Cooking Appliances Parts

XPARTCO WB2K101 Burner Grate Rubber Foot Replaces Part Numbers: WB2K101, ERWB2K101, 247410, AH241358, EA241358, AP2622260, PS241358, WB02K0101  Rubber feet for gas burner grate, kit of 4  Fits in a 3/16" hole   This is an aftermarket part that can be used as a replacement for the OEM part.

Read more less

ERP 316011200 Range Top Burner Spark Igniter Electrode The 316011200 is an aftermarket replacement gas range surface burner spark igniter electrode compatible with select Frigidaire, Tappan, Electrolux, Gibson, Kelvinator, White-Westinghouse, Kenmore, and Danby gas ranges and cooktops. The spark igniter electrode is the ceramic-and-metal tip mounted next to each surface burner that generates the electrical spark needed to ignite the gas when a burner knob is turned. When the electrode cracks, corrodes, or its internal wiring degrades, it will produce a weak or absent spark — causing the burner to not light, to require a long hold of the ignition button, or to click repeatedly without igniting. Made from porcelain and metal, each electrode measures 3/4"L x 1/2"W x 1-3/8"H and is sold individually. One electrode is used per surface burner — most gas ranges have 4 or 6 surface burners, each with its own electrode. It directly replaces AP2123862, 5303311262, 464, AH436633, EA436633, EAP436633, PS436633, LP11343, and PD00000522. Installs in 15–30 minutes depending on model disassembly required. Note: While this part is involved in a gas appliance, the electrode itself is not a gas component — it carries only a low-voltage electrical signal from the ignition module. Always unplug the range and shut off the gas before beginning any repair. Quick Answer The 316011200 Range Top Burner Spark Igniter Electrode fixes Frigidaire-platform gas ranges where a surface burner won't light, requires a long hold to ignite, sparks continuously without lighting, or produces a weak clicking sound. Porcelain/metal, 3/4"L x 1/2"W x 1-3/8"H. Sold individually — one per burner. Compatible with Frigidaire, Tappan, Electrolux, Gibson, Kelvinator, White-Westinghouse, Kenmore, and Danby gas ranges. Replaces AP2123862, 5303311262, 464, EA436633, PS436633, LP11343. Common Problems This Part Fixes Surface burner will not light — electrode not producing a spark Burner requires holding the ignition knob for an extended time before the gas lights Burner sparks repeatedly (rapid clicking) without ever lighting the gas One burner does not spark while all others work normally — that burner's electrode has failed Weak or intermittent spark at a specific burner Electrode visibly cracked, chipped, or tip broken off Corrosion or moisture damage to the electrode tip or wiring from a cooking spill Replaces Part Numbers This spark igniter electrode directly replaces the following OEM and cross-reference part numbers: 316011200, 5303311262, AFR16248, AH436633, AP2123862, EA436633, EAP436633, LP11343, PD00000522, PS436633. If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This spark igniter electrode is compatible with select gas ranges and cooktops from the following brands: Frigidaire gas ranges and cooktops Tappan gas ranges and cooktops Electrolux gas ranges (select models) Gibson gas ranges Kelvinator gas ranges White-Westinghouse gas ranges Kenmore / Sears gas ranges (Frigidaire/Electrolux-built models) Danby gas ranges (select models) Note: This electrode is sold individually — one electrode per burner. Most gas ranges have 4 or 6 surface burners, each with its own electrode. If multiple burners are not lighting, you may need to order multiple electrodes. Always verify your model number before ordering to confirm this electrode fits the specific burner assembly on your range. Key Features Generates the electrical spark that ignites the gas at each surface burner when the ignition knob is turned Porcelain insulator body with metal electrode tip — designed to withstand continuous thermal cycling near the burner flame Dimensions: 3/4"L x 1/2"W x 1-3/8"H — matches original electrode dimensions for compatible Frigidaire-platform models Sold individually — one electrode per surface burner; order one per failed burner Replaces AP2123862, 5303311262, 464, EA436633, PS436633, LP11343, and EAP436633 Compatible with Frigidaire, Tappan, Electrolux, Gibson, Kelvinator, White-Westinghouse, Kenmore, and Danby gas ranges Aftermarket replacement built to OEM-equivalent quality standards DIY repair — installs in 15–30 minutes with basic hand tools Product Specifications Part Number 316011200 Part Type Gas Range Surface Burner Spark Igniter Electrode Condition Aftermarket