Genuine OEM WR60X27396 Refrigerator Air Damper Assembly
The WR60X27396 is a genuine OEM air damper assembly for GE refrigerators, including side-by-side and bottom-mount models. The damper is a motorized flap that opens and closes to direct cold air from the freezer into the fresh food compartment, which is how the refrigerator keeps the fresh food section at the right temperature. When it sticks open or closed, or its motor stops working, the compartments fall out of balance: the fresh food section can run too warm or too cold, frost can build up, and the damper may make noise as it moves.
This is a genuine OEM part from GE Appliances, not an aftermarket equivalent, so the fit and operation match the original. It supersedes the earlier WR31X20918 damper assembly.
Quick Answer
The Genuine OEM WR60X27396 Air Damper Assembly fixes a GE refrigerator whose fresh food section is too warm or too cold, or has uneven temperatures, frost buildup, or damper noise because the damper is stuck or has failed. Genuine OEM from GE Appliances. Classic symptom: the freezer is cold but the fresh food section is warm, or the fresh food section freezes items, even with normal settings.
Common Problems This Part Fixes
Fresh food section too warm while the freezer stays cold
Fresh food section too cold, freezing food
Damper stuck open or closed, causing a temperature imbalance
Unusual clicking or buzzing noises when the damper moves
Frost or ice buildup that interferes with the damper
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This air damper assembly replaces the following part numbers:
WR60X27396, 4590355, WR09X10065, WR31X20918, WR9X10065, AGE29713, AP6280910, EAP12172988, PD00047584, PS12172988.
WR60X27396 is GE's current number for this damper, superseding WR31X20918. If your old damper or parts diagram shows WR31X20918, this is the matching replacement.
Compatibility
This damper assembly is listed for GE refrigerators, including:
Side-by-side models such as ZISS360DNKSS, ZIS420NNEII, and ZISS480DPESS
Bottom-mount models such as CFE26KP2NLS1, CDB36LP2RBS1, GDE21EGKARWW, and ZIC360NHDLH
Note: The model list above is only a sample, since one retailer lists over 150 compatible models. Confirm fit by matching the number on your old damper or your parts diagram against the Replaces list, or contact our support team with your model number and we'll verify before you order.
Key Features
Genuine OEM GE damper assembly, not an aftermarket equivalent
Motorized damper that regulates cold airflow from the freezer into the fresh food section
Restores even temperatures between compartments
Authorized by GE for refrigerators using flammable refrigerant such as R600a
Supersedes the earlier WR31X20918
Product Specifications
Part Number
WR60X27396
OEM Part Number
WR60X27396
Part Type
Refrigerator Air Damper Assembly (Motorized)
Condition
Genuine OEM
Manufacturer
GE Appliances
Supersedes
WR31X20918
Application
Select GE Refrigerators
Installation Notes
⚠️ Unplug Power Before Installing Unplug the refrigerator before starting, and move perishable food to a cooler or another refrigerator so it stays safe during the repair. Following your model's service guide, remove the panels or covers needed to reach the damper, which sits in the air path between the freezer and the fresh food section. Note the position of the old damper, disconnect its wiring connector, and remove the fasteners holding it in place. Install the new damper in the same position, reconnect the connector, and replace the panels. Restore power and allow time for the temperatures to stabilize before judging the repair.
Frequently Asked Questions
My freezer is cold but the fresh food section is warm. Is this the part I need?
It can be. If the damper is stuck closed, not enough cold air reaches the fresh food section. Before replacing it, check that the vents aren't blocked by food and that frost isn't jamming the damper. A stuck or failed damper is a likely cause when those are clear.
My fresh food section is freezing my food. Could this be the damper?
Yes. A damper stuck open lets too much cold air in from the freezer, which can freeze items in the fresh food section.
My old damper is marked WR31X20918. Will this work?
Yes. WR31X20918 is on the Replaces list, and WR60X27396 is its current replacement. If you're unsure, contact our support team with your model number and we'll confirm.
Is this a genuine GE part?
Yes. This is a genuine OEM part from GE Appliances, not an aftermarket equivalent.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Genuine OEM Parts ✓ Compatibility Support ✓ Secure Checkout
W11236851 Refrigerator Genuine OEM Air Damper Diffuser
The W11236851 is a genuine Whirlpool OEM air damper diffuser assembly for Whirlpool refrigerators, and also fits select Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and Ikea models. Located inside the refrigerator behind the evaporator cover, this damper controls the flow of cold air from the freezer into the refrigerator compartment, opening and closing as needed to maintain the set temperatures in each section.
Causes of a bad damper include wear and tear of the movable parts over time, failure of the actuator motor that powers it, or damage from something accidentally blocking the damper mechanism. Symptoms of a failing damper include the refrigerator section running too cold or too warm, the freezer section running too cool or too warm, difficulty maintaining set temperatures, excessive condensation inside the appliance, or ice accumulation. It directly replaces 4814117, W11175955, AP6783936, EAP12584010, AWP43935, PD00058357, PS12584010.
Quick Answer
The W11236851 Refrigerator Genuine OEM Air Damper Diffuser fixes Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and Ikea refrigerators where the fridge or freezer section runs too warm or too cold, temperatures are hard to maintain, or you notice excessive condensation or ice buildup. Replaces 4814117, W11175955, AP6783936, EAP12584010, AWP43935, PD00058357, PS12584010. Check that nothing is accidentally blocking the damper mechanism before assuming it has failed — food items or packaging pushed against it can cause the same symptoms as a worn or broken damper.
Common Problems This Part Fixes
Refrigerator section too cold
Refrigerator section too warm
Freezer section too cool
Freezer section too warm
Excessive condensation inside the appliance
Ice accumulation
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This refrigerator air damper diffuser directly replaces the following OEM and cross-reference part numbers:
W11236851, 4814117, W11175955, AP6783936, EAP12584010, AWP43935, PD00058357, PS12584010
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This air damper diffuser is compatible with select Whirlpool refrigerators, and also fits select Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and Ikea refrigerators built on the Whirlpool platform.
Note: Always verify your full model number before ordering, since Whirlpool uses several different damper designs across its refrigerator lineup. Contact our support team with your model number if you're unsure.
Key Features
Genuine Whirlpool OEM part — factory-specified damper and actuator design
Controls cold airflow from the freezer into the refrigerator compartment
Resolves "too cold," "too warm," "excessive condensation," and "ice accumulation" symptoms
Located behind the evaporator cover
Direct drop-in replacement matching the original mounting and connections
Replaces 4814117, W11175955, AP6783936, EAP12584010, AWP43935, PD00058357, PS12584010
Compatible with Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and Ikea refrigerators
Genuine OEM replacement — guaranteed fit, materials, and performance
Product Specifications
Part Number
W11236851
Part Type
Refrigerator Air Damper Diffuser Assembly
Condition
Genuine OEM
Brand
Whirlpool
Location
Behind the evaporator cover
Function
Controls cold airflow between the freezer and refrigerator compartments
Repair Difficulty
Moderate
Quantity
1 damper assembly
Compatible Brands
Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, Ikea
Installation Notes
⚠️ Unplug Refrigerator Before Starting — Check For Blockages First Unplug the refrigerator and safely store any food that could spoil while the power is off. Wear work gloves. Before disassembling anything, check whether food items or packaging have been accidentally pushed against the damper mechanism, since this can cause the same temperature symptoms as a genuinely failed part. Locate the evaporator cover, typically in the freezer or at the back of the fresh food compartment depending on your model, and remove it to access the damper assembly. Photograph the wiring connection to the actuator motor before disconnecting anything. Disconnect the wiring harness from the old damper assembly, remove any mounting clips or fasteners, and pull it free. Install the new W11236851 in the same position, reconnect the wiring harness fully, and secure any mounting hardware. Reinstall the evaporator cover. Restore power and monitor both the refrigerator and freezer temperatures over the next 24 hours to confirm consistent, accurate cooling in both compartments. Tools needed: Phillips screwdriver (model-dependent), work gloves.
Frequently Asked Questions
My refrigerator section is too warm but the freezer is fine. Is this the part I need?
Yes, this is a common symptom of a failing air damper. Since this damper controls how much cold air moves from the freezer into the refrigerator compartment, a stuck or broken damper can leave the refrigerator section too warm even while the freezer maintains a normal temperature.
My freezer or fridge is too cold instead of too warm. Could this still be the damper?
Yes. A damper stuck in the open position can let too much cold air flow into the refrigerator compartment, making it colder than intended, while a damper stuck closed can have the opposite effect. Both too-cold and too-warm symptoms in either compartment can point to this same part.
What should I check before assuming the damper itself is broken?
Check that nothing — food packaging, containers, or shifted items — is physically blocking the damper mechanism, since accidental blocking can produce the same temperature symptoms as a genuinely worn or failed damper, without requiring a replacement part at all.
Is this an OEM or aftermarket part?
This is a genuine OEM part, manufactured by Whirlpool to factory specifications — guaranteed fit, materials, and performance. It matches the original damper and actuator design of the air damper diffuser originally installed in your refrigerator.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Genuine OEM Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
WR60X10062 Refrigerator Air Damper Assembly
Replaces Part Numbers:WR60X10062, 914163, AH304650, EA304650, AP3184950, PS304650.
California Residents only
WARNING: Cancer and/or Reproductive Harm - www.p65warnings.ca.gov
5040JA2004A Genuine OEM LG Refrigerator Motor Damper Grommet (Rear)
The 5040JA2004A is a genuine LG OEM rubber motor damper grommet for LG and select Kenmore refrigerators. This small rubber component mounts and isolates a fan motor from the surrounding bracket, cushioning it against vibration as the motor runs. This is the rear-position grommet; LG refrigerators typically use more than one grommet to support a fan motor from multiple points.
Made of rubber, this grommet naturally degrades over years of exposure to cold temperatures and constant vibration, eventually cracking, hardening, or losing its cushioning shape. Once it fails, the motor it supports is no longer properly isolated, and the metal motor bracket can end up in direct contact with the surrounding housing. A worn or failed grommet typically shows up as new or worsening rattling, buzzing, or vibration noise coming from the back of the refrigerator, especially noticeable when the fan motor is running. It directly replaces 5040JA2004B, 1268010, AP4635690, AH3526229, EA3526229, PS3526229, EAP3526229, and PD00027884.
Quick Answer
The 5040JA2004A Genuine OEM LG Refrigerator Motor Damper Grommet (Rear) fixes LG and select Kenmore refrigerators with new or worsening rattling, buzzing, or vibration noise from the back of the unit, especially when the fan motor is running. Rubber, rear-position grommet. Replaces 5040JA2004B, 1268010, AP4635690, AH3526229, EA3526229, PS3526229, EAP3526229, PD00027884. This grommet is used with a fan motor at the rear of the refrigerator; sources vary on whether that's the evaporator or condenser fan depending on the specific model, so confirm your model number before ordering.
Common Problems This Part Fixes
Rattling or buzzing noise from the back of the refrigerator
Vibration noise that's especially noticeable when the fan motor is running
Noise that has gradually worsened over time
Visibly cracked, hardened, or flattened rubber grommet
Motor bracket that feels loose or vibrates excessively against its housing
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This motor damper grommet directly replaces the following OEM and cross-reference part numbers:
5040JA2004A, 1268010, AP4635690, AH3526229, EA3526229, PS3526229, EAP3526229, PD00027884
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This motor damper grommet is compatible with select LG refrigerators, and also fits select Kenmore refrigerators built on the LG platform, including model numbers such as LSXS26386S00, LTCS20030S/00, LTC24380SB00, LRSCS21935SW, LFC24770ST/02, LSXS26326W/01, and Kenmore 795.79043311, 795.51089011, 795.51832412, 795.79412810, and 795.78032211.
Note: This is the rear-position grommet. LG also lists a related grommet, part number 5040JA2009B, used as a support damper for fan motors on other models — the two are not necessarily interchangeable, so confirm your exact part number and position before ordering. Always verify your full model number before ordering. Contact our support team with your model number if you're unsure.
Key Features
Genuine LG OEM part — factory-specified rubber compound and fit
Isolates the fan motor from its bracket, cushioning it against vibration
Resolves "rattling," "buzzing," and "vibration noise" symptoms caused by a worn or failed grommet
Rear-position grommet
Durable rubber construction designed for the refrigerator's cold operating environment
Direct drop-in replacement — no tools required on most models
Replaces 5040JA2004B, 1268010, AP4635690, AH3526229, EA3526229, PS3526229, EAP3526229, and PD00027884
Compatible with LG and select Kenmore refrigerators
Genuine OEM replacement — guaranteed fit, materials, and performance
Product Specifications
Part Number
5040JA2004A
Part Type
Fan Motor Damper Grommet — Rear
Condition
Genuine OEM
Brand
LG
Material
Rubber
Function
Isolates and cushions a fan motor from vibration at its bracket
Position
Rear
Related Part
5040JA2009B (support damper, different position/models — verify before substituting)
Repair Difficulty
Very Easy — typically no tools required
Quantity
1 damper grommet
Compatible Brands
LG, Kenmore
Installation Notes
⚠️ Unplug Refrigerator Before Starting Disconnect power at the outlet before beginning, and move perishable food to a cooler if access requires opening the freezer compartment. Wear work gloves. Access depends on your model — this grommet supports a fan motor that may be located behind the freezer's rear interior panel or in the compressor/machine compartment at the back or bottom of the unit, so check your model's service diagram for the exact location. Remove any panel screws needed to reach the motor bracket. Photograph the grommet's position and how it seats against the bracket before removing it. Gently remove the old, worn grommet from around the motor mounting post — it typically pulls or presses off without tools. Press the new 5040JA2004A grommet into the same position, seating it fully so it cushions the motor bracket evenly. Reassemble any panels removed for access, restore power, and run the refrigerator for a while to confirm the rattling or vibration noise has resolved. Tools needed: Phillips screwdriver (for panel access), work gloves.
