, and ZISS480DPESS
Bottom-mount models such as CFE26KP2NLS1, CDB36LP2RBS1, GDE21EGKARWW, and ZIC360NHDLH
Note: The model list above is only a sample, since one retailer lists over 150 compatible models. Confirm fit by matching the number on your old damper or your parts diagram against the Replaces list, or contact our support team with your model number and we'll verify before you order.
Key Features
Genuine OEM GE damper assembly, not an aftermarket equivalent
Motorized damper that regulates cold airflow from the freezer into the fresh food section
Restores even temperatures between compartments
Authorized by GE for refrigerators using flammable refrigerant such as R600a
Supersedes the earlier WR31X20918
Product Specifications
Part Number
WR60X27396
OEM Part Number
WR60X27396
Part Type
Refrigerator Air Damper Assembly (Motorized)
Condition
Genuine OEM
Manufacturer
GE Appliances
Supersedes
WR31X20918
Application
Select GE Refrigerators
Installation Notes
⚠️ Unplug Power Before Installing Unplug the refrigerator before starting, and move perishable food to a cooler or another refrigerator so it stays safe during the repair. Following your model's service guide, remove the panels or covers needed to reach the damper, which sits in the air path between the freezer and the fresh food section. Note the position of the old damper, disconnect its wiring connector, and remove the fasteners holding it in place. Install the new damper in the same position, reconnect the connector, and replace the panels. Restore power and allow time for the temperatures to stabilize before judging the repair.
Frequently Asked Questions
My freezer is cold but the fresh food section is warm. Is this the part I need?
It can be. If the damper is stuck closed, not enough cold air reaches the fresh food section. Before replacing it, check that the vents aren't blocked by food and that frost isn't jamming the damper. A stuck or failed damper is a likely cause when those are clear.
My fresh food section is freezing my food. Could this be the damper?
Yes. A damper stuck open lets too much cold air in from the freezer, which can freeze items in the fresh food section.
My old damper is marked WR31X20918. Will this work?
Yes. WR31X20918 is on the Replaces list, and WR60X27396 is its current replacement. If you're unsure, contact our support team with your model number and we'll confirm.
Is this a genuine GE part?
Yes. This is a genuine OEM part from GE Appliances, not an aftermarket equivalent.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Genuine OEM Parts ✓ Compatibility Support ✓ Secure Checkout
XPARTCO 2188820 Refrigerator Thermistor (Sensor) Replaces WP2188820
The XPARTCO 2188820 is an aftermarket replacement refrigerator temperature sensor (thermistor) compatible with select Whirlpool, Kenmore, KitchenAid, Maytag, Jenn-Air, Dacor, and Thermador refrigerators. The thermistor is an NTC (negative temperature coefficient) sensor that continuously monitors the air temperature inside the refrigerator or freezer compartment and sends resistance-based readings to the electronic control board. The control board uses these readings to regulate compressor run time and fan operation, maintaining the set temperature accurately and efficiently.
This thermistor features an NTC resistance of 50K ohms at 25°C (27K ohms at 0°C/32°F) and a standard wire length of approximately 5.3 inches (13.46 cm), compatible with low-voltage refrigerator control boards (5V/12V). It directly replaces WP2188820, 2213442, AP6006068, PS11739132, and 1057764. Note: this thermistor is compatible with non-WISE system refrigerators only — it is not compatible with newer Whirlpool refrigerators using the WISE (Whirlpool Intelligent Smart Energy) control system. Installs in under 15 minutes.
Quick Answer
The XPARTCO 2188820 Refrigerator Thermistor fixes Whirlpool-family refrigerators that are too warm, too cold, have erratic temperatures, run the compressor too long, or display temperature-related error codes. NTC sensor, 50K ohm at 25°C, ~5.3" wire. Non-WISE system models only. Compatible with Whirlpool, Kenmore, KitchenAid, Maytag, Jenn-Air, Dacor, and Thermador. Replaces WP2188820, 2213442, AP6006068, PS11739132.
