XPARTCO W10730972 Washer Drain Pump Replaces WPW10730972
The XPARTCO W10730972 is an aftermarket replacement front-load washer drain pump and motor assembly compatible with a wide range of Whirlpool, Maytag, Kenmore, Amana, Inglis, and KitchenAid front-load washers — including the Whirlpool Duet, Maytag 2000/3000/4000 series, and Kenmore HE2/HE2T Plus. The drain pump removes water from the washer tub during the drain and spin phases of each wash cycle. When the pump fails, the washer will not drain, will leave standing water in the tub, stop mid-cycle, display error codes F21, F33, or SD, or leak from the pump area.
This complete assembly includes the motor, pump housing, and integrated filter — these components are only available as a complete assembly and are not sold separately. Rated 120V, 60Hz, 78W, 1.2A (CL.F duty class). Assembly dimensions are 8-3/4"L x 7"W x 5-1/4"H in off-white plastic housing. Note: Whirlpool redesigned this pump — the replacement may look different from the original but fits and functions identically. It directly replaces WPW10730972, W10130913, W10130913-B, 8540024, 8540025, 8540027, 8540028, 8540996, W10117829, W10183434, W10190647, W10190648, W10201457, AP6023956, PS11757304, and additional cross-reference numbers. Installs in 20–30 minutes with basic hand tools.
Quick Answer
The XPARTCO W10730972 Washer Drain Pump fixes Whirlpool Duet, Maytag 2000/3000/4000 series, and Kenmore HE2/HE2T Plus front-load washers that won't drain, leave standing water, or display error codes F21, F33, or SD. Complete assembly — motor, pump housing, and filter included. 120V/60Hz/78W/1.2A. 8-3/4"L x 7"W x 5-1/4"H. Note: redesigned — may look different from original but fits identically. Replaces WPW10730972, W10130913, 8540024, 8540996, W10117829, AP6023956, PS11757304.
Common Problems This Part Fixes
Washer not draining — standing water remaining in the tub after a cycle
Error code F21 displayed — long drain fault (washer unable to drain in allotted time)
Error code F33 displayed — pump motor fault
Error code SD displayed — suds detection or drain issue
Washer stopping mid-cycle due to a drain fault
Loud humming or grinding noise during the drain phase
Water leaking from the front lower area of the washer — pump seal failure
Pump motor running but water not being expelled from the tub
Replaces Part Numbers
This drain pump directly replaces the following OEM and cross-reference part numbers:
WPW10730972, W10730972, W10130913, 4281917, 8540024, 8540025, 8540027, 8540028, 8540996, W10117829, W10183434, W10190647, W10190648, W10201457, WPW10730972VP, AP6023956, AWP50633, B40-3A01, EAP11757304, PD00025949, PS11757304
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This drain pump is compatible with select front-load washers from the following brands and series:
Whirlpool front-load washers — Duet series (WFW8300, WFW8400, WFW9050, WFW9150, WFW9200, WFW9250, WFW9400, WFW9450, WFW9500, WFW9550, WFW9600, WFW96HEA, WFW97HED, WFW98HEB and related models)
Maytag front-load washers — 2000 series (MHW2000AW, MHW2000BWW and related models)
Maytag front-load washers — 3000 series (MHW3000BW and related models)
Maytag front-load washers — 4000 series (MHW4000BW, MHW4200BW, MHW5100DW, MHW6000AW, MHW6000XW and related models)
Kenmore / Sears front-load washers — HE2 and HE2T Plus series (110.45862400, 110.47532602 and related models)
Amana front-load washers (select models)
Inglis front-load washers (select models)
KitchenAid front-load washers (select models)
Note: Whirlpool redesigned this pump assembly — the replacement may look different from your original pump (larger in size on some versions) but is engineered to fit and function identically in all compatible models. Always verify your model number before ordering. Before replacing the pump, check and clear the coin trap/drain filter — a clogged filter is a common cause of F21/F33 errors that does not require pump replacement.
Key Features
Removes water from the tub during drain and spin cycles — essential for proper washer operation
Complete assembly — motor, pump housing, and integrated filter included; components are not sold separately
Rated 120V, 60Hz, 78W, 1.2A (CL.F) — correct electrical specifications for compatible Whirlpool-family front-load washers
Dimensions: 8-3/4"L x 7"W x 5-1/4"H — off-white plastic housing
Resolves error codes F21 (long drain), F33 (pump motor fault), and SD (suds/drain) on compatible models
Redesigned assembly — may look different from original but fits and functions identically
Replaces WPW10730972, W10130913, 8540024, 8540996, W10117829, AP6023956, and over 20 additional cross-references
Compatible with Whirlpool Duet, Maytag 2000/3000/4000 series, Kenmore HE2/HE2T Plus, Amana, Inglis, and KitchenAid
Aftermarket replacement built to OEM-equivalent quality standards
DIY repair — installs in 20–30 minutes with basic hand tools
Product Specifications
Part Number
XPW10730972
OEM Part Number
WPW10730972
Part Type
Front-Load Washer Drain Pump and Motor Assembly
Condition
Aftermarket Replacement
Application
Front-Load Washers (Duet, Maytag 2000/3000/4000, Kenmore HE2/HE2T Plus)
Voltage
120V AC
Frequency
60 Hz
Wattage
78W
Amperage
1.2A
Duty Class
CL.F
Dimensions
8-3/4"L x 7"W x 5-1/4"H
Color
Off-White
Material
Plastic housing
Includes
Motor, pump housing, and integrated filter — complete assembly
Design Note
Redesigned — may look different from original; fits identically
Error Codes Resolved
F21 (long drain), F33 (pump motor fault), SD (suds/drain)
Compatible Brands
Whirlpool, Maytag, Kenmore, Amana, Inglis, KitchenAid
Installation Notes
⚠️ Unplug Washer and Shut Off Water Before Starting — Work Gloves Recommended Disconnect power and turn off the water supply before beginning. Place towels on the floor — residual water will drain when the pump is disconnected. The drain pump is accessed through the lower front panel of the washer. Remove the screws on the lower kick panel or snap panel to expose the pump access area. Before removing the pump, drain residual water by removing the coin trap/filter cap from the filter housing (have a shallow pan ready — up to a quart of water may flow out). After draining, disconnect the pump wiring harness. Release the drain hose clamps and disconnect the hoses from the pump. Unscrew or unclip the pump mounting hardware and remove the old pump. Transfer the hoses and wiring to the new W10730972 pump, secure the mounting hardware, and reinstall the front panel. Restore power and water, run a drain/spin cycle, and check for leaks. Tools needed: Phillips screwdriver, Torx screwdriver (T20 on some models), pliers, shallow pan, towels, work gloves.
Frequently Asked Questions
What do error codes F21, F33, and SD mean on Whirlpool Duet and Maytag washers?
F21 indicates a long drain fault — the washer was unable to drain within the expected time (typically 8 minutes). F33 indicates a pump motor fault — the control board is not detecting the pump motor operating correctly. SD is a suds detection code that can also appear when drain issues prevent the suds from clearing properly. All three codes point toward the drain pump or a drain obstruction. Before replacing the pump, check and clean the coin trap filter — a clogged filter is one of the most common causes of F21 errors and clearing it often resolves the code without needing a new pump.
Should I check the coin trap filter before replacing the pump?
Yes — always check the coin trap filter before replacing the pump. On Whirlpool Duet and Maytag front-load washers, the coin trap filter is located inside the lower front access panel, typically behind a small cap or cover. Removing the cap and clearing lint, coins, and debris from the filter restores drain flow and clears F21/F33 errors in many cases without any part replacement needed. If the filter is clear and the pump still humbles or fails to drain, the pump needs replacement.
Why does the replacement pump look different from the original?
Whirlpool redesigned this drain pump assembly during its production lifecycle — the WPW10730972 replacement is physically larger than some of the older 8540024-series pumps it supersedes. Despite looking different, the redesigned pump uses the same hose and electrical connection points and is a direct fit in all compatible models. The larger housing is an intentional design improvement to increase pumping capacity. If the pump looks bigger than what you removed, this is normal and expected — install it in the same way as the original.
What is the difference between W10730972 and WPW10730972?
These are the same drain pump assembly. WPW10730972 is the updated Whirlpool OEM part number that superseded the original W10730972. The W10130913 and 8540024 are also cross-references for earlier versions of this same pump. This aftermarket replacement is compatible with all of these numbers.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is manufactured to match the electrical specifications and performance of the original WPW10730972 drain pump assembly.
