Cooking Appliances Parts

807047102 Range Genuine OEM Drawer Guide Fits Specific Frigidaire Range modles Replaces Part Numbers: 807047102, 316407301, 5304490937, 316407300, 4456932, AP6036410, PS11770783.   California Residents only WARNING: Cancer and/or Reproductive Harm - www.p65warnings.ca.gov

Read more less

W11517331 Range Genuine OEM Control Knob Replaces Part Number: W11517331, W11117415, W10850027, AP7002931, PS16543518. Description: This W11517331 Range Genuine OEM Control Knob provides precise temperature control for your range. Made of high-quality materials, this knob is durable and reliable. With its sleek design, it adds a modern touch to your kitchen. Easy to install and use, it ensures an optimal cooking experience.

Read more less

XPARTCO 5304509706 Gas Oven Igniter Product Overview The XPARTCO 5304509706 Gas Oven Igniter is designed to ignite the gas burner and ensure consistent oven heating performance. This Oven Igniter is a replacement part for select Frigidaire, Kenmore, GE gas oven models, designed to ignite the gas in the oven burner to start the heating process. This part is responsible for creating the spark that ignites the gas, providing the heat needed to cook and bake food. Over time, the oven igniter can wear out or become damaged, which can prevent the oven from heating. Quick Answer If your gas oven is not heating, takes too long to preheat, or the burner does not ignite, the 5304509706 igniter may be weak or faulty. Replacing this igniter restores proper ignition and consistent oven performance. Replaces Part Numbers Replaces OEM part number: 5304509706, 316489402, 316489408, 316119301, 4545981, 012505482182, EAP12071409, AFR18015, PD00035904, AP6230715, PS12071409, WB2X10016, WB02X10016, 1704, EAP241804, AGE826644, PD00042950, AH241804, EA241804, AP2009619, PS241804. Compatibility This gas oven igniter is compatible with select Frigidaire, Electrolux, Kenmore, and other compatible gas ranges and ovens. Frigidaire Gas Ranges Electrolux Ovens GE Gas Ranges Kenmore Gas Ovens Always verify your appliance model number before ordering. Common Problems This Part Fixes Oven not heating Slow or delayed ignition Burner not lighting Gas smell due to ignition failure Key Features Designed for gas oven ignition Provides fast and reliable burner ignition High-quality aftermarket replacement Durable construction for long-lasting performance Product Specifications Part Number: XP5304509706 Part Type: Gas Oven Igniter Brand: XPARTCO Condition: New OEM / Aftermarket: Aftermarket Application: Gas Ovens & Ranges Troubleshooting Guide Oven not igniting → Faulty igniter Long preheat time → Weak igniter No flame despite gas flow → Igniter failure When Should You Replace This Igniter? Replace this igniter if your oven fails to heat, takes too long to preheat, or does not ignite the gas burner properly. Installation Notes ⚠️ Disconnect power and shut off gas before installation. Remove mounting screws, disconnect wiring, and install the new igniter carefully. Avoid touching the igniter surface with bare hands. Related Parts Gas Oven Safety Valve Oven Temperature Sensor Control Board Frequently Asked Questions Will this igniter fit my oven?This igniter fits many Frigidaire and compatible gas ovens. Always verify your model number. What does an oven igniter do?It ignites the gas burner and allows the oven to heat properly. What are signs of a bad igniter?Oven not heating, delayed ignition, or no flame during operation. Is this OEM or aftermarket?This is a high-quality aftermarket replacement part. Shop With Confidence Parts-O-Matic is a U.S.-based appliance parts retailer specializing in OEM and high-quality replacement parts. We offer fast shipping, reliable products, and expert support. Fast Shipping Quality Tested Parts Compatibility Support

