XPARTCO W11688995 Washer Water Inlet Valve (Cold)
The XPARTCO W11688995 is an aftermarket replacement cold water inlet valve designed as a direct fit for select Whirlpool, Maytag, Amana, KitchenAid, Jenn-Air, Magic Chef, Admiral, Norge, Roper, Inglis, and Kenmore front-load washers. The cold water inlet valve is mounted at the back of the washer where the cold water supply hose connects. When the washer's control board calls for cold water during a wash cycle, the valve's internal solenoid opens, letting water flow into the tub or detergent dispenser. The valve closes the instant the control board cuts power, stopping flow precisely as the correct fill level is reached.
When this valve fails, the washer may not fill with cold water at all, fill very slowly, fail to dispense fabric softener, continuously drip water into the tub even when off, or display F8E1 or LO FL error codes. Construction is blue and white plastic with metal solenoid coil, ~3"H x 4"W x 3"L, with 1/2" NPT threaded inlet for standard washer supply hose. It directly replaces W11688995, W11036930, W11316256, W11486361, AP7218603, EAP12711564, PD00086086, PS12711564, 4929298, and AP6835737. Often replaced as a pair with the hot water inlet valve (W11688994, sold separately). Installs in 10–15 minutes with basic hand tools.
Quick Answer
The XPARTCO W11688995 Washer Water Inlet Valve (Cold) fixes Whirlpool, Maytag, Amana, KitchenAid, Jenn-Air, and Kenmore front-load washers displaying F8E1 or LO FL error codes, not filling with cold water, filling slowly, failing to dispense fabric softener, or continuously dripping into the tub. Blue/white plastic with metal coil, 1/2" NPT thread, ~3"H x 4"W x 3"L. Replaces W11036930, W11316256, W11486361, AP7218603, EAP12711564, PD00086086, PS12711564, 4929298, AP6835737. Often paired with the hot water valve (W11688994, sold separately).
Common Problems This Part Fixes
Washer not filling with cold water — valve solenoid not opening when commanded
Washer filling slowly with cold water — valve partially clogged or weak solenoid
F8E1 error code displayed — cold water inlet valve fault
LO FL (low flow) error code — valve unable to deliver normal water flow
Fabric softener not being dispensed — cold water flush to dispenser failing
Water continuously dripping into the tub when the washer is off — valve stuck open or not fully closing
Water leaks at the valve body — internal seal failure
Wash cycles taking much longer than normal due to slow fill
Replaces Part Numbers
This cold water inlet valve directly replaces the following OEM and cross-reference part numbers:
W11688995, W11316256, W11036930, W11486361, 4983050, PD00086086, FIX17216730, EAP17216730, OEM28874414, AP7218603, AWP46809, PS17216730.
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This cold water inlet valve is compatible with select front-load washers from the following brands:
Whirlpool front-load washers — WFC6810LW0, WFC9820HC0, WFC9820HW0 series
Whirlpool front-load washers — WFW560CHW0, WFW560CHW1, WFW560CHW2, WFW560CHW3, WFW560CHW4 series
Whirlpool front-load washers — WFW5605MC0, WFW5605MW0 series
Whirlpool front-load washers — WFW5620HW0, WFW5620HW1, WFW5620HW2, WFW5620HW3 series
Whirlpool front-load washers — WFW6620HC0, WFW6620HC1, WFW6620HC2, WFW6620HW0, WFW6620HW1 series
Whirlpool front-load washers — WFW8620HC0, WFW8620HC1, WFW8620HC2, WFW8620HC3, WFW8620HC4, WFW8620HW0, WFW8620HW1, WFW8620HW2, WFW8620HW3, WFW8620HW4 series
Whirlpool front-load washers — WFW862CHC0, WFW862CHC1, WFW862CHC2, WFW862CHC3 series
Whirlpool front-load washers — WFW9620HBK1, WFW9620HBK2, WFW9620HBK3, WFW9620HC0, WFW9620HC1, WFW9620HC3, WFW9620HW0, WFW9620HW1, WFW9620HW2, WFW9620HW3 series
Maytag front-load washers — MHW5630HC0, MHW5630HW1, MHW5630MBK0 series and related
Amana front-load washers — NFW5800HW0, NFW5800HW1 and related models
Inglis front-load washers — IFW5900HW, IFW5900HW1 and related models
KitchenAid, Jenn-Air, Magic Chef, Admiral, Norge, Roper front-load washers — select Whirlpool-built models
Kenmore / Sears front-load washers — select Whirlpool-built models
Note: This is the cold water inlet valve (typically blue). The matching hot water inlet valve is part number W11688994 (typically red). When you replace one valve, it's a good practice to replace the other at the same time since they're the same age, both are accessible during the same repair, and the second valve will likely fail in the near term. Always verify your model number before ordering.
