Refrigerator Fan Motors, Condenser & Evaporator and Fan Blades

XPARTCO DA31-00334C Refrigerator Evaporator Fan Motor The XPARTCO DA31-00334C is an aftermarket replacement evaporator fan motor for Samsung bottom-mount and side-by-side refrigerators. This small brushless DC (BLDC) motor sits behind the freezer's rear panel, directly in front of the evaporator coil, and its job is to pull cold air off that coil and push it through the duct system into both the freezer and fresh food compartments. Without it circulating air, the coil itself keeps getting cold, but that cold air never reaches your food — the freezer may still work reasonably well since it sits closer to the coil, while the fresh food side drifts warmer and warmer since it depends entirely on ducted airflow from the back. Rated at 12V DC, 2.5W, 0.12A, running at approximately 1,870 RPM. As a brushless design, this motor has no physical brushes to wear out, so failure typically comes from a worn bearing that lets the blade wobble or bind, a winding that has burned out electrically, or a blade that has become jammed by a chunk of built-up frost or freezer debris. It directly replaces DA31-00287B, DA31-00334A, DA31-00305A, DA96-00968A, AP6803162, 3954921, AP5948644, PS9494284, EAP9494284, PS12590897, and EAP12590897. Also compatible with select Kenmore refrigerators built on the Samsung platform. Quick Answer The XPARTCO DA31-00334C Refrigerator Evaporator Fan Motor fixes Samsung bottom-mount and side-by-side refrigerators with uneven cooling, a fresh food compartment that's warmer than it should be, frost or ice buildup at the back or bottom of the freezer, or a grinding/buzzing noise from inside the cabinet. Brushless DC (BLDC) motor, 12V DC, 2.5W, 0.12A, ~1,870 RPM. Replaces DA31-00287B, DA31-00334A, DA31-00305A, DA96-00968A, AP6803162, 3954921, AP5948644, PS9494284, EAP9494284, PS12590897, EAP12590897. Verify your model number before ordering — Samsung uses several different evaporator fan motors, and this is not the same part as our DA81-06013A listing. Common Problems This Part Fixes Fresh food compartment running warmer than the freezer, or warmer than it used to Uneven temperatures between shelves or between the fresh food and freezer sides Frost or ice buildup accumulating at the back panel or bottom of the freezer Grinding, buzzing, or rattling noise coming from inside the refrigerator cabinet Noise that stops when the freezer door is opened and starts again once it's closed Freezer holding temperature reasonably well while the fresh food side drifts warm Fan blade that doesn't spin freely, or spins with noticeable wobble, when checked by hand Refrigerator running constantly as the compressor tries to compensate for poor air circulation Cross Reference Information Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item. Replaces Part Numbers This refrigerator evaporator fan motor directly replaces the following OEM and cross-reference part numbers: DA31-00334C, DA31-00287B, DA96-00968A, 12035GE-12M-YT, 12V DC 0.26A, ARES2120RA, Model # 12035GE-12M-YT, AP6803162, ASM1061854, EAP12590897, PD00075168, PS12590897. If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This evaporator fan motor is compatible with select Samsung bottom-mount and side-by-side refrigerators, and also fits select Kenmore refrigerators built on the Samsung platform. Note — not the same motor as DA81-06013A: Samsung uses several different evaporator fan motor designs across its refrigerator lineup. The DA31-00334C is a distinct part from our DA81-06013A listing, which is built for a different model family and has its own connector and mounting configuration. Fitting the wrong motor can result in a connector that won't mate with your wiring harness or a fan blade that doesn't clear the housing correctly. Always verify your full model number before ordering. Contact our support team with your model number if you're unsure which motor fits your refrigerator. Key Features Brushless DC (BLDC) evaporator fan motor — no brushes to wear out over time Circulates cold air from the evaporator coil throughout the freezer and fresh food compartments Resolves "fresh food too warm," "uneven cooling," "frost buildup," and "grinding or buzzing noise" symptoms caused by fan motor failure Rated 12V DC, 2.5W, 0.12A, approximately 1,870 RPM Direct drop-in replacement matching the original mounting bracket and blade fitment Replaces DA31-00287B, DA31-00334A, DA31-00305A, DA96-00968A, AP6803162, 3954921, AP5948644, PS9494284, EAP9494284, PS12590897, and EAP12590897 Compatible with select Samsung and Kenmore (Samsung-platform) refrigerators Aftermarket replacement built to OEM-equivalent quality standards Product Specifications Part Number XPDA31-00334C OEM Part Number DA31-00334C Part Type Refrigerator Evaporator Fan Motor Condition Aftermarket Replacement Brand Samsung Motor Type Brushless DC (BLDC) Voltage 12V DC Wattage 2.5 W Amperage 0.12 A Speed ~1,870 RPM Application Bottom-Mount and