W11568627 Genuine OEM Whirlpool/Kenmore Dryer Drum Belt
The W11568627 is a genuine OEM drum (cylinder) belt for select Whirlpool and Kenmore front-load dryers. This belt wraps around the outside of the drum and routes around the drive motor pulley and idler pulley — it's what actually spins the drum during a drying cycle while the motor and blower keep running independently. Over time this belt stretches, glazes, or cracks from heat and friction, and it eventually slips or snaps, leaving the drum motionless even though the rest of the dryer still runs.
Manufactured by Whirlpool to factory spec for smooth, durable drum operation under high-demand drying cycles, this is a genuine OEM part — not an aftermarket equivalent — so fit and long-term performance match what came on the dryer originally.
Quick Answer
The Genuine OEM W11568627 Dryer Drum Belt fixes a Whirlpool or Kenmore dryer whose drum won't spin, or that runs with a rubbing/thumping noise from the drum area. Genuine OEM replacement, factory fit. Classic symptom: motor and airflow run normally, but the drum sits still — or a rubbing sound right before the belt fails completely.
Common Problems This Part Fixes
Dryer runs (motor and airflow work) but the drum doesn't spin
Rubbing, squealing, or thumping noise from inside the dryer during operation
Clothes bunch up in one spot instead of tumbling
Burning rubber smell from a slipping or overheating belt
Visible cracking, glazing, or fraying on the old belt
Dryer drum spins freely by hand with no resistance from the motor
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This drum belt directly replaces the following part number:
W11568627, W10577771, AP7175918, AWP45299, EAP16660508, OEM21527763, PD00070745, PS16660508
W10577771 is the previous Whirlpool part number for this belt; W11568627 is the current production number. We were not able to confirm additional cross-reference numbers beyond these two at this time. If you have one, contact our support team before ordering and we will verify compatibility.
Compatibility
This drum belt is compatible with the following Whirlpool and Kenmore dryer models:
11061632610, 11061632611
11061633610, 11061633611, 11061633612
11071632610, 11071633610, 110C61633610
WED9500EC0, WED9500EW0, WGD9500EC0, WGD9500EW0
Note: Not all applicable models are necessarily listed above — this is the compatibility data we were able to confirm from available sourcing, and Whirlpool may use this belt on additional models not shown here. Confirm the belt shown on your dryer's parts diagram matches this part number, or contact our support team with your model number to verify before ordering.
Key Features
Genuine OEM drum belt — factory fit and durability, not an aftermarket equivalent
Drives drum rotation during the drying cycle
Built for smooth, reliable operation under high-demand drying cycles
Resolves drum-not-spinning, rubbing/thumping noise, and slipping-belt symptoms
Direct replacement for both W11568627 and the earlier W10577771 numbering
One-year manufacturer replacement warranty on genuine parts
Product Specifications
Part Number
W11568627
OEM Part Number
W11568627
Part Type
Dryer Drum (Cylinder) Belt
Condition
Genuine OEM
Application
Whirlpool & Kenmore Dryers
Country of Origin
Mexico
Installation Notes
ℹ️ Unplug Power Before Installing Unplug the dryer or switch off its circuit breaker before beginning. Remove the dryer's front or rear access panel per your model's service guide to reach the drum, motor pulley, and idler pulley. Release tension on the idler pulley to slip the old belt off, and note the belt's routing path around the drum and pulleys before removing it — a photo taken beforehand makes reinstallation much easier. Loop the new belt around the drum with the ribbed side against the drum surface, then route it around the motor pulley and back around the idler pulley in the same path as the original, making sure it isn't twisted. Reinstall the idler pulley to restore proper tension, then rotate the drum by hand to confirm the belt tracks straight and doesn't rub before closing up the panel.
Frequently Asked Questions
My dryer runs but the drum won't turn — is this the part I need?
Yes, in most cases. A broken or badly slipped drum belt is the most common cause of a dryer that powers on, runs the motor and blower, and still produces heat and airflow, but the drum itself sits motionless.
Is W10577771 the same belt as W11568627?
Yes. W10577771 was the earlier Whirlpool part number for this belt; W11568627 is the current production number for the same design. If your dryer's parts diagram shows W10577771, this part is the correct current replacement.
My exact model isn't listed — will this still fit?
Possibly. Whirlpool uses this belt across a range of models beyond what's confirmed in our current compatibility data. Contact our support team with your full model number and we'll verify fit before you order.
Do I need to replace the idler pulley at the same time?
Not necessarily — this listing is for the belt only. However, if your idler pulley is worn, noisy, or doesn't spin freely, it's worth inspecting and replacing while the dryer is already apart, since a bad idler pulley can shorten the life of a new belt.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout
WPW10547292 Genuine OEM Whirlpool Dryer Idler Pulley
The WPW10547292 is a genuine Whirlpool OEM idler pulley assembly for Whirlpool, Maytag, and Kenmore dryers. This pulley sits to the left of the motor, just below the drum belt, and its job is to ride against the belt and keep constant tension on it as the motor turns — without that tension, the belt would sag, slip on the motor pulley, and fail to reliably turn the drum. The pulley wheel itself spins freely on a bearing mounted to a bracket, so as the belt moves, the pulley spins along with it under light load.
Over time, the bearing inside the pulley wheel wears out, causing it to spin roughly, seize partially, or bind up entirely instead of turning freely. When that happens, the belt drags against a pulley that should be spinning smoothly with it, generating friction, heat, and noise. A worn idler pulley produces a very recognizable symptom: a persistent squeaking or squealing sound during operation that often gets more noticeable over time, and in more advanced cases, a drum that struggles to spin or doesn't spin at all, or a burning smell as the seized pulley drags against the belt. It directly replaces W10547292, WPW10547292VP, AP6022817, 8547160, PS11756154, and LP16246.
Quick Answer
The WPW10547292 Genuine OEM Whirlpool Dryer Idler Pulley fixes Whirlpool, Maytag, and Kenmore dryers with a persistent squeaking or squealing noise during operation, a drum that struggles to spin, or a burning smell from a seized pulley dragging against the belt. Mounts to the left of the motor, below the belt. Replaces W10547292, WPW10547292VP, AP6022817, 8547160, PS11756154, LP16246. Consider replacing the drum belt (8544742/WP8544742) at the same time — a seized idler pulley is a common cause of premature belt wear, and you'll already have the cabinet open.
