Genuine OEM Dryer Part
W11683629 Dryer Genuine OEM Thermistor
A manufacturer-approved temperature-sensing component designed to help the dryer control system regulate heat and drying performance.
Product Description
The W11683629 Dryer Genuine OEM Thermistor monitors air temperature inside the dryer and sends temperature information to the electronic control system. The control uses this signal to cycle the heat source and maintain the correct operating temperature during the drying cycle.
This is a Genuine OEM replacement part manufactured to the original equipment specifications for fit, electrical response, and dependable operation. Replacing a failed thermistor can help restore accurate temperature control, normal cycle times, and consistent drying results.
Quick Answer
W11683629 is a Genuine OEM dryer thermistor. It senses dryer air temperature and communicates with the control board so the appliance can regulate heating. Replace it when testing or diagnosis confirms an open, shorted, damaged, or inaccurate temperature sensor.
Common Problems This Part Fixes
Dryer overheats or runs hotter than normal
Clothes remain damp after a complete cycle
Drying cycles take too long
Heat cycles on and off incorrectly
Dryer stops before clothes are dry
Temperature-sensor or heating-related error codes
Replaces Part Number
The product title identifies the following part number:
W11683629, W11452857, AP7216892, AWP1400864, PS17216463.
No additional replacement or cross-reference number was included in the supplied product title.
Compatibility
Designed for select dryer models that specify Genuine OEM part number W11683629. Appliance parts can look similar while using different resistance ranges, connectors, mounting positions, or control logic.
Always verify the complete dryer model number and the required part number before ordering. The model-number label is commonly located around the door opening, on the cabinet frame, or on the rear identification plate.
Key Features
Genuine OEM manufacturer-approved component
Monitors dryer operating temperature
Sends temperature feedback to the control system
Helps regulate heating and cycle performance
Built to original fit and electrical specifications
Direct replacement when W11683629 is specified
Product Specifications
Part Number
W11683629
Part Type
Dryer Thermistor / Temperature Sensor
Condition
New
Quality
Genuine OEM
Application
Clothes Dryer
Primary Function
Measures air temperature for the dryer control system
Package Quantity
1 Thermistor
Troubleshooting Guide
Disconnect the dryer from electrical power before opening or servicing the cabinet.
Inspect the exhaust vent, lint path, and blower area. Restricted airflow can produce symptoms similar to a failed thermistor.
Inspect the thermistor body, terminals, connector, and wire harness for damage, corrosion, loose connections, or heat discoloration.
Disconnect the thermistor and test resistance with a multimeter. Compare the reading with the dryer service information for the measured temperature.
Warm or cool the sensor carefully. Resistance should change smoothly as temperature changes; an open circuit, short circuit, or unstable reading can indicate failure.
Check the heater circuit, thermal devices, moisture-sensing system, and control board when the thermistor tests within specification.
Safety: Do not bypass a thermistor or protective temperature device. Installation and diagnosis should be performed by a qualified person when you are not comfortable servicing electrical appliances.
When Should You Replace This Part?
The thermistor is open, shorted, or outside the specified resistance range
The sensor reading does not change correctly with temperature
The housing or connector is cracked, burned, or physically damaged
A service diagnostic identifies W11683629 as the failed component
Airflow and related heating components have been checked and the thermistor fails testing
Shop With Confidence
Purchase the correct Genuine OEM replacement part for dependable fit and performance. Verify your dryer model number before ordering, and contact our parts team when compatibility assistance is needed.
Genuine OEM Fast U.S. Shipping Compatibility Support Secure Checkout
XPARTCO WE03X32037 Dryer Drum Belt Replaces WE12M24
The XPARTCO WE03X32037 is an aftermarket replacement drum drive belt for GE, Hotpoint, and RCA portable, compact, and unitized stack dryers. The belt is a long, slender loop that wraps all the way around the outside of the drum, passes around the idler tension pulley, and finishes around the small drive motor pulley. That belt is the only mechanical link between the motor and the drum — there are no gears and no direct coupling — so when it breaks, the dryer behaves in a very specific way: the console lights up, the motor runs, the blower moves air, and the drum simply sits there. Open the door and spin the drum by hand and it coasts freely with no resistance at all.
This belt measures approximately 79 inches long and about 1/4 inch wide, with a 4-rib multi-groove profile molded into the inner face. The 79" length is the defining specification here — GE uses several visually similar 4-rib dryer belts across its lineup, and the difference between them is length. Belts fail from heat and age: the rubber hardens, the ribs glaze and begin slipping under a heavy wet load, and eventually the belt cracks through or snaps. Fraying edges, a squeal at startup, a rhythmic thump timed to drum rotation, or black rubber dust in the bottom of the cabinet all point to a belt nearing the end of its life. It directly replaces WE12M24, WE12M9, WE12X79, WE12X0079, AP3418890, AP7186820, PS755943, and related numbers. Installs in 45–90 minutes with basic hand tools.
Quick Answer
The XPARTCO WE03X32037 Dryer Drum Belt fixes GE, Hotpoint, and RCA portable, compact, and stack dryers where the motor runs but the drum won't turn, the drum spins freely by hand, or the dryer squeals, thumps, or rumbles during a cycle. Approximately 79" long, 1/4" wide, 4 ribs, black rubber. Fits DDP1370/DDP1375/DDP1380 portable and DSKP333/DSKS333/DSKS433 stack models. Replaces WE12M24, WE12M9, WE12X79, WE12X0079, AP3418890, AP7186820, PS755943. Not the same belt as the 89-1/2" full-size GE WE12M29 — length is what separates them.
Common Problems This Part Fixes
Dryer runs and hums but the drum does not turn — the classic broken belt symptom
Drum spins freely by hand with no resistance when the door is open
Loud squealing or screeching that begins as soon as the cycle starts
Rhythmic thumping or slapping noise timed to drum rotation — cracked or split belt
Grinding or rumbling from inside the cabinet as a frayed belt drags
Drum turns slowly, intermittently, or stalls under a heavy wet load — glazed belt slipping
Clothes not drying because the drum isn't tumbling to expose them to airflow
Black rubber dust or belt fragments in the bottom of the cabinet
Visible cracking, fraying, glazing, or stretching on the old belt
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This dryer drum belt directly replaces the following OEM and cross-reference part numbers:
WE03X32037, WE12M24, WE12M9, WE12X79, WE12X0079, AP3418890, AP7186820, PS755943, PS16729246, EAP16729246, AH755943, EA755943, 943874, AGE25647, PD00074729
WE03X32037 is the current GE part number; WE12M24 is the long-running legacy number that most service diagrams and older belts still carry. If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This drum belt is compatible with select portable, compact, and unitized stack dryers from the following brands:
GE portable and compact electric dryers — DDP1370, DDP1375, and DDP1380 series
GE unitized stack and Spacemaker laundry centers — DSKP333, DSKS333, and DSKS433 series
Hotpoint compact and stack dryers (select GE-built models)
RCA compact and stack dryers (select GE-built models)
Select Kenmore compact dryers built on the GE platform
Verified model numbers include: DDP1370GAM, DDP1370SAM, DDP1370SBM, DDP1375GAM, DDP1375GBM, DDP1375GCM, DDP1375GDM, DDP1375GEM, DDP1375SAM, DDP1375SBM, DDP1380GAM, DDP1380GBM, DDP1380GCM, DDP1380GDM, DDP1380GFM, DDP1380SAM, DDP1380SBM, DDP1380SCM, DDP1380SDM, DDP1380TAM, DSKP333EC0WH, DSKP333EC0WW, DSKP333EC2WW, DSKP333EC3WW, DSKP333EC4WW, DSKP333EC5WW, DSKP333EC6WW, DSKS333EC0WH, DSKS333EC0WW, DSKS333EC2WW, DSKS333EC3WW, DSKS333EC4WW, DSKS333EC5WW, DSKS333EC6WW, DSKS433EA0AA, DSKS433EB3WW, DSKS433EB5WW, DSKS433EB6WW, and DSKS433EB7WW.