Common Problems This Part Fixes
Refrigerator not maintaining set temperature — too warm or too cold
Freezer section too warm or food not freezing properly
Compressor running continuously without cycling off
Temperature fluctuating erratically despite stable ambient conditions
Refrigerator temperature-related error codes displayed on the control panel
Excessive frost buildup caused by incorrect temperature regulation
Food or beverages freezing in the fresh food section
Replaces Part Numbers
This refrigerator thermistor directly replaces the following OEM and cross-reference part numbers:
WP2188820, 2188820, 2213442, EAP11739132, AWP46934, PD00033406, AP6006068, PS11739132.
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This thermistor is compatible with select refrigerators from the following brands and series:
Whirlpool refrigerators — 5VW, GC3, EC3, GC5 series
Kenmore / Sears refrigerators — 106 series (Whirlpool-built models)
KitchenAid refrigerators — KSCS, KSSS, JS series
Maytag refrigerators (select models)
Jenn-Air refrigerators (select models)
Dacor refrigerators (select models)
Thermador refrigerators (select models)
Important — WISE System Compatibility: The 2188820 thermistor is compatible with non-WISE system refrigerators only. It is not compatible with newer Whirlpool refrigerators equipped with the WISE (Whirlpool Intelligent Smart Energy) control system. If your refrigerator uses the WISE system, this thermistor will not work correctly. Verify your model number before ordering, or contact our support team to confirm compatibility.
Key Features
NTC (negative temperature coefficient) thermistor — resistance decreases as temperature increases, allowing precise temperature monitoring
50K ohm resistance at 25°C (27K ohm at 0°C/32°F) — matches original WP2188820 specifications
Wire length approximately 5.3 inches (13.46 cm) — standard length matching OEM dimensions
Low-voltage design compatible with 5V/12V refrigerator control boards
Continuously sends temperature readings to the control board to regulate compressor and fan operation
Non-WISE system compatible only — verify your model before ordering
Direct replacement for WP2188820, 2213442, AP6006068, and PS11739132
Compatible with Whirlpool, Kenmore, KitchenAid, Maytag, Jenn-Air, Dacor, and Thermador refrigerators
Aftermarket replacement built to OEM-equivalent quality standards
Quick DIY repair — installs in under 15 minutes
Product Specifications
Part Number
2188820
OEM Part Number
WP2188820
Part Type
Refrigerator Temperature Sensor (NTC Thermistor)
Condition
Aftermarket Replacement
Sensor Type
NTC (Negative Temperature Coefficient)
Resistance at 25°C
50,000 ohms (50K ohm)
Resistance at 0°C (32°F)
27,000 ohms (27K ohm)
Wire Length
Approximately 5.3 inches (13.46 cm)
Voltage
5V / 12V (low voltage)
WISE System Compatibility
Non-WISE models only
Compatible Brands
Whirlpool, Kenmore, KitchenAid, Maytag, Jenn-Air, Dacor, Thermador
Installation Notes
⚠️ Unplug Refrigerator Before Starting Disconnect power before beginning. The thermistor location varies by model — it is typically clipped to a bracket on the interior side wall of the fresh food or freezer compartment, or mounted near the evaporator coil. Consult your model's parts diagram or service manual to confirm the exact location before disassembly. Open the sensor cover or unclip the sensor bracket, disconnect the wiring connector, and pull the old thermistor out. Insert the new 2188820 thermistor, reconnect the wiring connector, and snap the cover or bracket back into place. Ensure the sensor head is positioned close to the compartment wall and the wiring is not pinched. Restore power and monitor the refrigerator temperature over the next few hours to confirm stable, accurate cooling. Tools needed: Phillips screwdriver (for panel access on some models); no tools needed for sensor replacement itself.
Frequently Asked Questions
What is the difference between 2188820 and WP2188820?