Frequently Asked Questions
My refrigerator has developed a rattling noise from the back. Is this the grommet?
Yes, this is a common cause of exactly that symptom. Once the rubber grommet cracks, hardens, or loses its cushioning shape, the fan motor's mounting bracket is no longer properly isolated and can vibrate directly against the surrounding housing, producing a rattling or buzzing noise — especially noticeable whenever the fan motor is actively running.
Is this for the evaporator fan motor or the condenser fan motor?
Sources describe this grommet's application somewhat differently depending on the specific refrigerator model — some reference it as supporting the evaporator fan motor, others the condenser fan motor. In practice, this reflects that LG uses the same grommet design for fan motor mounting in more than one location depending on the model. Confirm your full model number against the compatibility list, or check your appliance's parts diagram, to be certain which motor this grommet supports on your specific unit.
Do I need any tools to replace this?
The grommet itself is tool-free — it simply presses into place around the motor mounting post. You will likely need a screwdriver to remove whatever panel is covering the area where the motor and grommet are located, but the grommet swap itself requires no tools.
Is this an OEM or aftermarket part?
This is a genuine OEM part, manufactured by LG to factory specifications — guaranteed fit, materials, and performance. It matches the original rubber compound and mounting fit of the motor damper grommet originally installed in your refrigerator.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Genuine OEM Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
5040JA2009B Genuine OEM LG Refrigerator Motor Damper Grommet (Front)
The 5040JA2009B is a genuine LG OEM front evaporator motor grommet for LG and select Kenmore refrigerators, and also fits select freezers. This rubber grommet cushions and secures the front side of the evaporator fan motor's mount, reducing vibration and noise as the motor runs. It's the front-position counterpart to our 5040JA2004A rear grommet — LG mounts this evaporator fan motor from both the front and rear with matching grommets working together.
Made of rubber, this grommet naturally degrades from prolonged use, exposure to the freezer's cold temperatures, or physical damage from an accidental impact during cleaning or organizing. Once it fails, the evaporator motor loses proper cushioning and can shift slightly out of alignment. Symptoms of a bad grommet include increased noise and vibration, particularly noticeable when the evaporator fan motor is running, along with a rattling or buzzing sound coming from the freezer area. It directly replaces AP4443769, 1268013, AH3526237, EA3526237, PS3526237, and 5040JQ2003B.
Quick Answer
The 5040JA2009B Genuine OEM LG Refrigerator Motor Damper Grommet (Front) fixes LG and select Kenmore refrigerators with increased noise or vibration from the evaporator fan motor, or a rattling/buzzing sound from the freezer area. Rubber, front-position grommet for the evaporator fan motor. Replaces AP4443769, 1268013, AH3526237, EA3526237, PS3526237, 5040JQ2003B. This is the front counterpart to our 5040JA2004A rear grommet — both support the same evaporator fan motor from opposite sides.
Common Problems This Part Fixes
Increased noise or vibration from the evaporator fan motor
Rattling or buzzing sound coming from the freezer area
Noise that's especially noticeable when the fan motor is running
Evaporator motor that has shifted slightly out of alignment
Visibly cracked, hardened, or damaged rubber grommet
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This motor damper grommet directly replaces the following OEM and cross-reference part numbers:
5040JA2009B, AP4443769, 1268013, AH3526237, EA3526237, PS3526237, 5040JQ2003B
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This front evaporator motor grommet is compatible with select LG refrigerators and freezers, and also fits select Kenmore refrigerators built on the LG platform, including model numbers such as LFXC24726S, LMXS30776S, LSC27950ST, LFC20760SB, LFX25960SB, and LFX28968ST/02.
Note — front grommet, not rear: This is the front-position evaporator motor grommet. The matching rear-position grommet for the same motor is a separate part, our 5040JA2004A listing. Both are typically checked and often replaced together, since they support the same motor and are usually the same age. Always verify your full model number before ordering. Contact our support team with your model number if you're unsure.
Key Features
Genuine LG OEM part — factory-specified rubber compound and fit
Cushions and secures the front side of the evaporator fan motor mount
Resolves "increased motor noise," "vibration," and "rattling/buzzing from the freezer" symptoms
Front-position counterpart to our 5040JA2004A rear grommet
Durable rubber construction designed for the freezer's cold operating environment
Direct drop-in replacement — no tools required for the grommet itself
Replaces AP4443769, 1268013, AH3526237, EA3526237, PS3526237, and 5040JQ2003B
Compatible with LG and select Kenmore refrigerators and freezers
Genuine OEM replacement — guaranteed fit, materials, and performance
Product Specifications
Part Number
5040JA2009B
Part Type
Front Evaporator Motor Grommet
Condition
Genuine OEM
Brand
LG
Material
Rubber
Function
Cushions and secures the front side of the evaporator fan motor mount
Position
Front
Related Part
5040JA2004A (rear-position grommet for the same motor, sold separately)
Repair Difficulty
Moderate — freezer teardown required for access
Quantity
1 damper grommet
Compatible Brands
LG, Kenmore
Installation Notes
⚠️ Unplug Refrigerator Before Starting — Photograph Wiring Before Disconnecting Disconnect power at the outlet before beginning, and move perishable food to a cooler for the duration of the repair. Wear work gloves. Access to the evaporator motor on many models requires going in through the freezer: empty the top half of the freezer, remove the side rails holding the ice bin, then remove the outer screws holding the ice auger assembly — on many models this means only the two outer screws on each side, not the middle ones. With the ice maker components clear, remove the rear panel to access the evaporator fan motor and its front and rear grommets. Photograph the wiring connections carefully before disconnecting anything, since several wires can look interchangeable but are not, and reconnecting one in reverse can cause a malfunction. Remove the old front grommet from the motor mount — it typically pulls free without tools. Press the new 5040JA2009B grommet into the same position, seating it fully. If the rear grommet is also worn, this is a good time to replace it as well since you already have access. Reassemble the ice maker components, rear panel, and any other parts removed for access, restore power, and run the refrigerator for a while to confirm the noise or vibration has resolved. Tools needed: Phillips screwdriver, work gloves.
Frequently Asked Questions
Should I replace the rear grommet at the same time as this front one?
