Refrigerator Evaporator Fan Motors

XPARTCO EAU61524007 Refrigerator Evaporator Fan Motor 13V, 1.5 W, 0.118A. 1-1/2" shaft. Has quick disconnect. Fits specific LG Refrigerator Models. Description:  This ERP EAU61524007 Refrigerator Evaporator Fan Motor is designed for reliable and efficient cooling performance. It features the EAU61524007 model, providing optimal airflow and preserving freshness in your refrigerator. Upgrade your appliance with this high-quality fan motor and enjoy the benefits of improved cooling and longer-lasting food. Replaces Part Numbers:EAU61524007, AP5950081, EAU60694510, PS10058947   This is an aftermarket part that can be used as a replacement for the OEM part.

Read more less

WR60X26866 Genuine OEM GE Refrigerator Axial Evaporator Fan Motor The WR60X26866 is a Genuine OEM GE replacement axial evaporator fan motor manufactured by GE to factory specifications, designed as a direct fit for the fresh food section of select GE French door refrigerators, including the CFE28, CFE29, CWE23, CYE22, CYE23, DFE28, DFE29, GFD28, GFE26, GFE27, GFE28, GFE29, GFS26, GFS28, GNE26, GNE29, GYE22, GYS22, PFD28, PFE28, PFE29, PWE23, PYD22, PYE22, PYE23, and ZWE23 series. The evaporator fan motor pulls air through the evaporator coils to remove heat from the circulating air inside the refrigerator. Without a functioning evaporator fan, the refrigerator compartment cannot maintain its target temperature even when the compressor and condenser are running normally — the cold air generated at the evaporator simply isn't being circulated to the food storage areas. The WR60X26866 is a DC motor rated at 13.6V DC, 0.16A, with a fan housing measuring 3-4/7"L x 2"W x 3-1/8"H, plus a multi-color wire harness and plug approximately 11-1/2" long. It includes the axial fan blade and harness as a complete assembly. It directly replaces WR60X26033, WR60X26030, WR60X24303, WR60X10341, WR60X10356, WR60X10357, WR02X13733, 239D1412P006, V80E14MS2A3-57A611, 8817V-W1, 4546026, AP5985039, AP6278228, EAP12172983, PD00038765, PS11721915, and PS12172983. Important: if your refrigerator was built between May 2014 and March 2015 with serial range FF–HD, the unit's software must be updated before installing this fan motor — see FAQ below. Installs in 20–30 minutes with basic hand tools. Quick Answer The WR60X26866 Genuine OEM GE Refrigerator Axial Evaporator Fan Motor fixes GE French door refrigerators where the fridge isn't cooling but the freezer is cold, the evaporator coils are frosted over, the ice maker isn't working due to insufficient cooling, or there's loud humming or grinding from the freezer area. Axial fan motor, 13.6V DC, 0.16A. Fan housing: 3-4/7"L x 2"W x 3-1/8"H; harness ~11-1/2"L. Replaces WR60X26033, WR60X26030, WR60X24303, WR60X10341, WR60X10356, WR60X10357, WR02X13733, 239D1412P006, V80E14MS2A3-57A611, 8817V-W1, 4546026, AP5985039, AP6278228, EAP12172983, PD00038765, PS11721915, PS12172983. Note: May 2014 – Mar 2015 build refrigerators (serial range FF–HD) require a software update before installation. Common Problems This Part Fixes Refrigerator not cooling properly while the freezer remains cold — classic evaporator fan failure Freezer cold but fridge warm — fresh food compartment air not being circulated Frosty or frozen evaporator coils due to insufficient air circulation Ice maker failure caused by inadequate cooling in the compartment Loud humming, grinding, or buzzing noise from the freezer or fresh food compartment Refrigerator running continuously without reaching set temperature Fan blade not spinning freely or seized when checked by hand Multimeter shows no continuity through the motor windings Replaces Part Numbers This evaporator fan motor directly replaces the following OEM and cross-reference part numbers: WR60X26866, WR02X13733, WR60X10341, WR60X10356, WR60X10357, WR60X24303, WR60X26030, WR60X26033, V80E14MS2A3-57A611, 8817V W1, 239D1412P006, PD00038765, FIX12172983, AGE29673, AP6278228, PS12172983. If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This evaporator fan motor is compatible with select GE French door refrigerators, including: GE refrigerators — CFE28, CFE29, CWE23, CYE22, CYE23 series (CFE28TP2MBS1, CFE28USHNSS, CWE23SP2MBS1, CYE22TP2MBS1 and related) GE refrigerators — DFE28, DFE29 series (DFE28JELCDS and related) GE refrigerators — GFD28, GFE26, GFE27, GFE28, GFE29 series (GFD28GBLBTS, GFE26GGHEBB and related) GE refrigerators — GFS26, GFS28, GNE26, GNE29 series GE refrigerators — GYE22, GYS22 series (GYE22HMKEES and related) GE refrigerators — PFD28, PFE28, PFE29 series (PFE28KELFDS and related) GE refrigerators — PWE23 series (PWE23KSKDSS and related) GE refrigerators — PYD22, PYE22, PYE23 series (PYE22KSKBSS and related) GE refrigerators — ZWE23 series and select related Café and Profile French door models Important — Software Update Requirement: If your GE refrigerator was manufactured between May 2014 and March 2015 with a serial number in the range FF–HD, the refrigerator's control software must be updated by GE factory service (or via Software Update Module WR98R882802) before installing this fan motor. Installing the new motor without the software update on these affected units may result in improper performance. Check your refrigerator's serial number plate before ordering. Key Features Axial evaporator fan motor for the fresh food section of GE French door refrigerators Pulls air through the evaporator coils to remove heat and circulate cold air through the refrigerator compartment DC motor — rated 13.6V DC, 0.16A — runs on DC voltage from the refrigerator control board Includes the axial fan blade and pre-attached multi-color wire harness with plug Fan housing dimensions: 3-4/7"L x 2"W x 3-1/8"H; harness and plug approximately 11-1/2" long Quiet operation — engineered to minimize hum and vibration in the refrigerator cabinet Plastic and metal construction, black housing with multi-color harness Replaces an extensive list of GE part numbers including WR60X26033, WR60X26030, WR60X24303, WR60X10341, WR60X10356, WR60X10357, and additional cross-references Compatible with GE, GE Café, and GE Profile French door refrigerators in the CFE, CWE, CYE, DFE, GFD, GFE, GFS, GNE, GYE, GYS, PFD, PFE, PWE, PYD, PYE, and ZWE series Genuine OEM part manufactured by GE to factory specifications — guaranteed fit and performance DIY repair — installs in 20–30 minutes with basic hand tools Product Specifications