XPARTCO EAU65058315 Refrigerator Evaporator Fan Motor
The XPARTCO EAU65058315 is an aftermarket replacement DC evaporator fan motor assembly for select LG and Kenmore refrigerators, replacing LG part EAU65058315. The evaporator fan motor circulates cold air through the refrigerator, helping to keep temperatures consistent and prevent frost buildup. When it wears out or fails, the refrigerator may run too warm or too cold, build up frost, or make unusual noise.
This is the evaporator fan, which moves air across the evaporator coils, not the condenser fan near the compressor. Check your model number before ordering.
Quick Answer
The XPARTCO EAU65058315 Evaporator Fan Motor replaces the evaporator fan motor on a compatible LG or Kenmore refrigerator when it has failed. Classic symptoms: the refrigerator or freezer is too warm, frost builds up, or the fan makes unusual noise. Other parts can cause the same symptoms, so confirm the fan is the problem first.
Common Problems This Part Fixes
Refrigerator or freezer too warm or too cold
Frost buildup
Unusual noises from the fan area
Moisture or water leaking
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This evaporator fan motor directly replaces the following part number:
EAU65058315, EAU63103209, ODM-056F-15, ALG54104, AP6247423, EAP12115088, PD00081425, PS12115088, PS17308826, AP7211789
LG uses many similar fan motor numbers for different models. If your old motor shows a different number, contact our support team and we'll check whether it matches.
Compatibility
This evaporator fan motor is listed for LG, Kenmore and Kenmore Elite bottom-mount refrigerators, including these examples:
LG LFX25974SW, LFCS22520S, LFDS22520S
Kenmore 79570339411, 79579412811, 79579412810
Kenmore Elite 79579049314, 79579044313
Note: The models above are a sample, not a full list. Check your full model number against your parts diagram, or contact our support team to verify fit before ordering.
Key Features
Aftermarket replacement for the LG EAU65058315 evaporator fan motor
DC motor assembly
Circulates cold air through the refrigerator
Helps keep temperatures consistent and prevent frost buildup
Product Specifications
Part Number
XPEAU65058315
OEM Part Number
EAU65058315
Part Type
Refrigerator Evaporator Fan Motor
Condition
Aftermarket Replacement
Motor Type
DC
Application
Select LG, Kenmore & Kenmore Elite Refrigerators
Installation Notes
⚠️ Unplug Power Before Installing Unplug the refrigerator and move perishable food to a cooler before you begin. Wear work gloves. Follow your model's service guide to reach the evaporator fan, note how the wiring connects, and swap the motor. Reconnect the wiring, restore power, and check that the fan runs quietly.
Frequently Asked Questions
My refrigerator is running warm. Is this the part I need?
It can be, if the evaporator fan has failed. Other parts can cause the same symptoms, so confirm the fan is not blocked by frost and that it fails to spin before replacing it.
Is this the evaporator fan or the condenser fan?
This is the evaporator fan motor, which circulates cold air through the refrigerator. The condenser fan motor is a different part, located near the compressor.
Is this an OEM or aftermarket part?
This is an aftermarket replacement from XPARTCO, made to replace LG part EAU65058315. If you specifically need a genuine LG part, contact our support team.
Will this fit my refrigerator?
It is listed for select LG, Kenmore and Kenmore Elite bottom-mount models, but the model list above is only a sample. Check your full model number against your parts diagram, or contact our support team and we'll verify it before you order.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout
Genuine OEM EAU65058315 Refrigerator Evaporator Fan Motor
The Genuine OEM LG EAU65058315 is a DC evaporator fan motor assembly for select LG and Kenmore refrigerators. The evaporator fan motor circulates cold air through the refrigerator, helping to keep temperatures consistent and prevent frost buildup. When it wears out or fails, the refrigerator may run too warm or too cold, build up frost, or make unusual noise.
This is the original LG part, not an aftermarket equivalent. It is the evaporator fan, not the condenser fan near the compressor. Check your model number before ordering.
Quick Answer
The Genuine OEM EAU65058315 Evaporator Fan Motor replaces the evaporator fan motor on a compatible LG or Kenmore refrigerator when it has failed. Classic symptoms: the refrigerator or freezer is too warm, frost builds up, or the fan makes unusual noise. Other parts can cause the same symptoms, so confirm the fan is the problem first.
Common Problems This Part Fixes
Refrigerator or freezer too warm or too cold
Frost buildup
Unusual noises from the fan area
Moisture or water leaking
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This evaporator fan motor is listed under the following part number:
EAU65058315 replaces EAU63103209, ODM-056F-15, ALG54104, AP6247423, EAP12115088, PD00081425, PS12115088, PS17308826, AP7211789
LG uses many similar fan motor numbers for different models. If your old motor shows a different number, contact our support team and we'll check whether it matches.
Compatibility
This evaporator fan motor is listed for LG, Kenmore and Kenmore Elite bottom-mount refrigerators, including these examples:
LG LFX25974SW, LFCS22520S, LFDS22520S
Kenmore 79570339411, 79579412811, 79579412810
Kenmore Elite 79579049314, 79579044313
Note: The models above are a sample, not a full list. Check your full model number against your parts diagram, or contact our support team to verify fit before ordering.
Key Features
Genuine OEM LG part, not an aftermarket equivalent
DC motor assembly
Circulates cold air through the refrigerator
Helps keep temperatures consistent and prevent frost buildup
Product Specifications
Part Number
EAU65058315
OEM Part Number
EAU65058315
Part Type
Refrigerator Evaporator Fan Motor
Condition
Genuine OEM
Manufacturer
LG
Motor Type
DC
Application
Select LG, Kenmore & Kenmore Elite Refrigerators
Installation Notes
⚠️ Unplug Power Before Installing Unplug the refrigerator and move perishable food to a cooler before you begin. Wear work gloves. Follow your model's service guide to reach the evaporator fan, note how the wiring connects, and swap the motor. Reconnect the wiring, restore power, and check that the fan runs quietly.
Frequently Asked Questions
My refrigerator is running warm. Is this the part I need?
It can be, if the evaporator fan has failed. Other parts can cause the same symptoms, so check that the fan isn't blocked by frost and that the fan itself isn't spinning before replacing it.
Is this the evaporator fan or the condenser fan?
This is the evaporator fan motor, which circulates cold air through the refrigerator. The condenser fan motor is a different part, located near the compressor.
Is this an OEM or aftermarket part?
This is a genuine OEM part from LG, not an aftermarket equivalent.
Will this fit my refrigerator?
It is listed for select LG, Kenmore and Kenmore Elite bottom-mount models, but the model list above is only a sample. Check your full model number against your parts diagram, or contact our support team and we'll verify it before you order.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Genuine OEM Parts ✓ Compatibility Support ✓ Secure Checkout
DA31-00146E Genuine OEM Refrigerator Evaporator Fan Motor - Compatible with Samsung, Maytag
Product Description
Maintain optimal cooling with the DA31-00146E Genuine OEM Refrigerator Evaporator Fan Motor. This Samsung-manufactured motor is designed as a replacement for select Samsung and Maytag refrigerators. It powers the fan to circulate air through the freezer and refrigerator compartments, ensuring even temperature distribution and efficient cooling. This part addresses issues like fridge/freezer too warm, frost buildup, unusual noises, or the appliance not shutting off, often caused by a faulty or seized motor.
Note: Includes (1) evaporator fan motor (fan blade not included). Disconnect power before installation. Verify compatibility with your refrigerator model.
Replaces part numbers: DA31-00146E, 1486536, DA31-00146G, DREP3020LA/HAL, PD00002015, AP4136569, PS4138376.
Compatibility:
Compatible with select refrigerator models, including but not limited to:
Samsung: RFG238AABPXAA0000, RS25H5111BC/AA, RS265TDBP/XAA, RS267TDBP/XAA, RH25H5611BC/AA, RH25H5611WW/AA, DFSF9VKBABB, DFSS9VKBASS
Maytag: Various models (verify with model number)
Verify your model number or contact our support team for assistance.