Key Features
Aftermarket replacement built to OEM-equivalent quality standards
Controls the flow of cold water into the washer during fill cycles
Solenoid-actuated — opens precisely when the control board calls for cold water and closes the moment the call is dropped
Resolves F8E1 and LO FL error codes when caused by a failed cold inlet valve
1/2" NPT threaded inlet for standard washer supply hose connection
Dimensions: approximately 3" H x 4" W x 3" L
Blue and white plastic body with metal solenoid coil — designed for long-term reliability against wash cycle pressure and temperature
Replaces W11036930, W11316256, W11486361, AP7218603, EAP12711564, PD00086086, PS12711564, 4929298, and AP6835737
Compatible with Whirlpool, Maytag, Amana, KitchenAid, Jenn-Air, Magic Chef, Admiral, Norge, Roper, Inglis, and Kenmore front-load washers
Often replaced together with the hot water inlet valve (W11688994, sold separately) as a paired repair
Quick DIY repair — installs in 10–15 minutes with basic hand tools
Product Specifications
Part Number
XPW11688995
Part Type
Washer Water Inlet Valve (Cold)
Condition
Aftermarket Replacement
Application
Front-Load Washers (Whirlpool platform)
Water Type
Cold (paired hot valve is W11688994)
Inlet Thread
1/2" NPT
Dimensions
Approximately 3" H x 4" W x 3" L
Color
Blue / White
Material
Plastic / Metal
Error Codes Resolved
F8E1, LO FL (when caused by cold valve fault)
Often Paired With
Hot Water Inlet Valve (W11688994, sold separately)
Compatible Brands
Whirlpool, Maytag, Amana, KitchenAid, Jenn-Air, Magic Chef, Admiral, Norge, Roper, Inglis, Kenmore
Installation Notes
⚠️ Unplug Washer and Shut Off Water Supply Before Starting — Wear Work Gloves Disconnect power and shut off both the hot and cold water supplies at the wall before beginning. Wear work gloves to protect your hands. Have towels ready — residual water remains in the supply hoses and will spill when disconnected. Pull the washer out from the wall to access the back. Remove the three 1/4" screws securing the rear edge of the top cover, push the top cover slightly back, and lift it off. Locate the inlet valves at the back of the washer — the cold valve is typically blue. Disconnect the cold water supply hose from the valve (water will drip — towels). Photograph the wire connections before disconnecting. Unplug the small electrical connector from the valve solenoid. Remove the single 3/16" mounting screw (or similar hardware, model-dependent) holding the valve in place, and disconnect any internal water hoses from the valve outlet (channel-lock pliers may help with hose clamps). Install the new W11688995 valve in the same position with the same orientation, reconnect the internal water hoses and electrical connector, and secure the mounting screw. Reconnect the cold supply hose at the wall, restore water and power, and run a test cycle to confirm normal cold water fill with no leaks. Tip: while the top cover is off, this is the ideal time to also replace the hot water valve (W11688994) — they share the same access and lifespan. Tools needed: 1/4" nut driver, 3/16" nut driver, adjustable wrench or pliers, work gloves.
Frequently Asked Questions
What do error codes F8E1 and LO FL mean on Whirlpool washers?
Both codes indicate a water fill problem. F8E1 appears when the control board doesn't detect normal water flow during a fill cycle — typically caused by a failed inlet valve, a clogged inlet screen, kinked supply hose, or restricted water supply. LO FL (low flow) appears when the washer detects that water is flowing in, but at a rate too low to complete the fill within the expected time window. When the cold water inlet valve has failed or is partially clogged, both codes can appear together. Before replacing the valve, check that the household cold water supply is on and the supply hose isn't kinked, and inspect the inlet screen on the valve for sediment buildup. If those check out, replacing the W11688995 typically resolves the codes.
My washer isn't dispensing fabric softener — could this be the cold valve?
Yes — this is actually a common symptom that's often misdiagnosed. The cold water inlet valve also feeds the detergent dispenser tray on most Whirlpool front-load washers, including the fabric softener compartment. If the cold valve is clogged or failing to fully open at the right moment in the cycle, water doesn't flow through the fabric softener compartment to flush it into the tub, leaving softener pooled in the tray at the end of the cycle. If you've already cleaned the dispenser tray and water lines and the problem persists, replacing the cold inlet valve (W11688995) often resolves the issue.
Should I replace the hot water valve at the same time?
Yes, it's strongly recommended. The cold and hot inlet valves are essentially identical components installed side by side at the back of the washer — they're the same age, are exposed to the same wash cycle stress, and have the same expected service life. When one fails, the other is typically not far behind. Since the top cover is already off and both valves are accessible during the same repair, replacing both saves you a second teardown later. The matching hot water valve is part number W11688994 (red, sold separately) and is also available as a paired kit.
My washer is dripping water into the tub even when it's off — is this the valve?
Yes, that's a classic sign of a failed inlet valve. When the solenoid wears out or debris keeps the valve from sealing fully closed, water leaks past it at low rates and drips into the tub even with the washer powered off — especially noticeable as a slow puddle forming over a day or two. Since both the hot and cold valves feed into the tub, you'll want to identify which one is leaking: shut off the hot water supply at the wall and check if dripping continues. If it stops, the hot valve is at fault; if it continues, this cold valve is the cause. Replacing the W11688995 will resolve a leaking cold valve.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is manufactured to match the dimensions, electrical specifications, 1/2" NPT thread, and solenoid function of the original W11688995 cold water inlet valve used in compatible Whirlpool, Maytag, Amana, KitchenAid, and Kenmore front-load washers.