It's worth considering. Both grommets support the same evaporator fan motor from opposite sides and are typically the same age, so if one has degraded, the other is often not far behind. Since accessing the motor for this repair already requires a fair amount of teardown, replacing both together — our 5040JA2004A rear grommet and this front one — saves you from repeating the same access work again soon after.
Why do I need to go through the ice maker to reach this part?
On many LG refrigerator models, the evaporator fan motor and its grommets sit behind the freezer's ice maker assembly, so reaching them requires removing the ice bin, its side rails, and the auger mechanism first. This is a more involved access path than some other freezer repairs, so budget extra time and take photos as you go to keep track of how everything reassembles.
Why is it so important to photograph the wiring before disconnecting?
Several of the wires in this area can look similar and are easy to connect in reverse or in the wrong position, which can cause a malfunction after reassembly. Taking clear photos of each connection before you disconnect anything is a simple step that prevents a frustrating troubleshooting session later.
Is this an OEM or aftermarket part?
This is a genuine OEM part, manufactured by LG to factory specifications — guaranteed fit, materials, and performance. It matches the original rubber compound and mounting fit of the front evaporator motor grommet originally installed in your refrigerator.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Genuine OEM Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
XPARTCO WR51X10055 Refrigerator Defrost Heater Assembly
The XPARTCO WR51X10055 is an aftermarket replacement refrigerator defrost heater and bracket assembly compatible with a wide range of GE, Hotpoint, Kenmore, Haier, Americana, Monogram, and Café refrigerators. The defrost heater is a glass quartz tube heater mounted on a bracket below the evaporator coils in the freezer compartment. During each automatic defrost cycle, the heater energizes and melts any frost that has accumulated on the evaporator coils — maintaining unobstructed airflow through the coils so the refrigerator can cool efficiently. When the heater fails, frost accumulates on the coils unchecked, blocking airflow and causing both the freezer and fresh food sections to gradually warm up.
Rated at 120V, 725W, this single quartz tube heater assembly measures 12-1/8" L x 3-3/8" W x 2-1/8" H and includes the heater element and mounting bracket. It directly replaces WR51X10030, AP3183311, 914088, AH303781, EA303781, PS303781, SH323, and EAP303781. Often replaced together with the defrost thermostat (WR50X10068) and temperature sensor (WR55X10025) for a complete defrost system repair. Installs in 20–30 minutes with basic hand tools.
Quick Answer
The XPARTCO WR51X10055 Refrigerator Defrost Heater Assembly fixes GE and Hotpoint refrigerators where frost is building up on the evaporator coils, the freezer is too warm, the fresh food section is warming up, or the refrigerator is running continuously without cooling properly. Single quartz tube heater, 120V / 725W. Assembly measures 12-1/8" L x 3-3/8" W x 2-1/8" H. Includes heater and bracket. Replaces WR51X10030, AP3183311, 914088, SH323, and more. Compatible with GE, Hotpoint, Kenmore, Haier, Americana, Monogram, and Café.
Common Problems This Part Fixes
Frost or ice buildup covering the evaporator coils in the freezer compartment
Freezer section warming up or not maintaining set temperature
Fresh food section warming up even though the freezer is running
Refrigerator running continuously but not cooling properly
Visible frost accumulation on the freezer back wall behind the panel
Defrost heater element visibly burned out, broken, or dark/charred at the ends
Both compartments gradually warming up after working normally for years
Replaces Part Numbers
This defrost heater assembly directly replaces the following OEM and cross-reference part numbers:
WR51X10055, WR51X10030, 914088, AGE29323, AH303781, AP3183311, EA303781, EAP303781, PD00001004, PS303781.
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This defrost heater is compatible with select refrigerators from the following brands:
GE refrigerators (side-by-side, French door, top-freezer, and bottom-freezer)
Hotpoint refrigerators
Kenmore / Sears refrigerators (select GE-built models)
Haier refrigerators (select GE-platform models)
Americana refrigerators
Monogram refrigerators
Café refrigerators
Tip: When replacing the defrost heater, it is highly recommended to also replace the defrost thermostat (WR50X10068) and temperature sensor (WR55X10025) at the same time. These three parts form the defrost system and are commonly replaced together — replacing all three prevents a second disassembly if another component fails soon after.
Key Features
Single quartz tube glass heater — melts frost from the evaporator coils during each automatic defrost cycle, maintaining airflow and cooling efficiency
Rated 120V / 725W — correct electrical specifications for compatible GE refrigerators
Assembly dimensions: 12-1/8" L x 3-3/8" W x 2-1/8" H — direct fit into the evaporator coil bracket
Includes heater element and mounting bracket — complete assembly ready to install
Replaces WR51X10030 and WR51X10055 — both older and current part numbers covered
Compatible with GE, Hotpoint, Kenmore, Haier, Americana, Monogram, and Café refrigerators
Often replaced together with WR50X10068 defrost thermostat and WR55X10025 temperature sensor
Aftermarket replacement built to OEM-equivalent quality standards
DIY repair — installs in 20–30 minutes with basic hand tools
Product Specifications
Part Number
WR51X10055
Also Replaces
WR51X10030
Part Type
Refrigerator Defrost Heater and Bracket Assembly
Condition
Aftermarket Replacement
Heater Type
Single quartz tube glass heater
Voltage
120V AC
Wattage
725W
Dimensions
12-1/8" L x 3-3/8" W x 2-1/8" H
Includes
Heater element and mounting bracket
Often Replaced With
WR50X10068 Defrost Thermostat, WR55X10025 Temperature Sensor
Compatible Brands
GE, Hotpoint, Kenmore, Haier, Americana, Monogram, Café
Installation Notes
⚠️ Unplug Refrigerator Before Starting — Wear Work Gloves Unplug the refrigerator before beginning. Remove all food and shelving from the freezer compartment. Remove the freezer bottom drawer and the back panel screws (typically 2 hex-head screws). Slide out the back panel to expose the evaporator coils and defrost heater assembly. If the coils are covered in frost or ice, use a hair dryer to melt the ice before removing the heater — do not chip or force the heater free while iced over, as the glass element is fragile and will break. Disconnect the heater wires from the wiring harness — note the orientation before disconnecting. Remove the 2 Phillips screws securing the heater bracket and lift the heater assembly out. Install the new WR51X10055 heater assembly in the same position, reconnect the wires, and reinstall the bracket screws. Reinstall the back panel, shelving, and food. Restore power and verify the defrost cycle operates normally. Wear work gloves throughout — the evaporator area has sharp edges. Tools needed: Phillips screwdriver, 1/4" nut driver, hair dryer (if coils are iced over), work gloves.
Frequently Asked Questions
What does the refrigerator defrost heater do?