Side-by-Side Refrigerators Quantity 1 fan motor Compatible Brands Samsung, select Kenmore Installation Notes ⚠️ Unplug Refrigerator Before Starting — Let The Freezer Thaw If Iced Over Disconnect power at the outlet before beginning, and remove all food from the freezer to a cooler for the duration of the repair. Wear work gloves. Access is through the freezer's rear interior panel: remove the shelving and bins as needed, then remove the screws securing the back panel and set it aside to expose the evaporator coil and fan assembly. If you see significant frost or ice buildup around the fan or coil, let the unit sit unplugged with the door open for a few hours (or run a manual defrost) before continuing, since ice can be masking the actual point of failure and can also make the old motor difficult to remove cleanly. Photograph the wiring harness connector and the fan blade's orientation before disconnecting anything. Unplug the motor's wiring harness connector, remove the mounting screws or clips holding the motor bracket in place, and carefully pull the motor and fan blade assembly free — on many models the blade is a separate piece that pulls off the motor shaft. Transfer the fan blade to the new motor if it isn't included, or install the new blade supplied with this motor, matching the original orientation. Mount the new DA31-00334C in the same position, reconnect the wiring harness connector fully, and confirm the blade spins freely by hand without contacting the housing before reassembling the back panel. Restore power and monitor both compartments over the next 24 hours to confirm even cooling has returned. Tools needed: Phillips screwdriver, nut driver, work gloves. Frequently Asked Questions My freezer seems fine but the fresh food section is warm. Is this really the fan motor? Yes, this is a very common and telling symptom pattern. The freezer compartment sits right next to the evaporator coil and can stay reasonably cold through simple proximity even with poor air circulation, but the fresh food compartment depends entirely on the fan pushing cold air through the ducting to reach it. When the fan motor fails or slows down, the fresh food side is usually the first and most noticeably affected area, while the freezer may seem to lag only slightly behind. I hear a grinding or buzzing noise that stops when I open the freezer door. What does that mean? This is a classic symptom of a worn fan motor bearing or a blade that's catching on built-up frost. Opening the door often triggers the refrigerator's internal light switch or door sensor, which can cut power to the fan momentarily — the noise stops because the fan stops spinning, then resumes once the door closes and the fan restarts. If you can see or reach the fan blade with the freezer open, check whether it spins freely and smoothly by hand; a blade that wobbles, binds, or contacts the housing points to the motor as the cause. There's a lot of frost around the back panel of my freezer. Should I fix that before replacing the fan? It's worth understanding which came first. Excess frost can be a cause of fan failure — a jammed blade can burn out the motor over time — or a result of it, since poor air circulation lets moisture condense and freeze unevenly around the coil area. Either way, thawing the ice out fully before you install the new motor makes the repair easier and lets you confirm the blade spins freely once everything is defrosted, rather than immediately jamming again on refrozen ice. Do I need to transfer the fan blade from my old motor? It depends on what's included with your specific order — check whether a blade came with your new motor before removing the old one. If a blade is not included, the blade from your original motor typically pulls off the shaft and can be transferred over. Photograph the blade's orientation on the shaft before removing it so you can reinstall it the same way; an improperly oriented blade can affect airflow or contact the housing. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Samsung OEM part, but is manufactured to match the electrical specifications (12V DC, 2.5W, 0.12A, ~1,870 RPM), brushless motor design, and mounting configuration of the original DA31-00334C evaporator fan motor used in compatible Samsung and Kenmore refrigerators. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Quality Aftermarket Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout

Read more less

5304532557 Refrigerator Genuine Evaporator Motor Replaces Part Numbers: 5304532557, 242077707, AP7194947, PS16745551. Description: This Part is a Genuine OEM refrigerator evaporator fan motor compatible with specific Electrolux, Frigidaire refrigerator models. The fan motor is a vital component of your refrigerator. It is designed to maintain cold temperatures by circulating air through the fresh food compartments. By doing so, it ensures uniform cooling within the refrigerator. This helps to prevent warm spots that can lead to frost build-up.

