154825001 Genuine OEM Frigidaire Dishwasher Heating Element
The 154825001 is a genuine Frigidaire OEM round heating element that sits exposed at the bottom of the dishwasher tub. Unlike a hidden element concealed beneath the tub floor, this is a visible ring-shaped element you can see sitting right in the bottom of the wash chamber. It serves two jobs: it heats the wash water to the temperature needed to properly dissolve detergent and break down grease and food soil, and at the end of the cycle it provides the heat that drives the drying phase, helping moisture evaporate off your dishes rather than leaving them wet.
Mounted through a 0.98" hole with two mounting nuts and connected by two wire terminals, this element carries a pair of white alignment dots that must line up with the tub's retaining clips during installation. Over time, mineral buildup from hard water, general corrosion, or simple electrical wear can cause the element to fail. A failing or dead element produces a specific and recognizable pattern: water never gets hot enough to clean effectively, dishes come out wet at the end of the cycle instead of dry, and the whole cycle may run noticeably longer as the dishwasher's control tries to compensate. It directly replaces AP5628696, 154482901, 154663801, 2308825, PS3653449, and EAP3653449. As a genuine OEM part, the 154825001 is manufactured by Frigidaire to factory specifications — guaranteed fit, materials, and performance.
Quick Answer
The 154825001 Genuine OEM Frigidaire Dishwasher Heating Element fixes Frigidaire, Kenmore, Electrolux, Crosley, Gibson, Kelvinator, Tappan, and Westinghouse dishwashers with dishes that don't get properly clean, dishes that come out wet instead of dry, or cycles that take longer than they used to. Exposed round heating element, 0.98" mounting hole, 2 wire terminals. Replaces AP5628696, 154482901, 154663801, 2308825, PS3653449, EAP3653449. Before replacing, test the old element with a multimeter for resistance — a bad control board relay can produce identical symptoms with a perfectly good element.
Common Problems This Part Fixes
Dishes not getting properly clean because wash water isn't reaching the correct temperature
Dishwasher not drying dishes — items come out wet at the end of the cycle
Cycle taking noticeably longer than usual to complete
Visible damage, corrosion, or discoloration on the element itself
Element that doesn't glow or heat up when the wash cycle is running
Water leaking near the high-temperature wire connector at the element terminals
Mineral scale buildup visible on or around the element
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This dishwasher heating element directly replaces the following OEM and cross-reference part numbers:
154825001, 154482901, 154663801, 2308825, AP5628696, AFR14520, EAP3653449, PD00000951, PS3653449.
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This heating element is compatible with select Frigidaire, Electrolux, Kenmore, Crosley, Gibson, Kelvinator, Tappan, and Westinghouse dishwashers, spanning a wide range of model series including BBBD, BGBD, BGHD, DGBD, DGCD, DGHD, FDB, FDBB, FDBD, FFBD, FFID, FGBD, FGCD, FGHD, FGID, FPHD, FPID, GLD, GSB, LEDB, LFBD, LFID, LGBD, LGHD, and PLD.
Verified model numbers include: FFCD2413UW1A, FGID2466QF4A, FGID2466QF5A, FFID2426TD1A, FGBD2438PF4A, FGHD2465NF1A, FGHD2433KF1, LFID2426TF1A, LFID2422RF0A, LFID2422RF3B, LFID2422RF4B, LFID2426TF4A, LFID2426TF5A, LGBD2431LF0A, LGBD2431NF0B, LGBD2431NF1B, LGBD2432LW0A, LGBD2432LW0B, and CDB350/CDB500/CDB900 series models. Also fits Kenmore 587-series, Crosley CBD-series, Kelvinator KADB240, and White-Westinghouse WWBD2400 dishwashers.
Note: This is an exposed round heating element sitting visibly in the bottom of the tub, not a hidden element mounted underneath. It is not interchangeable with hidden/concealed heating elements used on other dishwasher platforms. Always verify your full model number before ordering. Contact our support team with your model number if you're unsure.