Key Features:
✅ Brand and Models Compatibility: Fits select Samsung and Maytag refrigerators.
🔧 Specifications: Genuine OEM Samsung BLDC fan motor, 3.21W, 12VDC, 2520RPM, 1-1/2" shaft.
💪 Reliable Performance: Circulates air to maintain consistent temperatures and cool evaporator coils.
🛠️ Easy Installation: Requires screwdriver and pliers; typically installed in 30–60 minutes.
🛡️ Effective Fixes: Resolves warm fridge/freezer, frost buildup, noisy operation, or failure to shut off.
Product Specification
Part Number: DA31-00146E
Component Type: Refrigerator evaporator fan motor
Material: Metal and plastic
Electrical Specs: 3.21W, 12VDC, 2520RPM, 1-1/2" shaft
Compliance: UL-listed, Prop 65 warning for California
Installation Notes:
Safety First: Disconnect the refrigerator from the power source before installation.
Shop for high-quality appliance parts with a 30-day return policy. Keep your refrigerator cooling efficiently today!
Add to cart now for a reliable fix!
XPARTCO XPC5-450R Round Motor Run Capacitor (CBB65, 5 MFD, 450V)
The XPARTCO XPC5-450R is a universal single run capacitor for single-phase AC motors. Unlike a dual run capacitor, which combines two capacitors into one can to serve both a compressor and a fan motor, this is a single capacitor with two terminals, sized for one motor circuit. Once a motor has started, this capacitor stays in the circuit continuously, correcting the phase of the current feeding the motor's auxiliary winding, which improves torque, efficiency, and running smoothness. This 5 MFD size is a very common rating for condenser fan motors, but the same CBB65-style capacitor is also widely used on pool pumps, small air compressors, washing machines, and other single-phase motor equipment.
Rated 5 MFD at 450VAC. Like all run capacitors, this one stores an electrical charge even after power is disconnected, and it should always be treated as energized until properly discharged. Over time, the dielectric material inside breaks down from heat and electrical stress, causing the capacitor to lose capacitance or fail outright. A failing run capacitor produces a recognizable symptom set: the motor hums but won't start, runs weakly, overheats, trips a breaker or overload protector, or the capacitor can itself becomes visibly bulged, domed, or leaks oily residue at the top.
Quick Answer
The XPARTCO XPC5-450R Round Motor Run Capacitor fixes single-phase motor equipment — condenser fan motors, pool pumps, small compressors, and similar applications — where the motor hums but won't start, runs weakly, overheats, or trips its breaker or overload protector. 5 MFD, 450VAC, round CBB65-style capacitor, 2 terminals. Capacitors store a dangerous electrical charge even after power is disconnected — always discharge before handling.
Common Problems This Part Fixes
Motor hums but won't start
Motor runs, but weakly or with reduced torque
Motor runs hot or trips its internal overload protector
Fan or pump won't start on its own but will run if given a manual push
Equipment trips the circuit breaker shortly after starting
Capacitor can visibly bulging, domed on top, or leaking oily residue
Motor that used to start slowly and has now stopped starting altogether
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
XPC5-450R
This is a universal component rather than a single-manufacturer part, so the specific OEM number your equipment's label references will vary by brand. This capacitor is a correct replacement for any single run capacitor matching the 5 MFD rating with a voltage rating of 450V or lower. If you have your original part number, contact our support team and we will verify compatibility before you order.
Compatibility
This single run capacitor is a universal replacement compatible with single-phase AC motor equipment across all major brands, wherever the original capacitor is rated:
5 MFD
370V, 440V, or 450V (this capacitor's 450V rating exceeds and safely replaces either lower rating)
Round can shape with 2 terminals
Common applications include central air conditioner and heat pump condenser fan motors, pool and spa pumps, small single-phase air compressors, and various single-phase motor equipment.
Note — single run, not dual: This is a single-motor capacitor with 2 terminals, distinct from our dual run capacitors (such as the XPDC80X5-450R and similar listings), which combine two capacitors and 3 terminals to serve both a compressor and a fan motor from one can. If your equipment's original capacitor has 3 terminals labeled C, Herm, and Fan, you need a dual capacitor instead of this single one. The MFD rating must match your original capacitor exactly; voltage rating can be equal to or higher than the original, but never lower. Always verify your original capacitor's specifications, printed on its can, before ordering. Contact our support team if you'd like help confirming compatibility.
Key Features
Universal single run capacitor for single-phase AC motors
5 MFD rating in a compact round can — a common size for condenser fan motors and similar equipment
450VAC rating — a safe upgrade replacement for equipment originally speced at 370V or 440V
Round CBB65-style can construction
Resolves "hums but won't start," "runs weakly," "overheats," and "trips the breaker" symptoms caused by capacitor failure
2 quick-connect terminals for a direct plug-on fit to standard motor wiring
50/60Hz rated
Built to meet or exceed industry-standard specifications for this capacitor class
Product Specifications
Part Number
XPC5-450R
Part Type
Single Run Capacitor
Condition
New — Universal Replacement Part
Capacitance
5 MFD (µF)
Voltage Rating
450VAC
Shape
Round
Terminals
2 (quick-connect)
Frequency
50/60 Hz
Tolerance
±5%
Construction Type
Polypropylene film capacitor
Operating Temperature Range
-40°C to 70°C (-40°F to +158°F)
Safety Approvals
CQC, VDE, TÜV, CL
Approval Standard
GB/T 3667, EN 60252
Application
Single-Phase AC Motors — Condenser Fans, Pool Pumps, Small Compressors
Quantity
1 single run capacitor
Compatible Brands
Universal — all major brands
Installation Notes
⚠️ Danger — Capacitors Store A Dangerous Electrical Charge Shut off power to the equipment at the disconnect box and at the breaker before beginning. A capacitor stores an electrical charge even after power has been disconnected, and that charge can deliver a serious or fatal shock. Before touching either terminal, discharge the capacitor by shorting the two terminals together using an insulated-handle screwdriver, or by using a proper capacitor discharge tool with a resistor. Never short the terminals with a bare metal tool held with your bare hand. If you are not fully comfortable performing a capacitor discharge safely, have a qualified technician replace this part instead.
⚠️ Photograph The Wiring Before Disconnecting Wear work gloves and safety glasses. After confirming the capacitor is fully discharged, photograph the wiring on the old capacitor's terminals before disconnecting anything. Note which wire came from which terminal, or label them individually with tape. Remove the mounting strap or bracket holding the old capacitor in its housing, and disconnect each wire from its terminal. Install the new XPC5-450R in the same mounting position, secure it with the strap or bracket, and reconnect each wire to its matching terminal exactly as labeled. Double-check both connections before restoring power. Restore power at the breaker and disconnect box, and confirm the motor starts promptly and runs smoothly. Tools needed: insulated-handle screwdriver or capacitor discharge tool, nut driver, work gloves, safety glasses.
Frequently Asked Questions
How do I know if I need this single capacitor or a dual run capacitor?
Look at your old capacitor's terminals. If it has only 2 terminals serving one motor circuit, this single capacitor is the correct type. If it has 3 terminals labeled C, Herm, and Fan (or similar), it's a dual capacitor serving both a compressor and a fan motor from one can, and you'll need a dual capacitor such as our XPDC-series listings instead. The two types are not interchangeable.
Can I use a 450V capacitor to replace my old 370V or 440V one?
Yes. Voltage rating is a ceiling, not an exact match requirement — a capacitor rated for a higher voltage than your original will work safely and often lasts longer under the same electrical stress. What you cannot do is go the other direction: never install a capacitor with a lower voltage rating than your original, since that risks premature failure or the capacitor breaking down under normal operating conditions.
My fan or pump motor hums but won't start. Is this the capacitor?