Common Problems This Part Fixes
Persistent squeaking or squealing noise during operation
Noise that gradually gets louder or more frequent over time
Drum that struggles to spin, spins intermittently, or won't spin at all
Burning smell coming from inside the dryer cabinet
Pulley wheel that feels stiff, gritty, or seized when checked by hand
Drive belt showing premature wear or fraying from dragging against a bound-up pulley
Noise that stops and starts depending on drum rotation or load size
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This dryer idler pulley directly replaces the following OEM and cross-reference part numbers:
WPW10547292, W10547292, WPW10547292VP, AP6022817, 8547160, EAP11756154, PS11756154, AWP50878, PD00003590, LP16246
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This idler pulley is compatible with select Whirlpool, Maytag, and Kenmore dryers, including model numbers such as:
Whirlpool: WED7300XW0, WED7800XB0, WED8100BW0, WED8500BC0, WED8500BR0, WED8500BW0, WED8600YW0, WED8600YW1, 7MWGD7800XW0, 7MWGD8800AW0, 7MWGD8800AW1
Whirlpool (Y-prefix): YWED8000BW0, YWED8100BW0, YWED8200YW2, YWED8400YW2, YWED8500BC0, YWED8500BW0, YWED8800YC2, YWED8800YW2, YWED8900BC0, YWED8900BW0, YMEDB980BW0
Maytag: 7MMGDB850WL0, 7MMGDB950AG0, MEDB200VQ1, MEDB725BW0, MEDB800VB0, MEDB850WL1, MEDB850WR1
Kenmore: 110.78102310, 11067032600, 11067032601, 11067042600, 11067042601, 11067052600, 11067062600, 11067072600, 11067082600, 11067086600
Note: Whirlpool uses several different idler pulley designs across its dryer lineup, and they are NOT interchangeable. This WPW10547292 pulley is a separate part from the W10837240 pulley (used on Cabrio, Duet, and Bravos XL platforms) and the 279640 pulley (an older, differently-shaped design). Fitting the wrong pulley can result in a bracket that doesn't mount correctly or a wheel that doesn't align with your belt. Always verify your full model number before ordering. Contact our support team with your model number if you're unsure which pulley fits your dryer.
Key Features
Genuine Whirlpool OEM part — factory-specified bearing and bracket design
Maintains constant tension on the drive belt so it can turn the drum smoothly
Resolves "squeaking or squealing noise," "drum won't spin," and "burning smell" symptoms caused by a worn or seized pulley bearing
Complete wheel-and-bracket assembly — no need to source parts separately
Direct drop-in replacement — mounts to the original bracket position with the same bolt
Replaces W10547292, WPW10547292VP, AP6022817, 8547160, PS11756154, and LP16246
Compatible with Whirlpool, Maytag, and Kenmore dryers
Genuine OEM replacement — guaranteed fit, materials, and performance
Product Specifications
Part Number
WPW10547292
Part Type
Dryer Idler Pulley Assembly (Wheel + Bracket)
Condition
Genuine OEM
Brand
Whirlpool
Location
Left of the motor, below the drum belt
Function
Maintains tension on the drive belt as it turns the drum
Fuel Type
Electric and gas dryers
Companion Part
8544742 / WP8544742 drum belt (check/replace if pulley failed)
Repair Difficulty
Medium — requires some disassembly
Quantity
1 idler pulley assembly
Compatible Brands
Whirlpool, Maytag, Kenmore
Installation Notes
⚠️ Unplug Dryer Before Starting — On Gas Models, Shut Off The Gas Supply Too Disconnect power at the outlet or shut off the circuit breaker before beginning. On a gas dryer, also close the gas shutoff valve before moving the cabinet. Wear work gloves. Remove the lint filter, then remove the screws along the top edge of the front panel and take the panel off. With the front open, locate the belt tensioner pulley — it sits to the left of the motor, just below the belt. Use a socket wrench with an extension to loosen the pulley's mounting bolt, then remove the old pulley assembly, releasing the belt from it as you go. Slide the new WPW10547292 assembly onto the mounting post, making sure the grooves line up correctly so the belt seats snugly against the wheel, then re-tighten the mounting bolt securely. Before closing everything up, spin the new pulley by hand to confirm it turns freely with no grinding or resistance, and inspect the belt for wear, glazing, or fraying — replace it as well if it shows any of these signs, since a worn belt will quickly wear out even a brand-new pulley. Reinstall the front panel and its screws, restore power, and run a short empty cycle listening for the squeak to confirm it's resolved. Tools needed: 1/4" nut driver, 3/8" socket wrench with extension, Phillips screwdriver, work gloves.
Frequently Asked Questions
My dryer squeaks constantly. Is this definitely the idler pulley?
It's one of the most common causes of a persistent squeak, especially if the noise is steady and present throughout the cycle rather than only at certain moments. The pulley's internal bearing wears out over years of use, and a worn bearing produces exactly this kind of ongoing squeal as it spins roughly instead of smoothly. If you can access the pulley and spin it by hand, feeling any grinding or stiffness confirms the diagnosis.
Is this a hard repair, or can I do it myself?
It's a moderate repair — you'll need to remove the front panel and access the area behind the motor, which some customers describe as needing to "pull the entire dryer apart" to reach the pulley. It's very doable with basic hand tools and some patience, but budget more time than a simple part swap, and expect to use a socket wrench with an extension to reach the mounting bolt in that tighter space.
Should I replace the belt while I'm already in there?
It's worth strongly considering. A seized or dragging pulley puts extra wear on the belt, so if your pulley failed from being seized rather than just noisy, the belt may already be showing damage. Since you'll already have the cabinet open and the belt exposed, inspecting it — and replacing it if it shows glazing, cracking, or fraying — saves you from repeating this same teardown again soon after.
Is this an OEM or aftermarket part?
This is a genuine OEM part, manufactured by Whirlpool to factory specifications — guaranteed fit, materials, and performance. It matches the original bearing design, bracket shape, and mounting configuration of the idler pulley assembly originally installed in your Whirlpool, Maytag, or Kenmore dryer.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Genuine OEM Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
W10844024 Genuine OEM Whirlpool Dishwasher Water Inlet Valve
The W10844024 is a genuine Whirlpool OEM water inlet valve for Whirlpool, Kenmore, KitchenAid, Estate, Roper, Inglis, Maytag, Crosley, Ikea, Magic Chef, Kirkland, and Amana dishwashers. This valve regulates the flow of water into the appliance during each fill stage of the wash cycle, opening and closing to admit the correct amount of water at the right times.