Key Features
Genuine Frigidaire OEM part — factory-specified heating output and terminal configuration
Exposed round design sits in the tub bottom for direct water heating and drying support
Resolves "not cleaning properly," "not drying," and "cycle taking too long" symptoms caused by element failure
0.98" mounting hole with two mounting nuts and wire terminals
Two white alignment dots for correct positioning in the tub's retaining clips
Direct drop-in replacement — no modification required
Replaces 154482901, 154663801, 2308825, AP5628696, PS3653449, and EAP3653449
Compatible with Frigidaire, Electrolux, Kenmore, Crosley, Gibson, Kelvinator, Tappan, and Westinghouse dishwashers
Genuine OEM replacement — guaranteed fit, materials, and performance
Product Specifications
Part Number
154825001
Part Type
Dishwasher Round Heating Element (Exposed)
Condition
Genuine OEM
Brand
Frigidaire / Electrolux
Location
Bottom of the wash tub (exposed, visible)
Mounting Hole
0.98 in.
Terminals
2 wire connections + 2 mounting nuts
Alignment
2 white dots must align with tub retaining clips
Repair Difficulty
Medium — basic dishwasher familiarity required
Tools Required
Screwdrivers, wrench set
Quantity
1 heating element
Compatible Brands
Frigidaire, Electrolux, Kenmore, Crosley, Gibson, Kelvinator, Tappan, Westinghouse
Installation Notes
⚠️ Unplug Dishwasher And Shut Off Water Before Starting — Handle The Element Carefully Disconnect power at the circuit breaker and shut off the water supply before beginning. Wear work gloves. On many models you'll need to pull the dishwasher out from under the counter to access the undercarriage — remove the two screws securing the unit to the counter first. Remove the lower rack and the lower spray arm (it typically pushes down and twists to unlock) to access the element inside the tub. From underneath, disconnect the two wires from the element's terminals and remove the two mounting nuts with a 1/2" wrench, taking care not to overtighten when you reach the new element — over-torquing can crush the sealing washers and cause a leak at the connector. Lift the old element free from its retaining clips inside the tub. To install the new 154825001, locate the two white alignment dots on the element and position them so they slide into the tub's retaining clips correctly — this ensures the element seats in its proper orientation. Push the terminals down through the mounting hole, then from underneath, reinstall and tighten the mounting nuts snugly but not excessively. Reconnect the two wires to the terminals, reinstall the lower spray arm and press it down to lock it in place, and reinstall the lower rack. Restore water and power, then slide the dishwasher back into place and secure it to the counter with its mounting screws. Run a test cycle and check underneath for any leaks at the element connection before considering the repair complete. Tools needed: screwdriver, 1/2" wrench, work gloves.
Frequently Asked Questions
How do I know it's the heating element and not something else, like the control board?
Before replacing the element, it's worth testing it with a multimeter for resistance — a healthy element typically reads in the neighborhood of 14 ohms, though exact values vary by model. If the old element tests fine but dishes still aren't drying or getting hot enough, the more likely cause is upstream of the element itself, such as a control board relay that isn't sending power to it correctly. Some owners have replaced a perfectly good element only to find the actual fault was a bad solder connection on the control board relay — testing first can save you an unnecessary purchase.
Can I clean the element instead of replacing it?
Light surface cleaning to remove mineral scale buildup is reasonable and can sometimes help if reduced heating output is due to scale insulating the element. However, if the element tests as an open circuit (no continuity) or shows visible damage, cracking, or corrosion through the metal sheath, cleaning won't restore it — replacement is the correct fix at that point.
I noticed water leaking near the element's wire connector. Is that related?
Yes, this is a documented failure point on this element design — the high-temperature wire connector at the terminals can develop a leak, especially if the mounting nuts were overtightened during a prior installation and damaged the sealing washer. When installing the new element, tighten the mounting nuts snugly but avoid excessive force, which helps prevent this same leak point from recurring.
Do I really need to pull the dishwasher out from under the counter?
On most installations, yes — accessing the mounting nuts and wire terminals underneath the tub requires pulling the unit forward after removing the two screws that secure it to the counter. Some technicians have managed the nut removal with a deep socket without fully pulling the unit, but planning for full access makes the job considerably easier, especially the first time.
Is this an OEM or aftermarket part?
This is a genuine OEM part, manufactured by Frigidaire to factory specifications — guaranteed fit, materials, and performance. It matches the original heating output, mounting configuration, and terminal layout of the element originally installed in your dishwasher.