Modern refrigerators use an automatic defrost system that periodically runs a defrost cycle — typically once or twice a day — to melt frost that accumulates on the evaporator coils during normal operation. The defrost heater is a glass quartz heating element that energizes during this cycle and melts the frost off the coils. This keeps the coils clear so air can flow freely through them to cool the refrigerator. When the heater fails, frost builds up unchecked on the coils over days or weeks — eventually blocking airflow completely and causing both compartments to warm up, even though the compressor is still running.
How do I know if my defrost heater has failed?
Remove the freezer back panel to expose the evaporator coils. If the coils are heavily coated in frost or solid ice — especially if both the freezer and refrigerator sections have been warming up — a failed defrost heater is the most likely cause. You can confirm with a multimeter: disconnect the heater and probe both wire ends. A working heater shows continuity (resistance between approximately 10–200 ohms at room temperature depending on wattage). No continuity confirms the heater element has burned out. Also visually inspect the glass tube — a burned, blackened, or broken tube is a clear sign of failure.
Should I also replace the defrost thermostat and temperature sensor?
Yes — since the freezer must be fully emptied and the back panel removed to replace the heater, it is highly recommended to also replace the defrost thermostat (WR50X10068) and temperature sensor (WR55X10025) at the same time. All three components form the defrost system and wear at similar rates. A failed thermostat or sensor can cause the heater to run too long or not at all — replacing all three in a single repair eliminates that risk and saves you from another complete freezer teardown in the near future.
My freezer is warming up but the compressor is running — is it the defrost heater?
It often is — but not always. A compressor that is running but not cooling can be caused by a failed defrost heater (frost blocking airflow), a faulty evaporator fan motor (air not circulating), a defrost thermostat or timer failure, or a sealed system problem (refrigerant leak or compressor issue). The easiest way to distinguish a defrost system failure from other causes is to open the freezer and check whether frost has built up on the back panel or coils. If yes, the defrost heater is the most likely culprit. If the coils are clear and the compressor is running, look at the evaporator fan or sealed system next.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine GE OEM part, but is manufactured as a single quartz tube glass heater rated at 120V/725W to match the dimensions and performance of the original WR51X10055 defrost heater assembly.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout
XPARTCO WR17X11653 Refrigerator Dispenser Ice Door Flapper
The XPARTCO WR17X11653 is an aftermarket replacement ice door flapper, also sold as the dispenser door assembly, ice chute door or door recess assembly, for GE, Hotpoint and Kenmore side-by-side refrigerators, replacing GE part WR17X11653. It sits in the ice chute opening, seals the freezer against warm room air, and opens when the dispenser lever is pressed so ice can reach your glass.
If the door is cracked, warped, or its gasket no longer seals, warm air gets into the chute and the dispenser suffers. Check your model number before ordering, as the kit may include more than one piece.
Quick Answer
The XPARTCO WR17X11653 Ice Door Flapper replaces the ice chute door on a compatible GE, Hotpoint or Kenmore refrigerator when it is cracked, warped, or no longer seals. Classic symptoms: door sweating, frost buildup at the chute, or ice not dispensing.
Common Problems This Part Fixes
Ice dispenser door sweating
Frost buildup around the ice chute
Ice not dispensing
Cracked, warped or damaged ice door
Worn rubber gasket leaking air into the freezer
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This ice door flapper directly replaces the following part numbers:
WR17X11653, WR17X3093, WR17X3492, AGE28222, AH964304, AP3672582, EA964304, EAP964304, PD00001157, PS964304
If your old part shows a different number, contact our support team and we'll check whether it matches.
Compatibility
This ice door flapper is listed for GE, Hotpoint and Kenmore side-by-side refrigerators, including these examples:
GE TPH21PRSABB, TPH21PBSAWW, TFX20JRSBAD
GE DSE26JSEBCSS, DSF25KGTABG, DSF26DHWABB, CSK28DRBBAA
Kenmore 3639544313, 3639537713, 3639542623
Note: The models above are a small sample. One retailer lists this part for over 1,000 models. Check your full model number against your parts diagram, or contact our support team to verify fit before ordering.
Key Features
Aftermarket replacement for the GE WR17X11653 ice door flapper
Seals the ice chute opening against warm room air
Opens when the dispenser lever is pressed to release ice
Replaces a cracked, warped or leaking ice door
Product Specifications
Part Number
XPWR17X11653
OEM Part Number
WR17X11653
Part Type
Refrigerator Dispenser Ice Door Flapper
Condition
Aftermarket Replacement
Application
Select GE, Hotpoint and Kenmore Side-by-Side Refrigerators
Installation Notes
⚠️ Unplug Power Before Installing Unplug the refrigerator and move perishable food to a cooler before you begin. Wear work gloves. A Phillips screwdriver and a small flat-blade screwdriver are typically needed. No installation instructions are included with the part, so keep your model's parts diagram handy and note how the old door and any springs or pieces come apart before removing them. Install the new door the same way, then restore power and test the dispenser.
Frequently Asked Questions
What does the ice door flapper do?
It seals the ice chute opening to keep warm room air out of the freezer, and it opens when you press the dispenser lever so ice can drop into your glass.
How do I know if my ice door needs replacing?
Look for a cracked or warped door, a damaged rubber gasket, door sweating, or frost buildup around the chute. Ice that won't dispense can also point to the door.
Is this an OEM or aftermarket part?
This is an aftermarket replacement from XPARTCO, made to replace GE part WR17X11653. If you specifically need a genuine GE part, contact our support team.
Will this fit my refrigerator?
It is listed for a large number of GE, Hotpoint and Kenmore side-by-side models, but the list above is only a sample. Check your full model number against your parts diagram, or contact our support team and we'll verify it before you order.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout
XPARTCO W10316760 Refrigerator Thermistor Sensor
The XPARTCO W10316760 is an aftermarket replacement temperature thermistor compatible with a wide range of Whirlpool-built refrigerators sold under the Whirlpool, KitchenAid, Maytag, Jenn-Air, Amana, Inglis, and Magic Chef brands. The thermistor sits inside the fresh food or freezer compartment and continuously reports internal temperature back to the electronic control board, which uses that reading to cycle the compressor, evaporator fan, and damper to keep the compartment in range. When the thermistor drifts out of calibration or fails outright, the control board loses an accurate temperature signal and the refrigerator commonly responds with erratic cooling, a warmer-than-normal compartment, food freezing when it shouldn't, or a flashing/blank temperature display.
This XPARTCO version is built with a quick-connect mounting clip, so it plugs in without cutting or splicing wires — unlike the genuine Whirlpool OEM part, which ships as a splice-in kit requiring you to cut the old thermistor's leads and join the new ones with included wire connectors. It directly replaces W10316760, WPW10323459, W10323459, 12791417, 12791417SP, 12791419SP, 1876627, W10280385, W10280386, W10308052, W10316760VP, W10438639, W10438761, W10452402, AH2580944, AP4538142, AWP40532, EA2580944, EAP2580944, PD00006590, PS2580944, and additional cross-reference numbers listed below. Installs in 15–30 minutes with basic hand tools.
Quick Answer
The XPARTCO W10316760 Refrigerator Thermistor Sensor fixes Whirlpool, KitchenAid, Maytag, Jenn-Air, Amana, Inglis, and Magic Chef refrigerators that are running warm, running constantly, freezing food unexpectedly, or showing a flashing/blank temperature display. This version uses a quick-connect clip — no wire cutting or splicing like the genuine Whirlpool splice-kit version requires. Replaces W10316760, WPW10323459, W10323459, 12791417, 12791417SP, 12791419SP, 1876627, W10280385, W10280386, W10308052, W10316760VP, W10438639, W10438761, W10452402, AH2580944, AP4538142, AWP40532, EA2580944, EAP2580944, PD00006590, PS2580944. Classic symptom: fridge or freezer running warmer than the setting, or running nonstop.
Common Problems This Part Fixes
Refrigerator or freezer running noticeably warmer than the temperature setting
Fridge running constantly and never cycling off
Temperature display flashing, showing dashes, or displaying an error code
Food freezing in the fresh food compartment when it shouldn't be
Compressor and fans not cycling normally, or running nonstop
Inconsistent or swinging temperature readings on the display
One compartment (fridge or freezer) running warm while the other stays normal
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This refrigerator thermistor directly replaces the following OEM and cross-reference part numbers:
W10316760, WPW10323459, W10323459, 12791417, 12791417SP, 12791419SP, 1876627, W10280385, W10280386, W10308052, W10316760VP, W10438639, W10438761, W10452402, AH2580944, AP4538142, AWP40532, EA2580944, EAP2580944, PD00006590, PS2580944
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This thermistor is used across a wide range of Whirlpool-built refrigerators from the following brands:
Whirlpool refrigerators (including WRF535SMBM00, WRX735SDBM00, and related French door / side-by-side models)
KitchenAid refrigerators (including KBFS22EWBL1, KBFS22EWMS1, KBFS22EWMS3, KBFS22EWMS5, KBFS22EWMS7, KBFS22EWWH1)
Maytag refrigerators (select Whirlpool-built models, including KRFF302ESS)
Jenn-Air refrigerators (select Whirlpool-built models, including MFI2269VEM)
Amana refrigerators (select models)
Inglis refrigerators (select models)
Magic Chef refrigerators (select models)
Note: Many of these refrigerators use separate thermistors for the fresh food and freezer compartments, so confirm which sensor location your model uses before ordering — appearance can be similar across positions. Always verify your appliance model number before ordering. Contact our support team with your model number if you're unsure.
Key Features
Direct-fit replacement refrigerator temperature thermistor — reports compartment temperature to the electronic control board
Resolves "running warm," "running constantly," "freezing food," and "flashing display" symptoms caused by thermistor failure
Quick-connect mounting clip — no wire cutting or splicing required
Matches OEM electrical resistance curve for accurate temperature sensing
Approximate lead length ~5 inches
Replaces W10316760, WPW10323459, W10323459, 12791417, 12791417SP, 12791419SP, 1876627, W10280385, W10280386, W10308052, W10316760VP, W10438639, W10438761, W10452402, AH2580944, AP4538142, AWP40532, EA2580944, EAP2580944, PD00006590, PS2580944, and additional cross-reference numbers
Compatible with Whirlpool, KitchenAid, Maytag, Jenn-Air, Amana, Inglis, and Magic Chef refrigerators
Aftermarket replacement built to OEM-equivalent quality standards
Quick DIY repair — installs in 15–30 minutes with basic hand tools
Product Specifications
Part Number
XPW10316760
OEM Part Number
W10316760
Part Type
Refrigerator Temperature Thermistor / Sensor
Condition
Aftermarket Replacement
Application
Whirlpool-Built Refrigerators (Fresh Food / Freezer Compartment)
Mounting
Quick-connect clip (no splicing)
Approx. Lead Length
~5 inches (may vary by model)
Compatible Brands
Whirlpool, KitchenAid, Maytag, Jenn-Air, Amana, Inglis, Magic Chef
Installation Notes
⚠️ Disconnect Power Before Starting Unplug the refrigerator or shut off power at the breaker before accessing internal panels. Locate the thermistor at its mounting position inside the fresh food or freezer compartment (location varies by model — consult your model's parts diagram if unsure). Photograph the wire routing before disconnecting. On this XPARTCO version, simply unplug the old thermistor's connector from the wiring harness — no cutting or splicing needed. Release the old thermistor from its mounting clip or bracket and remove it. Install the new thermistor in the same position, securing it in its mounting clip. Plug the new thermistor's connector into the wiring harness, matching your photos. Reassemble any panels removed for access. Restore power and allow the refrigerator several hours to stabilize before checking temperatures. Tools needed: nut driver or screwdriver (for panel access), needle-nose pliers (for mounting clip).
Frequently Asked Questions
Is this the same as the genuine Whirlpool W10316760 thermistor?
It's a direct-fit aftermarket equivalent, not the genuine Whirlpool part. The key functional difference is installation: the genuine OEM version ships as a splice-in kit requiring you to cut the old wires and use included splice connectors, while this XPARTCO version has a quick-connect clip that simply plugs in — no splicing tools needed.
Will this fit my refrigerator?
W10316760 and its cross-reference numbers span a wide range of Whirlpool-built models across several brands. Confirm fit using your refrigerator's exact model number before ordering, since visually similar thermistors are used across different platforms and compartment locations. Contact our support team with your model number if you're unsure.
My fridge is warm but the freezer is fine (or vice versa) — could this part be the cause?
Yes. Most of these refrigerators use separate thermistors for the fresh food and freezer compartments, so a single failed sensor can cause one section to run warm while the other stays normal. Confirm which sensor location your model uses before ordering.
Do I need any tools to install this?
Basic hand tools to access the interior panel (typically a nut driver or screwdriver) plus needle-nose pliers to release the old mounting clip. Because this version uses a plug-style connector, no wire strippers, cutters, or splice connectors are needed — unlike the genuine OEM splice-kit version.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is manufactured to match the electrical resistance curve, mounting position, and temperature-sensing function of the original W10316760 thermistor used in compatible Whirlpool, KitchenAid, Maytag, Jenn-Air, Amana, Inglis, and Magic Chef refrigerators.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout
XPARTCO W10350564 Refrigerator Run Capacitor Replaces WPW10350564
The XPARTCO W10350564 is an aftermarket replacement compressor run capacitor compatible with a wide range of Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Roper, Admiral, Ikea, and Kenmore refrigerators and freezers. The run capacitor is a small but critical electrical component mounted near the compressor at the back of the refrigerator — it delivers a phase-shifted power boost that helps the compressor motor start at the beginning of each cooling cycle, and supports smooth, efficient motor operation while the compressor runs. When the capacitor fails — typically from dielectric breakdown, age, heat, or moisture intrusion — the compressor may fail to start, hum without starting, kick on and off repeatedly, or cause inconsistent cooling throughout the refrigerator.