It's one of the most common causes of exactly that symptom. A run capacitor gives the motor the extra push needed to start turning; without it working correctly, the motor can draw power and hum in place without ever actually starting to spin. If you can see the capacitor can and it looks bulged, domed on top, or is leaking a brown oily residue, that's strong visual confirmation of failure.
Is this a genuine OEM part?
This is a universal replacement part rather than a brand-specific OEM part. Because run capacitors are a standardized component defined by their electrical specifications rather than their manufacturer, this capacitor is a correct replacement for any equipment's original capacitor that shares the same 5 MFD, 450VAC, round rating — regardless of which brand originally installed it.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Quality Replacement Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
LCR5X440 HVAC OVAL MOTOR RUN CAPACITOR
Engineered by an ISO manufacturer with over twenty years' experience in OEM capacitor fabrication, Linebacker® capacitors are manufactured by the OEM factory and are 100% in-line production tested to the same rigorous standards.
Features/Benefits
10,000 AFC pressure sensitive short circuit interrupting capability
3-year warranty from the date of purchase
Continuous life tested, oil leak tested and dielectric tested for insulation effectiveness
Life tested to 85° C operating temperature for 10,000 cycles
Manufactured with thick polypropylene foil to handle increased operating temperatures
Meets EIA-456A accelerated life test at 70° C for 60,000 hours
PCB-free oil to prevent over-heating
UL File # E352486
US and Canada UL approved (C22.2NO.190)
Applications
Air conditioning compressors
Refrigeration Compressors
Furnace blower motors
Condenser fan motors
Specification:
Voltage:
Up to 440 VAC
Operating Temperature:
-40°F to 185°F (-40°C to 85°C)
Foil Thickness:
6.0 µm +/- 5%
Standard Tolerance:
+/- 5%
MFD Value:
5
Style:
Oval
Size:
2.03x1.24x1.57
XPARTCO XPC75-450R Round Run / Start Capacitor (CBB65, 7.5 MFD, 450V)
The XPARTCO XPC75-450R is a universal single run capacitor for single-phase AC motors. Unlike a dual run capacitor, which combines two capacitors into one can to serve both a compressor and a fan motor, this is a single capacitor with two terminals, sized for one motor circuit. Once a motor has started, this capacitor stays in the circuit continuously, correcting the phase of the current feeding the motor's auxiliary winding, which improves torque, efficiency, and running smoothness. This 7.5 MFD size is a very common rating for condenser fan motors, but the same CBB65-style capacitor is also widely used on pool pumps, small air compressors, washing machines, and other single-phase motor equipment.
Rated 7.5 MFD at 450VAC. Like all run capacitors, this one stores an electrical charge even after power is disconnected, and it should always be treated as energized until properly discharged. Over time, the dielectric material inside breaks down from heat and electrical stress, causing the capacitor to lose capacitance or fail outright. A failing run capacitor produces a recognizable symptom set: the motor hums but won't start, runs weakly, overheats, trips a breaker or overload protector, or the capacitor can itself becomes visibly bulged, domed, or leaks oily residue at the top.
Quick Answer
The XPARTCO XPC75-450R Round Motor Run Capacitor fixes single-phase motor equipment — condenser fan motors, pool pumps, small compressors, and similar applications — where the motor hums but won't start, runs weakly, overheats, or trips its breaker or overload protector. 7.5 MFD, 450VAC, round CBB65-style capacitor, 2 terminals. Capacitors store a dangerous electrical charge even after power is disconnected — always discharge before handling.
Common Problems This Part Fixes
Motor hums but won't start
Motor runs, but weakly or with reduced torque
Motor runs hot or trips its internal overload protector
Fan or pump won't start on its own but will run if given a manual push
Equipment trips the circuit breaker shortly after starting
Capacitor can visibly bulging, domed on top, or leaking oily residue
Motor that used to start slowly and has now stopped starting altogether
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
XPC75-450R
This is a universal component rather than a single-manufacturer part, so the specific OEM number your equipment's label references will vary by brand. This capacitor is a correct replacement for any single run capacitor matching the 7.5 MFD rating with a voltage rating of 450V or lower. If you have your original part number, contact our support team and we will verify compatibility before you order.
Compatibility
This single run capacitor is a universal replacement compatible with single-phase AC motor equipment across all major brands, wherever the original capacitor is rated:
7.5 MFD
370V, 440V, or 450V (this capacitor's 450V rating exceeds and safely replaces either lower rating)
Round can shape with 2 terminals
Common applications include central air conditioner and heat pump condenser fan motors, pool and spa pumps, small single-phase air compressors, and various single-phase motor equipment.
Note — single run, not dual: This is a single-motor capacitor with 2 terminals, distinct from our dual run capacitors (such as the XPDC80X5-450R and similar listings), which combine two capacitors and 3 terminals to serve both a compressor and a fan motor from one can. If your equipment's original capacitor has 3 terminals labeled C, Herm, and Fan, you need a dual capacitor instead of this single one. The MFD rating must match your original capacitor exactly; voltage rating can be equal to or higher than the original, but never lower. Always verify your original capacitor's specifications, printed on its can, before ordering. Contact our support team if you'd like help confirming compatibility.
Key Features
Universal single run capacitor for single-phase AC motors
7.5 MFD rating in a compact round can — a common size for condenser fan motors and similar equipment
450VAC rating — a safe upgrade replacement for equipment originally speced at 370V or 440V
Round CBB65-style can construction
Resolves "hums but won't start," "runs weakly," "overheats," and "trips the breaker" symptoms caused by capacitor failure
2 quick-connect terminals for a direct plug-on fit to standard motor wiring
50/60Hz rated
Built to meet or exceed industry-standard specifications for this capacitor class
Product Specifications
Part Number
XPC75-450R
Part Type
Single Run Capacitor
Condition
New — Universal Replacement Part
Capacitance
7.5 MFD (µF)
Voltage Rating
450VAC
Shape
Round
Terminals
2 (quick-connect)
Frequency
50/60 Hz
Tolerance
±5%
Construction Type
Polypropylene film capacitor
Operating Temperature Range
-40°C to 70°C (-40°F to +158°F)
Safety Approvals
CQC, VDE, TÜV, CL
Approval Standard
GB/T 3667, EN 60252
Application
Single-Phase AC Motors — Condenser Fans, Pool Pumps, Small Compressors
Quantity
1 single run capacitor
Compatible Brands
Universal — all major brands
Installation Notes
⚠️ Danger — Capacitors Store A Dangerous Electrical Charge Shut off power to the equipment at the disconnect box and at the breaker before beginning. A capacitor stores an electrical charge even after power has been disconnected, and that charge can deliver a serious or fatal shock. Before touching either terminal, discharge the capacitor by shorting the two terminals together using an insulated-handle screwdriver, or by using a proper capacitor discharge tool with a resistor. Never short the terminals with a bare metal tool held with your bare hand. If you are not fully comfortable performing a capacitor discharge safely, have a qualified technician replace this part instead.
⚠️ Photograph The Wiring Before Disconnecting Wear work gloves and safety glasses. After confirming the capacitor is fully discharged, photograph the wiring on the old capacitor's terminals before disconnecting anything. Note which wire came from which terminal, or label them individually with tape. Remove the mounting strap or bracket holding the old capacitor in its housing, and disconnect each wire from its terminal. Install the new XPC75-450R in the same mounting position, secure it with the strap or bracket, and reconnect each wire to its matching terminal exactly as labeled. Double-check both connections before restoring power. Restore power at the breaker and disconnect box, and confirm the motor starts promptly and runs smoothly. Tools needed: insulated-handle screwdriver or capacitor discharge tool, nut driver, work gloves, safety glasses.
Frequently Asked Questions
How do I know if I need this single capacitor or a dual run capacitor?