Note — 79" portable/compact belt only: GE uses several visually identical 4-rib dryer belts that differ only in length, and they are NOT interchangeable. This belt is approximately 79 inches, for portable, compact, and stack units. It is NOT the WE12M29 / WE03X29897 belt (89-1/2") used on full-size GE dryers, NOT the WE12X10009 belt (87"), and NOT the WE12X10014 / WE12X42 belt (87-13/16"). Fitting a longer belt leaves slack the idler cannot take up, and the belt will slip or walk off the pulley within minutes. Measure your old belt end to end, or verify your full model number, before ordering. Contact our support team with your model number if you're unsure.
Key Features
Aftermarket replacement drum drive belt — transfers motor rotation to the dryer drum
Approximately 79" long, the correct length for GE portable, compact, and unitized stack dryers
4-rib multi-groove profile molded into the inner face for positive grip on the motor pulley
1/4" width matched to the original belt track and idler pulley
Durable black rubber construction that resists heat hardening and cracking
Resolves "motor runs but drum won't turn," "squealing," "thumping," and "drum spins freely by hand" symptoms
Multi-rib design prevents slipping under heavy wet loads where a worn belt would stall
Direct drop-in replacement — no cutting, splicing, or modification required
Replaces WE12M24, WE12M9, WE12X79, WE12X0079, AP3418890, AP7186820, PS755943, AH755943, EA755943, and 943874
Compatible with GE, Hotpoint, RCA, and select Kenmore compact and stack dryers
Aftermarket replacement built to OEM-equivalent quality standards
Straightforward DIY repair — installs in 45–90 minutes with basic hand tools
Product Specifications
Part Number
XPWE03X32037
OEM Part Number
WE03X32037 (formerly WE12M24)
Part Type
Dryer Drum Drive Belt
Condition
Aftermarket Replacement
Application
GE Portable, Compact, and Unitized Stack Dryers
Length
Approx. 79 in.
Width
1/4 in.
Ribs
4 ribs / 3 grooves
Material
Rubber
Color
Black
Rib Orientation
Ribbed side faces the drum
Routing
Around drum → idler tension pulley → drive motor pulley
Fuel Type
Electric and gas dryers
Quantity
1 belt
Compatible Brands
GE, Hotpoint, RCA, select Kenmore
Installation Notes
⚠️ Unplug Dryer Before Starting — Photograph Belt Routing First Disconnect power at the outlet or shut off the circuit breaker before beginning. On a gas model, also close the gas shutoff valve before moving the cabinet. Wear work gloves — the sheet metal edges inside the cabinet are sharp. Before removing anything, photograph how the old belt routes around the drum, around the idler tension pulley, and around the motor pulley. If the belt is already broken and the routing isn't visible, note that the ribbed side of the belt faces toward the drum, with the smooth back riding against the idler pulley. Access on these compact and stack units is generally from the front: remove the top panel, then the control panel and front panel, which frees the drum enough to lift or tilt it forward. Vacuum out accumulated lint while the cabinet is open — restricted airflow and lint packed around the motor are what cook belts prematurely. Slip the new belt around the drum roughly one-third of the way back from the front lip, ribbed side against the drum, and seat it in the polished wear track the old belt left behind. Reach underneath, route the belt around the idler pulley, then loop it around the small motor pulley. Useful trick: tape the belt loosely to the drum with a strip of masking tape before you reach underneath, so it can't slide off while you work the idler into position. Many GE idler arms have a locked or pre-loaded position — if yours does, remember to release it after the belt is seated, or the belt will have no tension and the drum will stall under load. Once routed, rotate the drum several full turns by hand and confirm the belt tracks straight and stays centered without walking toward an edge. While you're in there, spin the idler pulley and each drum roller by hand; if any is noisy, gritty, or has side-to-side play, replace it now, because a seized idler or flat-spotted roller will destroy the new belt quickly. Reassemble, restore power, and run a short empty cycle listening for squeal or thump before loading it. Tools needed: Phillips screwdriver, nut driver or socket set, putty knife, masking tape, flashlight, work gloves.
Frequently Asked Questions
How do I confirm the belt is broken and not the motor?
With the dryer unplugged, open the door and try to spin the drum by hand. An intact belt gives firm resistance, because you're turning the motor and idler through the belt. If the drum coasts freely like a bicycle wheel, the belt is broken or has jumped off its pulleys. Sound is the other tell: with a broken belt the motor hums and the blower whooshes normally, so the dryer sounds like it's running perfectly while the drum sits still. A failed motor usually buzzes and does nothing, or trips the breaker outright.
What's the difference between WE03X32037 and WE12M24?
They are the same belt across production revisions. WE12M24 was the long-running legacy GE number and WE03X32037 is the current number that supersedes it. If your dryer's parts diagram or the old belt itself shows WE12M24, WE12M9, WE12X79, or WE12X0079, this listing is the correct replacement. The remaining cross-references (AP3418890, AP7186820, PS755943, AH755943, EA755943, 943874) are catalog identifiers used by various parts distributors for the same belt.
Can I use a longer GE belt if this one is out of stock?
No. GE's 4-rib dryer belts look nearly identical and differ mainly in length, which is precisely why they get substituted by mistake. This belt is about 79"; the full-size GE belt WE12M29 is 89-1/2", and WE12X10009 and WE12X10014 are around 87". On a compact or portable drum, that extra 8 to 10 inches is far more slack than the idler arm can absorb, so the belt runs loose, slips on the motor pulley, and typically walks off within minutes. If you're unsure, lay your old belt flat in a loop and measure its circumference before ordering.
Which way do the ribs face?
On this GE platform the ribbed side faces toward the drum, so the ribs grip the drum surface while the smooth back of the belt rides against the idler pulley. This is worth stating plainly because rib orientation is not universal across manufacturers — some other platforms run the grooves against the motor pulley instead. Whenever possible, photograph the old belt before removing it. The polished wear track on the drum will also show you exactly where the belt is meant to sit.
The dryer squeals but the drum still turns. Belt or something else?
Could be either, and it's worth diagnosing before you order. A glazed or hardening belt squeals as it slips on the motor pulley, usually loudest at startup and under a heavy wet load. But a dry idler pulley bearing makes a very similar squeal, and worn drum rollers add a low rumble underneath. With the cabinet open, spin the idler and each roller by hand — they should turn smoothly and silently. If they're gritty, noisy, or have play, replace them along with the belt, since they share the same teardown and you'd otherwise be opening the dryer twice.
Why did my belt fail in the first place?
