W10919003 Washer Genuine OEM Drain Pump Replaces Part Numbers: W10919003, 4461359, W10775446, AP6038235, PS11770076. Description: This Water Pump is a Genuine OEM replacement part for specific Maytag, Kenmore, Whirlpool washing machine models. It plays a crucial role in circulating water throughout the wash cycles and draining the used water from the tub.

Read more less

6601EN1003D Washer Door Lock Interlock Switch Replaces Part Numbers: 6601EN1003D, 6601ER1005A, 2651099, AH3636296, AP5594317, EA3636296, PS3636296.   This is an aftermarket part that can be used as a replacement for the OEM part. WARNING: California’s Proposition 65 (California Residents Only)

Read more less

XPARTCO 8572717 Washer Motor Start Capacitor The XPARTCO 8572717 is an aftermarket replacement motor start capacitor for Whirlpool-built top-load washers and washer/dryer combination units. Unlike a run capacitor that stays in the circuit continuously, this start capacitor's job is brief and intense: at the instant the motor is commanded to start, it delivers a strong momentary boost of voltage to help the motor overcome its own inertia and get up to speed quickly. Once the motor reaches running speed, a relay switches it out of the circuit, handing off to the run capacitor for continuous operation. That short, high-stress duty cycle is exactly why start capacitors are a common failure point — they work hard for a fraction of a second on every single cycle start. Rated 189–227 MFD at 125VAC, 60Hz. The capacitor is a black cylindrical component mounted to the rear panel of the washer, held in place by a small plastic retaining clip and wrapped in a foam shield that protects it from moisture. Common failure modes include the internal dielectric breaking down from repeated startup stress, and in some cases the capacitor overheating badly enough to produce visible smoke if it fails while still energized. A failing start capacitor produces a clear symptom: the washer motor hums but won't start, or the motor fails to spin up while other functions of the washer still respond normally. It directly replaces 357021, 3949169, 661606, W10161696, W10244889, AP6013434, AH11746660, EA11746660, EAP11746660, PS11746660, AWP49120, and PD00003006. Quick Answer The XPARTCO 8572717 Washer Motor Start Capacitor fixes Whirlpool-built top-load washers and washer/dryer combos where the motor hums but won't start, the washer won't agitate or spin, or there's a burning smell from the motor area. Includes foam shield. 189–227 MFD, 125VAC, 60Hz. Replaces 357021, 3949169, 661606, W10161696, W10244889, AP6013434, AH11746660, EA11746660, EAP11746660, PS11746660, AWP49120, PD00003006. Capacitors store a dangerous electrical charge even after power is disconnected — always discharge before handling. Common Problems This Part Fixes Washer motor hums but won't start Washer won't agitate Washer won't spin or drain because the motor never starts Burning smell coming from the motor area Washer that starts a cycle but the drum never begins moving Motor that struggles to start under load but may start when the drum is empty Visible discoloration, bulging, or a burnt smell from the capacitor itself Cross Reference Information Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item. Replaces Part Numbers This washer motor start capacitor directly replaces the following OEM and cross-reference part numbers: 8572717, WP8572717, 357021, 3949169, 661606, W10161696, W10244889, AP6013434, AH11746660, EA11746660, EAP11746660, PS11746660, AWP49120, PD00003006 If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This motor start capacitor is compatible with select Whirlpool-built top-load washers and washer/dryer combination units across the Whirlpool family of brands, including: Whirlpool top-load washers and washer/dryer combos — WET, WGT series Kenmore top-load washers (select Whirlpool-built 110-series models) Maytag, KitchenAid, Jenn-Air, and Amana washers (select models) Roper, Admiral, Hardwick, and Estate washers (select models) Magic Chef, Crosley, Inglis, Norge, Modern Maid, and Caloric washers (select models) Select Ikea washers built on the Whirlpool platform Verified model numbers include: WET4027EW, WET4024EW, LTE5243DQ, WET3300XQ, WGT3300XQ, MTW5670TQ0, SAWS800JQ1, LSN7233BW1, LSR7233DZ1, LSQ8243HQ0, LSQ8512KQ0, LSQ8543JQ0, LSQ8543JQ1, LSQ8543JT0, LSQ8543JT1, LSQ9244EQ0, LSQ9544KQ0, LSQ9549LG0, LSQ9549LG1, LSQ9549LG2, LSQ9549LG3, LSQ9549PW2, 8LSC6244BQ0, and Kenmore 110.72407600, 110.72408440, 110.74414130, 110.81360430, 110.82074620, 110.82984100, 110.91565810, and 110.98573110. Note: This capacitor fits both standalone washers and Whirlpool washer/dryer combination units. Always verify your full model number before ordering, since specifications and mounting can vary by platform. Contact our support team with your model number if you're unsure. Key Features Aftermarket replacement start capacitor — delivers a momentary voltage boost to get the washer motor spinning at startup Resolves "motor hums but won't start," "won't agitate," "won't spin," and "burning smell" symptoms caused by capacitor failure Rated 189–227 MFD, 125VAC, 60Hz Includes foam shield to protect against moisture — transfer or reuse per your model's original configuration Direct