Look at your old capacitor's terminals. If it has only 2 terminals serving one motor circuit, this single capacitor is the correct type. If it has 3 terminals labeled C, Herm, and Fan (or similar), it's a dual capacitor serving both a compressor and a fan motor from one can, and you'll need a dual capacitor such as our XPDC-series listings instead. The two types are not interchangeable.
Can I use a 450V capacitor to replace my old 370V or 440V one?
Yes. Voltage rating is a ceiling, not an exact match requirement — a capacitor rated for a higher voltage than your original will work safely and often lasts longer under the same electrical stress. What you cannot do is go the other direction: never install a capacitor with a lower voltage rating than your original, since that risks premature failure or the capacitor breaking down under normal operating conditions.
My fan or pump motor hums but won't start. Is this the capacitor?
It's one of the most common causes of exactly that symptom. A run capacitor gives the motor the extra push needed to start turning; without it working correctly, the motor can draw power and hum in place without ever actually starting to spin. If you can see the capacitor can and it looks bulged, domed on top, or is leaking a brown oily residue, that's strong visual confirmation of failure.
Is this a genuine OEM part?
This is a universal replacement part rather than a brand-specific OEM part. Because run capacitors are a standardized component defined by their electrical specifications rather than their manufacturer, this capacitor is a correct replacement for any equipment's original capacitor that shares the same 7.5 MFD, 450VAC, round rating — regardless of which brand originally installed it.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Quality Replacement Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
XPARTCO XPDC45X5-450R Dual Run Capacitor (45/5 MFD, 450V, Round)
The XPARTCO XPDC45X5-450R is a universal dual run capacitor for central air conditioners, heat pumps, and condensing units. A run capacitor works alongside a single-phase AC motor to keep it running efficiently once it's started, boosting torque and correcting the phase of the current feeding the motor's windings. This is a dual capacitor, meaning it combines two separate capacitors — one for the compressor, one for the condenser fan motor — into a single three-terminal can, which is why nearly every residential outdoor AC unit uses exactly this style of component to run both motors from one part.
Rated 45 MFD for the compressor circuit and 5 MFD for the fan motor circuit, at 450VAC, in a round aluminum can housing. Because a capacitor's voltage rating is a ceiling rather than a fixed match, this 450V-rated capacitor can safely replace an original capacitor rated 370V or 440V — going higher on voltage is always safe, going lower is not. Over time, the dielectric material inside a run capacitor breaks down from heat cycling and electrical stress, causing it to lose capacitance or fail outright. A failing dual capacitor produces a very recognizable set of symptoms: the outdoor unit hums but the compressor or fan won't start, the fan spins slowly or needs a manual push to get going, the system trips the breaker, or the capacitor can itself is visibly bulging, domed, or leaking oily residue at the top.
Quick Answer
The XPARTCO XPDC45X5-450R Dual Run Capacitor fixes central air conditioners and heat pumps where the outdoor unit hums but won't start, the compressor or fan motor won't run, the fan spins slowly or needs a manual push, the breaker trips, or the capacitor can is visibly bulged or leaking. 45 MFD (compressor) + 5 MFD (fan) dual capacitor, 450VAC, round, 3-terminal. Universal fit for equipment originally speced at 370V or 440V, since a higher voltage rating is always a safe upgrade. Capacitors store a dangerous electrical charge even after power is disconnected — always discharge before handling.
Common Problems This Part Fixes
Outdoor AC unit hums but the compressor won't start
Condenser fan won't spin, or spins slowly and needs a manual push to get going
System trips the breaker shortly after starting
AC blows warm air because the compressor isn't running
Repeated clicking sound from the contactor as it tries and fails to start the motor
Capacitor can visibly bulging, domed on top, or leaking oily residue
System that used to start slowly and has now stopped starting altogether
Burning smell from the outdoor unit's electrical compartment
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
XPDC45X5-450R
This is a universal component rather than a single-manufacturer part, so the specific OEM number your HVAC system's label references will vary by brand (Goodman, Trane, Carrier, Rheem, York, Lennox, Amana, and others). This capacitor is a correct replacement for any dual run capacitor matching the 45 MFD / 5 MFD rating with a voltage rating of 450V or lower. If you have your original part number, contact our support team and we will verify compatibility before you order.
Compatibility
This dual run capacitor is a universal replacement compatible with central air conditioners, heat pumps, and condensing units across all major HVAC brands, wherever the original capacitor is rated:
45 MFD (compressor) + 5 MFD (fan motor)
370V, 440V, or 450V (this capacitor's 450V rating exceeds and safely replaces either lower rating)
Round can shape with 3 terminals
Note: The MFD (microfarad) rating must match your original capacitor exactly on both sides — do not substitute a different MFD value for either the compressor or fan side. Voltage rating, on the other hand, can be equal to or higher than the original (450V safely replaces 370V or 440V), but never lower. Can shape (round vs. oval) affects only physical fit inside your unit's electrical compartment, not performance. If you're unsure of your original capacitor's specifications, they're printed directly on its can — contact our support team if you'd like help confirming compatibility.
Key Features
Universal dual run capacitor — supports both the compressor and condenser fan motor from one component
45 MFD compressor rating + 5 MFD fan motor rating in a single 3-terminal can
450VAC rating — a safe upgrade replacement for equipment originally speced at 370V or 440V
Round aluminum can construction
Resolves "hums but won't start," "fan spins slowly," "trips the breaker," and "bulging or leaking can" symptoms caused by capacitor failure
1/4" quick-connect terminals for a direct plug-on fit to standard HVAC wiring
50/60Hz rated
Safety approved: CQC, VDE, TÜV, and CL; built to GB/T 3667 and EN 60252 standards
Built to meet or exceed industry-standard specifications for this capacitor class
Product Specifications
Part Number
XPDC45X5-450R
Part Type
Dual Run Capacitor
Condition
New — Universal Replacement Part
Capacitance — Compressor
45 MFD (µF)
Capacitance — Fan Motor
5 MFD (µF)
Voltage Rating
450VAC
Shape
Round
Terminals
3 (1/4" quick-connect)
Frequency
50/60 Hz
Tolerance
±5%
Construction Type
Polypropylene film capacitor
Operating Temperature Range
-40°C to 70°C (-40°F to +158°F)
Safety Approvals
CQC, VDE, TÜV, CL
Approval Standard
GB/T 3667, EN 60252
Application
Central Air Conditioners, Heat Pumps, Condensing Units
Quantity
1 dual run capacitor
Compatible Brands
Universal — all major HVAC brands
Installation Notes
⚠️ Danger — Capacitors Store A Dangerous Electrical Charge Shut off power to the outdoor unit at the disconnect box and at the breaker before beginning. A capacitor stores an electrical charge even after power has been disconnected, and that charge can deliver a serious or fatal shock. Before touching any terminal, discharge the capacitor by shorting each pair of terminals together (C-to-Fan, C-to-Herm, and Fan-to-Herm) using an insulated-handle screwdriver, or by using a proper capacitor discharge tool with a resistor. Never short the terminals with a bare metal tool held with your bare hand. If you are not fully comfortable performing a capacitor discharge safely, have a qualified HVAC technician replace this part instead.
⚠️ Photograph The Wiring Before Disconnecting — Match Terminals Exactly Wear work gloves and safety glasses. After confirming the capacitor is fully discharged, photograph the wiring on the old capacitor's terminals before disconnecting anything — dual capacitors are labeled C (Common), Herm or Comp (compressor/hermetic), and Fan, and getting a wire on the wrong terminal can damage the new capacitor or the motor it feeds. Note which terminal each wire came from, or label them individually with tape. Remove the mounting strap or bracket holding the old capacitor in its housing, and disconnect each wire from its terminal. Install the new XPDC45X5-450R in the same mounting position, secure it with the strap or bracket, and reconnect each wire to the matching terminal (C, Herm, and Fan) exactly as labeled. Double-check every connection before restoring power. Restore power at the breaker and disconnect box, and confirm the compressor and fan both start promptly and run smoothly. Tools needed: insulated-handle screwdriver or capacitor discharge tool, nut driver, work gloves, safety glasses.