Usually heat and age — rubber hardens over years of thermal cycling until it cracks. Two things accelerate it sharply. Restricted airflow from a lint-clogged vent makes the whole cabinet run far hotter than designed, which cooks the belt. And a seized idler pulley or a flat-spotted drum roller forces the belt to drag against a stationary surface, shredding it in short order. If your belt failed unusually early, clean the vent ducting end to end and inspect the idler and rollers rather than assuming the new belt will simply last longer.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine GE OEM part, but is manufactured to match the dimensions (approximately 79" length, 1/4" width), 4-rib profile, rubber construction, and drum-drive function of the original WE03X32037 / WE12M24 belt used in compatible GE, Hotpoint, RCA, and related portable, compact, and unitized stack dryers.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Quality Aftermarket Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
(2 Pack) EXP570 Dryer Door Latch Kit
Product Overview
This Door Catch and Strike Kit is a replacement part for specific Maytag, Kenmore, LG, Frigidaire, GE, Amana, Whirlpool dryer models. It includes the door catch and strike. This kit ensures the dryer door remains securely closed during operation, preventing heat loss and ensuring the appliance functions efficiently. Common causes of a bad door catch include regular wear and tear, physical damage, or misalignment of the door, which can impact the catch's ability to latch properly
Replaces Part Numbers
5366021400, 5303207102, AP2153772, PS475419, AP2137890, PS455020, LA-1003, LA1003, PS2162263, AP4242465, WE1M1011, WE1X1192, WE1M536, WE1X1195, WE01X1158, WE01X10023, WE01X10188, WE01X10184, AP5324728, PS3502777, AP2042206, PS266893, AP5324728, PS3502777, AP2042209, PS266896, AP2042175, PS266861, AP2042031, PS264343, AP3775568, PS959860, AP5238145, PS959856, WE1X1194, PS266895, AP2042208, WE1M1011, WE1X1192, WE1M536, WE1X1195, WE01X1158, WE01X10023, WE01X10188, WE01X10184, AP5324728, PS3502777, AP2042206, PS266893, AP5324728, PS3502777, AP2042209, PS266896, AP2042175, PS266861, AP2042031, PS264343, AP3775568, PS959860, AP5238145, PS959856, 4027EL2001A, 4026EL3001A, PS3522845, AP5238145, AP5242421, PS3522822, 00491624, AP3735937, PS959856, 5366021400, 5303207102, AP2153772, PS475419, AP2137890, PS455020, 279570.
Fixes the Following Issues
Dryer door doesn’t stay closed
Dryer won’t start due to an open-door error
Door pops open mid-cycle
Worn or broken latch mechanism
Compatible Brands
This latch kit is compatible with dryers manufactured by Whirlpool, Kenmore (Whirlpool-built), Maytag, Amana, Roper, Estate, Frigidaire, GE, Hotpoint, Inglis and many more, covering a broad range of top-loading and front-loading residential models.
Why Buy from Parts-O-Matic
High-quality aftermarket performance
Always Fast and Free U.S. shipping
Trusted by appliance repair techs and DIYers
Easy returns and responsive customer service
XPARTCO 3390719 Dryer Thermal Fuse – Replaces WP3390719 – Compatible with Whirlpool, Maytag & Kenmore Dryers
Product Description
Restore safe dryer operation and proper heating with the XPARTCO 3390719 Dryer Thermal Fuse. This dryer Thermal Fuse is a replacement part for specific Whirlpool, Kenmore dryer models. This disposable, one-time fuse ensures safe operation of your appliance by cutting off power if the temperature exceeds safe limits. A bad thermal fuse can cause your appliance to stop functioning or prevent it from turning on altogether. Symptoms of a bad thermal fuse include no heat or a dryer that won't start. It is located on the blower housing and cannot be reset.
XPARTCO is a trusted aftermarket brand offering appliance replacement parts built to OEM-equivalent specifications at a cost-effective price.
Replaces Part Numbers
WP3390719, 3390719, 15-198, 279650, 3389639, 3389640, 660877, 688841, 690198, 690798, 80004, ET402, G4AP0401, PD00002330, EAP11741444, AP6008309, PS11741444.
Compatibility
This replacement dryer thermal fuse fits select Whirlpool, Maytag, Kenmore, Amana, Estate, Roper, and Crosley dryers.
Commonly installed on the blower housing or exhaust duct, depending on model.
Always verify your dryer’s model number before ordering.Contact our support team if you’re unsure.
✅ Key Features
🔄 Aftermarket Replacement – Matches OEM safety and temperature ratings
🛡️ Overheat Protection – Shuts off power if unsafe temperatures are detected
🔥 Fixes No-Heat or No-Run Issues – Common solution for blown fuse symptoms
🧩 Direct-Fit Design – Installs easily without modification
💰 Cost-Effective Repair – Reliable alternative to OEM thermal fuses
📐 Product Specification
Part Number: 3390719
Component Type: Dryer Thermal Fuse
Function: One-time over-temperature safety cutoff
Application: Blower housing or exhaust system
Mounting: Screw-mounted
Quality Level: Aftermarket replacement (not OEM)
🛠️ Installation Notes
Tools Needed: Phillips screwdriver, nut driver
⚠️ Safety First: Unplug the dryer before servicing to avoid electrical shock.
Basic Steps:
Disconnect dryer power.
Remove the rear or front access panel (model dependent).
Locate the thermal fuse on the blower housing or exhaust duct.
Disconnect wires and remove the old fuse.
Install the new XPARTCO 3390719 thermal fuse.
Reconnect wiring, reassemble panels, and restore power.
Test dryer operation.
⏱️ Time Required: 15–20 minutes
📦 Shop With Confidence
🚚 Free Shipping on All Orders
⚙️ Trusted Aftermarket Appliance Parts
🔄 30-Day Return Policy
Restore dryer safety and reliable operation — Add to Cart Now for a dependable, budget-friendly repair!
5301EL1001J Dryer Genuine Heating Element
Fits Specific LG Dryer Models.
240V, 5400W complete assembly with housing and thermostats
Replaces Part Numbers: 5301EL1001J, 5301EL1001A, 1377645, AEG72910307, AH3527791, AP4439759, EA3527791, PS3527791, 5301EL1001H, 1377645, 5301EL1001E, 5301EL1001G, 5301EL1001S, 5301EL1001U, 5301EL1001W, AH3527790, AP5072170, EA3527790, PS3527790, AEG72910301, AP5669354, AEG72910309, AP7211081.
Description: This Heater Assembly is a Genuine OEM part for specific LG dryer models. This component is responsible for generating the heat required to dry clothes effectively. It consists of a heating element and necessary components that work together to maintain the desired drying temperature, ensuring clothes come out dry and ready to wear. Causes of a bad heater assembly can include wear and tear from regular use, overheating, electrical issues, or damage to the heating element itself. A malfunctioning heater assembly can lead to inefficient drying or no heat at all.
California Residents only
WARNING: Cancer and/or Reproductive Harm - www.p65warnings.ca.go
XPARTCO 17438200000160 Gas Dryer Flame Switch
The XPARTCO 17438200000160 is an aftermarket replacement gas dryer flame switch compatible with select Midea, Insignia gas dryers, including the MLG45N1BWW, MLG45N3BMG, MLG45N3BWW, MLG52S7AWW, CDG41N1AW/CDG45N1AW series, NSDRE67WH8A, NSFDRG67WH8A, NSDRE67WH8AC, NSTDRG75W1. The flame switch is a safety component mounted on the burner assembly that confirms a flame is actually present after the gas valve opens and the igniter lights the burner. If the switch does not detect a flame within the expected window, it signals the control board to shut off the gas valve, preventing unburned gas from continuing to flow into the dryer cabinet.
