Cooking Appliances Parts

XPARTCO XGR403 Gas Oven Round Igniter Replaces WB2X9154, 5304401265, 4342528 The XPARTCO XGR403 is a universal round-style oven igniter for gas ranges from GE, Hotpoint, Kenmore, RCA, Roper, Whirlpool, and Electrolux. This is a silicon carbide (carborundum) igniter, and it does double duty as both the spark source and the safety valve trigger: when the oven or broiler calls for heat, current flows through the igniter and it begins to glow. As it heats up, its electrical resistance drops, which increases the current draw through the circuit — and it's that rising current draw, not the glow itself, that eventually pulls in the gas safety valve and lets gas flow to be ignited by the now white-hot igniter tip. If the igniter can't draw enough current, the valve never opens, even though the igniter is clearly glowing. This is why a weakening round igniter produces such a specific and recognizable symptom: it glows, sometimes for well over a minute, but the oven or broiler never actually lights. GE's own service guidance puts a number on this — if the igniter glows for more than about 90 seconds without opening the valve, it no longer has enough draw to do its job and needs to be replaced. This igniter measures approximately 3-1/2" long, is rated 120V at 2.5–3.0A, and ships as a complete kit with a mounting bracket, ceramic wire nut connectors, and installation instructions. It directly replaces WB2X9154, 5304401265, 4342528, GR403, AR403, SGR403, WB13K10027, WB13K3, WB13K4, WB13K1, AP2014008, PS243425, 300259, 319887, 327617, 330689, 337263, 4336387, 4338008, 8053999, and WB00X6640. Quick Answer The XPARTCO XGR403 Gas Oven Round Igniter fixes GE, Hotpoint, Kenmore, RCA, Roper, Whirlpool, and Electrolux gas ranges where the oven or broiler igniter glows but the burner never lights, or the oven doesn't heat at all. Round-style silicon carbide igniter, 3-1/2" long, 120V, 2.5–3.0A. Complete kit with mounting bracket and ceramic wire nuts. Replaces WB2X9154, 5304401265, 4342528, GR403, AR403, SGR403, WB13K10027, WB13K3, WB13K4, WB13K1, AP2014008, PS243425. Round style only — this igniter will NOT replace a flat-style (hot surface) igniter. Common Problems This Part Fixes Oven or broiler igniter glows but the burner never lights Igniter glows for 90 seconds or longer with no ignition — a strong sign it's too weak to open the gas valve Oven doesn't heat at all despite the igniter appearing to glow normally Gas smell near the igniter without ignition — igniter drawing insufficient current to trip the valve Igniter that used to glow bright orange now glows dim or dull Visible cracks, chips, or a broken tip on the ceramic-bodied igniter Intermittent ignition — sometimes lights, sometimes doesn't Igniter that doesn't glow at all — may indicate the igniter or its wiring has failed completely Cross Reference Information Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item. Replaces Part Numbers This gas oven round igniter directly replaces the following OEM and cross-reference part numbers: 5304401265, 08007988, 235030, 5308007988, 638543, 7954, 8007988, 9360, A00P235030, A00P235230, A1505523, A1505786, AH470557, AP00235030, AP235027, AP235030, DAP235030, EA470557, P235030, AP2592228, PS470557, Q000198333, WB2X9154, 1990, 300259, 319887, 327617, 330689, 337263, 4336387, 4338008, AH243425, EA243425, AP2014008, PS243425, WB00X6640, WB02X9154, WB13K0001, WB13K0003, WB13K0004, WB13K01, WB13K04, WB13K1, WB13K10027, WB13K3, WB13K4, 4342528,  300259, 3196447, 321342, 327617, 337263, 337389, 337390, 3422, 4157446, 4322910, 4332948, 4338008, 4338037, 4342528VP, 4389493, 8053999, AH360921, EA360921, F16-569, GR403, K16866, PS360921, AP3104565, SGR403. If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This round-style igniter is a universal replacement compatible with select gas ranges, ovens, and broilers from the following brands: GE and Hotpoint gas ranges (select models using a round XL44-style igniter) Kenmore and RCA gas ranges (select GE-built models) Roper gas ranges (select models) Whirlpool gas ranges (select models) Electrolux gas ranges (select models) Note — round style only, and it may be a bake OR broil igniter: This is a round-style igniter and will NOT replace a flat-style (hot surface) igniter used on other gas range platforms — the two are not interchangeable. Additionally, many gas ranges use a round igniter for both the bake and broil burners; some models use different igniters for each, so confirm whether the failing igniter is for the bake or broil compartment before ordering. Always verify your full model number and igniter style before ordering. Contact our support team with your model number if you're unsure. Key Features Universal aftermarket replacement round-style oven igniter — fits a wide range of GE, Hotpoint, Kenmore, RCA, Roper, Whirlpool, and Electrolux gas ranges Silicon carbide (carborundum) construction glows and draws current to trigger the gas safety valve Resolves "igniter glows but won't light," "oven not heating," and "intermittent ignition" symptoms caused by a weakening igniter Approximately 3-1/2" long, rated 120V at 2.5–3.0A Complete kit — includes mounting bracket, ceramic wire nut connectors, and installation instructions UL listed for safety compliance Replaces WB2X9154, 5304401265, 4342528, GR403, AR403, SGR403, WB13K10027, WB13K3, WB13K4, WB13K1, AP2014008, PS243425, 300259, 319887, 327617, 330689, 337263, 4336387, 4338008, 8053999, and WB00X6640 Aftermarket replacement built to OEM-equivalent quality standards Product Specifications Part Number XGR403 OEM Part Number WB2X9154 Part Type Gas Oven Round Igniter (Bake / Broil) Condition Aftermarket Replacement Style Round (not compatible with flat-style igniters) Material Silicon carbide (carborundum) Length Approx. 3-1/2 in. Voltage 120V Amperage 2.5–3.0 A Kit Contents Igniter, mounting bracket, ceramic wire nuts, instructions Certification UL listed Quantity 1 igniter Compatible Brands GE, Hotpoint, Kenmore, RCA, Roper, Whirlpool, Electrolux Installation Notes ⚠️ Danger — Gas Appliance Turn off the gas supply to the range at the shutoff valve and unplug the range (or shut off its circuit breaker) before beginning. After reassembly, check every disturbed gas connection for leaks using a soapy water solution — bubbling indicates a leak. If you ever smell gas at any point during this repair, do not attempt to light the range or operate any switches; leave the area immediately and contact your gas utility or a qualified technician. ⚠️ Fragile — Handle By The Bracket Only Wear work gloves. Remove the oven racks and, if replacing the broil igniter, the broiler pan and floor panel as needed to access the igniter assembly, typically located at the front of the burner tube. Photograph the wiring connections before disconnecting anything. This igniter is extremely fragile — the ceramic body and silicon carbide tip can crack from a light bump or from skin oils weakening the material over time, so handle it only by the metal mounting bracket, never by the ceramic body itself. Disconnect the wire leads at the ceramic wire nut splices (or the terminal connector, depending on your model), then remove the mounting screw and lift the old igniter free. Position the new XGR403 in the same location and orientation relative to the burner tube — proper alignment matters, since the igniter needs to sit close enough to reliably ignite the gas once the valve opens. Secure the mounting bracket, then reconnect the wire leads using the included ceramic wire nuts, twisting them securely and confirming no bare wire is exposed. Restore the gas supply and power, then test the burner and check for leaks at any connection you touched. Watch the igniter glow through a full ignition cycle to confirm the burner lights well within 90 seconds. Tools needed: Phillips or flat-blade screwdriver (model-dependent), soapy water for leak testing, work gloves. Frequently Asked Questions My igniter glows bright orange but the oven never lights. Is this the right part? Yes, this is the single most common symptom of a failing round igniter. As the igniter ages, its silicon carbide element degrades and can no longer draw enough current to trip open the gas safety valve, even though it still glows. A well-known rule of thumb: if the igniter is glowing for more than about 90 seconds without the burner lighting, it has lost the current draw needed to do its job, and replacement is the correct fix. Can I use this for both the bake and broil igniter? On many GE-platform ranges, yes — the same round igniter design serves both the bake and broil burner positions. However, some model platforms use different igniters for bake versus broil, so before ordering, confirm which compartment's igniter has failed and verify your specific model number to make sure this is the correct igniter for that position. Will this fit my flat-style igniter oven? No. This is a round-style (carborundum rod) igniter and is not interchangeable with a flat-style (hot surface) igniter used on other gas range platforms — the mounting, shape, and electrical characteristics are different. Check the shape of your original igniter before ordering: a round igniter looks like a short ceramic rod or cylinder, while a flat igniter has a thin, flat ceramic element. The igniter doesn't glow at all. Is it definitely the igniter itself? Not necessarily. A round igniter that doesn't glow at all can also point to a wiring problem, a failed connection at the ceramic wire nut splice, or in some cases a bad oven control board sending no signal to the igniter circuit. Check that the wiring is intact and securely connected before assuming the igniter itself has failed completely — a partial glow that just won't sustain, versus zero glow whatsoever, can point you toward different causes. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine brand-specific OEM part, but is manufactured to match the round silicon carbide design, 120V/2.5–3.0A electrical rating, and mounting configuration of the OEM igniters (including WB2X9154) used in compatible GE, Hotpoint, Kenmore, RCA, Roper, Whirlpool, and Electrolux gas ranges. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Quality Aftermarket Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout

Read more less

WB24T10029 Genuine OEM GE Range Surface Burner Control Switch The WB24T10029 is a genuine GE OEM surface burner control switch — also called an infinite switch — for the 6-inch surface element on GE, Hotpoint, and select Kenmore electric ranges and cooktops. This switch is what the burner knob actually turns: it doesn't have fixed positions like a light switch, but instead cycles the element's power on and off at varying ratios as you rotate the knob, which is why it's called an "infinite" switch — it lets you dial in a continuous range of heat levels rather than a handful of fixed steps. Turn the knob to a low setting and the switch feeds the element power only briefly out of every few seconds; turn it toward high and the element stays powered for most of that same window. This switch is rated for 1,500 watts and controls a 6-inch surface element, drawing 4.4–7.4A at 240V. Over years of use the internal contacts wear, pit, or weld from repeated on/off cycling, and moisture from boilovers or spills can corrode the switch body and cause it to short internally. A worn switch produces predictable symptoms: the burner won't turn on or off at all, it sticks at one heat level no matter where the knob is turned, or it works only intermittently. It directly replaces 769696, AP2024076, AH236754, EA236754, and PS236754. As a genuine OEM part, the WB24T10029 is manufactured by GE to factory specifications — guaranteed fit, materials, and performance. Quick Answer The WB24T10029 Genuine OEM GE Range Surface Burner Control Switch fixes GE, Hotpoint, and Kenmore electric ranges where a surface burner won't turn on or off, stays at one heat level regardless of the knob setting, or works intermittently. This is the 6-inch element switch — 1,500W, 4.4–7.4A at 240V. Replaces 769696, AP2024076, AH236754, EA236754, PS236754. Not the same switch as the WB24T10025 used on the 8-inch element — check which burner is affected before ordering. Common Problems This Part Fixes Surface burner won't turn on at all when the knob is turned Burner won't turn off — stays hot even with the knob at the off position Burner stuck at one heat level regardless of where the knob is set No ability to adjust temperature — always full blast or always low Intermittent burner operation — works sometimes, not others Burner cycles unpredictably, on and off faster or slower than the knob setting suggests Knob feels loose, gritty, or doesn't click through its normal range of motion Burner failure that followed a boilover or liquid spill on the control panel Cross Reference Information Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item. Replaces Part Numbers This range surface burner control switch directly replaces the following OEM and cross-reference part numbers: WB24T10029, 769696, AP2024076, AH236754, EA236754, EAP236754, AGE22522, PD00008555, PS236754 If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This surface burner control switch is compatible with select GE, Hotpoint, and Kenmore electric ranges and cooktops using a 6-inch surface element, across a very wide range of model families, including: GE JB, JBP, JCBP, and JBS series electric ranges GE RB and RA series electric ranges Hotpoint RB series electric ranges (select GE-built models) Select Kenmore electric ranges built on the GE platform This switch fits several thousand model variants across GE's electric range lineup, including common families such as JB250, JB350, JB500, JB600 through JB870, JBP10 through JBP99, JCBP35 through JCBP85, JBS07, JBS27, JBS55, JBS60, JBS86, RA724, RB536, RB540, RB560, RB585, RB720, RB740, RB757, RB758, RB787, RB790, RB798, and RB800 — each spanning many color and revision suffixes. Because the model list is extremely long, always verify your full model number against your range's data label, located inside the storage drawer or along the back panel, before ordering. Note — 6-inch element switch only: GE ranges typically pair a smaller 6-inch element with a larger 8-inch element, and each uses its own dedicated infinite switch. The WB24T10029 is the switch for the 6-inch element. The larger 8-inch element on the same range uses the separate WB24T10025 switch (replaces 769692, AP2024072, AH236750, EA236750, PS236750) instead. The two switches look nearly identical and are easy to mix up when ordering — before you buy, confirm which specific burner has failed and measure or check the element size. Contact our support team with your model number if you're unsure which switch you need. Key Features Genuine GE OEM part — factory-specified contact design and heat-cycling calibration Infinite switch design allows continuous heat adjustment rather than a handful of fixed positions Rated for the 6-inch surface element — 1,500 watts, 4.4–7.4A at 240V Resolves "burner won't turn on," "burner won't turn off," "stuck at one heat level," and "intermittent operation" symptoms caused by worn or corroded switch contacts Direct drop-in replacement — mounts to the same control panel bracket and wiring harness Replaces 769696, AP2024076, AH236754, EA236754, and PS236754 Compatible with a wide range of GE, Hotpoint, and Kenmore electric range models Genuine OEM replacement — guaranteed fit, materials, and performance Product Specifications Part Number WB24T10029 Part Type Range Surface Burner Control Switch (Infinite Switch) Condition Genuine OEM Brand GE Element Size Controlled 6 in. Wattage Rating 1,500 W Amperage 4.4–7.4 A Voltage 240V Function Cycles element power to allow continuous (infinite) heat adjustment Mounting Control panel bracket, knob shaft, and wiring harness terminals Quantity 1 switch Compatible Brands GE, Hotpoint, select Kenmore Installation Notes ⚠️ 240V Circuit — Unplug Range Or Shut Off Breaker Before Starting Disconnect power at the outlet or shut off the circuit breaker before beginning — this switch operates on a 240V circuit, and working on it while powered presents a serious shock hazard. Wear work gloves. Access is from the front of the control panel: remove the burner knob (it typically pulls straight off, though some models use a small retaining clip or screw), then remove the screws securing the control panel or backsplash to reach the switch from behind. Photograph the wiring before disconnecting anything — this switch has multiple terminals and getting one out of order will affect either the wrong burner or its heat-cycling behavior. Disconnect the wire terminals from the old switch, noting or labeling each one, then remove the mounting screws or clips holding the switch to the panel and pull it free. Install the new WB24T10029 in the same orientation, reconnect each wire terminal exactly as labeled, and secure the mounting hardware. Reinstall the control panel or backsplash, press the knob back onto the shaft, restore power, and test the burner through its full range from low to high to confirm smooth, continuous heat adjustment. Tools needed: Phillips screwdriver, nut driver, wire terminal pliers (helpful but optional), work gloves. Frequently Asked Questions How do I know if I need the WB24T10029 or the WB24T10025? It depends entirely on which burner has failed. Most GE ranges pair a smaller 6-inch element with a larger 8-inch element, and each has its own dedicated infinite switch. The WB24T10029 is for the 6-inch element; the WB24T10025 is for the 8-inch element. Look at your range and identify which specific burner is misbehaving, then measure that element's diameter if you're not sure — the two switches are not interchangeable even though they look nearly identical side by side. What does "infinite switch" mean, and why does mine only work at one setting? An infinite switch lets you dial in a continuous range of heat rather than a few fixed positions, by rapidly cycling the element's power on and off at a ratio set by the knob — low settings get short power pulses, high settings get long ones. When the internal contacts wear or weld together from years of cycling, the switch can get stuck feeding constant power (burner always hot) or stop switching at all (burner always off), regardless of where the knob is turned. That "stuck at one heat level" complaint is the classic symptom of a failing infinite switch. A spill got into the control panel and now the burner won't turn off. Is that the switch? Very likely, yes. Liquid boilovers and spills are one of the most common causes of infinite switch failure — moisture gets into the switch body, corrodes or bridges the internal contacts, and the switch can end up stuck feeding power continuously even with the knob turned to off. If you suspect this, shut off power to the range immediately at the breaker rather than relying on the knob, since a shorted switch may not respond to it at all. My burner works but only at high heat no matter where I turn the knob. Could it be something else? The infinite switch is the most common cause, but it's worth a quick visual check first. Make sure the knob itself is properly seated on its shaft — a knob that's been pushed on at the wrong angle, or whose shaft has worn round, can make it feel like the switch isn't responding even though it is. If the knob is properly seated and turns smoothly through its full range but the heat output doesn't change, the switch's internal contacts have failed and replacement is the correct fix. Is this an OEM or aftermarket part? This is a genuine OEM part, manufactured by GE to factory specifications — guaranteed fit, materials, and performance. It matches the original 1,500W, 4.4–7.4A, 240V electrical rating and the heat-cycling behavior of the infinite switch originally installed for the 6-inch element in your GE, Hotpoint, or Kenmore range. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Genuine OEM Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout

Read more less

Genuine OEM GE Range Hood Part WB26X30785 Range Hood Genuine OEM Blower Motor Assembly A complete manufacturer-approved blower assembly designed to circulate air and help remove cooking grease, smoke, steam, and odors from the kitchen. Product Overview The GE WB26X30785 Range Hood Blower Motor Assembly is the main air-moving component inside compatible range hoods. When the hood fan is switched on, the motor turns the blower wheel to pull air through the filters and move smoke, steam, grease, and cooking odors through the venting system or recirculation path. This is a new Genuine OEM GE replacement part manufactured to the original equipment specifications. The assembly includes the blower motor and blower wheel, helping provide a more complete repair than replacing an individual motor component alone. Quick Answer WB26X30785 is a Genuine OEM GE range hood blower motor assembly that includes the motor and blower wheel. It replaces previous GE part number WB26X27202 and is used in select GE range hood models. Always verify your complete appliance model number before ordering. Common Problems This Part May Fix Range hood fan does not run Blower starts intermittently or stops during use Weak or reduced airflow Smoke and cooking odors are not being removed properly Grinding, rattling, humming, or scraping noise from the blower area Blower wheel is damaged, loose, or difficult to turn Replaces Part Numbers WB26X30785, WB26X27202, AGE22285, AP6880846, EAP12716502, PD00066165, PS12716502. WB26X30785 is the current manufacturer part number. Cross-reference numbers are included only to help identify the same component; order by your appliance model whenever possible. Compatibility Designed for select GE range hood models that specify part number WB26X30785 or the superseded number WB26X27202. Confirmed model examples include: JVX5300EJ1ES JVX5300SJ2SS JVX5360DJ2WW JVX5360EJ2ES JVX5360SJ2SS Important: This is a partial compatibility list. Range hood parts can look alike while using different mounting points, wiring connectors, motor ratings, or blower-wheel designs. Verify the complete model number from the hood identification label before purchasing. Key Features Genuine OEM GE replacement part Complete blower motor and blower wheel assembly Moves air through the range hood ventilation system Helps remove grease, smoke, steam, and cooking odors Manufactured for original fit and performance Direct replacement when WB26X30785 is specified Supersedes GE part number WB26X27202 Product Specifications Manufacturer Part Number WB26X30785 Brand GE Appliances Part Type Range Hood Blower Motor Assembly Condition New Quality Genuine OEM Application Range Hood / Vent Hood Assembly Includes Blower Motor and Blower Wheel Primary Function Circulates air through the hood ventilation system Package Quantity 1 Blower Motor Assembly Installation Notes Disconnect the range hood from electrical power or switch off the correct house circuit breaker before beginning service. Remove the grease filters and any covers needed to access the blower compartment. Photograph or label the wire connections before disconnecting the original motor assembly. Inspect the wiring harness, connector, capacitor, mounting hardware, and vent path for additional damage or blockage. Remove the old blower assembly and install WB26X30785 in the same position, using the original hardware when required. Confirm that the blower wheel turns freely and does not contact the housing before reassembling the hood. Restore power only after all covers, filters, and safety components are correctly reinstalled. Safety: Electrical diagnosis and installation should be performed by a qualified technician when you are not experienced with appliance repair. Do not work on the hood while power is connected. Frequently Asked Questions Is WB26X30785 a genuine GE part? Yes. WB26X30785 is a Genuine OEM GE Appliances replacement blower motor assembly. What is included with the assembly? The assembly includes the blower motor and blower wheel used to move air through the range hood. Which part number does WB26X30785 replace? WB26X30785 replaces the previous GE manufacturer part number WB26X27202. Will this part fit every GE range hood? No. It fits only select models. Compare your complete range hood model number and required manufacturer part number before ordering. Can this assembly fix a noisy range hood? It may correct noise caused by a worn motor, damaged blower wheel, loose shaft, or internal blower failure. First check the filters, ductwork, mounting hardware, and blower housing for obstructions or loose components. Shop With Confidence Purchase the correct Genuine OEM replacement part for dependable fit and performance. Verify your complete range hood model number before ordering, and contact our parts team when compatibility assistance is needed. Genuine OEM GE Fast U.S. Shipping Compatibility Support Secure Checkout

Read more less

DG94-01496A Genuine OEM Samsung Gas Cooktop Valve Assembly The DG94-01496A is a Genuine OEM Samsung replacement gas cooktop auxiliary valve assembly compatible with select Samsung gas cooktops in the NA30K, NA30N, NA36K, and related series. The valve assembly is the mechanical component that connects the burner knob to the gas supply manifold — when you turn the knob, the valve precisely regulates the flow of gas to the burner, controlling the flame size from low simmer to high heat. Without a properly functioning valve, the burner can fail to light, stay lit, shut off when turned, or stick in position making the knob unable to turn. This is the auxiliary (single-flow) burner valve, used in burner positions that have a single flame ring. Samsung cooktops typically use multiple valve assemblies — one per burner position — and the center burner (dual-flame) uses a different dual valve assembly. As a Genuine OEM part manufactured by Samsung to factory specifications, the DG94-01496A directly replaces AP6049694, EAP12072702, PD00052726, and PS12072702. Important: this is a gas appliance part — installation requires shutting off the gas supply, working safely with gas connections, and leak-testing after installation. Installs in 45–60 minutes with basic hand tools by experienced DIYers, or call a qualified appliance technician. Quick Answer The DG94-01496A Genuine OEM Samsung Gas Cooktop Valve Assembly fixes Samsung gas cooktops with a burner that won't light, won't shut off, where the knob is stuck or won't turn, or where flame size won't adjust properly. Auxiliary (single-flow) burner valve. Genuine OEM. Replaces AP6049694, EAP12072702, PD00052726, PS12072702. Compatible with Samsung NA30K6550TG/AA, NA30K6550TS/AA, NA30N6555TG/AA, NA36K6550TG/AA, NA36K7750TG/AA and related gas cooktops. Center (dual-flame) burner uses a different valve — confirm which burner position before ordering. Common Problems This Part Fixes Burner won't light — gas not flowing through the valve to the burner Burner won't shut off — valve stuck open, gas continuing to flow even with the knob turned to "OFF" Knob stuck and won't turn — valve internally seized (often caused by water entering during cleaning) Burner flame size won't adjust — valve unable to modulate gas flow Flame too high even on low setting — valve not restricting flow properly Flame too low or weak on high setting — valve partially blocked Gas smell at the cooktop or burner area — valve seal failure Difficulty turning the knob — internal valve corrosion or wear Replaces Part Numbers This gas cooktop valve assembly directly replaces the following OEM and cross-reference part numbers: AP6049694, ASM116044, EAP12072702, PD00052726, PS12072702. Contact our support team with your model number if you need confirmation before ordering. Compatibility This valve assembly is compatible with select Samsung gas cooktops, including: Samsung gas cooktops — NA30K6550TG/AA-00, NA30K6550TS/AA-00 series Samsung gas cooktops — NA30N6555TG/AA-00 series Samsung gas cooktops — NA36K6550TG/AA-00, NA36K7750TG/AA-00 series Other Samsung gas cooktops in the NA-series using compatible auxiliary burner valves Important — Confirm the Burner Position Before Ordering: Samsung gas cooktops use multiple valve assemblies — typically one per burner position. The DG94-01496A is the auxiliary (single-flow) burner valve. The center dual-flame burner uses a different valve assembly, and other burner positions may also have position-specific part numbers. Before ordering, verify in your cooktop's parts diagram that DG94-01496A is listed for the specific burner position you're replacing, or compare the old valve's part number markings to the new one. Contact our support team with your model number if you're unsure. Key Features Genuine OEM part manufactured by Samsung to factory specifications — guaranteed fit and performance Auxiliary (single-flow) burner valve assembly — controls gas flow to one burner position on compatible Samsung gas cooktops Restores smooth knob action and precise flame size adjustment from simmer to high heat Replaces a stuck, leaking, or failed original valve Replaces AP6049694, EAP12072702, PD00052726, and PS12072702 Compatible with Samsung NA30K, NA30N, NA36K series gas cooktops For experienced DIYers or qualified appliance technicians — gas appliance work requires safety precautions and leak testing Installation typically takes 45–60 minutes with basic hand tools Product Specifications Part Number DG94-01496A Part Type Gas Cooktop Valve Assembly (Auxiliary / Single-Flow Burner) Condition Genuine OEM Application Gas Cooktops (Samsung NA-series) Valve Type Auxiliary (single-flow) burner valve Note Center dual-flame burner uses a different valve assembly Compatible Brands Samsung Installation Notes ⚠️ Gas Appliance Safety Warning This part is installed in a gas cooktop. Always shut off the gas supply at the shutoff valve before beginning any repair, and disconnect electrical power to the cooktop. After installation is complete, ALL gas connections must be checked for leaks using a soap-and-water solution or an approved gas leak detector before restoring full gas service. If you smell gas at any point during or after installation, leave the area immediately and contact your gas utility provider. If you are not comfortable working with gas connections, have this repair done by a qualified appliance technician. Improper installation of gas components can cause fire, explosion, or carbon monoxide hazards. ⚠️ Wear Work Gloves — Significant Disassembly Required Shut off the gas supply at the shutoff valve and disconnect electrical power. Wear work gloves to protect your hands. Remove the burner caps, burner heads, and grates from the cooktop surface. The valve assembly is accessed by removing the cooktop top surface — this typically involves removing 16–20 screws around the perimeter of the cooktop to lift the top free. Photograph everything as you go, including the gas line routing and electrical wire connections. Once the top is off, locate the specific valve being replaced (confirm against the parts diagram and the burner position). Disconnect the gas line from the valve (use two wrenches — one to hold the manifold, one to turn the nut — to avoid stressing the manifold). Disconnect any electrical connections to the valve (spark ignitor wires) and remove the valve's mounting hardware. Install the new DG94-01496A valve in the same position with the same orientation, reconnect the gas line and any electrical connections, and secure the mounting hardware. Reinstall the cooktop top, burner heads, caps, and grates. Before restoring full gas service, turn on the gas at the shutoff valve and use a soap-and-water solution or gas leak detector on all gas connections to confirm there are no leaks. Restore electrical power and test the burner by lighting it and confirming smooth flame control across the full range of the knob. Tools needed: Phillips screwdriver, set of wrenches (two needed at each gas connection), gas leak detector or soap solution, work gloves. Frequently Asked Questions Why is my burner knob stuck and won't turn? A stuck burner knob is one of the most common symptoms of a failed valve assembly on Samsung gas cooktops — and one frequent root cause is water entering the valve during knob cleaning. When the knobs are washed (especially with soap and water) and water enters the valve through the knob shaft, it can rust the internal valve mechanism, causing the knob to seize. Once the valve is internally corroded, no amount of force on the knob will free it without risking damage — replacing the valve is the correct repair. To prevent recurrence on the remaining valves: clean knobs by wiping them in place rather than removing and submerging them, and dry the knob shaft area carefully before reinstalling. Does this fit all five burners on my Samsung cooktop? Not necessarily. Samsung gas cooktops typically use multiple valve assemblies — the surrounding burner positions (front-left, front-right, rear-left, rear-right) use auxiliary single-flow valves like the DG94-01496A, while the center burner is typically a dual-flame burner that uses a different dual-valve assembly. If you're replacing valves on more than one burner, confirm which position each valve is needed for and verify the part numbers in your specific model's parts diagram. The valves often look similar but are not interchangeable across positions. Can I do this repair myself, or should I hire a technician? Replacing a gas valve is a manageable DIY repair for someone comfortable with mechanical work, but it does involve disconnecting and reconnecting gas connections — which means leak testing is mandatory and any error can have serious safety consequences. If you have experience with plumbing or gas appliance work and you're confident in your ability to make tight, leak-free connections and properly test them, this is a feasible DIY. If you've never worked with gas connections before, hiring a qualified appliance technician (typical cost $200–$400) is the safer option. The PartsDr customer story mentioned that a quote from a service technician was $750 for this repair, so the DIY savings are substantial — but only if done safely. My cooktop has more than one stuck or failed valve — should I replace them all at once? If multiple valves have failed at the same time, it's worth considering. Once the cooktop top is off, all valves are accessible — replacing additional valves only adds 5–10 minutes per valve. Since the valves are exposed to the same age, use, and potential water intrusion, multiple valve failures often indicate the others are heading the same way. However, valve part numbers may differ by burner position (the center dual-flame valve is different from the auxiliary single-flow valves) — make sure you order the correct valve for each specific position. Is this a Genuine OEM or aftermarket part? This is a Genuine OEM part manufactured by Samsung to factory specifications. It is the exact same gas cooktop valve assembly installed in compatible Samsung gas cooktops from the factory — guaranteed fit, materials, and performance. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Genuine OEM Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout

Read more less

XPARTCO W11590294 Gas Oven Igniter The XPARTCO W11590294 is an aftermarket replacement flat-style silicon carbide gas oven igniter compatible with select Whirlpool, Amana, Maytag, KitchenAid, Crosley, Jenn-Air, Magic Chef, Admiral, Norge, Roper, and Kenmore gas ranges in the WFG, AGR, VRGW, and related series. The oven igniter is a silicon carbide heating element mounted next to the oven burner tube. When a bake or broil cycle is started, the igniter draws electrical current through the gas safety valve, which holds the valve open — and simultaneously heats to ignition temperature to light the gas. The igniter must draw at least 3.2 amps to hold the gas valve fully open; as the silicon carbide element ages and weakens, it draws progressively less current, causing the oven to take too long to light, not light at all, or glow without ever opening the gas valve. This flat-style igniter is rated 3.3–3.6 amps at 120V and measures approximately 4" wide x 1" high. It features a silicon carbide element, high-temperature ceramic housing, and metal bracket. The current part number W11590294 directly supersedes W11208965, W11613927, and W11506321 — all four are the same igniter across successive production revisions. It also replaces 4977065, AP7193166, PS16744629, and EAP16744629. Pre-attached wire connectors included. Note: do not touch the silicon carbide element with bare hands — skin oils cause premature burnout. Installs in 15–30 minutes with basic hand tools. Quick Answer The XPARTCO W11590294 Gas Oven Igniter fixes Whirlpool-family gas ovens that won't heat, where the igniter glows but the burner never lights, or where preheat takes too long. Flat silicon carbide igniter, 3.3–3.6A, 120V, approx. 4"W x 1"H. Do not touch element with bare hands. Replaces W11208965, W11613927, W11506321, 4977065, AP7193166, PS16744629. Compatible with Whirlpool WFG320/WFG505, Amana AGR4203/AGR6303, Crosley VRGW, Maytag, KitchenAid, and more. Common Problems This Part Fixes Oven not heating — igniter not reaching operating temperature or gas valve not opening Igniter glows orange or red but the oven burner never lights Oven takes more than 90 seconds to ignite — igniter too weak to fully open the gas valve Oven preheats very slowly — weakened igniter limiting gas valve opening Gas smell when oven is turned on but burner does not light Igniter visibly cracked, broken, or burned out Bake or broil function not working on compatible models Replaces Part Numbers This oven igniter directly replaces the following OEM and cross-reference part numbers: W11590294, W11208965, W11506321, W11613927, AP7193166, AWP45526, EAP16744629, PD00083398, PS16744629. W11590294 is the current production part number superseding W11208965, W11613927, and W11506321 — all four are the same igniter. If your parts diagram shows any of these numbers, this replacement is correct. Contact our support team with your model number if you need confirmation before ordering. Compatibility This oven igniter is compatible with select gas ranges and ovens from the following brands and series: Whirlpool gas ranges — WFG320 series (WFG320M0MB0, WFG320M0MS0, WFG320M0MW0 and related models) Whirlpool gas ranges — WFG505 series (WFG505M0BS4, WFG505M0BW3, WFG505M0MB0, WFG505M0MS0, WFG505M0MW0 and related models) Amana gas ranges — AGR4203 series (AGR4203MNB0, AGR4203MNW0 and related models) Amana gas ranges — AGR6303 series (AGR6303MMB0, AGR6303MMW0 and related models) Crosley gas ranges — VRGW series (VRGW3150RB0, VRGW3150RW0, VRGW3162RB0, VRGW3162RS0, VRGW3162RW0 and related models) Maytag gas ranges (select models) KitchenAid gas ranges (select models) Jenn-Air gas ranges (select models) Magic Chef, Admiral, Norge, Roper, and Kenmore gas ranges (select models) Always verify your appliance model number before ordering. Contact our support team if you're unsure. Key Features Flat-style silicon carbide oven igniter — heats to ignition temperature and draws current through the gas safety valve to hold it open so gas can flow to the burner Draws 3.3–3.6 amps at 120V — correct amperage range to reliably open the oven gas safety valve on compatible models Dimensions: approximately 4" wide x 1" high Silicon carbide element, high-temperature ceramic housing, metal mounting bracket Pre-attached wire connectors included — direct plug-in installation on compatible models Current production part superseding W11208965, W11613927, and W11506321 Do not touch the silicon carbide element with bare hands — skin oils cause premature burnout Compatible with Whirlpool WFG320/WFG505, Amana AGR4203/AGR6303, Crosley VRGW, Maytag, KitchenAid, and related brands Aftermarket replacement built to OEM-equivalent quality standards DIY repair — installs in 15–30 minutes with basic hand tools Product Specifications Part Number XPW11590294 Supersedes W11208965, W11613927, W11506321 Part Type Gas Oven Flat Igniter (Hot Surface Igniter) Condition Aftermarket Replacement Application Gas Ranges and Ovens Igniter Style Flat silicon carbide element Amperage Draw 3.3 – 3.6 Amps Voltage 120V AC Dimensions Approximately 4" W x 1" H Material Silicon carbide / Ceramic / Metal / Plastic Color White / Silver Connector Pre-attached wire connectors Handling Note Do not touch element — skin oils cause premature burnout Compatible Brands Whirlpool, Amana, Maytag, KitchenAid, Crosley, Jenn-Air, Magic Chef, Admiral, Norge, Roper, Kenmore Installation Notes ⚠️ Gas Appliance Safety Warning This part is installed in a gas range. Always unplug the range and shut off the gas supply at the shutoff valve before beginning any repair. If you smell gas at any point during or after installation, leave the area immediately and contact your gas utility provider. Do not restore power or gas until the repair is fully complete and all connections are confirmed secure. ⚠️ Handle With Care — Do Not Touch the Igniter Element The silicon carbide igniter element is fragile and sensitive to skin oils. Handle only by the bracket and wiring — never touch the silicon carbide element itself. To install: unplug the range and shut off gas. Remove the oven racks and oven bottom panel to expose the burner assembly. Locate the old igniter mounted next to the oven burner tube. Disconnect the igniter's wire connectors and remove the two mounting screws securing the bracket. Note the wire routing inside the range cavity before removing — be careful not to let the burner wires fall back into the range body. Connect the new W11590294 igniter's pre-attached connectors to the matching wires from the range. Mount the new igniter in the same position with the two bracket screws. Reinstall the oven bottom panel and racks. Restore gas and power, then run a bake cycle and confirm the igniter glows and the burner lights within 60–90 seconds. Tools needed: Phillips screwdriver, work gloves. Frequently Asked Questions What is the relationship between W11590294, W11208965, W11613927, and W11506321? These are all part numbers for the same gas oven igniter across successive production revisions by Whirlpool. W11506321 was an earlier version, W11613927 and W11208965 were subsequent updates, and W11590294 is the current production number. All four are the same flat silicon carbide igniter with the same specifications, dimensions, and function. If your range's parts diagram or old igniter shows any of these numbers, this replacement covers all of them. My oven igniter glows but the burner never lights — is this the right part? Yes — an igniter that glows but fails to light the burner is the most common symptom of a weakened igniter. The gas safety valve requires at least 3.2 amps of current draw through the igniter to hold it open. As the silicon carbide element ages, it draws less current — eventually reaching a point where it glows visibly but no longer draws enough current to fully open the gas valve. If the igniter glows for more than 90 seconds without the burner lighting, it needs replacement. The W11590294 is rated 3.3–3.6 amps, which is the correct range to reliably activate the safety valve on compatible models. What is the difference between W11590294 and W11176454? Both are flat silicon carbide oven igniters for Whirlpool-family gas ranges, but for different model series. The W11590294 is used on the WFG320, WFG505, and related entry-level Whirlpool and Amana gas ranges. The W11176454 (which replaces W10914411) is used on higher-end Whirlpool, Amana, and Maytag models across a broader range of WFG, MGR, and related series. They have the same amperage rating and igniter style but are not always interchangeable — always verify your model number before ordering to confirm which igniter is correct for your range. How do I test if the oven igniter has failed? The most practical test is observation: if the igniter glows for more than 90 seconds without the burner lighting, the igniter is too weak. For a more precise test, use a multimeter in resistance mode — disconnect the igniter and measure resistance across the element. A working W11590294-style igniter typically reads between 40–100 ohms at room temperature. An open circuit (infinite resistance) means the element has burned through completely. You can also test in operation by measuring current draw at the igniter circuit — a reading below 3.2 amps indicates the igniter is too weak to reliably open the gas valve. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is manufactured from silicon carbide, ceramic, metal, and plastic to match the amperage draw, dimensions, and performance of the original W11590294 gas oven igniter. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout

Read more less

XPARTCO PB04001 Oven Bake Igniter for Viking Replaces 065650-000 The XPARTCO PB04001 is an aftermarket replacement oven bake igniter compatible with select Viking gas ranges with hot surface ignition systems, including the CVDSC, EVGIC, EVGRT, VDSC, VGIC, VGRT, VGSC, VGSS, and VGGT series. The oven bake igniter is a flat glow bar hot surface igniter — it draws electrical current through the oven's gas safety valve to open it, then heats to ignition temperature to light the gas burner. When the igniter weakens or fails, the oven will not heat, will take too long to reach temperature, or the igniter will glow but the burner will never light. This is a silicon carbide flat-style igniter with a 2.25-inch white ceramic body and 4.5-inch overall length. Wire leads extend approximately 12.5 inches from the igniter body with female insulated terminals for plug-in installation. Ceramic wire nuts for spliced installation are included. Rated 3.2–3.6 amps at 120V AC — the correct amperage range to open the Viking oven gas safety valve. It directly replaces 065650-000, PB040001, 792263, AP5315579, AP7180264, SGR4001, SGR40001, GR40001, RP712, and AR402. Sold individually. Installs in 15–25 minutes with basic hand tools. Quick Answer The XPARTCO PB04001 Oven Bake Igniter fixes Viking gas ranges where the oven won't heat, takes too long to preheat, or the igniter glows but the burner never lights. Flat silicon carbide glow bar, 3.2–3.6A, 120V AC. Ceramic body 2.25", overall 4.5", leads 12.5" with female terminals. Ceramic wire nuts included. Sold individually. Compatible with Viking CVDSC, EVGIC, EVGRT, VDSC, VGIC, VGRT, VGSC, VGSS, VGGT series. Replaces 065650-000, PB040001, 792263, AP5315579, AP7180264, SGR4001. Common Problems This Part Fixes Oven not heating at all — igniter has failed or burned out Oven takes much longer than normal to preheat Igniter glows orange but the gas burner never lights Gas smell when oven is turned on but burner does not light Oven heats on first use but fails to relight during subsequent heat cycles Igniter visibly cracked, broken, or dark/charred at the ends Oven baking inconsistently or shutting off heat mid-cycle Replaces Part Numbers This oven igniter directly replaces the following OEM and cross-reference part numbers: 065650-000, AP7180264, PB040001, PB04001, 792263, SGR40001, GR40001, RP712, AR402 If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This oven igniter is compatible with select Viking gas ranges with hot surface ignition (glow bar) systems, including the following series: Viking CVDSC series — CVDSC365-4G, CVDSC485-6G and related models Viking EVGIC series — EVGIC305, EVGIC365, EVGIC485 and related models Viking EVGRT series — EVGRT360, EVGRT480, EVGRT600 and related models Viking VDSC series — VDSC365, VDSC367, VDSC485, VDSC487 and related models Viking VGIC series — VGIC245, VGIC245G, VGIC245K, VGIC245Q, VGIC305, VGIC367 and related models Viking VGSC series — VGSC300, VGSC305 and related models Viking VGSS series — VGSS300, VGSS480 and related models Viking VGRT and VGGT series — VGRT360, VGGT240 and related models Note: This igniter is for Viking ranges with hot surface (glow bar) ignition systems only. Not all Viking ranges use this style of igniter — verify your model number before ordering. Always verify compatibility before purchasing. Key Features Flat glow bar hot surface igniter — draws current through the oven gas safety valve to open it, then heats to ignition temperature to light the oven burner Silicon carbide construction — superior heat resistance, reaches 1,800°F–3,100°F operating temperature in approximately 60 seconds Draws 3.2–3.6 amps at 120V AC — correct amperage range to open the Viking oven gas safety valve Ceramic body: 2.25 inches; overall length: 4.5 inches; wire leads: approximately 12.5 inches with female insulated terminals Plug-in installation with female terminals; ceramic wire nuts included for spliced installation if needed Sold individually — one igniter per order Replaces 065650-000, PB040001, 792263, AP5315579, AP7180264, SGR4001, and more Fragile silicon carbide element — handle only by the bracket and wires; never touch the ceramic body with bare hands Aftermarket replacement built to OEM-equivalent quality standards DIY repair — installs in 15–25 minutes with basic hand tools Product Specifications Part Number PB04001 Also Known As PB040001 Part Type Gas Oven Bake Igniter (Flat Glow Bar Hot Surface Igniter) Condition Aftermarket Replacement Application Viking Gas Ranges with Hot Surface Ignition Igniter Style Flat glow bar, silicon carbide Amperage Draw 3.2 – 3.6 Amps Voltage 120V AC Operating Temperature 1,800°F – 3,100°F (approximately 60-second heat-up) Ceramic Body Length 2.25 inches Overall Length 4.5 inches Lead Length Approximately 12.5 inches (female insulated terminals) Includes Igniter and ceramic wire nuts Sold As Single igniter Compatible Brands Viking Installation Notes ⚠️ Gas Appliance Safety Warning This part is used in gas ranges. Always shut off the gas supply at the shutoff valve and unplug the range from the electrical outlet before beginning any repair. If you smell gas at any point during or after installation, leave the area immediately and contact your gas utility provider. If you are not confident working on gas appliances, have this part installed by a qualified appliance technician. ⚠️ Handle With Extreme Care — Fragile Silicon Carbide Element The silicon carbide igniter element is extremely fragile and will crack or break with minimal force. Never touch the ceramic bar with bare hands — oils from skin will damage the element and cause premature failure. Handle only by the bracket, wires, and ceramic wire nut connectors. To install: unplug the range and shut off gas. Remove the oven racks and oven bottom panel. Disconnect the old igniter's wire connector (or cut wires if splicing). Unscrew the mounting bracket from the burner assembly and remove the old igniter. Position the new PB04001 igniter on the burner bracket and secure with the mounting screws. If the female terminals plug directly into the existing wiring, connect them. If wires need to be spliced, use the included ceramic wire nuts — never use standard plastic wire nuts near the oven burner. Reinstall the oven bottom panel and racks. Restore gas and power, then run a test cycle to confirm the igniter heats and the burner lights within 60 seconds. Tools needed: Phillips screwdriver, work gloves. Frequently Asked Questions How does a hot surface igniter work on a Viking gas oven? The hot surface igniter is wired in series with the oven's gas safety valve. When the oven is turned on, electrical current flows through the igniter, heating the silicon carbide element until it reaches ignition temperature — typically glowing bright orange. As the element heats, its electrical resistance changes and the current draw increases to 3.2–3.6 amps. At that amperage level, the gas safety valve opens and gas flows to the burner, where the glowing igniter ignites it. If the igniter weakens and can no longer draw enough current to open the safety valve, the oven will glow but the burner will never fire — this is the most common cause of a Viking oven not heating. What is the difference between PB04001 and PB040001? PB04001 and PB040001 are the same oven igniter — PB04001 is the shortened version of the PB040001 part number. Both refer to the same flat silicon carbide glow bar igniter used on compatible Viking gas ranges. This listing covers both designations and the part functions identically regardless of which number is referenced. How do I know if my oven igniter has failed? The most common sign is an oven that glows orange but the burner never lights. A healthy igniter glows bright orange and ignites the burner within about 60 seconds. If it glows dimly, stays on indefinitely without the burner lighting, or does not glow at all when the oven is turned on, the igniter has failed. You can also test with a multimeter — with the oven cold and unplugged, a working igniter shows resistance of approximately 40–90 ohms; an open circuit confirms failure. Visually inspect the element for cracks, dark spots, or a broken ceramic bar. Why must I use ceramic wire nuts instead of standard plastic ones? Standard plastic wire nuts are not rated for the temperatures inside an oven cavity — they will melt or degrade near the burner, exposing bare wires and creating a safety hazard. Ceramic wire nuts (included with this igniter) are heat-rated for oven burner temperatures and provide a safe, permanent connection when splicing is required. Always use only ceramic wire nuts for any wiring connections near the oven burner. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Viking OEM part, but is manufactured from silicon carbide and high-temperature materials to match the electrical specifications and dimensions of the original 065650-000 oven bake igniter. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout

Read more less

WP74010750 Genuine OEM Whirlpool Oven Bake Element The WP74010750 is a Genuine OEM Whirlpool replacement oven bake element compatible with select Whirlpool, Jenn-Air, Maytag, KitchenAid, Amana, Kenmore, Magic Chef, Admiral, Norge, and Roper electric ranges and ovens — particularly CE-series, JDS-series, and MES-series slide-in and freestanding ranges. The bake element is the lower heating element located at the bottom of the oven cavity. It provides the primary heat source for baking, roasting, and preheating. When the element coil burns through, the oven will not heat, will bake unevenly, or will trip the circuit breaker when the bake cycle is selected. This Genuine OEM part is manufactured by Whirlpool to factory specifications and is rated at 2585W with push-on terminal ends (two 1/4" high-temp connectors). It measures approximately 23-5/8" wide x 15-3/8" long with 3-3/8" inserts. It directly replaces 74010750, 74003039, 7406P425-60, 1184162, WP74010750VP, ERB0750, AP6011209, PS11744404, and several additional cross-reference numbers. Installs in 15–20 minutes with basic hand tools. Quick Answer The WP74010750 Genuine OEM Whirlpool Oven Bake Element fixes electric ovens that won't heat, bake unevenly, or trip the circuit breaker during bake. 2585W, push-on terminal ends (two 1/4" high-temp connectors), 23-5/8"W x 15-3/8"L, 3-3/8" inserts. Genuine OEM. Compatible with Whirlpool CE, Jenn-Air JDS, Maytag MES series and related brands. Replaces 74010750, 74003039, 7406P425-60, 1184162, ERB0750, AP6011209, PS11744404. Common Problems This Part Fixes Oven produces no heat — bake element coil has burned through Oven takes much longer than normal to preheat Food baking unevenly — bottom of food undercooked while top is done Bake element not glowing red during the bake cycle Visible burn marks, blistering, holes, or breaks in the element coil Oven trips the circuit breaker when the bake cycle is selected — shorted element Burning smell during a bake cycle — arcing at a weak point in the element Replaces Part Numbers This bake element directly replaces the following OEM and cross-reference part numbers: WP74010750, 74010750, 1184162, 74003039, 7406P425-60, AP6011209, AWP47950, EAP11744404, PD00002565, PS11744404, WP74010750VP. Contact our support team with your model number if you need confirmation before ordering. Compatibility This bake element is compatible with select electric ranges and ovens from the following brands and series: Whirlpool electric ranges — CE35200, CE38800 and related CE-series models Jenn-Air electric ranges — JDS8850, JDS9860 and related JDS-series slide-in models Maytag electric ranges — MES5770 and related MES-series models KitchenAid electric ranges (select models) Amana electric ranges (select models) Kenmore / Sears electric ranges (select Whirlpool-built models) Magic Chef electric ranges (select models) Admiral electric ranges Norge electric ranges Roper electric ranges Note: Always verify your exact model number before ordering — bake elements are model-specific due to differences in dimensions and terminal configuration. The WP74010750 uses 1/4" push-on terminals and specific mounting dimensions that differ from other Whirlpool-family bake elements. If you are not sure this element is the right fit, contact our support team with your model number. Key Features Genuine OEM part manufactured by Whirlpool to factory specifications — guaranteed fit and performance Primary heat source for baking, roasting, and preheating in compatible electric ovens Rated 2585W — correct wattage for compatible CE, JDS, and MES series models Push-on terminal ends — two 1/4" high-temperature connectors for direct wire attachment Dimensions: approximately 23-5/8" wide x 15-3/8" long, with 3-3/8" inserts Replaces 74010750, 74003039, 7406P425-60, 1184162, ERB0750, and AP6011209 Compatible with Whirlpool, Jenn-Air, Maytag, KitchenAid, Amana, Kenmore, Magic Chef, Admiral, Norge, and Roper electric ranges DIY repair — installs in 15–20 minutes with basic hand tools Product Specifications Part Number WP74010750 Part Type Oven Bake Element (Lower Heating Element) Condition Genuine OEM Application Electric Ranges and Ovens Wattage 2585W Terminal Type Push-on — two 1/4" high-temperature connectors Width Approximately 23-5/8 inches Length Approximately 15-3/8 inches Inserts 3-3/8 inches Compatible Brands Whirlpool, Jenn-Air, Maytag, KitchenAid, Amana, Kenmore, Magic Chef, Admiral, Norge, Roper Installation Notes ⚠️ Unplug Range or Turn Off Breaker Before Starting Disconnect power before beginning and allow the oven to cool completely. Open the oven door and remove all racks. The bake element is located at the bottom of the oven cavity. Remove the screws securing the element bracket to the rear oven wall — typically one or two Phillips screws at the back. Carefully pull the element forward toward the door to expose the two 1/4" push-on wire connectors behind the oven rear wall. Note the position of each wire before disconnecting — take a photo. Pull each wire connector off the element terminals by gripping the connector (not the wire) and pulling straight back. Connect the two wires to the new WP74010750 element's terminals, slide the element back into position, and secure the mounting screws. Restore power and run a bake cycle to confirm the element heats and glows red. Tools needed: Phillips screwdriver. Frequently Asked Questions How do I know if my bake element has failed? The clearest sign is an oven that does not heat, takes much longer than usual to preheat, or bakes food unevenly with the bottom undercooked. When the bake element is working, it should glow bright red during a bake cycle. If it does not glow at all, the element has failed. You can also visually inspect the element for burn marks, blistering, cracks, or a visible break in the coil. A multimeter continuity test will confirm failure — a working element shows continuity (resistance of approximately 10–100 ohms), while a failed element reads open circuit. If the element trips the circuit breaker when selected, the element coil has shorted to the metal housing — replace it immediately. What is the difference between WP74010750 and WP74003019? Both are Genuine OEM Whirlpool oven bake elements but for different model families and with different wattage ratings. The WP74010750 is rated 2585W and is used on CE, JDS, and MES-series electric ranges. The WP74003019 is rated 2800W and is used on a different set of models. They are not interchangeable — always verify your model number to confirm which element is correct for your oven before ordering. Is it normal for a bake element to arc or spark before it fully fails? Yes — it is not unusual for a bake element to arc or spark at a weak spot before the coil fully burns through. If you see sparking, arcing, or a bright flash from the element area, immediately turn off the oven and disconnect power. Do not use the oven again until the element has been replaced. An arcing element can damage the oven liner and, in rare cases, pose a fire risk. The good news is that once you replace the WP74010750 element, the oven should perform normally again. Are the wires interchangeable on the bake element terminals? On most electric range bake elements — including the WP74010750 — the two terminal wires are interchangeable. The bake element is a resistance heater with no polarity, so either wire can connect to either terminal and the element will heat correctly. However, it is good practice to photograph the original connection before disconnecting to ensure you reconnect in the same configuration, particularly if one wire is color-coded differently from the other. Is this a Genuine OEM or aftermarket part? This is a Genuine OEM part manufactured by Whirlpool to factory specifications. It is the exact same bake element installed in compatible Whirlpool, Jenn-Air, Maytag, and related brand electric ranges from the factory — guaranteed fit, materials, and performance. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Genuine OEM Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout

Read more less

XPARTCO W11366438 Range Surface Burner Knob Product Overview The XPARTCO W11366438 Range Surface Burner Knob is designed to control the heat level of your stove burners with precision. This high-quality replacement knob restores smooth operation and enhances the appearance of your cooktop. Quick Answer If your stove knob is cracked, loose, missing, or difficult to turn, the W11366438 burner knob is likely worn out. Replacing it restores proper burner control and usability. Replaces Part Numbers Replaces OEM part number: W11366438, W11084623, 4929319, W11359382, W11505414, EAP12723935, AWP44385, PD00054489, AP6888134, PS12723935. Compatibility This surface burner knob is compatible with select Whirlpool, Maytag, and other compatible ranges. Whirlpool Ranges Maytag Ranges Always verify your appliance model number before ordering. Common Problems This Part Fixes Broken or cracked knob Knob slipping or not engaging Missing control knob Difficulty adjusting burner heat Key Features Restores precise burner control Easy push-on installation High-quality aftermarket replacement Durable construction for daily use Product Specifications Part Number: XPW11366438 Part Type: Range Surface Burner Knob Brand: XPARTCO Condition: New OEM / Aftermarket: Aftermarket Application: Range Burner Control Troubleshooting Guide Knob spins freely → Worn insert Cannot adjust flame → Damaged knob Knob falls off → Cracked fitting When Should You Replace This Knob? Replace this knob if it is cracked, loose, missing, or not functioning properly. Installation Notes ⚠️ Ensure the appliance is off. Pull the old knob straight off and push the new knob firmly onto the control shaft. Related Parts Surface Burner Valve Igniter Switch Control Panel Overlay Frequently Asked Questions Will this knob fit my range?This knob fits many Whirlpool and compatible models. Always verify your model number. Is installation difficult?No, this knob is typically push-on and easy to install. What are signs of a bad knob?Cracks, slipping, or inability to control heat settings. Is this OEM or aftermarket?This is a high-quality aftermarket replacement part. Shop With Confidence Parts-O-Matic is a U.S.-based appliance parts retailer specializing in OEM and high-quality replacement parts. We offer fast shipping, reliable products, and expert support. Fast Shipping Quality Tested Parts Compatibility Support

Read more less

XPARTCO W11176454 Gas Range Oven Igniter The XPARTCO W11176454 is an aftermarket replacement oven burner igniter compatible with select Whirlpool, Maytag, and Amana gas ranges. The igniter is a hot surface igniter made from silicon carbide that draws electrical current through the oven safety valve to open it, then heats to ignition temperature to light the gas burner. When the igniter weakens or fails, the oven will not heat, will take too long to preheat, or the igniter will glow without lighting the burner. This igniter draws 3.3–3.6 amps at 120V AC and reaches operating temperatures of 1,800°F–3,100°F with a heating time of approximately 17 seconds. The igniter body measures 3-7/10 inches (Length A) with 9-1/2 inch leads and two separate connectors. It directly replaces OEM part numbers W11176454 and W10914411, and is compatible with Whirlpool WFG and WFG505 series, Amana AGR and AGG series, and select Maytag gas range models. Installs in 10–20 minutes with basic hand tools. Quick Answer The XPARTCO W11176454 Gas Range Oven Igniter fixes Whirlpool, Maytag, and Amana gas ovens that won't heat, take too long to preheat, or have an igniter that glows but never lights the burner. Silicon carbide construction. Draws 3.3–3.6A at 120V. Igniter body 3-7/10" with 9-1/2" leads and 2 separate connectors. Replaces W10914411. Common Problems This Part Fixes Oven not heating at all — gas is not igniting Oven takes excessively long to preheat (weak igniter not reaching ignition temperature) Igniter glows orange or red but never lights the gas burner Smell of gas when oven is turned on but burner does not light Oven heats inconsistently or shuts off mid-cycle Clicking sounds from the oven without successful ignition Oven element will not heat despite other components functioning normally Replaces Part Numbers This oven igniter directly replaces the following OEM and cross-reference part numbers: W11176454, 4547416, W10914411, EAP12348439, AWP43029, PD00044759, AP6327293, PS12348439. If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This igniter is compatible with select gas ranges from the following brands: Whirlpool gas ranges — WFG320 and WFG505 series (freestanding) Amana gas ranges — AGR and AGG series Maytag gas ranges — select AGR series models Always verify your model number before ordering. Contact our support team if you're unsure. Key Features Hot surface igniter — draws current through the oven safety valve to open it, then ignites the gas burner Silicon carbide construction — superior heat resistance vs. standard ceramic igniters Draws 3.3–3.6 amps at 120V AC — correct range to open the Whirlpool gas safety valve Operating temperature: 1,800°F – 3,100°F with approximately 17-second heat-up time Igniter body length: 3-7/10 inches; lead length: 9-1/2 inches Two separate connectors for easy plug-in installation Directly replaces W11176454 and W10914411 — no modification required Aftermarket replacement built to OEM-equivalent quality standards Quick DIY repair — installs in 10–20 minutes with a screwdriver Product Specifications Part Number W11176454 Also Replaces W10914411 Part Type Oven Burner Igniter (Hot Surface Igniter) Condition Aftermarket Replacement Application Gas Ranges and Ovens Material Silicon Carbide Amperage Draw 3.3 – 3.6 Amps Voltage 120V AC Resistance 40 – 800 Ohms Operating Temperature 1,800°F – 3,100°F Heat-Up Time Approximately 17 seconds Igniter Body Length (A) 3-7/10 inches Lead Length 9-1/2 inches Connectors 2 separate connectors Compatible Brands Whirlpool, Amana, Maytag Installation Notes ⚠️ Gas Appliance Safety Warning This part is used in gas ranges. Working with gas appliances carries risk of gas leaks, fire, and explosion if installed incorrectly. Always shut off the gas supply at the shutoff valve and unplug the range before beginning any repair. If you smell gas at any point during or after installation, leave the area immediately and contact your gas utility provider. If you are not confident working on gas appliances, have this part installed by a qualified appliance technician. ⚠️ Installation Instructions Unplug the range and shut off the gas supply before beginning. Open the oven door and remove the oven racks. Lift and remove the oven bottom panel by unscrewing the retaining screws. Remove the heat shield (if present) to expose the burner and igniter assembly. Unscrew the igniter mounting screws — typically one or two — and carefully disconnect the wire connector. Connect the new W11176454 igniter to the wire harness using the two separate connectors, secure it to the burner bracket with the mounting screws, then reinstall the heat shield and oven bottom panel. Restore gas supply and power and run a test cycle to confirm the oven lights correctly. Important: Do not touch the silicon carbide igniter element with bare hands — oils from skin reduce its lifespan. Handle only by the bracket and leads. Tools needed: Phillips screwdriver, work gloves. Frequently Asked Questions What is the difference between W11176454 and W10914411? The W11176454 is the updated part number that directly supersedes the older W10914411. Both are the same hot surface igniter for compatible Whirlpool, Amana, and Maytag gas ranges. This aftermarket replacement is compatible with both part numbers. How do I know if my oven igniter needs to be replaced? The most common signs are the oven not heating at all, taking much longer than usual to preheat, or the igniter glowing orange but never lighting the burner. A working igniter reaches ignition temperature within about 30–90 seconds and glows bright orange. If it glows dimly or stays on indefinitely without the burner lighting, the igniter has weakened and is no longer drawing enough current to open the gas safety valve. Why does my igniter glow but the oven still won't heat? This is the classic symptom of a weak igniter. The gas safety valve requires a minimum amperage draw — typically around 3.2 amps — to open and allow gas to flow to the burner. As the igniter ages, its resistance increases and amperage drops below this threshold. The igniter still glows because it has some current, but not enough to open the valve. Replacing the igniter resolves this in nearly all cases. Is the W11176454 compatible with my Amana or Maytag range? Yes — the W11176454 is compatible with select Amana AGR and AGG series gas ranges and select Maytag AGR series models in addition to Whirlpool WFG320 and WFG505 series ranges. Always verify your specific model number before ordering to confirm compatibility. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Whirlpool OEM part, but is made from silicon carbide to match the electrical specifications and performance of the original W11176454 igniter. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Fast US Shipping ✓ Quality Aftermarket Parts ✓ Compatibility Support ✓ Secure Checkout

Read more less

XPARTCO 8273103 Gas Range Burner Knob (Black) – Replaces WP8273103 – Compatible with Whirlpool, Maytag & KitchenAid Ranges Product Description Restore smooth and precise burner control with the XPARTCO 8273103 Gas Range Burner Knob (Black). This high-quality aftermarket replacement knob fits securely onto the burner control shaft, allowing accurate flame adjustment from low to high heat settings. A cracked, loose, or broken knob can make it difficult to regulate temperature or safely turn the burner off. Replacing it with this durable XPARTCO knob restores proper control and enhances everyday cooking convenience. XPARTCO provides cost-effective aftermarket appliance parts engineered to match original fit and function. Replaces Part Numbers WP8273103, 8273103, 8273107, 8273111, 831219, WP8273103VP, ER8273103, PD00005537, EAP393678, AP6012363, PS11745570. Compatibility This replacement gas range burner knob fits select Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, and Kenmore (Whirlpool-manufactured) gas ranges. Common compatible models include (but are not limited to): Whirlpool WFG320M0BS Maytag MGR6600FZ KitchenAid KFGG500ESS Always verify your range’s model number before ordering.Contact our support team if you’re unsure. ✅ Key Features 🔄 Aftermarket Replacement – Matches OEM fit and appearance 🔥 Precise Flame Control – Smooth adjustment from simmer to high heat 🧩 Direct Push-On Fit – Secure installation onto control shaft 💪 Durable Plastic Construction – Built for daily kitchen use 🎨 Black Finish – Matches original style 💰 Cost-Effective Repair – Affordable alternative to OEM knobs 📐 Product Specification Part Number: 8273103 Component Type: Gas Range Burner Control Knob Material: High-strength molded plastic Color: Black Mounting: Push-on / shaft-fit Application: Gas range surface burner control Quality Level: Aftermarket replacement (not OEM) 🛠️ Installation Notes Tools Needed: None ⚠️ Safety First: Ensure all burners are turned off and cool before installing the knob. Basic Steps: Confirm burner control is in the OFF position. Align the new XPARTCO 8273103 knob with the control shaft. Press firmly until fully seated. Rotate to verify smooth operation and proper engagement. ⏱️ Time Required: Under 2 minutes 📦 Shop With Confidence 🚚 Free Shipping on All Orders ⚙️ Trusted Aftermarket Appliance Parts 🔄 30-Day Return Policy Restore safe, precise burner control in seconds — Add to Cart Now for a quick, budget-friendly fix!

Read more less

WPW10411934 Range Genuine OEM Surface Element Switch – Compatible with Whirlpool, Maytag & KitchenAid Ranges Product Description Restore precise burner temperature control with the WPW10411934 Range Genuine OEM Surface Element Switch. This Genuine OEM switch is engineered by the original manufacturer to control the heat output of electric surface elements. A faulty surface element switch can cause burners to stay on high, not heat at all, or cycle inconsistently. Replacing it with this authentic OEM part ensures proper electrical performance, safe operation, and factory-level reliability. This part is a Genuine OEM component, manufactured to exact specifications for fit, durability, and long-term performance. Replaces Part Numbers WPW10411934, W10411934, 4446483, PD00033778, EAP11754410, AP6021089, PS11754410. Compatibility This Genuine OEM surface element switch fits select Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, and Kenmore (Whirlpool-manufactured) electric ranges. Common compatible models include (but are not limited to): Whirlpool WFE515S0ES Maytag MER8800FZ KitchenAid KERA205PB Always verify your range’s model number before ordering.Contact our support team if you’re unsure. ✅ Key Features 🏭 Genuine OEM Part – Manufactured to original factory specifications 🔥 Accurate Heat Regulation – Restores proper burner temperature control ⚡ Safe Electrical Operation – Designed for correct voltage and load handling 🎛️ Smooth Adjustment – Ensures responsive burner control 🔧 Exact Fit & Direct Replacement – No modifications required 📐 Product Specification Part Number: WPW10411934 Component Type: Surface Element Control Switch Voltage: 240V Application: Electric range surface burner control Mounting: Shaft-mounted behind control panel OEM Status: Genuine OEM 🛠️ Installation Notes Tools Needed: Phillips screwdriver, nut driver ⚠️ Safety First: Disconnect power at the breaker before servicing the range to avoid electrical shock. Basic Steps: Turn off power to the range at the breaker. Remove the control knob and access the control panel. Label and disconnect wires from the old switch. Remove mounting screws and remove the old switch. Install the new WPW10411934 Genuine OEM switch. Reconnect wiring, reassemble the control panel, and restore power. Test burner operation. ⏱️ Time Required: 20–30 minutes 📦 Shop With Confidence 🏭 Genuine OEM Appliance Part 🚚 Free Shipping on All Orders 🔄 30-Day Return Policy Restore factory-level burner control and safe cooking performance — Add to Cart Now with confidence!

Read more less

XPARTCO AEZ73293801 Cooktop Burner Control Knob – Compatible with LG & Kenmore Cooktops Product Description Restore smooth, precise burner control with the XPARTCO AEZ73293801 Cooktop Burner Control Knob. This high-quality aftermarket replacement knob fits securely onto the burner control shaft, allowing accurate flame adjustment and dependable operation. A cracked, loose, or missing knob can make it difficult to control heat or safely operate your cooktop. Replacing it with this durable XPARTCO knob restores proper functionality and everyday cooking convenience. XPARTCO is a trusted aftermarket brand offering appliance replacement parts built to OEM-equivalent specifications at a cost-effective price. Replaces Part Numbers AEZ73293801, EBZ60710601, 2025031, PD00055975, EAP3639420, AH3639420, EA3639420, AP5594929, PS3639420. Compatibility This replacement cooktop burner control knob fits select LG and Kenmore (LG-manufactured) gas cooktops and ranges. Commonly used on surface burner controls. Always verify your appliance’s model number before ordering.Contact our support team if you’re unsure. ✅ Key Features 🔄 Aftermarket Replacement – Matches original fit and appearance 🎛️ Smooth Flame Control – Restores accurate burner adjustment 🧩 Direct-Fit Design – Push-on installation for secure seating 💪 Durable Plastic Construction – Built for daily kitchen use 💰 Cost-Effective Repair – Affordable alternative to OEM knobs 📐 Product Specification Part Number: AEZ73293801 Component Type: Cooktop Burner Control Knob Material: High-strength molded plastic Color: Black (OEM-style) Mounting: Push-on / shaft-fit Application: Gas cooktop or range burner control Quality Level: Aftermarket replacement (not OEM) 🛠️ Installation Notes Tools Needed: None ⚠️ Safety First: Ensure the cooktop or range is turned off and cool before installing the knob. Basic Steps: Turn the burner control to the OFF position. Align the new XPARTCO AEZ73293801 knob with the control shaft. Press firmly until fully seated. Rotate to confirm smooth operation. ⏱️ Time Required: Under 2 minutes 📦 Shop With Confidence 🚚 Free Shipping on All Orders ⚙️ Trusted Aftermarket Appliance Parts 🔄 30-Day Return Policy Restore safe, precise burner control in seconds — Add to Cart Now for a quick, budget-friendly fix!

Read more less