Weighing approximately 0.2 lbs, common failure causes include mineral or sediment buildup inside the valve and general electrical wear in the solenoid. A failing valve produces a clear set of symptoms: the dishwasher not filling with water at all, or a valve that's unusually noisy — starting and stopping repeatedly — during heavy wash cycles as it struggles to regulate flow correctly. It directly replaces 3384890, 8283346, 9744468, W10219643, WP9744468, WPW10219643, 3378779, 3379356, 4383567, 8274221, 8283345, 9743175, 9743559, 9744029, 9744284, W10327248, W10844024VP, AP5989613, AWP42052, EAP11730996, PD00032565, PS11730996
Quick Answer
The W10844024 Genuine OEM Whirlpool Dishwasher Water Inlet Valve fixes Whirlpool, Kenmore, KitchenAid, Estate, Roper, Inglis, Maytag, Crosley, Ikea, Magic Chef, Kirkland, and Amana dishwashers that aren't filling with water, or that are unusually noisy — starting and stopping — during heavy wash cycles. Replaces 3384890, 8283346, 9744468, W10219643, WP9744468, WPW10219643, 3378779, 3379356, 4383567, 8274221, 8283345, 9743175, 9743559, 9744029, 9744284, W10327248, W10844024VP, AP5989613, AWP42052, EAP11730996, PD00032565, PS11730996. Some households need a separate hose adapter for this valve if the existing water line connector has a smaller diameter than the new valve's fitting — check before you start, or be prepared for a quick hardware store trip.
Common Problems This Part Fixes
Dishwasher not filling with water at all
Valve unusually noisy — starting and stopping repeatedly during heavy wash cycles
Cycle stalling at the fill step and never advancing to wash
Poor washing results due to insufficient water fill
Leaking near the valve connections
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This dishwasher water inlet valve directly replaces the following OEM and cross-reference part numbers:
W10844024, 3384890, 8283346, 9744468, W10219643, WP9744468, WPW10219643, 3378779, 3379356, 4383567, 8274221, 8283345, 9743175, 9743559, 9744029, 9744284, W10327248, W10844024VP, AP5989613, AWP42052, EAP11730996, PD00032565, PS11730996
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This water inlet valve is compatible with select Whirlpool dishwashers, and also fits select Kenmore, KitchenAid, Estate, Roper, Inglis, Maytag, Crosley, Ikea, Magic Chef, Kirkland, and Amana dishwashers built on the Whirlpool platform, including model numbers such as KUDR25SHWH1, MDB4629AWB1, DU900PWKB0, DU900PWKQ0, and Kenmore 665.15522000, 66517662991, and 66516669991.
Note: Always verify your full model number before ordering, since similar-looking dishwasher water valves can vary between models. Contact our support team with your model number if you're unsure.
Key Features
Genuine Whirlpool OEM part — factory-specified solenoid design and flow rate
Regulates water flow into the dishwasher during each fill stage of the cycle
Resolves "won't fill" and "noisy, starts and stops when filling" symptoms caused by valve failure
Factory Certified Part built to Whirlpool's engineering specifications
Direct drop-in replacement — matches the original mounting and hose connections
Replaces 3384890, 8283346, 9744468, W10219643, WP9744468, WPW10219643, 3378779, 3379356, 4383567, 8274221, 8283345, 9743175, 9743559, 9744029, 9744284, W10327248, W10844024VP, AP5989613, AWP42052, EAP11730996, PD00032565, PS11730996
Compatible with Whirlpool, Kenmore, KitchenAid, Estate, Roper, Inglis, Maytag, Crosley, Ikea, Magic Chef, Kirkland, and Amana dishwashers
Genuine OEM replacement — guaranteed fit, materials, and performance
Product Specifications
Part Number
W10844024
Part Type
Dishwasher Water Inlet Valve
Condition
Genuine OEM
Brand
Whirlpool
Weight
Approx. 0.2 lbs
Function
Regulates water flow into the dishwasher during fill
Repair Difficulty
Easy to Moderate
Quantity
1 valve
Compatible Brands
Whirlpool, Kenmore, KitchenAid, Estate, Roper, Inglis, Maytag, Crosley, Ikea, Magic Chef, Kirkland, Amana
Installation Notes
⚠️ Unplug Dishwasher And Shut Off Water Supply Before Starting — Check Your Hose Connector Size First Disconnect power at the outlet or shut off the circuit breaker, and disconnect the water lines connected to the old valve before beginning. Wear work gloves. Have a shop vacuum on hand — some customers have needed to remove standing water from the bottom of the dishwasher before starting this repair. Locate the old valve and use pliers to unscrew any screws or bolts connecting it to the appliance. Clean the area where the old valve was located, removing any debris before installing the new one. Check the diameter of your existing water line connector before starting — some households have a smaller-diameter connector than this new valve's fitting requires, in which case you'll need a separate hose adapter from a hardware store to complete the connection. Take the new W10844024 and place it in the same position as the old valve, making sure it's connected correctly, and secure any screws or bolts. Reattach the water lines to the new valve and reconnect power. Double-check all connections before restoring power, then run a test cycle to confirm the dishwasher fills correctly with no leaks. Tools needed: pliers, possibly a hose adapter, shop vacuum (if needed), work gloves.
Frequently Asked Questions
My dishwasher isn't filling with water at all. Is this the right part?
Yes, this is the most direct symptom of a failed water inlet valve. Since this valve is what admits water from your household supply into the dishwasher, a solenoid failure or internal blockage can prevent any water from entering at all, stopping the wash cycle from proceeding.
Will I need any extra parts for this installation?
Possibly. A few customers have found their existing water line connector had a smaller diameter than this valve's fitting, requiring a separate hose adapter purchased locally from a hardware store to complete the connection. It's worth checking your connector size beforehand, or having a quick trip to the hardware store planned just in case.
My dishwasher makes a noisy, start-and-stop sound when filling. Is that this valve?
Yes, this is a documented symptom. One customer described their valve as "very noisy on heavy wash cycles, started and stopped when filling" before replacing it with this exact part, which resolved the issue.
Is this an OEM or aftermarket part?
This is a genuine OEM part, manufactured by Whirlpool to factory specifications — guaranteed fit, materials, and performance. It matches the original solenoid design, flow rate, and connection type of the water inlet valve originally installed in your dishwasher.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Genuine OEM Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
137292700 Dryer Genuine OEM Drum Belt
The 137292700 is a genuine Frigidaire OEM multi-rib drum belt for Frigidaire stacked laundry center (combination washer/dryer) units, and also fits select Crosley, Electrolux, Gibson, Kelvinator, Kenmore, Tappan, and White Westinghouse combo models. This belt attaches to the motor pulley and spins the drum as the motor rotates, keeping clothes tumbling evenly throughout the drying cycle.
Measures approximately 89-1/2" long and 1/4" wide, with multiple ribs. Over time, this belt naturally dries out, cracks, or breaks from regular use. If your dryer is running but the drum won't turn, there's a good chance the belt has broken. Symptoms of a failing belt include the drum not turning, loud banging noises, or the dryer failing to tumble clothes. It directly replaces 134163500, 134503900, 5303283287, 4PH 2273, 4PH2273, AFR14366, AH3408299, AP4565702, EA3408299, EAP3408299, PD00000115, PS3408299.
