LCR5X440 HVAC OVAL MOTOR RUN CAPACITOR Engineered by an ISO manufacturer with over twenty years' experience in OEM capacitor fabrication, Linebacker® capacitors are manufactured by the OEM factory and are 100% in-line production tested to the same rigorous standards. Features/Benefits 10,000 AFC pressure sensitive short circuit interrupting capability 3-year warranty from the date of purchase Continuous life tested, oil leak tested and dielectric tested for insulation effectiveness Life tested to 85° C operating temperature for 10,000 cycles Manufactured with thick polypropylene foil to handle increased operating temperatures Meets EIA-456A accelerated life test at 70° C for 60,000 hours PCB-free oil to prevent over-heating UL File # E352486 US and Canada UL approved (C22.2NO.190) Applications       Air conditioning compressors     Refrigeration Compressors     Furnace blower motors     Condenser fan motors Specification: Voltage: Up to 440 VAC Operating Temperature: -40°F to 185°F (-40°C to 85°C) Foil Thickness: 6.0 µm +/- 5% Standard Tolerance: +/- 5% MFD Value: 5 Style: Oval Size: 2.03x1.24x1.57

Read more less

CON-5-370-R HVAC ROUND MOTOR RUN CAPACITOR Appli Parts Run Capacitor for ac 5 Mfd uF (microfarads) 370 VAC Appli Parts Run Capacitor for ac 5 Mfd uF (microfarads) 370 VAC Round Universal fit for hvac and other applications 2-1/2 in High 1-1/2 in Wide CON-5-370Universal: Replaces any brand with the same capacitance capacity and voltage. Will work for 370V . 1/4 in Male Quick-connectSpecs: Tolerance is +/- 5 % of Capacity, Working temperature environment from -40F (-40C) to +185F (85C). Dimensions 2-5/8 in H, 1-1/2 in WProtection: Protected for 10,000AFC which means this product will not burst if by any reason is short circuitsReplaces: TRCF5 PRCF5A CAP-5-370Confirm that the dimensions and other attributes of the product closely match those of the original item being replaced

Read more less

XPARTCO EAU63923603 Refrigerator Evaporator Fan Motor The XPARTCO EAU63923603 is an aftermarket replacement evaporator fan motor assembly compatible with a wide range of LG and Kenmore LG-built French door, side-by-side, and bottom-freezer refrigerators — including the LFCC, LFCS, LFXC, LFXS, LMXC, LMXS, LRDCS, LRFCS, LRFDS, LRFWS, LRFXS, LRMVS, LRMXC, and LRMXS series. The evaporator fan motor draws air across the cold evaporator coils and circulates it through the fresh food compartment. This constant airflow is what keeps the refrigerator section at temperature. When the fan motor fails, the most telling symptom is that the refrigerator section runs warm while the freezer stays cold — because the coils are still producing cold, but nothing is moving that air up into the fridge. Electrical specs: DC 12V, 1.0A, with a 4-pin connector. Motor body: 75 x 55 x 25 mm. Shaft: 46 mm (1.81") long, 3.0 mm diameter. Lead length: 70 cm (27.5"). Housing made from durable ABS plastic with quality metal internal components. It directly replaces EAU63923603, EAU65058305, EAU63923606, AP6317197, PS12383671, EAP12383671, and PD00045140. Note: this is an upgraded replacement design — the motor body may look slightly larger than your original, but the mounting holes and connector locations are identical, so fit and compatibility are unchanged. Installs in 30–45 minutes with basic hand tools. Quick Answer The XPARTCO EAU63923603 Refrigerator Evaporator Fan Motor fixes LG and Kenmore LG-built refrigerators where the fridge section is warm but the freezer is cold, cooling is insufficient, the freezer has excessive frost, the fan is noisy, or the fan doesn't spin at all. DC 12V, 1.0A, 4-pin connector. Body 75x55x25mm · Shaft 46mm L x 3.0mm dia · 70cm (27.5") lead. ABS housing. Replaces EAU65058305, EAU63923606, AP6317197, PS12383671, EAP12383671, PD00045140. Compatible with LG LFCC/LFCS/LFXC/LFXS/LMXC/LMXS/LRDCS/LRFCS/LRFDS/LRFWS/LRFXS/LRMVS/LRMXC/LRMXS series. Upgraded design — may look slightly larger, but mounting holes and connector are identical. Common Problems This Part Fixes Refrigerator (fresh food) compartment warm while the freezer stays cold — the signature symptom of evaporator fan motor failure Insufficient cooling throughout the refrigerator Uneven or inconsistent temperatures between compartments Excessive frost buildup in the freezer or on the evaporator coils Unusual or loud noises coming from the fan area — failing motor bearings or a blade rubbing on frost Fan motor doesn't run or the fan blade doesn't spin at all Visible damage or obstruction to the motor or fan blades Refrigerator running continuously to compensate for poor air circulation Food spoiling faster than normal in the fresh food compartment Cross Reference Information Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item. Replaces Part Numbers This evaporator fan motor directly replaces the following OEM and cross-reference part numbers: EAU63923603, EAU63923606, EAU65058305, AP7178305, ALG53955, AP6317197, PD00045140, PS12383671. If your part number is not listed above, contact our support team before ordering and we will verify compatibility. LG uses several different evaporator fan motors across its refrigerator lineup — verify your original motor's part number and connector before ordering. Compatibility This evaporator fan motor is compatible with select LG and Kenmore refrigerators, including: LG French door refrigerators — LFCC22426S (/00, /01), LFCC23596S (/01), LFCS27596S (/00, /01), LFCS28768S (/00) series LG French door refrigerators — LFXC22526D (/00, /02, /04, /10), LFXC22526S (/00, /01), LFXC22596D (/00), LFXC22596S (/00, /01) series LG French door refrigerators — LFXS26596D (/01), LFXS26596M (/00), LFXS26596S (/00, /01), LFXS26973D (/00), LFXS28566D, LFXS28566S, LFXS28596D, LFXS28596M, LFXS28596S, LFXS28968D, LFXS28968S series LG French door refrigerators — LMXC22626D, LMXC22626S, LMXS28596M, LMXS28596S, LMXS28626S, LMXS28636S series LG refrigerators — LRDCS2603S, LRFCS2503S, LRFDS2503S, LRFWS2906D, LRFWS2906S, LRFXS2503S, LRFXS2503D series LG refrigerators — LRMVS2806D, LRMVS2806S, LRMXC2206D, LRMXC2206S, LRMXS2806S series Kenmore / Sears refrigerators — select LG-built models (including 795-series such as 79574109810) Note: This is an upgraded replacement design — the motor body may appear slightly larger than your original, but the mounting holes and connector locations are identical, so fit and compatibility are unchanged. LG uses several different evaporator fan motors across its lineup with different voltages and connectors — verify your original motor's part number and 4-pin connector before ordering. Contact our support team with your