These are the same thermistor. WP2188820 is the updated Whirlpool OEM part number that superseded the original 2188820. The 2213442 is also a cross-reference for the same part. This aftermarket replacement is compatible with all three numbers.
What does an NTC thermistor do and how do I know if mine has failed?
An NTC thermistor is a resistor whose resistance decreases as temperature increases. The control board sends a small voltage through the thermistor and measures the resulting resistance — a lower resistance means warmer temperature, and a higher resistance means cooler temperature. The board uses this reading to decide when to run the compressor and fans. A failed thermistor either reads open circuit (no continuity), short circuit (zero resistance), or provides incorrect readings that cause the refrigerator to run too warm, too cold, or cycle erratically. Test with a multimeter at room temperature — a working 2188820 should read approximately 50K ohms at 25°C (77°F). Significant deviation indicates failure.
How do I know if my refrigerator uses the WISE system?
The WISE (Whirlpool Intelligent Smart Energy) system was introduced on newer Whirlpool refrigerator models and uses a different thermistor specification that is not interchangeable with the 2188820. Models that use the WISE system are typically marked in the product documentation or on the control board. The easiest way to confirm compatibility is to verify your model number with our support team before ordering, or check whether WP2188820 appears in your model's official parts diagram. If your parts diagram lists WP2188820, this replacement is compatible.
Where is the thermistor located in my refrigerator?
The thermistor location varies by model and brand. On Whirlpool and KitchenAid models, it is commonly found on the interior side wall of the fresh food compartment clipped to a plastic housing. On some models it is located near the evaporator coil behind the freezer back panel. On Kenmore 106 series models, it may be on the fresh food section wall or inside the back panel. Consult your specific model's parts diagram or search for a model-specific installation video to locate the sensor before disassembling the refrigerator.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is manufactured with an NTC thermistor rated to the same 50K ohm specification as the original WP2188820 to match the performance and accuracy of the factory sensor.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout
XPARTCO DA32-10105X Refrigerator Temperature Sensor – Compatible with Samsung and Kenmore Refrigerators
Product Description
Maintain consistent cooling performance with the XPARTCO DA32-10105X Refrigerator Temperature Sensor. This high-quality replacement monitors internal refrigerator temperature and communicates with the control board to regulate cooling cycles. A faulty sensor can cause temperature fluctuations, frost buildup, or over-cooling. Installing this reliable XPARTCO sensor helps restore accurate temperature readings and energy-efficient operation.
Replaces Part Numbers
DA32-10105X, 2030345, PD00002045, EAP4138686, AP4338786, PS4138686
Compatibility
This replacement temperature sensor fits select Samsung and Kenmore refrigerators.
Example compatible models include (but are not limited to): Samsung RF28HMEDBSR/AA, RF23HCEDBSR/AA, and Kenmore 795.72053.112.
Always verify your refrigerator’s model number before ordering. Contact our support team if you’re unsure.
✅ Key Features
🔄 Aftermarket Replacement – Designed to match OEM accuracy and reliability
❄️ Precision Cooling Control – Ensures stable refrigerator and freezer temperatures
💰 Budget-Friendly Fix – Provides OEM-level performance at a lower cost
🛠️ Easy Installation – Plug-in design for fast and simple replacement
🛡️ Fixes Common Issues – Solves cooling inconsistencies, frost buildup, or warm compartment problems
📐 Product Specification
Part Number: DA32-10105X
Component Type: Refrigerator Thermistor (Temperature Sensor)
Material: Plastic sensor probe with insulated wiring harness
Mounting: Clip-in or taped to evaporator wall depending on model
Compliance: Built to OEM-equivalent quality standards (not OEM)
🛠️ Installation Notes
Tools Needed: Phillips screwdriver, needle-nose pliers
⚠️ Safety First: Always unplug the refrigerator before performing any repairs to prevent electrical shock.