Quick Answer
The 137292700 Dryer Genuine OEM Drum Belt fixes Frigidaire, Crosley, Electrolux, Gibson, Kelvinator, Kenmore, Tappan, and White Westinghouse stacked laundry center units where the drum won't turn, you hear loud banging noises, or the dryer won't tumble clothes. Approximately 89-1/2" long, 1/4" wide, multiple ribs. Replaces 134163500, 134503900, 5303283287, 4PH 2273, 4PH2273, AFR14366, AH3408299, AP4565702, EA3408299, EAP3408299, PD00000115, PS3408299. This is a laundry center (stacked combo) belt, distinct from standalone dryer belts — verify your full model number before ordering.
Common Problems This Part Fixes
Drum won't turn even though the motor is running
Loud banging noises during operation
Dryer failing to tumble clothes
Belt visibly cracked, dried out, or broken
Drum stopping mid-cycle
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This dryer drum belt directly replaces the following OEM and cross-reference part numbers:
134163500, 134503900, 5303283287, 4PH 2273, 4PH2273, AFR14366, AH3408299, AP4565702, EA3408299, EAP3408299, PD00000115, PS3408299
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This drum belt is compatible with select Frigidaire stacked laundry center units, and also fits select Crosley, Electrolux, Gibson, Kelvinator, Kenmore, Tappan, and White Westinghouse combo units built on the same platform, including model numbers such as WLXG42REW0, FLSE72GCTC, FLSG72GCT1, FLSG72GCT6, LCE852LL1, FLXG52RBS2, FLXG52RBS8, FLXE52RBS9, CLCG900FW0, CLCG900FW1, CLCG900FW2, CLCG900FW3, CLCE900FW0, CLCE900FW1, CLCE900FW2, CLCG500FW0, CLCG500FW1, CLCE600RW0, CLCE500MW1, CLCE500FW2, and CLCE500FW4.
Note: This is a laundry center (stacked washer/dryer combo) belt, distinct from standalone Frigidaire dryer belts. Always verify your full model number before ordering. Contact our support team with your model number if you're unsure.
Key Features
Genuine Frigidaire OEM part — factory-specified multi-rib design
Attaches to the motor pulley to spin the drum for laundry center (combo) units
Resolves "drum won't turn," "loud banging noises," and "won't tumble" symptoms
Approximately 89-1/2" long, 1/4" wide, multiple ribs
Direct drop-in replacement matching the original length and profile
Replaces 134163500, 134503900, 5303283287, 4PH 2273, 4PH2273, AFR14366, AH3408299, AP4565702, EA3408299, EAP3408299, PD00000115, PS3408299
Compatible with Frigidaire, Crosley, Electrolux, Gibson, Kelvinator, Kenmore, Tappan, and White Westinghouse laundry center units
Genuine OEM replacement — guaranteed fit, materials, and performance
Product Specifications
Part Number
137292700
Part Type
Laundry Center Multi-Rib Drum Belt
Condition
Genuine OEM
Brand
Frigidaire
Application
Stacked Washer/Dryer Laundry Centers
Length
Approx. 89-1/2"
Width
1/4"
Ribs
Multiple
Function
Transmits motor rotation to spin the drum
Repair Difficulty
Moderate — laundry center disassembly required
Quantity
1 drum belt
Compatible Brands
Frigidaire, Crosley, Electrolux, Gibson, Kelvinator, Kenmore, Tappan, White Westinghouse
Installation Notes
⚠️ Unplug The Laundry Center Before Starting Disconnect power to the laundry center unit at the outlet before beginning. Wear work gloves. This repair is best approached from the top down: remove the top of the unit first, which gives more room to get the dryer tub out. Remove the two screws from the vented plate on the back of the machine to access and undo the old belt. Since this is a stackable washer/dryer combo, also remove the white plate on the front between the washer and dryer sections for full access. Locate the old belt connecting the motor pulley to the drum and remove it. Fit the new 137292700 belt around the drum and motor pulley in the same path as the old one, making sure it seats correctly and is properly tensioned. Reassemble the front plate, vented back plate, and top of the unit. Restore power and run a test cycle to confirm the drum tumbles smoothly with no banging or unusual noise. Tools needed: putty knife, screwdriver set, work gloves.
Frequently Asked Questions
The motor is running but the drum won't turn. Is this the belt I need?
Yes, this is the classic and most reliable sign of a broken drum belt. If you can hear the motor running normally but the drum itself stays still, the belt has likely dried out and broken, no longer connecting the motor's rotation to the drum.
Is this the same as a standalone Frigidaire dryer belt?
No, this belt is specifically sized and profiled for Frigidaire-style stacked laundry center units, where the washer and dryer are combined into one appliance. It's a different part from standalone Frigidaire dryer belts used on separate dryers. Confirm your unit type and model number before ordering.
Is this a difficult repair?
It's a moderate repair since it involves removing the top of the laundry center unit, the vented back plate, and the front plate between the washer and dryer sections to get full access to the belt. One customer described working from the top down as the easiest approach, since it gives more room to remove the dryer tub.
Is this an OEM or aftermarket part?
This is a genuine OEM part, manufactured by Frigidaire to factory specifications — guaranteed fit, materials, and performance. It matches the original length, width, and rib pattern of the multi-rib drum belt originally installed in your laundry center.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Genuine OEM Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
W11665769 Dishwasher Sump Pump and Motor
Pump and Motor Assembly
Replaces Part Numbers: W11665769, W11085683, W10917110, W11164469, AP7212556, PS16875975.
Description: This dishwasher pump and motor assembly is compatible with specific Whirlpool, Maytag, Kenmore dishwasher models. It is supplied directly by the original manufacturer to ensure that it fits perfectly with your model. The pump and motor are responsible for moving water throughout the dishwasher during the wash cycle. The pump draws water from the tub and pumps it through various channels, such as the detergent dispenser, spray arms, and drain hose. The motor provides the power necessary to drive the circulation pump, causing the pump to rotate and circulate water. If the assembly is faulty, you will notice difficulties starting or filling the dishwasher, poor cleaning performance, incomplete cycles, and water leaks.
XPARTCO W10780048 Washer Suspension Rods Kit
Washer Suspension Rods Kit, set of 4.
Fits specific Kenmore, Maytag, Whirlpool top load machine models.
Replaces Part numbers: W10780048, W10349191, 4185114, W10257087, W10257088, W10349193, W10748952, W10821948, AP5971398, PS11703290.
Description: This Suspension Rods are replacement parts for specific Kenmore, Maytag, Whirlpool washing machine models. They are designed to support the washer's tub assembly, maintaining balance and stability during the spin and agitation cycles. These rods connect the tub to the washer's frame and help absorb vibrations, preventing excessive movement that can lead to operational issues.
This is an aftermarket part that can be used as a replacement for the OEM part.