Part Number WR60X26866 Part Type Refrigerator Evaporator Fan Motor (Fresh Food / Axial) Condition Genuine OEM Application GE French Door Refrigerators Voltage 13.6V DC Amperage 0.16A Fan Type Axial Fan Housing Dimensions 3-4/7"L x 2"W x 3-1/8"H Harness Length Approximately 11-1/2 inches Color Black housing with multi-color harness Material Plastic / Metal Includes Axial fan motor assembly with harness Software Update Required For May 2014 – Mar 2015 builds (serial range FF–HD) — use WR98R882802 Compatible Brands GE, GE Café, GE Profile Installation Notes ⚠️ Unplug Refrigerator and Move Perishable Food Before Starting — Wear Work Gloves Unplug the refrigerator and safely store any food that could spoil while the power is off. Wear work gloves to protect your hands. The evaporator fan motor for the fresh food section is mounted on the back wall of the fresh food (refrigerator) compartment, behind an access panel. Take a photo of the existing fan position and wire harness routing before disconnecting. Remove the shelves and any internal components blocking access to the back wall, then remove the screws holding the rear access panel in place. Disconnect the fan motor's wire harness connector and remove the mounting screws securing the old motor. Note the fan blade orientation on the motor shaft. Install the new WR60X26866 motor assembly in the same position with the blade facing the same direction, reconnect the wiring harness, and reinstall the mounting screws and access panel. Replace the shelves and other internal components, restore power, and confirm the fan spins and the refrigerator cools properly. Allow several hours for the refrigerator to return to its set temperature before reloading with food. Tools needed: Phillips screwdriver, 1/4" nut driver, work gloves. Frequently Asked Questions My fridge is warm but my freezer is cold — is the evaporator fan motor the problem? Yes — this is one of the most recognizable symptoms of evaporator fan motor failure on GE French door refrigerators with a separate fresh food evaporator. The freezer side has its own cooling circuit and remains cold, while the fresh food side relies on this fan to circulate air across its evaporator coils. When the fan fails, the freezer continues working but the fresh food compartment loses its cold air supply, warming up while the freezer stays at temperature. If you also notice frost building up on the evaporator coils behind the back panel of the fresh food compartment, the fan failure is confirmed. What is the software update requirement for May 2014 – March 2015 refrigerators? GE issued a software update for certain refrigerators manufactured between May 2014 and March 2015 (serial range FF–HD) before they could properly support newer revisions of the WR60X26866 evaporator fan motor. If your refrigerator falls in this date and serial range, the control software must be updated before installing this fan motor — either by GE factory service or by using the Software Update Module part WR98R882802. Installing the new fan on an unupdated unit can result in improper performance. Check the serial number plate inside your refrigerator (typically on the left side wall) to confirm whether your unit is affected. Refrigerators built outside this range do not require the update. How do I test if the evaporator fan motor has failed? Unplug the refrigerator, then access the fan behind the rear panel of the fresh food compartment. First, try turning the fan blade by hand — if it doesn't spin freely, is stiff, or seizes, the motor bearing has failed. Next, listen during normal operation — if the motor is unusually noisy or makes a grinding sound, the bearings are worn even if it still spins. Finally, with the unit unplugged and the motor disconnected, use a multimeter on the motor windings to check for continuity. If the windings show no continuity, the motor has failed electrically. Also check for approximately 11–14V DC at the connector when the refrigerator is running — if voltage is present but the motor doesn't spin, the motor has failed. My fridge has two evaporator fans — which one does this replace? Some GE French door refrigerators have separate evaporator fan motors for the freezer and the fresh food sections. The WR60X26866 is the fresh food evaporator fan motor — it's the axial fan located behind the rear panel of the fresh food compartment, not in the freezer. If your symptom is "freezer cold, fridge warm," this is the correct part. If your symptom is "freezer warm" or "ice maker not making ice but fridge is fine," the freezer evaporator fan motor (a different part number) is more likely the cause. Confirm which compartment has the cooling problem before ordering. Is this an OEM or aftermarket part? This is a Genuine OEM part manufactured by GE to factory specifications. It is the exact same axial evaporator fan motor installed in compatible GE, GE Café, and GE Profile French door refrigerators from the factory — guaranteed fit, materials, and performance. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Fast US Shipping ✓ Genuine OEM Parts ✓ Compatibility Support ✓ Secure Checkout

Read more less

XPARTCO WR60X10185 Refrigerator Evaporator Fan Motor The XPARTCO WR60X10185 is an aftermarket replacement evaporator fan motor located in the freezer compartment, for GE, Hotpoint, and select Kenmore, Haier, Monogram, and Café refrigerators. This motor pulls air across the evaporator coils to strip heat from it, then circulates that cold air through the freezer and, via ducting, to the fresh food compartment. This particular motor does not include a thermistor — it ships as a fan motor with a 4-wire harness on a 6-pin connector, with two of those six pin slots left empty. If your refrigerator's original connector has a white thermistor wire in it, or a separate connector for a freezer light, this is not the correct motor for your unit. Rated 9.75V DC, 3.25W. A fan motor generally has a long service life, but it can burn out quickly if debris or ice buildup obstructs the blade and forces the motor to work against resistance it wasn't designed for. Common symptoms of a failing motor include unusual noise from the freezer, a fresh food compartment that's warmer than it should be while the freezer stays reasonably cold, frost or ice accumulating around the fan or coil, and a refrigerator that runs constantly trying to compensate for lost circulation. It directly replaces