Steps:
Disconnect power and remove interior shelves for access.
Locate the existing temperature sensor near the evaporator coil or rear wall.
Unplug the old sensor from its wiring harness.
Install the new XPARTCO DA32-10105X sensor and reconnect the harness.
Secure the sensor in place with clips or adhesive as applicable.
Reassemble interior panels and restore power.
⏱️ Time Required: 15–20 minutes
📦 Shop With Confidence
🚚 Free Shipping on All Orders
⚙️ Trusted Appliance Parts Supplier
🔄 30-Day Return Policy
Keep your refrigerator running efficiently — Add to Cart Now for a reliable, cost-effective repair!
XPARTCO HS810 Refrigerator 3-in-1 Hard Start Kit 1/12 to 1/5 HP 120V
The XPARTCO XPHS810 is a universal 3-in-1 hard start kit that combines a solid-state starting relay, a start capacitor, and thermal overload protection into a single prewired unit for refrigerator and freezer compressors rated 1/12 to 1/5 HP at 120V (110–125VAC). It's designed as a direct equivalent to the widely used Supco RCO810 and similar kits, giving a struggling compressor extra starting torque to overcome internal friction and gas pressure at startup — commonly used to fix the classic "click-buzz-click" no-start symptom without replacing the entire compressor.
The kit is fully prewired with color-coded leads (typically black = Common, white = Start, red = Run) and mounts directly onto the compressor's terminal pins, with instructions printed on the unit itself. It directly replaces Supco RCO810, URCO810, URC0810, RC0810, RC100, TJ90RCO810, AP4503019, ERP810, ERPU810, HS8, HS810, HS81, PCS810, and Mars 32781. Installs in 15–30 minutes with basic hand tools.
Quick Answer
The XPARTCO HS810 3-in-1 Hard Start Kit fixes refrigerators and freezers whose compressor makes a repeated "click-buzz-click" sound and fails to start, or that shut off on thermal overload during startup. Combines relay, start capacitor, and overload protector in one prewired unit for 1/12 to 1/5 HP compressors, 120V, 3.5A RLA. Replaces Supco RCO810, URCO810, RC0810, RC100, TJ90RCO810, AP4503019, ERP810, HS8, HS810, HS81, PCS810, Mars 32781. Do not install on LG linear/inverter compressors — see Installation Notes.
Common Problems This Part Fixes
Compressor makes a repeated "click-buzz-click" noise and fails to start
Refrigerator or freezer runs warm because the compressor won't stay running
Compressor hums but doesn't start, then trips off on overload
Refrigerator cycles on and off rapidly without reaching temperature
Older or worn compressor that starts hard, especially after a power outage
⚠ Capacitor Hazard — Read Before Servicing This kit contains a start capacitor, which can store a dangerous electrical charge even after the refrigerator is unplugged. Always disconnect power before servicing, and discharge the capacitor safely (using an insulated-handle resistor tool or by briefly shorting the terminals with an insulated screwdriver) before handling it. Never touch capacitor terminals with bare hands. If you are not comfortable working around stored electrical charge, have this repair performed by a qualified technician.
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This 3-in-1 hard start kit directly replaces the following OEM and cross-reference part numbers:
XPHS810, RCO810, URCO810, URC0810, RC0810, RC100, TJ90RCO810, AP4503019, ERP810, ERPU810, HS8, HS810, HS81, PCS810, Mars 32781
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This universal hard start kit is compatible with refrigerator and freezer compressors in the following range:
Compressors rated 1/12 HP through 1/5 HP
120V (110–125VAC) single-phase compressors
Standard PSC (permanent split capacitor) and RSIR compressor types across Whirlpool, GE, Frigidaire, LG, Samsung, and most other major brands
Important: Do NOT install this kit on LG linear/inverter compressors, or any compressor using a variable-speed inverter board (often labeled "Inverter," "Linear," "BLDC," or "Digital"). Connecting a standard hard start kit to an inverter-driven compressor can destroy the inverter control board. Check your compressor's label before ordering, or contact our support team with your model number if you're unsure.