XPARTCO W10730972 Washer Drain Pump Replaces WPW10730972
The XPARTCO W10730972 is an aftermarket replacement front-load washer drain pump and motor assembly compatible with a wide range of Whirlpool, Maytag, Kenmore, Amana, Inglis, and KitchenAid front-load washers — including the Whirlpool Duet, Maytag 2000/3000/4000 series, and Kenmore HE2/HE2T Plus. The drain pump removes water from the washer tub during the drain and spin phases of each wash cycle. When the pump fails, the washer will not drain, will leave standing water in the tub, stop mid-cycle, display error codes F21, F33, or SD, or leak from the pump area.
This complete assembly includes the motor, pump housing, and integrated filter — these components are only available as a complete assembly and are not sold separately. Rated 120V, 60Hz, 78W, 1.2A (CL.F duty class). Assembly dimensions are 8-3/4"L x 7"W x 5-1/4"H in off-white plastic housing. Note: Whirlpool redesigned this pump — the replacement may look different from the original but fits and functions identically. It directly replaces WPW10730972, W10130913, W10130913-B, 8540024, 8540025, 8540027, 8540028, 8540996, W10117829, W10183434, W10190647, W10190648, W10201457, AP6023956, PS11757304, and additional cross-reference numbers. Installs in 20–30 minutes with basic hand tools.
Quick Answer
The XPARTCO W10730972 Washer Drain Pump fixes Whirlpool Duet, Maytag 2000/3000/4000 series, and Kenmore HE2/HE2T Plus front-load washers that won't drain, leave standing water, or display error codes F21, F33, or SD. Complete assembly — motor, pump housing, and filter included. 120V/60Hz/78W/1.2A. 8-3/4"L x 7"W x 5-1/4"H. Note: redesigned — may look different from original but fits identically. Replaces WPW10730972, W10130913, 8540024, 8540996, W10117829, AP6023956, PS11757304.
Common Problems This Part Fixes
Washer not draining — standing water remaining in the tub after a cycle
Error code F21 displayed — long drain fault (washer unable to drain in allotted time)
Error code F33 displayed — pump motor fault
Error code SD displayed — suds detection or drain issue
Washer stopping mid-cycle due to a drain fault
Loud humming or grinding noise during the drain phase
Water leaking from the front lower area of the washer — pump seal failure
Pump motor running but water not being expelled from the tub
Replaces Part Numbers
This drain pump directly replaces the following OEM and cross-reference part numbers:
WPW10730972, W10730972, W10130913, 4281917, 8540024, 8540025, 8540027, 8540028, 8540996, W10117829, W10183434, W10190647, W10190648, W10201457, WPW10730972VP, AP6023956, AWP50633, B40-3A01, EAP11757304, PD00025949, PS11757304
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This drain pump is compatible with select front-load washers from the following brands and series:
Whirlpool front-load washers — Duet series (WFW8300, WFW8400, WFW9050, WFW9150, WFW9200, WFW9250, WFW9400, WFW9450, WFW9500, WFW9550, WFW9600, WFW96HEA, WFW97HED, WFW98HEB and related models)
Maytag front-load washers — 2000 series (MHW2000AW, MHW2000BWW and related models)
Maytag front-load washers — 3000 series (MHW3000BW and related models)
Maytag front-load washers — 4000 series (MHW4000BW, MHW4200BW, MHW5100DW, MHW6000AW, MHW6000XW and related models)
Kenmore / Sears front-load washers — HE2 and HE2T Plus series (110.45862400, 110.47532602 and related models)
Amana front-load washers (select models)
Inglis front-load washers (select models)
KitchenAid front-load washers (select models)
Note: Whirlpool redesigned this pump assembly — the replacement may look different from your original pump (larger in size on some versions) but is engineered to fit and function identically in all compatible models. Always verify your model number before ordering. Before replacing the pump, check and clear the coin trap/drain filter — a clogged filter is a common cause of F21/F33 errors that does not require pump replacement.
Key Features
Removes water from the tub during drain and spin cycles — essential for proper washer operation
Complete assembly — motor, pump housing, and integrated filter included; components are not sold separately
Rated 120V, 60Hz, 78W, 1.2A (CL.F) — correct electrical specifications for compatible Whirlpool-family front-load washers
Dimensions: 8-3/4"L x 7"W x 5-1/4"H — off-white plastic housing
Resolves error codes F21 (long drain), F33 (pump motor fault), and SD (suds/drain) on compatible models
Redesigned assembly — may look different from original but fits and functions identically
Replaces WPW10730972, W10130913, 8540024, 8540996, W10117829, AP6023956, and over 20 additional cross-references
Compatible with Whirlpool Duet, Maytag 2000/3000/4000 series, Kenmore HE2/HE2T Plus, Amana, Inglis, and KitchenAid
Aftermarket replacement built to OEM-equivalent quality standards
DIY repair — installs in 20–30 minutes with basic hand tools
Product Specifications
Part Number
XPW10730972
OEM Part Number
WPW10730972
Part Type
Front-Load Washer Drain Pump and Motor Assembly
Condition
Aftermarket Replacement
Application
Front-Load Washers (Duet, Maytag 2000/3000/4000, Kenmore HE2/HE2T Plus)
Voltage
120V AC
Frequency
60 Hz
Wattage
78W
Amperage
1.2A
Duty Class
CL.F
Dimensions
8-3/4"L x 7"W x 5-1/4"H
Color
Off-White
Material
Plastic housing
Includes
Motor, pump housing, and integrated filter — complete assembly
Design Note
Redesigned — may look different from original; fits identically
Error Codes Resolved
F21 (long drain), F33 (pump motor fault), SD (suds/drain)
Compatible Brands
Whirlpool, Maytag, Kenmore, Amana, Inglis, KitchenAid
Installation Notes
⚠️ Unplug Washer and Shut Off Water Before Starting — Work Gloves Recommended Disconnect power and turn off the water supply before beginning. Place towels on the floor — residual water will drain when the pump is disconnected. The drain pump is accessed through the lower front panel of the washer. Remove the screws on the lower kick panel or snap panel to expose the pump access area. Before removing the pump, drain residual water by removing the coin trap/filter cap from the filter housing (have a shallow pan ready — up to a quart of water may flow out). After draining, disconnect the pump wiring harness. Release the drain hose clamps and disconnect the hoses from the pump. Unscrew or unclip the pump mounting hardware and remove the old pump. Transfer the hoses and wiring to the new W10730972 pump, secure the mounting hardware, and reinstall the front panel. Restore power and water, run a drain/spin cycle, and check for leaks. Tools needed: Phillips screwdriver, Torx screwdriver (T20 on some models), pliers, shallow pan, towels, work gloves.
Frequently Asked Questions
What do error codes F21, F33, and SD mean on Whirlpool Duet and Maytag washers?