Replacement Application Gas Ranges and Cooktops Material Porcelain / Metal Color White / Gray Dimensions 3/4"L x 1/2"W x 1-3/8"H Sold As Single electrode (one per burner) Compatible Brands Frigidaire, Tappan, Electrolux, Gibson, Kelvinator, White-Westinghouse, Kenmore, Danby Installation Notes ⚠️ Gas Appliance Safety — Unplug and Shut Off Gas Before Starting This part is installed on a gas range. Always unplug the range from the power outlet and shut off the gas supply at the shutoff valve before beginning any repair. If you smell gas at any point during or after installation, leave the area immediately and contact your gas utility provider. Do not restore gas or power until the repair is complete and you have confirmed there are no gas connections disturbed during the repair. ⚠️ Range Top Access May Require Lifting the Cooktop On most Frigidaire-platform gas ranges, the spark igniter electrodes are mounted beneath the cooktop surface and accessed by lifting the top panel — this requires removing all grates and burner caps, then lifting the top from the front. The electrode is secured by a single screw and connected to the ignition module by an insulated wire. Disconnect the wire, unscrew the mounting screw, and remove the old electrode. Install the new 316011200 electrode in the same position, tighten the mounting screw, and reconnect the wire. Important: inspect the insulated wire carefully for damage — if the wire is cracked or bare in any section, it may arc to the stove body and should be repaired with heat-resistant tape or replaced before installing the new electrode. Restore gas and power and test the burner. Tools needed: Phillips screwdriver, possibly a nut driver for some models. Frequently Asked Questions What does the spark igniter electrode do? The spark igniter electrode is the small ceramic-and-metal tip mounted next to each surface burner on a gas range. When you turn a burner knob to the "light" or "ignite" position, the ignition module sends a high-voltage electrical pulse through the wire to the electrode tip. This creates a visible electrical spark that jumps between the electrode tip and the metal burner cap, igniting the gas. The electrode itself carries only a brief electrical pulse — it does not directly handle gas — but it must be in good condition with an intact porcelain body and clean metal tip to produce a reliable, consistent spark. One burner won't light but all the others work — is it the electrode? Almost certainly yes. When all other burners spark normally but one does not, the fault is almost always isolated to that burner's electrode or its connecting wire — not the ignition module (which powers all burners) or the gas supply (which feeds all burners). Inspect the electrode on the non-lighting burner: look for cracks, chips, or a broken tip on the porcelain body. Also check the connecting wire for corrosion at the connection point or damage to the insulation. Replacing the 316011200 electrode on that burner will restore normal ignition in most cases. My burner clicks continuously even when not trying to ignite — what causes this? Continuous clicking when no burner is being lit is typically caused by moisture or food residue on the electrode tip or in the burner cap area creating an unintended electrical path — the ignition module detects a spark condition and keeps firing. Clean the electrode tip, burner cap, and burner head thoroughly with a dry cloth or soft toothbrush, and allow them to dry completely. If cleaning stops the clicking, a cracked or degraded electrode that is allowing moisture to reach the internal wiring is the likely underlying cause — replace the electrode to prevent recurrence. If the clicking persists after the burner area is completely clean and dry, the ignition module may be faulty. How many electrodes does my gas range need? Each surface burner on a gas range has its own dedicated spark igniter electrode — one electrode per burner. A standard 4-burner gas range uses 4 electrodes; a 5- or 6-burner range uses 5 or 6. This listing is for a single electrode. If multiple burners are not lighting, order one electrode for each affected burner. When replacing one electrode, it is a good opportunity to inspect all other electrodes for cracks or corrosion and replace any that show visible wear at the same time. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Frigidaire OEM part, but is manufactured from porcelain and metal to match the dimensions and performance of the original 316011200 surface burner spark igniter electrode. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout

Read more less

(2 Pack) 20A Ceramic Fuse 6.35 x 32 mm, 20A 250V - Compatible with GE, Whirlpool, Kenmore, Maytag, Frigidaire, LG, Samsung and Other Appliances Product Description Protect your appliances with the replacement 20A Slow-Blow Ceramic Fuse 6.35 x 32 mm, 20A 250V. This high-quality time-delay (slow-blow) ceramic cartridge fuse is designed for GE, Whirlpool, Kenmore, and other appliances like microwaves, washers, dryers, and spa control systems. With a ceramic body for durability and heat resistance, this fuse (6.35 x 32 mm, 20A, 250V AC) safeguards circuits from over current and short circuits while tolerating brief surges. It addresses issues like appliance failure, power loss, or blown fuses.  Note: Includes one ceramic fuse. Disconnect power before installation. Verify fuse size and rating match your appliance’s requirements. Replaces part numbers: EXP20A, MDA-20, 0326020.HXP, 0326020.MXDP, BK1-MDP-20-R, BK-MDP-V-20-R, GSA20, 8020.0605, 8020.0605.G, WB27X10388, AP3094537, AH334641, EA334641, EAP334641, PS334641, WP4375321, W11305892, W11305905, AP6009296, PS11742452, 3601-001198, AP4046006, PS4131369, 5F1CD2031S, AP4565040, 1206681, 4922155, WB27X11151, AP4980434, PS3486702, WB27X11151, AP4980434, PS3486702, WB2X3910, PS242167, AP2010811, WB2X3910, WB27X995, WB27X945, B27X10388, PS239525, AP2631556, WP8183507, 8183507, PS11745084, AP6011884, M0805101, AP6014669, PS11747931, WPM0805101, 5304423383, PS472662, AP2151673, EA472662, WB27X10928, AP3994062, WB27X10388, AH1481237, EA1481237, PS1481237, W11707984, W10138793, AP7225218, PS17629444, 3B74133Q, AP4440371, PS3522743, 5F1CD0202S, 5F1CD2031S, 3B74133K. AH3522741, EA3522741, AP4438152, PS3522741. Compatibility: Compatible with appliances including but not limited to: GE Microwaves: JE1860SH04, JVM1540SM5SS, JVM1440WH04 Whirlpool Microwaves: MH1150XMQ0, MH2175XSB0 Kenmore Microwaves: 721.62649200, 665.68612800 Whirlpool Washers: WTW5300SQ0, LSQ9544KQ0 Whirlpool Dryers: WED5300SQ0 Balboa Spa Control Systems: 30123 Other Brands: KitchenAid, Maytag, Amana, Hotpoint, and other appliances requiring 6.35 x 32 mm, 20A 250V slow-blow fuses Verify your model number or contact our support team for assistance. Key Features: ✅ Brand and Models Compatibility: Fits select GE, Whirlpool, Kenmore, KitchenAid, Maytag, Amana, Hotpoint, LG, Samsung and other appliances requiring 6.35 x 32 mm, 20A 250V fuses. 🔥 Specifications: replacement slow-blow ceramic fuse, 6.35 x 32 mm (1/4" x 1-1/4"), 20A, 250V AC, ceramic body, time-delay, 3.35–3.5 mOhms resistance, cylindrical, holder/clip mount. 💰 Cost-Effective Alternative: replacement fuse offers OEM-equivalent performance at a lower price. 🛠️ Easy Installation: Requires insulated gloves, needle-nose pliers; typically installed in 5–15 minutes. 🛡️ Reliable Fixes: Resolves appliance failure, power loss, or blown fuse issues in microwaves, washers, dryers, and spa systems. Installation Notes: Safety First: Disconnect the appliance from the power source before installation. Shop Parts-O-Matic for high-quality replacement appliance parts with a 30-day return policy. Keep your appliances running safely and efficiently today! Add to cart now for a budget-friendly fix!

Read more less

XPARTCO WB24X10115 Range Hood Membrane Switch Replaces: WB24X10115, WB24X10004, 1086006, AH953533, EA953533, AP3203483, PS953533. California Residents only WARNING: Cancer and/or Reproductive Harm - www.p65warnings.ca.gov

Read more less

XPARTCO WB27X10542 Range Vent Hood Fuse – Compatible with GE and Hotpoint Range Hoods Product Description Protect your vent hood electronics from power surges and overheating with the XPARTCO WB27X10542 Range Vent Hood Fuse. This high-quality aftermarket replacement fuse interrupts electrical current when excessive heat or voltage occurs, safeguarding the control board and motor. A blown fuse can cause the vent hood lights or fan to stop working. Replacing it with this durable XPARTCO fuse restores safe, reliable operation at a fraction of the OEM cost. Replaces Part Numbers WB27X10542, 946789, AH239683, EA239683, PD00040792, AP3185501, PS239683. Compatibility This replacement line fuse fits select GE and Hotpoint range hoods. Example compatible models include (but are not limited to): GE JV347H1WW, GE JV348L1SS, and Hotpoint RVM1535DM1BB. Always verify your vent hood’s model number before ordering. Contact our support team if you’re unsure. ✅ Key Features 🔄 Aftermarket Replacement – Matches OEM performance for GE range hoods ⚡ Electrical Protection – Prevents control board and motor damage from power surges 💰 Budget-Friendly Fix – Reliable replacement at a lower cost than OEM 🛠️ Quick Installation – Direct-fit design requires only basic tools 🛡️ Fixes Common Issues – Solves power loss, fan not running, or lights not turning on 📐 Product Specification Part Number: WB27X10542 Component Type: Range Hood Line Fuse - FUSE 5 A 125V Material: Ceramic and metal fuse with insulated leads Mounting: Inline wiring harness or control board clip Operating Conditions: Rated for high-temperature kitchen environments Compliance: Built to OEM-equivalent safety standards (not OEM) 🛠️ Installation Notes Tools Needed: Phillips screwdriver, needle-nose pliers ⚠️ Safety First: Always unplug the range hood or switch off the circuit breaker before performing repairs to prevent electrical shock. Steps: Disconnect power to the range hood. Remove the cover or control panel to access the fuse holder. Carefully disconnect the old fuse from its terminals. Install the new XPARTCO WB27X10542 fuse in the same orientation. Replace the cover, restore power, and test operation. ⏱️ Time Required: 10–15 minutes 📦 Shop With Confidence 🚚 Free Shipping on All Orders ⚙️ Trusted Appliance Parts Supplier 🔄 30-Day Return Policy Restore safe vent hood operation — Add to Cart Now for a reliable, cost-effective repair!