Read more less

6324W1A001L Genuine LG OEM Microwave Magnetron The 6324W1A001L is a genuine LG OEM magnetron for microwave ovens and microwave/oven combination units. The magnetron is the component that actually generates the microwave energy used to cook and heat food — it converts high-voltage electrical power into microwave-frequency radiation, which is then directed into the oven cavity by the waveguide to agitate water molecules in your food and produce heat. Without a functioning magnetron, every other part of the microwave can work perfectly — the turntable spins, the display counts down, the fan runs — while the food inside never actually heats up. This is a genuine LG-manufactured magnetron used not only in LG microwaves but also, under LG's role as a shared component supplier, in microwaves sold under Frigidaire, Whirlpool, Kenmore, GE, Jenn-Air, Thermador, KitchenAid, Panasonic, Goldstar, Crosley, Gaggenau, Amana, and Bosch branding. Measuring approximately 4.5"L x 4.25"W x 5"H. A failed magnetron produces a distinct symptom: the microwave runs normally in every other respect — it powers on, the turntable turns, the timer counts down — but the food inside stays cold. Sparking or arcing behind the waveguide cover, visible burn marks on the magnetron, or a burning smell are also signs of magnetron failure or damage. It directly replaces 6324W1A001A, 6324W1A001B, 6324W1A001E, 6324W1A001H, 6324W1A001Y, AGF76878403, AP4457332, EAS42812905, EAS42812906, EAS42812937, PS3529034, and 1268208. Quick Answer The 6324W1A001L Genuine LG OEM Microwave Magnetron fixes microwaves and microwave/oven combos that run normally — turntable spins, display works, timer counts down — but the food never actually heats up. Also fixes sparking or arcing behind the waveguide cover. Approximately 4.5"L x 4.25"W x 5"H. Replaces 6324W1A001A, 6324W1A001B, 6324W1A001E, 6324W1A001H, 6324W1A001Y, AGF76878403, AP4457332, EAS42812905, EAS42812906, EAS42812937, PS3529034, 1268208. Microwaves contain a high-voltage capacitor that stores a dangerous charge even after unplugging — always discharge it before accessing the magnetron. Common Problems This Part Fixes Microwave runs normally — turntable spins, display works, timer counts down — but food doesn't heat up Microwave heats very weakly or inconsistently Sparking or arcing visible behind the waveguide cover in the oven cavity Burning smell coming from the microwave during or after use Visible smoke from inside the cavity Burn marks or visible damage on the magnetron itself Loud humming with no heating effect on food Cross Reference Information Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item. Replaces Part Numbers This microwave magnetron directly replaces the following OEM and cross-reference part numbers: 6324W1A001L, 6324W1A001A, 6324W1A001B, 6324W1A001E, 6324W1A001H, 6324W1A001Y, AGF76878403, AP4457332, EAS42812905, EAS42812906, EAS42812937, PS3529034, WB26X32629, AP6888676, WB27X26081, WB27X10305, 4930994, WB27X10876. If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This magnetron is compatible with select microwaves and microwave/oven combos from a wide range of brands, since LG manufactures this component for use across multiple appliance brands, including: LG (including LRM2060ST and LMV2031ST models) Kenmore, GE, Frigidaire, Whirlpool, and Amana Jenn-Air, KitchenAid, Thermador, Gaggenau, and Bosch Panasonic, Goldstar, and Crosley Note: Even though this magnetron is used across many brands, magnetrons that look similar can have small but important variations in size and shape between models. Always verify your full model number before ordering. Contact our support team with your model number if you're unsure. Key Features Genuine LG OEM part — factory-specified microwave frequency output and mounting configuration Generates the microwave energy that cooks and heats food Resolves "runs but doesn't heat," "weak or inconsistent heating," "sparking behind the waveguide," and "burning smell" symptoms caused by magnetron failure Approximately 4.5"L x 4.25"W x 5"H Direct drop-in replacement — matches the original mounting bracket and waveguide alignment Replaces 6324W1A001A, 6324W1A001B, 6324W1A001E, 6324W1A001H, 6324W1A001Y, AGF76878403, AP4457332, EAS42812905, EAS42812906, EAS42812937, PS3529034, and 1268208 Widely compatible across LG, Kenmore, GE, Frigidaire, Whirlpool, Jenn-Air, KitchenAid, Thermador, Panasonic, Goldstar, Crosley, Gaggenau, Amana, and Bosch microwaves Genuine OEM replacement — guaranteed fit, materials, and performance Moderate DIY repair for those comfortable with microwave high-voltage safety procedures Product Specifications Part Number 6324W1A001L Part Type Microwave Magnetron Condition Genuine OEM Brand LG Application Microwave Ovens / Microwave-Oven Combos Function Generates the microwave energy used to heat and cook food Dimensions Approx. 