Rated 12 µF (MFD) ±5% capacitance, 180VAC, 50/60Hz. This capacitor works together with the compressor start relay/start device — the two components are frequently replaced together, since a failed capacitor often stresses the relay and vice versa. It directly replaces WPW10350564, W10350564, AP6020176, PS11753490, EAP11753490, and 2683570. This is one of the most cost-effective refrigerator repairs — a failed run capacitor mimics symptoms of a failed compressor (a far more expensive repair), so testing and replacing the capacitor first can save hundreds of dollars. Installs in about 15 minutes with basic hand tools.
Quick Answer
The XPARTCO W10350564 Refrigerator Run Capacitor fixes Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, and Kenmore refrigerators and freezers where the compressor won't start, hums without starting, kicks on and off, or the fridge/freezer is too warm with inconsistent cooling. 12 µF (MFD) ±5%, 180VAC, 50/60Hz. Replaces WPW10350564, AP6020176, PS11753490, EAP11753490, 2683570. Often replaced together with the compressor start relay. A 15-minute repair that can save you from misdiagnosing a "failed compressor."
Common Problems This Part Fixes
Compressor won't start — no power boost from the failed capacitor
Compressor hums or clicks but doesn't start running
Compressor kicks on and off repeatedly (short cycling)
Refrigerator and freezer too warm — cooling cycles not completing
Fridge too warm while freezer seems okay — weak compressor operation
Noticeable humming sounds from the back of the refrigerator
Inconsistent cooling and variable temperatures inside the refrigerator
Refrigerator will not start at all
Capacitor visibly bulged, leaking, or burned
Capacitance test reads significantly off from 12 µF
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This run capacitor directly replaces the following OEM and cross-reference part numbers:
WPW10350564, W10350564, PD00030179, EAP11753490, AP6020176, AWP50050, PS11753490.
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This run capacitor is compatible with select refrigerators and freezers from the following brands:
Whirlpool refrigerators — French door, side-by-side, and bottom-mount models (including WRX735SDBM00 and related WRX/WRF series)
Maytag refrigerators (select models)
KitchenAid refrigerators (select models)
Jenn-Air refrigerators (select models)
Amana refrigerators (select models)
Magic Chef refrigerators (select models)
Roper refrigerators (select models)
Admiral refrigerators (select models)
Ikea refrigerators (select Whirlpool-built models)
Kenmore / Sears refrigerators (select Whirlpool-built models)
Also fits compatible upright and chest freezers on the Whirlpool platform
Note: The run capacitor works together with the compressor start relay/start device. When one fails, the other has typically been stressed by the same electrical events — many repair scenarios call for replacing both at the same time since both are accessible in the same location and the combined parts cost is still far below a service call. Always verify your model number before ordering.
Key Features
Compressor run capacitor — delivers the phase-shifted power boost that starts the compressor motor and supports smooth operation during cooling cycles
Rated 12 µF (MFD) capacitance with ±5% tolerance — precise match to OEM electrical specifications
180VAC, 50/60Hz rating for compatible refrigerator compressor circuits
Resolves "compressor won't start," "humming but not starting," "short cycling," and "too warm" symptoms when caused by capacitor failure
A cost-effective first repair — failed capacitors commonly mimic the symptoms of a far more expensive failed compressor
Replaces WPW10350564, AP6020176, PS11753490, EAP11753490, and 2683570
Compatible with Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Roper, Admiral, Ikea, and Kenmore refrigerators and freezers
Often replaced together with the compressor start relay/start device as a paired repair
Aftermarket replacement built to OEM-equivalent quality standards
Quick DIY repair — installs in about 15 minutes with basic hand tools
Product Specifications
Part Number
W10350564
OEM Part Number
WPW10350564
Part Type
Refrigerator Compressor Run Capacitor
Condition
Aftermarket Replacement
Application
Refrigerators and Freezers (Whirlpool platform)
Capacitance
12 µF (MFD)
Tolerance
±5%
Voltage
180V AC
Frequency
50/60 Hz
Mounting Location
Near compressor, rear of refrigerator
Often Paired With
Compressor Start Relay / Start Device
Compatible Brands
Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Roper, Admiral, Ikea, Kenmore
Installation Notes
⚠️ Capacitor Safety Warning — Stored Electrical Charge Capacitors store an electrical charge even after the refrigerator is unplugged. Before handling the old capacitor, discharge it safely: with the refrigerator unplugged, touch the blade of an insulated-handle screwdriver across both capacitor terminals simultaneously to short them together (you may see or hear a small spark — that's the stored charge dissipating). Never touch the capacitor terminals with bare hands before discharging. If you're not comfortable with this step, have the repair done by a qualified appliance technician.
⚠️ Unplug Refrigerator Before Starting — Wear Work Gloves Unplug the refrigerator and pull it away from the wall to access the rear. Safely store any food that could spoil if the repair takes longer than expected. Wear work gloves to protect your hands. The run capacitor is located near the compressor at the bottom rear of the refrigerator, typically behind a lower rear access panel. Remove the screws holding the access panel and set it aside. Locate the capacitor — a small rectangular or oval component connected to the compressor's start relay/start device by wire terminals. Photograph the wire connections before disconnecting anything. Discharge the old capacitor before touching the terminals (see the safety warning above). Disconnect the wire terminals from the old capacitor — note which wire goes to which terminal. Release the capacitor from its mounting clip or bracket. Install the new W10350564 capacitor in the same position, secure the mounting clip, and reconnect the wires to the same terminals as photographed. While the panel is open, inspect the start relay/start device on the side of the compressor — if it rattles when shaken, shows burn marks, or has corroded terminals, replace it at the same time. Reinstall the rear access panel, push the refrigerator back into place, plug it in, and listen for the compressor to start smoothly within a few minutes. Allow several hours for the refrigerator to return to its set temperature. Tools needed: Phillips screwdriver, 1/4" nut driver, insulated-handle flathead screwdriver (for discharging), needle-nose pliers, work gloves.
Frequently Asked Questions
How do I know if the run capacitor has failed and not the compressor?
This is the key question — because a failed $15–30 capacitor produces nearly identical symptoms to a failed $300+ compressor. Signs pointing to the capacitor: the compressor hums or clicks but won't start; the compressor tries to start, runs briefly, then shuts off (short cycling); or the refrigerator gradually stopped cooling with humming from the rear. To test: unplug the refrigerator, discharge the capacitor, disconnect it, and measure it with a multimeter that has a capacitance setting — a healthy capacitor reads close to 12 µF (within ±5%). A reading far off, zero, or infinite confirms the capacitor has failed. Visual signs like bulging, leaking, or burn marks also confirm failure. Given the low cost, replacing the capacitor (and start relay) first is the standard diagnostic approach before condemning the compressor.
