Cooking Appliances Parts

5304509493 Electric Range Oven Genuine OEM Control Board Genuine Frigidaire part Replaces Part Numbers: 5304509493, 316557115, 4547461, AFR17844, A03619506, EAP12114577, SF5401-S9506, PD00038168, AP6248375, PS12114577

Read more less

XPARTCO W11590294 Gas Oven Igniter The XPARTCO W11590294 is an aftermarket replacement flat-style silicon carbide gas oven igniter compatible with select Whirlpool, Amana, Maytag, KitchenAid, Crosley, Jenn-Air, Magic Chef, Admiral, Norge, Roper, and Kenmore gas ranges in the WFG, AGR, VRGW, and related series. The oven igniter is a silicon carbide heating element mounted next to the oven burner tube. When a bake or broil cycle is started, the igniter draws electrical current through the gas safety valve, which holds the valve open — and simultaneously heats to ignition temperature to light the gas. The igniter must draw at least 3.2 amps to hold the gas valve fully open; as the silicon carbide element ages and weakens, it draws progressively less current, causing the oven to take too long to light, not light at all, or glow without ever opening the gas valve. This flat-style igniter is rated 3.3–3.6 amps at 120V and measures approximately 4" wide x 1" high. It features a silicon carbide element, high-temperature ceramic housing, and metal bracket. The current part number W11590294 directly supersedes W11208965, W11613927, and W11506321 — all four are the same igniter across successive production revisions. It also replaces 4977065, AP7193166, PS16744629, and EAP16744629. Pre-attached wire connectors included. Note: do not touch the silicon carbide element with bare hands — skin oils cause premature burnout. Installs in 15–30 minutes with basic hand tools. Quick Answer The XPARTCO W11590294 Gas Oven Igniter fixes Whirlpool-family gas ovens that won't heat, where the igniter glows but the burner never lights, or where preheat takes too long. Flat silicon carbide igniter, 3.3–3.6A, 120V, approx. 4"W x 1"H. Do not touch element with bare hands. Replaces W11208965, W11613927, W11506321, 4977065, AP7193166, PS16744629. Compatible with Whirlpool WFG320/WFG505, Amana AGR4203/AGR6303, Crosley VRGW, Maytag, KitchenAid, and more. Common Problems This Part Fixes Oven not heating — igniter not reaching operating temperature or gas valve not opening Igniter glows orange or red but the oven burner never lights Oven takes more than 90 seconds to ignite — igniter too weak to fully open the gas valve Oven preheats very slowly — weakened igniter limiting gas valve opening Gas smell when oven is turned on but burner does not light Igniter visibly cracked, broken, or burned out Bake or broil function not working on compatible models Replaces Part Numbers This oven igniter directly replaces the following OEM and cross-reference part numbers: W11590294, W11208965, W11506321, W11613927, AP7193166, AWP45526, EAP16744629, PD00083398, PS16744629. W11590294 is the current production part number superseding W11208965, W11613927, and W11506321 — all four are the same igniter. If your parts diagram shows any of these numbers, this replacement is correct. Contact our support team with your model number if you need confirmation before ordering. Compatibility This oven igniter is compatible with select gas ranges and ovens from the following brands and series: Whirlpool gas ranges — WFG320 series (WFG320M0MB0, WFG320M0MS0, WFG320M0MW0 and related models) Whirlpool gas ranges — WFG505 series (WFG505M0BS4, WFG505M0BW3, WFG505M0MB0, WFG505M0MS0, WFG505M0MW0 and related models) Amana gas ranges — AGR4203 series (AGR4203MNB0, AGR4203MNW0 and related models) Amana gas ranges — AGR6303 series (AGR6303MMB0, AGR6303MMW0 and related models) Crosley gas ranges — VRGW series (VRGW3150RB0, VRGW3150RW0, VRGW3162RB0, VRGW3162RS0, VRGW3162RW0 and related models) Maytag gas ranges (select models) KitchenAid gas ranges (select models) Jenn-Air gas ranges (select models) Magic Chef, Admiral, Norge, Roper, and Kenmore gas ranges (select models) Always verify your appliance model number before ordering. Contact our support team if you're unsure. Key Features Flat-style silicon carbide oven igniter — heats to ignition temperature and draws current through the gas safety valve to hold it open so gas can flow to the burner Draws 3.3–3.6 amps at 120V — correct amperage range to reliably open the oven gas safety valve on compatible models Dimensions: approximately 4" wide x 1" high Silicon carbide element, high-temperature ceramic housing, metal mounting bracket Pre-attached wire connectors included — direct plug-in installation on compatible models Current production part superseding W11208965, W11613927, and W11506321 Do not touch the silicon carbide element with bare hands — skin oils cause premature burnout Compatible with Whirlpool WFG320/WFG505, Amana AGR4203/AGR6303, Crosley VRGW, Maytag, KitchenAid, and related brands Aftermarket replacement built to OEM-equivalent