F21 indicates a long drain fault — the washer was unable to drain within the expected time (typically 8 minutes). F33 indicates a pump motor fault — the control board is not detecting the pump motor operating correctly. SD is a suds detection code that can also appear when drain issues prevent the suds from clearing properly. All three codes point toward the drain pump or a drain obstruction. Before replacing the pump, check and clean the coin trap filter — a clogged filter is one of the most common causes of F21 errors and clearing it often resolves the code without needing a new pump.
Should I check the coin trap filter before replacing the pump?
Yes — always check the coin trap filter before replacing the pump. On Whirlpool Duet and Maytag front-load washers, the coin trap filter is located inside the lower front access panel, typically behind a small cap or cover. Removing the cap and clearing lint, coins, and debris from the filter restores drain flow and clears F21/F33 errors in many cases without any part replacement needed. If the filter is clear and the pump still humbles or fails to drain, the pump needs replacement.
Why does the replacement pump look different from the original?
Whirlpool redesigned this drain pump assembly during its production lifecycle — the WPW10730972 replacement is physically larger than some of the older 8540024-series pumps it supersedes. Despite looking different, the redesigned pump uses the same hose and electrical connection points and is a direct fit in all compatible models. The larger housing is an intentional design improvement to increase pumping capacity. If the pump looks bigger than what you removed, this is normal and expected — install it in the same way as the original.
What is the difference between W10730972 and WPW10730972?
These are the same drain pump assembly. WPW10730972 is the updated Whirlpool OEM part number that superseded the original W10730972. The W10130913 and 8540024 are also cross-references for earlier versions of this same pump. This aftermarket replacement is compatible with all of these numbers.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is manufactured to match the electrical specifications and performance of the original WPW10730972 drain pump assembly.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout
Genuine OEM WH44X27239 Washer Tub Cover
The Genuine OEM GE WH44X27239 is the tub cover, also called a tub ring, for select GE 24-inch washer-dryer combo units. It snaps over the top of the tub and acts as a splash shield. If your cover is cracked, broken or missing, this is the replacement.
This is the original GE part, not an aftermarket equivalent. It is sold individually. Check your model number before ordering.
Quick Answer
The Genuine OEM WH44X27239 Tub Cover replaces the snap-on tub cover (splash shield) on a compatible GE 24-inch washer-dryer combo. Typical reasons to replace it: the cover is cracked, broken or missing.
When To Replace This Part
Tub cover is cracked or broken
Tub cover is missing or no longer snaps securely over the tub
Splash shield is damaged
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This tub cover is listed under the following part number:
WH44X27239, 4588351, AP6328375, AGE26665, EAP12343494, PS12343494, PD00068486
If your old cover shows a different number, contact our support team and we'll check whether it matches.
Compatibility
This tub cover is listed for GE 24-inch washer-dryer combo units, including:
GE GUD24ESSM0WW, GUD24ESSM1WW
GE GUD24GSSM0WW, GUD24GSSM1WW
Note: These are the models retailers list for this part. GE also sells other tub covers with different part numbers that look similar. Check your full model number against your parts diagram, or contact our support team to verify fit before ordering.
Key Features
Genuine OEM GE part, not an aftermarket equivalent
Snaps over the top of the tub as a splash shield
Sold individually
Product Specifications
Part Number
WH44X27239
OEM Part Number
WH44X27239
Part Type
Washer Tub Cover (Tub Ring)
Condition
Genuine OEM
Manufacturer
GE
Quantity
1 Cover
Application
Select GE 24-Inch Washer-Dryer Combos
Installation Notes
⚠️ Disconnect Power Before Installing Unplug the unit before you begin and wear work gloves. Remove the old cover and snap the new cover over the top of the tub, making sure it seats all the way around. Restore power and run a short cycle to confirm it stays in place.
Frequently Asked Questions
What does the tub cover do?
It snaps over the top of the tub and works as a splash shield.
Is this an OEM or aftermarket part?
This is a genuine OEM part from GE, not an aftermarket equivalent.
Is this for a standalone washer?
It is listed for GE 24-inch washer-dryer combo units. Match the part number and your model number before ordering, or contact our support team.
Will this fit my washer-dryer?
It is listed for GUD24ESSM0WW, GUD24ESSM1WW, GUD24GSSM0WW and GUD24GSSM1WW. If your model is not on that list, check your parts diagram or contact our support team and we'll verify it before you order.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Genuine OEM Parts ✓ Compatibility Support ✓ Secure Checkout
XPARTCO WE04X24550 Dryer Timer
The XPARTCO WE04X24550 is an aftermarket replacement dryer timer for select GE dryers, replacing GE part WE04X24550. The timer controls the dryer's electrical components and the length of each drying cycle. When it fails, the dryer may not start, may stop partway through a cycle, or may not respond to the controls.
A faulty timer is a less common cause of a drum that won't turn, so check the other common parts first. If they test fine, test the timer against your wiring diagram and replace it only if it is defective. Check your model number before ordering.
Quick Answer
The XPARTCO WE04X24550 Dryer Timer replaces the cycle timer on a compatible GE dryer when it has failed. Replaces WE04X24549. Classic symptoms: the dryer starts and then stops, the controls don't work, or the dryer overheats.
Common Problems This Part Fixes
Dryer starts and then stops
Dryer controls don't work
Drum not turning (check other parts first)
Dryer overheating
Dryer starts on its own
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This dryer timer directly replaces the following part numbers:
WE04X24550, WE04X24549, 234D2377P003, 234D2377P004, 4546121, TMD14M30, TMD16M12, AGE25986, AP6031056, FIX11763064, OEM18093177, PD00039467, PS11763064
If your old timer shows a different number, contact our support team and we'll check whether it matches.
Compatibility
This timer is listed for select GE dryers, including these examples:
GE GTD42GASJ0WW, GTD42GASJ1WW, GTX42GASJ0WW, GTX42GASJ1WW, GTX42GASJ2WW
GE GTD42EASJ0WW, GTD42EASJ3WW, GTX42EASJ1WW
GE GTD48EASW0WB, XTD72E8ST1WS
Note: The models above are a small sample, not a full list. Check your full model number against your parts diagram, or contact our support team to verify fit before ordering.
Key Features
Aftermarket replacement for the GE WE04X24550 dryer timer
Controls the dryer's electrical components and cycle length
Replaces the earlier GE part WE04X24549
Product Specifications
Part Number
XPWE04X24550
OEM Part Number
WE04X24550
Part Type
Dryer Timer
Condition
Aftermarket Replacement
Application
Select GE Dryers
Installation Notes
⚠️ Unplug Power Before Installing Unplug the dryer before you begin, and wear work gloves. Remove the console panel to reach the timer, note where each wire connects, and remove the knob and old timer. Install the new timer, reconnect the wiring in the same positions, and refit the knob and console. Restore power and test the dryer.