Read more less

XPARTCO S97018253 Range Vent Hood Light Fuse The replacement S97018253 Range Vent Hood Light Fuse is designed for select Broan range hood models. This replacement fuse protects the range hood’s light circuit from power surges or faults. Ideal for restoring functionality to select Broan range hoods experiencing light-related issues, such as non-functioning lights or intermittent power. Note: Disconnect power before installation. Handle glass fuse carefully. Replaces part numbers: S97018253, 1930589, 97018253, AP5616207, PS10280886. Compatibility (S97018253): Compatible with select Broan range hood models, including but not limited to: Broan: QP2, QP3, QP4 series (e.g., QP230BC, QP230BL, QP230SS, QP236BC, QP236BL, QP236SS, QP236WW, QP242BC, QP242BL, QP242SS, QP242WW, QP330BL, QP330SS, QP330WW, QP336BL, QP336SS, QP336WW, QP342BL, QP342SS, QP342WW, QP430SS, QP436SS, QP442SS) Verify your model number or contact our support team for assistance. Key Features (S97018253): ✅ Brand Compatibility: Fits select Broan range hood models. 🔥 Specifications: Replacement fuse, 8A, 120V, glass fuse (5x20mm), heat-resistant. 💰 Cost-Effective Alternative: Offers OEM-equivalent performance at a lower price. 🛠️ Easy Installation: Requires basic tools (e.g., screwdriver, pliers); typically installed in 10–15 minutes. 🛡️ Reliable Fixes: Addresses range hood light issues like non-functioning lights or intermittent power. Installation Notes (S97018253): Safety First: Disconnect the appliance from the power source before installation. Location: Typically found in the upper left corner of the range hood control board; remove filters and bottom pan to access. Tools: Use a screwdriver to access the control board and pliers to remove and install the fuse. Shop Parts-O-Matic for high-quality replacement appliance parts with a 30-day return policy. Get your microwave or range hood running today! Add to cart now for a budget-friendly fix!

Read more less

WB24X25013 Surface Element Infinite Switch - Compatible with GE Electric Ranges JB645, JB655, JB750, JS645, JS760 Product Description Restore precise heat control to your GE electric range with the Genuine OEM WB24X25013 Surface Element Infinite Switch. This authentic GE switch regulates the heat output of surface burners (240VAC, 15A), ensuring reliable and consistent cooking performance for select GE models, including JB645, JB655, JB750, JS645, and JS760. It resolves issues like burners not heating, overheating, or only operating at high settings. Note: Includes one infinite switch. Disconnect power before installation. Take a photo of existing wiring for reference. Replaces part numbers: WB24X25013, PD00040820, EAP11729102, AP5999509, PS11729102, 191D4774P005, MDSA-W767-GEM. Compatibility: Compatible with models including but not limited to: GE: JB645DK4BB, JB645RK4SS, JB645RK5SS, JB645DK5BB, JB645DK6BB, JB645RK6SS, JB655SK3SS, JB655SK4SS, JB750DJ9BB, JB860DJ2BB, JB860EJ2ES, JB860SJ5SS, JS645SL3SS, JS645EL1ES, JS645FL2DS, JS760SL4SS Hotpoint, RCA, Kenmore: Select models requiring WB24X25013 Verify your model number or contact our support team for assistance. Key Features: ✅ Brand and Models Compatibility: Fits select GE, Hotpoint, RCA, and Kenmore electric ranges. 🔥 Specifications: Genuine OEM infinite switch, 240VAC, 15A, rotary/dial-type with variable resistor. 💯 Authentic GE Quality: Provides factory-standard performance and durability. 🛠️ Easy Installation: Requires Phillips screwdriver, needle-nose pliers, work gloves; typically installed in 10–15 minutes. 🛡️ Reliable Fixes: Addresses burners not heating, overheating, or lack of heat adjustment. Product Specification Part Number: WB24X25013 Switch Type: Infinite, rotary/dial Voltage Rating: 240VAC Current Rating: 15A Input Range: 2-9% Material: Heat-resistant plastic and metal Dimensions: 2.5" x 2.5" x 2" (approximate, including shaft) Weight: 2.0 oz Operating Conditions: Suitable for high-temperature range control panels Compliance: UL-listed components, Prop 65 warning for California Installation Notes: Safety First: Disconnect the range from the power source or shut off the circuit breaker before installation. Shop for high-quality Genuine OEM appliance parts with a 30-day return policy. Get your range cooking perfectly today! Add to cart now for a reliable fix!

Read more less