Read more less

WR60X31522 Genuine OEM GE Refrigerator Evaporator Fan Motor The WR60X31522 is a Genuine OEM GE replacement evaporator fan motor compatible with select GE, Hotpoint, RCA, and Americana top-mount freezer refrigerators. The evaporator fan motor is located at the back of the freezer compartment and circulates air across the evaporator coils — converting the heat from the air into cool air that's then distributed throughout both the freezer and fresh food sections. Without a properly functioning evaporator fan, the refrigerator can't move cold air where it's needed, causing the fresh food and/or freezer sections to warm up, ice to build up on the coils, and the compressor to run continuously trying to compensate. This 115V AC motor is rated at 60Hz, 3.3W and uses a 2-pin connector plus ground wire. Dimensions are 3-1/4"L x 2-3/8"W x 3-3/8"H, with a harness and plug extending approximately 3-1/2" from the motor. Construction is plastic and metal in marbled white & gray. Note: this listing is for the motor with harness only — the fan blade may need to be transferred from the old motor. It directly replaces WR60X10045, WR60X10046, WR60X10072, WR60X10138, WR60X10141, WR60X10346, WR60X23584, WR60X27646, WR60X28783, WR60X28784, WR60X31122, WR60X31523, 4959523, 197D2038P031, AP6977246, EAP12741350, PD00062864, and PS12741350. Installs in 30–45 minutes with basic hand tools. Quick Answer The WR60X31522 Genuine OEM GE Refrigerator Evaporator Fan Motor fixes GE, Hotpoint, RCA, and Americana top-mount freezer refrigerators that aren't cooling properly, have heavy frost buildup on the evaporator coils, run continuously, or are noisy from the freezer compartment. 115V AC, 60Hz, 3.3W. 2-pin connector + ground wire. 3-1/4"L x 2-3/8"W x 3-3/8"H. Marbled white & gray. Replaces WR60X10045, WR60X10046, WR60X10072, WR60X10138, WR60X10141, WR60X10346, WR60X23584, WR60X27646, WR60X28783, WR60X28784, WR60X31122, WR60X31523, 4959523, 197D2038P031, AP6977246, EAP12741350, PD00062864, PS12741350. Common Problems This Part Fixes Refrigerator fresh food and/or freezer sections not cooling properly Heavy frost or ice buildup on the evaporator coils ("Antarctica" frost) Loud whining, grinding, or scraping noise from the freezer compartment Fan blade not spinning when checked by hand or stiff/seized rotation Refrigerator running continuously trying to maintain temperature Compressor running but cool air not being circulated Motor failing continuity test with a multimeter Visible damage to the fan motor or its harness Replaces Part Numbers This evaporator fan motor directly replaces the following OEM and cross-reference part numbers: WR60X31522, WR60X23584, WR60X10141, WR60X10346, WR60X28783, WR60X10045, WR60X10046, WR60X10072, WR60X10138, WR60X27646, WR60X28784, WR60X31122, AGE29819, 115V-60Hz 3.3W, 197D2038P031, FDQR002GSL, PD00062864, AP6977246, PS12741350. If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This evaporator fan motor is compatible with select GE, Hotpoint, RCA, and Americana refrigerators, typically top-mount freezer units: GE top-mount refrigerators (select models) GE Profile and Café refrigerators (select models) Hotpoint refrigerators (select models) RCA refrigerators (select GE-built models) Americana refrigerators (select GE-built models) Note: Some refrigerator models have two evaporator fan motors — one in the fresh food section and one in the freezer section. The WR60X31522 is typically the freezer-section evaporator fan motor on top-mount style refrigerators. Confirm the failed motor's location and that the WR60X31522 part number matches your refrigerator's parts diagram before ordering. Always verify your appliance model number first. Key Features Evaporator fan motor for the freezer compartment of compatible GE/Hotpoint top-mount refrigerators Pulls air through the evaporator coils to remove heat and circulate cool air throughout the refrigerator 115V AC, 60Hz, 3.3W — correct electrical specifications for compatible GE-platform refrigerators 2-pin connector plus ground wire — direct plug-in installation with the included harness Dimensions: 3-1/4"L x 2-3/8"W x 3-3/8"H; harness and plug extend approximately 3-1/2" from the motor Marbled white & gray plastic and metal construction Replaces 18 OEM and aftermarket cross-reference part numbers including WR60X10045, WR60X10141, WR60X23584, WR60X27646, WR60X28783, WR60X31122, and PS12741350 Compatible with GE, Hotpoint, RCA, and Americana refrigerators (top-mount freezer units) Genuine OEM part manufactured by GE to factory specifications — guaranteed fit and performance DIY repair — installs in 30–45 minutes with basic hand tools Product Specifications Part Number WR60X31522 Part Type Refrigerator Evaporator Fan Motor (Freezer Section) Condition Genuine OEM Application Top-Mount Freezer Refrigerators (GE platform) Voltage 115V AC Frequency 60 Hz Wattage 3.3W Connector 2-pin connector plus ground wire Dimensions 3-1/4"L x 2-3/8"W x 3-3/8"H Harness Length Approximately 3-1/2" from motor Color Marbled White & Gray / Gray Material Plastic / Metal Includes Evaporator fan motor with harness and plug (fan blade may need to be transferred from old motor) Compatible Brands GE, Hotpoint, RCA, Americana Installation Notes ⚠️ Unplug Refrigerator and Move Perishable Food Before Starting — Wear Work Gloves Unplug the refrigerator and safely store any food that could spoil while the power is off. Wear work gloves to protect your hands. The evaporator fan motor is located at the back of the freezer compartment, behind an interior access panel. Remove the freezer shelves and any internal components blocking access to the rear panel. Remove the screws holding the rear access panel in place to expose the evaporator coils and fan motor. Photograph the wire connections and fan blade orientation before disconnecting. Disconnect the 2-pin wire harness connector and the ground wire from the old motor. Note the orientation of the fan blade on the motor shaft — the blade typically presses onto the shaft and may need to be transferred to the new motor. Remove the mounting screws or release the motor from its mounting bracket, and pull the old motor free. Carefully transfer the fan blade to the new WR60X31522 motor in the same orientation (or use a new blade if you have one). Install the new motor in the same position, reconnect the wire harness and ground wire, and reinstall the access panel and shelves. Plug the refrigerator back in and allow several hours for the unit to return to its set temperature before reloading with food. Tools needed: Phillips screwdriver, 1/4" nut driver, work gloves. Frequently Asked Questions How do I know if the evaporator fan motor has failed? The most common symptoms are: the refrigerator or freezer is warmer than its set temperature even though the compressor sounds like it's running normally; heavy frost or ice buildup on the evaporator coils behind the freezer access panel ("Antarctica" frost); and loud whining, grinding, or scraping noise from the freezer area. To confirm: unplug the refrigerator, remove the rear freezer access panel, and try turning the fan blade by hand. If it doesn't spin freely or is stiff/seized, the motor bearing has failed. You can also test for motor continuity with a multimeter — no continuity confirms electrical failure. My refrigerator has two evaporator fans — which one does this replace? Some refrigerator models have two evaporator fan motors — one in the fresh food section and one in the freezer section. The WR60X31522 is typically the freezer-section evaporator fan motor on top-mount style GE and Hotpoint refrigerators. If your symptom is "freezer not cooling properly" or "frost on freezer coils," this is the correct part. If your symptom is specifically "fresh food section warm while freezer is fine" on a French door refrigerator, you may need a different fan motor — contact our support team with your model number to confirm. Does this motor come with the fan blade? No — the WR60X31522 listing is for the motor with harness and plug only. The fan blade is typically transferred from the old motor: carefully pull it off the old motor shaft (it presses on, no hardware needed), and press it onto the new motor shaft in the same orientation. If your old fan blade is damaged or cracked, it should be replaced separately. Installing the blade in the wrong direction will reverse the airflow and reduce cooling performance. What's the difference between the WR60X31522 (115V AC) and DC motors like the WR60X10209 or WR60X26866? GE refrigerators use different fan motor technologies across model generations. The WR60X31522 is a 115V AC motor with a 2-pin connector plus ground — used in many GE and Hotpoint top-mount freezer refrigerators. The WR60X10209 and WR60X26866 are DC voltage motors (around 11–14V DC) used in newer GE French door refrigerators with electronic control boards that supply variable DC voltage for energy-efficient variable-speed fan operation. These are not interchangeable — always verify the correct part number for your specific refrigerator model before ordering. Is this an OEM or aftermarket part? This is a Genuine OEM part manufactured by GE to factory specifications. It is the exact same evaporator fan motor installed in compatible GE, Hotpoint, RCA, and Americana refrigerators from the factory — guaranteed fit, materials, and performance. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Fast US Shipping ✓ Genuine OEM Parts ✓ Compatibility Support ✓ Secure Checkout

Read more less

XPARTCO DA97-15765C Refrigerator Condenser Fan Motor The XPARTCO DA97-15765C is an aftermarket replacement condenser fan motor assembly for Samsung French door refrigerators. This assembly includes both the motor and the fan blade together, and it lives in the compressor/machine compartment at the back or bottom of the refrigerator, where its job is to pull air across the condenser coils and compressor to carry heat away from the refrigeration system. That's a different job from an evaporator fan — this motor cools the mechanical side of the system rather than circulating cold air to your food, so a failing condenser fan tends to affect the whole refrigerator's cooling capacity rather than just one compartment. Rated 12V DC, 0.14A, 1.7W, running at approximately 1,120 RPM. On many Samsung models, a failed condenser fan motor triggers a 23C or 23E error code on the display, alongside symptoms like noticeable vibration or noise from the condenser area, elevated internal temperatures, or the over-temperature alarm sensor tripping. Common causes include normal wear on the motor bearings after prolonged use, blockages from dust and debris accumulation around the coils, or damage from moisture exposure. A fan blade that tries to spin but can't complete a full revolution, or that needs a manual nudge to keep turning, is a classic sign this assembly has started to fail. It directly replaces DA97-15765A, DA97-12842A, DA97-12842B, DA97-12842D, DA97-15765D, AP6001015, PS11733650, EAP11733650, DA31-00340A, RMF002ASSA, and 4959328. Quick Answer The XPARTCO DA97-15765C Refrigerator Condenser Fan Motor fixes Samsung French door refrigerators where the whole unit runs warm, the compressor area is noisy or vibrating, a 23C or 23E error code appears, or the over-temperature alarm trips. Includes motor and fan blade. 12V DC, 0.14A, 1.7W, ~1,120 RPM. Replaces DA97-15765A, DA97-12842A, DA97-12842B, DA97-12842D, DA97-15765D, AP6001015, PS11733650, EAP11733650, DA31-00340A, RMF002ASSA, 4959328. This cools the compressor and condenser coils — a different part and symptom pattern than an evaporator fan, which only affects internal air circulation to the food compartments. Common Problems This Part Fixes Both the fresh food and freezer compartments running warmer than normal at the same time 23C or 23E error code displayed on the control panel Noticeable vibration or unusual noise from the condenser/compressor area at the back or bottom of the cabinet Over-temperature alarm sensor tripping Fan blade that tries to spin but doesn't complete a full revolution Fan blade that stops spinning if not manually nudged to keep turning Refrigerator running constantly as the compressor struggles to keep up Excessive dust or debris buildup visible around the condenser coils and fan Cross Reference Information Part numbers can change over a product's lifecycle as manufacturers update designs or release new appliance models. For your convenience, we've included any known superseded, alternate, or cross-reference part numbers that match this item. Replaces Part Numbers This refrigerator condenser fan motor assembly directly replaces the following OEM and cross-reference part numbers: DA97-15765C, DA97-15765A, DA97-15765D, DA97-12842A, DA97-12842B, DA97-12842D, AP6001015, PS11733650, EAP11733650, DA31-00340A, RMF002ASSA, 4959328, OEM18003054, ASM138992, PD00050574 If your part number is not listed above, contact our support team before ordering and we will verify compatibility. Compatibility This condenser fan motor assembly is compatible with select Samsung French door refrigerators, including model numbers such as: RF220NCTABC, RF220NCTASG, RF220NCTASP, RF220NCTASR, RF220NCTAWW RF221NCTABC, RF221NCTASP, RF221NCTAWW RF22K9381SG F261BEAESR This assembly also fits many additional Samsung French door refrigerator models beyond those listed above. Note — condenser fan, not evaporator fan: This motor cools the compressor and condenser coils in the machine compartment at the back or bottom of the refrigerator. It is a completely different part from an evaporator fan motor (such as our DA31-00334C listing), which sits behind the freezer's rear panel and circulates cold air to the food compartments. It is also a different part family from our DA97-20025A condenser fan listing, which serves a different group of Samsung models. Always verify your full model number before ordering. Contact our support team with your model number if you're unsure which fan motor your refrigerator needs. Key Features Complete assembly — includes both the motor and the fan blade Aftermarket replacement condenser fan motor — draws air across the condenser coils and compressor to remove system heat Resolves "whole fridge running warm," "23C or 23E error code," "noise or vibration from the compressor area," and "over-temperature alarm" symptoms caused by fan failure Rated 12V DC, 0.14A, 1.7W, approximately 1,120 RPM Direct drop-in replacement matching the original mounting and back panel cam-bracket attachment Replaces DA97-15765A, DA97-12842A, DA97-12842B, DA97-12842D, DA97-15765D, AP6001015, PS11733650, EAP11733650, DA31-00340A, RMF002ASSA, and 4959328 Aftermarket replacement built to OEM-equivalent quality standards DIY-friendly repair — typically completed in under an hour Product Specifications Part Number DA97-15765C OEM Part Number DA97-15765C Part Type Refrigerator Condenser Fan Motor Assembly (Motor + Blade) Condition Aftermarket Replacement Brand Samsung Location Compressor/machine compartment (back or bottom of cabinet) Function Cools the condenser coils and compressor Voltage 12V DC Amperage 0.14 A Wattage 1.7 W Speed ~1,120 RPM Related Error Codes 23C, 23E Quantity 1 fan motor assembly Compatible Brand Samsung Installation Notes ⚠️ Unplug Refrigerator Before Starting — Store Perishable Food Separately Disconnect power at the outlet before beginning, and move perishable food to a cooler for the duration of the repair. Wear work gloves. Remove all shelves from the upper refrigerator cabinet to improve access. Using a flat-blade screwdriver, gently ease the back panel away from the cabinet — on many models it's retained by a cam bracket and snaps into place, so it should release without excessive force. This exposes the condenser/circulating fan. Before condemning the motor, clear away any dust, lint, or debris built up around the condenser coils and fan blade — restricted airflow from a dirty coil produces symptoms similar to a failing motor and costs nothing to rule out. Photograph the wiring harness connector and the fan blade's position before disconnecting anything. Remove the two screws holding the fan in place, unplug the fan lead harness connector, and remove the defective fan assembly. Install the new DA97-15765C in the same position, reconnect the harness plug, and reinstall and tighten the two mounting screws securely. Confirm the blade spins freely by hand without contacting the housing or coils before reinstalling the back panel — it should snap back into place via the cam bracket. Reinstall the shelves, restore power, and monitor the refrigerator over the next 24 hours to confirm normal, even cooling has returned and any error code has cleared. Tools needed: flat-blade screwdriver, Phillips screwdriver, work gloves. Frequently Asked Questions My display shows a 23C or 23E error code. Does that mean I need this part? It's a strong indicator on many Samsung models, since these codes are commonly associated with condenser fan motor failure. Before ordering, it's still worth a quick visual check — clear any dust or debris from around the condenser coils and fan blade, since a heavily clogged condenser can sometimes trigger similar temperature-related codes. If the error persists after cleaning, or if the fan blade doesn't spin freely by hand, this assembly is the likely fix. The fan blade tries to spin but won't complete a full turn. Is that normal? No — this is a classic sign the motor bearings are wearing out or that something is obstructing the blade. A healthy condenser fan should spin freely and continuously once started. If you find yourself needing to give the blade a manual nudge to keep it turning, or it stalls partway through a rotation, the motor has failed and needs to be replaced rather than repeatedly restarted by hand. Both my fresh food and freezer sections are warm. Is this the right part? Yes, that pattern points toward the condenser fan rather than an evaporator fan. Because the condenser fan cools the compressor and coils that the entire refrigeration cycle depends on, a failing condenser fan tends to reduce cooling capacity across both compartments together, rather than leaving one side fine while the other struggles. Does this include the fan blade, or just the motor? This is a complete assembly that includes both the motor and the fan blade together, so there's no need to transfer a blade from your old unit or source one separately. Is this an OEM or aftermarket part? This is an aftermarket replacement part built to OEM-equivalent quality standards. It is not a genuine Samsung OEM part, but is manufactured to match the electrical specifications (12V DC, 0.14A, 1.7W, ~1,120 RPM), fan blade design, and mounting configuration of the original DA97-15765C condenser fan motor assembly used in compatible Samsung French door refrigerators. Shop With Confidence A U.S.-based appliance parts retailer specializing in genuine OEM and high-quality replacement parts. We stock components for all major appliance brands and offer fast shipping from our U.S. warehouse. Our team is available to help verify compatibility before you purchase. ✓ Quality Aftermarket Parts ✓ Fast US Shipping ✓ Compatibility Support ✓ Secure Checkout

Read more less

4681JB1029D Refrigerator Genuine OEM Condenser Fan Motor Fits Specific LG, Kenmore Refrigerator Models Replaces Part Numbers: 4681JB1029D, EAU61644104, 1267566, AH3523330, EA3523330, OEM17751134, AP4437783, PS3523330. Description: This Condenser Fan Motor is a Genuine part for specific LG, Kenmore refrigerator models. This motor is responsible for powering the fan that cools the condenser coils, which helps dissipate heat from the refrigerator. Proper functioning of the condenser fan motor is crucial for maintaining the efficiency and cooling performance of the refrigerator. California Residents only WARNING: Cancer and/or Reproductive Harm - www.p65warnings.ca.gov

Read more less

WP2315548 Refrigerator Genuine Evaporator Fan Motor  Replaces Part Numbers: WP2315548, 2315548, 1194733, 2220149, AP6007249, PS11740361. Description: The Evaporator Fan Motor is a Genuine OEM part for specific Whirlpool, Maytag refrigerator models. It is responsible for circulating cold air within the fridge and freezer compartments, helping to maintain even temperatures and keep food fresh. Causes of a bad evaporator fan motor include failure due to normal wear and tear over time, damage due to improper cleaning, or issues with the motor's electronic components.

Read more less