Frequently Asked Questions
My AC unit hums but won't start. Is this the capacitor?
It's one of the most common causes of exactly that symptom. A run capacitor gives the compressor or fan motor the extra push needed to start turning; without it, the motor can draw power and hum in place without ever actually starting to spin. If you can see the capacitor can and it looks bulged, domed on top, or is leaking a brown oily residue, that's strong visual confirmation of failure.
Can I use a 450V capacitor to replace my old 370V or 440V one?
Yes. Voltage rating is a ceiling, not an exact match requirement — a capacitor rated for a higher voltage than your original will work safely and often lasts longer under the same electrical stress. What you cannot do is go the other direction: never install a capacitor with a lower voltage rating than your original, since that risks premature failure or the capacitor breaking down under normal operating conditions.
Does the round vs. oval shape matter?
Only for physical fit inside your unit's electrical compartment — it has no effect on electrical performance. If your unit's mounting bracket or available space is sized for a round can, use a round capacitor; if it's sized for an oval can, use an oval one. The MFD and voltage ratings are what matter electrically, not the shape.
The fan spins if I give it a push, but won't start on its own. What does that mean?
This is a classic sign of a weak or failing capacitor — it may still have enough charge to keep the motor running once it's already spinning, but not enough to provide the initial starting torque. This is a strong signal to replace the capacitor before it fails completely and leaves you with no cooling at all.
Is this a genuine OEM part?
This is a universal replacement part rather than a brand-specific OEM part. Because dual run capacitors are a standardized component defined by their electrical specifications rather than their manufacturer, this capacitor is a correct replacement for any unit's original capacitor that shares the same 45/5 MFD, 450VAC, round dual run capacitor rating — regardless of which HVAC brand originally installed it.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Quality Replacement Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
809069207 Refrigerator Genuine OEM Evaporator Fan Motor – Compatible with Frigidaire, Electrolux, and Kenmore Refrigerators
Product Description
Restore powerful and consistent cooling with the 809069207 Refrigerator Genuine OEM Evaporator Fan Motor. This factory-approved motor circulates cold air throughout the refrigerator and freezer compartments, ensuring even temperature distribution. A failing fan motor can cause warm spots, frost buildup, poor cooling, or unusual noises. Replacing it with this Genuine OEM part ensures dependable performance and the same airflow efficiency your appliance had when new.
Replaces Part Numbers
809069207, PD00064424, EAP12705983, AP6834878, PS12705983.
Compatibility
This Genuine OEM evaporator fan motor fits select Frigidaire, Electrolux, and Kenmore refrigerators.
Example compatible models include (but are not limited to):Frigidaire FFHS2622MB3, FFSS2615TS0, Electrolux EI23CS55GS1, and Kenmore 253.7031321A.
Always verify your refrigerator’s model number before ordering. Contact our support team if you’re unsure.
✅ Key Features
🧩 Genuine OEM Replacement – Factory-certified for perfect fit and long-lasting performance
❄️ Restores Air Circulation – Ensures even cooling in fresh food and freezer sections
🔇 Quiet Motor Operation – Balanced OEM motor design lowers noise and vibration
💪 High Durability – Built with premium materials for extended service life
🛡️ Fixes Common Issues – Solves poor cooling, frost buildup, noisy fan, or warm temperatures
📐 Product Specification
Part Number: 809069207
Component Type: Refrigerator Evaporator Fan Motor
Material: Reinforced plastic fan housing with factory motor
Voltage: 115V AC (model dependent)
Mounting: Direct-fit motor mounted behind freezer interior panel
Compliance: Genuine OEM certified
🛠️ Installation Notes
Tools Needed: Phillips screwdriver, nut driver
⚠️ Safety First: Always unplug the refrigerator before servicing to avoid electrical shock.
Steps:
Disconnect power and remove freezer shelves and panels.
Locate the evaporator fan assembly.
Disconnect the wiring harness and remove the old motor.
Install the new 809069207 motor in the same location.
Reassemble interior panels and restore power.
Allow several minutes for airflow to stabilize.
⏱️ Time Required: 20–30 minutes
📦 Shop With Confidence
🚚 Free Shipping on All Orders
⚙️ Genuine OEM Replacement Part
🔄 30-Day Return Policy
Restore powerful, even cooling — Add to Cart Now for a factory-quality repair!
XPARTCO EAU63103201 Refrigerator Evaporator Fan Motor
The XPARTCO EAU63103201 is an aftermarket replacement evaporator fan motor for LG and select Kenmore/Kenmore Elite refrigerators. On this platform, the fan sits behind a panel near the crisper drawers and circulates air specifically through the fresh food compartment — a different physical location than the freezer-mounted evaporator fans found on many other brands. When this motor slows down or fails, the fresh food section is the part of the refrigerator most directly affected, since it depends on this fan to keep cold air moving across the compartment.
Rated 12V DC at 1A with a 4-pin connector, this motor has a 2.36" (60mm) shaft length and a 0.12" (3.16mm) shaft diameter, with roughly a 20.5" (56cm) wire lead. Common failure modes include worn motor bearings that let the blade wobble or bind, and general electrical wear from age. A fridge running warm, not cold at all, or making unusual noise from behind the crisper area are all signs pointing to this motor. It directly replaces 4391461, AP6317185, PS11761147, EAP11761147, and PD00051700. Also identified by its production number, ODM-001F-41.
Quick Answer
The XPARTCO EAU63103201 Refrigerator Evaporator Fan Motor fixes LG and select Kenmore/Kenmore Elite refrigerators where the fresh food compartment runs too warm or isn't cooling at all, or there's unusual noise from behind the crisper drawer area. DC 12V, 1A, 4-pin connector, 2.36" (60mm) shaft length, 0.12" (3.16mm) shaft diameter. Replaces 4391461, AP6317185, PS11761147, EAP11761147, PD00051700. LG uses several similarly-numbered EAU-prefix fan motors across its lineup — this is a different part from the EAU63923603/EAU65058305 assembly used on other LG models, so verify your exact model number before ordering.
Common Problems This Part Fixes
Fresh food compartment running too warm
Refrigerator not cooling at all in the fresh food section
Unusual noise coming from behind the crisper drawer area
Fan motor that won't run due to aging or internal damage
Refrigerator running constantly as it struggles to maintain temperature
Fan blade that doesn't spin freely, or spins with noticeable resistance, when checked by hand
Frost or condensation forming near the fan location behind the crisper panel
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This refrigerator evaporator fan motor directly replaces the following OEM and cross-reference part numbers:
EAU63103201, ODM-001F-41, 4391461, ALG1473540, AP6317185, PS11761147, OEM18086529, EAP11761147, PD00051700
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This evaporator fan motor is compatible with select LG refrigerators, and also fits select Kenmore and Kenmore Elite refrigerators built on the LG platform, including model numbers such as:
LG LRSES2706V, LRSPS2706V
LG LSXC22396D, LSXC22396S, LSXC22426S, LSXC22436S
LG LSXC22486D, LSXC22486S
LG LSXS26326B, LSXS26326S, LSXS26326W
LG LSXS26336S, LSXS26336V, LSXS26336D
LG LSXS26386S, LSXS26396S
Kenmore 795.5173381, 795.5173781, 795.5183241, 795.5183242, 795.5183341, 795.5183941, 795.5183942, 795.5185361, 795.5185761, 795.5186261, 795.5186361, 795.5186761, 795.5186961
Note: LG uses several different evaporator fan motors across its refrigerator lineup with similar EAU-prefix part numbers. This EAU63103201 motor is a separate, distinct part from the EAU63923603 / EAU65058305 fan motor assembly used on other LG models (such as the LFXS28596S, LMXS28626S, LFXS26596S, and LFXS26973D series) — the two are not interchangeable. Always verify your full model number before ordering. Contact our support team with your model number if you're unsure which fan motor your refrigerator needs.
