XPARTCO 349241T Dryer Drum Roller Set (2-Pack)
The XPARTCO 349241T is an aftermarket replacement dryer rear drum support roller set compatible with a wide range of Whirlpool-family 29-inch dryers including Whirlpool, Kenmore, Maytag, KitchenAid, Amana, Roper, Crosley, Estate, Inglis, Admiral, and Magic Chef. The drum support rollers are cylindrical rubber-and-metal wheels mounted on shafts at the rear of the dryer cabinet that cradle and support the outer edge of the drum as it rotates. Without the rollers, the drum would drag directly on the cabinet, causing rapid wear and generating the loud thumping or squealing noise that indicates failing rollers.
This set includes 2 drum rollers, 4 tri-ring retaining clips, and 2 retaining washers — everything needed for a complete rear roller replacement. Each roller measures 3-1/4"L x 1"W x 3-1/4"H and is constructed from rubber over a metal bearing hub with a plastic axle support. Both rollers must always be replaced at the same time. The set directly replaces 349241, 349241TVP, 8170, 8205, 337089, 340352, 661562, 3389901, 3397588, 3397590, AP3098345, PS347627, and several additional cross-reference numbers. Often replaced together with the drum belt (341241) and idler pulley (691366 or 279640) for a complete drum drive repair. Installs in 30–60 minutes with basic hand tools.
Quick Answer
The XPARTCO 349241T Dryer Drum Roller Set fixes Whirlpool-family 29" dryers that are squealing, thumping, rumbling, or where the drum is not turning smoothly. Set of 2 rollers with 4 tri-rings and 2 retaining washers. 3-1/4"L x 1"W x 3-1/4"H each. Replace both rollers at the same time. Compatible with Whirlpool, Kenmore, Maytag, KitchenAid, Amana, Roper, Crosley, Estate, Inglis, Admiral, and Magic Chef 29" dryers. Replaces 349241, 8170, 8205, 337089, 3389901, AP3098345, PS347627.
Common Problems This Part Fixes
Loud thumping, rumbling, or squealing noise during the drying cycle
Grinding or scraping sound when the drum is turning
Drum turning unevenly or wobbling during operation
Drum not spinning — rollers so worn they can no longer support the drum
Squealing or squeaking that gets worse over time as roller bearings degrade
Marks or scuff lines on clothes — drum dragging against the dryer cabinet
Excessive vibration during the drying cycle
Replaces Part Numbers
This drum roller set directly replaces the following OEM and cross-reference part numbers:
349241T, 26000349241, 337089, 3389901, 3397588, 3397590, 340352, 3436, 349241, 349241TVP, 661562, 8170, 8205, 99989678, 99989679, AWP39168, AH347627, EA347627, K34-895, PD00002257, EAP347627, AP3098345, PS347627.
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This drum roller set is compatible with select 29-inch gas and electric dryers from the following brands:
Whirlpool dryers (gas and electric — 29" models)
Kenmore / Sears dryers (Whirlpool-built models)
Maytag dryers
KitchenAid dryers
Amana dryers
Roper dryers
Crosley dryers
Estate dryers
Inglis dryers
Admiral dryers
Magic Chef dryers
Note: The 349241T rollers are for 29-inch Whirlpool-family dryers. Newer Whirlpool Duet front-load dryers and larger-capacity models use different roller part numbers (such as WPW10314173 / 8536974). Always verify your model number before ordering.
Key Features
Set of 2 rear drum support rollers — supports and cradles the drum as it rotates for smooth, quiet operation
Includes all hardware: 2 rollers, 4 tri-ring retaining clips, 2 retaining washers — everything needed for a complete installation
Dimensions: 3-1/4"L x 1"W x 3-1/4"H per roller
Rubber wheel over metal bearing hub with plastic axle support — designed to resist wear and heat under continuous drum load
Both rollers must be replaced at the same time — replacing only one results in uneven drum support and accelerated wear on the new roller
Often replaced together with the drum belt (341241) and idler pulley (691366 or 279640) for a complete drum drive repair
Compatible with 11 major appliance brands on the Whirlpool 29-inch platform
Aftermarket replacement built to OEM-equivalent quality standards
DIY repair — installs in 30–60 minutes with basic hand tools
Product Specifications
Part Number
349241T
Part Type
Dryer Rear Drum Support Roller Set
Condition
Aftermarket Replacement
Application
29-inch Gas and Electric Dryers
Quantity
Set of 2 rollers (replace both at the same time)
Roller Dimensions
3-1/4"L x 1"W x 3-1/4"H (per roller)
Material
Rubber wheel / Metal bearing hub / Plastic axle support
Color
Black / White
Kit Includes
2 drum rollers, 4 tri-ring retaining clips, 2 retaining washers
Often Replaced With
341241 Drum Belt, 691366 or 279640 Idler Pulley
Compatible Brands
Whirlpool, Kenmore, Maytag, KitchenAid, Amana, Roper, Crosley, Estate, Inglis, Admiral, Magic Chef
Installation Notes
⚠️ Unplug Dryer Before Starting Disconnect power (and shut off gas for gas dryers) before beginning. Remove the lint screen and unscrew the screws inside the lint screen housing. Use a putty knife to release the top panel spring clips and lift the top panel. Remove the front panel to access the drum. Release the drive belt from the idler pulley, lift the drum forward, and set it aside. The rear drum support rollers are mounted on shafts on the rear bulkhead — each roller is secured with a tri-ring clip and a retaining washer. Use needle-nose pliers to remove the old tri-ring clips, then slide the old rollers off the shafts. Install the new rollers, new retaining washers, and new tri-ring clips on the shafts. Reinstall the drum, re-route the belt around the motor and idler pulley, and reassemble the front and top panels. Restore power and run a test cycle to verify quiet, smooth drum operation. Tip: while the dryer is open, inspect and replace the drum belt (341241) and idler pulley (691366 or 279640) if worn. Tools needed: Phillips screwdriver, 1/4" or 5/16" nut driver, putty knife, needle-nose pliers.
Frequently Asked Questions
What do the drum support rollers do?
The rear drum support rollers are cylindrical wheels mounted on fixed shafts at the back of the dryer cabinet. As the drum rotates, its rear outer rim rests on these rollers, which carry the drum's weight and allow it to spin smoothly and quietly. When the rubber wheels wear down or the bearing hubs corrode, the drum no longer rides smoothly on the rollers — causing thumping, rumbling, or squealing noises that get progressively worse. In severe cases, worn rollers allow the drum to sag and drag against the cabinet rear panel.
Why must I replace both rollers at the same time?
Both rear drum support rollers carry the same load and experience the same wear through every drying cycle. When one roller fails, the other has been under the same stress for the same number of cycles and is almost certainly near the end of its useful life. Replacing only the failed roller leaves one worn roller supporting the drum unevenly, which puts extra stress on the new roller and causes it to wear out much faster. Replace both rollers at the same time to ensure even drum support and get the full service life from the new parts.
Should I also replace the belt and idler pulley at the same time?
Yes — this is the ideal time. Since the dryer must be fully disassembled to access the rear drum rollers, replacing the drum belt (341241) and idler pulley (691366 or 279640) at the same time is strongly recommended. All three parts wear at similar rates, and a worn belt or idler pulley is often what caused the rollers to wear prematurely. Doing all three in one repair eliminates the most common drum drive failure points and saves you from repeating the teardown in the near future. The 4392065 maintenance kit includes all three parts together.
What causes dryer drum rollers to wear out?
Drum rollers wear naturally over time from the continuous load of supporting the rotating drum. The most common accelerating factors are operating the dryer with a worn or broken belt (which allows the drum to sag and puts extra weight on the rollers), running very large or heavy loads frequently, and allowing lint to accumulate around the roller shafts, which causes the bearings to run dry and wear faster. Regular dryer maintenance — including cleaning lint from around the drum and periodically checking the belt — helps extend roller life.
Is this an OEM or aftermarket part?
This is an aftermarket replacement set built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is manufactured from rubber, metal, and plastic to match the dimensions and load-bearing performance of the original 349241T drum roller set.