model number if you're unsure. Key Features Evaporator fan motor assembly — circulates air across the evaporator coils and through the fresh food compartment for efficient, even cooling Resolves the classic "fridge warm, freezer cold" symptom of evaporator fan failure Also fixes insufficient cooling, excessive frost, unusual fan noise, and a fan that won't spin Electrical specs: DC 12V, 1.0A with a 4-pin connector Motor body: 75 x 55 x 25 mm · Shaft: 46 mm (1.81") long x 3.0 mm diameter · Lead length: 70 cm (27.5") Durable ABS plastic housing with quality metal internal components for long service life Upgraded design — body may be slightly larger than the original, but mounting holes and connector locations are identical Cost-effective repair — restores cooling performance instead of replacing the whole refrigerator Replaces EAU65058305, EAU63923606, AP6317197, PS12383671, EAP12383671, and PD00045140 Compatible with LG LFCC, LFCS, LFXC, LFXS, LMXC, LMXS, LRDCS, LRFCS, LRFDS, LRFWS, LRFXS, LRMVS, LRMXC, LRMXS series and Kenmore LG-built refrigerators Aftermarket replacement built to OEM-equivalent quality standards DIY repair — installs in 30–45 minutes with basic hand tools Product Specifications Part Number EAU63923603 Part Type Refrigerator Evaporator Fan Motor Assembly Condition Aftermarket Replacement Application French Door, Side-by-Side & Bottom-Freezer Refrigerators (LG platform) Voltage DC 12V Current 1.0A Connector 4-pin Motor Body Dimensions 75 x 55 x 25 mm Shaft Length 46 mm (1.81") Shaft Diameter 3.0 mm Lead Length 70 cm (27.5") Housing Material ABS plastic Design Note Upgraded — body may be slightly larger; mounting holes and connector identical Compatible Brands LG, Kenmore (LG-built) Installation Notes ⚠️ Unplug Refrigerator and Move Perishable Food Before Starting — Wear Work Gloves Unplug the refrigerator and safely store any food that could spoil while the power is off. Wear work gloves to protect your hands. The evaporator fan motor is located behind the rear evaporator access panel. Remove the shelves, drawers, and any items blocking access to the back wall of the compartment. If there's frost or ice buildup on the panel or coils, allow it to thaw completely before continuing — never chip or pry ice off the evaporator coils, as the aluminum fins damage easily and a damaged coil is a far more expensive repair. Remove the screws securing the rear access panel and lift it away to expose the evaporator coils and fan motor. Photograph the wiring connection, fan blade position, and motor orientation before disconnecting anything. Disconnect the 4-pin wiring connector by gently pulling the plug. Remove the fan blade from the motor shaft (note its orientation — it must go back the same way), then remove the mounting screws holding the motor in place and lift out the old motor. Install the new EAU63923603 motor in the same position and orientation — the mounting holes and connector location match the original even though the body may look slightly larger. Secure the mounting hardware, reinstall the fan blade on the 3.0 mm shaft, and reconnect the 4-pin wiring connector until it seats firmly. Confirm the fan blade spins freely by hand without rubbing on any surrounding surface. Reinstall the rear access panel, shelves, and drawers. Plug the refrigerator back in and allow several hours for the unit to return to its set temperature before reloading with food. Tools needed: Phillips screwdriver, nut driver, work gloves. Frequently Asked Questions My refrigerator section is warm but the freezer is still cold — is this the fan motor? This is the single most common and telling symptom of a failed evaporator fan motor. Here's why: the evaporator coils (which produce the cold) sit in the freezer section, and the evaporator fan is what pushes that cold air into the fresh food compartment. When the fan motor fails, the freezer stays cold (it's right next to the coils) but the fridge warms up because no air is being circulated to it. If your freezer is cold and your fridge is warm, the evaporator fan motor is the prime suspect. You can confirm by listening for the fan when the compressor runs, or by opening the rear evaporator panel to see if the fan spins. The new motor looks bigger than my old one — is it the right part? Yes — this is an upgraded replacement design, and it's normal for the motor body to appear slightly larger than the original LG unit. What matters is that the mounting holes and connector locations are identical to the original, so it bolts into the same position and plugs into the same 4-pin harness. The shaft (46 mm long, 3.0 mm diameter) also matches, so your existing fan blade transfers over. Compatibility is unchanged. If you have any concern, compare the mounting hole spacing and the connector to your old motor before installing. Why is my evaporator fan making noise? A noisy evaporator fan usually means one of two things: the motor bearings are wearing out (producing grinding, buzzing, or squealing), or the fan blade is rubbing against frost or ice that has built up around it. If frost buildup is the cause, that often points to a secondary problem in the defrost system (defrost heater, sensor, or control) allowing ice to accumulate where it shouldn't. Replacing a worn-out fan motor resolves the bearing noise. If heavy frost keeps returning after replacement, investigate the defrost system next. LG has several similar fan motors — how do I know this is the right one? LG uses several different evaporator fan motors across its refrigerator lineup, and while they look similar, they differ in voltage, current, shaft dimensions, and connector style. The EAU63923603 is a DC 12V / 1.0A motor with a 4-pin connector, 46 mm shaft, and 70 cm lead, used across the LFCC/LFCS/LFXC/LFXS/LMXC/LMXS/LRDCS/LRFCS/LRFDS/LRFWS/LRFXS/LRMVS/LRMXC/LRMXS series. Before ordering, find the part number printed on your old motor and confirm it's EAU63923603 or one of the listed cross-references (EAU65058305, EAU63923606, AP6317197, PS12383671). If your motor shows a different number, contact our support team with your model number and we'll confirm the correct motor. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine LG OEM part, but is manufactured with an ABS housing and quality metal internal components to match the electrical specifications (DC 12V, 1.0A), 4-pin connector, shaft dimensions (46 mm x 3.0 mm), mounting hole pattern, and cooling function of the original EAU63923603 evaporator fan motor used in compatible LG and Kenmore LG-built refrigerators. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout

Read more less

XPARTCO WR60X10220 Refrigerator Condenser Fan Motor The XPARTCO WR60X10220 is an aftermarket replacement condenser fan motor for GE frost-free refrigerators with a condenser coil. This motor lives in the compressor/machine compartment at the back or bottom of the refrigerator. Whenever the compressor runs, this fan runs right along with it, circulating air through the refrigerator's grille to cool both the compressor and the condenser coils as they work. It also plays a secondary role in helping evaporate excess water that collects in the drain pan. Because the condenser fan cools the mechanical side of the refrigeration system rather than circulating cold air to your food, a failing motor tends to affect the whole refrigerator's cooling capacity rather than just one compartment. The harness and plug extend approximately 8" from the motor body. Common failure causes include worn motor bearings, dust and debris buildup around the coils restricting airflow, and general electrical wear over time. Symptoms include a refrigerator that runs warm overall, a hot cabinet area near the back or bottom of the unit, a squealing or grinding noise, or the compressor running constantly as it struggles to shed heat. It directly replaces AP4298602, 1257132, AH1766247, EA1766247, PS1766247, WR60X10133, WR60X10171, WR60X10192, and SM10220. Quick Answer The XPARTCO WR60X10220 Refrigerator Condenser Fan Motor fixes GE, Hotpoint, RCA, Kenmore, Haier, Monogram, and Café frost-free refrigerators with a hot cabinet area, squealing or grinding noise, or a fridge running warm overall. Harness and plug extend approximately 8" from the motor. Replaces AP4298602, 1257132, AH1766247, EA1766247, PS1766247, WR60X10133, WR60X10171, WR60X10192, SM10220. This cools the compressor and condenser coils — a different part and symptom pattern than an evaporator fan, which only affects internal air circulation to the food compartments. Common Problems This Part Fixes Refrigerator running warm overall, in both the fresh food and freezer compartments Hot cabinet area noticeable near the back or bottom of the refrigerator Squealing, grinding, or buzzing noise coming from the compressor compartment Refrigerator running constantly as the compressor struggles to shed heat Water pooling or not evaporating properly in the drain pan Fan blade that doesn't spin freely, or doesn't spin at all, when checked by hand Excessive dust or debris buildup visible around the condenser coils and fan Cross Reference Information Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item. Replaces Part Numbers This refrigerator condenser fan motor directly replaces the following OEM and cross-reference part numbers: WR60X10220, WR60X10133, WR60X10171, WR60X10192, 197D1871P026, IS-2321GEN, AH1766247, EA1766247, EAP1766247, AP4298602, AGE29216, PD00001198, PS1766247, SM10220 If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This condenser fan motor is compatible with select GE, Hotpoint, and RCA frost-free refrigerators, and also fits select Kenmore, Haier, Monogram, and Café refrigerators built on the GE platform. Note — condenser fan, not evaporator fan: This motor cools the compressor and condenser coils in the machine compartment at the back or bottom of the refrigerator. It is a completely different part from an evaporator fan motor (such as our WR60X10185 or WR60X10318 listings), which sits behind the freezer's rear panel and circulates cold air to the food compartments. Always verify your full model number before ordering. Contact our support team with your model number if you're unsure which fan motor your refrigerator needs. Key Features Aftermarket replacement condenser fan motor — draws air across the condenser coils and compressor to remove system heat Resolves "hot cabinet area," "squealing or grinding noise," "runs warm overall," and "runs constantly" symptoms caused by fan failure Also helps evaporate excess water collecting in the drain pan Harness and plug extend approximately 8" from the motor body Sturdy construction built for long-term reliable performance Direct drop-in replacement matching the original mounting and blade fitment Replaces WR60X10133, WR60X10171, WR60X10192, AP4298602, 1257132, AH1766247, EA1766247, PS1766247, and SM10220 Aftermarket replacement built to OEM-equivalent quality standards DIY-friendly repair — typically under 30 minutes Product Specifications Part Number WR60X10220 OEM Part Number WR60X10220 Part Type Refrigerator Condenser Fan Motor Condition Aftermarket Replacement Brand GE Location Compressor/machine compartment (back or bottom of cabinet) Function Cools the condenser coils and compressor; aids drain pan evaporation Dimensions 2-1/2"H x 4"W x 11"D Harness/Plug Length Approx. 8" from motor Repair Difficulty Easy — under 30 minutes Quantity 1 fan motor Compatible Brands GE, Hotpoint, RCA, Kenmore, Haier, Monogram, Café Installation Notes ⚠️ Unplug Refrigerator Before Starting Shut off power at the circuit breaker or fuse box, then pull the refrigerator away from the wall and disconnect the power cord from the outlet. Wear work gloves. Remove the condenser fan motor cover, typically held on by two screws, to access the motor. Before condemning the motor, clear away any dust, lint, or debris built up around the condenser coils and fan blade — restricted airflow from a dirty coil produces symptoms similar to a failing motor and costs nothing to rule out. Photograph the wiring and the fan blade's position before disconnecting anything. Disconnect the power wire and the ground wire from the old motor, remove the mounting screws or clips holding the motor bracket in place, and pull the motor and fan blade assembly free. If the old fan blade is seized onto the motor shaft, a firm, sudden strike (rather than steady pressure) will typically break the blade loose from the shaft without damaging the plastic blade, so it can be reused on the new motor. Mount the new WR60X10220 in the same position, reconnect the power and ground wires, and confirm the blade spins freely by hand without contacting the housing before reinstalling the fan cover. Restore power and monitor the refrigerator over the next 24 hours to confirm normal, even cooling has returned and any hot cabinet area or noise has resolved. Tools needed: Phillips screwdriver, work gloves. Frequently Asked Questions My refrigerator has a hot spot on the cabinet and runs warm overall. Is this the right part? Yes, this is a classic symptom pair for a failing condenser fan motor. Without proper airflow across the condenser coils and compressor, heat builds up in the machine compartment (producing that hot cabinet area) while the whole refrigeration cycle loses efficiency, which shows up as both compartments running warmer than normal rather than just one. The old fan blade is stuck on the motor shaft. How do I remove it without breaking it? A gentle, steady pull often won't budge a seized blade, but a firm, sudden strike to the blade (rather than continuous pressure) will typically pop it loose from the metal shaft without damaging the plastic blade itself, so you can reuse it on the new motor if a blade isn't included. Work carefully and support the blade so it doesn't fall and crack once it releases. Could dirty condenser coils cause the same symptoms as a bad fan motor? Yes, and it's worth checking before you buy a new motor. A condenser fan pushing air through coils caked in dust, pet hair, or debris will struggle to cool the system properly even if the motor itself is working fine. Clean the coils and the fan blade thoroughly first; if the fan still doesn't spin freely, spins with a wobble, or doesn't run at all afterward, the motor itself has failed and this replacement is the correct fix. Does this fan also affect my drain pan? Yes, indirectly. In addition to cooling the compressor and condenser coils, this fan helps evaporate excess water that collects in the drain pan beneath the refrigerator. If the fan has failed, you may notice water pooling or not evaporating as it normally would, in addition to the more obvious cooling and noise symptoms. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine GE OEM part, but is manufactured to match the mounting configuration, dimensions, and airflow performance of the original WR60X10220 condenser fan motor used in compatible GE, Hotpoint, RCA, Kenmore, Haier, Monogram, and Café refrigerators. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Quality Aftermarket Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout

Read more less

XPARTCO 2315539 Refrigerator Evaporator Fan Motor Replaces WP2315539 The XPARTCO 2315539 is an aftermarket replacement refrigerator/freezer evaporator fan motor compatible with a wide range of Whirlpool, Kenmore, Maytag, KitchenAid, Amana, Roper, Crosley, Admiral, Estate, Inglis, Ikea, and Gladiator refrigerators. The evaporator fan motor is located in the freezer section and circulates air across the evaporator coils — the cold air generated at the coils is then pushed throughout the freezer and the fresh food compartment. When this motor fails, the most common symptom is excessive noise from the freezer area, and often the refrigerator section won't cool properly even though the freezer remains cold. This motor includes the incorporated wire harness and plug. Rated 115V, 60Hz, with clockwise rotation. It directly replaces WP2315539, WP2315539VP, 2219689, 2225625, W10438708, 1372146, 1518337, AP3996841, AP6007247, ESF-U2B, EAP11740359, PD00021608, PS11740359, and PS1518337. Important: don't forget to transfer the two rubber grommets from your old motor to the new one for proper mounting. Installs in 30–45 minutes with basic hand tools. Quick Answer The XPARTCO 2315539 Refrigerator Evaporator Fan Motor fixes Whirlpool, Kenmore, Maytag, KitchenAid, and Amana refrigerators with excessive noise from the freezer area, ice buildup in the freezer, or where the fresh food section is warm but the freezer is still cold. Includes incorporated wire harness and plug. 115V, 60Hz, clockwise rotation. Transfer rubber grommets from old motor for mounting. Replaces WP2315539, WP2315539VP, 2219689, 2225625, W10438708, 1372146, AP3996841, AP6007247, ESF-U2B, EAP11740359, PS11740359, PS1518337. Common Problems This Part Fixes Excessive noise from the freezer area — most common symptom of evaporator fan motor failure Loud humming, whining, grinding, or scraping noises during operation Freezer compartment cold but fresh food section warm — cool air not being circulated Heavy ice buildup on the evaporator coils or rear freezer wall Refrigerator running continuously trying to maintain temperature Fan blade not spinning freely or seized when checked by hand Motor failing continuity test with a multimeter Visible damage to the fan motor housing or harness Replaces Part Numbers This evaporator fan motor directly replaces the following OEM and cross-reference part numbers: WP2315539, 2315539, W10438708, 1372146, 2219689, 2225625, ESF-U2B, AP6007247, AWP47336, EAP11740359, PD00003243, PS11740359. If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This evaporator fan motor is compatible with select refrigerators from the following brands: Whirlpool refrigerators (top-mount, side-by-side, and Gold series — select models) Kenmore / Sears refrigerators (Whirlpool-built — select 106-series and related models) Maytag refrigerators (select models) KitchenAid refrigerators (select models) Amana refrigerators (select models) Roper refrigerators (select models) Crosley refrigerators (select models) Admiral refrigerators (select models) Estate refrigerators (select models) Inglis refrigerators (select models) Ikea refrigerators (select Whirlpool-built models) Gladiator refrigerators (select models) Note: This motor includes an incorporated wire harness. If your old motor has a separate wire harness (not incorporated), confirm the correct part with our support team before ordering. Always verify your model number first. Remember to transfer the two rubber grommets from your old motor to the new one — they're essential for proper mounting. Key Features Refrigerator/freezer evaporator fan motor — circulates cold air from the evaporator coils throughout both the freezer and fresh food compartments Includes incorporated wire harness and plug — direct plug-in installation Rated 115V, 60Hz — correct electrical specifications for compatible Whirlpool-platform refrigerators Clockwise motor rotation Replaces WP2315539, WP2315539VP, 2219689, 2225625, W10438708, 1372146, AP3996841, AP6007247, ESF-U2B, PS11740359, PS1518337, and additional cross-references Compatible with Whirlpool, Kenmore, Maytag, KitchenAid, Amana, Roper, Crosley, Admiral, Estate, Inglis, Ikea, and Gladiator refrigerators Important: transfer the two rubber grommets from the old motor to the new one for proper mounting Aftermarket replacement built to OEM-equivalent quality standards DIY repair — installs in 30–45 minutes with basic hand tools Product Specifications Part Number 2315539 OEM Part Number WP2315539 Part Type Refrigerator Evaporator Fan Motor (Freezer Section) Condition Aftermarket Replacement Application Refrigerators (Whirlpool platform) Voltage 115V AC Frequency 60 Hz Rotation Clockwise Wire Harness Incorporated wire harness and plug included Mounting Transfer two rubber grommets from old motor Compatible Brands Whirlpool, Kenmore, Maytag, KitchenAid, Amana, Roper, Crosley, Admiral, Estate, Inglis, Ikea, Gladiator Installation Notes ⚠️ Unplug Refrigerator and Move Perishable Food Before Starting — Wear Work Gloves Unplug the refrigerator and safely store any food that could spoil while the power is off. Wear work gloves to protect your hands. The evaporator fan motor is located behind the rear access panel inside the freezer compartment. Remove the freezer shelves and any internal components blocking access to the rear panel. Remove the screws holding the rear access panel to expose the evaporator coils and fan motor (a 1/4" hex driver is commonly needed). Photograph the wire connections and fan blade orientation before disconnecting. Disconnect the wire harness connector from the old motor. Note the orientation of the fan blade on the motor shaft and the position of the two rubber mounting grommets — both must be transferred to the new motor. Remove the mounting screws or release the motor from its bracket, and pull the old motor free. Transfer the rubber grommets and fan blade (if not pre-installed) to the new 2315539 motor in the same orientation. Install the new motor in the same position, reconnect the wire harness, and reinstall the access panel and shelves. Plug the refrigerator back in and allow several hours for the unit to return to its set temperature before reloading with food. Tools needed: 1/4" hex driver, Phillips screwdriver, flathead screwdriver, work gloves. Frequently Asked Questions My freezer is making loud noise — is it the evaporator fan motor? Yes, this is the most recognizable symptom of a failed evaporator fan motor on Whirlpool-platform refrigerators. When the motor's bearings wear out, it produces loud humming, whining, grinding, or scraping noises during operation. The noise often varies as the fan speed changes or as ice builds up around the fan blade. To confirm, unplug the refrigerator and access the fan behind the rear freezer panel — try turning the blade by hand. If it doesn't spin freely, is stiff, or seizes, the motor bearing has failed and needs replacement. My freezer is cold but my fridge is warm — could this be the cause? Yes — on many Whirlpool-platform refrigerators, the freezer's evaporator fan motor is responsible for circulating cool air from the freezer evaporator into the fresh food compartment as well. When this fan fails, the freezer's own compartment may stay cold because the cold air is generated right there, but the fresh food section warms up because no air is being moved into it. If your fridge is warm while the freezer remains cold, this is a likely cause — especially if you also hear unusual noise from the freezer area or see ice buildup on the evaporator coils. What is the difference between 2315539 and WP2315539? These are the same evaporator fan motor. WP2315539 is the updated Whirlpool OEM part number that superseded the original 2315539. The 2219689, 2225625, W10438708, and ESF-U2B are also cross-references for this same motor across various Whirlpool catalog revisions and production runs. This aftermarket replacement is compatible with all of these numbers. Why do I need to transfer the rubber grommets from the old motor? The two rubber grommets seat between the motor housing and the mounting bracket inside the refrigerator. They isolate the motor from the cabinet to dampen vibration and reduce noise during operation, and they also keep the motor properly positioned in its mount. The new 2315539 typically ships without these grommets — they are reused from the old motor. Remove them carefully from the old motor before discarding it, and slide them onto the new motor in the same positions. Without the grommets, the motor may run noisily or vibrate excessively. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is manufactured to match the dimensions, electrical specifications (115V AC, 60Hz, clockwise rotation), incorporated wire harness, and function of the original WP2315539/2315539 evaporator fan motor. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout

Read more less

DA31-00103A Genuine OEM Refrigerator Condenser Fan Motor - Compatible with Samsung Product Description Ensure efficient cooling with the DA31-00103A Genuine OEM Refrigerator Condenser Fan Motor. This Samsung-manufactured motor is designed as a replacement for select Samsung refrigerators. It powers the fan to circulate air over the condenser coils, dissipating heat to maintain optimal refrigeration performance. This part addresses issues like insufficient cooling, frost buildup, unusual noises (e.g., chirping, buzzing), or the refrigerator running too frequently, often caused by a faulty or worn motor. Note: Includes (1) condenser fan motor (fan blade not included). Disconnect power before installation. Verify compatibility with your refrigerator model. Replaces part numbers: DA31-00103A, IS-27210SCD6A, PD00002207, EAP4138348m AP4140906, 1472692, PS4138348. Compatibility: Compatible with select Samsung refrigerator models, including but not limited to: Samsung: RS2631SL, RS2631SL/XAA, RS2623WW/XAA, RS2624SW, RS2624SW/XAA, RS2624WW, RS2631SW, RS2631SW/XAA, RSC5DBSH, RS2621SW/XAA, RS2623BB, RS2623BB/XAA, RS2623SH, RS2623SL, RS2623VQ, RS2630SH, RS2630WW Verify your model number or contact our support team for assistance. Key Features: ✅ Brand and Models Compatibility: Fits select Samsung refrigerators. 🔧 Specifications: Genuine OEM Samsung AC fan motor, 115V, 60Hz, 0.16A, 1300RPM, 1-5/8" shaft. 💪 Reliable Performance: Circulates air to dissipate heat from condenser coils for efficient cooling. 🛠️ Easy Installation: Requires screwdriver and pliers; typically installed in 15–30 minutes. 🛡️ Effective Fixes: Resolves insufficient cooling, frost buildup, noisy operation, or frequent running. Product Specification Part Number: DA31-00103A Component Type: Refrigerator condenser fan motor Material: Metal and plastic Electrical Specs: 115V, 60Hz, 0.16A, 1300RPM, 1-5/8" shaft, quick disconnect Compliance: UL-listed, Prop 65 warning for California. Installation Notes: Safety First: Disconnect the refrigerator from the power source before installation. Shop for high-quality appliance parts with a 30-day return policy. Keep your refrigerator cooling efficiently today! Add to cart now for a reliable fix!

