279570 Genuine OEM Whirlpool Dryer Door Catch Kit
The 279570 is a Genuine OEM Whirlpool dryer door catch and strike kit compatible with a wide range of Whirlpool, Kenmore, Roper, Estate, Amana, Crosley, Inglis, KitchenAid, Maytag, and Admiral dryers. The door catch is the spring-clip mechanism on the dryer door that snaps over the door strike to hold the door firmly closed during operation, activating the door switch so the dryer can run. When the catch breaks, wears out, or loses tension, the door will not stay closed, the door switch will not be activated, and the dryer will either not start or will stop mid-cycle. The strike is the corresponding post or tab on the dryer cabinet that the catch engages.
This Genuine OEM kit includes three color-coded door catches of different tensions and two metal door strikes, plus one screw. Because the tension of the catch must match the original, Whirlpool includes three options in the kit — each is color-coded and numbered on the back. Refer to identify which catch is correct for your model. The kit directly replaces a very large list of older cross-reference numbers including 279570VP, 3493, 2003, 8208, 279280, 279337, 696144, 693717, AP3094183, PS334230, and dozens more. Installs in under 15 minutes with a Phillips screwdriver.
Quick Answer
The 279570 Genuine OEM Whirlpool Dryer Door Catch Kit fixes dryers where the door won't stay closed, pops open mid-cycle, or won't activate the door switch to start. Kit includes 3 color-coded catches (different tensions), 2 metal strikes, 1 screw. Use the catch that matches your original. Genuine OEM. Compatible with Whirlpool, Kenmore, Roper, Estate, Amana, Crosley, Inglis, KitchenAid, Maytag, and Admiral dryers. Installs in under 15 minutes.
Common Problems This Kit Fixes
Dryer door will not stay closed during the drying cycle
Door pops open mid-cycle, stopping the dryer
Dryer will not start — door switch not being activated by a worn or broken catch
Door feels loose or does not click shut firmly when closed
Door catch visibly cracked, broken, or missing
Door strike bent or missing — door cannot engage the catch properly
Dryer requires the door to be held or pushed closed to stay running
Replaces Part Numbers
This door catch kit directly replaces the following OEM and cross-reference part numbers:
279570, 14205029, 14205577, 14210022, 2003, 236876, 236877, 241282, 241890, 26000279570, 261847, 263067, 279280, 279337, 279469, 279570VP, 291949, 3390239, 3392538, 3398175, 342295, 347813, 3493, 4165234, 51651001, 51655001, 66021, 690081, 690082, 693717, 694343, 696144, 8208, 830751, 834767, 834813, 834943, 834944, AH334230, DE902, EA334230, EAP334230, FSP279570, AP3094183, AWP39897, PD00002346, PS334230.
Contact our support team with your model number if you need confirmation before ordering.
Compatibility
This door catch kit is compatible with select dryers from the following brands:
Whirlpool dryers (gas and electric)
Kenmore / Sears dryers (Whirlpool-built models)
Roper dryers
Estate dryers
Amana dryers
Crosley dryers
Inglis dryers
KitchenAid dryers
Maytag dryers
Admiral dryers
Important: This kit includes three catches with different spring tensions, color-coded and numbered on the back. You must use the catch that matches the tension of your original. Using the wrong tension catch may result in a door that is too hard to open or too easy to pop open.
Key Features
Genuine OEM kit manufactured by Whirlpool to factory specifications — guaranteed fit and performance
Holds the dryer door closed and activates the door switch so the dryer can run safely
Kit includes 3 color-coded door catches (different spring tensions), 2 metal door strikes, 1 screw
Catches are color-coded and numbered on the back — use the one that matches your original.
Plastic catches with metal strikes and metal screw — durable construction for long service life
Consolidates a very large list of older Whirlpool-family door catch cross-reference numbers
Compatible with 10 major appliance brands on the Whirlpool platform
Quick DIY repair — installs in under 15 minutes with a Phillips screwdriver
Product Specifications
Part Number
279570
Part Type
Dryer Door Catch and Strike Kit
Condition
Genuine OEM
Application
Gas and Electric Dryers
Kit Includes
3 color-coded door catches (different tensions), 2 metal strikes, 1 screw
Material
Plastic catches / Metal strikes
Color
White / Silver
Catch Selection
Color-coded and numbered, Use the catch that matches your original
Compatible Brands
Whirlpool, Kenmore, Roper, Estate, Amana, Crosley, Inglis, KitchenAid, Maytag, Admiral
Installation Notes
⚠️ Unplug Dryer Before Starting Disconnect power before beginning. using the wrong tension catch will result in incorrect door resistance. Open the dryer door and locate the old door catch on the inside of the door panel and the strike on the dryer cabinet opening. To remove the old catch: press the retaining tabs and pull the catch free from its slot, or unscrew the mounting screw. Install the correct new catch into the same position. To replace the strike: remove the old strike (typically held by a single screw) and install the new strike in the same position. Close the dryer door to confirm it latches firmly with a satisfying click. Restore power and run a short test cycle to confirm the door stays closed and the dryer operates normally. Tools needed: Phillips screwdriver; needle-nose pliers may help with catch removal on some models.
Frequently Asked Questions
Why does the kit include three different catches?
Whirlpool used door catches with different spring tensions across its dryer lineup — a lighter catch on some models and a stiffer catch on others. To cover all compatible models in a single kit, Whirlpool includes three catches of different tensions, each color-coded and numbered on the back. It is important to use the correct one — using a catch with too little tension may allow the door to pop open, while a catch with too much tension may make the door difficult to open.
Do I need to replace both the catch and the strike, or just one?
It depends on which component has failed. The catch (the spring-clip on the door) is the more commonly replaced part — it wears out from repeated use faster than the strike. Inspect both: if the catch is cracked or has lost its spring tension, replace the catch. If the strike is bent, cracked, or missing, replace the strike. Since the kit includes both catches and strikes, you have everything needed for a complete repair. When in doubt, replacing both ensures the full latch system is renewed.
My dryer will not start even after replacing the door catch — what else could it be?
If the dryer still will not start after the catch is replaced, the door switch may also need to be tested. The door switch is the electrical component that the door catch activates when the door closes — if the switch itself is failed, replacing the catch alone will not restore function. Test the door switch (3406105 for most Whirlpool-family models) with a multimeter for continuity in both the open and closed positions. If the switch reads open in both positions or closed in both positions, it has failed and needs replacement.
How is the 279570 different from the W11429587 dryer door catch?
The 279570 is the door catch kit for older Whirlpool-family dryers — it includes multiple catches of different tensions and metal strikes because it covers a wide range of older models. The W11429587 is a single snap-in door catch for newer Whirlpool-family dryers (Cabrio and newer platform models). If your dryer is a newer model with a snap-in catch slot rather than a screw-mounted catch and strike, you likely need the W11429587. Verify your model number to confirm which part is correct.
Is this a Genuine OEM or aftermarket part?
This is a Genuine OEM kit manufactured by Whirlpool to factory specifications. It is the exact same door catch and strike kit supplied by Whirlpool for compatible dryer service repairs — guaranteed fit, materials, and performance.