4.5"L x 4.25"W x 5"H Repair Difficulty Moderate — high-voltage discharge required Quantity 1 magnetron Compatible Brands LG, Kenmore, GE, Frigidaire, Whirlpool, Amana, Jenn-Air, KitchenAid, Thermador, Gaggenau, Bosch, Panasonic, Goldstar, Crosley Installation Notes ⚠️ Danger — Microwave High-Voltage Capacitor Unplug the microwave before beginning any work. Microwaves contain a high-voltage capacitor that can store a dangerous, potentially lethal electrical charge even after the unit has been unplugged. Before opening the cabinet or touching any internal component, discharge the capacitor using an insulated screwdriver shorted across its terminals — never touch the capacitor or its terminals directly, and never work on a microwave's internals without performing this step first. If you are not fully comfortable and experienced with high-voltage discharge procedures, have a qualified appliance technician perform this repair instead. ⚠️ Test Other High-Voltage Components Before Assuming It's The Magnetron Wear work gloves. After confirming the capacitor is fully discharged, remove the outer cabinet to access the internal components. Before replacing the magnetron, it's worth testing the other high-voltage components — the transformer, diode, and capacitor — since a fault in any of these can produce similar "runs but doesn't heat" symptoms, and replacing the magnetron alone won't fix the problem if one of these other parts has actually failed. Photograph the magnetron's mounting and waveguide connection before removing anything. Disconnect the magnetron's electrical leads, remove the mounting screws securing it to the waveguide assembly, and carefully lift the old magnetron free. Install the new 6324W1A001L in the same orientation, aligning it correctly with the waveguide opening, and secure the mounting screws. Reconnect the electrical leads exactly as they were before removal. Reinstall the outer cabinet, restore power, and test with a cup of water to confirm normal heating without unusual sounds, sparking, or smoke. Tools needed: nut driver or socket set, Phillips screwdriver, insulated screwdriver for capacitor discharge, multimeter (for testing other components), work gloves. Frequently Asked Questions My microwave runs but doesn't heat anything. Is this the right part? It's the most common cause of exactly that symptom. When the turntable spins, the display works, and the timer counts down normally, but food comes out just as cold as it went in, the magnetron has very likely failed. Other high-voltage components (the transformer, diode, or capacitor) can sometimes cause the same symptom, so if you're comfortable testing with a multimeter, it's worth ruling those out first — but a failed magnetron is the single most frequent cause reported for this exact complaint. Why does the same part fit so many different brands? LG manufactures magnetrons and other core components that get used across microwaves sold under many different brand names, since several appliance companies share manufacturing platforms or source key parts from the same suppliers rather than building everything in-house. This is a normal and well-documented part of how microwave manufacturing works — it doesn't mean the part is generic or lower quality, just that LG's magnetron design is used broadly across the industry. I see sparking behind the cover inside the microwave. Is that the magnetron? It can be. Sparking or arcing behind the waveguide cover, especially with visible smoke or a burning smell, points to damage in the magnetron or the waveguide area. Inspect the magnetron for burn marks once you've safely discharged the capacitor and opened the cabinet — if you see charring or damage, replacement is the correct fix. Stop using the microwave immediately if you notice sparking, smoke, or burning smells. Do I need any special skills to replace this part? This is a moderate DIY repair, and the key skill required isn't mechanical — it's safely discharging the microwave's high-voltage capacitor before doing anything else. If you're not fully confident performing that step correctly, this is a good repair to leave to a qualified appliance technician, since the capacitor can hold a dangerous charge even with the unit unplugged. Is this an OEM or aftermarket part? This is a genuine OEM part, manufactured by LG to factory specifications — guaranteed fit, materials, and performance. It matches the original microwave frequency output, mounting configuration, and dimensions of the magnetron originally installed in your microwave. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Genuine OEM Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout

Read more less

WB02X4221CM Gas Range Oven Igniter  Gas Oven Igniter  3.2 - 3.6 Amp igniter with 5.5" overall length. Fits Specific GE Gas Range, Oven Models. Replaces Part Numbers: WB2X4306, WB02X4221, WB02X4306, WB02X4752, WB2X4221, WB2X4752, AH242243, EA242243, AP2011155, PS242243.  Description: This Flat Style Oven Igniter Kit is a replacement part for specific GE gas oven models. It is designed to ignite the gas in the oven burner, facilitating the start of the heating process. This igniter is crucial for ensuring your oven heats up quickly and efficiently, providing the necessary flame for cooking and baking.  This is an aftermarket part that can be used as a replacement for the OEM part.

Read more less

(2 Pack) WB31M20CM Porcelain 6" Drip Pan Porcelain drip bowl (also called a drip pan) for 6 inch burner on an electric range. The drip pan sits underneath the heating element to collect drips or spills around the burner. 6" Porcelain pan. Fits GE, Hotpoint range. Replaces Part Numbers: WB31M20, WB32X5070, WB31M0020, AH244375, EA244375, AP2028044, PS244375.   This is an aftermarket part that can be used as a replacement for the OEM part. California Residents only WARNING: Cancer and/or Reproductive Harm - www.p65warnings.ca.gov

Read more less

(2 Pack) WB31M19CM 8" Porcelain Drip Pan Porcelain drip bowl (also called a drip pan) for 8 inch burner on an electric range. The drip pan sits underneath the heating element to collect drips or spills around the burner. 8" Porcelain pan. Fits GE, Hotpoint range. Replaces Part Numbers: WB31M19, WB32X5069, WB31M0019, AH244373, EA244373, AP2028043, PS244373.   This is an aftermarket part that can be used as a replacement for the OEM part. California Residents only WARNING: Cancer and/or Reproductive Harm - www.p65warnings.ca.gov

Read more less

(2 Pack) WB31X5010CM 6" Burner Drip Pan Chrome drip bowl (also called a drip pan) for 6 inch burner on an electric range. The drip pan sits underneath the heating element to collect drips or spills around the burner. 6" Chrome pan/ring. Fits GE, Hotpoint range. Replaces Part Numbers: WB31X5010, 4, AH244466, DP101, EA244466, PM32X0101, PM32X101, SGP400, WB31X5010A, WB31X5010B, WB31X5010R, AP2028082, PS244466. This is an aftermarket part that can be used as a replacement for the OEM part. California Residents only WARNING: Cancer and/or Reproductive Harm - www.p65warnings.ca.gov