quality standards DIY repair — installs in 15–30 minutes with basic hand tools Product Specifications Part Number XPW11590294 Supersedes W11208965, W11613927, W11506321 Part Type Gas Oven Flat Igniter (Hot Surface Igniter) Condition Aftermarket Replacement Application Gas Ranges and Ovens Igniter Style Flat silicon carbide element Amperage Draw 3.3 – 3.6 Amps Voltage 120V AC Dimensions Approximately 4" W x 1" H Material Silicon carbide / Ceramic / Metal / Plastic Color White / Silver Connector Pre-attached wire connectors Handling Note Do not touch element — skin oils cause premature burnout Compatible Brands Whirlpool, Amana, Maytag, KitchenAid, Crosley, Jenn-Air, Magic Chef, Admiral, Norge, Roper, Kenmore Installation Notes ⚠️ Gas Appliance Safety Warning This part is installed in a gas range. Always unplug the range and shut off the gas supply at the shutoff valve before beginning any repair. If you smell gas at any point during or after installation, leave the area immediately and contact your gas utility provider. Do not restore power or gas until the repair is fully complete and all connections are confirmed secure. ⚠️ Handle With Care — Do Not Touch the Igniter Element The silicon carbide igniter element is fragile and sensitive to skin oils. Handle only by the bracket and wiring — never touch the silicon carbide element itself. To install: unplug the range and shut off gas. Remove the oven racks and oven bottom panel to expose the burner assembly. Locate the old igniter mounted next to the oven burner tube. Disconnect the igniter's wire connectors and remove the two mounting screws securing the bracket. Note the wire routing inside the range cavity before removing — be careful not to let the burner wires fall back into the range body. Connect the new W11590294 igniter's pre-attached connectors to the matching wires from the range. Mount the new igniter in the same position with the two bracket screws. Reinstall the oven bottom panel and racks. Restore gas and power, then run a bake cycle and confirm the igniter glows and the burner lights within 60–90 seconds. Tools needed: Phillips screwdriver, work gloves. Frequently Asked Questions What is the relationship between W11590294, W11208965, W11613927, and W11506321? These are all part numbers for the same gas oven igniter across successive production revisions by Whirlpool. W11506321 was an earlier version, W11613927 and W11208965 were subsequent updates, and W11590294 is the current production number. All four are the same flat silicon carbide igniter with the same specifications, dimensions, and function. If your range's parts diagram or old igniter shows any of these numbers, this replacement covers all of them. My oven igniter glows but the burner never lights — is this the right part? Yes — an igniter that glows but fails to light the burner is the most common symptom of a weakened igniter. The gas safety valve requires at least 3.2 amps of current draw through the igniter to hold it open. As the silicon carbide element ages, it draws less current — eventually reaching a point where it glows visibly but no longer draws enough current to fully open the gas valve. If the igniter glows for more than 90 seconds without the burner lighting, it needs replacement. The W11590294 is rated 3.3–3.6 amps, which is the correct range to reliably activate the safety valve on compatible models. What is the difference between W11590294 and W11176454? Both are flat silicon carbide oven igniters for Whirlpool-family gas ranges, but for different model series. The W11590294 is used on the WFG320, WFG505, and related entry-level Whirlpool and Amana gas ranges. The W11176454 (which replaces W10914411) is used on higher-end Whirlpool, Amana, and Maytag models across a broader range of WFG, MGR, and related series. They have the same amperage rating and igniter style but are not always interchangeable — always verify your model number before ordering to confirm which igniter is correct for your range. How do I test if the oven igniter has failed? The most practical test is observation: if the igniter glows for more than 90 seconds without the burner lighting, the igniter is too weak. For a more precise test, use a multimeter in resistance mode — disconnect the igniter and measure resistance across the element. A working W11590294-style igniter typically reads between 40–100 ohms at room temperature. An open circuit (infinite resistance) means the element has burned through completely. You can also test in operation by measuring current draw at the igniter circuit — a reading below 3.2 amps indicates the igniter is too weak to reliably open the gas valve. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is manufactured from silicon carbide, ceramic, metal, and plastic to match the amperage draw, dimensions, and performance of the original W11590294 gas oven igniter. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout

Read more less

XPARTCO PB04001 Oven Bake Igniter for Viking Replaces 065650-000 The XPARTCO PB04001 is an aftermarket replacement oven bake igniter compatible with select Viking gas ranges with hot surface ignition systems, including the CVDSC, EVGIC, EVGRT, VDSC, VGIC, VGRT, VGSC, VGSS, and VGGT series. The oven bake igniter is a flat glow bar hot surface igniter — it draws electrical current through the oven's gas safety valve to open it, then heats to ignition temperature to light the gas burner. When the igniter weakens or fails, the oven will not heat, will take too long to reach temperature, or the igniter will glow but the burner will never light. This is a silicon carbide flat-style igniter with a 2.25-inch white ceramic body and 4.5-inch overall length. Wire leads extend approximately 12.5 inches from the igniter body with female insulated terminals for plug-in installation. Ceramic wire nuts for spliced installation are included. Rated 3.2–3.6 amps at 120V AC — the correct amperage range to open the Viking oven gas safety valve. It directly replaces 065650-000, PB040001, 792263, AP5315579, AP7180264, SGR4001, SGR40001, GR40001, RP712, and AR402. Sold individually. Installs in 15–25 minutes with basic hand tools. Quick Answer The XPARTCO PB04001 Oven Bake Igniter fixes Viking gas ranges where the oven won't heat, takes too long to preheat, or the igniter glows but the burner never lights. Flat silicon carbide glow bar, 3.2–3.6A, 120V AC. Ceramic body 2.25", overall 4.5", leads 12.5" with female terminals. Ceramic wire nuts included. Sold individually. Compatible with Viking CVDSC, EVGIC, EVGRT, VDSC, VGIC, VGRT, VGSC, VGSS, VGGT series. Replaces 065650-000, PB040001, 792263, AP5315579, AP7180264, SGR4001. Common Problems This Part Fixes Oven not heating at all — igniter has failed or burned out Oven takes much longer than normal to preheat Igniter glows orange but the gas burner never lights Gas smell when oven is turned on but burner does not light Oven heats on first use but fails to relight during subsequent heat cycles Igniter visibly cracked, broken, or dark/charred at the ends Oven baking inconsistently or shutting off heat mid-cycle Replaces Part Numbers This oven igniter directly replaces the following OEM and cross-reference part numbers: 065650-000, AP7180264, PB040001, PB04001, 792263, SGR40001, GR40001, RP712, AR402 If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This oven igniter is compatible with select Viking gas ranges with hot surface ignition (glow bar) systems, including the following series: Viking CVDSC series — CVDSC365-4G, CVDSC485-6G and related models Viking EVGIC series — EVGIC305, EVGIC365, EVGIC485 and related models Viking EVGRT series — EVGRT360, EVGRT480, EVGRT600 and related models Viking VDSC series — VDSC365, VDSC367, VDSC485, VDSC487 and related models Viking VGIC series — VGIC245, VGIC245G, VGIC245K, VGIC245Q, VGIC305, VGIC367 and related models Viking VGSC series — VGSC300, VGSC305 and related models Viking VGSS series — VGSS300, VGSS480 and related models Viking VGRT and VGGT series — VGRT360, VGGT240 and related models Note: This igniter is for Viking ranges with hot surface (glow bar) ignition systems only. Not all Viking ranges use this style of igniter — verify your model number before ordering. Always verify compatibility before purchasing. Key Features Flat glow bar hot surface igniter — draws current through the oven gas safety valve to open it, then heats to ignition temperature to light the oven burner Silicon carbide construction — superior heat resistance, reaches 1,800°F–3,100°F operating temperature in approximately 60 seconds Draws 3.2–3.6 amps at 120V AC — correct amperage range to open the Viking oven gas safety valve Ceramic body: 2.25 inches; overall length: 4.5 inches; wire leads: approximately 12.5 inches with female insulated terminals Plug-in installation with female terminals; ceramic wire nuts included for spliced installation if needed Sold individually — one igniter per order Replaces 065650-000, PB040001, 792263, AP5315579, AP7180264, SGR4001, and more Fragile silicon carbide element — handle only by the bracket and wires; never touch the ceramic body with bare hands Aftermarket replacement built to OEM-equivalent quality standards DIY repair — installs in 15–25 minutes with basic hand tools Product Specifications Part Number PB04001 Also Known As PB040001 Part Type Gas Oven Bake Igniter (Flat Glow Bar Hot Surface Igniter) Condition Aftermarket Replacement Application Viking Gas Ranges with Hot Surface Ignition Igniter Style Flat glow bar, silicon carbide Amperage Draw 3.2 – 3.6 Amps Voltage 120V AC Operating Temperature 1,800°F – 3,100°F (approximately 60-second heat-up) Ceramic Body Length 2.25 inches Overall Length 4.5 inches Lead Length Approximately 12.5 inches (female insulated terminals) Includes Igniter and ceramic wire nuts Sold As Single igniter Compatible Brands Viking Installation Notes ⚠️ Gas Appliance Safety Warning This part is used in gas ranges. Always shut off the gas supply at the shutoff valve and unplug the range from the electrical outlet before beginning any repair. If you smell gas at any point during or after installation, leave the area immediately and contact your gas utility provider. If you are not confident working on gas appliances, have this part installed by a qualified appliance technician. ⚠️ Handle With Extreme Care — Fragile Silicon Carbide Element The silicon carbide igniter element is extremely fragile and will crack or break with minimal force. Never touch the ceramic bar with bare hands — oils from skin will damage the element and cause premature failure. Handle only by the bracket, wires, and ceramic wire nut connectors. To install: unplug the range and shut off gas. Remove the oven racks and oven bottom panel. Disconnect the old igniter's wire connector (or cut wires if splicing). Unscrew the mounting bracket from the burner assembly and remove the old igniter. Position the new PB04001 igniter on the burner bracket and secure with the mounting screws. If the female terminals plug directly into the existing wiring, connect them. If wires need to be spliced, use the included ceramic wire nuts — never use standard plastic wire nuts near the oven burner. Reinstall the oven bottom panel and racks. Restore gas and power, then run a test cycle to confirm the igniter heats and the burner lights within 60 seconds. Tools needed: Phillips screwdriver, work gloves. Frequently Asked Questions How does a hot surface igniter work on a Viking gas oven? The hot surface igniter is wired in series with the oven's gas safety valve. When the oven is turned on, electrical current flows through the igniter, heating the silicon carbide element until it reaches ignition temperature — typically glowing bright orange. As the element heats, its electrical resistance changes and the current draw increases to 3.2–3.6 amps. At that amperage level, the gas safety valve opens and gas flows to the burner, where the glowing igniter ignites it. If the igniter weakens and can no longer draw enough current to open the safety valve, the oven will glow but the burner will never fire — this is the most common cause of a Viking oven not heating. What is the difference between PB04001 and PB040001? PB04001 and PB040001 are the same oven igniter — PB04001 is the shortened version of the PB040001 part number. Both refer to the same flat silicon carbide glow bar igniter used on compatible Viking gas ranges. This listing covers both designations and the part functions identically regardless of which number is referenced. How do I know if my oven igniter has failed? The most common sign is an oven that glows orange but the burner never lights. A healthy igniter glows bright orange and ignites the burner within about 60 seconds. If it glows dimly, stays on indefinitely without the burner lighting, or does not glow at all when the oven is turned on, the igniter has failed. You can also test with a multimeter — with the oven cold and unplugged, a working igniter shows resistance of approximately 40–90 ohms; an open circuit confirms failure. Visually inspect the element for cracks, dark spots, or a broken ceramic bar. Why must I use ceramic wire nuts instead of standard plastic ones? Standard plastic wire nuts are not rated for the temperatures inside an oven cavity — they will melt or degrade near the burner, exposing bare wires and creating a safety hazard. Ceramic wire nuts (included with this igniter) are heat-rated for oven burner temperatures and provide a safe, permanent connection when splicing is required. Always use only ceramic wire nuts for any wiring connections near the oven burner. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Viking OEM part, but is manufactured from silicon carbide and high-temperature materials to match the electrical specifications and dimensions of the original 065650-000 oven bake igniter. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout

Read more less

316282997 Range Genuine OEM Maintop Glass Assembly Genuine OEM range maintop glass assembly designed to restore the cooking surface appearance and support proper cooktop operation. ✓ Genuine OEM Part ✓ Replaces 316282997 ✓ Compatibility Support Product Description The Genuine OEM 316282997 Range Maintop Glass Assembly provides the main glass cooking surface for compatible electric ranges. A cracked or damaged maintop assembly can affect cooking safety, appearance, and cooktop performance. Replacing the maintop glass assembly can help restore the original appearance and functionality of your range cooktop. Quick Answer If your range cooktop glass is cracked, chipped, or damaged, the 316282997 maintop glass assembly may need replacement. ⚠️ Always verify your range’s model number before ordering. Contact our support team if you’re unsure. Common Problems This Part Fixes Cracked range cooktop glass Damaged maintop assembly Chipped or broken cooking surface Unsafe cooktop operation Worn or damaged glass top appearance Replaces part Number 316282997, AFR16080, AP5788357, 3016593, PS8746736. Compatibility This part fits select Frigidaire, Electrolux, Kenmore, and compatible electric range models using part number 316282997. Always verify your range’s model number before ordering. Contact our support team if you’re unsure. Key Features Genuine OEM maintop glass assembly Restores cooktop appearance and function Supports safe cooking surface operation Designed for compatible electric ranges Durable OEM replacement component Product Specifications Brand Frigidaire Part Type Range Maintop Glass Assembly Primary Part Number 316282997 Compatible Appliance Type Range Condition Genuine OEM New Installation Disconnect power before installation. Handle glass surfaces carefully to avoid damage. Troubleshooting Guide ⚠️ Disconnect power before servicing the range. Inspect the glass surface for cracks or chips. Check burner mounting areas for damage. Ensure cooktop surface is aligned properly after installation. Replace the maintop assembly if damaged or unsafe for use. When Should You Replace This Part? Replace the maintop glass assembly if the cooktop surface is cracked, chipped, damaged, or unsafe to operate. Shop With Confidence We are a U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock parts for major appliance brands and ship quickly from our U.S. warehouse. ✓ Fast Shipping ✓ Genuine OEM Parts ✓ Compatibility Support ✓ Secure Checkout

Read more less

318258203 Genuine OEM Frigidaire Range Radiant Bridge Surface Burner Element The 318258203 is a Genuine OEM Frigidaire replacement radiant bridge surface burner element compatible with select Frigidaire, Electrolux, and Kenmore electric ranges and cooktops. This is a dual surface bridge element — it spans two separate burner zones and bridges them together to create one large, elongated heating surface ideal for griddles, fish pans, and oversized cookware. Rated at 1800W / 2600W, it uses an exposed resistance wire (haliant-style) to generate heat directly on the glass-ceramic cooktop surface. As a Genuine OEM part manufactured by Frigidaire to factory specifications, the 318258203 is a direct factory-exact replacement. It also replaces the earlier 7318258203 part number. The element uses exposed resistance wire to heat the cooking surface — note that minor surface cracks in the glass covering do not affect heating performance. Before installation, photograph the original element's wire terminal connections so you can reconnect the new element correctly. Always unplug the range before beginning. Installs in 20–30 minutes with basic hand tools. Quick Answer The 318258203 Genuine OEM Frigidaire Radiant Bridge Surface Burner Element fixes electric ranges where the bridge burner zone is not heating, heats unevenly, or the element has visibly burned out. Dual bridge element rated 1800W/2600W. Haliant-style exposed resistance wire. Replaces 7318258203. Compatible with Frigidaire, Electrolux, and Kenmore electric ranges. Genuine OEM — factory-exact fit and performance. Common Problems This Part Fixes Bridge burner zone not heating at all when activated Bridge element heating only on one side — uneven heating across the element Visible burn marks, breaks, or open spots on the resistance wire Bridge burner zone glowing on one side but not the other Element cycles on and off erratically instead of maintaining steady heat Cooktop surface shows discoloration or hot spots directly above the element area Replaces Part Numbers This burner element directly replaces the following OEM and cross-reference part numbers: 318258203, 1197704, 7318258203, AH1529079, AFR16668, AP3965799, EA1529079, PD00057059, PS1529079. Contact our support team with your model number if you need confirmation before ordering. Compatibility This bridge surface element is compatible with select electric ranges and cooktops from the following brands: Frigidaire electric ranges and cooktops Electrolux electric ranges and cooktops Kenmore / Sears electric ranges (Frigidaire/Electrolux-built models) Always verify your appliance model number before ordering. Contact our support team if you're unsure. Key Features Genuine OEM part manufactured by Frigidaire to factory specifications — guaranteed fit and performance Dual bridge element — spans two burner zones to create one large elongated cooking surface for griddles and oversized cookware Rated 1800W / 2600W — dual-power design for large-surface cooking flexibility Haliant-style exposed resistance wire heating — heats the glass-ceramic surface directly and efficiently Replaces 7318258203 and cross-references AH1529079, AFR16668, AP3965799, EA1529079, PD00057059, PS1529079. Compatible with Frigidaire, Electrolux, and Kenmore electric ranges Note: photograph terminal wiring before removal to ensure correct reconnection Product Specifications Part Number 318258203 Also Replaces 7318258203 Part Type Radiant Bridge Surface Burner Element (Dual / Haliant-style) Condition Genuine OEM Application Electric Ranges and Cooktops (glass-ceramic surface) Wattage 1800W / 2600W (dual power) Element Type Haliant — exposed resistance wire on element surface Element Style Bridge (spans two burner zones) Compatible Brands Frigidaire, Electrolux, Kenmore Installation Notes ⚠️ Unplug Range Before Starting Unplug the range or turn off the circuit breaker before beginning. Allow the cooktop to cool completely before touching the element. Photograph the existing element's terminal wiring connections before disconnecting anything — the terminal block connections must be replicated exactly on the new element. Lift the glass-ceramic cooktop surface by opening the front and removing the retaining screws (typically under the front trim), then prop the top open. Unplug the element's terminal connections from the terminal block. Remove the element bracket screws and lift the old element out. Position the new 318258203 element in the same location, secure the mounting bracket, and reconnect the terminal wires in the same positions as documented in your photo. Lower the cooktop, restore power, and test both bridge element power settings. Note: do not touch the haliant wire surface of the element during installation. Tools needed: Phillips screwdriver, 1/4" nut driver. Frequently Asked Questions What is a bridge burner element and what is it used for? A bridge burner element connects two adjacent burner zones on a glass-ceramic electric cooktop into one elongated heating surface. When activated, the bridge element heats the entire combined area — ideal for using a griddle, roasting pan, fish pan, or any large flat-bottomed cookware that spans more than one standard burner. When the bridge is not in use, each adjacent zone functions as its own independent standard burner. The bridge element activates when the bridge control is selected on the range's control panel. What is a haliant element and how is it different from a standard radiant element? A haliant (also called halogent or exposed coil radiant) element uses resistance wire that is partially exposed on the surface of the element body, rather than sheathed inside a smooth glass tube. Both types heat the glass-ceramic surface above them, but haliant elements tend to heat up faster and can reach higher surface temperatures than sheathed radiant elements. Minor surface cracks in the element's glass material do not affect heating performance — the resistance wire is what generates heat, and it functions independently of the outer covering. How do I test if the bridge element has failed? The most reliable test is a continuity check with a multimeter. Unplug the range, lift the cooktop, and disconnect the element's terminal wires. Probe the element's terminal connections with a multimeter set to resistance mode. A working element will show a resistance reading (typically between 10–100 ohms for the heating coil). An open circuit (no continuity / infinite resistance) confirms the element has burned out. You can also visually inspect the haliant wire for visible breaks, dark spots, or melted areas — any visible break in the wire confirms failure. Why is it important to photograph the terminal wiring before removing the old element? Bridge elements have multiple terminal connections for the dual power settings (1800W and 2600W). The wires must be connected to the correct terminals on the new element to ensure both power levels work correctly. If the wires are connected in the wrong order, the element may not heat at all, heat only on one setting, or may not be protected by the correct thermal limiter. Always take a clear photo of the old element's terminal connections before disconnecting anything, and use that photo as a reference when connecting the new element. Is this a Genuine OEM or aftermarket part? This is a Genuine OEM part manufactured by Frigidaire to factory specifications. It is the exact same bridge surface element installed in compatible Frigidaire and Electrolux ranges from the factory — guaranteed fit, materials, and performance. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Genuine OEM Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout

Read more less

XPHVC1095 Microwave High Voltage Capacitor, 2100 VAC, 0.95 µF – Universal Microwave Replacement Product Description Restore proper microwave heating performance with the HVC1095 Microwave High Voltage Capacitor (2100 VAC, 0.95 µF). This high-quality aftermarket capacitor stores and releases electrical energy required by the high-voltage circuit to power the magnetron. A faulty capacitor may cause the microwave to stop heating, hum loudly, or trip breakers. Replacing it with this reliable XPHVC1095 capacitor helps restore efficient heating and safe microwave operation. Compatibility This universal microwave high-voltage capacitor is compatible with many GE, Whirlpool, Samsung, LG, Frigidaire, Panasonic, Sharp, and Kenmore microwave ovens that require a 2100 VAC, 0.95 µF capacitor. Commonly used in countertop, over-the-range, and built-in microwave models. Always verify voltage and capacitance requirements before ordering.Contact our support team if you’re unsure. ✅ Key Features 🔄 Aftermarket Replacement – Built to OEM-equivalent electrical specifications ⚡ 2100 VAC, 0.95 µF Rating – Supports proper magnetron operation 🔥 Restores Heating Function – Fixes microwave running but not heating 💪 Heavy-Duty Construction – Designed for high-voltage applications 💰 Cost-Effective Repair – Reliable alternative to OEM microwave capacitors 📐 Product Specification Part Number: XPHVC1095 Component Type: Microwave High Voltage Capacitor Voltage Rating: 2100 VAC Capacitance: 0.95 µF (microfarad) Application: High-voltage power supply circuit, (4.8 mm) 2 male terminals, Oval Shape Mounting: Bracket-mounted Quality Level: Aftermarket replacement (not OEM) 🛠️ Installation Notes Tools Needed: Phillips screwdriver, insulated pliers ⚠️ Safety First:WARNING: This high-voltage capacitor is for microwaves. High-voltage capacitor is an electric device that holds a charge of electricity in the high-voltage circuit of the microwave. Because high-voltage capacitors in a microwave can retain a lethal electrical charge even when the microwave is unplugged, a service technician should install this part. Basic Steps: Unplug the microwave. Remove the outer cabinet. Safely discharge the existing capacitor. Disconnect wiring and remove the old capacitor. Install the new HVC1095 capacitor securely. Reconnect wiring, reassemble the cabinet, and restore power. Test microwave heating operation. ⏱️ Time Required: 20–30 minutes 📦 Shop With Confidence 🚚 Free Shipping on All Orders ⚙️ Trusted Aftermarket Appliance Parts 🔄 30-Day Return Policy Restore microwave heating safely and efficiently — Add to Cart Now for a dependable, budget-friendly repair!