Key Features
3-in-1 design combines starting relay, start capacitor, and thermal overload protector in one prewired unit
Delivers additional starting torque to help a struggling compressor overcome startup friction and gas pressure
Resolves "click-buzz-click," "won't start," and "trips on overload" symptoms on eligible compressors
Rated for 1/12 to 1/5 HP compressors at 120V, 3.5A RLA
Prewired, color-coded leads with instructions printed on the unit for straightforward installation
Can operate with or without an existing run capacitor
Replaces Supco RCO810, URCO810, RC0810, RC100, TJ90RCO810, AP4503019, ERP810, HS8, HS810, HS81, PCS810, and Mars 32781
Aftermarket replacement built to OEM-equivalent quality and safety standards
Product Specifications
Part Number
XPHS810
Equivalent To
Supco RCO810 / RC0810
Part Type
3-in-1 Refrigerator/Freezer Hard Start Kit (Relay, Capacitor, Overload)
Condition
Aftermarket Replacement
HP Range
1/12 to 1/5 HP
Voltage
120V (110–125VAC)
Current Rating
3.5A RLA
Terminal / Wire Color Code
Black = Common (C), White = Start (S), Red = Run (R) — typical; confirm against included diagram
Not Compatible With
LG linear/inverter compressors
Installation Notes
⚠️ Unplug Refrigerator Before Starting — Discharge Capacitor Safely Disconnect power before beginning. Before touching any wiring, check your compressor's data label to confirm it is NOT a linear/inverter/BLDC compressor — this kit is not compatible with those and can damage the inverter board if connected. Access the compressor compartment, typically at the rear or bottom of the unit. Remove the existing relay/overload assembly by gently pulling it straight off the compressor terminal pins — do not force or twist. Use a multimeter to confirm which pins are Common (C), Start (S), and Run (R) if not already labeled. Connect the hard start kit's wires to the matching pins. Wire the kit's main power leads into the refrigerator's supply wiring using wire nuts, following the included diagram. Secure the kit with zip ties or its mounting strap to prevent vibration damage during compressor operation. Restore power and confirm the compressor starts smoothly without repeated clicking. Tools needed: nut driver or screwdriver, digital multimeter, wire nuts, insulated screwdriver (for capacitor discharge).
Frequently Asked Questions
My compressor makes a clicking or buzzing sound and won't start — will this fix it?
A hard start kit resolves this in many cases, especially on older or worn compressors that struggle to overcome internal gas pressure at startup. However, "click-buzz-click" can also indicate a failing compressor winding or a compressor nearing end of life. If the hard start kit doesn't resolve the issue, the compressor itself may need replacement — a hard start kit can extend a marginal compressor's life but can't revive one with failed internal windings.
Can I use this on any refrigerator?
This kit works on standard PSC and RSIR compressors within the 1/12 to 1/5 HP range at 120V. It is NOT compatible with LG linear/inverter compressors or any variable-speed inverter-driven compressor — connecting it to one of those can destroy the inverter control board. Check your compressor's label for "Inverter," "Linear," "BLDC," or "Digital" before ordering.
Do I need to remove my existing start capacitor or relay first?
Yes — remove the old relay/overload assembly from the compressor terminal pins before installing this kit. The XPHS810 is designed to work with or without an existing separate run capacitor remaining in the circuit, but the old start relay and any old start capacitor should be removed and replaced by this kit, not left in place alongside it.
Is this safe to install myself?
Many DIYers install hard start kits successfully, but this repair involves a capacitor that can hold a dangerous electrical charge even after the unit is unplugged, plus correctly identifying compressor terminals. If you're not comfortable working around stored electrical charge or don't have a multimeter to confirm terminal identification, we'd recommend having a qualified technician perform this repair.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout
DE47-20034A Microwave Genuine High Limit Thermostat
Thermal cutout.
