WD21X25468 Genuine OEM GE Dishwasher Pressure Sensor Assembly
The WD21X25468 is a Genuine OEM GE replacement dishwasher pressure sensor assembly compatible with a wide range of GE, GE Profile, GE Café, Hotpoint, Haier, and Monogram dishwashers in the GDF, GDT, GDP, PDT, CDT, ZDT, QDP, and HDF series. The pressure sensor monitors water pressure inside the dishwasher tub during fill and drain cycles and sends real-time readings to the electronic control board. The control board uses these readings to calculate the correct amount of water needed for each wash cycle and to confirm that the tub has drained properly before advancing to the next cycle phase.
When the pressure sensor fails — or when it becomes clogged with grease, food residue, or mineral buildup — the dishwasher may not fill with water, may overfill, may stop mid-cycle, may fail to drain correctly, or may display error codes H2O or FTD (Failure to Drain). This Genuine OEM part is manufactured by GE to factory specifications. It directly replaces AP6976524, PS12741258, EAP12741258, 4962334, 37640602, and 265D3356P001. Sold individually. Installs in 15–20 minutes — a screwdriver is the only tool required for most models.
Quick Answer
The WD21X25468 Genuine OEM GE Dishwasher Pressure Sensor Assembly fixes GE dishwashers displaying error codes H2O or FTD (Failure to Drain), not filling with water, overfilling, stopping mid-cycle, or running excessive noise from the spray arms. Monitors water level and pressure — signals the control board to fill, wash, and drain correctly. Genuine OEM. Replaces AP6976524, PS12741258, EAP12741258, 4962334, 37640602, 265D3356P001. Sold individually. Compatible with GE GDF, GDT, PDT, CDT, ZDT, QDP, HDF, and related series.
Common Problems This Part Fixes
Error code H2O displayed — dishwasher not receiving enough water or no water at all
Error code FTD (Failure to Drain) displayed — sensor not confirming tub has drained
Dishwasher not filling with water when a cycle is started
Dishwasher overfilling — sensor not signaling the control board to stop filling
Dishwasher stopping mid-cycle without completing the wash
Excessive noise during operation — sensor not accurately controlling spray arm water pressure
Dishwasher requires priming with water to start (filling the tub manually before it will run)
Replaces Part Numbers
This pressure sensor directly replaces the following OEM and cross-reference part numbers:
WD21X25468, 265D3356P001, AGE24772, AP6976524, EAP12741258, PD00067609, PS12741258.
Contact our support team with your model number if you need confirmation before ordering.
Compatibility
This pressure sensor is compatible with a wide range of dishwashers from the following GE product lines:
GE dishwashers — GDF450, GDF510, GDF511, GDF535, GDF550, GDF565, GDF570, GDF630, GDF640, GDF645 series
GE dishwashers — GDT530, GDT535, GDT565, GDT580, GDT605, GDT625, GDT630, GDT635, GDT645, GDT695 series
GE dishwashers — GDP615, GDP645, GDP665 series
GE Profile dishwashers — PDT715, PDT775, PDT785 series
GE Café dishwashers — CDT800, CDT875 series
GE Monogram dishwashers — ZDT800, ZDT870, ZDT925, ZDT985 series
Hotpoint dishwashers — HDF310, HDF330 series
Haier dishwashers (select GE-platform models)
GE / Café / Profile — QDP555 series
Always verify your appliance model number before ordering. Contact our support team if you're unsure.
