318258203 Genuine OEM Frigidaire Range Radiant Bridge Surface Burner Element
The 318258203 is a Genuine OEM Frigidaire replacement radiant bridge surface burner element compatible with select Frigidaire, Electrolux, and Kenmore electric ranges and cooktops. This is a dual surface bridge element — it spans two separate burner zones and bridges them together to create one large, elongated heating surface ideal for griddles, fish pans, and oversized cookware. Rated at 1800W / 2600W, it uses an exposed resistance wire (haliant-style) to generate heat directly on the glass-ceramic cooktop surface.
As a Genuine OEM part manufactured by Frigidaire to factory specifications, the 318258203 is a direct factory-exact replacement. It also replaces the earlier 7318258203 part number. The element uses exposed resistance wire to heat the cooking surface — note that minor surface cracks in the glass covering do not affect heating performance. Before installation, photograph the original element's wire terminal connections so you can reconnect the new element correctly. Always unplug the range before beginning. Installs in 20–30 minutes with basic hand tools.
Quick Answer
The 318258203 Genuine OEM Frigidaire Radiant Bridge Surface Burner Element fixes electric ranges where the bridge burner zone is not heating, heats unevenly, or the element has visibly burned out. Dual bridge element rated 1800W/2600W. Haliant-style exposed resistance wire. Replaces 7318258203. Compatible with Frigidaire, Electrolux, and Kenmore electric ranges. Genuine OEM — factory-exact fit and performance.
Common Problems This Part Fixes
Bridge burner zone not heating at all when activated
Bridge element heating only on one side — uneven heating across the element
Visible burn marks, breaks, or open spots on the resistance wire
Bridge burner zone glowing on one side but not the other
Element cycles on and off erratically instead of maintaining steady heat
Cooktop surface shows discoloration or hot spots directly above the element area
Replaces Part Numbers
This burner element directly replaces the following OEM and cross-reference part numbers:
318258203, 1197704, 7318258203, AH1529079, AFR16668, AP3965799, EA1529079, PD00057059, PS1529079.
Contact our support team with your model number if you need confirmation before ordering.
Compatibility
This bridge surface element is compatible with select electric ranges and cooktops from the following brands:
Frigidaire electric ranges and cooktops
Electrolux electric ranges and cooktops
Kenmore / Sears electric ranges (Frigidaire/Electrolux-built models)
Always verify your appliance model number before ordering. Contact our support team if you're unsure.
Key Features
Genuine OEM part manufactured by Frigidaire to factory specifications — guaranteed fit and performance
Dual bridge element — spans two burner zones to create one large elongated cooking surface for griddles and oversized cookware
Rated 1800W / 2600W — dual-power design for large-surface cooking flexibility
Haliant-style exposed resistance wire heating — heats the glass-ceramic surface directly and efficiently
Replaces 7318258203 and cross-references AH1529079, AFR16668, AP3965799, EA1529079, PD00057059, PS1529079.
Compatible with Frigidaire, Electrolux, and Kenmore electric ranges
Note: photograph terminal wiring before removal to ensure correct reconnection
Product Specifications
Part Number
318258203
Also Replaces
7318258203
Part Type
Radiant Bridge Surface Burner Element (Dual / Haliant-style)
Condition
Genuine OEM
Application
Electric Ranges and Cooktops (glass-ceramic surface)
Wattage
1800W / 2600W (dual power)
Element Type
Haliant — exposed resistance wire on element surface
Element Style
Bridge (spans two burner zones)
Compatible Brands
Frigidaire, Electrolux, Kenmore
Installation Notes
⚠️ Unplug Range Before Starting Unplug the range or turn off the circuit breaker before beginning. Allow the cooktop to cool completely before touching the element. Photograph the existing element's terminal wiring connections before disconnecting anything — the terminal block connections must be replicated exactly on the new element. Lift the glass-ceramic cooktop surface by opening the front and removing the retaining screws (typically under the front trim), then prop the top open. Unplug the element's terminal connections from the terminal block. Remove the element bracket screws and lift the old element out. Position the new 318258203 element in the same location, secure the mounting bracket, and reconnect the terminal wires in the same positions as documented in your photo. Lower the cooktop, restore power, and test both bridge element power settings. Note: do not touch the haliant wire surface of the element during installation. Tools needed: Phillips screwdriver, 1/4" nut driver.
Frequently Asked Questions
What is a bridge burner element and what is it used for?
A bridge burner element connects two adjacent burner zones on a glass-ceramic electric cooktop into one elongated heating surface. When activated, the bridge element heats the entire combined area — ideal for using a griddle, roasting pan, fish pan, or any large flat-bottomed cookware that spans more than one standard burner. When the bridge is not in use, each adjacent zone functions as its own independent standard burner. The bridge element activates when the bridge control is selected on the range's control panel.
What is a haliant element and how is it different from a standard radiant element?
A haliant (also called halogent or exposed coil radiant) element uses resistance wire that is partially exposed on the surface of the element body, rather than sheathed inside a smooth glass tube. Both types heat the glass-ceramic surface above them, but haliant elements tend to heat up faster and can reach higher surface temperatures than sheathed radiant elements. Minor surface cracks in the element's glass material do not affect heating performance — the resistance wire is what generates heat, and it functions independently of the outer covering.
How do I test if the bridge element has failed?
The most reliable test is a continuity check with a multimeter. Unplug the range, lift the cooktop, and disconnect the element's terminal wires. Probe the element's terminal connections with a multimeter set to resistance mode. A working element will show a resistance reading (typically between 10–100 ohms for the heating coil). An open circuit (no continuity / infinite resistance) confirms the element has burned out. You can also visually inspect the haliant wire for visible breaks, dark spots, or melted areas — any visible break in the wire confirms failure.
Why is it important to photograph the terminal wiring before removing the old element?
Bridge elements have multiple terminal connections for the dual power settings (1800W and 2600W). The wires must be connected to the correct terminals on the new element to ensure both power levels work correctly. If the wires are connected in the wrong order, the element may not heat at all, heat only on one setting, or may not be protected by the correct thermal limiter. Always take a clear photo of the old element's terminal connections before disconnecting anything, and use that photo as a reference when connecting the new element.
Is this a Genuine OEM or aftermarket part?
This is a Genuine OEM part manufactured by Frigidaire to factory specifications. It is the exact same bridge surface element installed in compatible Frigidaire and Electrolux ranges from the factory — guaranteed fit, materials, and performance.