Key Features
Aftermarket replacement evaporator fan motor — circulates air through the fresh food compartment
Resolves "fresh food too warm," "not cooling at all," and "noise behind the crisper drawer" symptoms caused by fan motor failure
Rated 12V DC, 1A, with a 4-pin connector for direct plug-and-play electrical fit
2.36" (60mm) shaft length, 0.12" (3.16mm) shaft diameter
Approximately 20.5" (56cm) wire lead
Direct drop-in replacement matching the original mounting and blade fitment
Replaces 4391461, AP6317185, PS11761147, EAP11761147, and PD00051700
Compatible with LG and select Kenmore/Kenmore Elite refrigerators
Aftermarket replacement built to OEM-equivalent quality standards
Straightforward DIY repair — just a screwdriver needed on most models
Product Specifications
Part Number
XPEAU63103201
OEM Part Number
EAU63103201 (ODM-001F-41)
Part Type
Refrigerator Evaporator Fan Motor
Condition
Aftermarket Replacement
Compatible Brand
LG, Kenmore
Location
Behind panel near the crisper drawers, fresh food compartment
Voltage
12V DC
Amperage
1 A
Connector
4-pin
Shaft Length
2.36 in. (60mm)
Shaft Diameter
0.12 in. (3.16mm)
Wire Lead Length
Approx. 20.5 in. (56cm)
Color
Gray
Material
Plastic and metal
Quantity
1 fan motor
Compatible Brands
LG, Kenmore, Kenmore Elite
Installation Notes
⚠️ Unplug Refrigerator Before Starting Disconnect power at the outlet before beginning. Wear work gloves. Access on this platform is different from many other brands: rather than removing a rear panel inside the freezer, slide the crisper drawer out fully, then remove the panel behind or above the drawer area to expose the fan motor. Photograph the wiring connector and the fan blade's position before disconnecting anything. Disconnect the 4-pin electrical connector from the old motor, remove the mounting screws or clips holding the motor bracket in place, and carefully pull the motor and fan blade assembly free. Transfer the fan blade to the new motor if a blade isn't included, matching the original orientation on the 60mm shaft. Mount the new EAU63103201 in the same position, reconnect the 4-pin connector fully, and confirm the blade spins freely by hand without contacting the housing before reassembling the panel and sliding the crisper drawer back into place. Restore power and monitor the fresh food compartment over the next several hours to confirm normal cooling has returned. Tools needed: Phillips screwdriver, work gloves.
Frequently Asked Questions
Why is this fan located near the crisper drawers instead of in the freezer?
LG's refrigerator platform routes cold air to the fresh food compartment differently than many other brands, with this particular fan positioned behind a panel near the crisper drawer area rather than inside the freezer compartment. That's simply a difference in refrigerator design between manufacturers — it doesn't affect the fan's job, which is still to keep cold air circulating through the fresh food section, but it does mean the access point for this repair looks different from what you might expect if you've worked on a different brand before.
My fridge section is warm but everything else seems fine. Is this the right part?
Yes, this is the classic symptom this motor addresses. Since this fan specifically circulates air through the fresh food compartment, a failure here tends to affect that section directly — a warm fridge with an otherwise normally-functioning freezer points squarely at this motor rather than at the compressor or refrigerant system.
There are several similar LG fan motor part numbers online. How do I know I have the right one?
LG's EAU-prefix fan motors can look similar at a glance, but they aren't interchangeable — for example, the EAU63923603/EAU65058305 assembly used on models like the LFXS28596S and LMXS28626S is a completely different part from this EAU63103201 motor. The safest way to confirm is to check your refrigerator's full model number against a verified compatibility list, or contact our support team with your model number before ordering.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine LG OEM part, but is manufactured to match the electrical specifications (12V DC, 1A, 4-pin connector), shaft dimensions, and mounting configuration of the original EAU63103201 evaporator fan motor used in compatible LG and Kenmore refrigerators.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Quality Aftermarket Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
Genuine OEM 808602602 Refrigerator Evaporator Fan Motor - Compatible with Frigidaire, Kenmore, Crosley, White-Westinghouse Refrigerators
Product Description
Restore optimal cooling with the Genuine OEM 808602602 Refrigerator Evaporator Fan Motor. This authentic Frigidaire-manufactured motor, designed for Frigidaire, Kenmore, Crosley, and White-Westinghouse refrigerators, powers the evaporator fan to circulate cold air throughout the refrigerator and freezer compartments. Constructed with durable ABS plastic and metal (120V, 60Hz, 0.1A, 6W), this motor resolves issues like inconsistent temperatures, frost buildup, or excessive noise.
Note: Includes one evaporator fan motor with wiring harness. Disconnect power before installation. Take photos of wiring during disassembly for accurate replacement.
Replaces part numbers: 808602602, 241854601, 808602601, 4931129, PD00055240, EAP12729077, AP6893151, PS12729077.
Compatibility:
Compatible with models including but not limited to:
Frigidaire: FFSS2625TS2, FFSS2625TS1, FFSS2625TP2, FFSS2625TE1, FFSS2625TE2, FFSS2625TP1, BFHS2611LM0, BFHS2611LM1, BFHS2611LM2, DFHS2313MF0, DFHS2313MF1, FFHS2311LB0, FFHS2311LW0
Kenmore: 25355333607
Crosley: CRSH232PB0, CRSH232PB1, CRSH232PB2, CRSH232PB3, CRSH232PB5, CRSH232PB6, CRSH232PB7A, CRSH232PB8A, CRSH232PB9A, CRSH232PBEA
White-Westinghouse: FFSS2625TS2, FFSS2625TS1, FFSS2625TP2, FFSS2625TE1, FFSS2625TE2, FFSS2625TP1
Verify your model number or contact our support team for assistance.
Key Features:
✅ Brand and Models Compatibility: Fits select Frigidaire, Kenmore, Crosley, and White-Westinghouse refrigerator models.
🔥 Specifications: Genuine OEM evaporator fan motor, 120V, 60Hz, 0.1A, 6W, 4-pin connector, ABS plastic/metal construction, 1.25 lbs, corrosion-resistant.
💰 Premium Quality: Authentic Frigidaire part ensures reliability and compatibility, backed by manufacturer standards.
🛠️ Easy Installation: Requires Phillips screwdriver, work gloves; typically installed in 20–40 minutes.
🛡️ Reliable Fixes: Resolves inconsistent temperatures, frost/ice buildup, uneven cooling, or excessive fan noise.
Installation Notes:
Safety First: Disconnect the refrigerator from the power source before installation.
Shop Parts-O-Matic for authentic OEM appliance parts with a 30-day return policy. Ensure consistent cooling in your refrigerator today!
Add to cart now for a reliable, OEM-quality fix!
XPARTCO XPDC40X5-450R Dual Run Capacitor (40/5 MFD, 450V, Round)
The XPARTCO XPDC40X5-450R is a universal dual run capacitor for central air conditioners, heat pumps, and condensing units. A run capacitor works alongside a single-phase AC motor to keep it running efficiently once it's started, boosting torque and correcting the phase of the current feeding the motor's windings. This is a dual capacitor, meaning it combines two separate capacitors — one for the compressor, one for the condenser fan motor — into a single three-terminal can, which is why nearly every residential outdoor AC unit uses exactly this style of component to run both motors from one part.
Rated 40 MFD for the compressor circuit and 5 MFD for the fan motor circuit, at 450VAC, in a round aluminum can housing. Because a capacitor's voltage rating is a ceiling rather than a fixed match, this 450V-rated capacitor can safely replace an original capacitor rated 370V or 440V — going higher on voltage is always safe, going lower is not. Over time, the dielectric material inside a run capacitor breaks down from heat cycling and electrical stress, causing it to lose capacitance or fail outright. A failing dual capacitor produces a very recognizable set of symptoms: the outdoor unit hums but the compressor or fan won't start, the fan spins slowly or needs a manual push to get going, the system trips the breaker, or the capacitor can itself is visibly bulging, domed, or leaking oily residue at the top.
