137221600 (OE) Washer Drain Pump
The 137221600 (OE) is an Original Equipment (OE) replacement washer drain pump compatible with a wide range of Frigidaire, Electrolux, Crosley, Gibson, Kelvinator, Kenmore, Tappan, and Westinghouse front-load washers — including popular Affinity series and washer-dryer combo models. The drain pump is mounted at the base of the washer and is responsible for evacuating the wash and rinse water from the tub through the drain hose at the end of each cycle. When the drain pump fails, the washer can't drain — leaving clothes soaking wet, water pooling in the tub, and the wash cycle unable to advance to spin. Common failure symptoms include humming without pumping (blocked or seized impeller), leaks from the pump housing, loud grinding or clicking noises, and complete pump silence when a drain cycle should be running.
Rated 120V AC, 60Hz, 85W, 1.25A. Based on the Askol M65 design, with a firmly attached red flapper to prevent drain backflow into the tub. Constructed from strong, durable plastic to resist cracking and leaking through many years of cycling. Package includes the drain pump, mounting base, and mounting screw. This part directly replaces 137108100, 137151800, 137151800KITK, 131724000, 134051200, 134740500, 134740800, 2754548, ER137108100, TJ137108100, EAP7783938, LP1600, BPX401-72J, AP5684706, and PS7783938. Important: before installing the new pump, clean any lint or debris from the rubber boot, verify the drain hose is clear and properly fastened, and check the pump filter for blockage — installing a new pump on a system with the underlying blockage will not resolve the drainage problem. Installs in 30–60 minutes with basic hand tools.
Quick Answer
The 137221600 (OE) Washer Drain Pump fixes Frigidaire, Electrolux, Crosley, Gibson, Kelvinator, Kenmore, Tappan, and Westinghouse front-load washers that won't drain, leave clothes soaking wet, are noisy or humming during the drain cycle, or display an E11 error code. 120V AC, 60Hz, 85W, 1.25A. Askol M65 design with red backflow flapper. Kit includes pump + mounting base + screw. Original Equipment (OE) — same design and performance as the factory part, without the OEM label. Replaces 137108100, 137151800, 137151800KITK, 131724000, 134051200, 134740500, 134740800, 2754548, ER137108100, TJ137108100, EAP7783938, LP1600, BPX401-72J, AP5684706, PS7783938.
Common Problems This Part Fixes
Washer not draining — pump failed to remove water at the end of the wash or rinse cycle
Clothes left soaking wet at the end of the cycle — no drain, so no spin can start
Water leaking from the bottom of the washer — cracked pump housing or failed seal
Loud humming noise but no water flowing — pump motor running against a seized impeller or blockage
Grinding, clicking, or unusual noises during the drain cycle
E11 error code displayed on the control panel (drain fault)
Washer pumps but won't spin — drain cycle can't complete, blocking spin
Cycles taking much longer than normal as the washer tries to drain
Pump silent during drain — motor windings open or electrical fault
Impeller broken, cracked, or missing pieces after opening the pump
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This drain pump directly replaces the following OEM and cross-reference part numbers:
137221600, 131724000, 134051200, 134740500, 137108100, 137151800, 137151800KITK, 2754548, TJ137108100, ER137108100, PD00000118, EAP7783938, BPX401-72J, AFR14249, AP5684706, PS7783938, Also replaces GE WH23X10041, 2119312, WH23X10009, WH23X10017, WH23X10031, WH23X10034, AH3502779, EA3502779, AP5324214, PS3502779.
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This drain pump is compatible with select front-load washers and washer-dryer combos from the following brands:
Frigidaire front-load washers — Affinity series (FAFW3001LW3, FAFW3801LW3 and related), FEX831FS2/FS4, FTF2140ES1, FWS445RFS2, FWX445RFS3 series
Frigidaire front-load washers — ATF6000ES1, ATF8000FS1, ATFB6700FS0 series
Frigidaire front-load washers — GLTF2940ES3, GLTF2940FS1 and related GLTF series
Frigidaire washer-dryer combos — CWS3600AS1 and related
Electrolux front-load washers — select models
Crosley front-load washers — select models
Gibson front-load washers — select models
Kelvinator front-load washers — select models
Kenmore / Sears front-load washers — select Frigidaire-built models (41744052400, 41744052401, 41744052500, 41744082500, 41748102700, 41748106700, 41748116700, 41790812995 and related 417-series)
Tappan front-load washers — select models
Westinghouse front-load washers — select models
Note: The redesigned 137221600 may look slightly different from your original (e.g., white or gray housing vs. original black), but functions identically. Ensure proper orientation and flapper alignment during installation. Always verify your appliance model number before ordering.