drop-in replacement — mounts to the same rear panel retaining clip Replaces 357021, 3949169, 661606, W10161696, W10244889, AP6013434, AH11746660, EA11746660, EAP11746660, PS11746660, AWP49120, and PD00003006 Compatible with Whirlpool, Kenmore, Maytag, KitchenAid, Jenn-Air, Amana, Roper, and related top-load washers and washer/dryer combos Aftermarket replacement built to OEM-equivalent quality standards Product Specifications Part Number 8572717 OEM Part Number WP8572717 Part Type Washer Motor Start Capacitor Condition Aftermarket Replacement Application Top-Load Washers / Washer-Dryer Combos (Whirlpool-Built) Capacitance 189–227 MFD (µF) Voltage 125VAC Frequency 60 Hz Shape Cylindrical (black) Included Components Foam moisture shield Mounting Rear panel, plastic retaining clip Quantity 1 start capacitor Compatible Brands Whirlpool, Kenmore, Maytag, KitchenAid, Jenn-Air, Amana, Roper, Admiral, Hardwick, Estate, Magic Chef, Crosley, Inglis, Norge, Modern Maid, Caloric, Ikea Installation Notes ⚠️ Danger — Capacitors Store A Dangerous Electrical Charge Unplug the washer or shut off the house circuit breaker before beginning. A capacitor stores an electrical charge even after power has been disconnected, and that charge can deliver a serious or fatal shock. Before touching either terminal, discharge the capacitor by shorting its two terminals together using an insulated-handle screwdriver, or by using a proper capacitor discharge tool with a resistor. Never short the terminals with a bare metal tool held with your bare hand. If you are not fully comfortable performing a capacitor discharge safely, have a qualified appliance technician replace this part instead. ⚠️ Transfer The Foam Shield To The New Capacitor Wear work gloves. Remove the washer's console and then the spring clips that secure the top/body assembly to the washer frame, using a putty knife to gently release them. With the body lifted or set aside, locate the capacitor — a black cylindrical component mounted to the rear panel, held in place by a small plastic retaining clip. Using a flat-blade screwdriver, gently pop the plastic clip away from the capacitor to release it. After confirming the capacitor is fully discharged, unplug it from the appliance wiring. Remove the foam shield from the old capacitor and transfer it onto the new one before installing — this shield protects the capacitor from moisture, and skipping it leaves the new part more exposed to washer humidity. Connect the new 8572717 capacitor to the wiring, snap it back into the plastic retaining clip in the same position, and reassemble the body, spring clips, and console in reverse order. Restore power and run a test cycle to confirm the motor starts promptly on both agitate and spin. Tools needed: putty knife, flat-blade screwdriver, Phillips screwdriver, insulated-handle screwdriver or capacitor discharge tool, work gloves. Frequently Asked Questions My washer motor hums but won't start. Is this the right part? Yes, this is the classic symptom of a failed start capacitor. Since this capacitor's entire job is delivering the momentary voltage boost needed to get the motor spinning from a standstill, a failure here often leaves the motor energized and humming but unable to actually overcome its own inertia and start turning. What's the difference between a start capacitor and a run capacitor? A start capacitor works only for a brief moment — it delivers a strong voltage boost the instant the motor is told to start, then a relay switches it out of the circuit once the motor reaches running speed. A run capacitor, by contrast, stays in the circuit continuously while the motor operates, correcting current phase for efficiency. Because the start capacitor works so hard in such a short burst on every single start, it's a more common failure point than a run capacitor on this type of motor. Do I need to reuse the foam shield from my old capacitor? Yes, it's worth transferring. The foam shield wraps around the capacitor to protect it from moisture inside the washer cabinet, and reusing it on the new capacitor helps the replacement hold up the same way the original was designed to. If the foam has degraded significantly, you can skip it, but it's a simple step that adds meaningful protection. My old capacitor got hot and smoked. Is that dangerous? Yes — a capacitor that overheats to the point of smoking has failed in a way that can pose a fire or electrical hazard, and the washer should not be used again until it's replaced. This kind of failure typically happens when a capacitor stays energized longer than it should, generating heat it isn't designed to dissipate. Replace the capacitor and, if the washer's start relay or timer seems to be holding the capacitor in the circuit too long, have that checked as well. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is manufactured to match the electrical specifications (189–227 MFD, 125VAC, 60Hz), cylindrical form factor, and mounting configuration of the original WP8572717 start capacitor used in compatible Whirlpool, Kenmore, Maytag, KitchenAid, and related top-load washers and washer/dryer combos. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Quality Aftermarket Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout

Read more less

AHA72973309 Genuine OEM LG Washer Drain & Circulation Pump Assembly The AHA72973309 is a genuine LG OEM drain and circulation pump assembly for LG and select Kenmore front-load washers. This is a dual-purpose pump — an Askoll M120-2 unit — that handles two separate jobs from one motor and housing. During the drain portion of the cycle, it pumps wastewater out of the tub and out through the drain hose. During the wash and rinse portions, it switches roles and recirculates water from the bottom of the tub back up through the dispenser and spray nozzle, showering it back over the load. That recirculation spray is what lets LG's front-load washers clean effectively with less water than an older top-load design would need. Because this single assembly performs both functions, a failure here can show up in more than one way: standing water left in the tub after a cycle, a washer that won't complete its drain step, unusual grinding or humming noise, or reduced wash performance if the recirculation spray isn't working even though draining still seems fine. Common causes include debris such as coins, buttons, or lint lodged in the impeller, general wear and tear on the motor bearings, or an electrical failure in the pump motor itself. It directly replaces AP5676608, 2659237, AHA72973304, and PS7788830. As a genuine OEM part, the AHA72973309 is manufactured by LG to factory specifications — guaranteed fit, materials, and performance. Quick Answer The AHA72973309 Genuine OEM LG Washer Drain & Circulation Pump Assembly fixes LG and select Kenmore front-load washers with standing water left in the tub after a cycle, a washer that won't drain, unusual grinding or humming noise, or reduced wash performance from a weak recirculation spray. Askoll M120-2 dual-purpose pump — handles both draining and mid-cycle water recirculation. Replaces AP5676608, 2659237, AHA72973304, PS7788830. Installation is average difficulty, 30 to 60 minutes — and on many models it's accessible through the front panel without needing to tip the washer over. Common Problems This Part Fixes Standing water left in the tub after a cycle finishes Washer won't drain, or drains very slowly Drainage-related error code displayed on the control panel Unusual grinding, humming, or rattling noise during the drain or wash portion of the cycle Reduced wash performance — clothes not getting as clean, possibly from a weak recirculation spray Washer stalling mid-cycle at the drain step Water leaking from underneath the washer near the pump housing Pump that hums but doesn't seem to move water — possible clog or seized impeller Cross Reference Information Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item. Replaces Part Numbers This washer drain and circulation pump assembly directly replaces the following OEM and cross-reference part numbers: AHA72973309, AHA72973304, AP5676608, 2659237, ALG53336, PD00024680, PS7788830 If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This drain and circulation pump assembly is compatible with select LG front-load washers, and also fits select Kenmore and Kenmore Elite front-load washers built on the LG platform. Note: This is a dual-function drain-and-circulation assembly specific to LG's front-load platform, built around the Askoll M120-2 pump. It is not a drain-only pump, and it is not intended for top-load washers, which use a different pump design. Always verify your full model number before ordering. Contact our support team with your model number if you're unsure. Key Features Genuine LG OEM part — factory-specified motor, impeller, and housing design Dual-purpose Askoll M120-2 pump — drains the tub and recirculates wash water through the dispenser spray nozzle Resolves "standing water in the tub," "won't drain," "grinding or humming noise," and "reduced wash performance" symptoms caused by pump failure Includes all necessary wiring and mounting hardware for a complete replacement Direct drop-in replacement — no modification required Replaces AP5676608, 2659237, AHA72973304, and PS7788830 Compatible with LG and select Kenmore/Kenmore Elite front-load washers Genuine OEM replacement — guaranteed fit, materials, and performance Average installation difficulty — typically 30 to 60 minutes Product Specifications Part Number AHA72973309 Part Type Washer Drain & Circulation Pump Assembly Condition Genuine OEM Brand LG Pump Model Askoll M120-2 Function Drains tub water and recirculates wash water through the dispenser spray Kit Contents Pump assembly with wiring and mounting hardware Application Front-Load Washers (LG-Built) Repair Difficulty Average — 30 to 60 minutes Quantity 1 pump assembly Compatible Brands LG, select Kenmore, Kenmore Elite Installation Notes ⚠️ Unplug Washer And Shut Off Water Before Starting — Drain Residual Water First Disconnect power at the outlet or shut off the circuit breaker, and close the water supply valves before beginning. Wear work gloves. Place towels down and have a shallow pan ready, since the pump housing will hold residual water even after a completed cycle — draining this into a pan before disconnecting hoses will save you a mess. On many models, this pump is fully accessible by removing the front lower access panel or kick plate, without needing to tip the washer onto its back — check this first, since it can save significant time and effort compared to some online guides that recommend tipping the unit. Photograph the hose routing and wiring connections before disconnecting anything. Disconnect the two hose clamps connecting the pump to the tub and drain hose, and unplug the electrical connector from the pump motor. Remove the mounting screws or clips securing the pump assembly and lift it free, checking the impeller area for coins, buttons, or debris while it's out — clearing a clog here may have been the actual cause of the original symptom. Install the new AHA72973309 in the same orientation, reconnect both hoses with their clamps, and reconnect the electrical connector fully. Reinstall the front access panel, restore water and power, and run a short cycle to confirm normal draining, recirculation spray, and no leaks around the pump housing. Tools needed: Phillips screwdriver, hose clamp pliers, shallow pan or towels, work gloves. Frequently Asked Questions Do I really need to tip the washer over to replace this pump? Not necessarily — check your model first. While a lot of general online guidance recommends tipping the washer onto its back to access the pump from underneath, many LG and Kenmore Elite front-load models make this pump fully accessible through the front lower access panel or kick plate instead, without any tipping required. It's worth removing that panel first and seeing what you find before committing to the more involved tip-over approach. Why does this one pump handle both draining and something during the wash cycle? LG's front-load washers use this same Askoll pump for two different jobs at different points in the cycle: pumping wastewater out during the drain step, and recirculating water from the bottom of the tub back up through the dispenser and spray nozzle during wash and rinse to shower it over the load. That recirculation spray is part of how these washers clean effectively while using less water than an older top-load design. Because one pump does both jobs, a failure can affect draining, wash performance, or both, depending on what's actually gone wrong inside it. There's water left in the tub after every cycle. Is this definitely the pump? It's one of the most common causes, but check the easy things first. A clogged drain filter or a kinked drain hose can produce the same "won't drain" symptom and cost nothing to fix. If the filter and hose are clear and water is still standing in the tub, or if the pump hums but doesn't seem to move any water, the pump assembly itself has likely failed. My washer drains fine but clothes aren't coming out as clean. Could this pump be the cause? Possibly. Since this same assembly also handles the recirculation spray during wash, a partial failure can leave draining intact while weakening or eliminating that spray function, which reduces how effectively detergent and water reach the load. If drainage is normal but wash performance has noticeably declined, it's worth having this pump checked as one possible cause alongside things like detergent dosing and water hardness. Is this an OEM or aftermarket part? This is a genuine OEM part, manufactured by LG to factory specifications — guaranteed fit, materials, and performance. It includes the same Askoll M120-2 dual-function pump design, wiring, and mounting configuration as the drain and circulation pump assembly originally installed in your front-load washer. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Genuine OEM Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout

Read more less

Genuine OEM Frigidaire / Electrolux Washer Part 134762010 Washer Genuine OEM Water Level Pressure Switch Monitors air pressure from the washer tub and signals the control system when the correct water level has been reached. Product Overview The Frigidaire 134762010 Washer Water Level Pressure Switch senses changes in air pressure through the washer pressure hose to monitor the amount of water inside the tub. It signals the washer control system when the correct water level has been reached so the appliance can fill, wash, drain, and advance through the cycle correctly. This is a new Genuine OEM Frigidaire / Electrolux replacement part manufactured to the original equipment specifications for proper fit, electrical connection, and operation in compatible washers. Quick Answer 134762010 is a Genuine OEM water-level pressure switch for select Frigidaire, Electrolux, Kenmore, and Crosley front-load washers. It replaces 7134762010. This listing is for the pressure switch only; the pressure hose, clamp, wiring harness, and mounting hardware are not included unless specifically shown. Common Problems This Part May Fix Washer overfills with water Washer does not fill or underfills Incorrect or inconsistent water level Cycle stops or will not advance Washer does not drain or complete the cycle correctly E35 or another water-level-related error on applicable models Replaces and Cross-References 134762010, 1482962, 7134762010, AH2349296, AP4368525, AFR14413, EA2349296, PD00007813, PS2349296. 134762010 is the current manufacturer part number. Other numbers are previous manufacturer or retailer cross-references. Compatibility Designed for select front-load washers manufactured by Electrolux and sold under Frigidaire, Electrolux, Kenmore, and Crosley brand names. Confirmed model examples include: 41741100000 41744130000 EIFLS55IRR0 EIFLS60JIW1 FAFS4473LN0 FAFW3921NW0 FFFW5000QW0 CFW4700LW0 CFW7400QW0 Important: This is a partial compatibility list. Pressure switches can look alike while using different settings, terminals, mounting tabs, or control calibration. Verify the complete washer model number before ordering. Key Features Genuine OEM Frigidaire / Electrolux replacement part Monitors the water level inside the washer tub Signals the control system when the correct fill level is reached Supports proper filling, washing, draining, and cycle operation Snap-tab mounting design on compatible models Designed for original fit and electrical connection Product Specifications Manufacturer Part Number 134762010 Brand Frigidaire / Electrolux Part Type Washer Water Level Pressure Switch Condition New Quality Genuine OEM Application Front-Load Washing Machine Primary Function Senses and controls the washer water level Included One Water Level Pressure Switch Installation Notes Unplug the washer and shut off both water-supply valves. Remove the washer top panel as required for your model. Photograph the wire connector and pressure-hose connection before disconnecting them. Disconnect the electrical connector without pulling on the wires. Release the clamp and carefully remove the pressure hose. Remove the old switch and install the replacement in the same position. Reconnect the hose, clamp, and electrical connector, then reinstall the top panel. Diagnostic tip: Inspect the pressure hose for cracks, pinholes, blockage, moisture, loose connections, or trapped debris. A damaged or obstructed hose can cause the same symptoms as a failed pressure switch. Frequently Asked Questions Is 134762010 a genuine OEM part? Yes. It is a Genuine OEM Frigidaire / Electrolux washer water-level pressure switch. What does the pressure switch do? It monitors air pressure from the washer tub and signals the control system when the correct water level has been reached. Which part number does it replace? It replaces previous manufacturer part number 7134762010. Does this include the pressure hose? No. The listing is for the pressure switch only unless additional components are specifically shown and stated as included. Will it fit every Frigidaire or Electrolux washer? No. Verify the complete appliance model number and required manufacturer part number before purchasing. Shop With Confidence Purchase the correct Genuine OEM replacement part for dependable fit and operation. Verify your washer model number before ordering, and contact our parts team when compatibility assistance is needed. Genuine OEM PartFast U.S. ShippingCompatibility SupportSecure Checkout

Read more less

XPARTCO DC97-20621C Washer Drain Pump Assembly The XPARTCO DC97-20621C is an aftermarket replacement drain pump assembly compatible with a wide range of Samsung front-load washers in the specific series, as well as select Kenmore front-load washers built on the Samsung platform. The drain pump removes water from the washer tub during the drain portion of each wash cycle. When the pump fails, the washer will not drain, leave standing water in the tub, stop mid-cycle, display error codes 5C, SE, nd, 5E, or 4E, or make loud grinding or humming noises during the drain phase. The DC97-20621C is the current production revision of this pump, which also covers the earlier DC97-20621A variants — all three are the same pump in successive production runs. It also replaces DC97-17999N, DC31-00187A, PX3516-01, AP6807020, 4959632, PS12592830, and EAP12592830. Before ordering, always check the drain filter/coin trap at the bottom front of the washer — a clogged filter is a common cause of drain error codes that does not require pump replacement. Installs in 20–30 minutes with basic hand tools. Quick Answer The XPARTCO DC97-20621C Washer Drain Pump Assembly fixes Samsung front-load washers displaying error codes 5C, SE, nd, 5E, or 4E, not draining, leaving standing water, or making loud grinding or humming noises during the drain cycle. Covers DC97-20621A and DC97-20621B variants. Compatible with select Samsung series and Kenmore (Samsung-built). Replaces DC97-20621A, DC97-17999N, DC31-00187A, PX3516-01, AP6807020, 4959632, PS12592830, EAP12592830. Check drain filter before replacing pump. Common Problems This Part Fixes Washer not draining — standing water remaining in the tub after a cycle Error codes 5C, SE, nd, 5E, or 4E displayed — drain fault detected Washer stopping mid-cycle due to a drain fault Loud humming during the drain phase — pump motor running but not pumping Grinding or rattling noise during drain — damaged impeller or worn pump bearings Water draining very slowly — worn pump below rated performance Clothes excessively wet after a cycle — pump not fully removing water before spin Water leaking from the pump area at the front bottom of the washer Replaces Part Numbers This drain pump directly replaces the following OEM and cross-reference part numbers: DC97-17999N, DC97-20621A, 03DC31-00187A, AP7366238, ASM105564, PFIX17701443, PD00095227, PX3516-01, PS17701443, AP6807020, PS12592830. If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This drain pump is compatible with select Samsung front-load washers and related Kenmore models: Samsung series — WF50R8500AW, WF45T6200AW, WF53BB8900 and related models Kenmore / Sears front-load washers (select Samsung-built models) Important: Before replacing the pump, check and clean the drain filter/coin trap located behind the lower access panel at the front of the washer. A clogged filter causes the same error codes as a failed pump and is the most common fixable cause of Samsung front-load drain errors. Always verify your model number before ordering. Key Features Removes water from the tub during drain and spin cycles for proper washer operation Resolves Samsung error codes 5C, SE, nd, 5E, and 4E caused by drain pump failure DC97-20621C is the current production revision — covers DC97-20621A and DC97-20621B as well Also replaces DC97-17999N, DC31-00187A, PX3516-01, AP6807020, 4959632, PS12592830, and EAP12592830 Compatible with select Samsung series and Kenmore Samsung-built front-load washers Aftermarket replacement built to OEM-equivalent quality standards DIY repair — installs in 20–30 minutes with basic hand tools Product Specifications Part Number XPDC97-20621C Also Covers DC97-20621A (prior revisions) Part Type Front-Load Washer Drain Pump Assembly Condition Aftermarket Replacement Application Samsung Front-Load Washers  Error Codes Resolved 5C, SE, nd, 5E, 4E Compatible Brands Samsung, Kenmore (Samsung-built) Installation Notes ⚠️ Unplug Washer and Shut Off Water Before Starting Disconnect power and turn off the water supply before beginning. Place towels on the floor in front of the washer — residual water will drain when the pump is disconnected. The drain pump is accessed through the lower front panel. Remove the lower kick panel screws to expose the drain filter and pump area. First, drain residual water by removing the drain filter cap (have a shallow pan ready — up to a quart of water may flow out). After draining, disconnect the pump wiring harness. Release the hose clamps and disconnect the drain hoses from the pump. Unscrew or unclip the pump mounting hardware and remove the old pump. Install the new DC97-20621C pump in the same position, reconnect drain hoses and secure clamps, reconnect the wiring harness, and reinstall the front panel. Restore power and water and run a drain/spin cycle to confirm drainage and check for leaks. Tools needed: Phillips screwdriver, pliers, shallow pan, towels. Frequently Asked Questions What is the difference between DC97-20621C and DC97-20621A? These are successive production revisions of the same Samsung front-load washer drain pump assembly. DC97-20621A was the original version, DC97-20621B was an intermediate revision, and DC97-20621C is the current production part. All three are the same pump with minor manufacturing changes across production runs — they are fully interchangeable. If your washer's parts diagram or old pump label shows any of these numbers, this replacement covers all of them. What error codes indicate a drain pump failure on Samsung front-load washers? Error codes 5C, SE, nd, 5E, and 4E on Samsung front-load washers all indicate a drain fault — the washer was unable to drain within the expected time. Before replacing the pump, clean the drain filter/coin trap at the front lower access panel — lint, coins, and debris in the filter are among the most common causes of these error codes. If the filter is clean and the errors persist, the pump itself has failed and needs replacement. Where is the drain filter on my Samsung front-load washer? The drain filter (also called the coin trap) on Samsung front-load washers is located behind the lower front access panel, typically on the right side. Remove the lower kick panel by pressing the release tab or removing the screws. You will see a small cap or twist-out cover — that is the filter. Place a shallow pan under it and slowly unscrew the cap to allow water to drain out. Remove any debris from the filter, then replace the cap and reinstall the panel. Run a cycle to check if the error clears. If the filter was clogged, this may be all the repair needed. My washer makes a loud noise during draining — is it the pump? A loud humming or grinding during the drain cycle is a common sign of a failing pump. Humming without water movement means the motor is running but the impeller is not pumping — either jammed by debris or mechanically failed. Grinding suggests worn pump bearings or a damaged impeller. Check the drain filter first for foreign objects. If the filter is clear and the noise persists, the pump needs replacement. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Samsung OEM part, but is manufactured to match the specifications and performance of the original DC97-20621C drain pump assembly. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout

Read more less

XPARTCO W10276397 Washer Drain Pump Replaces WPW10276397 The XPARTCO W10276397 is an aftermarket replacement washer drain pump and motor assembly compatible with a wide range of Whirlpool-family top-load washers including Whirlpool Cabrio, Maytag Centennial, Amana, Kenmore, Roper, Crosley, and Inglis. The drain pump removes water from the washer tub during the drain portion of each wash cycle. When the pump fails, the washer will not drain, will leave standing water in the tub, display error code F9E1, stop mid-cycle, or produce unusual humming or grinding noises during the drain phase. This complete drain pump and motor assembly uses a Hanyu B40-3A motor (also marked 91PS3132) and includes the integrated impeller — the impeller is not sold separately. It directly replaces WPW10276397, W10276397, WPW10276397VP, 1874334, B40-3A, LP397, AP6018417, PS11751719, and several additional cross-reference numbers. Before ordering, confirm that the drain hose and any coin trap or filter are clear — a blocked hose or clogged filter can mimic pump failure symptoms. Installs in 20–30 minutes with basic hand tools. Quick Answer The XPARTCO W10276397 Washer Drain Pump fixes Whirlpool Cabrio and Maytag Centennial top-load washers that won't drain, leave standing water, display error code F9E1, or make humming/grinding noises during the drain cycle. Complete pump and motor assembly with integrated impeller. Motor: Hanyu B40-3A / 91PS3132. Replaces WPW10276397, 1874334, B40-3A, LP397, AP6018417, PS11751719. Compatible with Whirlpool Cabrio, Maytag Centennial/MVWC/MVWX, Amana, Kenmore, Roper, Crosley, and Inglis top-load washers. Common Problems This Part Fixes Washer not draining — standing water remaining in the tub after a cycle Error code F9E1 displayed — drain pump fault or slow drain detected Washer stopping mid-cycle due to a drain fault Loud humming during the drain phase — motor running but impeller not pumping Grinding or rattling noise during drain — physical damage to impeller or pump housing Water draining very slowly — worn pump motor below rated flow Water leaking from the drain pump area Replaces Part Numbers This drain pump directly replaces the following OEM and cross-reference part numbers: WPW10276397, W10276397, 1874334, AWP50231 EAP11751719 FIX11751719, OEM24073670, PD00003595, AP6018417, PS11751719, WPW10276397VP If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This drain pump is compatible with select top-load washers from the following brands and series: Whirlpool top-load washers — Cabrio series (WTW4800, WTW4810, WTW4850, WTW4900, WTW5000, WTW5200, WTW5300, WTW5500, WTW5600, WTW5640, WTW5700 and related models) Maytag top-load washers — Centennial series (MVWC200, MVWC215, MVWC300, MVWC400, MVWC415, MVWC416, MVWC425, MVWC465 and related models) Maytag top-load washers — MVWX series (MVWX500, MVWX550, MVWX600, MVWX700 and related models) Amana top-load washers (ATW, NTW series and related models) Kenmore / Sears top-load washers — 110 series (Whirlpool-built Cabrio-platform models) Roper top-load washers (RTW series) Crosley top-load washers (CAE series) Inglis top-load washers (select models) Note: This pump is for top-load washers only. Always verify your exact model number before ordering. Check and clear the drain hose and any coin trap before replacing the pump — a blocked hose can produce the same symptoms as a failed pump. Key Features Removes water from the tub during the drain and spin cycles for proper washer operation Complete pump and motor assembly — includes integrated impeller (impeller not sold separately) Motor: Hanyu B40-3A / 91PS3132 — matched to original pump specifications Resolves error code F9E1 (drain pump fault / slow drain) on compatible Whirlpool and Maytag top-load washers Replaces WPW10276397, W10276397, 1874334, B40-3A, LP397, and AP6018417 Compatible with Whirlpool Cabrio, Maytag Centennial/MVWX, Amana, Kenmore, Roper, Crosley, and Inglis top-load washers Aftermarket replacement built to OEM-equivalent quality standards DIY repair — installs in 20–30 minutes with basic hand tools Product Specifications Part Number W10276397 OEM Part Number WPW10276397 Part Type Washer Drain Pump and Motor Assembly Condition Aftermarket Replacement Application Top-Load Washers (Cabrio, Centennial, and related platforms) Motor Hanyu B40-3A / 91PS3132 Includes Pump motor and integrated impeller assembly Error Code Resolved F9E1 (drain pump fault / slow drain) Compatible Brands Whirlpool, Maytag, Amana, Kenmore, Roper, Crosley, Inglis Installation Notes ⚠️ Unplug Washer and Shut Off Water Before Starting Disconnect power and turn off the water supply before beginning. Place towels and a shallow pan near the pump access area to catch residual water. The drain pump is located beneath the washer tub on Cabrio and Centennial models — access it by removing the front lower panel or by tilting the washer back and working from underneath. Disconnect the drain hose clamp and hose from the pump, then disconnect the wire harness connector. Unscrew the pump mounting screws and remove the old pump. Before installing the new pump, verify the drain hose and any coin trap or filter are completely clear of debris — a blocked hose or trap will cause the new pump to fail again. Install the new W10276397 pump in the same position, reconnect the hose and wire harness, and secure the mounting screws. Restore power and water and run a drain or spin cycle to confirm drainage and check for leaks. Tools needed: Phillips screwdriver, pliers, shallow pan, towels. Frequently Asked Questions What does error code F9E1 mean on Whirlpool Cabrio and Maytag Centennial washers? F9E1 indicates a drain fault — the washer was unable to drain within the expected time during the cycle. It can be caused by a clogged drain hose, a blocked coin trap or filter, a kinked drain hose, or a failed drain pump motor. Always check and clear the drain hose and filter before replacing the pump — a blockage is often the cause and clearing it resolves the error without needing a new pump. If the hose and filter are clear and the error persists, the pump motor has likely failed. What is the difference between W10276397 and WPW10276397? These are the same drain pump assembly. WPW10276397 is the updated Whirlpool OEM part number that superseded the original W10276397. The 1874334 and B40-3A are also cross-references for this same pump. This aftermarket replacement is compatible with all of these numbers. My washer hums but won't drain — is it the pump? A humming sound during the drain cycle without water being expelled usually means the pump motor is receiving power and running, but the impeller is not turning — either because it is jammed with debris or because the impeller shaft has broken. First check for and remove any foreign objects (coins, lint, small clothing items) from the pump area. If the impeller is clear and the pump still hums without draining, the motor or impeller is mechanically failed and the pump assembly needs replacement. Does this pump fit the Whirlpool Cabrio and Maytag Bravos washers? The W10276397 is compatible with Whirlpool Cabrio and Maytag Centennial top-load washers on the VM transmission platform. Maytag Bravos XL and Bravos X models may also be compatible depending on the specific model number — verify your exact model before ordering. Contact our support team if you need confirmation for a specific Bravos model. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is manufactured with a Hanyu B40-3A motor to match the specifications and performance of the original WPW10276397 drain pump assembly. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout

Read more less

WH11X39237 Genuine OEM GE Washer Drain Pump The WH11X39237 is a Genuine OEM GE replacement drain pump and filter assembly compatible with select GE, GE Profile, and GE 2-in-1 Washer/Dryer Combo front-load washers in the GFW510, GFW550, GFW650, GFW655, GFW850, PFW, and PFQ series. The drain pump is responsible for removing water from the washer drum during the drain and spin cycles — when it fails, the washer will not drain, will leave standing water in the drum, or will produce unusual noises during the drain cycle. This complete drain pump and filter assembly operates at 120V, 60Hz, 1.2A and includes the pump motor, impeller housing, and integrated filter. It directly replaces the discontinued WH11X29539 — WH11X39237 is the current manufacturer-approved updated part number. Also replaces AP6986715, 4962370, B25-3A04, and several additional cross-reference numbers. Installs in 30–45 minutes with basic hand tools. Quick Answer The WH11X39237 Genuine OEM GE Washer Drain Pump fixes GE front-load washers that won't drain, leave standing water in the drum, display drain error codes, or make loud humming or grinding noises during the drain cycle. Complete pump and filter assembly. 120V/60Hz/1.2A. Replaces discontinued WH11X29539. Compatible with GE GFW510, GFW550, GFW650, GFW655, GFW850, PFW, and PFQ series. Common Problems This Part Fixes Washer not draining — standing water remaining in the drum after a cycle Drain error codes displayed on GE front-load washers (e.g. E23, E24, or pump-related codes) Loud humming, grinding, or buzzing noise during the drain cycle Washer stopping mid-cycle due to a drain fault Water leaking from around the drain pump area Drain pump running continuously but water not being expelled Pump impeller jammed by debris and motor burned out Replaces Part Numbers This drain pump directly replaces the following OEM and cross-reference part numbers: WH11X39237, WH11X29539, Hanyu B25-3A04, 9019841, PD00094541, AGE1260100, AP8054992, PS18351790. WH11X39237 is the current manufacturer-approved replacement for the discontinued WH11X29539. If your appliance documentation lists WH11X29539, this is the correct updated part. Compatibility This drain pump is compatible with select front-load washers and laundry combos from the following GE product lines: GE front-load washers — GFW510 series GE front-load washers — GFW550 series GE front-load washers — GFW650 series GE front-load washers — GFW655 series GE front-load washers — GFW850 series GE Profile front-load washers — PFW870, PFW950, PFW955 series GE Profile front-load washers — PFQ83 series GE 2-in-1 Washer/Dryer Combo (select models) Always verify your appliance model number before ordering. Contact our support team if you're unsure. Key Features Complete drain pump and filter assembly — pump motor, impeller housing, and integrated filter all included Removes water from the drum during drain and spin cycles for proper washer operation Integrated filter traps lint, coins, and debris to prevent pump impeller damage and clogs Electrical specs: 120V, 60Hz, 1.2A — correct for compatible GE front-load models WH11X39237 is the current manufacturer-approved replacement for discontinued WH11X29539 Direct replacement — installs into existing pump housing with no modification required Genuine OEM part manufactured by GE to factory specifications — guaranteed fit and performance Compatible with GFW510, GFW550, GFW650, GFW655, GFW850, PFW, and PFQ series DIY-friendly repair — installs in 30–45 minutes with basic hand tools Product Specifications Part Number WH11X39237 Supersedes WH11X29539 (discontinued) Part Type Washer Drain Pump and Filter Assembly Condition Genuine OEM Application GE Front-Load Washers and 2-in-1 Washer/Dryer Combos Voltage 120V AC Frequency 60 Hz Amperage 1.2A Includes Pump motor, impeller housing, and integrated filter Compatible Series GFW510, GFW550, GFW650, GFW655, GFW850, PFW870, PFW950, PFW955, PFQ83 Compatible Brands GE, GE Profile Installation Notes ⚠️ Unplug Washer and Shut Off Water Before Starting Disconnect power and turn off the water supply before beginning any repair. Place towels and a shallow pan under the pump access area to catch residual water. Remove the front lower access panel of the washer. Before removing the pump, first clean the pump filter (WH23X38617) and check for a clogged filter or debris in the pump housing — a jammed impeller is sometimes mistaken for a failed pump. If the pump motor is confirmed failed, disconnect the wire harness and drain hoses from the old pump assembly, then unscrew or unclip the pump from the mounting bracket. Install the new WH11X39237 pump assembly, reconnect the drain hoses and secure with clamps, reconnect the wire harness, and reinstall the access panel. Restore power and water supply, then run a drain-only cycle to verify proper drainage and check for leaks. Tools needed: Phillips screwdriver, pliers, shallow pan or towels. Frequently Asked Questions What is the difference between WH11X39237 and WH11X29539? These are the same drain pump assembly — WH11X39237 is the current updated part number that GE issued to replace the discontinued WH11X29539. If your washer's documentation, parts diagram, or old pump label shows WH11X29539, the WH11X39237 is the correct replacement to order. Should I check the pump filter before replacing the drain pump? Yes — always check and clean the pump filter (WH23X38617) before replacing the drain pump. A heavily clogged filter can restrict water flow enough to mimic pump failure symptoms, and a foreign object jammed in the impeller can stall the pump motor without permanently damaging it. Remove the filter, clear any debris from the housing and impeller, and test the washer again. If the pump still fails to drain after cleaning, then pump replacement is the next step. How do I know if my drain pump has failed? A failed drain pump typically causes the washer to stop mid-cycle with a drain error code, or to finish a cycle with standing water in the drum. You may also hear a loud humming noise during the drain phase — this indicates the motor is running but the impeller is not turning (jammed or broken). A grinding noise suggests physical damage to the impeller or pump housing. If the pump is completely silent during the drain cycle despite power being delivered to it, the motor has likely burned out. Is the WH11X39237 compatible with GE Profile and GE 2-in-1 models? Yes — the WH11X39237 is compatible with select GE Profile front-load washers in the PFW870, PFW950, PFW955, and PFQ83 series, as well as select GE 2-in-1 Washer/Dryer Combo models. Always verify your specific model number before ordering to confirm compatibility. Is this an OEM or aftermarket part? This is a Genuine OEM part manufactured by GE to factory specifications. It is the exact same drain pump and filter assembly installed in compatible GE and GE Profile front-load washers from the factory — guaranteed fit, materials, and performance. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Fast US Shipping ✓ Genuine OEM Parts ✓ Compatibility Support ✓ Secure Checkout

Read more less