Key Features
Genuine OEM part manufactured by GE to factory specifications — guaranteed fit and performance
Monitors water pressure inside the tub throughout fill and drain cycles — signals the control board to fill to the correct level and confirm complete drainage
Resolves H2O and FTD error codes on compatible GE dishwashers
Sensor can also fail due to grease or mineral buildup blocking the pressure port — cleaning may resolve the issue without replacement
Replaces AP6976524, PS12741258, EAP12741258, 4962334, 37640602, and 265D3356P001
Compatible with GE GDF, GDT, GDP, PDT, CDT, ZDT, QDP, HDF, and Hotpoint dishwasher series
Sold individually
Quick DIY repair — installs in 15–20 minutes with a screwdriver
Product Specifications
Part Number
WD21X25468
Part Type
Dishwasher Pressure Sensor Assembly (Pressure Switch)
Condition
Genuine OEM
Application
GE, GE Profile, GE Café, GE Monogram, Hotpoint, Haier Dishwashers
Function
Monitors tub water level and pressure — signals control board for fill and drain control
Error Codes Resolved
H2O (no/low water), FTD (Failure to Drain)
Sold As
Single sensor assembly
Compatible Brands
GE, GE Profile, GE Café, GE Monogram, Hotpoint, Haier
Installation Notes
⚠️ Unplug Dishwasher and Shut Off Water Before Starting Disconnect power and shut off the water supply before beginning. On most compatible GE models, the pressure sensor is located near the bottom of the dishwasher tub, accessible after removing the lower front kick panel (secured by one or two screws). The sensor assembly connects to a small hose and a wiring harness connector. Tip: before replacing the sensor, remove it and inspect the pressure port and hose for grease, food residue, or mineral buildup — a clogged sensor port can cause H2O and FTD errors without the sensor itself being electrically failed. Clean the port and hose with warm water and a small brush, reinstall, and test the dishwasher. If the error codes persist after cleaning, replace the WD21X25468 sensor. To replace: disconnect the hose and wiring harness from the old sensor, unclip or unscrew the sensor from its mounting bracket, and install the new sensor in the same position. Reconnect the hose and harness, restore power and water, and run a test cycle. Tools needed: Phillips screwdriver.
Frequently Asked Questions
What does the dishwasher pressure sensor do?
The pressure sensor monitors the water pressure — and therefore the water level — inside the dishwasher tub throughout the wash cycle. It sends continuous readings to the electronic control board, which uses the data to determine how much water to add during fill, when to stop filling, and whether the tub has drained completely before advancing to the next cycle phase. An accurate pressure sensor is essential for the dishwasher to fill to the correct level (not too much, not too little), wash with the correct spray arm pressure, and drain fully before moving on to rinse or dry cycles.
What do error codes H2O and FTD mean on GE dishwashers?
H2O error code on compatible GE dishwashers indicates that the dishwasher is not detecting enough water in the tub — either water is not filling at all, or the pressure sensor is not sensing the water that has filled. FTD (Failure to Drain) code indicates the dishwasher has not confirmed that the tub has drained within the expected time. Both codes can be caused by a faulty pressure sensor, a clogged sensor port, a failed fill valve, a blocked drain system, or control board issues. The pressure sensor should be inspected and tested first since it is the most accessible and commonly replaced component for these two error codes.
Should I try cleaning the sensor before replacing it?
Yes — absolutely. The pressure sensor on GE dishwashers can produce H2O and FTD error codes when its pressure port or connected hose becomes clogged with grease, food residue, or hard water mineral deposits — even if the sensor itself is electrically intact. Before ordering a replacement, remove the sensor, inspect the pressure port opening, and clean it thoroughly with warm water and a small brush. Flush the connected hose to clear any buildup. Reinstall and run a test cycle. If the error codes return, the sensor has electrically failed and needs replacement with the WD21X25468.
My dishwasher won't fill unless I pour water in manually first — is this the pressure sensor?
Yes — this is a classic symptom of a clogged or failed pressure sensor. When the sensor port is blocked, the sensor reads zero pressure (empty tub) even when the dishwasher starts. In some cases the control board interprets this as a drainage confirmation and will not initiate the fill cycle. Pouring water into the filter manually raises the physical water level enough to trigger filling. Check and clean the sensor port as described above. If cleaning does not resolve the issue, replace the WD21X25468 sensor.
Is this a Genuine OEM or aftermarket part?
This is a Genuine OEM part manufactured by GE to factory specifications. It is the exact same pressure sensor assembly installed in compatible GE, GE Profile, GE Café, Hotpoint, and related brand dishwashers from the factory — guaranteed fit, materials, and performance.