High limit thermostat. Open for continuity at room temperature, closes when it gets hot.
Fits Samsung over counter microwaves.
Replaces Part Numbers:DE47-20034A, AP4219754, PS4226431.
California Residents only
WARNING: Cancer and/or Reproductive Harm - www.p65warnings.ca.gov
XPARTCO W10613606 Refrigerator Compressor Start Relay and Capacitor
The XPARTCO W10613606 is an aftermarket replacement compressor start relay and capacitor assembly compatible with a wide range of Whirlpool, Kenmore, Maytag, KitchenAid, Amana, Jenn-Air, Admiral, Crosley, Dacor, Hardwick, Inglis, Litton, and Magic Chef refrigerators. The start relay is a small but critical electrical component that plugs directly onto the compressor terminals and provides the initial power surge needed to start the compressor motor. Once the compressor reaches operating speed, the relay drops out — leaving the compressor to run on its own. The capacitor (rated 15µF ±5%, 250VAC) works alongside the relay to store and release the burst of electrical energy needed on startup.
When the start relay fails, the compressor cannot start — causing the refrigerator to stop cooling entirely. A failed relay typically produces a clicking sound every few minutes as the compressor tries and fails to start, followed by a short rest, then another attempt. This kit includes both the start relay and the CBB61 capacitor. It directly replaces W10416065, 8208290, 8208368, C8931605, 67003186, 67005560, 67005561, 67005562, 67003764, 8171210, and several additional cross-reference numbers. Installs in under 15 minutes — no tools required in most cases.
Quick Answer
The XPARTCO W10613606 Refrigerator Compressor Start Relay and Capacitor fixes refrigerators that are not cooling, are too warm, or are making a repeated clicking sound every few minutes as the compressor tries to start. Plugs directly onto the compressor terminals. Kit includes start relay and 15µF 250VAC CBB61 capacitor. Compatible with Whirlpool, Kenmore, Maytag, KitchenAid, Amana, and more. Replaces W10416065, 8208290, C8931605, 67005560, and more. No tools required — installs in under 15 minutes.
Common Problems This Part Fixes
Refrigerator not cooling — compressor not running
Freezer section too warm or not freezing
Both refrigerator and freezer compartments gradually warming up
Repeated clicking sound every 2–5 minutes from behind or underneath the refrigerator
Compressor hums briefly then shuts off without reaching operating temperature
Refrigerator runs but cannot maintain set temperature
Shaking the start relay reveals a rattling sound inside — confirms internal failure
Replaces Part Numbers
This start relay and capacitor kit directly replaces the following OEM and cross-reference part numbers:
W10613606, 67005560, 3023300, 67003186, 67003764, 67005561, 67005562, W10416065, 8171210, 8208290, 8208368, W10244032, 302TFBYY, SSP14R302TFR, AWP41206, C8931605, PD00004905, EAP8746522, AP5787784, PS8746522.
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This start relay and capacitor is compatible with select refrigerators from the following brands:
Whirlpool refrigerators (side-by-side, French door, bottom-freezer)
Kenmore / Sears refrigerators (select Whirlpool-built models)
Maytag refrigerators
KitchenAid refrigerators
Amana refrigerators
Jenn-Air refrigerators
Admiral refrigerators
Crosley refrigerators
Dacor refrigerators
Hardwick refrigerators
Inglis refrigerators
Litton refrigerators
Magic Chef refrigerators
Important: Always verify your refrigerator's model number and compare the old relay's shape and terminal configuration to the new part before installing. Some models may require trimming the wire connector tabs for a proper fit. Contact our support team with your model number if you need confirmation before ordering.