AP3875639, 1170107, 197D2039P007, 197D2039P008, PS1019114, EAP1019114, WR23X10346, WR23X10350, WR23X10353, WR23X10355, WR23X10364, WR23X10404, WR23X10405, WR23X10406, WR60X10043, WR60X10059, WR60X10068, WR60X10083, WR60X10084, WR60X10099, WR60X10149, WR60X10152, WR60X10154, and WR60X10157. As an aftermarket replacement, the WR60X10185 is built to OEM-equivalent quality standards. Quick Answer The XPARTCO WR60X10185 Refrigerator Evaporator Fan Motor fixes GE, Hotpoint, and select Kenmore refrigerators where the fresh food section runs warm while the freezer stays cold, there's unusual noise from the freezer, or frost is building up around the coil. 9.75V DC, 3.25W, 4-wire harness on a 6-pin connector (2 pins empty). Does NOT include a thermistor. Replaces AP3875639, 1170107, 197D2039P007, 197D2039P008, PS1019114, WR23X10353, WR23X10355, WR23X10364, WR60X10043, WR60X10154, and others listed below. If your old connector has a white thermistor wire, you need WR60X10074 instead; if it has a light connector, you need WR23X10467. Common Problems This Part Fixes Fresh food compartment running warmer than normal while the freezer stays reasonably cold Unusual noise — humming, buzzing, or grinding — coming from the freezer Freezer not cooling properly, which in turn affects compressor performance Frost or ice buildup accumulating around the fan blade or evaporator coil Refrigerator running continuously as it struggles to maintain temperature Fan motor that has burned out due to an obstruction preventing the blade from turning Fan blade that doesn't spin freely, or doesn't spin at all, when checked by hand Cross Reference Information Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item. Replaces Part Numbers This refrigerator evaporator fan motor directly replaces the following OEM and cross-reference part numbers: WR60X10185, WR60X10043, WR60X10059, WR60X10068, WR60X10083, WR60X10084, WR60X10099, WR60X10149, WR60X10152, WR60X10154, WR60X10157, WR23X10346, WR23X10350, WR23X10353, WR23X10355, WR23X10364, WR23X10404, WR23X10405, WR23X10406, 197D2039P013, 1170107, UDQT26GE4, AP3875639, AGE29155, PD00000986, PS1019114, EAP1019114 If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This evaporator fan motor is compatible with select GE and Hotpoint refrigerators, and also fits select Kenmore, Haier, Monogram, and Café refrigerators built on the GE platform. Note — check your connector before ordering: GE uses several different evaporator fan motor variants that look nearly identical, and choosing the wrong one means the connector or function won't match your refrigerator. This WR60X10185 motor has no thermistor and a plain 4-wire harness with 2 empty slots on its 6-pin connector. If your old motor's connector has a white thermistor wire in it, you need WR60X10074 instead (harness with integrated thermistor). If your old connector instead has a dedicated light connector, you need WR23X10467. This part is also a separate motor from our WR60X10318 listing, which is a side-by-side platform assembly with its own integrated thermistor and a longer harness. Always verify your full model number before ordering. Contact our support team with your model number if you're unsure which motor fits your refrigerator. Key Features Aftermarket replacement built to match GE's factory-specified motor and blade design Pulls air across the evaporator coils and circulates it through the freezer and fresh food compartments Resolves "fresh food warm while freezer stays cold," "unusual noise," and "frost buildup" symptoms caused by fan motor failure Rated 9.75V DC, 3.25W Includes the fan motor and 4-wire harness assembly (does not include thermistor) Direct drop-in replacement matching the original mounting and blade fitment Replaces a wide range of legacy WR23X and WR60X part numbers plus AP3875639 and PS1019114 Aftermarket replacement built to OEM-equivalent quality standards Product Specifications Part Number XPWR60X10185 OEM Part Number WR60X10185 Part Type Refrigerator Evaporator Fan Motor Condition Aftermarket Replacement Brand GE Location Freezer compartment Voltage 9.75V DC Wattage 3.25 W Harness 4-wire, 6-pin connector (2 pins unused) Includes Thermistor No Quantity 1 fan motor Compatible Brands GE, Hotpoint, Kenmore, Haier, Monogram, Café Installation Notes ⚠️ Unplug Refrigerator Before Starting — Check Your Connector Type First Disconnect power at the outlet before beginning, and move perishable food to a cooler for the duration of the repair. Wear work gloves. Before removing the old motor, look closely at its connector: confirm it's a plain 4-wire harness with no thermistor wire and no separate light connector, matching this replacement. Access is through the freezer's rear interior panel: remove shelving and bins as needed, then remove the screws securing the back panel to expose the evaporator coil and fan assembly. If there's significant frost or ice around the fan or coil, let the unit sit unplugged with the door open for a few hours, or run a manual defrost, before continuing. Photograph the wiring harness connector and the fan blade's orientation before disconnecting anything. Unplug the motor's wiring harness connector, remove the mounting screws or clips holding the motor bracket in place, and pull the motor and fan blade assembly free. Transfer the fan blade to the new motor if a blade isn't included, matching the original orientation. Mount the new WR60X10185 in the same position, reconnect the wiring harness connector fully, and confirm the blade spins freely by hand without contacting the housing before reassembling the back panel. Restore power and monitor both compartments over the next 24 hours to confirm even, consistent cooling has returned. Tools needed: Phillips screwdriver, nut driver, work gloves. Frequently Asked Questions How do I know if I need this motor or the one with the thermistor? Look directly at your old motor's electrical connector before ordering. This WR60X10185 motor has a plain 4-wire harness on a 6-pin plug, with two of the six pin positions left empty — there's no thermistor wire involved. If your connector instead has a white thermistor wire running into it, you'll need WR60X10074, which includes an integrated thermistor and is not interchangeable with this motor. If your connector has a separate plug specifically for a freezer light, you'll need WR23X10467 instead. My fresh food section is warm but the freezer seems fine. Is