Key Features
Original Equipment (OE) replacement — produced to the same design and performance standards as the factory part but not sold under the appliance brand's OEM label; provides the same fit and function at a more affordable price
Drain pump — removes water from the washer tub through the drain hose at the end of the wash and rinse cycles
Resolves "won't drain," "won't spin," "wet clothes," "E11 error," and "humming pump" symptoms
120V AC, 60Hz, 85W, 1.25A — correct electrical specifications for compatible Frigidaire-platform washers
Askol M65 design with red backflow flapper to prevent water from flowing back into the tub
Strong, durable plastic construction resistant to cracking and leaking
Kit includes: 1x drain pump, 1x mounting base, 1x mounting screw
Replaces 15+ OEM and cross-reference part numbers including 137108100, 137151800, 131724000, 134051200, 134740500, 134740800, AP5684706, and PS7783938
Compatible with Frigidaire (Affinity, FEX, FTF, FWS, FWX, ATF, ATFB, GLTF, CWS series), Electrolux, Crosley, Gibson, Kelvinator, Kenmore (417-series), Tappan, and Westinghouse front-load washers and washer-dryer combos
DIY repair — installs in 30–60 minutes with basic hand tools
Product Specifications
Part Number
137221600-OE
Designation
OE (Original Equipment)
Part Type
Washer Drain Pump
Condition
OE Replacement
Application
Front-Load Washers and Washer-Dryer Combos (Frigidaire/Electrolux platform)
Voltage
120V AC
Frequency
60 Hz
Wattage
85W
Amperage
1.25A
Design
Askol M65 with red backflow flapper
Material
Durable plastic
Includes
1x Drain Pump, 1x Mounting Base, 1x Mounting Screw
Error Codes Resolved
E11 (drain fault)
Compatible Brands
Frigidaire, Electrolux, Crosley, Gibson, Kelvinator, Kenmore, Tappan, Westinghouse
Installation Notes
⚠️ Unplug Washer and Shut Off Water Before Starting — Wear Work Gloves — Check for Blockage First Disconnect power at the outlet or breaker and shut off both water supplies at the wall before beginning. Wear work gloves to protect your hands — pump components can have sharp edges. Have towels ready — residual water remains in the pump housing and hoses. Important: before replacing the pump, check for the underlying cause of the drain problem. Inspect the pump filter (accessible on many models via the lower front kick panel), the drain hose for kinks, and the rubber boot at the bottom of the tub for lint, coins, buttons, or other debris — installing a new pump on a system with an unresolved blockage will not fix the drain problem. Remove the appropriate access panel (typically the rear or front lower kick panel — model-dependent) to expose the pump. Photograph the wire harness and hose connections before disconnecting. Disconnect the electrical wire connectors from the pump motor. Squeeze the hose clamps with pliers and slide them back to release the tub-to-pump hose and the pump-to-drain-hose from the pump. Remove the 2 mounting screws holding the pump to its base and lift the old pump out. Clean any residual debris from the rubber boot, hoses, and pump filter area. Install the new 137221600 (OE) pump using the included mounting base and screw. Reconnect the hoses with the clamps, orient the red backflow flapper correctly, and reconnect the electrical connectors. Reinstall the access panel, restore water and power, and run a rinse cycle to test drainage and check for leaks at all connections. Tools needed: Phillips screwdriver, needle-nose pliers, channel-lock pliers, small flathead screwdriver, towel, work gloves.
Frequently Asked Questions
What does "OE" mean and how is it different from Genuine OEM?
OE (Original Equipment) parts are produced to the same design and performance standards as the original factory part, but they are not sold under the appliance brand's OEM label. They provide the same fit and function as the OEM part at a more affordable price. The 137221600 (OE) drain pump matches the electrical specifications (120V, 60Hz, 85W, 1.25A), Askol M65 design, and physical fit of the original Frigidaire OEM part, and installs identically. The main difference from a Genuine OEM Frigidaire part is the branding and warranty — the OE version delivers equivalent performance and durability without the OEM price premium.
My washer won't drain — is it always the pump?
Not always. Before replacing the pump, check for these common causes: 1) Clogged pump filter — most Frigidaire front-load washers have a filter accessible via the lower front kick panel; coins, buttons, lint, and small items can block it. 2) Kinked or clogged drain hose — inspect the entire drain hose from the pump to the wall standpipe or sink. 3) Blocked rubber boot — small items can get stuck between the tub and the pump inlet. 4) Failed lid lock/door switch — if the washer doesn't detect a locked door, it won't run the drain cycle. If all of these check out and the pump still isn't draining (or is humming without moving water), the pump has failed and this is the correct repair.
What is the E11 error code on my Frigidaire washer?
E11 on Frigidaire and Electrolux front-load washers indicates a drain fault — the control board is not detecting successful drainage within the expected time. Common causes are a failed drain pump, a clogged pump filter, a kinked or clogged drain hose, or debris blocking the impeller. If you've verified the filter and hose are clear but the code persists, replacing the 137221600 drain pump typically resolves it. If the code returns after replacement, check the wire harness between the pump and the control board.
Does the pump come with everything I need for installation?
Yes — the 137221600 (OE) package includes the drain pump itself, a mounting base, and a mounting screw. This is everything you need for the pump replacement itself. However, you should reuse the original hose clamps and hoses from your old pump (they should still be in good condition). If you find that the rubber boot at the base of the tub is cracked, hardened, or torn during the repair, that's a separate part that would need to be ordered — inspect it before completing the reinstallation.
The new pump looks different from my old one — is it the right part?
Very likely, yes. The 137221600 has been through several revisions over its production history — some housings are black, others white or gray, and the exact shape can vary slightly across production runs. As long as the mounting bolt pattern, hose inlet/outlet sizes, and electrical connector are the same, and the specs match (120V, 60Hz, 85W, Askol M65 design), the pump will function identically to your original. During installation, focus on correct orientation and flapper alignment — the flapper (red) must be positioned so it opens outward toward the drain hose direction to prevent backflow.