When the flame switch fails, the dryer may not heat at all, may shut off the burner shortly after ignition (short-cycling the flame), may trip a no-heat fault code on models with digital displays, or — in rarer failure modes — may fail to shut off gas flow appropriately, which is a safety-relevant failure. It directly replaces 17438200000160 (Midea OEM). Installs in 30–45 minutes with basic hand tools.
Quick Answer
The XPARTCO 17438200000160 Gas Dryer Flame Switch fixes Midea gas dryers that won't heat, where the burner lights and then shuts off shortly after ignition, or where a no-heat fault is displayed. Mounted on the burner assembly — confirms flame presence after ignition and signals the control board to keep the gas valve open. Genuine Midea OEM part number. Compatible with Midea MLG45N1BWW, MLG45N3BMG, MLG45N3BWW, MLG52S7AWW, CDG41N1AW, and CDG45N1AW gas dryers.
Common Problems This Part Fixes
Gas dryer not heating — flame switch not confirming flame presence to the control board
Burner lights briefly and then shuts off — flame switch failing to maintain the "flame confirmed" signal
No-heat fault code displayed on models with digital control panels
Dryer runs and tumbles normally but produces no heat
Burner repeatedly cycling on and off rapidly during a heat cycle
Visible damage, corrosion, or carbon buildup on the flame switch near the burner
Replaces Part Numbers
This flame switch directly replaces the following part number:
17438200000160, AP7153000, PS18188577.
This is the Midea, Insignia manufacturer part number used across multiple Midea gas dryer models. Contact our support team with your model number if you need confirmation before ordering.
Compatibility
This flame switch is compatible with select Midea, Insignia gas dryers, including:
Midea MLG45N1BWW gas dryer
Midea MLG45N3BMG gas dryer
Midea MLG45N3BWW gas dryer
Midea MLG52S7AWW gas dryer (8.0 cu. ft. front load)
Midea CDG41N1AW gas dryer (Criterion, air vent)
Midea CDG45N1AW gas dryer (Criterion, air vent)
Always verify your appliance model number before ordering. Contact our support team if you're unsure.
Key Features
Confirms flame presence at the burner after ignition and signals the control board accordingly
Safety component — helps ensure the gas valve closes promptly if a flame is not detected
Mounts directly to the burner assembly in the same position as the original switch
Genuine Midea manufacturer part number — designed as a direct fit for compatible models
Compatible with Midea MLG45N1BWW, MLG45N3BMG, MLG45N3BWW, MLG52S7AWW, CDG41N1AW, and CDG45N1AW gas dryers
Installs in 30–45 minutes with basic hand tools
Product Specifications
Part Number
XP17438200000160
Part Type
Gas Dryer Flame Switch
Condition
Aftermarket Replacement
Application
Gas Dryers (Midea platform)
Location
Mounted on the burner assembly
Compatible Brands
Midea
Installation Notes
⚠️ Gas Appliance Safety Warning This part is installed in a gas dryer. Always unplug the dryer and shut off the gas supply at the shutoff valve before beginning any repair. If you smell gas at any point during or after installation, leave the area immediately and contact your gas utility provider. Do not restore power or gas until the repair is fully complete and all connections are confirmed secure. If you are not comfortable working on gas appliances or safety-relevant flame-detection components, have this part installed by a qualified technician.
⚠️ Wear Work Gloves — Access Requires Cabinet Disassembly Disconnect power and shut off gas before beginning. Wear work gloves throughout — there are sharp metal edges inside the dryer cabinet. Remove the lint filter and the screws securing the lint filter housing. Release the top panel locking clips with a putty knife and lift the top panel. Disconnect the door switch harness and remove the front panel to access the drum and burner assembly. Locate the flame switch mounted on the burner assembly — it is positioned to detect the flame produced once the igniter lights the gas. Photograph the wire connections before disconnecting. Disconnect the wires from the old flame switch, remove the mounting screw, and pull the switch free. Install the new 17438200000160 flame switch in the same position, secure the mounting screw, and reconnect the wires. Reassemble the front panel, drum, and top panel in reverse order. Restore gas and power, and run a test heat cycle to confirm the burner ignites and stays lit normally. Tools needed: Phillips screwdriver, putty knife, work gloves.
Frequently Asked Questions
What does the flame switch do, and how is it different from an igniter?
The igniter is the component that heats up and ignites the gas at the burner. The flame switch is a separate safety component that confirms a flame is actually present after the igniter has done its job and the gas valve has opened. If the flame switch does not detect the expected flame condition, it signals the control system to close the gas valve, stopping gas flow. This two-part system — ignition plus flame confirmation — is a standard safety design in gas dryers and gas appliances generally, ensuring gas does not continue flowing if combustion isn't actually occurring.
My burner lights and then shuts off after a few seconds — is this the flame switch?
Yes, this is a common symptom of a failing flame switch. If the switch is not reliably maintaining its "flame detected" signal to the control board even though the burner is genuinely lit, the system may interpret this as a flame failure and shut the gas valve as a safety precaution — causing the burner to repeatedly light and then extinguish. This short-cycling pattern during what should be a continuous heat cycle is a strong indicator that the flame switch needs replacement.
Why is this called a "flame switch" rather than a "flame sensor"?
Different manufacturers use different terminology for similar flame-detection safety components. On Whirlpool-family gas dryers, this type of part is typically called a "flame sensor" — a bimetal-style sensor near the igniter that closes a circuit when it senses sufficient heat. Midea's parts catalog labels this specific component the "flame switch," and it serves an analogous safety role within the Midea gas burner system: confirming the presence of a flame after ignition. The terminology differs by manufacturer, but the safety function is similar in concept.
Why does this repair require opening the whole dryer cabinet?
On Midea gas dryers, the flame switch is mounted directly on the burner assembly inside the dryer cabinet, which is only accessible after removing the lint filter housing, releasing the top panel, and removing the front panel. This is a more involved repair than swapping an externally accessible part, but it follows the same general gas dryer disassembly procedure used for replacing igniters, thermal fuses, and other burner-area components. Since the cabinet must be opened, it can be a good opportunity to inspect other burner components (igniter, gas valve coils) for wear at the same time.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is manufactured to match the dimensions, mounting configuration, and function of the original 17438200000160 Midea flame switch.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout
XPARTCO 3977394 Dryer Thermal Cut-Off Kit – Compatible with Whirlpool, Kenmore, Maytag, and KitchenAid Dryers
Product Description
Protect your dryer from overheating with the XPARTCO 3977394 Dryer Thermal Cut-Off Kit. This high-quality aftermarket replacement shuts off the heating element if the dryer temperature rises above safe operating limits. A failed cut-off can cause no-heat issues or overheating during drying cycles. Installing this reliable XPARTCO 3977394 kit restores safe temperature control and helps prevent damage to internal components.
Replaces Part Numbers
XPTC352, 3977394, 352F, EXPTC352
Compatibility
This replacement thermal cut-off kit fits select Whirlpool, Kenmore, Maytag, Roper, Estate, Crosley, and KitchenAid dryers.
Example compatible models include (but are not limited to): Whirlpool WED4815EW1, Kenmore 110.86573110, and Maytag MEDC215EW1.
Always verify your dryer’s model number before ordering. Contact our support team if you’re unsure.
✅ Key Features
🔄 Aftermarket Replacement – Matches OEM safety and temperature performance
🔥 Overheat Protection – Automatically shuts off power to the heating element if the dryer overheats
💰 Cost-Effective Fix – Affordable alternative to OEM thermal cut-off kits
🛠️ Easy Installation – Direct-fit design with included thermostats and connectors
🛡️ Fixes Common Issues – Solves dryer not heating, overheating, or shutting off prematurely
📐 Product Specification
Part Number: 3977394
Component Type: Dryer Thermal Cut-Off Kit
Includes: Thermal cut-off, high-limit thermostat, mounting hardware, and wire connectors
Temperature Rating: Cut-off opens at ~352°F.
Material: Metal thermostat housing and heat-resistant components
Compliance: Built to OEM-equivalent quality standards (not OEM)
🛠️ Installation Notes
Tools Needed: Nut driver, Phillips screwdriver
⚠️ Safety First: Always unplug the dryer before performing any repairs to prevent electrical shock.
Steps:
Disconnect power and remove the rear dryer panel.
Locate the heating element housing and identify the cut-off and thermostat.
Disconnect wires and remove the old components.
Install the new 3977394 cut-off and thermostat in the same locations.
Reconnect wires, reassemble the back panel, and restore power.
Run a short test cycle to verify proper heating.
⏱️ Time Required: 15–25 minutes
📦 Shop With Confidence
🚚 Free Shipping on All Orders
⚙️ Trusted Appliance Parts Supplier
🔄 30-Day Return Policy
Keep your dryer safe and efficient — Add to Cart Now for a reliable, budget-friendly repair!
XPARTCO W10849499 Dryer Drum Belt
The XPARTCO W10849499 is an aftermarket replacement drum belt for Whirlpool's large-capacity dryer platform. The belt wraps all the way around the outside of the drum, passes around the idler tension pulley, and loops around the drive motor pulley — that belt is the only mechanical connection between the motor and the drum, so when it breaks, the console still lights up, the motor still hums, and the blower still moves air, but the drum sits completely still. Open the door and spin the drum by hand and it will turn freely with no resistance.
This belt measures approximately 97.75 inches long. Belts fail from age and heat: the rubber hardens over years of thermal cycling, the ribs glaze over and begin slipping under a heavy wet load, and eventually the belt cracks through or snaps outright. A worn or seized idler pulley is also a common root cause of premature belt failure, since a pulley that won't turn freely forces the belt to drag continuously against a stationary surface until it shreds. Squealing or chirping at startup, a rhythmic thump timed to drum rotation, fraying at the edges, or black rubber dust in the cabinet are all signs a belt is near the end of its life. As an aftermarket replacement, the W10849499 is built to OEM-equivalent quality standards. It directly replaces AP5989682, 4383705, PS11731121, and W10610882.
Quick Answer
The XPARTCO W10849499 Dryer Drum Belt fixes Whirlpool large-capacity dryers where the motor runs but the drum won't turn, the drum spins freely by hand, or the dryer squeals, chirps, or thumps during operation. Approximately 97.75" long. Replaces AP5989682, 4383705, PS11731121, W10610882. If your belt broke due to a worn idler pulley rather than simple age, replace the pulley (PS334244) at the same time or the new belt will wear out quickly too.
Common Problems This Part Fixes
Dryer runs and hums but the drum does not turn — the classic broken belt symptom
Drum spins freely by hand with no resistance when the door is open
Loud squealing, chirping, or scraping noise from inside the dryer
Rhythmic thumping or slapping noise timed to drum rotation — cracked or split belt
Drum turns slowly, intermittently, or stalls under a heavy wet load — glazed belt slipping
Clothes not drying completely, or drying taking longer than it used to
Broken belt pieces or fragments found inside the drum
Visible cracking, fraying, glazing, or stretching on the old belt
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This dryer drum belt directly replaces the following OEM and cross-reference part numbers:
W10849499, W10610882, AP5989682, 4383705, AWP42591, EAP11731121, OEM17969055, PD00046442, PS11731121
W10610882 was the immediately preceding number for this same belt. If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This drum belt is compatible with select large-capacity Whirlpool-built dryers across the Whirlpool family of brands, including:
Whirlpool large-capacity electric and gas dryers
Maytag dryers (select Whirlpool-built models)
KitchenAid, Jenn-Air, and Amana dryers (select models)
Magic Chef, Admiral, Norge, Roper, and Inglis dryers (select models)
Select Kenmore and Ikea dryers built on the Whirlpool platform
Verified model numbers include: YWED8500DC, YWED8000DW, YWED8500DW, 7MWGD8000E, and 7MWGD8500E.
Note: Whirlpool uses several different drum belt lengths across its dryer lineup, and this one is approximately 97.75" long — different from the shorter belts used on other Whirlpool-built platforms. Belts of a similar rib profile but a different length are not interchangeable; a belt that's too long or short for your drum will slip, walk off the pulley, or fail to seat properly. Verify your model number, or measure your old belt end to end, before ordering. Contact our support team with your model number if you're unsure.
Key Features
Aftermarket replacement drum belt for Whirlpool's large-capacity dryer platform
Approximately 97.75" in length
Wraps around the drum, idler tension pulley, and drive motor pulley to transfer motor rotation to the drum
Resolves "motor runs but drum won't turn," "squealing or chirping," and "drum spins freely by hand" symptoms
Direct drop-in replacement — no cutting, splicing, or modification required
Replaces W10610882, AP5989682, 4383705, and PS11731121
Compatible with Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Inglis, and Kenmore large-capacity dryers
Aftermarket replacement built to OEM-equivalent quality standards
Product Specifications
Part Number
W10849499
OEM Part Number
W10849499 (formerly W10610882)
Part Type
Dryer Drum Drive Belt
Condition
Aftermarket Replacement
Application
Whirlpool Large-Capacity Dryers
Length
Approx. 97.75 in.
Routing
Around drum → idler tension pulley → drive motor pulley
Fuel Type
Electric and gas dryers
Companion Part
Idler pulley PS334244 (check/replace if belt failed prematurely)
Quantity
1 belt
Compatible Brands
Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Inglis, Kenmore
Installation Notes
⚠️ Unplug Dryer Before Starting — A Second Person Helps Support The Drum Disconnect power at the outlet or shut off the circuit breaker before beginning. On a gas model, also close the gas shutoff valve before moving the cabinet. Wear work gloves — sheet metal edges inside the cabinet are sharp. On many large-capacity models, both the front and rear panels need to come off to fully access the belt and drum, so budget extra time compared to a simpler platform. Photograph how the old belt routes around the drum, the idler pulley, and the motor pulley before removing anything. Loosen and remove the motor mount or bracket as needed to slip the old belt free, and check the idler pulley by spinning it with your fingers — if it's stiff, gritty, or doesn't spin freely, replace it at the same time, since a worn pulley is a common cause of premature belt failure and will shorten the life of the new belt. With the front panel off, the drum may need to be supported by hand as it comes free — having a second person hold the drum steady makes this significantly easier and reduces the risk of scratching the drum or dropping it. Vacuum out accumulated lint while the cabinet is open. Place the new belt around the drum, seat it in the polished wear track left by the old belt, then route it around the idler pulley and around the motor pulley. Reinstall the motor mount, rotate the drum by hand to confirm the belt tracks straight and stays centered, then reassemble the front and rear panels. Restore power and run a short empty cycle listening for squeal or thump before loading it. Tools needed: nut driver or bit driver, open-end wrench, Phillips screwdriver, work gloves, and ideally a second person to support the drum.
Frequently Asked Questions
How do I confirm the belt is broken and not the motor?
With the dryer unplugged, open the door and try to spin the drum by hand. An intact belt gives firm resistance, because you're turning the motor and idler through the belt. If the drum coasts freely like a bicycle wheel, the belt is broken or has jumped off its pulleys. Sound is the other tell: with a broken belt the motor hums and the blower whooshes normally, so the dryer sounds like it's running perfectly while the drum sits still.
My belt broke and I noticed the idler pulley felt stiff. Do I need to replace that too?
Yes, strongly consider it. A worn or seized idler pulley is a well-documented cause of belt failure — if the pulley can't spin freely, it drags against the belt continuously instead of rolling with it, which wears through even a brand-new belt quickly. If your old belt broke and the pulley feels stiff, gritty, or doesn't spin smoothly when you turn it by hand, replace the idler pulley (part PS334244) along with the belt to avoid repeating this repair soon.
Is this the same length as your other Whirlpool dryer belt listings?
Not necessarily — Whirlpool uses different belt lengths across different dryer platforms even when the rib profile looks similar. This belt is approximately 97.75" long, which is specific to the large-capacity platform it's designed for. Always check your model number or measure your old belt's total length before ordering, since a belt of the wrong length will not seat and tension correctly.
Why does replacing this belt need two people?
On this large-capacity platform, accessing the belt often means removing the front panel and freeing the drum, which is heavy and can be awkward to support single-handedly while also working with your other hand. A second person holding the drum steady while you route the new belt reduces the risk of the drum shifting, scratching the finish, or being dropped. It's not strictly required, but it makes the job considerably easier.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is manufactured to match the approximately 97.75" length and rib profile of the original W10849499 / W10610882 belt used in compatible Whirlpool, Maytag, KitchenAid, Jenn-Air, and related large-capacity dryers.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Quality Aftermarket Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
EXP694 Dryer Repair Kit Replaces DC97-16782A, 6602-001655, DC93-00634A
The EXP694 Dryer Repair Kit is a complete drum system rebuild solution designed to restore smooth, quiet, and efficient dryer operation. This kit includes the most common wear components found inside your dryer: drum belt, idler pulley, and drum support rollers.
Over time, these parts wear down together, causing squeaking, grinding, drum slippage, or complete failure to spin. Replacing all components at once ensures proper alignment, eliminates noise, and prevents repeat breakdowns — making this the most effective long-term repair solution.
Quick Answer
The EXP694 Dryer Repair Kit fixes dryers that won’t spin, make loud squeaking or grinding noises, or stop tumbling. It replaces the belt, rollers, and idler pulley to restore smooth and quiet drum operation.
Note: Includes four rollers (each with shaft and two tri-rings), one idler pulley, and one belt. Replace all four rollers for even wear. Inspect the drum and felt seal (e.g., DC97-07618A) for wear. Clean lint from the drum and cabinet to prevent overheating.
Common Problems This Part Fixes
Dryer drum not spinning or slipping
Loud squeaking, grinding, or thumping noises
Uneven or slow drum rotation
Dryer stopping mid-cycle
Excessive vibration or instability
Worn belt, rollers, or idler pulley components
Replaces Part Numbers
This repair kit replaces the following common drum system components:
Drum Roller: DC97-16782A, AP5325135, DC97-16782C, DC97-16782D, 2027851, DC97-07523A, DC97-07523B, PS4221885, WPW10177428, AP6016361, W10177428, 35001136, DC97-07523A, PS11749648
Idler Pulley: DC93-00634A, AP6038887, DC96-00882C, DC61-01230B, DC96-00882B, PS11771601, 12002777, AP4010261, 1401171, 35001083, 35001098, 35001276, AH2004052, DC61-01215A, DC96-00882B, EA2004052, PS2004052
Drum Belt: 6602-001655, AP4373659, 1935594, 6602-001314, PS4133825, WPW10205415, AP6017004, W10205415, 35001137, 6602-001314, PS11750299
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This repair kit is compatible with select dryers from the following brands:
Samsung dryers (gas and electric models)
Kenmore / Sears dryers (select models built on Samsung platform)
Always verify your appliance model number before ordering. Contact our support team if you're unsure.
Key Features
Complete drum repair kit including belt, rollers, and idler pulley
OEM-equivalent fit, performance, and durability
Eliminates noise and restores smooth drum rotation
Prevents repeat repairs by replacing all wear components together
Cost-effective all-in-one repair solution
DIY-friendly installation with basic tools
Product Specifications
Includes 4 drum rollers (DC97-16782A, ~3-1/4" diameter x 1-1/8" width, blue/black plastic/rubber, metal shaft, self-lubricating bushing with ball bearing, each with shaft and two tri-rings), 1 idler pulley (DC93-00634A, metal/plastic), 1 drum belt (6602-001655, 92" long, 5 ribs, neoprene), kit dimensions ~10"L x 6"W x 4"H.
Part Type
Dryer Repair Kit
Includes
Belt, Rollers, Idler Pulley
Application
Dryer Drum System
Condition
Aftermarket Replacement
Compatible Brands
Samsung, Kenmore
Installation Notes
⚠️ Safety First — Unplug Dryer Before Starting Disconnect power before servicing. Remove dryer panels, release belt tension, and replace worn components. Ensure proper alignment of the belt and rollers before reassembly. For best results, replace all components included in this kit at the same time.
Frequently Asked Questions
Should I replace all parts at once?
Yes. The belt, rollers, and pulley wear together. Replacing all components ensures smooth operation and prevents future breakdowns.
Will this fix dryer noise?
Yes. This kit resolves most squeaking, grinding, and thumping noises caused by worn drum components.
Is this an OEM part?
This is a high-quality aftermarket repair kit built to OEM-equivalent standards for performance and durability.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Quality Parts ✓ Compatibility Support ✓ Secure Checkout
(8 Pack) 3977394 Dryer Thermal Cut-Off Kit – Replaces 3977394 – Compatible with Whirlpool, Kenmore, Maytag, and KitchenAid Dryers
Product Description
Protect your dryer from overheating with the 3977394 Dryer Thermal Cut-Off Kit. This high-quality aftermarket replacement shuts off the heating element if the dryer temperature rises above safe operating limits. A failed cut-off can cause no-heat issues or overheating during drying cycles. Installing this reliable 3977394 kit restores safe temperature control and helps prevent damage to internal components.
Replaces Part Numbers
XPTC352, 3977394, 352F
Compatibility
This replacement thermal cut-off kit fits select Whirlpool, Kenmore, Maytag, Roper, Estate, Crosley, and KitchenAid dryers.
Example compatible models include (but are not limited to): Whirlpool WED4815EW1, Kenmore 110.86573110, and Maytag MEDC215EW1.
Always verify your dryer’s model number before ordering. Contact our support team if you’re unsure.
✅ Key Features
🔄 Aftermarket Replacement – Matches OEM safety and temperature performance
🔥 Overheat Protection – Automatically shuts off power to the heating element if the dryer overheats
💰 Cost-Effective Fix – Affordable alternative to OEM thermal cut-off kits
🛠️ Easy Installation – Direct-fit design with included thermostats and connectors
🛡️ Fixes Common Issues – Solves dryer not heating, overheating, or shutting off prematurely
📐 Product Specification
Part Number: 3977394
Component Type: Dryer Thermal Cut-Off Kit
Includes: Thermal cut-off, high-limit thermostat, mounting hardware, and wire connectors
Temperature Rating: Cut-off opens at ~352°F.
Material: Metal thermostat housing and heat-resistant components
Compliance: Built to OEM-equivalent quality standards (not OEM)
🛠️ Installation Notes
Tools Needed: Nut driver, Phillips screwdriver
⚠️ Safety First: Always unplug the dryer before performing any repairs to prevent electrical shock.
Steps:
Disconnect power and remove the rear dryer panel.
Locate the heating element housing and identify the cut-off and thermostat.
Disconnect wires and remove the old components.
Install the new 3977394 cut-off and thermostat in the same locations.
Reconnect wires, reassemble the back panel, and restore power.
Run a short test cycle to verify proper heating.
⏱️ Time Required: 15–25 minutes
📦 Shop With Confidence
🚚 Free Shipping on All Orders
⚙️ Trusted Appliance Parts Supplier
🔄 30-Day Return Policy
Keep your dryer safe and efficient — Add to Cart Now for a reliable, budget-friendly repair!
XPARTCO 33002535 Dryer Drum Belt Replaces WP33002535
The XPARTCO 33002535 is an aftermarket replacement dryer drum belt compatible with a wide range of Maytag, Amana, Crosley, and Kenmore dryers. The drum belt is a long, ribbed rubber belt that wraps around the outside of the dryer drum and connects to the motor pulley and idler pulley, transferring the motor's rotation to spin the drum during every drying cycle. When the belt breaks or wears out, the motor continues to run but the drum stops spinning — clothes tumble only under gravity or not at all, and the dryer produces heat with no airflow through the load.
This belt measures 91-5/8" in length and 5/16" in width, with 5 ribs and 4 grooves — the correct profile to grip the drum, motor pulley, and idler pulley on compatible Maytag-platform dryers. Made from high-strength rubber designed to resist stretching, cracking, and heat degradation over years of use. It directly replaces WP33002535, 33001777, 63700300, 791135, WP33002535VP, and several additional cross-reference numbers. Installs in 30–45 minutes with basic hand tools.
Quick Answer
The XPARTCO 33002535 Dryer Drum Belt fixes Maytag-platform dryers where the drum is not spinning, the motor runs but the drum is still, or the belt is visibly broken or worn. 91-5/8" long x 5/16" wide, 5 ribs, 4 grooves. Compatible with Maytag, Amana, Crosley, and Kenmore dryers. Replaces WP33002535, 33001777, 63700300, 791135, and more. Installs in 30–45 minutes.
Common Problems This Part Fixes
Dryer drum not spinning — motor runs but drum is completely still
Drum spinning only when manually pushed — belt is slipping or broken
Dryer running but not drying — drum not tumbling clothes through the airflow
Squealing or thumping noise just before the belt broke and the drum stopped
Belt visibly broken, frayed, or in pieces inside the dryer cabinet
Dryer tumbling unevenly or intermittently due to a stretched or slipping belt
Replaces Part Numbers
This dryer drum belt directly replaces the following OEM and cross-reference part numbers:
WP33002535, 33002535, 33001777, 63700300, 6 3713880, 791135,AWP47236, EAP11741110, ER33002535, AP6007983, PD00002428, PS11741110.
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This drum belt is compatible with select gas and electric dryers from the following brands:
Maytag dryers (gas and electric — MDE and MDG series)
Amana dryers (gas and electric)
Crosley dryers (gas and electric)
Kenmore / Sears dryers (select Maytag-built models)
Always verify your appliance model number before ordering. Contact our support team if you're unsure.
Key Features
Wraps around the drum and connects to the motor pulley and idler pulley to transfer motor rotation to the drum
Length: 91-5/8 inches (91.5" / 2327 mm) — correct circumference for Maytag-platform dryers
Width: 5/16 inch — correct profile for the drum groove on compatible models
5 ribs, 4 grooves — ribbed profile grips the motor pulley and idler pulley without slipping
High-strength rubber construction — resists heat, stretching, cracking, and wear over years of daily use
Replaces WP33002535, 33001777, 63700300, 791135, and over 15 additional cross-reference numbers
Often replaced together with drum support rollers (12001541) and idler pulley (WP6-3700340)
Aftermarket replacement built to OEM-equivalent quality standards
DIY repair — installs in 30–45 minutes with basic hand tools
Product Specifications
Part Number
33002535
OEM Part Number
WP33002535
Part Type
Dryer Drum Drive Belt
Condition
Aftermarket Replacement
Application
Gas and Electric Dryers
Length
91-5/8 inches (91.5" / 2327 mm)
Width
5/16 inch
Ribs / Grooves
5 ribs, 4 grooves
Material
High-strength rubber
Color
Black
Often Replaced With
12001541 Drum Rollers, WP6-3700340 Idler Pulley
Compatible Brands
Maytag, Amana, Crosley, Kenmore
Installation Notes
⚠️ Unplug Dryer Before Starting Disconnect power (and shut off gas for gas dryers) before beginning. Remove the top panel by unscrewing the screws inside the lint screen housing and releasing the front clips with a putty knife. Remove the front panel to access the drum. Release tension from the old belt at the idler pulley, then slide the belt off the drum, idler pulley, and motor pulley. Note how the belt is routed before removing it — take a photo if needed. Loop the new 33002535 belt around the drum with the ribbed side facing inward (toward the drum). Route the belt under the idler pulley and around the motor pulley, then pull the idler pulley toward you to create tension. Reassemble the front and top panels, restore power, and run a test cycle to confirm the drum spins. Tip: while the dryer is open, inspect the drum support rollers (12001541) and idler pulley (WP6-3700340) for wear and replace if needed. Tools needed: Phillips screwdriver, 1/4" nut driver, putty knife.
Frequently Asked Questions
What is the difference between 33002535 and WP33002535?
These are the same dryer drum belt. WP33002535 is the updated Whirlpool/Maytag OEM part number that superseded the original 33002535. The 33001777 is also a cross-reference for this same belt. This aftermarket replacement is compatible with all three numbers.
How do I know if my dryer belt has broken?
The clearest sign of a broken belt is a motor that runs — you can hear it humming — but the drum does not spin when you start the dryer. On most Maytag-platform dryers, you can open the dryer door and try to spin the drum by hand — if it spins very freely with almost no resistance, the belt has likely broken. You can also open the top or front panel to visually inspect the belt; a broken belt will be lying loose inside the cabinet or wrapped around components rather than stretched around the drum.
Should I replace the drum rollers and idler pulley at the same time?
Yes — since the dryer is already disassembled, this is the ideal time to inspect and replace the drum support rollers (12001541) and idler pulley (WP6-3700340). These components wear at similar rates to the belt, and a worn roller or pulley bearing is often what caused the belt to wear and break prematurely. Replacing all three together eliminates the most common sources of drum noise and prevents a second teardown in the near future.
Which side of the belt faces the drum?
The ribbed side of the 33002535 belt faces inward — toward the drum surface. The smooth side faces outward, away from the drum. When installing, wrap the belt around the drum with the ribs against the drum, then route the smooth side under the idler pulley and around the motor pulley. If the belt is installed inside-out, it will slip and the drum will not spin correctly.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Maytag or Whirlpool OEM part, but is manufactured from high-strength rubber to match the length, width, and rib profile of the original WP33002535 drum belt.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout
XPARTCO W10198086 Dryer Drum Belt Replaces WPW10198086
The XPARTCO W10198086 is an aftermarket replacement dryer drum belt for Whirlpool, Maytag, and Amana electric dryers. This belt wraps around the drum and the motor pulley, and it's what actually makes the drum turn — the motor drives the belt, and the belt tumbles the drum. When this belt breaks or wears out, the motor can still run, but nothing inside the dryer actually moves.
This is a 5-rib belt measuring approximately 92-1/2"L x 5/16"W x 1/8"H, with grooves on one side and a flat surface on the other. A broken or badly worn belt produces an unmistakable symptom: the dryer runs — you'll hear the motor and often the blower — but the drum doesn't turn at all, or turns only briefly before stopping. A simple way to confirm this diagnosis before opening the dryer is to try turning the drum by hand; if it spins freely with no resistance, the belt is almost certainly broken. Overloading the dryer with oversized loads is a common cause of belt failure over time. It directly replaces WPW10198086, W11575709, W11667279, LB8086, 1481904, AP6016842, AH2348726, EA2348726, PS2348726, EAP11750135, PS11750135, AWP49253, and PD00007598.
Quick Answer
The XPARTCO W10198086 Dryer Drum Belt fixes Whirlpool, Maytag, and Amana electric dryers where the motor runs but the drum doesn't turn, or turns only briefly. 5-rib belt, approximately 92-1/2"L x 5/16"W x 1/8"H. Replaces WPW10198086, W11575709, W11667279, LB8086, 1481904, AP6016842, AH2348726, EA2348726, PS2348726, EAP11750135, PS11750135, AWP49253, PD00007598. Try turning the drum by hand first — if it spins freely with no resistance, the belt has broken.
Common Problems This Part Fixes
Dryer runs — motor and blower audible — but the drum doesn't turn
Drum turns briefly then stops
Drum spins freely by hand with no resistance (indicating a broken belt)
Loud squeaking noise during operation from a worn but not yet broken belt
Burning rubber smell from a slipping or overheating belt
Dryer that stopped tumbling suddenly during a cycle
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This dryer drum belt directly replaces the following OEM and cross-reference part numbers:
WPW10198086, W10198086, 1481904, W11575709, W11667279, LB8086, PD00007598, EAP11750135, AP6016842, AWP49253, PS11750135
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This drum belt is compatible with select Whirlpool electric dryers, and also fits select Maytag and Amana dryers built on the same platform, including model numbers such as:
MEDC465HW0, MEDC215EW0, MEDC215EW1, MEDC200XW0, MEDC200XW1, MEDC200XW3
MEDX655DW0, MEDX655DW1, MEDX500BW0, MEDX500BW1
MEDC300BW0, MEDC300XW0, MEDC300XW1, MEDC400VW0, MEDC400BW1, MEDC415EW0
MGDC400VW0, MGDC215EW0, MGDC215EW2, MGDC465HW0, MGDC300XW3, MGDC400BW1, MGDC400BW2, MGDC500VW0, MGDC555DW1
MEDC555DW1, MEDC555DW2, MEDC100YQ0, MEDB766FW0
7MMGDC400DW0, 7MMGDC400DW1, 7MMGDC400DW2, 7MMEDC300DW1, 7MMEDC300BW0
Note: Always verify your full model number before ordering, since Whirlpool uses several different drum belts across its dryer lineup with different lengths and rib counts. Contact our support team with your model number if you're unsure.
Key Features
Aftermarket replacement drum belt — connects the motor pulley to the drum so it can turn
Resolves "motor runs but drum won't turn," "drum stops mid-cycle," and "squeaking" symptoms caused by a worn or broken belt
5-rib design with grooves on one side, flat on the other
Approximately 92-1/2"L x 5/16"W x 1/8"H
Direct drop-in replacement matching the original belt routing
Replaces WPW10198086, W11575709, W11667279, LB8086, 1481904, AP6016842, AH2348726, EA2348726, PS2348726, EAP11750135, PS11750135, AWP49253, and PD00007598
Compatible with Whirlpool, Maytag, and Amana electric dryers
Aftermarket replacement built to OEM-equivalent quality standards
Product Specifications
Part Number
W10198086
OEM Part Number
WPW10198086
Part Type
Dryer Drum Belt
Condition
Aftermarket Replacement
Length
Approx. 92-1/2 in.
Width
5/16 in.
Thickness
1/8 in.
Ribs
5
Color
Black
Material
Rubber
Repair Difficulty
Easy — 15 to 30 minutes
Quantity
1 drum belt
Compatible Brands
Whirlpool, Maytag, Amana
Installation Notes
⚠️ Unplug Dryer Before Starting — Check The Idler Pulley While You're In There Disconnect power at the outlet or shut off the circuit breaker before beginning. Wear work gloves. Lift the lint screen cover and remove the two screws underneath it — if your model has a lint screen with a built-in cover, simply pull it out and remove the screws. Run a putty knife around the top edge of the dryer to find the release clips, then press them in to release and swing the top open. Remove the front panel to access the drum and belt area; on many models, all the work for this repair is performed from the front rather than the rear. Route the new W10198086 belt around the drum with the grooved side against the drum, then loop it around the motor pulley and the idler pulley, following the routing diagram on the inside of the cabinet or your old belt's path if it's still intact when you remove it. If the belt broke rather than just wearing out, check that the idler pulley is still properly seated — a belt snapping can sometimes cause the pulley to pop out of position, and reseating it is a quick fix while you already have the panel open. Reinstall the front panel, close the top and secure the release clips, and reinstall the lint screen area and its screws. Restore power and run a test cycle to confirm the drum turns smoothly with no slipping or noise. Tools needed: Phillips screwdriver, 5/16" nut driver, putty knife, work gloves.
Frequently Asked Questions
My dryer runs but the drum won't turn. How do I confirm it's the belt before ordering?
Try turning the drum by hand with the dryer unplugged. If it spins freely with little to no resistance, that's a strong sign the belt has broken, since an intact belt normally provides some resistance from the motor and idler pulley connected to it. If the drum feels stuck or hard to turn instead, the problem may be elsewhere, such as a seized idler pulley or motor issue.
What caused my belt to break in the first place?
Belts wear out from age and normal use, but overloading the dryer with oversized or overly heavy loads is a common accelerating factor, since it puts extra strain on the belt with every rotation. Avoiding overloaded loads going forward can help the new belt last as long as it should.
While replacing the belt, I noticed the idler pulley looks out of place. Is that related?
Yes, this can happen when a belt breaks suddenly — the pulley can pop out of its normal seated position as tension is lost. Since you'll already have the panel open for the belt replacement, take a moment to check that the idler pulley is properly seated before closing everything back up, as this is a common and easy thing to overlook.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is manufactured to match the length, width, rib count, and routing configuration of the original WPW10198086 drum belt used in compatible Whirlpool, Maytag, and Amana electric dryers.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Quality Aftermarket Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