Frequently Asked Questions
My dryer drum stopped turning. Is this the part I need?
Probably not first. A faulty timer is rarely the cause of a drum that stops turning. Check the drive belt, motor and thermal fuse first. If those work, test the timer with a multimeter against your wiring diagram.
Is this an OEM or aftermarket part?
This is an aftermarket replacement from XPARTCO, made to replace GE part WE04X24550. If you specifically need a genuine GE part, contact our support team.
Will this fit my dryer?
It is listed for select GE dryers, but the model list above is only a sample. Check your full model number against your parts diagram, or contact our support team and we'll verify it before you order.
Is this the same as other GE dryer timers?
Not necessarily. GE uses different timer numbers for different dryers, so match the part number and your model number rather than assuming a similar-looking timer fits.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout
Genuine OEM WH49X27322 Washer Transmission Platform Assembly Kit
The Genuine OEM GE WH49X27322 is the transmission platform assembly and nut kit for select GE washer-dryer combo units. The platform supports the transmission and keeps it aligned with the drum. When it wears, cracks or shifts out of alignment, the unit can make clunking or grinding noises during the spin cycle or vibrate heavily.
This is the original GE part, not an aftermarket equivalent. It is sold as a kit. Check your model number before ordering.
Quick Answer
The Genuine OEM WH49X27322 Transmission Platform Assembly Kit replaces the transmission platform and nut on a compatible GE washer-dryer combo when the platform has worn or failed. Classic symptoms: loud clunking or grinding during the spin cycle, or excessive vibration.
Common Problems This Part Fixes
Loud clunking or grinding noise during the spin cycle
Excessive vibration or shaking
Worn, cracked or misaligned transmission platform
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This transmission platform kit is listed under the following part number:
WH49X27322, 4588460, AGE26889, AP6328404, EAP12343556, PD00053354, PS12343556
If your old platform shows a different number, contact our support team and we'll check whether it matches.
Compatibility
This kit is listed for GE washer-dryer combo units, including these examples:
GE GUD24ESSM0WW, GUD24ESSM1WW, GUD24GSSM0WW, GUD24GSSM1WW
GE GUD27ESSM0WW, GUD27ESSM1WW, GUD27GSSM0WW, GUD27GSSM1WW, GUD27ESPM0DG, GUD27GSPM0DG
GE GUV27ESSM0WW, GUV27ESSM1WW, XUD27ESSM0WW, XUD27GSSM0WW
Note: The models above are a sample of 27 that retailers list, not a full list. Check your full model number against your parts diagram, or contact our support team to verify fit before ordering.
Key Features
Genuine OEM GE part, not an aftermarket equivalent
Transmission platform assembly and nut kit
Supports the transmission and keeps it aligned with the drum
Sold as a kit
Product Specifications
Part Number
WH49X27322
OEM Part Number
WH49X27322
Part Type
Washer Transmission Platform Assembly Kit
Condition
Genuine OEM
Manufacturer
GE
Quantity
1 Kit
Application
Select GE Washer-Dryer Combos
Installation Notes
⚠️ Disconnect Power And Water Before Installing Unplug the unit and turn off the water supply before you begin. This repair involves the transmission area and is best done with a second person and your model's service guide. Remove the cabinet panels to reach the transmission, remove the screws holding the old platform, install the new platform with the drum and transmission aligned, and secure it with the nut and screws. Reassemble, restore power and water, and run a test cycle.
Frequently Asked Questions
My unit clunks or grinds on spin. Is this the part I need?
It can be. A worn or cracked platform can cause noise and vibration, but worn bearings, drive parts or a loose load can cause similar symptoms. Confirm the platform is the problem before replacing it.
Is this an OEM or aftermarket part?
This is a genuine OEM part from GE, not an aftermarket equivalent.
What is in the kit?
It is sold as the transmission platform assembly and nut kit. Retailers do not list the exact contents, so contact our support team if you need to confirm them before ordering.
Will this fit my washer-dryer?
It is listed for 27 GE washer-dryer combo models, but the model list above is only a sample. Check your full model number against your parts diagram, or contact our support team and we'll verify it before you order.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Genuine OEM Parts ✓ Compatibility Support ✓ Secure Checkout
5304524452 Washer Genuine OEM Drain Pump Assembly
The 5304524452 is a genuine Frigidaire OEM drain pump assembly for Frigidaire stacked laundry center (washer/dryer combo) units, and also fits select Crosley, Electrolux, Gibson, Kelvinator, Westinghouse, and Kenmore models. This pump removes wash water from the tub at the end of each cycle, draining it out before the washer refills with fresh water for rinses.
Common causes of a failing pump include normal wear and tear over time, an obstructed drain line, or issues with the pump housing or impeller. Symptoms of a bad pump assembly include incomplete draining of water at the end of cycles, water pooling in the tub, or the washer failing to advance through its cycle because it can't clear the water. It directly replaces 4246239, 4839543, 4959972, 5304500535, 5304515673, A03077601, AP5962219, AP6333076, AFR19009, AP6989734, BPX401-13J, EAP11703882, EAP12365991, EAP16218540, PD00063454, PS16218540.
Quick Answer
The 5304524452 Washer Genuine OEM Drain Pump Assembly fixes Frigidaire, Crosley, Electrolux, Gibson, Kelvinator, Westinghouse, and Kenmore stacked laundry center units where the washer won't drain, water pools in the tub, or the cycle won't advance past the drain step. Replaces 4246239, 4839543, 4959972, 5304500535, 5304515673, A03077601, AP5962219, AP6333076, AFR19009, AP6989734, BPX401-13J, EAP11703882, EAP12365991, EAP16218540, PD00063454, PS16218540. Several sources note that some replacement drain pumps look similar to this one but aren't the same part — check your original pump's model number or your washing machine's model number carefully before ordering.
Common Problems This Part Fixes
Washer not draining at the end of a cycle
Water pooling or standing in the tub after a completed cycle
Washer failing to advance past the drain step
Incomplete draining leaving damp or soaked clothes
Pump making unusual noise from a damaged impeller
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This washer drain pump assembly directly replaces the following OEM and cross-reference part numbers:
5304524452, 4246239, 4839543, 4959972, 5304500535, 5304515673, A03077601, AP5962219, AP6333076, AFR19009, AP6989734, BPX401-13J, EAP11703882, EAP12365991, EAP16218540, PD00063454, PS16218540
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This drain pump assembly is compatible with select Frigidaire stacked laundry center units, and also fits select Crosley, Electrolux, Gibson, Kelvinator, Westinghouse, and Kenmore combo units built on the same platform, including model numbers such as CFLE3900UW0, CFLE3900UW1, CFLE3900UW3, FFLE3900UW0, FFLE3900UW1, FFLE3900UW2, FFLE3900UW3, FFLE3911QW0, FFLE3911QW1, FFLE39C1QW0, FFLE4033QT0, FFLE4033QW0, FFLE40C3QT0, FFLE40C3QW0, FFLG3900UW0, FFLG3900UW1, FFLG3900UW2, FFLG3900UW5, FFLG3911QW0, FFLG3911QW1, FFLG3911QW2, FFLG4033QT0, FFLG4033QT1, FFLG4033QW0, FFLG4033QW1, SFLG3911RW0, SFLG3911RW1, SFLG4033RT0, SFLG4033RT1, SFLG4033RW0, SFLG4033RW1, and Kenmore 417.61712510, 417.61712511, 417.61722510, 417.61723510, 417.61732810, 417.61733810, 417.71712510, 417.71712511, 417.71722510, 417.71722511, 417.71723510, 417.71723511, 417.71732810, and 417.71733810.
Note — similar-looking but different pumps exist: Some replacement drain pumps are visually similar to this one but aren't compatible. Check your original pump's model number or your washing machine's model number carefully before ordering. Always verify your full model number before ordering. Contact our support team with your model number if you're unsure.
Key Features
Genuine Frigidaire OEM part — factory-specified pump housing and impeller design
Drains wash water from the tub at the end of each cycle
Resolves "won't drain," "water pooling," and "won't advance past drain step" symptoms
Direct drop-in replacement matching the original mounting and hose connections
Replaces 4246239, 4839543, 4959972, 5304500535, 5304515673, A03077601, AP5962219, AP6333076, AFR19009, AP6989734, BPX401-13J, EAP11703882, EAP12365991, EAP16218540, PD00063454, PS16218540
Compatible with Frigidaire, Crosley, Electrolux, Gibson, Kelvinator, Westinghouse, and Kenmore laundry center units
Genuine OEM replacement — guaranteed fit, materials, and performance
Simple DIY repair with basic tools
Product Specifications
Part Number
5304524452
Part Type
Washer Drain Pump Assembly
Condition
Genuine OEM
Brand
Frigidaire
Application
Stacked Washer/Dryer Laundry Centers
Function
Drains wash water from the tub at the end of each cycle
Repair Difficulty
Easy
Quantity
1 drain pump assembly
Compatible Brands
Frigidaire, Crosley, Electrolux, Gibson, Kelvinator, Westinghouse, Kenmore
Installation Notes
⚠️ Unplug The Laundry Center And Shut Off Water Supply Before Starting Disconnect power to the laundry center unit and shut off the water supply before beginning. Wear work gloves and have towels ready for any residual water. Access the pump, typically located at the bottom front or rear of the washer section depending on your model. Remove the clamp attaching the hose to the old pump, then remove the hose. Remove the three screws holding the pump to the washer. Take out the old pump. Install the new 5304524452 in the same position and secure it with the three mounting screws. Reattach the hose to the new pump and secure the clamp. Restore the water supply and power, then run a test cycle to confirm the washer drains completely with no leaks. Tools needed: pliers, screwdriver, work gloves.
Frequently Asked Questions
My washer isn't draining. Is this the part I need?
Yes, this is the most direct symptom of a failed drain pump. Since this pump is responsible for removing wash water from the tub at the end of each cycle, a worn impeller or internal failure can leave water standing in the tub and prevent the washer from advancing to the next stage of the cycle.
Is this a difficult repair?
No, one customer described it as an easy removal and installation: remove the clamp attaching the hose to the pump, remove the hose, remove the three screws holding the pump to the washer, then reverse the process with the new pump.
How do I make sure I'm ordering the correct pump, since some look similar?
Check the model number printed on your original pump, or your washing machine's full model number, before ordering. Multiple sources note that some replacement drain pumps look visually similar to this one but aren't actually compatible, so matching your specific part or model number is the reliable way to confirm fit.
Is this an OEM or aftermarket part?
This is a genuine OEM part, manufactured by Frigidaire to factory specifications — guaranteed fit, materials, and performance. It matches the original pump housing, impeller, and connection type of the drain pump assembly originally installed in your washer.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Genuine OEM Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
XPARTCO 137311900 Washer Drain Pump Assembly – Compatible with Frigidaire & Electrolux Washers
Product Description
Restore proper water drainage and dependable washer operation with the XPARTCO 137311900 Washer Drain Pump Assembly. This high-quality aftermarket replacement pump is designed to efficiently remove water during drain and spin cycles. A worn or failing drain pump can cause standing water, slow draining, error codes, or loud humming noises. Replacing it with this reliable XPARTCO pump helps return your washer to smooth, consistent performance at a budget-friendly price.
XPARTCO aftermarket parts are engineered to match original fit and function while offering a cost-effective alternative to OE or Genuine OEM components.
Replaces Part Numbers
137311900, 2688889, PD00006068, EAP3655041, AP5630474, PS3655041.
Compatibility
This replacement washer drain pump assembly fits select Frigidaire, Electrolux, Crosley, Gibson, and Kenmore (Frigidaire-manufactured) washers.
Example compatible models include (but are not limited to):
Frigidaire FAFW3577KW0, FFTW4120SW
Electrolux EIFLW55HIW0
Always verify your washer’s model number before ordering.Contact our support team if you’re unsure.
✅ Key Features
🔄 Aftermarket Replacement – Matches OEM fit and pumping performance
💧 Efficient Water Removal – Restores proper draining during cycles
🔇 Quiet, Smooth Operation – Helps eliminate humming or grinding noises
💪 Durable Motor & Housing – Built for reliable long-term use
💰 Cost-Effective Repair – Affordable alternative to OE and OEM pumps
📐 Product Specification
Part Number: 137311900
Component Type: Washer Drain Pump Assembly
Voltage: 120V AC
Mounting: Direct-fit, bolt-on installation
Application: Washer drain and spin system
Quality Level: Aftermarket replacement (not OE / not OEM)
🛠️ Installation Notes
Tools Needed: Phillips screwdriver, nut driver, pliers
⚠️ Safety First: Unplug the washer and shut off the water supply before servicing.
Basic Steps:
Disconnect washer power and water supply.
Access the drain pump from the bottom or rear of the washer.
Remove hoses and electrical connectors.
Remove mounting screws and take out the old pump.
Install the new XPARTCO 137311900 drain pump assembly.
Reconnect hoses and wiring, reassemble panels, and restore power.
Run a test cycle to confirm proper draining.
⏱️ Time Required: 25–35 minutes
📦 Shop With Confidence
🚚 Free Shipping on All Orders
⚙️ Trusted Aftermarket Appliance Parts
🔄 30-Day Return Policy
Fix drainage issues and get your washer running smoothly again — Add to Cart Now for a dependable, budget-friendly repair!
