XPARTCO 8573713 Gas Dryer Thermal Cut-Off Fuse Replaces WP8573713
The XPARTCO 8573713 is an aftermarket replacement thermal cut-off fuse for Whirlpool, Maytag, Kenmore, Crosley, Amana, and Inglis gas dryers. This fuse is mounted on top of the burner funnel, directly under the drum, and it's a one-time safety device: as long as the dryer stays within its normal operating temperature, it does nothing at all, but the instant temperatures near the burner climb high enough — almost always from restricted airflow — the fuse permanently opens the circuit and cuts power. That's why a blown fuse produces such a specific symptom: the dryer won't heat, even though the drum may still tumble and the rest of the dryer seems to run normally.
Because this fuse sits on the burner funnel underneath the drum rather than on the more accessible blower housing, replacing it is a more involved repair than a typical thermal fuse swap — the drum has to come out of the cabinet to reach it. Unlike a resettable thermostat, this fuse cannot be reset once it blows; it must be replaced. A blown thermal fuse is almost always a symptom rather than a random failure: restricted exhaust venting is the leading cause, since trapped heat near the burner is exactly what this fuse is designed to react to. It directly replaces WP8573713, AP6013467, and PS11746693.
Quick Answer
The XPARTCO 8573713 Gas Dryer Thermal Cut-Off Fuse fixes Whirlpool, Maytag, Kenmore, Crosley, Amana, and Inglis gas dryers that won't heat, even if the drum still tumbles normally. Mounted on the burner funnel under the drum. Replaces WP8573713, AP6013467, PS11746693. Always inspect and clean the dryer venting when replacing this fuse — a blown fuse is a symptom of restricted airflow, and installing a new fuse without fixing the vent will likely blow it again.
Common Problems This Part Fixes
Dryer runs and tumbles but produces no heat
Dryer that stopped heating suddenly, especially after running unusually hot
Drying times that have gotten noticeably longer or clothes coming out damp
Repeated blown fuses on a dryer with a known venting or airflow restriction
Dryer that recently smelled like burning or overheating before losing heat
Continuity test shows an open circuit across the old fuse
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This gas dryer thermal cut-off fuse directly replaces the following OEM and cross-reference part numbers:
WP8573713, 1180872, 8573713, AP3866211, EAP990558, PS990558, AWP49233, PD00006618
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This thermal cut-off fuse is compatible with select Whirlpool gas dryers, and also fits select Maytag, Kenmore, Kenmore Elite, Crosley, Amana, Inglis, and Sears Canada gas dryers built on the Whirlpool platform, including model numbers such as WGD8500SR0, and Kenmore 11070372710 and 11071112020.
Note: This fuse is specific to gas dryers, mounted on the burner funnel. It is not the same fuse used on electric dryer platforms. Always verify your full model number before ordering. Contact our support team with your model number if you're unsure.
Key Features
Aftermarket replacement thermal cut-off fuse — one-time safety device that cuts power if the dryer overheats
Mounted on top of the burner funnel, directly under the drum
Resolves "runs but won't heat," "drying takes too long," and "clothes coming out damp" symptoms caused by a blown fuse
Replaces WP8573713, AP6013467, and PS11746693
Compatible with Whirlpool, Maytag, Kenmore, Kenmore Elite, Crosley, Amana, Inglis, and Sears Canada gas dryers
Aftermarket replacement built to OEM-equivalent quality standards
Product Specifications
Part Number
8573713
OEM Part Number
WP8573713
Part Type
Gas Dryer Thermal Cut-Off Fuse
Condition
Aftermarket Replacement
Application
Gas Dryers
Location
Top of the burner funnel, under the drum
Resettable
No — one-time use, must be replaced once blown
Material
Plastic housing
Dimensions
Approx. 1"H x 1"W
Repair Difficulty
Moderate to Hard — drum removal required for access
Quantity
1 thermal cut-off fuse
Compatible Brands
Whirlpool, Maytag, Kenmore, Kenmore Elite, Crosley, Amana, Inglis, Sears Canada
Installation Notes
⚠️ Gas Safety — Shut Off The Gas Supply Before Starting This fuse sits directly on the burner funnel, close to the gas burner assembly. Before beginning, close the gas shutoff valve behind the dryer in addition to unplugging the dryer or shutting off its circuit breaker. If at any point you smell gas, stop immediately, leave the area, and do not operate any switches — contact your gas utility or a qualified technician. Do not attempt this repair if you are not comfortable working safely around a gas appliance's burner assembly; a qualified technician can complete it instead.
⚠️ Drum Removal Required — Inspect And Clean The Venting Before Reassembling Wear work gloves. This repair requires removing the drum from the dryer cabinet to access the burner funnel, so budget more time and disassembly than a typical thermal fuse swap. Remove the top and front panels according to your model's service diagram, disconnect the drive belt from the idler pulley, and lift the drum out of the cabinet to expose the burner funnel underneath. Photograph the wiring before disconnecting the old fuse's connectors. Test the old fuse for continuity with a multimeter to confirm it's actually blown (no continuity) rather than assuming, and test the new fuse to confirm it's good out of the box. This is the most important step: fully inspect and clean the dryer's exhaust vent, from the lint trap housing all the way to the exterior vent hood, checking for lint buildup, crushed sections, or excessive length. A blown thermal fuse is a symptom of restricted airflow, and skipping this step means the new fuse is likely to blow again. Install the new 8573713 fuse on the burner funnel in the same mounting position, reconnect the wiring, and reassemble the drum, belt, and panels in reverse order. Restore the gas supply and power, and run a test cycle to confirm normal heating and shutoff behavior. Tools needed: Phillips or nut driver (model-dependent), multimeter, vent brush or vacuum attachment for cleaning ductwork, work gloves.
Frequently Asked Questions
My dryer tumbles fine but there's no heat. Is this the right part?
Yes, this is the classic symptom of a blown gas dryer thermal cut-off fuse. Because this fuse only interrupts the heating circuit and not the drive motor, the drum can continue tumbling completely normally while the dryer produces no heat at all. If you've confirmed the burner isn't igniting and the fuse tests as an open circuit, this is very likely the fix.
Why does this repair require removing the drum? My other dryer's fuse didn't need that.
This particular fuse is mounted on the burner funnel underneath the drum rather than on the blower housing at the back of the cabinet, which is where many thermal fuses on other platforms are located. Reaching the burner funnel requires taking the drum out of the cabinet, which is why this repair involves more disassembly than some other thermal fuse replacements.
I replaced the fuse and it blew again. What's going on?
This is a strong sign that the underlying cause — almost always restricted airflow — was never addressed. Thermal fuses don't fail from age; they blow because the dryer overheated. If a new fuse keeps blowing, thoroughly inspect and clean the entire exhaust path from the lint trap housing to the outside vent hood, checking for lint buildup, crushed or kinked ductwork, or a vent run that's too long.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is manufactured to match the electrical specifications and mounting configuration of the original WP8573713 thermal cut-off fuse used in compatible Whirlpool, Maytag, Kenmore, Crosley, Amana, and Inglis gas dryers.