this the right part? Yes, this is a very common and telling symptom pattern. The freezer sits right next to the evaporator coil and can stay reasonably cold through proximity even with weakening air circulation, but the fresh food compartment depends entirely on the fan pushing cold air through the ducting to reach it. When the fan motor fails or slows down, the fresh food side is usually the first and most noticeably affected area, and GE's own guidance confirms that a fresh-food-warm/freezer-fine pattern points to this fan. Why would a fan motor "burn out quickly" instead of just wearing out slowly? While this motor generally has a long service life, it can fail rapidly if something obstructs the fan blade from turning — commonly built-up frost or ice, or occasionally debris. When the blade can't turn freely, the motor works against resistance it wasn't designed for, which accelerates internal wear and can burn it out much faster than normal aging would. Clearing ice from around the fan before or during replacement helps prevent stressing the new motor the same way. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine GE OEM part, but is manufactured to match the original 9.75V, 3.25W motor design, blade fitment, and 4-wire harness configuration of the fan motor originally installed in your refrigerator. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Quality Aftermarket Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout

Read more less

XPARTCO 4681JB1029A Refrigerator Evaporator Fan Motor – Compatible with LG and Kenmore Refrigerators Product Description Keep your refrigerator cooling evenly with the XPARTCO 4681JB1029A Refrigerator Evaporator Fan Motor. This Fan Motor is a replacement component for specific LG, Kenmore refrigerator models. It operates the circulation fan located in the back of the refrigerator compartment, distributing cool air evenly throughout. The motor enables constant airflow across shelves and compartments to maintain consistent temperatures and humidity levels. Causes of a bad fan motor include failure of bearings or windings due to prolonged use. Replaces Part Numbers 4681JB1029A, EAU60694507, 1330410, 4681JB1010C, 4681JB1017A, 4681JB1017D, 4681JB1027A, EAU61762902, EAU41921810, PD00037982, EAP3523328, AH3523328, EA3523328, AP4438221, PS3523328.  Compatibility This replacement evaporator fan motor fits select LG and Kenmore refrigerators. Example compatible models include (but are not limited to): LG LFX25960ST, LG LFX28968ST, and Kenmore 795.77543600. Always verify your refrigerator’s model number before ordering. Contact our support team if you’re unsure. ✅ Key Features 🔄 Aftermarket Replacement – Built to meet OEM airflow and reliability standards ❄️ Efficient Air Circulation – Distributes cold air evenly through refrigerator and freezer 💰 Affordable Solution – Quality replacement at a lower cost than OEM parts 🛠️ DIY Installation – Simple plug-in wiring connector for quick installation 🛡️ Fixes Common Issues – Solves frost buildup, uneven cooling, or noisy fan problems 📐 Product Specification Part Number: 4681JB1029A Component Type: Refrigerator Evaporator Fan Motor Material: Metal motor housing with balanced plastic fan blade Mounting: Direct-fit replacement in freezer evaporator compartment Operating Conditions: Designed for continuous low-temperature operation Compliance: Built to OEM-equivalent quality standards (not OEM) 🛠️ Installation Notes Tools Needed: Phillips screwdriver, nut driver ⚠️ Safety First: Always unplug the refrigerator before performing repairs to prevent electrical shock. Steps: Unplug the refrigerator. Remove shelves and freezer rear panel to access the evaporator area. Disconnect the wiring harness and mounting screws on the old fan motor. Install the new XPARTCO 4681JB1029A motor, reconnect wiring, and secure the panel. Restore power and verify quiet, consistent airflow. ⏱️ Time Required: 20–25 minutes 📦 Shop With Confidence 🚚 Free Shipping on All Orders ⚙️ Trusted Appliance Parts Supplier 🔄 30-Day Return Policy Restore efficient, even cooling — Add to Cart Now for a reliable, budget-friendly repair!

Read more less

XPARTCO 2315539 Refrigerator Evaporator Fan Motor Replaces WP2315539 The XPARTCO 2315539 is an aftermarket replacement refrigerator/freezer evaporator fan motor compatible with a wide range of Whirlpool, Kenmore, Maytag, KitchenAid, Amana, Roper, Crosley, Admiral, Estate, Inglis, Ikea, and Gladiator refrigerators. The evaporator fan motor is located in the freezer section and circulates air across the evaporator coils — the cold air generated at the coils is then pushed throughout the freezer and the fresh food compartment. When this motor fails, the most common symptom is excessive noise from the freezer area, and often the refrigerator section won't cool properly even though the freezer remains cold. This motor includes the incorporated wire harness and plug. Rated 115V, 60Hz, with clockwise rotation. It directly replaces WP2315539, WP2315539VP, 2219689, 2225625, W10438708, 1372146, 1518337, AP3996841, AP6007247, ESF-U2B, EAP11740359, PD00021608, PS11740359, and PS1518337. Important: don't forget to transfer the two rubber grommets from your old motor to the new one for proper mounting. Installs in 30–45 minutes with basic hand tools. Quick Answer The XPARTCO 2315539 Refrigerator Evaporator Fan Motor fixes Whirlpool, Kenmore, Maytag, KitchenAid, and Amana refrigerators with excessive noise from the freezer area, ice buildup in the freezer, or where the fresh food section is warm but the freezer is still cold. Includes incorporated wire harness and plug. 115V, 60Hz, clockwise rotation. Transfer rubber grommets from old motor for mounting. Replaces WP2315539, WP2315539VP, 2219689, 2225625, W10438708, 1372146, AP3996841, AP6007247, ESF-U2B, EAP11740359, PS11740359, PS1518337. Common Problems This Part Fixes Excessive noise from the freezer area — most common symptom of evaporator fan motor failure Loud humming, whining, grinding, or scraping noises during operation Freezer compartment cold but fresh food section warm — cool air not being circulated Heavy ice buildup on the evaporator coils or rear freezer wall Refrigerator running continuously trying to maintain temperature Fan blade not spinning freely or seized when checked by hand Motor failing continuity test with a multimeter Visible damage to the fan motor housing or harness Replaces Part Numbers