Read more less

10 Pack - XPARTCO EXPHV10 Microwave High Voltage Diode The XPARTCO EXPHV10 is a universal aftermarket replacement high voltage diode (rectifier) compatible with most major microwave brands including GE, Whirlpool, Maytag, Samsung, LG, Frigidaire, Panasonic, Sharp, KitchenAid, and Kenmore. The high voltage diode is a critical component in the microwave's high-voltage circuit, working alongside the high-voltage capacitor and transformer to convert alternating current (AC) to direct current (DC) — providing the high-voltage DC power required by the magnetron to generate microwave energy and heat food. When the diode fails — due to electrical surges, overheating, or normal wear — the magnetron cannot receive the correct power supply, resulting in a microwave that runs but does not heat. A failed diode may also cause the high-voltage fuse to blow repeatedly. Rated at 12,000V DC (12 kV) with a 500mA current capacity, the EXPHV10 is a universal cross-brand replacement that meets or exceeds OEM specifications across hundreds of microwave models. ⚡ HIGH VOLTAGE SAFETY WARNING — READ BEFORE SERVICING Microwaves contain a high-voltage capacitor that can store a lethal electrical charge of up to 2,100 volts even when the microwave is unplugged. Do NOT touch any internal components without first discharging the capacitor. If you are not experienced with high-voltage appliance repair, do not attempt this repair yourself — contact a qualified appliance technician. Always unplug the microwave before opening the cabinet and discharge the capacitor using a properly insulated discharge tool before handling any internal parts. Quick Answer The XPARTCO EXPHV10 Microwave High Voltage Diode fixes microwaves that run but produce no heat, have a repeatedly blown fuse, or have a humming sound with no heating. It converts AC to DC power for the magnetron and is rated 12,000V DC / 500mA. Universal fit — compatible with most GE, Whirlpool, Maytag, Samsung, LG, Frigidaire, Panasonic, Sharp, KitchenAid, and Kenmore microwaves. Common Problems This Part Fixes Microwave runs (turntable spins, light works) but does not heat food High-voltage fuse blows repeatedly after replacement Loud humming or buzzing sound with no heating Microwave takes much longer than normal to heat food Microwave heats unevenly or inconsistently Replaces Part Numbers This diode directly replaces the following OEM and cross-reference part numbers: HV10, EXPHV10, 2CL70, 2CL77, W11256462, W10886077, AWP43735, PD00047836, AP6784287, PS12584264, WB27X1160, AGE22195, PD00026293, AP2026385, PS239843, DE91-70063D, DE91-70063A, ASM94577, PD00033057, AP4236698, PS4235633, 5304417430, AP2151558, PS472334, 6021W3B001U, AP4439834, PS3528798, 6851W1A002E, ALG51731, PD00006373, AP5203812, PS3529603, 5304456178, AP3960683, PS1532581, 3518400800, AP7110292, 5304509479, 5304472472, AFR17769, PD00040522, AP4433625, PS12071314, WPR9800486, AWP128355, PD00004942, AP6014695, PS11747959, 11QBP0237, AP5633255, PS4085135, WB27X10744, AP3792899, PS953886, WB27X35382, WB27X10930, WB18X10449, WB27X10892, WB27X10965, WB27X11035, AP6992536, PS16219547, WB27X10562, AGE1037090, AP3187536, PS239704, WP13091701, AWP634588, PD00035043, AP6005641 PS11738693, WB27X10687, AGE1019656, PD00032466, AP3207509, PS953843, WB27X10107, AP2026017, PS239224, WB27X10037, AGE22509 PD00031660, AP2025948, PS239148, WPDE91-70063D, AWP547793, PD00034036, AP6014620, PS11747873, 6021W3B001V, 6021W3B001R, AP5632506 EAP3528799, ALG51931, PD00008859, AP4438526, PS3528799, WB27X21012, AGE360033, PD00037340, AP5791119, PS8754690, 00625682, 10001605, ABS11495, PD00047510, AP5804800, PS8770335, CL04-12. If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This universal high voltage diode is compatible with most microwave ovens from the following brands: GE and Hotpoint microwaves Whirlpool microwaves Maytag microwaves KitchenAid microwaves Samsung microwaves LG microwaves Frigidaire and Electrolux microwaves Panasonic microwaves Sharp microwaves Kenmore / Sears microwaves Always verify your appliance model number before ordering. Contact our support team if you're unsure. Key Features Converts AC to DC power in the microwave's high-voltage circuit — enabling the magnetron to generate microwave energy and heat food Rated 12,000V DC (12 kV) / 500mA — meets or exceeds OEM electrical specifications Universal fit — compatible with most major microwave brands across hundreds of models Aftermarket replacement built to OEM-equivalent quality standards Pre-terminated leads — direct drop-in replacement, no modification required Compact insulated design for safe and easy installation Budget-friendly fix for one of the most common microwave no-heat failures Product Specifications Part Number EXPHV10 Part Type High Voltage Diode (Rectifier) Condition Aftermarket Replacement Application Microwave Oven High Voltage Circuit Voltage Rating 12,000V DC (12 kV) Current Rating 500 mA Material Insulated Epoxy Body Terminals Pre-terminated leads Fit Type Universal — fits most major microwave brands Compatible Brands GE, Whirlpool, Maytag, KitchenAid, Samsung, LG, Frigidaire, Panasonic, Sharp, Kenmore Installation Notes ⚡ DANGER — HIGH VOLTAGE — DISCHARGE CAPACITOR BEFORE SERVICING Microwaves store a lethal charge in the high-voltage capacitor even when unplugged. You must discharge the capacitor before touching any internal parts. Use a properly insulated discharge tool or resistor — never a screwdriver or bare wire. Once the capacitor is safely discharged: unplug the microwave and remove the outer cover. Locate the high voltage diode — it is connected between the high-voltage capacitor and the chassis ground. Disconnect both leads, note the orientation/polarity, remove the old diode, and install the new EXPHV10 in the same position and orientation. Reconnect leads, reassemble the cover, and test heating operation. Time required: approximately 20–25 minutes. If you are unsure about any step, contact a qualified appliance technician. Frequently Asked Questions Will the EXPHV10 fit my microwave? The EXPHV10 is a universal replacement diode compatible with most GE, Whirlpool, Maytag, KitchenAid, Samsung, LG, Frigidaire, Panasonic, Sharp, and Kenmore microwaves. Use the model search above to verify, or contact our support team before ordering. What does the high voltage diode do? The high voltage diode works with the capacitor and transformer to convert AC power to high-voltage DC power — typically around 4,000 to 5,000 volts. This DC voltage powers the magnetron, which generates the microwave energy that heats food. A failed diode prevents the magnetron from receiving proper power, resulting in a microwave that runs but does not heat. How do I test if my microwave diode is bad? After safely discharging the capacitor, use a multimeter set to the diode test mode. A good diode will show continuity in one direction and no continuity in the other (one-way electrical flow). A bad diode will show either no continuity in both directions (open) or continuity in both directions (shorted). A shorted diode will also cause the fuse to blow repeatedly. My microwave fuse keeps blowing — is the diode the problem? A shorted high voltage diode is one of the most common causes of a repeatedly blown microwave fuse. When the diode shorts, it draws excess current which blows the fuse. If you replace only the fuse and it blows again immediately, test the diode and capacitor as well before replacing the fuse again. Is this an OEM or aftermarket part? This is an aftermarket universal replacement part built to OEM-equivalent electrical specifications. It is not a genuine OEM part from any specific brand, but is rated at 12,000V DC / 500mA — meeting or exceeding the requirements of most microwave high-voltage circuits. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout

Read more less

XPHVP-16 Microwave Convection Oven High Voltage Diode – Replaces TurboChef 100481 – Compatible with Commercial & Residential Microwave Models Product Description Restore proper heating performance in your commercial or residential microwave with the XPHVP-16 Microwave Convection Oven High Voltage Diode. This high-quality aftermarket diode replaces TurboChef 100481 and is engineered to handle the elevated heat and voltage levels found in high-speed ovens and convection microwave systems. A failing HV diode can cause the microwave to run without heating, blow fuses, or produce loud humming sounds. Installing this XPHVP-16 diode restores safe high-voltage operation and consistent heating. Replaces Part Numbers XPHVP-16, TurboChef 100481, HV07-16, HVP-16, TBC100481, CKTE100481 equivalent high-voltage microwave diodes.  Compatibility This aftermarket high-voltage diode replaces TurboChef 100481 and fits many commercial and household microwave or convection microwave ovens, including: Fits specific TurboChef models including Bullet, ECO ST, Encore, Encore 2, G5, I3, NGC, NGC2, NGO, Sota/I1, TORNADO 2, i5. Typical compatible equipment includes:TurboChef High-Speed Ovens, and other convection microwave systems requiring a 12–16kV diode. Always verify electrical specifications before ordering.Contact our support team if you’re unsure. ✅ Key Features 🔄 Aftermarket Replacement – Designed to replace TurboChef 100481 and match OEM electrical performance 🔥 High-Heat & High-Voltage Rated – Built for demanding commercial microwave environments 💰 Cost-Effective Commercial Repair – A reliable alternative to costly OEM replacement parts 🛡️ Solves Common Issues – Fixes no-heat conditions, humming, blown fuses, and weak heating output 📐 Product Specification Part Number: XPHVP-16 Replaces: TurboChef 100481 Component Type: High Voltage Rectifier Diode Voltage Rating: 12–16 kV peak Current Rating: Max. Forward Current 750MA Polarity: Standard microwave HV polarity (stripe = cathode) Material: Heat-resistant high-voltage diode with insulated leads Compliance: Built to OEM-equivalent quality standards (not OEM) 🛠️ Installation Notes Tools Needed: Screwdriver, insulated gloves, needle-nose pliers ⚠️ Safety First: Microwave and commercial oven repairs involve dangerously high voltage even when unplugged. Only qualified technicians should replace HV components. Steps (for trained professionals): Disconnect power and properly discharge the HV capacitor. Remove the microwave or oven’s service cover. Locate the HV diode near the capacitor and transformer. Remove the old diode and install the new XPHVP-16, ensuring correct polarity. Reassemble unit and test heating performance. ⏱️ Time Required: 20–30 minutes (professional repair recommended) 📦 Shop With Confidence 🚚 Free Shipping on All Orders ⚙️ Trusted Appliance & Commercial Equipment Parts Supplier 🔄 30-Day Return Policy Restore powerful, consistent heating — Add to Cart Now for a reliable and cost-effective replacement!

Read more less

XPARTCO S99527471 Hood Fuse – Compatible with Broan, Nutone, and Kenmore Range Hoods Product Description Protect your vent hood’s electrical system with the XPARTCO S99527471 Hood Fuse. This high-quality aftermarket replacement safeguards your range hood’s control board, fan motor, and lights from electrical surges and overheating. A blown fuse can cause the fan or light to stop working. Replacing it with this reliable XPARTCO fuse restores safe, efficient operation at a fraction of the OEM cost. Replaces Part Numbers S99527471, AP5611426, 1931293, PS10281737, 99527471. Compatibility This replacement hood line fuse fits select Broan, Nutone, and Kenmore range hoods. Example compatible models include (but are not limited to): Broan QP230SS, Nutone RL6200 Series, and Kenmore 233.52343310. Always verify your range hood’s model number before ordering. Contact our support team if you’re unsure. ✅ Key Features 🔄 Aftermarket Replacement – Designed to meet OEM safety and performance standards ⚡ Electrical Protection – Prevents power surges from damaging internal components 💰 Cost-Effective Solution – High-quality fuse at a lower price than OEM parts 🛠️ Quick Installation – Direct-fit design for easy DIY replacement 🛡️ Fixes Common Issues – Restores power to hood lights or fan after fuse failure 📐 Product Specification Part Number: S99527471 Component Type: Range Hood Line Fuse Material: Ceramic fuse with insulated metal terminals Mounting: Inline wiring harness or fuse holder on control board Operating Conditions: Rated for high-temperature kitchen environments Compliance: Built to OEM-equivalent quality and safety standards (not OEM) 🛠️ Installation Notes Tools Needed: Phillips screwdriver, needle-nose pliers ⚠️ Safety First: Always unplug the range hood or turn off power at the circuit breaker before servicing to prevent electrical shock. Steps: Disconnect power and remove the control panel or cover. Locate the fuse on the wiring harness or control board. Gently remove the blown fuse using pliers. Install the new XPARTCO S99527471 fuse securely in place. Reassemble the cover, restore power, and test operation. ⏱️ Time Required: 10–15 minutes 📦 Shop With Confidence 🚚 Free Shipping on All Orders ⚙️ Trusted Appliance Parts Supplier 🔄 30-Day Return Policy Restore your range hood’s safety and performance — Add to Cart Now for a reliable, affordable replacement!