Read more less

XPARTCO EXP20AG Glass Line Fuse, Fast Blow, 20A The XPARTCO EXP20AG is an aftermarket replacement fast-blow glass line fuse rated 20A at 250V, used as the primary overcurrent protection component in microwaves and a range of other household appliances. A line fuse sits directly in the incoming power path: as long as current draw stays within its rating, it does nothing at all, but the instant a short circuit or an overcurrent condition pushes current past 20A, the thin wire element inside the fuse melts and opens the circuit — sacrificing itself to protect the more expensive components downstream, like a transformer, magnetron, or control board. A blown fuse is why an appliance can go from working normally to completely dead with no lights, no display, and no response to any button. This is a standard-dimension glass cartridge fuse measuring 6mm x 30mm, fast-blow (fast-acting) rated, so it opens quickly once its rating is exceeded rather than tolerating a brief surge the way a slow-blow fuse would. It is commonly used across GE, Frigidaire, Whirlpool, Kenmore, and other brands' microwaves, and also turns up in HVAC control boards and various small appliances that use this same standard fuse size and rating. A fuse itself does not wear out from age the way a mechanical part does — if one has blown, it is a symptom of an overcurrent event somewhere else in the appliance, and it's worth understanding why before simply swapping in a new one. Quick Answer The XPARTCO EXP20AG Glass Line Fuse fixes microwaves and other appliances that have gone completely dead — no lights, no display, no response to any button. Fast-blow, 20A, 250V, standard glass cartridge, 6mm x 30mm. Commonly used across GE, Frigidaire, Whirlpool, and Kenmore microwaves and other appliances requiring this fuse size and rating. If a new fuse blows again right away, don't just keep replacing it — that almost always means there's an underlying short circuit that needs to be diagnosed first. Common Problems This Part Fixes Microwave completely dead — no display, no lights, no response to any button Appliance suddenly stopped working with no warning Microwave won't start even though the outlet has power HVAC control board or other appliance electronics unresponsive Appliance tripped off after a power surge or brownout Visible blown or darkened fuse when inspected against a light Continuity test shows an open circuit across the old fuse Cross Reference Information Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item. Replaces Part Numbers This glass line fuse directly replaces the following OEM and cross-reference part numbers: EXP20AG, AGC20, GMA20, 20AG, 5304509451, AP6230606, PS12071294, 5304488359, AP5648907, PS5136235, 5304464087 Because this is a standard fuse size and rating rather than a brand-specific component, the exact OEM part number your appliance's manual references will vary. If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This fuse is compatible with select appliances from the following brands that use a standard 20A, 250V, fast-blow 6mm x 30mm glass cartridge fuse: GE and Hotpoint microwaves (select models) Frigidaire microwaves (select models) Whirlpool and Kenmore microwaves (select models) KitchenAid, Maytag, and Amana microwaves (select models) Select HVAC control boards and other electronics using this fuse size and rating Note — glass vs. ceramic body: This is the glass-body EXP20AG fuse. A visually similar ceramic-body fuse (commonly labeled EXP20A) is also widely sold at the same 20A/250V rating for many of the same appliances. Check which body material your appliance's original fuse used before ordering, and always match the amperage and voltage rating exactly — never substitute a higher-amperage fuse "to stop it from blowing," since that removes the very protection the fuse is designed to provide. Contact our support team with your model number if you're unsure which fuse your appliance needs. Key Features Aftermarket replacement fast-blow glass line fuse — primary overcurrent protection for the appliance's incoming power circuit Rated 20A at 250V, standard 6mm x 30mm glass cartridge dimensions Fast-blow (fast-acting) design opens quickly once the rated current is exceeded Resolves "completely dead," "no display," and "no response to any button" symptoms caused by a blown line fuse Fits standard fuse holders/clips used across a wide range of microwaves and other appliances Replaces EXP20AG, AGC20, GMA20, 20AG, 5304509451, AP6230606, PS12071294, 5304488359, AP5648907, PS5136235, and 5304464087 Compatible with GE, Frigidaire, Whirlpool, Kenmore, KitchenAid, Maytag, and Amana appliances requiring this fuse size and rating Aftermarket replacement built to OEM-equivalent quality standards Product Specifications Part Number EXP20AG OEM Part Number Varies by brand/model — see Replaces Part Numbers Part Type Glass Line Fuse (Overcurrent Protection) Condition Aftermarket Replacement Amperage 20A Voltage 250V Response Speed Fast-blow (fast-acting) Body Material Glass Fuse Size 6mm x 30mm Application Microwaves and select other household appliances / HVAC controls Quantity 1 fuse Compatible Brands GE, Frigidaire, Whirlpool, Kenmore, KitchenAid, Maytag, Amana Installation Notes ⚠️ Danger — Microwave High-Voltage Capacitor If you are replacing this fuse in a microwave, be aware that microwaves contain a high-voltage capacitor that can store a dangerous electrical charge even after the unit has been unplugged. Never open a microwave's cabinet without first discharging the capacitor using an insulated screwdriver shorted across its terminals, and never touch the capacitor or its terminals directly. If you are not fully comfortable with this step, have a qualified appliance technician perform the fuse replacement instead. ⚠️ Unplug The Appliance Before Starting — Match Amperage And Voltage Exactly Disconnect power at the outlet or shut off the circuit breaker before beginning. Locate the fuse holder — on most microwaves this is accessible after removing the outer cabinet, often near the incoming power cord or the control board. Remove the old fuse from its clip or holder and inspect it: a blown fast-blow fuse often shows a visibly darkened or broken filament, or a scorched glass body. Test with a multimeter set to continuity if the fuse looks intact but you suspect it's still bad — a good fuse shows continuity end to end, a blown one shows none. Install the new EXP20AG fuse in the same holder, making sure the amperage and voltage rating match your appliance's original fuse exactly. Reassemble the cabinet, restore power, and test the appliance. Tools needed: Phillips screwdriver, insulated screwdriver (for microwave capacitor discharge), multimeter (recommended), work gloves. Frequently Asked Questions I replaced the fuse and it blew again right away. What's going on? A fuse doesn't fail on its own from age — it blows because something downstream drew more current than it should have. If the new fuse blows again immediately, that's a strong sign of an underlying short circuit or a failing component such as the transformer, magnetron, or a shorted capacitor. Continuing to replace the fuse without finding that root cause will just keep blowing new fuses, and in a microwave specifically, that diagnosis involves working near a high-voltage capacitor that should only be handled by someone comfortable discharging it safely, or by a qualified technician. Can I use a higher-amperage fuse if this one keeps blowing? No — this is one of the most important things to avoid with any fuse. The fuse's rating is chosen specifically to protect the wiring and components in the circuit it sits in. Installing a higher-amperage fuse "so it stops blowing" removes that protection and can allow a fault to overheat wiring or damage expensive components (or start a fire) instead of safely interrupting the circuit. Always replace a fuse with the same amperage and voltage rating as the original. How do I know if the fuse is actually blown? Visually, a blown fast-blow fuse often shows a broken or darkened filament inside the glass body, or scorching on the glass itself. If it looks fine but you still suspect it, the reliable way to check is with a multimeter set to continuity (with the appliance unplugged and the fuse removed from the circuit) — a good fuse reads continuity end to end, while a blown fuse reads open with no continuity at all. Is EXP20AG the same as EXP20A? They share the same 20A/250V rating, but EXP20AG refers to the glass-body version of this fuse while EXP20A commonly refers to a ceramic-body version sold for many of the same appliances. Check which body material your appliance's original fuse used, and if you're not sure, contact our support team with your model number for confirmation. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine brand-specific OEM part, but is manufactured to the same standard 20A, 250V, fast-blow glass cartridge dimensions and rating used across the OEM fuses in compatible GE, Frigidaire, Whirlpool, Kenmore, KitchenAid, Maytag, and Amana appliances. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Quality Aftermarket Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout

Read more less

ERP 74010839 Burner Control Knob 1/4" stem length, 10 o'clock flat, notched Mold#: 5D75 Replaces Part Numbers: WP74010839, 74010839, 7737P372-60, AP6011218, PS11744413, WP74010839VP   This is an aftermarket part that can be used as a replacement for the OEM part. California Residents only WARNING: Cancer and/or Reproductive Harm - www.p65warnings.ca.gov

Read more less

(2 Pack) EXPHV11 Microwave High Voltage Diode (Rectifier) Replaces: GE, LG, AMANA, ELECTROLUX, GE, KENMORE, MAYTAG, WHIRLPOOL, Frigidaire T3512, 3512, T4512, H, CL01-12, HVM12, 512 H, 12Kv, 350mA.   Replaces Part Numbers: 11QBP0236, AP5633254, PS4085133, AP3192533, PS239740 EA239740, WB27X10597, 13091701, AP6005641 PS11738693, WP13091701, 417726, 00188507 AP3382376 PS8712310, 00417726, PS11745270, AP6012063, 8205489, AP4357534, PS2339491, EA2339491, 5304467670, AP4564925, 3518400400, PS11745270, AP6012063, WP8205489, PS3654932, AP5631218, W10245187, W10492278. Description: This Diode Assembly is a replacement part for specific microwave models. It plays a crucial role in converting alternating current (AC) to direct current (DC), which is essential for the microwave’s high-voltage functions, including powering the magnetron to generate microwave energy. Over time, diodes can fail due to electrical surges, excessive heat, or wear and tear. A faulty diode assembly can lead to inefficient or non-functional microwave operation, impacting its ability to heat food properly. Microwave High Voltage Diode – Universal Replacement Restore your microwave’s heating function with this high-quality high voltage diode. Built to handle up to 12,000V / 500mA, it’s a reliable replacement for worn or damaged diodes in many major brands. Features: Direct replacement for most microwave models Durable and rated for high-voltage performance Fixes common issues like no heat or humming Fits brands: GE, Whirlpool, LG, Samsung, Panasonic, Frigidaire, and more. ⚠️ Installation should be done with power disconnected. Not sure if it fits? Contact us to confirm compatibility.

Read more less

XPARTCO 4449751 Oven High Limit Thermostat Replaces WP4449751 The XPARTCO 4449751 is an aftermarket replacement oven high limit thermostat compatible with a wide range of Whirlpool, KitchenAid, Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore ovens, wall ovens, microwave-oven combinations, and ranges. The high limit thermostat is a critical safety device mounted near the oven cavity — it continuously monitors the oven's temperature and cuts off electrical power to the heating element if the oven exceeds its safe operating temperature. When the oven temperature drops back to normal, the thermostat closes and allows normal operation to resume. This backup safety layer protects against fires, damage to the oven, and unsafe cooking conditions when the main temperature control fails. Rated to trip at approximately 335°F (170°C). Common causes for the high limit thermostat to trip include a faulty control board, cooling fan failure, blocked ventilation, poor door sealing, disrupted air circulation, or an abnormal self-cleaning cycle. It directly replaces WP4449751, 1550872, AP6009390, AH2375382, EA2375382, PS2375382, PS11742549, EAP11742549, and AH11742549. Installs in 30–45 minutes with basic hand tools by experienced DIYers. This is a safety component in a 240V oven circuit — proceed only if you're comfortable with high-voltage electrical work, or call a qualified appliance technician. Quick Answer The XPARTCO 4449751 Oven High Limit Thermostat fixes Whirlpool, KitchenAid, Maytag, Jenn-Air, Amana, and Kenmore ovens with symptoms including oven not heating, oven overheating, uneven heating, oven failing to start, and self-clean door won't unlock after cycle. 335°F (170°C) trip temperature — cuts off power to heating element on overheat, then resets when temperature returns to normal. Replaces WP4449751, 1550872, AP6009390, AH2375382, EA2375382, PS2375382, PS11742549, EAP11742549, AH11742549. Compatible with WOS/WOD wall ovens, KOSE/KODE/KOCE series, JJW/JMW/JDRP/JDR series, and many more. Common Problems This Part Fixes Oven not heating at all — high limit thermostat tripped open Oven overheating — thermostat failing to trip when needed (rare failure mode) Inconsistent oven temperatures leading to undercooked or overcooked food Oven fails to start when powered on Oven door won't unlock after a self-cleaning cycle completes Uneven heating — hot spots or cold spots inside the oven cavity Oven cuts off heat mid-cycle without reaching set temperature F-code or thermostat-related error displayed on the control panel Multimeter continuity test on the thermostat shows an open circuit at room temperature Visible damage or discoloration on the thermostat housing from a prior overheat event Cross Reference Information Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item. Replaces Part Numbers This oven high limit thermostat directly replaces the following OEM and cross-reference part numbers: WP4449751, 4449751, 1550872, AP6009390, AWP47600, EAP2375382, PD00025977, PS11742549 If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This high limit thermostat is compatible with select ovens, wall ovens, ranges, and microwave-oven combinations from the following brands: Whirlpool wall ovens — WOS series (WOS31ES0JS, WOS51EC0AS, WOS51EC0HS, WOS51EC7HW02, WOS51EC7HW21, WOS72EC0HS/HV, WOS72EC7HS/HV, WOS92EC0/EC7 all revisions, WOS97ES0ES series) Whirlpool double wall ovens — WOD series (WOD51EC0AW03, WOD51EC7HS, WOD93EC7AS) Whirlpool combination wall ovens — WOC54EC0/EC7 series KitchenAid wall ovens — KOSE, KODE, and KOCE series (KOSE500ESS, KODE500ESS, KOCE500ESS, KOCE500EBL00/EBL01/EBL02/EBL04/EBL05) Jenn-Air wall ovens — JJW, JMW, JDRP, and JDR series (JJW2427DB/DS 00/01, JJW2430DS, JJW3430DS, JMW2430DS, JDRP430HL/HM 00/01, JDRP430WP00, JDRP436HL/HM/WP series, JDRP536HL/HM/WP series) Maytag wall ovens and ranges (select models) Amana wall ovens (select models — AWO6313SFB00/02, AWO6313SFS00/02, AWO6313SFW00/02) KitchenAid ranges — KDRS407 series (KDRS407VBK01, KDRS407VBU01, KDRS407VSS00) Whirlpool ranges — IBD350DS00, IBS300DS00, IBS350DS00 series Magic Chef, Admiral, Norge, Roper wall ovens (select Whirlpool-built models) Kenmore / Sears wall ovens (select Whirlpool-built models) Suitable for single or double electric wall ovens and microwave-oven combination units Always verify your appliance model number before ordering. Contact our support team if you're unsure. Key Features Aftermarket replacement built to OEM-equivalent quality standards High limit thermostat (safety switch) — cuts off power to the oven's heating element when temperature exceeds 335°F (170°C) to prevent overheating damage or fire Auto-reset design — closes and restores normal operation when the oven temperature returns to safe range Precision-calibrated to Whirlpool factory specifications for accurate trip temperature and reliable safety response Replaces WP4449751, 1550872, AP6009390, AH2375382, EA2375382, PS2375382, PS11742549, EAP11742549, and AH11742549 Compatible with Whirlpool WOS/WOD/WOC series, KitchenAid KOSE/KODE/KOCE series, Jenn-Air JJW/JMW/JDRP/JDR series, plus Maytag, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore ovens Fits single wall ovens, double wall ovens, ranges, and microwave-oven combination units Resolves "oven won't heat," "overheating," "uneven heating," "self-clean door stuck locked," and "won't start" symptoms when caused by a failed high limit thermostat For experienced DIYers or qualified appliance technicians — this is a safety component in a 240V oven circuit Installation typically takes 30–45 minutes with basic hand tools Product Specifications Part Number 4449751 OEM Part Number WP4449751 Part Type Oven High Limit Thermostat (Safety Switch) Condition Aftermarket Replacement Application Wall Ovens, Ranges, Microwave-Oven Combinations (Whirlpool platform) Trip Temperature 335°F (170°C) Type Auto-Reset (closes when temperature returns to safe range) Compatible Brands Whirlpool, KitchenAid, Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore Installation Notes ⚠️ Turn Off Power at Breaker Before Starting — This Is a 240V Oven Circuit — Wear Work Gloves Disconnect power at the household breaker before beginning — this is a 240V circuit and there is a serious risk of electrical shock if power is not fully disconnected. Verify power is off with a voltage tester before touching any wiring. Wear work gloves and safety glasses. Allow the oven to cool completely before beginning (several hours after any recent cooking). The high limit thermostat is typically mounted on the rear or side of the oven cavity, accessed by removing the back panel of the appliance (for freestanding ranges) or the front trim/service panel (for wall ovens). The exact location varies by model — consult your appliance's service diagram before starting. Photograph all wire connections and mounting details before disconnecting anything. Disconnect the wire terminals from the old thermostat (typically two spade-terminal wires). Remove the mounting screws or clips holding the thermostat to the oven cavity, and lift it out. Install the new 4449751 in the exact same position and orientation — the thermostat must be in good thermal contact with the oven cavity to function correctly. Secure the mounting hardware and reconnect the wires to their correct terminals. Reinstall the access panels. Restore power at the breaker and test the oven — start with a low-temperature bake cycle to confirm normal heating operation before running a high-temperature or self-clean cycle. Tools needed: Phillips screwdriver, 1/4" nut driver, voltage tester (essential), work gloves, safety glasses. Frequently Asked Questions Why did my high limit thermostat trip in the first place? A high limit thermostat trips because the oven exceeded its safe operating temperature — meaning something upstream in the temperature control chain failed to shut off the heating element when it should have. Common causes are: a failed oven control board (relay stuck closed), a failed cooling fan (allowing the oven cavity or electronics to overheat), blocked or restricted ventilation, poor door sealing (letting the cavity overheat), disrupted air circulation, or an abnormal self-cleaning cycle. Before installing the new thermostat, investigate and address the underlying cause — otherwise the new thermostat will trip again in short order. Also inspect the ventilation, oven door gasket, and cooling fan while you have the appliance open. What's the difference between a high limit thermostat and the operating thermostat? These are two different components serving two different roles. The operating thermostat (or the oven control board with its temperature sensor) is the primary component that maintains the oven at your set temperature by cycling the heating element on and off during normal operation — it opens and closes at your selected temperature (e.g., 350°F). The high limit thermostat (WP4449751) is a backup safety device that only trips when the oven temperature far exceeds normal operation (335°F over the cavity's safe threshold), typically because the operating thermostat or control has failed. If the high limit thermostat trips, both need to be checked — the operating thermostat may also need replacement. Does the high limit thermostat reset itself, or does it need to be replaced after tripping? The WP4449751 is an auto-reset thermostat — it closes automatically once the oven cools back to a safe temperature, allowing normal operation to resume. If your oven is heating normally again after cooling, the thermostat is likely still functional (the underlying overheating cause needs investigation). However, if the thermostat has failed permanently open — often the result of repeated overheat events or age — it will need replacement. Test with a multimeter set to continuity: a working thermostat shows continuity at room temperature. If it reads open (infinite resistance) when cold, it has failed and needs replacement. Why does my self-cleaning cycle leave the oven door locked and the oven won't heat? This is a classic symptom of a high limit thermostat that tripped during the self-clean cycle. Self-cleaning cycles run at extreme temperatures (800–1000°F) and stress every component in the oven — if the ventilation, door gasket, or cooling fan can't keep up, the high limit thermostat will trip open. Once tripped, the oven can't heat OR unlock the self-clean door lock mechanism, leaving the door stuck closed. Once the thermostat cools and closes (or is replaced), the door lock releases and normal operation resumes. If self-clean cycles routinely trip the thermostat, investigate whether the ventilation, cooling fan, or door gasket are causing the problem. Can I do this repair myself, or should I hire a technician? Replacing an oven high limit thermostat is a manageable DIY repair for someone comfortable with mechanical work and electrical connections, but this is a 240V circuit and the thermostat is a safety component — any error can create a serious safety risk. If you have experience with appliance repair, follow the safety precautions carefully (breaker off, voltage tester, correct thermostat orientation), and can confirm the wiring connections are secure, this is a feasible DIY. If you've never worked with 240V appliance circuits before, hiring a qualified appliance technician is the safer option. Also identify and address whatever caused the original overheat event — otherwise the new thermostat will trip again. Is this a Genuine OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is manufactured to match the trip temperature (335°F / 170°C), auto-reset function, terminal configuration, and fit of the original WP4449751 high limit thermostat used in compatible Whirlpool, KitchenAid, Maytag, Jenn-Air, Amana, and Kenmore ovens. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Quality Aftermarket Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout

Read more less