This evaporator fan motor directly replaces the following OEM and cross-reference part numbers: WP2315539, 2315539, W10438708, 1372146, 2219689, 2225625, ESF-U2B, AP6007247, AWP47336, EAP11740359, PD00003243, PS11740359. If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This evaporator fan motor is compatible with select refrigerators from the following brands: Whirlpool refrigerators (top-mount, side-by-side, and Gold series — select models) Kenmore / Sears refrigerators (Whirlpool-built — select 106-series and related models) Maytag refrigerators (select models) KitchenAid refrigerators (select models) Amana refrigerators (select models) Roper refrigerators (select models) Crosley refrigerators (select models) Admiral refrigerators (select models) Estate refrigerators (select models) Inglis refrigerators (select models) Ikea refrigerators (select Whirlpool-built models) Gladiator refrigerators (select models) Note: This motor includes an incorporated wire harness. If your old motor has a separate wire harness (not incorporated), confirm the correct part with our support team before ordering. Always verify your model number first. Remember to transfer the two rubber grommets from your old motor to the new one — they're essential for proper mounting. Key Features Refrigerator/freezer evaporator fan motor — circulates cold air from the evaporator coils throughout both the freezer and fresh food compartments Includes incorporated wire harness and plug — direct plug-in installation Rated 115V, 60Hz — correct electrical specifications for compatible Whirlpool-platform refrigerators Clockwise motor rotation Replaces WP2315539, WP2315539VP, 2219689, 2225625, W10438708, 1372146, AP3996841, AP6007247, ESF-U2B, PS11740359, PS1518337, and additional cross-references Compatible with Whirlpool, Kenmore, Maytag, KitchenAid, Amana, Roper, Crosley, Admiral, Estate, Inglis, Ikea, and Gladiator refrigerators Important: transfer the two rubber grommets from the old motor to the new one for proper mounting Aftermarket replacement built to OEM-equivalent quality standards DIY repair — installs in 30–45 minutes with basic hand tools Product Specifications Part Number 2315539 OEM Part Number WP2315539 Part Type Refrigerator Evaporator Fan Motor (Freezer Section) Condition Aftermarket Replacement Application Refrigerators (Whirlpool platform) Voltage 115V AC Frequency 60 Hz Rotation Clockwise Wire Harness Incorporated wire harness and plug included Mounting Transfer two rubber grommets from old motor Compatible Brands Whirlpool, Kenmore, Maytag, KitchenAid, Amana, Roper, Crosley, Admiral, Estate, Inglis, Ikea, Gladiator Installation Notes ⚠️ Unplug Refrigerator and Move Perishable Food Before Starting — Wear Work Gloves Unplug the refrigerator and safely store any food that could spoil while the power is off. Wear work gloves to protect your hands. The evaporator fan motor is located behind the rear access panel inside the freezer compartment. Remove the freezer shelves and any internal components blocking access to the rear panel. Remove the screws holding the rear access panel to expose the evaporator coils and fan motor (a 1/4" hex driver is commonly needed). Photograph the wire connections and fan blade orientation before disconnecting. Disconnect the wire harness connector from the old motor. Note the orientation of the fan blade on the motor shaft and the position of the two rubber mounting grommets — both must be transferred to the new motor. Remove the mounting screws or release the motor from its bracket, and pull the old motor free. Transfer the rubber grommets and fan blade (if not pre-installed) to the new 2315539 motor in the same orientation. Install the new motor in the same position, reconnect the wire harness, and reinstall the access panel and shelves. Plug the refrigerator back in and allow several hours for the unit to return to its set temperature before reloading with food. Tools needed: 1/4" hex driver, Phillips screwdriver, flathead screwdriver, work gloves. Frequently Asked Questions My freezer is making loud noise — is it the evaporator fan motor? Yes, this is the most recognizable symptom of a failed evaporator fan motor on Whirlpool-platform refrigerators. When the motor's bearings wear out, it produces loud humming, whining, grinding, or scraping noises during operation. The noise often varies as the fan speed changes or as ice builds up around the fan blade. To confirm, unplug the refrigerator and access the fan behind the rear freezer panel — try turning the blade by hand. If it doesn't spin freely, is stiff, or seizes, the motor bearing has failed and needs replacement. My freezer is cold but my fridge is warm — could this be the cause? Yes — on many Whirlpool-platform refrigerators, the freezer's evaporator fan motor is responsible for circulating cool air from the freezer evaporator into the fresh food compartment as well. When this fan fails, the freezer's own compartment may stay cold because the cold air is generated right there, but the fresh food section warms up because no air is being moved into it. If your fridge is warm while the freezer remains cold, this is a likely cause — especially if you also hear unusual noise from the freezer area or see ice buildup on the evaporator coils. What is the difference between 2315539 and WP2315539? These are the same evaporator fan motor. WP2315539 is the updated Whirlpool OEM part number that superseded the original 2315539. The 2219689, 2225625, W10438708, and ESF-U2B are also cross-references for this same motor across various Whirlpool catalog revisions and production runs. This aftermarket replacement is compatible with all of these numbers. Why do I need to transfer the rubber grommets from the old motor? The two rubber grommets seat between the motor housing and the mounting bracket inside the refrigerator. They isolate the motor from the cabinet to dampen vibration and reduce noise during operation, and they also keep the motor properly positioned in its mount. The new 2315539 typically ships without these grommets — they are reused from the old motor. Remove them carefully from the old motor before discarding it, and slide them onto the new motor in the same positions. Without the grommets, the motor may run noisily or vibrate excessively. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is manufactured to match the dimensions, electrical specifications (115V AC, 60Hz, clockwise rotation), incorporated wire harness, and function of the original WP2315539/2315539 evaporator fan motor. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout

Read more less

XPARTCO EAU63923603 Refrigerator Evaporator Fan Motor The XPARTCO EAU63923603 is an aftermarket replacement evaporator fan motor assembly compatible with a wide range of LG and Kenmore LG-built French door, side-by-side, and bottom-freezer refrigerators — including the LFCC, LFCS, LFXC, LFXS, LMXC, LMXS, LRDCS, LRFCS, LRFDS, LRFWS, LRFXS, LRMVS, LRMXC, and LRMXS series. The evaporator fan motor draws air across the cold evaporator coils and circulates it through the fresh food compartment. This constant airflow is what keeps the refrigerator section at temperature. When the fan motor fails, the most telling symptom is that the refrigerator section runs warm while the freezer stays cold — because the coils are still producing cold, but nothing is moving that air up into the fridge. Electrical specs: DC 12V, 1.0A, with a 4-pin connector. Motor body: 75 x 55 x 25 mm. Shaft: 46 mm (1.81") long, 3.0 mm diameter. Lead length: 70 cm (27.5"). Housing made from durable ABS plastic with quality metal internal components. It directly replaces EAU63923603, EAU65058305, EAU63923606, AP6317197, PS12383671, EAP12383671, and PD00045140. Note: this is an upgraded replacement design — the motor body may look slightly larger than your original, but the mounting holes and connector locations are identical, so fit and compatibility are unchanged. Installs in 30–45 minutes with basic hand tools. Quick Answer The XPARTCO EAU63923603 Refrigerator Evaporator Fan Motor fixes LG and Kenmore LG-built refrigerators where the fridge section is warm but the freezer is cold, cooling is insufficient, the freezer has excessive frost, the fan is noisy, or the fan doesn't spin at all. DC 12V, 1.0A, 4-pin connector. Body 75x55x25mm · Shaft 46mm L x 3.0mm dia · 70cm (27.5") lead. ABS housing. Replaces EAU65058305, EAU63923606, AP6317197, PS12383671, EAP12383671, PD00045140. Compatible with LG LFCC/LFCS/LFXC/LFXS/LMXC/LMXS/LRDCS/LRFCS/LRFDS/LRFWS/LRFXS/LRMVS/LRMXC/LRMXS series. Upgraded design — may look slightly larger, but mounting holes and connector are identical. Common Problems This Part Fixes Refrigerator (fresh food) compartment warm while the freezer stays cold — the signature symptom of evaporator fan motor failure Insufficient cooling throughout the refrigerator Uneven or inconsistent temperatures between compartments Excessive frost buildup in the freezer or on the evaporator coils Unusual or loud noises coming from the fan area — failing motor bearings or a blade rubbing on frost Fan motor doesn't run or the fan blade doesn't spin at all Visible damage or obstruction to the motor or fan blades Refrigerator running continuously to compensate for poor air circulation Food spoiling faster than normal in the fresh food compartment Cross Reference Information Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item. Replaces Part Numbers This evaporator fan motor directly replaces the following OEM and cross-reference part numbers: EAU63923603, EAU63923606, EAU65058305, AP7178305, ALG53955, AP6317197, PD00045140, PS12383671. If your part number is not listed above, contact our support team before ordering and we will verify compatibility. LG uses several different evaporator fan motors across its refrigerator lineup — verify your original motor's part number and connector before ordering. Compatibility This evaporator fan motor is compatible with select LG and Kenmore refrigerators, including: LG French door refrigerators — LFCC22426S (/00, /01), LFCC23596S (/01), LFCS27596S (/00, /01), LFCS28768S (/00) series LG French door refrigerators — LFXC22526D (/00, /02, /04, /10), LFXC22526S (/00, /01), LFXC22596D (/00), LFXC22596S (/00, /01) series LG French door refrigerators — LFXS26596D (/01), LFXS26596M (/00), LFXS26596S (/00, /01), LFXS26973D (/00), LFXS28566D, LFXS28566S, LFXS28596D, LFXS28596M, LFXS28596S, LFXS28968D, LFXS28968S series LG French door refrigerators — LMXC22626D, LMXC22626S, LMXS28596M, LMXS28596S, LMXS28626S, LMXS28636S series LG refrigerators — LRDCS2603S, LRFCS2503S, LRFDS2503S, LRFWS2906D, LRFWS2906S, LRFXS2503S, LRFXS2503D series LG refrigerators — LRMVS2806D, LRMVS2806S, LRMXC2206D, LRMXC2206S, LRMXS2806S series Kenmore / Sears refrigerators — select LG-built models (including 795-series such as 79574109810) Note: This is an upgraded replacement design — the motor body may appear slightly larger than your original, but the mounting holes and connector locations are identical, so fit and compatibility are unchanged. LG uses several different evaporator fan motors across its lineup with different voltages and connectors — verify your original motor's part number and 4-pin connector before ordering. Contact our support team with your model number if you're unsure. Key Features Evaporator fan motor assembly — circulates air across the evaporator coils and through the fresh food compartment for efficient, even cooling Resolves the classic "fridge warm, freezer cold" symptom of evaporator fan failure Also fixes insufficient cooling, excessive frost, unusual fan noise, and a fan that won't spin Electrical specs: DC 12V, 1.0A with a 4-pin connector Motor body: 75 x 55 x 25 mm · Shaft: 46 mm (1.81") long x 3.0 mm diameter · Lead length: 70 cm (27.5") Durable ABS plastic housing with quality metal internal components for long service life Upgraded design — body may be slightly larger than the original, but mounting holes and connector locations are identical Cost-effective repair — restores cooling performance instead of replacing the whole refrigerator Replaces EAU65058305, EAU63923606, AP6317197, PS12383671, EAP12383671, and PD00045140 Compatible with LG LFCC, LFCS, LFXC, LFXS, LMXC, LMXS, LRDCS, LRFCS, LRFDS, LRFWS, LRFXS, LRMVS, LRMXC, LRMXS series and Kenmore LG-built refrigerators Aftermarket replacement built to OEM-equivalent quality standards DIY repair — installs in 30–45 minutes with basic hand tools Product Specifications Part Number EAU63923603 Part Type Refrigerator Evaporator Fan Motor Assembly Condition Aftermarket Replacement Application French Door, Side-by-Side & Bottom-Freezer Refrigerators (LG platform) Voltage DC 12V Current 1.0A Connector 4-pin Motor Body Dimensions 75 x 55 x 25 mm Shaft Length 46 mm (1.81") Shaft Diameter 3.0 mm Lead Length 70 cm (27.5") Housing Material ABS plastic Design Note Upgraded — body may be slightly larger; mounting holes and connector identical Compatible Brands LG, Kenmore (LG-built) Installation Notes ⚠️ Unplug Refrigerator and Move Perishable Food Before Starting — Wear Work Gloves Unplug the refrigerator and safely store any food that could spoil while the power is off. Wear work gloves to protect your hands. The evaporator fan motor is located behind the rear evaporator access panel. Remove the shelves, drawers, and any items blocking access to the back wall of the compartment. If there's frost or ice buildup on the panel or coils, allow it to thaw completely before continuing — never chip or pry ice off the evaporator coils, as the aluminum fins damage easily and a damaged coil is a far more expensive repair. Remove the screws securing the rear access panel and lift it away to expose the evaporator coils and fan motor. Photograph the wiring connection, fan blade position, and motor orientation before disconnecting anything. Disconnect the 4-pin wiring connector by gently pulling the plug. Remove the fan blade from the motor shaft (note its orientation — it must go back the same way), then remove the mounting screws holding the motor in place and lift out the old motor. Install the new EAU63923603 motor in the same position and orientation — the mounting holes and connector location match the original even though the body may look slightly larger. Secure the mounting hardware, reinstall the fan blade on the 3.0 mm shaft, and reconnect the 4-pin wiring connector until it seats firmly. Confirm the fan blade spins freely by hand without rubbing on any surrounding surface. Reinstall the rear access panel, shelves, and drawers. Plug the refrigerator back in and allow several hours for the unit to return to its set temperature before reloading with food. Tools needed: Phillips screwdriver, nut driver, work gloves. Frequently Asked Questions My refrigerator section is warm but the freezer is still cold — is this the fan motor? This is the single most common and telling symptom of a failed evaporator fan motor. Here's why: the evaporator coils (which produce the cold) sit in the freezer section, and the evaporator fan is what pushes that cold air into the fresh food compartment. When the fan motor fails, the freezer stays cold (it's right next to the coils) but the fridge warms up because no air is being circulated to it. If your freezer is cold and your fridge is warm, the evaporator fan motor is the prime suspect. You can confirm by listening for the fan when the compressor runs, or by opening the rear evaporator panel to see if the fan spins. The new motor looks bigger than my old one — is it the right part? Yes — this is an upgraded replacement design, and it's normal for the motor body to appear slightly larger than the original LG unit. What matters is that the mounting holes and connector locations are identical to the original, so it bolts into the same position and plugs into the same 4-pin harness. The shaft (46 mm long, 3.0 mm diameter) also matches, so your existing fan blade transfers over. Compatibility is unchanged. If you have any concern, compare the mounting hole spacing and the connector to your old motor before installing. Why is my evaporator fan making noise? A noisy evaporator fan usually means one of two things: the motor bearings are wearing out (producing grinding, buzzing, or squealing), or the fan blade is rubbing against frost or ice that has built up around it. If frost buildup is the cause, that often points to a secondary problem in the defrost system (defrost heater, sensor, or control) allowing ice to accumulate where it shouldn't. Replacing a worn-out fan motor resolves the bearing noise. If heavy frost keeps returning after replacement, investigate the defrost system next. LG has several similar fan motors — how do I know this is the right one? LG uses several different evaporator fan motors across its refrigerator lineup, and while they look similar, they differ in voltage, current, shaft dimensions, and connector style. The EAU63923603 is a DC 12V / 1.0A motor with a 4-pin connector, 46 mm shaft, and 70 cm lead, used across the LFCC/LFCS/LFXC/LFXS/LMXC/LMXS/LRDCS/LRFCS/LRFDS/LRFWS/LRFXS/LRMVS/LRMXC/LRMXS series. Before ordering, find the part number printed on your old motor and confirm it's EAU63923603 or one of the listed cross-references (EAU65058305, EAU63923606, AP6317197, PS12383671). If your motor shows a different number, contact our support team with your model number and we'll confirm the correct motor. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine LG OEM part, but is manufactured with an ABS housing and quality metal internal components to match the electrical specifications (DC 12V, 1.0A), 4-pin connector, shaft dimensions (46 mm x 3.0 mm), mounting hole pattern, and cooling function of the original EAU63923603 evaporator fan motor used in compatible LG and Kenmore LG-built refrigerators. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout

Read more less

WR49X25197 Refrigerator Genuine OEM Axial Evaporator Motor Replaces WR60X26866 The WR49X25197 is a genuine GE OEM axial evaporator fan motor for the fresh food evaporator on select GE French door refrigerators. Unlike a standard evaporator fan motor, this is an axial-design motor purpose-built for the fresh food side of the refrigeration system, using its blade geometry to move air efficiently and quietly through that compartment's evaporator coil for precise, consistent temperature control. Rated 13.6VDC, 0.16A. Manufactured by Nidec, designation V80E14MS2A3-57A611. Over time, motor bearings wear out or the motor can fail electrically, and symptoms typically include the fresh food compartment running warm while the freezer remains unaffected, unusual noise from the fresh food evaporator area, or inconsistent cooling in that compartment specifically, since this motor doesn't serve the freezer side at all. It directly replaces WR60X26866, WR60X10341, WR60X24303, WR60X26033, WR60X10356, WR60X10357, WR60X26030, 239D1412P001, 239D1412P006, and AP6278228. Quick Answer The WR49X25197 Genuine OEM GE Axial Evaporator Motor fixes GE French door refrigerators where the fresh food compartment specifically runs warm, there's unusual noise from the fresh food evaporator area, or fresh food cooling is inconsistent while the freezer works fine. 13.6VDC, 0.16A