Read more less

Genuine Whirlpool W10727360 Microwave Door Switch - Compatible with Whirlpool, Maytag, Amana, KitchenAid, Jenn-Air, Kenmore Product Description Ensure safe microwave operation with the Genuine Whirlpool W10727360 Microwave Door Switch. This OEM three-terminal switch is designed for select Whirlpool, Maytag, Amana, KitchenAid, Jenn-Air, Magic Chef, Roper, Admiral, and Kenmore microwaves, preventing operation when the door is open to protect users from radiation exposure. Crafted for precise fit and reliable performance, it restores functionality, addressing issues like the microwave not starting or running with the door open. Note: Includes one three-terminal door switch. Disconnect power before installation. Professional installation is recommended due to microwave shielding requirements. Replaces part numbers: W10727360, W10269457, 3379124, PD00026511, EAP10057151, AP5950105, PS10057151, W10727360VP. Compatibility: Compatible with models including but not limited to: Whirlpool: WMH31017FB0, WMH31017HB0, WMH31017FS0, WMH31017FW0, WMH75021HZ0 Maytag: MMV4205FZ0, MMV6190FZ0 Amana: AMV2307PFS0 KitchenAid: KMHS120ESS0 Jenn-Air: JMV8208CS0 Kenmore: (select models, verify compatibility) Verify your model number or contact our support team for assistance. Key Features: ✅ Brand and Models Compatibility: Fits select Whirlpool, Maytag, Amana, KitchenAid, Jenn-Air, Magic Chef, Roper, Admiral, and Kenmore microwaves. 🔐 Specifications: OEM three-terminal door switch, approximately 1.5 inches with metal terminals, for precise safety control. 💪 Reliable Performance: Authentic Whirlpool part ensures long-lasting durability and safe operation. 🛠️ Easy Installation: Requires screwdriver and typically installed in 15–30 minutes by a professional. 🛡️ Effective Fixes: Resolves microwave not starting, intermittent stopping, running with door open, or unusual door noises. Product Specification Part Number: Genuine Whirlpool W10727360 Component Type: Microwave door switch (three-terminal) Material: Plastic housing with metal terminals Electrical: Compatible with 120V microwave circuits Mounting: Screw-mounted with spring mechanism, typically located behind the control panel Operating Conditions: Suitable for household microwave environments Compliance: Prop 65 warning for California Installation Notes: Safety First: Disconnect the microwave from the power source before installation. Shop for high-quality Genuine appliance parts with a 30-day return policy. Keep your microwave safe and functional today! Add to cart now for a reliable fix!

Read more less

XPARTCO W10711017 Range Vent Hood Thermal Fuse The replacement W10711017 Range Vent Hood Thermal Fuse is designed for Jenn-Air range hood models. This replacement fuse protects the range hood’s electrical system (e.g., fan or motor circuits) from overheating or power surges. Ideal for restoring functionality to Jenn-Air range hoods experiencing issues like no power, fan failure, or intermittent operation. This fuse is located on hood control board. Note: Disconnect power before installation. Verify voltage and amperage compatibility with your appliance model. Replaces part numbers: W10711017, AP5949884, PS10057091. Compatibility (W10711017): Compatible with select Jenn-Air range hood models, including but not limited to: Jenn-Air: JXI8736DS00, JXI8742DS00, JXI8936DS00, JXW8736DS00, JXW8936DS00. Verify your model number or contact our support team for assistance. Key Features (W10711017): ✅ Brand Compatibility: Fits select Jenn-Air range hood models. 🔥 Specifications: Replacement thermal fuse, specifications vary by model (typically 125V–250V, verify amperage), heat-resistant, single-use. 💰 Cost-Effective Alternative: Offers OEM-equivalent performance at a lower price. 🛠️ Easy Installation: Requires basic tools (e.g., screwdriver, pliers); typically installed in 10–15 minutes. 🛡️ Reliable Fixes: Addresses range hood issues like no power, fan failure, or intermittent operation. Installation Notes (W10711017): Safety First: Disconnect the appliance from the power source before installation. Location: Typically found on the control board; consult your model’s manual for exact placement. Tools: Use a screwdriver to access the fuse compartment and pliers to remove and install the fuse. Shop Parts-O-Matic for high-quality replacement appliance parts with a 30-day return policy. Get your microwave or range hood running today! Add to cart now for a budget-friendly fix!

Read more less

8053720 Range Genuine Surface Burner Igniter Replaces: W11032529, 8053720, W10850843, W10896683, 3186479, 3186480, 3186482, 3186486, 4455849, AP6038814, PS11770331. 8053720 Range Surface Burner Igniter – Genuine OEM Replacement Ensure reliable burner ignition on your gas range with the 8053720 Surface Burner Igniter. This Genuine OEM part provides the spark needed to ignite the burner quickly and safely. Key Features: ✅ Replaces: W11032529, 8053720, W10850843, W10896683, 3186479, 3186480, 3186482, 3186486, 4455849, AP6038814, PS11770331. ✅ Compatible with Whirlpool, KitchenAid, Maytag, and more ⚡ Supplies consistent spark to surface burner 🛠️ Durable ceramic construction for long-lasting use 🧰 Easy to install – OEM fit and function ⚠️ Disconnect power and gas before installation. Need help confirming compatibility? Contact us! 📦 Part Number: 8053720

Read more less