Read more less

XPARTCO HVAC Capacitor Contractor Pack — 18-Piece Assortment Kit (Dual + Single Run) The XPARTCO HVAC Capacitor Contractor Pack bundles the seven most commonly needed dual run capacitor ratings, plus two single run capacitor ratings, into a single 18-piece kit, so a technician can carry one box instead of restocking capacitors between jobs. Each dual run capacitor combines two capacitors into one round, three-terminal can — one rated for the compressor, one for the condenser fan motor — the standard design used across the vast majority of residential and light commercial split systems, window units, and heat pumps. The single run capacitors are 2-terminal units sized for one motor circuit, commonly used on standalone condenser fan motors, pool pumps, and other single-phase motor equipment. The mix in this kit is weighted toward the ratings that fail most often in the field: 35/5, 40/5, and 45/5 MFD capacitors cover the majority of residential 1.5–3.5 ton systems and are included in higher quantities, while 50/5, 60/5, 70/5, and 80/5 MFD round out coverage for larger residential and light commercial compressors. All fourteen capacitors are rated 450VAC, so each one is a safe upgrade replacement regardless of whether the original equipment was speced at 370V, 440V, or 450V. Quick Answer The XPARTCO HVAC Capacitor Contractor Pack is an 18-piece assortment covering the seven dual run capacitor ratings most commonly replaced on residential and light commercial AC systems and heat pumps, plus two single run capacitor ratings for fan motors and similar equipment: 35/5 (×2), 40/5 (×4), 45/5 (×4), 50/5 (×1), 60/5 (×1), 70/5 (×1), 80/5 (×1), single-run 5 (×2), and single-run 7.5 (×2) MFD, all rated 450VAC, round. Built for technicians who want to stock a truck once instead of reordering capacitors mid-week. Capacitors store a dangerous electrical charge even after power is disconnected — always discharge before handling. What's In The Kit Capacitor Rating Qty Typical Application 35/5 MFD, 450V, Round 2 Smaller residential split systems, window/PTAC units 40/5 MFD, 450V, Round 4 Common residential 2–2.5 ton systems — high-frequency replacement size 45/5 MFD, 450V, Round 4 Common residential 2.5–3 ton systems — high-frequency replacement size 50/5 MFD, 450V, Round 1 Mid-size residential systems, 3–3.5 ton 60/5 MFD, 450V, Round 1 Larger residential systems, 3.5–4 ton 70/5 MFD, 450V, Round 1 Larger residential/light commercial systems, 4–5 ton 80/5 MFD, 450V, Round 1 Larger compressors and light commercial equipment 5 MFD, 450V, Round (Single Run) 2 Standalone condenser fan motors, pool pumps, small single-phase motors 7.5 MFD, 450V, Round (Single Run) 2 Standalone condenser fan motors, pool pumps, small single-phase motors Common Problems This Kit Solves Outdoor AC unit hums but the compressor won't start Condenser fan won't spin, or spins slowly and needs a manual push to get going System trips the breaker shortly after starting AC blows warm air because the compressor isn't running Repeated clicking sound from the contactor as it tries and fails to start the motor Capacitor can visibly bulging, domed on top, or leaking oily residue Needing a specific capacitor rating on the spot without a return trip to the supply house Compatibility This kit's capacitors are universal replacements compatible with central air conditioners, heat pumps, and condensing units across all major HVAC brands, wherever the original capacitor's MFD rating matches one included in this kit and its voltage rating is 450V or lower (370V and 440V equipment included, since a higher voltage rating is always a safe upgrade). Note: The MFD (microfarad) rating must match the original capacitor exactly on both the compressor and fan sides — do not substitute a different MFD value. If a job calls for a rating not included in this kit (such as a 25/5, 30/5, or 55/5), each individual dual run capacitor rating is also available separately in our HVAC capacitor line. Contact our support team if you'd like help confirming which rating a specific job needs. Key Features 18-piece assortment covering the 7 most commonly replaced dual run ratings plus 2 single run ratings Quantities weighted toward the highest-frequency replacement sizes (35/5, 40/5, 45/5) All capacitors rated 450VAC — a safe upgrade for equipment originally speced at 370V or 440V Round can construction — 3-terminal (C, Herm, Fan) dual run capacitors and 2-terminal single run capacitors Polypropylene film construction; safety approved CQC, VDE, TÜV, CL; built to GB/T 3667 and EN 60252 standards Operating temperature range -40°C to 70°C (-40°F to +158°F) Eliminates truck-stock gaps — one kit replaces reordering single capacitors between jobs Each rating also available individually for restocking a single value Kit Specifications Kit Contents 18 capacitors — 14 dual run across 7 ratings + 4 single run across 2 ratings (see table above) Capacitor Types Dual Run (Compressor + Fan) and Single Run Condition New — Universal Replacement Parts Voltage Rating (all pieces) 450VAC Shape Round Terminals 3 per dual run capacitor / 2 per single run capacitor (1/4" quick-connect) Frequency 50/60 Hz Tolerance ±5% Construction Type Polypropylene film capacitor Operating Temperature Range -40°C to 70°C (-40°F to +158°F) Safety Approvals CQC, VDE, TÜV, CL Approval Standard GB/T 3667, EN 60252 Application Central Air Conditioners, Heat Pumps, Condensing Units Compatible Brands Universal — all major HVAC brands Installation Notes ⚠️ Danger — Capacitors Store A Dangerous Electrical Charge Shut off power to the outdoor unit at the disconnect box and at the breaker before beginning any capacitor replacement. A capacitor stores an electrical charge even after power has been disconnected, and that charge can deliver a serious or fatal shock. Before touching any terminal, discharge the capacitor fully: on a dual run capacitor, short each pair of terminals together (C-to-Fan, C-to-Herm, and Fan-to-Herm); on a single run capacitor, short the two terminals together. Use an insulated-handle screwdriver, or a proper capacitor discharge tool with a resistor. Never short the terminals with a bare metal tool held with your bare hand. ⚠️ Match The Rating Before Installing — Photograph Wiring First Confirm the failed capacitor's MFD rating on both the compressor and fan sides, and select the matching piece from this kit — the rating printed on the old capacitor's can is the reference, not the equipment's tonnage. Photograph the wiring on the old capacitor's terminals before disconnecting anything; terminals are typically labeled C (Common), Herm or Comp (compressor), and Fan. Remove the mounting strap holding the old capacitor, disconnect each wire, and install the replacement from this kit in the same mounting position, reconnecting each wire to the matching terminal. Restore power and confirm the compressor and fan both start promptly and run smoothly. Tools needed: insulated-handle screwdriver or capacitor discharge tool, nut driver, work gloves, safety glasses. Frequently Asked Questions Why are 35/5, 40/5, and 45/5 included in higher quantities than the others? These three ratings cover the size range used on the largest share of residential split systems in the field, so they're the ratings most likely to come up repeatedly across a week of service calls. The larger ratings (50/5 through 80/5) still come up regularly but less often, which is why the kit includes one of each rather than duplicates. What if a job needs a rating that isn't in this kit, like 25/5 or 55/5? Every rating in this kit — both dual run and single run — is also sold individually, so you can pick up less common values as needed without buying another full kit. Contact our support team if you want help identifying which individual rating a specific job calls for. Can I use a 450V capacitor from this kit to replace an original 370V or 440V capacitor? Yes. Voltage rating is a ceiling, not an exact match requirement — a capacitor rated for a higher voltage than the original works safely and often lasts longer under the same electrical stress. What you can't do is go the other direction, so every capacitor in this kit being 450V means it's a safe fit anywhere the original was rated 370V, 440V, or 450V. Does the MFD rating need to match exactly, or is there some tolerance? Match the rating on both the compressor and fan side as closely as possible to the original — these capacitors carry a ±5% manufacturing tolerance, but that's not the same as intentionally substituting a different rated value. Always select the kit piece whose printed MFD rating matches what was on the failed capacitor. Is this a genuine OEM kit? This is a universal replacement kit rather than a brand-specific OEM product. Because dual run capacitors are a standardized component defined by their electrical specifications rather than their manufacturer, each capacitor in this kit is a correct replacement for any unit's original capacitor sharing the same rating — regardless of which HVAC brand originally installed it. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Quality Replacement Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout

Read more less

WR60X31997 Genuine OEM GE Refrigerator Ice Box Fan Motor The WR60X31997 is a genuine GE OEM ice box fan motor assembly for GE, Hotpoint, Haier, Monogram, and Café refrigerators. This motor is situated in the freezer section and circulates cold air specifically around the ice box area, playing a direct role in ice production as well as general cooling and airflow in that part of the freezer. Consistent airflow here is what keeps the ice maker producing normally and prevents warm spots from developing nearby. Rated 12V DC, 0.23A. Common causes of failure include a malfunctioning motor, worn-out bushings that hinder smooth rotation, or damaged fan blades that restrict airflow; mineral buildup can also gradually degrade the fan's efficiency over time. A failing ice box fan produces a recognizable set of symptoms: reduced or inadequate ice production, items in the freezer warming up or defrosting even with the door shut, unusual sounds or vibration when the fan runs, or uneven frost patterns suggesting the airflow in that area isn't circulating properly. It directly replaces PD00071430, 4964240, AP6978662, PS12744140, and EAP12744140. Quick Answer The WR60X31997 Genuine OEM GE Refrigerator Ice Box Fan Motor fixes GE, Hotpoint, Haier, Monogram, and Café refrigerators with reduced or inadequate ice production, freezer items warming up despite the door being shut, unusual fan noise or vibration, or uneven frost patterns. 12V DC, 0.23A. Replaces PD00071430, 4964240, AP6978662, PS12744140, EAP12744140. Common Problems This Part Fixes Reduced or inadequate ice production from the ice maker Items in the freezer warming up or partially defrosting even with the door shut Unusual sounds or vibrations coming from the ice box fan area Uneven frost patterns suggesting ineffective air circulation Fan blade that doesn't spin freely, or doesn't spin at all, when checked by hand Freezer running less efficiently overall near the ice box area Cross Reference Information Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item. Replaces Part Numbers This refrigerator ice box fan motor directly replaces the following OEM and cross-reference part numbers: WR60X31997, 4964240, AP6978662, EAP12744140, Nidec Model G11I12MS1AZ-57, PS12744140, AGE29835, PD00071430 If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This ice box fan motor is compatible with select GE refrigerators, and also fits select Hotpoint, Haier, Monogram, Café, Profile, Fisher & Paykel, and Kenmore/Sears refrigerators built on the GE platform, including model numbers such as CQE28DM5NBS5, CVE28DM5NBS5, CVE28DM5NCS5, and CVE28DM5NS5. Note: This is the ice box fan motor specifically, a different component from GE's general evaporator fan motors used elsewhere in the freezer. Always verify your full model number before ordering. Contact our support team with your model number if you're unsure which fan motor your refrigerator needs. Key Features Genuine GE OEM part — factory-specified motor and blade design Circulates cold air around the ice box area, supporting ice production and nearby cooling Resolves "inadequate ice production," "items warming up," "unusual noise," and "uneven frost" symptoms caused by fan motor failure Premium motor coil and quality bearings for smooth, low-noise operation Rated 12V DC, 0.23A Direct drop-in replacement matching the original mounting and blade fitment Replaces PD00071430, 4964240, AP6978662, PS12744140, and EAP12744140 Compatible with GE, Hotpoint, Haier, Monogram, Café, Profile, Fisher & Paykel, and Kenmore/Sears refrigerators Genuine OEM replacement — guaranteed fit, materials, and performance Product Specifications Part Number WR60X31997 Part Type Refrigerator Ice Box Fan Motor Assembly Condition Genuine OEM Brand GE Location Freezer section, ice box area Function Circulates cold air to support ice production and cooling near the ice box Voltage 12V DC Amperage 0.23 A Quantity 1 fan motor assembly Compatible Brands GE, Hotpoint, Haier, Monogram, Café, Profile, Fisher & Paykel, Kenmore/Sears Installation Notes ⚠️ Unplug Refrigerator Before Starting Disconnect power at the outlet before beginning, and move perishable food to a cooler for the duration of the repair. Wear work gloves. Access the ice box fan by locating the panel or housing covering it in the freezer's ice box area — this may require removing the ice maker or nearby components for clearance depending on your model. Photograph the wiring and the fan blade's orientation before disconnecting anything. Disconnect the motor's wiring harness connector, remove the mounting screws or clips holding the motor bracket in place, and pull the motor and fan blade assembly free. Mount the new WR60X31997 in the same position, reconnect the wiring harness connector, and confirm the blade spins freely by hand without contacting the housing before reassembling any panels or components you removed for access. Restore power and monitor ice production and freezer temperature over the next 24 hours to confirm normal operation has returned. Tools needed: Phillips screwdriver, work gloves. Frequently Asked Questions My ice maker is producing less ice than usual. Could this fan be the cause? Yes, this is one of the more common symptoms of a failing ice box fan. Since this fan circulates cold air specifically around the ice box area, reduced airflow from a struggling or seized motor can directly slow down ice production, even if the rest of the freezer seems to be cooling normally. Items near the ice box seem to be warming up even though the freezer door is shut. Is that related? Yes. If this fan isn't circulating air properly, the area around the ice box can lose consistent cooling even while the rest of the freezer stays cold, since that zone depends specifically on this fan for airflow. This localized warming, paired with reduced ice production, is a strong combined signal pointing to this fan. Is this the same as a general evaporator fan motor? No, this is a distinct component. The ice box fan motor circulates air specifically around the ice box area to support ice production and nearby cooling, while a general evaporator fan motor circulates air across the evaporator coil for the freezer and fresh food compartments more broadly. The two serve different roles and are not interchangeable — always confirm which fan your model needs using your parts diagram or model number. Is this an OEM or aftermarket part? This is a genuine OEM part, manufactured by GE to factory specifications — guaranteed fit, materials, and performance. It matches the original motor design, blade fitment, and mounting configuration of the ice box fan motor originally installed in your refrigerator. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Genuine OEM Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout

Read more less

WR60X10209 Genuine OEM GE Refrigerator DC Condenser Fan Motor The WR60X10209 is a Genuine OEM GE replacement DC condenser fan motor compatible with a wide range of GE, Hotpoint, RCA, Kenmore, Haier, Monogram, and Café refrigerators in the GSS, GSL, HSS, PSS, PSC, GCE, PCE, and related series. The condenser fan motor is located near the compressor at the rear bottom of the refrigerator. It circulates air across the condenser coils to dissipate heat from the hot refrigerant before it returns to the evaporator — this is an essential step in the refrigeration cycle. Without the condenser fan running, heat builds up around the compressor and condenser coils, causing the refrigerator to run continuously, cool inefficiently, or trip the compressor's thermal overload protection. This Genuine OEM part is manufactured by GE to factory specifications. It is a DC voltage motor rated at 11.3V DC, 2.2W with a 4-pin plastic connector and four color-coded wires (white, blue, red, and yellow). It directly replaces WR60X10042, WR60X10053, WR60X10065, WR60X10080, WR60X10081, WR60X10155, WR60X10216, WR60X24483, WR60X10209-24PK, 1195784, AP4265957, AH1483567, EA1483567, and PS1483567. Installs in 15–30 minutes with basic hand tools. Quick Answer The WR60X10209 Genuine OEM GE Refrigerator DC Condenser Fan Motor fixes GE refrigerators that are not cooling properly, running continuously, making unusual noise from the back, or where the compressor is overheating. 11.3V DC, 2.2W, 4-pin connector (white/blue/red/yellow wires). Genuine OEM. Replaces WR60X10042, WR60X10053, WR60X10065, WR60X10080, WR60X10081, WR60X10155, WR60X10216, WR60X24483, AP4265957, PS1483567. Compatible with GE GSS, GSL, HSS, PSS, PSC, GCE, PCE series and Hotpoint, RCA, Kenmore, Haier, Monogram, Café. Common Problems This Part Fixes Refrigerator not cooling properly — condenser fan not circulating air across coils Refrigerator running continuously without reaching set temperature Compressor overheating — heat not being dissipated from condenser area Unusual noise or grinding from the back or bottom of the refrigerator Condenser fan motor visibly not spinning when compressor is running Refrigerator cycling off frequently on thermal overload protection Food spoilage — refrigerator unable to maintain safe temperatures Replaces Part Numbers This condenser fan motor directly replaces the following OEM and cross-reference part numbers: WR60X10209, 1195784, WR60X10042, WR60X10053, WR60X10065, WR60X10080, WR60X10081, WR60X10155, WR60X10216, 045900390950, 197D2407P013, AGE29194, AH1483567, EA1483567, EAP1483567, AP4265957, PD00001176, PS1483567. Contact our support team with your model number if you need confirmation before ordering. Compatibility This condenser fan motor is compatible with a wide range of refrigerators from the following GE product lines: GE refrigerators — GSS series (GSS22, GSS23, GSS25, GSS26 and related side-by-side models) GE refrigerators — GSL series (GSL22, GSL25 and related models) GE refrigerators — GCE series (GCE21, GCE23 and related models) GE refrigerators — PCE and PSS series (PCE23, PSS25, PSS26 and related Profile models) GE refrigerators — PSC series (PSC23, PSC25 and related Profile models) GE Monogram refrigerators — ZIS, ZISB series (select models) GE Café refrigerators (select models) Hotpoint refrigerators — HSS series (HSS22, HSS25 and related models) RCA refrigerators (select GE-built models) Kenmore / Sears refrigerators (select GE-built models) Haier refrigerators (select GE-platform models) Always verify your appliance model number before ordering. Contact our support team if you're unsure. Key Features Genuine OEM part manufactured by GE to factory specifications — guaranteed fit and performance Circulates air across the condenser coils to dissipate heat from the refrigerant and maintain efficient refrigeration cycle operation DC voltage motor rated at 11.3V DC, 2.2W — runs on DC voltage supplied by the refrigerator's control board 4-pin plastic connector with color-coded wires (white, blue, red, yellow) — direct plug-in installation on compatible models Replaces WR60X10042, WR60X10053, WR60X10065, WR60X10080, WR60X10081, WR60X10155, WR60X10216, WR60X24483, and AP4265957 Compatible with GE GSS/GSL/GCE/PCE/PSS/PSC, Hotpoint HSS, Kenmore, Haier, Monogram, Café, and RCA refrigerators DIY repair — installs in 15–30 minutes with basic hand tools Product Specifications Part Number WR60X10209 Part Type Refrigerator DC Condenser Fan Motor Condition Genuine OEM Application Refrigerators (side-by-side, French door, bottom-freezer) Voltage 11.3V DC Wattage 2.2W Connector 4-pin plastic plug Wire Colors White, Blue, Red, Yellow Location Near compressor at rear bottom of refrigerator Compatible Brands GE, Hotpoint, RCA, Kenmore, Haier, Monogram, Café Installation Notes ⚠️ Unplug Refrigerator Before Starting Unplug the refrigerator before beginning. Pull the refrigerator away from the wall to access the rear lower back panel. Remove the screws securing the back panel to expose the compressor, condenser coils, and condenser fan assembly. The condenser fan motor is mounted on a bracket near the compressor with the fan blade facing the condenser coil. Take a photo of the wire connector orientation before disconnecting. Disconnect the 4-pin wire connector from the motor. Remove the mounting screws securing the motor to the bracket and slide the old motor out. Note the orientation of the fan blade on the motor shaft — the blade must be reinstalled in the same direction on the new motor (or transferred from the old motor if the new motor does not include a blade). Install the new WR60X10209 motor, reconnect the wire connector, reinstall the back panel, restore power, and confirm the condenser fan spins when the compressor starts. Tools needed: Phillips screwdriver, 1/4" nut driver. Frequently Asked Questions What does the condenser fan motor do in a refrigerator? The condenser fan motor drives a fan blade that circulates ambient air across the condenser coils at the rear of the refrigerator. The condenser coils carry hot high-pressure refrigerant that has just been compressed — the fan removes heat from the refrigerant so it can cool, condense, and return to the evaporator to absorb heat from inside the refrigerator. Without the condenser fan running, heat builds up around the compressor and coils, causing the refrigerator to lose cooling efficiency, run continuously, or — in severe cases — trip the compressor's thermal overload and shut down entirely. Why does this motor use DC voltage instead of AC? Modern GE refrigerators use DC motors for the condenser fan because they are more energy-efficient, quieter, and easier to speed-control by the refrigerator's electronic control board than traditional AC motors. The refrigerator's main control board converts household 120V AC power to 11.3V DC to supply the condenser fan motor. This DC motor runs at a variable speed under board control, which allows GE's refrigerators to optimize fan speed based on cooling demand. How do I confirm the condenser fan motor has failed? Pull the refrigerator away from the wall, unplug it, and remove the rear lower panel. Spin the condenser fan blade by hand — if it is stiff, wobbles, or seizes, the motor bearing has failed. If the blade spins freely but the motor does not run when the refrigerator is plugged in and the compressor starts, check for DC voltage at the motor connector using a multimeter. If the board is supplying approximately 11–12V DC to the motor but the motor is not running, the motor has failed electrically. If no voltage is present, the control board may not be supplying power — a less common but possible failure mode. Does this motor come with the fan blade? The WR60X10209 is the motor only — the fan blade is typically not included and should be transferred from the old motor. When removing the old motor, carefully pull the fan blade off the motor shaft (it presses on — no hardware is typically needed). Press the blade onto the new motor shaft in the same orientation. If the fan blade is cracked or damaged, it should be replaced separately. Installing the blade in the wrong direction will reverse the airflow direction and reduce cooling efficiency. Is this a Genuine OEM or aftermarket part? This is a Genuine OEM part manufactured by GE to factory specifications. It is the exact same DC condenser fan motor installed in compatible GE, Hotpoint, and related brand refrigerators from the factory — guaranteed fit, materials, and performance. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Genuine OEM Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout

Read more less

XPARTCO EAU63103201 Refrigerator Evaporator Fan Motor The XPARTCO EAU63103201 is an aftermarket replacement evaporator fan motor for LG and select Kenmore/Kenmore Elite refrigerators. On this platform, the fan sits behind a panel near the crisper drawers and circulates air specifically through the fresh food compartment — a different physical location than the freezer-mounted evaporator fans found on many other brands. When this motor slows down or fails, the fresh food section is the part of the refrigerator most directly affected, since it depends on this fan to keep cold air moving across the compartment. Rated 12V DC at 1A with a 4-pin connector, this motor has a 2.36" (60mm) shaft length and a 0.12" (3.16mm) shaft diameter, with roughly a 20.5" (56cm) wire lead. Common failure modes include worn motor bearings that let the blade wobble or bind, and general electrical wear from age. A fridge running warm, not cold at all, or making unusual noise from behind the crisper area are all signs pointing to this motor. It directly replaces 4391461, AP6317185, PS11761147, EAP11761147, and PD00051700. Also identified by its production number, ODM-001F-41. Quick Answer The XPARTCO EAU63103201 Refrigerator Evaporator Fan Motor fixes LG and select Kenmore/Kenmore Elite refrigerators where the fresh food compartment runs too warm or isn't cooling at all, or there's unusual noise from behind the crisper drawer area. DC 12V, 1A, 4-pin connector, 2.36" (60mm) shaft length, 0.12" (3.16mm) shaft diameter. Replaces 4391461, AP6317185, PS11761147, EAP11761147, PD00051700. LG uses several similarly-numbered EAU-prefix fan motors across its lineup — this is a different part from the EAU63923603/EAU65058305 assembly used on other LG models, so verify your exact model number before ordering. Common Problems This Part Fixes Fresh food compartment running too warm Refrigerator not cooling at all in the fresh food section Unusual noise coming from behind the crisper drawer area Fan motor that won't run due to aging or internal damage Refrigerator running constantly as it struggles to maintain temperature Fan blade that doesn't spin freely, or spins with noticeable resistance, when checked by hand Frost or condensation forming near the fan location behind the crisper panel Cross Reference Information Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item. Replaces Part Numbers This refrigerator evaporator fan motor directly replaces the following OEM and cross-reference part numbers: EAU63103201, ODM-001F-41, 4391461, ALG1473540, AP6317185, PS11761147, OEM18086529, EAP11761147, PD00051700 If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This evaporator fan motor is compatible with select LG refrigerators, and also fits select Kenmore and Kenmore Elite refrigerators built on the LG platform, including model numbers such as: LG LRSES2706V, LRSPS2706V LG LSXC22396D, LSXC22396S, LSXC22426S, LSXC22436S LG LSXC22486D, LSXC22486S LG LSXS26326B, LSXS26326S, LSXS26326W LG LSXS26336S, LSXS26336V, LSXS26336D LG LSXS26386S, LSXS26396S Kenmore 795.5173381, 795.5173781, 795.5183241, 795.5183242, 795.5183341, 795.5183941, 795.5183942, 795.5185361, 795.5185761, 795.5186261, 795.5186361, 795.5186761, 795.5186961 Note: LG uses several different evaporator fan motors across its refrigerator lineup with similar EAU-prefix part numbers. This EAU63103201 motor is a separate, distinct part from the EAU63923603 / EAU65058305 fan motor assembly used on other LG models (such as the LFXS28596S, LMXS28626S, LFXS26596S, and LFXS26973D series) — the two are not interchangeable. Always verify your full model number before ordering. Contact our support team with your model number if you're unsure which fan motor your refrigerator needs. Key Features Aftermarket replacement evaporator fan motor — circulates air through the fresh food compartment Resolves "fresh food too warm," "not cooling at all," and "noise behind the crisper drawer" symptoms caused by fan motor failure Rated 12V DC, 1A, with a 4-pin connector for direct plug-and-play electrical fit 2.36" (60mm) shaft length, 0.12" (3.16mm) shaft diameter Approximately 20.5" (56cm) wire lead Direct drop-in replacement matching the original mounting and blade fitment Replaces 4391461, AP6317185, PS11761147, EAP11761147, and PD00051700 Compatible with LG and select Kenmore/Kenmore Elite refrigerators Aftermarket replacement built to OEM-equivalent quality standards Straightforward DIY repair — just a screwdriver needed on most models Product Specifications Part Number XPEAU63103201 OEM Part Number EAU63103201 (ODM-001F-41) Part Type Refrigerator Evaporator Fan Motor Condition Aftermarket Replacement Compatible Brand LG, Kenmore Location Behind panel near the crisper drawers, fresh food compartment Voltage 12V DC Amperage 1 A Connector 4-pin Shaft Length 2.36 in. (60mm) Shaft Diameter 0.12 in. (3.16mm) Wire Lead Length Approx. 20.5 in. (56cm) Color Gray Material Plastic and metal Quantity 1 fan motor Compatible Brands LG, Kenmore, Kenmore Elite Installation Notes ⚠️ Unplug Refrigerator Before Starting Disconnect power at the outlet before beginning. Wear work gloves. Access on this platform is different from many other brands: rather than removing a rear panel inside the freezer, slide the crisper drawer out fully, then remove the panel behind or above the drawer area to expose the fan motor. Photograph the wiring connector and the fan blade's position before disconnecting anything. Disconnect the 4-pin electrical connector from the old motor, remove the mounting screws or clips holding the motor bracket in place, and carefully pull the motor and fan blade assembly free. Transfer the fan blade to the new motor if a blade isn't included, matching the original orientation on the 60mm shaft. Mount the new EAU63103201 in the same position, reconnect the 4-pin connector fully, and confirm the blade spins freely by hand without contacting the housing before reassembling the panel and sliding the crisper drawer back into place. Restore power and monitor the fresh food compartment over the next several hours to confirm normal cooling has returned. Tools needed: Phillips screwdriver, work gloves. Frequently Asked Questions Why is this fan located near the crisper drawers instead of in the freezer? LG's refrigerator platform routes cold air to the fresh food compartment differently than many other brands, with this particular fan positioned behind a panel near the crisper drawer area rather than inside the freezer compartment. That's simply a difference in refrigerator design between manufacturers — it doesn't affect the fan's job, which is still to keep cold air circulating through the fresh food section, but it does mean the access point for this repair looks different from what you might expect if you've worked on a different brand before. My fridge section is warm but everything else seems fine. Is this the right part? Yes, this is the classic symptom this motor addresses. Since this fan specifically circulates air through the fresh food compartment, a failure here tends to affect that section directly — a warm fridge with an otherwise normally-functioning freezer points squarely at this motor rather than at the compressor or refrigerant system. There are several similar LG fan motor part numbers online. How do I know I have the right one? LG's EAU-prefix fan motors can look similar at a glance, but they aren't interchangeable — for example, the EAU63923603/EAU65058305 assembly used on models like the LFXS28596S and LMXS28626S is a completely different part from this EAU63103201 motor. The safest way to confirm is to check your refrigerator's full model number against a verified compatibility list, or contact our support team with your model number before ordering. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine LG OEM part, but is manufactured to match the electrical specifications (12V DC, 1A, 4-pin connector), shaft dimensions, and mounting configuration of the original EAU63103201 evaporator fan motor used in compatible LG and Kenmore refrigerators. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Quality Aftermarket Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout

Read more less

5304523741 Refrigerator Genuine OEM Evaporator Fan Motor – Compatible with Frigidaire, Electrolux, and Kenmore Refrigerators Product Description Keep your refrigerator cooling efficiently with the 5304523741 Refrigerator Genuine OEM Evaporator Fan Motor. This factory-approved replacement circulates cold air from the evaporator throughout the refrigerator and freezer compartments. A failing fan motor can cause uneven temperatures, frost buildup, or warm sections in your fridge. Installing this genuine OEM part ensures quiet, dependable air circulation and consistent cooling performance. Replaces Part Numbers 5304523741, AP6983831, EAP12746805, 4960926, PD00067011, PS12746805. Compatibility This genuine OEM fan motor fits select Frigidaire, Electrolux, and Kenmore refrigerators. Example compatible models include (but are not limited to): Frigidaire FFSS2615TS0, Electrolux LFHB2751TF, and Kenmore 253.70313214. Always verify your refrigerator’s model number before ordering. Contact our support team if you’re unsure. ✅ Key Features 🔄 Genuine OEM Replacement – Factory-approved motor for reliable cooling performance ❄️ Efficient Air Circulation – Distributes cold air evenly throughout the compartments 💰 Energy-Efficient Operation – Restores temperature consistency and reduces compressor strain 🛠️ DIY Friendly – Direct-fit replacement installs in minutes 🛡️ Fixes Common Issues – Solves warm freezer, frost buildup, or noisy fan motor problems 📐 Product Specification Part Number: 5304523741 Component Type: Refrigerator Evaporator Fan Motor Material: Metal and high-temperature plastic housing Mounting: Direct-fit replacement in freezer compartment Operating Conditions: Designed for continuous low-temperature operation Compliance: Genuine OEM certified 🛠️ Installation Notes Tools Needed: Phillips screwdriver, nut driver ⚠️ Safety First: Always unplug the refrigerator before servicing to prevent electrical shock. Steps: Disconnect power and remove freezer shelves and back panel. Locate and disconnect the wiring harness from the old fan motor. Remove mounting screws and take out the old motor and fan blade. Transfer the fan blade (if required) to the new 5304523741 motor. Mount the new motor, reconnect wiring, and reinstall back panel. Restore power and confirm even cooling and quiet operation. ⏱️ Time Required: 20–30 minutes 📦 Shop With Confidence 🚚 Free Shipping on All Orders 🧊 Genuine OEM Replacement Part 🔄 30-Day Return Policy Keep your refrigerator running at peak performance — Add to Cart Now for a genuine, factory-approved repair!