axial motor. Replaces WR60X26866, WR60X10341, WR60X24303, WR60X26033, WR60X10356, WR60X10357, WR60X26030, 239D1412P001, 239D1412P006, AP6278228. If your refrigerator was manufactured between May 2014 and March 2015 (serial range HD–FF), the control software must also be updated by factory service or a Software Update Module (WR98R882802) for this motor to perform correctly. Common Problems This Part Fixes Fresh food compartment running warm while the freezer stays normal Unusual noise coming from the fresh food evaporator area Inconsistent or fluctuating temperature in the fresh food section specifically Fresh food evaporator fan not spinning or spinning intermittently Reduced airflow affecting fresh food cooling performance Cross Reference Information Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item. Replaces Part Numbers This refrigerator axial evaporator motor directly replaces the following OEM and cross-reference part numbers: WR49X25197, WR60X26866, WR02X13733, WR60X10341, WR60X10356, WR60X10357, WR60X24303, WR60X26030, WR60X26033, V80E14MS2A3-57A611, 8817V W1, 239D1412P006, PD00038765, FIX12172983, AGE29673, AP6278228, PS12172983 If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This axial evaporator motor is compatible with select GE French door refrigerators. Note — fresh food evaporator only, and a software caveat for certain units: This motor serves the fresh food evaporator specifically — a different application from a general freezer evaporator fan motor. Additionally, if your refrigerator was manufactured between May 2014 and March 2015 (serial range HD through FF), the refrigerator's control software must be updated by factory service, or with a Software Update Module (WR98R882802), for this motor to perform correctly after installation. Always verify your full model number before ordering. Contact our support team with your model number if you're unsure. Key Features Genuine GE OEM part — factory-specified axial blade design for the fresh food evaporator Resolves "fresh food running warm," "unusual noise from the fresh food evaporator," and "inconsistent fresh food cooling" symptoms Rated 13.6VDC, 0.16A Manufactured by Nidec, designation V80E14MS2A3-57A611 Direct drop-in replacement matching the original mounting and blade fitment Replaces WR60X26866, WR60X10341, WR60X24303, WR60X26033, WR60X10356, WR60X10357, WR60X26030, 239D1412P001, 239D1412P006, and AP6278228 Compatible with GE French door refrigerators Genuine OEM replacement — guaranteed fit, materials, and performance Product Specifications Part Number WR49X25197 OEM Part Number WR60X26866 Part Type Axial Evaporator Fan Motor (Fresh Food) Condition Genuine OEM Brand GE Application French Door Refrigerators — Fresh Food Evaporator Voltage 13.6VDC Amperage 0.16A Motor Manufacturer Nidec (V80E14MS2A3-57A611) Motor Type Axial Software Update Caveat Required for units mfg. May 2014–March 2015, serial range HD–FF (WR98R882802) Quantity 1 evaporator motor Compatible Brand GE Installation Notes ⚠️ Unplug Refrigerator Before Starting — Check Your Manufacture Date For A Software Update Requirement Disconnect power at the outlet before beginning, and move perishable food to a cooler for the duration of the repair. Wear work gloves. Before starting, check your refrigerator's serial number/manufacture date sticker (typically inside the fresh food compartment) — if your unit was made between May 2014 and March 2015 with a serial range of HD through FF, plan for a control software update via factory service or a Software Update Module (WR98R882802) after installing this motor, since without it the new motor may not perform correctly. Access to the fresh food evaporator is typically through an interior panel in the fresh food compartment, separate from the freezer's evaporator access — check your model's service diagram. If there's frost or ice buildup around the fan or coil, let the unit sit unplugged with the door open for a few hours before continuing. Photograph the wiring harness connector and the fan blade's orientation before disconnecting anything. Unplug the wiring harness connector from the old motor, remove the mounting screws or clips holding the motor bracket in place, and pull the motor and fan blade assembly free. Mount the new WR49X25197 in the same position, reconnect the wiring harness connector fully, and confirm the blade spins freely by hand without contacting the housing before reassembling the panel. Restore power and monitor the fresh food compartment over the next 24 hours to confirm even, consistent cooling has returned. Tools needed: Phillips screwdriver, work gloves. Frequently Asked Questions My fresh food section runs warm but the freezer is fine. Is this the right part? Yes, this is exactly the symptom pattern this motor addresses, since it's dedicated specifically to the fresh food evaporator rather than serving both compartments. If your freezer is cooling normally and only the fresh food section is warm or inconsistent, this axial motor is a strong candidate for the cause. Do I really need a software update after installing this motor? Only if your refrigerator falls into a specific manufacturing window: units made between May 2014 and March 2015, identifiable by a serial range of HD through FF. For those units, GE's own guidance states the control software must be updated by factory service or with a Software Update Module (WR98R882802) for the new motor to perform correctly. If your refrigerator falls outside that date range, this step isn't necessary — check your serial number sticker to confirm which category your unit falls into. Is this the same as a regular evaporator fan motor? Not quite — this is an axial-design motor built specifically for the fresh food evaporator on GE French door refrigerators, distinct from general evaporator fan motors that serve the freezer side or both compartments together. Always confirm your model number and which compartment's fan has failed before ordering. Is this an OEM or aftermarket part? This is a genuine OEM part, manufactured by GE to factory specifications — guaranteed fit, materials, and performance. It matches the original axial motor design, blade fitment, and electrical rating of the fresh food evaporator motor originally installed in your refrigerator. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Genuine OEM Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout

Read more less