Should I replace the start relay at the same time?
Yes, it's strongly recommended. The run capacitor and the compressor start relay/start device work together in the compressor's starting circuit — the relay switches power to the start winding while the capacitor provides the phase-shifted boost. When one fails, the other has typically been stressed by the same electrical events (voltage spikes, overheating, repeated failed start attempts). Both components are inexpensive, mounted in the same location on or near the compressor, and accessible in the same repair session. A quick relay check: with the refrigerator unplugged, remove the relay and shake it — if it rattles, the internal components have failed and it needs replacement.
Why does the capacitor need to be discharged before handling?
Capacitors store electrical energy — that's their job. Even after the refrigerator is unplugged, the capacitor can hold a charge capable of delivering a painful (and potentially dangerous) shock when you touch both terminals. Before handling, always discharge the capacitor by shorting both terminals together with the blade of an insulated-handle screwdriver — touch the metal blade across both terminals at once and hold for a second or two. You may see a small spark as the charge dissipates; that's normal. After discharging, the capacitor is safe to handle. This takes five seconds and eliminates the shock risk entirely.
What's the difference between a run capacitor and a start capacitor?
Both assist the compressor motor but in different phases of operation. A start capacitor delivers a large, brief boost only during the initial moment of motor startup, then is switched out of the circuit. A run capacitor — like the W10350564 — stays in the circuit continuously while the motor runs, providing an ongoing phase shift that improves the motor's running efficiency and torque. Household refrigerators on the Whirlpool platform typically use a run capacitor working alongside the start relay/start device. Match the replacement to your original: the W10350564 is a 12 µF, 180VAC run capacitor, and the capacitance rating must match for correct compressor operation.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is manufactured to match the electrical specifications (12 µF ±5%, 180VAC, 50/60Hz), terminal configuration, and compressor-support function of the original WPW10350564/W10350564 run capacitor used in compatible Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, and Kenmore refrigerators and freezers.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout
Genuine GE OEM Refrigerator Part
GE WR14X29279 Freezer Genuine OEM Door Gasket
White magnetic freezer-door gasket for select GE, Haier, and Hotpoint top-mount refrigerators.
Product Overview
WR14X29279 is a Genuine GE OEM freezer door gasket. The gasket seals around the freezer door to help keep warm, humid room air from entering the freezer compartment.
A torn, hardened, twisted, or poorly sealing gasket can contribute to frost buildup, temperature instability, longer compressor run times, and moisture around the freezer opening.
Quick Answer
This listing is for one white Genuine GE OEM freezer door gasket, part WR14X29279. It is used on select compact GE, Haier, and Hotpoint top-mount refrigerators. Verify the complete appliance model number before ordering.
Common Problems This Part May Fix
Torn or cracked freezer door gasket
Visible gaps around the freezer door
Frost or moisture near the door opening
Warm air entering the freezer compartment
Freezer door does not seal tightly
Refrigerator runs longer because of an air leak
Replaces and Cross-References
WR14X29279, 312240100333, AP6328743, AGE28324, PD00077451
Cross-reference numbers are provided for identification. Always verify fit by complete appliance model number.
Compatibility
Compatible with select GE, Haier, and Hotpoint compact top-mount refrigerators. Verified model examples include:
HA10TG21BSW
HA10TG21CSW
HA10TG21SW
HA12TG21SW
HPS10LGVBRWW
VPS10FGMAWW
VPS10FGMBWW
VPS10FGMCWW
Partial model list only. Similar refrigerators may use a different fresh-food or freezer gasket depending on cabinet size, door color, and production revision.
Key Features
Genuine GE OEM replacement part
Freezer door gasket / magnetic seal
White finish
Helps prevent warm-air infiltration
Designed for select GE, Haier, and Hotpoint refrigerators
Factory-fit replacement for compatible models
Product Specifications
Part Number: WR14X29279
Brand: GE Appliances
Part Type: Freezer Door Gasket
Color: White
Condition: New
Quality: Genuine OEM
Package Quantity: 1 Gasket
Installation Notes
Unplug the refrigerator before service.
Temporarily move food to a safe cold location while the freezer door is open.
Remove the original gasket according to the appliance service procedure.
Install the replacement evenly around the door perimeter, making sure all corners and edges are fully seated.
Close the door and inspect the entire perimeter for gaps.
Shipping crease tip: If the gasket arrives folded or creased, warm it gently with warm water or a hair dryer on low heat, then allow it to relax into shape. Do not overheat the gasket.
Frequently Asked Questions
Is WR14X29279 the freezer gasket or refrigerator-door gasket?
WR14X29279 is the freezer door gasket. The fresh-food door can use a different gasket on the same refrigerator.
Is this Genuine GE OEM?
Yes. WR14X29279 is a Genuine GE Appliances replacement part.
Is the gasket white?
Yes. This part is the white freezer-door gasket version.
Can I install it if it arrives with folds?
Yes. Shipping folds can usually be relaxed by gently warming the gasket before installation.
Shop With Confidence
For best results, compare your complete refrigerator model number before ordering. Door gaskets can look nearly identical while differing in size, magnetic profile, color, or mounting design.
Genuine GE OEMFreezer Door GasketWhiteCompatibility Support
ERP 6750CL0001D Refrigerator Compressor Overload Protector
Fits Specific LG, Kenmore Refrigerator Models.
This Compressor Overload is an essential replacement part designed specifically for Specific Kenmore brand refrigerators. Compatible with a wide range of LG models, this overload ensures optimal cooling performance and extends the lifespan of your refrigerator.
Replaces Part Number 6750CL0001D, AH3603394, EA3603394, AP5331981, PS3603394.
This is an aftermarket part that can be used as a replacement for the OEM part.
California Residents only
WARNING: California’s Proposition 65
XPARTCO DA82-01415A Refrigerator Water Leak Service Kit
Water leak repair kit with updated internal duck bill.
Fits select Samsung refrigerator models.
Replaces Part Numbers: DA82-01415A, 3436781, AP5957964, PS10058968.
Description: This Water Leak Repair Kit is a replacement part for select Samsung refrigerator models, this field service kit used to address water leakage and excessive frost in bottom freezer or French door refrigerators with dual evaporators. The kit includes a drain probe, two drain tubes, and two silver foam strips. With these parts, you can prevent excessive frost buildup on the evaporator cover and fix issues like water leaks under the crisper or odd fan noises that stop when the doors are opened.
This is an aftermarket part that can be used as a replacement for the OEM part