Quick Answer
The XPARTCO XPDC40X5-450R Dual Run Capacitor fixes central air conditioners and heat pumps where the outdoor unit hums but won't start, the compressor or fan motor won't run, the fan spins slowly or needs a manual push, the breaker trips, or the capacitor can is visibly bulged or leaking. 40 MFD (compressor) + 5 MFD (fan) dual capacitor, 450VAC, round, 3-terminal. Universal fit for equipment originally speced at 370V or 440V, since a higher voltage rating is always a safe upgrade. Capacitors store a dangerous electrical charge even after power is disconnected — always discharge before handling.
Common Problems This Part Fixes
Outdoor AC unit hums but the compressor won't start
Condenser fan won't spin, or spins slowly and needs a manual push to get going
System trips the breaker shortly after starting
AC blows warm air because the compressor isn't running
Repeated clicking sound from the contactor as it tries and fails to start the motor
Capacitor can visibly bulging, domed on top, or leaking oily residue
System that used to start slowly and has now stopped starting altogether
Burning smell from the outdoor unit's electrical compartment
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
XPDC40X5-450R
This is a universal component rather than a single-manufacturer part, so the specific OEM number your HVAC system's label references will vary by brand (Goodman, Trane, Carrier, Rheem, York, Lennox, Amana, and others). This capacitor is a correct replacement for any dual run capacitor matching the 40 MFD / 5 MFD rating with a voltage rating of 450V or lower. If you have your original part number, contact our support team and we will verify compatibility before you order.
Compatibility
This dual run capacitor is a universal replacement compatible with central air conditioners, heat pumps, and condensing units across all major HVAC brands, wherever the original capacitor is rated:
40 MFD (compressor) + 5 MFD (fan motor)
370V, 440V, or 450V (this capacitor's 450V rating exceeds and safely replaces either lower rating)
Round can shape with 3 terminals
Note: The MFD (microfarad) rating must match your original capacitor exactly on both sides — do not substitute a different MFD value for either the compressor or fan side. Voltage rating, on the other hand, can be equal to or higher than the original (450V safely replaces 370V or 440V), but never lower. Can shape (round vs. oval) affects only physical fit inside your unit's electrical compartment, not performance. If you're unsure of your original capacitor's specifications, they're printed directly on its can — contact our support team if you'd like help confirming compatibility.
Key Features
Universal dual run capacitor — supports both the compressor and condenser fan motor from one component
40 MFD compressor rating + 5 MFD fan motor rating in a single 3-terminal can
450VAC rating — a safe upgrade replacement for equipment originally speced at 370V or 440V
Round aluminum can construction
Resolves "hums but won't start," "fan spins slowly," "trips the breaker," and "bulging or leaking can" symptoms caused by capacitor failure
1/4" quick-connect terminals for a direct plug-on fit to standard HVAC wiring
50/60Hz rated
Safety approved: CQC, VDE, TÜV, and CL; built to GB/T 3667 and EN 60252 standards
Built to meet or exceed industry-standard specifications for this capacitor class
Product Specifications
Part Number
XPDC40X5-450R
Part Type
Dual Run Capacitor
Condition
New — Universal Replacement Part
Capacitance — Compressor
40 MFD (µF)
Capacitance — Fan Motor
5 MFD (µF)
Voltage Rating
450VAC
Shape
Round
Terminals
3 (1/4" quick-connect)
Frequency
50/60 Hz
Tolerance
±5%
Construction Type
Polypropylene film capacitor
Operating Temperature Range
-40°C to 70°C (-40°F to +158°F)
Safety Approvals
CQC, VDE, TÜV, CL
Approval Standard
GB/T 3667, EN 60252
Application
Central Air Conditioners, Heat Pumps, Condensing Units
Quantity
1 dual run capacitor
Compatible Brands
Universal — all major HVAC brands
Installation Notes
⚠️ Danger — Capacitors Store A Dangerous Electrical Charge Shut off power to the outdoor unit at the disconnect box and at the breaker before beginning. A capacitor stores an electrical charge even after power has been disconnected, and that charge can deliver a serious or fatal shock. Before touching any terminal, discharge the capacitor by shorting each pair of terminals together (C-to-Fan, C-to-Herm, and Fan-to-Herm) using an insulated-handle screwdriver, or by using a proper capacitor discharge tool with a resistor. Never short the terminals with a bare metal tool held with your bare hand. If you are not fully comfortable performing a capacitor discharge safely, have a qualified HVAC technician replace this part instead.
⚠️ Photograph The Wiring Before Disconnecting — Match Terminals Exactly Wear work gloves and safety glasses. After confirming the capacitor is fully discharged, photograph the wiring on the old capacitor's terminals before disconnecting anything — dual capacitors are labeled C (Common), Herm or Comp (compressor/hermetic), and Fan, and getting a wire on the wrong terminal can damage the new capacitor or the motor it feeds. Note which terminal each wire came from, or label them individually with tape. Remove the mounting strap or bracket holding the old capacitor in its housing, and disconnect each wire from its terminal. Install the new XPDC40X5-450R in the same mounting position, secure it with the strap or bracket, and reconnect each wire to the matching terminal (C, Herm, and Fan) exactly as labeled. Double-check every connection before restoring power. Restore power at the breaker and disconnect box, and confirm the compressor and fan both start promptly and run smoothly. Tools needed: insulated-handle screwdriver or capacitor discharge tool, nut driver, work gloves, safety glasses.
Frequently Asked Questions
My AC unit hums but won't start. Is this the capacitor?
It's one of the most common causes of exactly that symptom. A run capacitor gives the compressor or fan motor the extra push needed to start turning; without it, the motor can draw power and hum in place without ever actually starting to spin. If you can see the capacitor can and it looks bulged, domed on top, or is leaking a brown oily residue, that's strong visual confirmation of failure.
Can I use a 450V capacitor to replace my old 370V or 440V one?
Yes. Voltage rating is a ceiling, not an exact match requirement — a capacitor rated for a higher voltage than your original will work safely and often lasts longer under the same electrical stress. What you cannot do is go the other direction: never install a capacitor with a lower voltage rating than your original, since that risks premature failure or the capacitor breaking down under normal operating conditions.
Does the round vs. oval shape matter?
Only for physical fit inside your unit's electrical compartment — it has no effect on electrical performance. If your unit's mounting bracket or available space is sized for a round can, use a round capacitor; if it's sized for an oval can, use an oval one. The MFD and voltage ratings are what matter electrically, not the shape.
The fan spins if I give it a push, but won't start on its own. What does that mean?
This is a classic sign of a weak or failing capacitor — it may still have enough charge to keep the motor running once it's already spinning, but not enough to provide the initial starting torque. This is a strong signal to replace the capacitor before it fails completely and leaves you with no cooling at all.
Is this a genuine OEM part?
This is a universal replacement part rather than a brand-specific OEM part. Because dual run capacitors are a standardized component defined by their electrical specifications rather than their manufacturer, this capacitor is a correct replacement for any unit's original capacitor that shares the same 40/5 MFD, 450VAC, round dual run capacitor rating — regardless of which HVAC brand originally installed it.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Quality Replacement Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
XPARTCO HVAC Capacitor Contractor Pack — 18-Piece Assortment Kit (Dual + Single Run)
The XPARTCO HVAC Capacitor Contractor Pack bundles the seven most commonly needed dual run capacitor ratings, plus two single run capacitor ratings, into a single 18-piece kit, so a technician can carry one box instead of restocking capacitors between jobs. Each dual run capacitor combines two capacitors into one round, three-terminal can — one rated for the compressor, one for the condenser fan motor — the standard design used across the vast majority of residential and light commercial split systems, window units, and heat pumps. The single run capacitors are 2-terminal units sized for one motor circuit, commonly used on standalone condenser fan motors, pool pumps, and other single-phase motor equipment.
The mix in this kit is weighted toward the ratings that fail most often in the field: 35/5, 40/5, and 45/5 MFD capacitors cover the majority of residential 1.5–3.5 ton systems and are included in higher quantities, while 50/5, 60/5, 70/5, and 80/5 MFD round out coverage for larger residential and light commercial compressors. All fourteen capacitors are rated 450VAC, so each one is a safe upgrade replacement regardless of whether the original equipment was speced at 370V, 440V, or 450V.
Quick Answer
The XPARTCO HVAC Capacitor Contractor Pack is an 18-piece assortment covering the seven dual run capacitor ratings most commonly replaced on residential and light commercial AC systems and heat pumps, plus two single run capacitor ratings for fan motors and similar equipment: 35/5 (×2), 40/5 (×4), 45/5 (×4), 50/5 (×1), 60/5 (×1), 70/5 (×1), 80/5 (×1), single-run 5 (×2), and single-run 7.5 (×2) MFD, all rated 450VAC, round. Built for technicians who want to stock a truck once instead of reordering capacitors mid-week. Capacitors store a dangerous electrical charge even after power is disconnected — always discharge before handling.
What's In The Kit
Capacitor Rating
Qty
Typical Application
35/5 MFD, 450V, Round
2
Smaller residential split systems, window/PTAC units
40/5 MFD, 450V, Round
4
Common residential 2–2.5 ton systems — high-frequency replacement size
45/5 MFD, 450V, Round
4
Common residential 2.5–3 ton systems — high-frequency replacement size
50/5 MFD, 450V, Round
1
Mid-size residential systems, 3–3.5 ton
60/5 MFD, 450V, Round
1
Larger residential systems, 3.5–4 ton
70/5 MFD, 450V, Round
1
Larger residential/light commercial systems, 4–5 ton
80/5 MFD, 450V, Round
1
Larger compressors and light commercial equipment
5 MFD, 450V, Round (Single Run)
2
Standalone condenser fan motors, pool pumps, small single-phase motors
7.5 MFD, 450V, Round (Single Run)
2
Standalone condenser fan motors, pool pumps, small single-phase motors
Common Problems This Kit Solves
Outdoor AC unit hums but the compressor won't start
Condenser fan won't spin, or spins slowly and needs a manual push to get going
System trips the breaker shortly after starting
AC blows warm air because the compressor isn't running
Repeated clicking sound from the contactor as it tries and fails to start the motor
Capacitor can visibly bulging, domed on top, or leaking oily residue
Needing a specific capacitor rating on the spot without a return trip to the supply house
Compatibility
This kit's capacitors are universal replacements compatible with central air conditioners, heat pumps, and condensing units across all major HVAC brands, wherever the original capacitor's MFD rating matches one included in this kit and its voltage rating is 450V or lower (370V and 440V equipment included, since a higher voltage rating is always a safe upgrade).
Note: The MFD (microfarad) rating must match the original capacitor exactly on both the compressor and fan sides — do not substitute a different MFD value. If a job calls for a rating not included in this kit (such as a 25/5, 30/5, or 55/5), each individual dual run capacitor rating is also available separately in our HVAC capacitor line. Contact our support team if you'd like help confirming which rating a specific job needs.
Key Features
18-piece assortment covering the 7 most commonly replaced dual run ratings plus 2 single run ratings
Quantities weighted toward the highest-frequency replacement sizes (35/5, 40/5, 45/5)
All capacitors rated 450VAC — a safe upgrade for equipment originally speced at 370V or 440V
Round can construction — 3-terminal (C, Herm, Fan) dual run capacitors and 2-terminal single run capacitors
Polypropylene film construction; safety approved CQC, VDE, TÜV, CL; built to GB/T 3667 and EN 60252 standards
Operating temperature range -40°C to 70°C (-40°F to +158°F)
Eliminates truck-stock gaps — one kit replaces reordering single capacitors between jobs
Each rating also available individually for restocking a single value
Kit Specifications
Kit Contents
18 capacitors — 14 dual run across 7 ratings + 4 single run across 2 ratings (see table above)
Capacitor Types
Dual Run (Compressor + Fan) and Single Run
Condition
New — Universal Replacement Parts
Voltage Rating (all pieces)
450VAC
Shape
Round
Terminals
3 per dual run capacitor / 2 per single run capacitor (1/4" quick-connect)
Frequency
50/60 Hz
Tolerance
±5%
Construction Type
Polypropylene film capacitor
Operating Temperature Range
-40°C to 70°C (-40°F to +158°F)
Safety Approvals
CQC, VDE, TÜV, CL
Approval Standard
GB/T 3667, EN 60252
Application
Central Air Conditioners, Heat Pumps, Condensing Units
Compatible Brands
Universal — all major HVAC brands
Installation Notes
⚠️ Danger — Capacitors Store A Dangerous Electrical Charge Shut off power to the outdoor unit at the disconnect box and at the breaker before beginning any capacitor replacement. A capacitor stores an electrical charge even after power has been disconnected, and that charge can deliver a serious or fatal shock. Before touching any terminal, discharge the capacitor fully: on a dual run capacitor, short each pair of terminals together (C-to-Fan, C-to-Herm, and Fan-to-Herm); on a single run capacitor, short the two terminals together. Use an insulated-handle screwdriver, or a proper capacitor discharge tool with a resistor. Never short the terminals with a bare metal tool held with your bare hand.
⚠️ Match The Rating Before Installing — Photograph Wiring First Confirm the failed capacitor's MFD rating on both the compressor and fan sides, and select the matching piece from this kit — the rating printed on the old capacitor's can is the reference, not the equipment's tonnage. Photograph the wiring on the old capacitor's terminals before disconnecting anything; terminals are typically labeled C (Common), Herm or Comp (compressor), and Fan. Remove the mounting strap holding the old capacitor, disconnect each wire, and install the replacement from this kit in the same mounting position, reconnecting each wire to the matching terminal. Restore power and confirm the compressor and fan both start promptly and run smoothly. Tools needed: insulated-handle screwdriver or capacitor discharge tool, nut driver, work gloves, safety glasses.
Frequently Asked Questions
Why are 35/5, 40/5, and 45/5 included in higher quantities than the others?
These three ratings cover the size range used on the largest share of residential split systems in the field, so they're the ratings most likely to come up repeatedly across a week of service calls. The larger ratings (50/5 through 80/5) still come up regularly but less often, which is why the kit includes one of each rather than duplicates.
What if a job needs a rating that isn't in this kit, like 25/5 or 55/5?
Every rating in this kit — both dual run and single run — is also sold individually, so you can pick up less common values as needed without buying another full kit. Contact our support team if you want help identifying which individual rating a specific job calls for.
Can I use a 450V capacitor from this kit to replace an original 370V or 440V capacitor?
Yes. Voltage rating is a ceiling, not an exact match requirement — a capacitor rated for a higher voltage than the original works safely and often lasts longer under the same electrical stress. What you can't do is go the other direction, so every capacitor in this kit being 450V means it's a safe fit anywhere the original was rated 370V, 440V, or 450V.
Does the MFD rating need to match exactly, or is there some tolerance?
Match the rating on both the compressor and fan side as closely as possible to the original — these capacitors carry a ±5% manufacturing tolerance, but that's not the same as intentionally substituting a different rated value. Always select the kit piece whose printed MFD rating matches what was on the failed capacitor.
Is this a genuine OEM kit?
This is a universal replacement kit rather than a brand-specific OEM product. Because dual run capacitors are a standardized component defined by their electrical specifications rather than their manufacturer, each capacitor in this kit is a correct replacement for any unit's original capacitor sharing the same rating — regardless of which HVAC brand originally installed it.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Quality Replacement Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