Key Features
Provides the initial electrical surge needed to start the compressor motor — without it, the compressor cannot run and the refrigerator cannot cool
Kit includes both the start relay and the CBB61 run capacitor (15µF ±5%, 250VAC) — everything needed in one package
Plugs directly onto the compressor terminals — no wiring or soldering required in most cases
Quick rattle test — shake the old relay; if it rattles, the internal contacts have failed and it needs replacement
Replaces W10416065, 8208290, C8931605, and over a dozen additional cross-reference part numbers
Compatible with 13 major appliance brands on the Whirlpool platform
Aftermarket replacement built to OEM-equivalent quality standards
Fast DIY repair — installs in under 15 minutes, no tools required in most cases
Product Specifications
Part Number
W10613606
Part Type
Refrigerator Compressor Start Relay and Capacitor Kit
Condition
Aftermarket Replacement
Application
Refrigerator Compressor (side-by-side, French door, bottom-freezer)
Capacitor Type
CBB61 Run Capacitor
Capacitor Rating
15µF ±5%, 250VAC
Kit Includes
1x Start relay, 1x CBB61 capacitor
Installation
Plug-in — no tools required in most cases
Compatible Brands
Whirlpool, Kenmore, Maytag, KitchenAid, Amana, Jenn-Air, Admiral, Crosley, Dacor, Hardwick, Inglis, Litton, Magic Chef
Installation Notes
⚠️ Unplug Refrigerator Before Starting Unplug the refrigerator from the power outlet before beginning. Move the refrigerator away from the wall to access the rear or lower back panel. Remove the rear access panel by unscrewing the retaining screws to expose the compressor. The compressor is a large black dome-shaped component — the start relay and capacitor assembly plugs onto the side terminals. Grip the old relay firmly and pull it straight off the compressor pins. Shake it — if it rattles, the internal contacts have failed and replacement is confirmed. Compare the old relay to the new W10613606 to confirm the terminal layout matches. Align the new relay with the compressor pins and press it firmly on. Reinstall the access panel, restore power, and listen for the compressor to start and run normally within a few minutes. Note: Some models may require trimming the wire connector tabs or reversing the connector orientation for a proper fit — do not force the connection. Tools needed: Phillips screwdriver (for panel access only).
Frequently Asked Questions
What does the compressor start relay do?
The start relay plugs onto the compressor terminals and provides the brief but powerful surge of electrical current needed to start the compressor motor from a standstill. Once the compressor reaches operating speed — usually within a second or two — the relay drops out and the compressor runs on its own. Without a working start relay, the compressor cannot start at all, and the refrigerator stops cooling. The capacitor works alongside the relay to store and deliver the extra energy needed on startup.
How do I know if my start relay has failed?
The most reliable quick test is the rattle test: unplug the refrigerator, pull the start relay off the compressor, and shake it near your ear. A working relay is silent. A failed relay will rattle — the internal contacts have broken free and are loose inside the casing. Another sign is a repeated clicking sound every 2–5 minutes from the back of the refrigerator, where the compressor attempts to start, fails, trips the overload protector, rests, and tries again. If the fridge is warm and you hear clicking, check the relay first.
What is the difference between the start relay and the capacitor?
The start relay is the switching device that connects and disconnects the start winding of the compressor motor during startup. The capacitor stores a charge and releases it during startup to give the motor the additional torque it needs to get moving under load. Together they work as a startup system for the compressor. This kit includes both — replacing both at the same time ensures the complete startup circuit is fresh and reliable.
My fridge is still not cooling after replacing the start relay — what else could it be?
If replacing the start relay does not restore cooling, other possible causes include a failed compressor (the compressor runs but no longer builds pressure), a refrigerant leak in the sealed system, a failed start capacitor (if not replaced along with the relay), a bad overload protector, or a faulty main control board. Listen carefully after installing the new relay — if the compressor now starts and runs but the fridge still doesn't cool after several hours, a sealed system issue or refrigerant problem is likely and will require a certified technician.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is manufactured to match the electrical specifications and terminal configuration of the original W10613606 start relay and capacitor assembly.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout
