XPARTCO EAU61524007 Refrigerator Evaporator Fan Motor
13V, 1.5 W, 0.118A.
1-1/2" shaft.
Has quick disconnect.
Fits specific LG Refrigerator Models.
Description: This ERP EAU61524007 Refrigerator Evaporator Fan Motor is designed for reliable and efficient cooling performance. It features the EAU61524007 model, providing optimal airflow and preserving freshness in your refrigerator. Upgrade your appliance with this high-quality fan motor and enjoy the benefits of improved cooling and longer-lasting food.
Replaces Part Numbers:EAU61524007, AP5950081, EAU60694510, PS10058947
This is an aftermarket part that can be used as a replacement for the OEM part.
Genuine Whirlpool OEM
Whirlpool WPW10184813 Refrigerator Genuine OEM Ice Dispenser Motor
Genuine OEM ice-dispenser door motor for select Whirlpool-built refrigerators.
Product Overview
The Whirlpool WPW10184813 Refrigerator Ice Dispenser Door Motor is a Genuine Whirlpool OEM replacement part. It opens and closes the ice chute door during dispenser operation so ice can pass through the chute and the door can reseal afterward.
A failed motor can cause the dispenser door to remain stuck open or closed, prevent ice from dispensing correctly, or allow warm room air to enter the chute area.
Quick Answer
WPW10184813 is the Genuine Whirlpool OEM ice-dispenser door motor that replaces W10184813 and 2305262. Verify the complete refrigerator model number before purchase.
Common Problems This Part May Fix
Ice dispenser door will not open
Ice chute door will not close
Ice maker makes ice but ice will not dispense
Chute door sticks or operates intermittently
Warm air enters around the dispenser chute
Frost or moisture develops around the dispenser opening
Replaces and Cross-References
WPW10184813, 1489085, 2305262, AP6016508, EAP11749796, W10184813, AWP49407, OEM18049533, PD00006398, PS11749796
Cross-reference numbers are provided for identification. Always verify compatibility by complete refrigerator model number.
Compatibility
Used on select Whirlpool-built refrigerators sold under Whirlpool, KitchenAid, JennAir, Maytag, and Kenmore brand names. Compatible model examples include:
GI7FVCXWY00
KSCS25FTMS02
KSRS25FTSS01
KSCS23FVMS02
KSRS25RSBT01
KSCS25FVMS01
KSCS25FTSS00
GC3NHAXVA00
106.56702500
Important: This is only a partial model list. Confirm the complete model number from the refrigerator identification label before ordering.
Key Features
Genuine Whirlpool OEM part
Operates the ice dispenser chute door
Replaces W10184813 and 2305262
For select Whirlpool-built side-by-side and French-door refrigerators
Helps restore proper dispenser-door opening and closing
Product Specifications
Manufacturer Part Number
WPW10184813
Brand
Whirlpool
Part Type
Refrigerator Ice Dispenser Door Motor
Condition
New
Quality
Genuine OEM
Application
Ice Dispenser Chute Door
Package Quantity
1 Motor
Installation Notes
Disconnect refrigerator power before service.
Remove the dispenser trim and front components according to the appliance service procedure.
Photograph connector and mechanical linkage positions before disassembly.
Inspect the chute door, hinge, spring, and linkage for binding or damage before replacing the motor.
Transfer or reconnect the wiring and linkage exactly as originally installed.
Reassemble all dispenser parts and verify the chute door opens and fully closes before returning the refrigerator to service.
Diagnostic tip: A dispenser that will not release ice can also be caused by an actuator, dispenser switch, control board, auger motor, frozen chute, or mechanical obstruction. Diagnose the dispenser system before replacing parts.
Frequently Asked Questions
Is WPW10184813 a Genuine Whirlpool OEM part?
Yes. WPW10184813 is a Genuine Whirlpool OEM ice-dispenser door motor.
Does it replace W10184813?
Yes. Whirlpool lists WPW10184813 as the replacement for W10184813 and 2305262.
What does this motor do?
It opens and closes the dispenser chute door so ice can pass through the chute and the opening can reseal after dispensing.
Will it fit every Whirlpool refrigerator?
No. Verify the complete refrigerator model number before ordering because dispenser designs vary by model and production revision.
Shop With Confidence
Genuine Whirlpool OEM replacement part. Verify your complete refrigerator model and original part number before ordering.
Genuine OEMIce Dispenser MotorCompatibility SupportFast U.S. Shipping
WR60X10209 (OE) Refrigerator Condenser Fan Motor
The WR60X10209 is an OE (Original Equipment) DC condenser fan motor for GE refrigerators. This motor lives in the compressor/machine compartment at the back or bottom of the refrigerator. Whenever the compressor runs, this fan runs right along with it, circulating air across the condenser coils to help dissipate heat from the hot refrigerant before it moves on to the evaporator, keeping the compressor from overheating and the whole system running efficiently.
Rated 11.3V DC, 2.2W, with a 4-pin plastic plug carrying 4 wires (white, blue, red, and yellow). The motor shaft measures 1/8" in diameter and 2-7/8" long. Common failure causes include worn motor bearings, dirty or obstructed condenser coils forcing the motor to work harder than intended, and general electrical wear. Symptoms include increased noise when the freezer door is opened, warm temperatures inside the refrigerator, and — left unaddressed — compressor overheating and food spoilage from a refrigerator that can no longer maintain temperature. It directly replaces WR60X10042, WR60X10053, WR60X10065, WR60X10080, WR60X10081, WR60X10155, WR60X10216, WR60X24483, AP4265957, and PS1483567.
Quick Answer
The WR60X10209 (OE) Refrigerator Condenser Fan Motor fixes GE, Hotpoint, RCA, and select Kenmore refrigerators with increased noise near the compressor compartment, warm temperatures inside the fridge, or early signs of compressor overheating. 11.3V DC, 2.2W, 4-pin/4-wire plug, 1/8" x 2-7/8" shaft. Replaces WR60X10042, WR60X10053, WR60X10065, WR60X10080, WR60X10081, WR60X10155, WR60X10216, WR60X24483, AP4265957, PS1483567. This is the 12V DC condenser fan — if your refrigerator needs a 120V motor, see our WR60X10220 listing instead.
Common Problems This Part Fixes
Increased noise near the compressor compartment or when the freezer door is opened
Warm temperatures inside the refrigerator
Refrigerator running constantly as it struggles to maintain temperature
Compressor overheating from restricted airflow around the condenser coils
Food spoilage from a refrigerator that can't hold a consistent temperature
Fan blade that doesn't spin freely, or doesn't spin at all, when checked by hand
What Is an OE Part?
OE (Original Equipment) means this part is manufactured by the same original supplier that produces the Genuine OEM version — identical fit, materials, and performance. The only difference is packaging: OE parts ship under our XPARTCO brand rather than the appliance manufacturer's branded box, which is why they can't be listed as Genuine OEM. You get factory-original quality at a more affordable price.
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This refrigerator condenser fan motor directly replaces the following OEM and cross-reference part numbers:
WR60X10209, 1195784, WR60X10042, WR60X10053, WR60X10065, WR60X10080, WR60X10081, WR60X10155, WR60X10216, 045900390950, 197D2407P013, AGE29194, AH1483567, EA1483567, EAP1483567, AP4265957, PD00001176, PS1483567.
The motor's own sticker also references production number 197D2407P013. If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This condenser fan motor is compatible with select GE and Hotpoint refrigerators, and also fits select RCA and Kenmore refrigerators built on the GE platform.
Note — 12V DC, not 120V: This is the 12V DC condenser fan motor. If your refrigerator calls for a 120V motor instead, you need our WR60X10220 listing. This is also a condenser fan (cools the compressor and condenser coils), not an evaporator fan (circulates cold air to the food compartments) — a different part from our WR60X10074, WR60X10185, and WR60X10318 evaporator fan motor listings. Always verify your full model number before ordering. Contact our support team with your model number if you're unsure which fan motor your refrigerator needs.
Key Features
OE (Original Equipment) condenser fan motor — draws air across the condenser coils to cool the refrigerant and compressor
Resolves "noise near the compressor," "warm fridge temperatures," and "compressor overheating" symptoms caused by fan failure
Rated 11.3V DC, 2.2W
4-pin plastic plug with 4 wires (white, blue, red, yellow)
1/8" diameter x 2-7/8" long shaft
Direct drop-in replacement matching the original mounting and blade fitment
Replaces WR60X10042, WR60X10053, WR60X10065, WR60X10080, WR60X10081, WR60X10155, WR60X10216, WR60X24483, AP4265957, and PS1483567
Compatible with GE, Hotpoint, RCA, and select Kenmore refrigerators
Product Specifications
Part Number
WR60X10209
Designation
OE (Original Equipment)
Part Type
Refrigerator DC Condenser Fan Motor
Brand
GE
Location
Compressor/machine compartment (back or bottom of cabinet)
Function
Cools the condenser coils and compressor
Voltage
11.3V DC
Wattage
2.2 W
Connector
4-pin plastic plug, 4-wire (white, blue, red, yellow)
Shaft
1/8" diameter x 2-7/8" long
Quantity
1 fan motor
Compatible Brands
GE, Hotpoint, RCA, Kenmore
Installation Notes
⚠️ Danger — Authorized Service Part Required For Flammable Refrigerant Systems GE's own service guidance carries an explicit warning for this component: it is a manufacturer-authorized service part intended for use in refrigerator models that use a flammable refrigerant, such as R600a. Using an unauthorized or incorrectly rated service part in a unit that uses a flammable refrigerant could lead to a risk of fire or explosion. Before ordering or installing, confirm your refrigerator's refrigerant type and verify this part is correct for your specific model. If you have any doubt about your refrigerant type or the correct part for your unit, contact our support team with your model number before proceeding, or have a qualified appliance technician perform this repair.
⚠️ Unplug Refrigerator Before Starting Shut off power at the circuit breaker or fuse box, then pull the refrigerator away from the wall and disconnect the power cord from the outlet. Wear work gloves. Remove the condenser fan motor cover, typically held on by two screws, to access the motor. Before condemning the motor, clear away any dust, lint, or debris built up around the condenser coils and fan blade — restricted airflow from a dirty coil produces symptoms similar to a failing motor and costs nothing to rule out. Photograph the wiring and the fan blade's position before disconnecting anything. Disconnect the 4-pin plug from the old motor, remove the mounting screws or clips holding the motor bracket in place, and pull the motor and fan blade assembly free. Mount the new WR60X10209 in the same position, reconnect the 4-pin plug fully, and confirm the blade spins freely by hand without contacting the housing before reinstalling the fan cover. Restore power and monitor the refrigerator over the next 24 hours to confirm normal, even cooling has returned. Tools needed: Phillips screwdriver, work gloves.
Frequently Asked Questions
Why is there a fire/explosion warning on this part?
Some refrigerators use a flammable refrigerant, such as R600a (isobutane), instead of older non-flammable refrigerants. Electrical components like fan motors sit near refrigerant lines and can be a source of ignition if a leak were ever present, which is why GE specifically requires an authorized, correctly rated service part for these systems rather than a generic substitute. This isn't a concern unique to this listing — it reflects GE's general guidance for electrical components used in flammable-refrigerant refrigerators, and confirming your model and refrigerant type before ordering is the appropriate precaution.
My refrigerator is noisy and runs warm. Is this the condenser fan?
It's a strong possibility, especially if the noise seems to come from the back or bottom of the unit and you notice both symptoms together. Without proper airflow across the condenser coils, heat builds up in the machine compartment, which reduces the whole refrigeration cycle's efficiency and shows up as warmer-than-normal temperatures throughout the fridge.
Could dirty condenser coils cause the same symptoms as a bad fan motor?
Yes, and it's worth checking before you buy a new motor. A condenser fan pushing air through coils caked in dust, pet hair, or debris will struggle to cool the system properly even if the motor itself is working fine. Clean the coils and the fan blade thoroughly first; if the fan still doesn't spin freely, spins with a wobble, or doesn't run at all afterward, the motor itself has failed and this replacement is the correct fix.
Is this a genuine OEM part?
This is an OE (Original Equipment) part sold under our XPARTCO brand. OE parts are manufactured by the same original supplier that produces the Genuine OEM part, so the fit, materials, and performance are identical — the difference is that OE parts ship in XPARTCO packaging rather than the appliance manufacturer's branded box, which is why we can't list them as Genuine OEM. This gives you factory-original quality at a more affordable price than the branded version.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ OE (Original Equipment) Quality ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
XPARTCO W11224591 Refrigerator Evaporator Fan Motor
The XPARTCO W11224591 is an aftermarket replacement freezer evaporator fan motor assembly compatible with a wide range of Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore bottom-mount French door refrigerators. The evaporator fan motor is located in the freezer compartment behind the rear panel — it draws cold air across the evaporator coils and circulates it throughout both the freezer and the fresh food compartment. This constant air movement is what keeps temperatures even and food fresh. When the fan motor fails, the most common symptom is telling: the refrigerator (fresh food) compartment stops cooling while the freezer stays cold but doesn't reach full capacity, because the fan is no longer moving the cold air up into the fridge section.
This is a complete assembly that includes the fan motor, wiring harness, temperature sensor (thermistor), and defrost thermostat — everything integrated into one replaceable unit. Finished in white. As a direct replacement for the Whirlpool W11224591, it also replaces AP6329809, W10865431, W10728111, W11215582, 4844712, and PS12349521. Motor failure typically results from normal wear, obstruction from frost or debris rubbing the fan blade, or motor winding issues. Installs in 30–45 minutes with basic hand tools.
Quick Answer
The XPARTCO W11224591 Refrigerator Evaporator Fan Motor fixes Whirlpool, Maytag, KitchenAid, Jenn-Air, and Amana bottom-mount French door refrigerators where the fridge section is warm but the freezer is cold, temperatures are uneven, frost builds up on the coils, or unusual noise comes from the freezer compartment. Complete assembly — includes fan motor, wiring harness, temperature sensor, and defrost thermostat. White finish. Replaces AP6329809, W10865431, W10728111, W11215582, 4844712, PS12349521. Compatible with Whirlpool WRF757/WRF767/WRF736 series, KitchenAid KRFF507 series, Maytag MFT2574 series and related models.
Common Problems This Part Fixes
Refrigerator (fresh food) compartment warm while the freezer stays cold — the signature symptom of evaporator fan motor failure
Uneven or inconsistent temperatures throughout the refrigerator
Unusual noises from the freezer compartment — grinding, squealing, or clicking as the motor bearings fail or the blade rubs on frost/ice
Frost or ice buildup around the cooling sections and evaporator coils
Refrigerator running continuously or more frequently than usual to compensate for poor air circulation
Noticeable decrease in overall cooling efficiency
Food spoiling faster than normal in the fresh food compartment
Fan motor not spinning at all when the compressor is running
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This evaporator fan motor assembly directly replaces the following OEM and cross-reference part numbers:
W11224591, W10865431, 4844712, W10728111, W11215582, AP6329809, AWP43665, EAP11738038, FIX12349521, DLB5985WPEB, PD00052715, PS12349521.
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This evaporator fan motor is compatible with select bottom-mount French door refrigerators from the following brands:
Whirlpool refrigerators — WRF757SDHV00, WRF757SDHZ00/Z01/Z02, WRF767SDHV00/V02, WRF767SDHZ00/Z01/Z02 series
Whirlpool refrigerators — WRF736SDAB14, WRF736SDAM14, WRF736SDAW14, 7WF736SDAM14 series
KitchenAid refrigerators — KRFF507HPS00/PS01/PS02, KRFF507HBS02, KRFF507HWH02 series
Maytag refrigerators — MFT2574DEH02 and related bottom-mount French door models
Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper refrigerators — select Whirlpool-built models
Kenmore / Sears and Ikea refrigerators — select Whirlpool-built models
Always verify your appliance model number before ordering. Contact our support team if you're unsure.
Key Features
Complete evaporator fan motor assembly — includes fan motor, wiring harness, temperature sensor (thermistor), and defrost thermostat in one integrated unit
Circulates cold air from the evaporator coils throughout the freezer and fresh food compartments for even temperatures
Resolves the classic "fridge warm, freezer cold" symptom of evaporator fan failure
Prevents frost buildup by maintaining proper airflow across the coils
White finish, direct-fit replacement using original mounting points and connectors
Because the assembly bundles the defrost thermostat and temperature sensor, it addresses multiple potential failure points in a single repair
Replaces AP6329809, W10865431, W10728111, W11215582, 4844712, and PS12349521
Compatible with Whirlpool WRF757/WRF767/WRF736 series, KitchenAid KRFF507 series, Maytag MFT2574 series, plus Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and Ikea Whirlpool-built bottom-mount refrigerators
Aftermarket replacement built to OEM-equivalent quality standards
DIY repair — installs in 30–45 minutes with basic hand tools
Product Specifications
Part Number
W11224591
Part Type
Freezer Evaporator Fan Motor Assembly
Condition
Aftermarket Replacement
Application
Bottom-Mount French Door Refrigerators (Whirlpool platform)
Assembly Includes
Fan Motor, Wiring Harness, Temperature Sensor (Thermistor), Defrost Thermostat
Location
Freezer compartment, behind rear panel
Color
White
Compatible Brands
Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, Ikea
Installation Notes
⚠️ Unplug Refrigerator and Move Perishable Food Before Starting — Wear Work Gloves Unplug the refrigerator and safely store any food that could spoil while the power is off. Wear work gloves to protect your hands. The evaporator fan motor is located in the freezer compartment behind the rear access panel. Remove all freezer shelves, drawers, and the ice maker (if equipped) to clear access to the back wall. If there's frost or ice buildup on the rear panel or coils, allow the freezer to thaw completely before continuing — never chip or pry ice off the evaporator coils, as the aluminum fins damage easily. Remove the screws securing the rear freezer access panel and lift it away to expose the evaporator coils and fan motor assembly. Photograph the wiring harness connections and the fan motor orientation before disconnecting anything. Disconnect the wire harness connectors from the old assembly and release it from its mounting points. Lift out the old fan motor assembly. Install the new W11224591 assembly using the original mounting points and connectors — since this is a complete assembly, the fan motor, harness, temperature sensor, and defrost thermostat all transfer as one unit. Reconnect the wiring harness, matching your photos. Confirm the fan blade spins freely by hand without rubbing on any surrounding surface. Reinstall the rear access panel, shelves, drawers, and ice maker. Plug the refrigerator back in and allow several hours for the unit to return to its set temperature before reloading with food. Test airflow and temperature consistency before considering the job complete. Tools needed: Phillips screwdriver, 1/4" nut driver, work gloves.
Frequently Asked Questions
My refrigerator section is warm but the freezer is still cold — is this the fan motor?
This is the single most common and telling symptom of a failed evaporator fan motor on these bottom-mount French door refrigerators. Here's why: the evaporator coils (which produce the cold) are in the freezer, and the evaporator fan is what pushes that cold air up into the fresh food compartment. When the fan motor fails, the freezer stays cold (it's right next to the coils) but the fridge section warms up because no air is being circulated to it. If your freezer is cold and your fridge is warm, the evaporator fan motor is the prime suspect. You can confirm by listening for the fan running when the compressor is on, or opening the freezer rear panel to see if the fan spins.
What's included with this part — is it just the motor?
This is a complete assembly, not just the bare motor. It includes the fan motor, the wiring harness, the temperature sensor (thermistor), and the defrost thermostat — all integrated into one unit. This is actually an advantage: since these components live together in the freezer compartment and can each cause cooling problems, replacing them as a bundle addresses multiple potential failure points in a single repair, reducing the chance you'll be back in the freezer compartment a few months later for a related part.
Why is my evaporator fan making noise?
A noisy evaporator fan usually means one of two things: the motor bearings are wearing out (producing grinding or squealing), or the fan blade is rubbing against frost or ice that has built up around it. If frost buildup is the cause, that often points to a secondary problem with the defrost system (defrost heater, thermostat, or control) allowing ice to accumulate where it shouldn't. Since this replacement assembly includes a new defrost thermostat, it addresses one of the common defrost-related causes. If heavy frost keeps returning after replacement, the defrost heater or control board should be investigated next.
Do I need to defrost the freezer before installing this?
If there's frost or ice buildup on the rear freezer panel or evaporator coils, yes — clear it before installing the new assembly. Leave the freezer empty and unplugged with the door open for several hours (longer for heavy ice) to let everything thaw naturally, placing towels at the base to catch melt water. Never chip or pry ice off the evaporator coils with a tool — the aluminum fins are delicate and a damaged coil is a far more expensive repair. Once everything is fully thawed and dried, proceed with the fan motor replacement.
Is this an OEM or aftermarket part?
This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is manufactured to match the fit, mounting points, connector configuration, and function of the original W11224591 evaporator fan motor assembly used in compatible Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, and Kenmore bottom-mount French door refrigerators — including the integrated harness, temperature sensor, and defrost thermostat.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout
5304530651 Refrigerator Genuine OEM Evaporator Fan Motor
115V 60hz 2.8W
Replaces Part Numbers: 5304530651, 242077704, AP7179350, PS16660872
Description: This Evaporator Fan Motor is a Genuine OEM part for specific Electrolux, Frigidaire refrigerator models. It is responsible for circulating air throughout the refrigerator’s interior to maintain consistent cooling and optimal temperature distribution. This motor works to move air over the evaporator coils, aiding in the cooling process and ensuring that the refrigerator and freezer compartments remain at the desired temperature.
WR60X26866 Genuine OEM GE Refrigerator Axial Evaporator Fan Motor
The WR60X26866 is a Genuine OEM GE replacement axial evaporator fan motor manufactured by GE to factory specifications, designed as a direct fit for the fresh food section of select GE French door refrigerators, including the CFE28, CFE29, CWE23, CYE22, CYE23, DFE28, DFE29, GFD28, GFE26, GFE27, GFE28, GFE29, GFS26, GFS28, GNE26, GNE29, GYE22, GYS22, PFD28, PFE28, PFE29, PWE23, PYD22, PYE22, PYE23, and ZWE23 series. The evaporator fan motor pulls air through the evaporator coils to remove heat from the circulating air inside the refrigerator. Without a functioning evaporator fan, the refrigerator compartment cannot maintain its target temperature even when the compressor and condenser are running normally — the cold air generated at the evaporator simply isn't being circulated to the food storage areas.
The WR60X26866 is a DC motor rated at 13.6V DC, 0.16A, with a fan housing measuring 3-4/7"L x 2"W x 3-1/8"H, plus a multi-color wire harness and plug approximately 11-1/2" long. It includes the axial fan blade and harness as a complete assembly. It directly replaces WR60X26033, WR60X26030, WR60X24303, WR60X10341, WR60X10356, WR60X10357, WR02X13733, 239D1412P006, V80E14MS2A3-57A611, 8817V-W1, 4546026, AP5985039, AP6278228, EAP12172983, PD00038765, PS11721915, and PS12172983. Important: if your refrigerator was built between May 2014 and March 2015 with serial range FF–HD, the unit's software must be updated before installing this fan motor — see FAQ below. Installs in 20–30 minutes with basic hand tools.
Quick Answer
The WR60X26866 Genuine OEM GE Refrigerator Axial Evaporator Fan Motor fixes GE French door refrigerators where the fridge isn't cooling but the freezer is cold, the evaporator coils are frosted over, the ice maker isn't working due to insufficient cooling, or there's loud humming or grinding from the freezer area. Axial fan motor, 13.6V DC, 0.16A. Fan housing: 3-4/7"L x 2"W x 3-1/8"H; harness ~11-1/2"L. Replaces WR60X26033, WR60X26030, WR60X24303, WR60X10341, WR60X10356, WR60X10357, WR02X13733, 239D1412P006, V80E14MS2A3-57A611, 8817V-W1, 4546026, AP5985039, AP6278228, EAP12172983, PD00038765, PS11721915, PS12172983. Note: May 2014 – Mar 2015 build refrigerators (serial range FF–HD) require a software update before installation.
Common Problems This Part Fixes
Refrigerator not cooling properly while the freezer remains cold — classic evaporator fan failure
Freezer cold but fridge warm — fresh food compartment air not being circulated
Frosty or frozen evaporator coils due to insufficient air circulation
Ice maker failure caused by inadequate cooling in the compartment
Loud humming, grinding, or buzzing noise from the freezer or fresh food compartment
Refrigerator running continuously without reaching set temperature
Fan blade not spinning freely or seized when checked by hand
Multimeter shows no continuity through the motor windings
Replaces Part Numbers
This evaporator fan motor directly replaces the following OEM and cross-reference part numbers:
WR60X26866, WR02X13733, WR60X10341, WR60X10356, WR60X10357, WR60X24303, WR60X26030, WR60X26033, V80E14MS2A3-57A611, 8817V W1, 239D1412P006, PD00038765, FIX12172983, AGE29673, AP6278228, PS12172983.
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This evaporator fan motor is compatible with select GE French door refrigerators, including:
GE refrigerators — CFE28, CFE29, CWE23, CYE22, CYE23 series (CFE28TP2MBS1, CFE28USHNSS, CWE23SP2MBS1, CYE22TP2MBS1 and related)
GE refrigerators — DFE28, DFE29 series (DFE28JELCDS and related)
GE refrigerators — GFD28, GFE26, GFE27, GFE28, GFE29 series (GFD28GBLBTS, GFE26GGHEBB and related)
GE refrigerators — GFS26, GFS28, GNE26, GNE29 series
GE refrigerators — GYE22, GYS22 series (GYE22HMKEES and related)
GE refrigerators — PFD28, PFE28, PFE29 series (PFE28KELFDS and related)
GE refrigerators — PWE23 series (PWE23KSKDSS and related)
GE refrigerators — PYD22, PYE22, PYE23 series (PYE22KSKBSS and related)
GE refrigerators — ZWE23 series and select related Café and Profile French door models
Important — Software Update Requirement: If your GE refrigerator was manufactured between May 2014 and March 2015 with a serial number in the range FF–HD, the refrigerator's control software must be updated by GE factory service (or via Software Update Module WR98R882802) before installing this fan motor. Installing the new motor without the software update on these affected units may result in improper performance. Check your refrigerator's serial number plate before ordering.
Key Features
Axial evaporator fan motor for the fresh food section of GE French door refrigerators
Pulls air through the evaporator coils to remove heat and circulate cold air through the refrigerator compartment
DC motor — rated 13.6V DC, 0.16A — runs on DC voltage from the refrigerator control board
Includes the axial fan blade and pre-attached multi-color wire harness with plug
Fan housing dimensions: 3-4/7"L x 2"W x 3-1/8"H; harness and plug approximately 11-1/2" long
Quiet operation — engineered to minimize hum and vibration in the refrigerator cabinet
Plastic and metal construction, black housing with multi-color harness
Replaces an extensive list of GE part numbers including WR60X26033, WR60X26030, WR60X24303, WR60X10341, WR60X10356, WR60X10357, and additional cross-references
Compatible with GE, GE Café, and GE Profile French door refrigerators in the CFE, CWE, CYE, DFE, GFD, GFE, GFS, GNE, GYE, GYS, PFD, PFE, PWE, PYD, PYE, and ZWE series
Genuine OEM part manufactured by GE to factory specifications — guaranteed fit and performance
DIY repair — installs in 20–30 minutes with basic hand tools
Product Specifications
Part Number
WR60X26866
Part Type
Refrigerator Evaporator Fan Motor (Fresh Food / Axial)
Condition
Genuine OEM
Application
GE French Door Refrigerators
Voltage
13.6V DC
Amperage
0.16A
Fan Type
Axial
Fan Housing Dimensions
3-4/7"L x 2"W x 3-1/8"H
Harness Length
Approximately 11-1/2 inches
Color
Black housing with multi-color harness
Material
Plastic / Metal
Includes
Axial fan motor assembly with harness
Software Update Required
For May 2014 – Mar 2015 builds (serial range FF–HD) — use WR98R882802
Compatible Brands
GE, GE Café, GE Profile
Installation Notes
⚠️ Unplug Refrigerator and Move Perishable Food Before Starting — Wear Work Gloves Unplug the refrigerator and safely store any food that could spoil while the power is off. Wear work gloves to protect your hands. The evaporator fan motor for the fresh food section is mounted on the back wall of the fresh food (refrigerator) compartment, behind an access panel. Take a photo of the existing fan position and wire harness routing before disconnecting. Remove the shelves and any internal components blocking access to the back wall, then remove the screws holding the rear access panel in place. Disconnect the fan motor's wire harness connector and remove the mounting screws securing the old motor. Note the fan blade orientation on the motor shaft. Install the new WR60X26866 motor assembly in the same position with the blade facing the same direction, reconnect the wiring harness, and reinstall the mounting screws and access panel. Replace the shelves and other internal components, restore power, and confirm the fan spins and the refrigerator cools properly. Allow several hours for the refrigerator to return to its set temperature before reloading with food. Tools needed: Phillips screwdriver, 1/4" nut driver, work gloves.
Frequently Asked Questions
My fridge is warm but my freezer is cold — is the evaporator fan motor the problem?
Yes — this is one of the most recognizable symptoms of evaporator fan motor failure on GE French door refrigerators with a separate fresh food evaporator. The freezer side has its own cooling circuit and remains cold, while the fresh food side relies on this fan to circulate air across its evaporator coils. When the fan fails, the freezer continues working but the fresh food compartment loses its cold air supply, warming up while the freezer stays at temperature. If you also notice frost building up on the evaporator coils behind the back panel of the fresh food compartment, the fan failure is confirmed.
What is the software update requirement for May 2014 – March 2015 refrigerators?
GE issued a software update for certain refrigerators manufactured between May 2014 and March 2015 (serial range FF–HD) before they could properly support newer revisions of the WR60X26866 evaporator fan motor. If your refrigerator falls in this date and serial range, the control software must be updated before installing this fan motor — either by GE factory service or by using the Software Update Module part WR98R882802. Installing the new fan on an unupdated unit can result in improper performance. Check the serial number plate inside your refrigerator (typically on the left side wall) to confirm whether your unit is affected. Refrigerators built outside this range do not require the update.
How do I test if the evaporator fan motor has failed?
Unplug the refrigerator, then access the fan behind the rear panel of the fresh food compartment. First, try turning the fan blade by hand — if it doesn't spin freely, is stiff, or seizes, the motor bearing has failed. Next, listen during normal operation — if the motor is unusually noisy or makes a grinding sound, the bearings are worn even if it still spins. Finally, with the unit unplugged and the motor disconnected, use a multimeter on the motor windings to check for continuity. If the windings show no continuity, the motor has failed electrically. Also check for approximately 11–14V DC at the connector when the refrigerator is running — if voltage is present but the motor doesn't spin, the motor has failed.
My fridge has two evaporator fans — which one does this replace?
Some GE French door refrigerators have separate evaporator fan motors for the freezer and the fresh food sections. The WR60X26866 is the fresh food evaporator fan motor — it's the axial fan located behind the rear panel of the fresh food compartment, not in the freezer. If your symptom is "freezer cold, fridge warm," this is the correct part. If your symptom is "freezer warm" or "ice maker not making ice but fridge is fine," the freezer evaporator fan motor (a different part number) is more likely the cause. Confirm which compartment has the cooling problem before ordering.
Is this an OEM or aftermarket part?
This is a Genuine OEM part manufactured by GE to factory specifications. It is the exact same axial evaporator fan motor installed in compatible GE, GE Café, and GE Profile French door refrigerators from the factory — guaranteed fit, materials, and performance.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Fast US Shipping ✓ Genuine OEM Parts ✓ Compatibility Support ✓ Secure Checkout
WR60X10318 Genuine OEM GE Refrigerator Evaporator Fan Motor
The WR60X10318 is a genuine GE OEM evaporator fan motor assembly used in side-by-side refrigerators, complete with an integrated 2-wire thermistor built right into its 6-pin wiring harness. This motor draws air across the evaporator coil and circulates it through both the fresh food and freezer compartments, while the built-in thermistor reports temperature back to the control board so it can regulate cooling accurately. Because the thermistor and fan motor arrive as a single assembly, a fault in either function shows up together, and replacing this one part addresses both.
The harness and plug measure approximately 13-7/8" in length. Common failure causes include worn motor bearings that eventually seize the shaft entirely, debris or ice buildup around the fan blade, and general electrical wear over time. On this side-by-side platform, a classic failure sequence is a bearing that starts out noisy, then progressively worsens until the motor freezes up completely — once the fan stops moving air, the evaporator coil often ices over heavily since moisture keeps accumulating with nowhere for the resulting cold air to go. Symptoms include unusual noise from the freezer, inconsistent or warm temperatures in either compartment, visible frost buildup on the coil, and a refrigerator that runs continuously trying to compensate. It directly replaces AP4981643, PS3487992, EAP3487992, and 1812462.
Quick Answer
The WR60X10318 Genuine OEM GE Refrigerator Evaporator Fan Motor fixes GE side-by-side refrigerators with unusual noise from the freezer, warm or inconsistent temperatures, frost or ice buildup on the evaporator coil, or a refrigerator running constantly. Complete assembly with integrated 2-wire thermistor on a 6-pin, 13-7/8" harness. Replaces AP4981643, PS3487992, EAP3487992, 1812462. Not the same part as our WR60X10307 or WR60X10185 listings — those are separate motors for different GE refrigerator platforms.
Common Problems This Part Fixes
Unusual noise — grinding, buzzing, or humming — coming from the freezer compartment
Inconsistent or warm temperatures in the fresh food or freezer compartment, or both
Visible frost or ice buildup on the evaporator coil
Refrigerator running continuously as it struggles to maintain temperature
Fan motor bearing noise that has progressively worsened, sometimes ending in the motor seizing entirely
Freezer icing over heavily while temperatures in both compartments climb
Fan blade that doesn't spin freely, or doesn't spin at all, when checked by hand
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This refrigerator evaporator fan motor directly replaces the following OEM and cross-reference part numbers:
WR60X10318, AP4981643, AGE29310, OEM14944938, PD00023381, PS3487992, EAP3487992, 1812462
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This evaporator fan motor is compatible with select GE side-by-side refrigerators, and also fits select Hotpoint, Haier, Monogram, Café, and Kenmore refrigerators built on the GE platform. In rare instances, this part is also referenced for compatibility with some LG models.
Note: GE uses several different evaporator fan motors across its refrigerator lineup. This WR60X10318 assembly is a separate part from our WR60X10307 and WR60X10185 listings, which serve different model platforms and have their own distinct cross-reference numbers. Always verify your full model number before ordering. Contact our support team with your model number if you're unsure which fan motor your refrigerator needs.
Key Features
Genuine GE OEM part — factory-specified motor, blade, and integrated thermistor design
Complete assembly — includes the fan motor plus a 2-wire thermistor built into the 6-pin harness
Resolves "unusual noise from the freezer," "warm or inconsistent temperatures," "frost or ice buildup," and "runs continuously" symptoms caused by fan motor failure
Approximately 13-7/8" harness and plug length
Direct drop-in replacement matching the original mounting and blade fitment
Replaces AP4981643, PS3487992, EAP3487992, and 1812462
Genuine OEM replacement — guaranteed fit, materials, and performance
DIY-friendly repair, though side-by-side units can have tight working clearance around the fan
Product Specifications
Part Number
WR60X10318
Part Type
Refrigerator Evaporator Fan Motor Assembly (with Thermistor)
Condition
Genuine OEM
Brand
GE
Application
Side-by-Side Refrigerators
Integrated Component
2-wire thermistor built into the wiring harness
Harness Connector
6-pin
Harness/Plug Length
Approx. 13-7/8 in.
Production Numbers
197D4964G011, FDQT26GE7
Quantity
1 fan motor assembly
Compatible Brands
GE, Hotpoint, Haier, Monogram, Café, Kenmore
Installation Notes
⚠️ Unplug Refrigerator Before Starting — Side-by-Side Units May Have Tight Clearance Disconnect power at the outlet before beginning, and move perishable food to a cooler for the duration of the repair. Wear work gloves. On side-by-side models, access can be tight: you may need to remove the rear interior panel, the ice maker, and a fan cover to reach the motor, so budget extra time and patience compared to a simpler platform. If the evaporator coil is heavily iced over, let the unit sit unplugged with the door open for several hours, or run a manual defrost, before continuing — ice can make the old motor difficult to remove cleanly and may be masking the actual point of failure. Photograph the 6-pin wiring harness connector and the fan blade's orientation before disconnecting anything. Remove the mounting screws holding the fan assembly in place, unplug the wiring harness connector, and slide the old assembly out of its housing. Slide the new WR60X10318 assembly into the same housing, secure it with the mounting screws, and reconnect the harness connector fully. Confirm the blade spins freely by hand without contacting the housing before reassembling the fan cover, ice maker, and rear panel. Restore power, open the door to test the fan, and monitor both compartments over the next 24 hours to confirm even, consistent cooling has returned. Tools needed: Phillips screwdriver, 1/4" and 5/16" nut drivers, work gloves, and a headlamp or flashlight for visibility in tight spaces.
Frequently Asked Questions
My freezer is heavily iced over and both compartments are warm. Is this the fan motor?
Yes, this is a very common failure sequence on this platform. Once the evaporator fan motor's bearings wear out and the motor slows or seizes, air stops circulating away from the coil, moisture keeps condensing on it, and ice builds up heavily. Once that happens, both the freezer and fresh food compartments typically lose cooling together, since neither is getting circulated cold air anymore. Thawing the ice and confirming the fan motor doesn't spin freely by hand will confirm this diagnosis.
Does this include the thermistor, or do I need to buy that separately?
It's included. This assembly ships with a 2-wire thermistor built directly into the 6-pin wiring harness, so you don't need to source or install a separate thermistor component — replacing this one part addresses both the fan motor and the thermistor together.
Why is access so tight on my side-by-side refrigerator?
Side-by-side refrigerators tend to pack components more tightly than French door or top-freezer models, and this evaporator fan often sits behind the ice maker and a dedicated fan cover in addition to the rear interior panel. Removing all of these takes more time than a simpler platform, but the fan motor itself installs the same straightforward way once you have access — a headlamp or flashlight helps considerably in the tighter space.
Is this an OEM or aftermarket part?
This is a genuine OEM part, manufactured by GE to factory specifications — guaranteed fit, materials, and performance. It includes the same motor design, fan blade, integrated thermistor, and 6-pin harness configuration as the evaporator fan motor assembly originally installed in your side-by-side refrigerator.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Genuine OEM Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
XPARTCO 4681JB1029D Refrigerator Condenser Fan Motor – Compatible with LG and Kenmore Refrigerators
Product Description
Keep your refrigerator running efficiently with the XPARTCO 4681JB1029D Refrigerator Condenser Fan Motor. This Condenser Fan Motor is a replacement part for specific LG, Kenmore refrigerator models. This motor is responsible for powering the fan that cools the condenser coils, which helps dissipate heat from the refrigerator. Proper functioning of the condenser fan motor is crucial for maintaining the efficiency and cooling performance of the refrigerator.
Replaces Part Numbers
4681JB1029D, EAU61644104, 4681JB1029Q, 1267566, AH3523330, EA3523330, PD00008709, AP4437783, PS3523330.
Compatibility
This replacement condenser fan motor fits select LG and Kenmore refrigerators.
Example compatible models include (but are not limited to): LG LFX25974ST, LG LFX28968ST, and Kenmore 795.71053.010.
Always verify your refrigerator’s model number before ordering. Contact our support team if you’re unsure.
✅ Key Features
🔄 Aftermarket Replacement – Designed to match OEM performance for LG refrigerators
🌬️ Reliable Airflow – Circulates air over coils to prevent overheating and improve efficiency
💰 Cost-Effective Fix – Quality replacement at a lower cost than OEM parts
🛠️ DIY Installation – Plug-and-play wiring connector for easy setup
🛡️ Fixes Common Issues – Solves overheating, loud operation, or poor cooling problems
📐 Product Specification
Part Number: 4681JB1029D
Component Type: Refrigerator Condenser Fan Motor Assembly
Material: Metal motor housing with plastic fan blade
Mounting: Direct-fit on rear compressor compartment bracket
Operating Conditions: Designed for continuous operation in refrigerator environments
Compliance: Built to OEM-equivalent quality standards (not OEM)
🛠️ Installation Notes
Tools Needed: Phillips screwdriver, nut driver, pliers
⚠️ Safety First: Always unplug the refrigerator before performing any repairs to prevent electrical shock.
Steps:
Disconnect power and pull refrigerator away from wall.
Remove the rear access panel to expose the condenser area.
Disconnect wiring harness and remove the old fan motor.
Mount the new 4681JB1029D motor using the same screws.
Reconnect the wiring harness and reinstall the rear panel.
Plug in the refrigerator and confirm proper fan operation.
⏱️ Time Required: 20–25 minutes
📦 Shop With Confidence
🚚 Free Shipping on All Orders
⚙️ Trusted Appliance Parts Supplier
🔄 30-Day Return Policy
Keep your refrigerator cool and efficient — Add to Cart Now for a reliable, budget-friendly replacement!
WR60X10209 Genuine OEM GE Refrigerator DC Condenser Fan Motor
The WR60X10209 is a Genuine OEM GE replacement DC condenser fan motor compatible with a wide range of GE, Hotpoint, RCA, Kenmore, Haier, Monogram, and Café refrigerators in the GSS, GSL, HSS, PSS, PSC, GCE, PCE, and related series. The condenser fan motor is located near the compressor at the rear bottom of the refrigerator. It circulates air across the condenser coils to dissipate heat from the hot refrigerant before it returns to the evaporator — this is an essential step in the refrigeration cycle. Without the condenser fan running, heat builds up around the compressor and condenser coils, causing the refrigerator to run continuously, cool inefficiently, or trip the compressor's thermal overload protection.
This Genuine OEM part is manufactured by GE to factory specifications. It is a DC voltage motor rated at 11.3V DC, 2.2W with a 4-pin plastic connector and four color-coded wires (white, blue, red, and yellow). It directly replaces WR60X10042, WR60X10053, WR60X10065, WR60X10080, WR60X10081, WR60X10155, WR60X10216, WR60X24483, WR60X10209-24PK, 1195784, AP4265957, AH1483567, EA1483567, and PS1483567. Installs in 15–30 minutes with basic hand tools.
Quick Answer
The WR60X10209 Genuine OEM GE Refrigerator DC Condenser Fan Motor fixes GE refrigerators that are not cooling properly, running continuously, making unusual noise from the back, or where the compressor is overheating. 11.3V DC, 2.2W, 4-pin connector (white/blue/red/yellow wires). Genuine OEM. Replaces WR60X10042, WR60X10053, WR60X10065, WR60X10080, WR60X10081, WR60X10155, WR60X10216, WR60X24483, AP4265957, PS1483567. Compatible with GE GSS, GSL, HSS, PSS, PSC, GCE, PCE series and Hotpoint, RCA, Kenmore, Haier, Monogram, Café.
Common Problems This Part Fixes
Refrigerator not cooling properly — condenser fan not circulating air across coils
Refrigerator running continuously without reaching set temperature
Compressor overheating — heat not being dissipated from condenser area
Unusual noise or grinding from the back or bottom of the refrigerator
Condenser fan motor visibly not spinning when compressor is running
Refrigerator cycling off frequently on thermal overload protection
Food spoilage — refrigerator unable to maintain safe temperatures
Replaces Part Numbers
This condenser fan motor directly replaces the following OEM and cross-reference part numbers:
WR60X10209, 1195784, WR60X10042, WR60X10053, WR60X10065, WR60X10080, WR60X10081, WR60X10155, WR60X10216, 045900390950, 197D2407P013, AGE29194, AH1483567, EA1483567, EAP1483567, AP4265957, PD00001176, PS1483567.
Contact our support team with your model number if you need confirmation before ordering.
Compatibility
This condenser fan motor is compatible with a wide range of refrigerators from the following GE product lines:
GE refrigerators — GSS series (GSS22, GSS23, GSS25, GSS26 and related side-by-side models)
GE refrigerators — GSL series (GSL22, GSL25 and related models)
GE refrigerators — GCE series (GCE21, GCE23 and related models)
GE refrigerators — PCE and PSS series (PCE23, PSS25, PSS26 and related Profile models)
GE refrigerators — PSC series (PSC23, PSC25 and related Profile models)
GE Monogram refrigerators — ZIS, ZISB series (select models)
GE Café refrigerators (select models)
Hotpoint refrigerators — HSS series (HSS22, HSS25 and related models)
RCA refrigerators (select GE-built models)
Kenmore / Sears refrigerators (select GE-built models)
Haier refrigerators (select GE-platform models)
Always verify your appliance model number before ordering. Contact our support team if you're unsure.
Key Features
Genuine OEM part manufactured by GE to factory specifications — guaranteed fit and performance
Circulates air across the condenser coils to dissipate heat from the refrigerant and maintain efficient refrigeration cycle operation
DC voltage motor rated at 11.3V DC, 2.2W — runs on DC voltage supplied by the refrigerator's control board
4-pin plastic connector with color-coded wires (white, blue, red, yellow) — direct plug-in installation on compatible models
Replaces WR60X10042, WR60X10053, WR60X10065, WR60X10080, WR60X10081, WR60X10155, WR60X10216, WR60X24483, and AP4265957
Compatible with GE GSS/GSL/GCE/PCE/PSS/PSC, Hotpoint HSS, Kenmore, Haier, Monogram, Café, and RCA refrigerators
DIY repair — installs in 15–30 minutes with basic hand tools
Product Specifications
Part Number
WR60X10209
Part Type
Refrigerator DC Condenser Fan Motor
Condition
Genuine OEM
Application
Refrigerators (side-by-side, French door, bottom-freezer)
Voltage
11.3V DC
Wattage
2.2W
Connector
4-pin plastic plug
Wire Colors
White, Blue, Red, Yellow
Location
Near compressor at rear bottom of refrigerator
Compatible Brands
GE, Hotpoint, RCA, Kenmore, Haier, Monogram, Café
Installation Notes
⚠️ Unplug Refrigerator Before Starting Unplug the refrigerator before beginning. Pull the refrigerator away from the wall to access the rear lower back panel. Remove the screws securing the back panel to expose the compressor, condenser coils, and condenser fan assembly. The condenser fan motor is mounted on a bracket near the compressor with the fan blade facing the condenser coil. Take a photo of the wire connector orientation before disconnecting. Disconnect the 4-pin wire connector from the motor. Remove the mounting screws securing the motor to the bracket and slide the old motor out. Note the orientation of the fan blade on the motor shaft — the blade must be reinstalled in the same direction on the new motor (or transferred from the old motor if the new motor does not include a blade). Install the new WR60X10209 motor, reconnect the wire connector, reinstall the back panel, restore power, and confirm the condenser fan spins when the compressor starts. Tools needed: Phillips screwdriver, 1/4" nut driver.
Frequently Asked Questions
What does the condenser fan motor do in a refrigerator?
The condenser fan motor drives a fan blade that circulates ambient air across the condenser coils at the rear of the refrigerator. The condenser coils carry hot high-pressure refrigerant that has just been compressed — the fan removes heat from the refrigerant so it can cool, condense, and return to the evaporator to absorb heat from inside the refrigerator. Without the condenser fan running, heat builds up around the compressor and coils, causing the refrigerator to lose cooling efficiency, run continuously, or — in severe cases — trip the compressor's thermal overload and shut down entirely.
Why does this motor use DC voltage instead of AC?
Modern GE refrigerators use DC motors for the condenser fan because they are more energy-efficient, quieter, and easier to speed-control by the refrigerator's electronic control board than traditional AC motors. The refrigerator's main control board converts household 120V AC power to 11.3V DC to supply the condenser fan motor. This DC motor runs at a variable speed under board control, which allows GE's refrigerators to optimize fan speed based on cooling demand.
How do I confirm the condenser fan motor has failed?
Pull the refrigerator away from the wall, unplug it, and remove the rear lower panel. Spin the condenser fan blade by hand — if it is stiff, wobbles, or seizes, the motor bearing has failed. If the blade spins freely but the motor does not run when the refrigerator is plugged in and the compressor starts, check for DC voltage at the motor connector using a multimeter. If the board is supplying approximately 11–12V DC to the motor but the motor is not running, the motor has failed electrically. If no voltage is present, the control board may not be supplying power — a less common but possible failure mode.
Does this motor come with the fan blade?
The WR60X10209 is the motor only — the fan blade is typically not included and should be transferred from the old motor. When removing the old motor, carefully pull the fan blade off the motor shaft (it presses on — no hardware is typically needed). Press the blade onto the new motor shaft in the same orientation. If the fan blade is cracked or damaged, it should be replaced separately. Installing the blade in the wrong direction will reverse the airflow direction and reduce cooling efficiency.
Is this a Genuine OEM or aftermarket part?
This is a Genuine OEM part manufactured by GE to factory specifications. It is the exact same DC condenser fan motor installed in compatible GE, Hotpoint, and related brand refrigerators from the factory — guaranteed fit, materials, and performance.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Genuine OEM Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
5304532557 Refrigerator Genuine Evaporator Motor
Replaces Part Numbers: 5304532557, 242077707, AP7194947, PS16745551.
Description: This Part is a Genuine OEM refrigerator evaporator fan motor compatible with specific Electrolux, Frigidaire refrigerator models. The fan motor is a vital component of your refrigerator. It is designed to maintain cold temperatures by circulating air through the fresh food compartments. By doing so, it ensures uniform cooling within the refrigerator. This helps to prevent warm spots that can lead to frost build-up.
WR60X10185 Genuine OEM GE Refrigerator Evaporator Fan Motor
The WR60X10185 is a genuine GE OEM evaporator fan motor located in the freezer compartment, for GE, Hotpoint, and select Kenmore, Haier, Monogram, and Café refrigerators. This motor pulls air across the evaporator coils to strip heat from it, then circulates that cold air through the freezer and, via ducting, to the fresh food compartment. This particular motor does not include a thermistor — it ships as a fan motor with a 4-wire harness on a 6-pin connector, with two of those six pin slots left empty. If your refrigerator's original connector has a white thermistor wire in it, or a separate connector for a freezer light, this is not the correct motor for your unit.
Rated 9.75V DC, 3.25W. A fan motor generally has a long service life, but it can burn out quickly if debris or ice buildup obstructs the blade and forces the motor to work against resistance it wasn't designed for. Common symptoms of a failing motor include unusual noise from the freezer, a fresh food compartment that's warmer than it should be while the freezer stays reasonably cold, frost or ice accumulating around the fan or coil, and a refrigerator that runs constantly trying to compensate for lost circulation. It directly replaces AP3875639, 1170107, 197D2039P007, 197D2039P008, PS1019114, EAP1019114, WR23X10346, WR23X10350, WR23X10353, WR23X10355, WR23X10364, WR23X10404, WR23X10405, WR23X10406, WR60X10043, WR60X10059, WR60X10068, WR60X10083, WR60X10084, WR60X10099, WR60X10149, WR60X10152, WR60X10154, and WR60X10157.
Quick Answer
The WR60X10185 Genuine OEM GE Refrigerator Evaporator Fan Motor fixes GE, Hotpoint, and select Kenmore refrigerators where the fresh food section runs warm while the freezer stays cold, there's unusual noise from the freezer, or frost is building up around the coil. 9.75V DC, 3.25W, 4-wire harness on a 6-pin connector (2 pins empty). Does NOT include a thermistor. Replaces AP3875639, 1170107, 197D2039P007, 197D2039P008, PS1019114, WR23X10353, WR23X10355, WR23X10364, WR60X10043, WR60X10154, and others listed below. If your old connector has a white thermistor wire, you need WR60X10074 instead; if it has a light connector, you need WR23X10467.
Common Problems This Part Fixes
Fresh food compartment running warmer than normal while the freezer stays reasonably cold
Unusual noise — humming, buzzing, or grinding — coming from the freezer
Freezer not cooling properly, which in turn affects compressor performance
Frost or ice buildup accumulating around the fan blade or evaporator coil
Refrigerator running continuously as it struggles to maintain temperature
Fan motor that has burned out due to an obstruction preventing the blade from turning
Fan blade that doesn't spin freely, or doesn't spin at all, when checked by hand
Cross Reference Information
Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item.
Replaces Part Numbers
This refrigerator evaporator fan motor directly replaces the following OEM and cross-reference part numbers:
WR60X10185, WR60X10043, WR60X10059, WR60X10068, WR60X10083, WR60X10084, WR60X10099, WR60X10149, WR60X10152, WR60X10154, WR60X10157, WR23X10346, WR23X10350, WR23X10353, WR23X10355, WR23X10364, WR23X10404, WR23X10405, WR23X10406, 197D2039P013, 1170107, UDQT26GE4, AP3875639, AGE29155, PD00000986, PS1019114, EAP1019114
If your part number is not listed above, contact our support team before ordering and we will verify compatibility.
Compatibility
This evaporator fan motor is compatible with select GE and Hotpoint refrigerators, and also fits select Kenmore, Haier, Monogram, and Café refrigerators built on the GE platform.
Note — check your connector before ordering: GE uses several different evaporator fan motor variants that look nearly identical, and choosing the wrong one means the connector or function won't match your refrigerator. This WR60X10185 motor has no thermistor and a plain 4-wire harness with 2 empty slots on its 6-pin connector. If your old motor's connector has a white thermistor wire in it, you need WR60X10074 instead (harness with integrated thermistor). If your old connector instead has a dedicated light connector, you need WR23X10467. This part is also a separate motor from our WR60X10318 listing, which is a side-by-side platform assembly with its own integrated thermistor and a longer harness. Always verify your full model number before ordering. Contact our support team with your model number if you're unsure which motor fits your refrigerator.
Key Features
Genuine GE OEM part — factory-specified motor and blade design
Pulls air across the evaporator coils and circulates it through the freezer and fresh food compartments
Resolves "fresh food warm while freezer stays cold," "unusual noise," and "frost buildup" symptoms caused by fan motor failure
Rated 9.75V DC, 3.25W
Includes the fan motor and 4-wire harness assembly (does not include thermistor)
Direct drop-in replacement matching the original mounting and blade fitment
Replaces a wide range of legacy WR23X and WR60X part numbers plus AP3875639 and PS1019114
Genuine OEM replacement — guaranteed fit, materials, and performance
Product Specifications
Part Number
WR60X10185
Part Type
Refrigerator Evaporator Fan Motor
Condition
Genuine OEM
Brand
GE
Location
Freezer compartment
Voltage
9.75V DC
Wattage
3.25 W
Harness
4-wire, 6-pin connector (2 pins unused)
Includes Thermistor
No
Quantity
1 fan motor
Compatible Brands
GE, Hotpoint, Kenmore, Haier, Monogram, Café
Installation Notes
⚠️ Unplug Refrigerator Before Starting — Check Your Connector Type First Disconnect power at the outlet before beginning, and move perishable food to a cooler for the duration of the repair. Wear work gloves. Before removing the old motor, look closely at its connector: confirm it's a plain 4-wire harness with no thermistor wire and no separate light connector, matching this replacement. Access is through the freezer's rear interior panel: remove shelving and bins as needed, then remove the screws securing the back panel to expose the evaporator coil and fan assembly. If there's significant frost or ice around the fan or coil, let the unit sit unplugged with the door open for a few hours, or run a manual defrost, before continuing. Photograph the wiring harness connector and the fan blade's orientation before disconnecting anything. Unplug the motor's wiring harness connector, remove the mounting screws or clips holding the motor bracket in place, and pull the motor and fan blade assembly free. Transfer the fan blade to the new motor if a blade isn't included, matching the original orientation. Mount the new WR60X10185 in the same position, reconnect the wiring harness connector fully, and confirm the blade spins freely by hand without contacting the housing before reassembling the back panel. Restore power and monitor both compartments over the next 24 hours to confirm even, consistent cooling has returned. Tools needed: Phillips screwdriver, nut driver, work gloves.
Frequently Asked Questions
How do I know if I need this motor or the one with the thermistor?
Look directly at your old motor's electrical connector before ordering. This WR60X10185 motor has a plain 4-wire harness on a 6-pin plug, with two of the six pin positions left empty — there's no thermistor wire involved. If your connector instead has a white thermistor wire running into it, you'll need WR60X10074, which includes an integrated thermistor and is not interchangeable with this motor. If your connector has a separate plug specifically for a freezer light, you'll need WR23X10467 instead.
My fresh food section is warm but the freezer seems fine. Is this the right part?
Yes, this is a very common and telling symptom pattern. The freezer sits right next to the evaporator coil and can stay reasonably cold through proximity even with weakening air circulation, but the fresh food compartment depends entirely on the fan pushing cold air through the ducting to reach it. When the fan motor fails or slows down, the fresh food side is usually the first and most noticeably affected area, and GE's own guidance confirms that a fresh-food-warm/freezer-fine pattern points to this fan.
Why would a fan motor "burn out quickly" instead of just wearing out slowly?
While this motor generally has a long service life, it can fail rapidly if something obstructs the fan blade from turning — commonly built-up frost or ice, or occasionally debris. When the blade can't turn freely, the motor works against resistance it wasn't designed for, which accelerates internal wear and can burn it out much faster than normal aging would. Clearing ice from around the fan before or during replacement helps prevent stressing the new motor the same way.
Is this an OEM or aftermarket part?
This is a genuine OEM part, manufactured by GE to factory specifications — guaranteed fit, materials, and performance. It matches the original 9.75V, 3.25W motor design, blade fitment, and 4-wire harness configuration of the fan motor originally installed in your refrigerator.
Shop With Confidence
A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase.
✓ Genuine OEM Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout
